metal architectural systems

(1)

(2)

Every building has a story to tell –

a character in its own environment,

reflecting a unique and carefully

considered design. And the building

envelope – whether bold, sleek, edgy,

or classic – introduces that story, gives

it cover, and invites the outside in.

Metal Sales roof and wall systems

offer the design versatility to make

a remarkable impression. Metal Sales

quality products come in a variety of

profiles, widths, and gauges. They

can be curved, perforated, and color

coated to any desired look – limited

only by your imagination.

For discriminating architects, owners,

and contractors, looks are just one reason

to specify Metal Sales. Equally important,

these systems are materially efficient,

durable, and virtually maintenance-free.

Metal Sales is the premier provider of

metal envelope systems with nationwide

manufacturing, sales, and distribution

facilities. This means that no matter

where you’re building, Metal Sales

is always nearby to provide expert

technical support and field service

24/7. And with leading warranties,

extensive product testing, and

real-world applications, Metal Sales

ensures ultimate life-cycle performance.

A building envelope from Metal Sales

offers the inspired introduction to an

engaging story – how will you tell yours?

2

i n sp i r i n g

Formosa 1140 West Hollywood, CA

Architect: Lorcan O’Herlihy Architects Profile: T16-E Wall

COVER PHOTO

Arizona State University Walter Cronkite School of Journalism and Mass Communication Phoenix, AZ

Architect: HDR Architecture, Ehrlich Architects Profile: T23 Wall

(3)

More ChoiCes,

More LoCations,

More ConvenienCe

More choices means more possibilities. That’s

why building professionals turn to Metal Sales

for the most ambitious metal roof and wall

solutions. We’re committed to giving you more

to help you create your inspired design.

With 21 locations nationwide and the largest

sales and service team in the industry, we

provide superior customer support, the widest

product selection, unmatched value, and the

most efficient delivery.

Our broad range of metal roof and wall products –

from industry classics to exotic, edgy profiles – are

designed to satisfy any aesthetic objective. To

help you achieve your vision, the Metal Sales

design assistance team works closely with you

to find solutions to your unique challenges.

We deliver a wealth of technical information

built from 50 years of American manufacturing

experience to make the design and specification

process as easy and convenient as possible.

Metal Sales products are manufactured reliably

and tested rigorously to meet the needs of high-

performance buildings. And with knowledgeable

and responsive sales and installation support,

you can be confident in the success of your

project from start to finish.

Explore the possibilities with Metal Sales.

Get to know our extensive product and system

offerings, straightforward retrofit solutions,

high-performance coating and material options,

company-wide commitment to sustainability,

and unparalleled technical support. Begin your

next project with more choices – inspired by

Metal Sales.

Page

Roof

Wall Soffit

STAnDing SEAM ROOF SySTEMS

5

Magna-Loc

5

Curved Magna-Loc 180

6

Vertical Seam

6

Seam-Loc 24

®

6

Snap-Loc 24

7

Mini-Batten

7

image ii

™

COnCEALED FASTEnER FLUSH FACE WALL SySTEMS

9

TL-17 Series

9

TL-1222

10

TLC Series

11

Soffit

ExPOSED FASTEnER ROOF & WALL SySTEMS

13

iC72-Panel

13

7/8” Corrugated

14

T10

14

T13

15

T16-E

15

T2630

16

T2832

16

TDR-6

17

T23

17

T25

(4)

seam roof system

s t a n d i n g

24

Metal Sales standing seam systems

deliver clean, linear elegance paired

with unmatched quality for a dependable,

long-lasting, and beautiful roof. Our

multiple system offerings are designed

to meet any aesthetic preference,

performance requirement, or budget.

Structural Standing Seam roof systems

are ideal for lower sloping and longer

spanning roofs, or where extreme

temperature variations exist. They

are installed over open framing.

• Thicker gauge substrate for superior

structural strength and durability

• May be installed directly onto open

purlins and serve as a work platform

for the installation crew, resulting in

a fast, efficient, and easy installation

• Installed with concealed clips to

allow for thermal movement

• Accommodate blanket insulation

for enhanced thermal efficiency

• Highest wind, fire, and impact

resistance of any roof option

Economical standing seam options

are also available. These have higher

slope requirements and are installed

over a solid substrate.

This catalog includes the most popular

profiles. For additional options visit

www.metalsales.us.com.

Silver Oak Cellars napa Valley Winery Oakville, CA

Architect: Taylor Lombardo Architects, LLP Profile: Vertical Seam Roof

(5)

Magna-Loc / Magna-Loc 180

Curved Magna-Loc 180

• Structural standing seam roof system • Panel coverages: 16" or 18"

• Rib height: 2"

• Gauges: 24 ga. standard, 22 ga. optional • Minimum roof slope: 1/2:12

• Factory-applied side lap sealant • Mechanically seamed side lap

• Concealed clip designed for thermal movement • Accommodates 1/2" to 6" blanket insulation • Applies over open framing or solid substrate

• Finishes: PVDF (Kynar 500®_{) and Acrylic Coated galvalume}®

• Contact Metal Sales for load carrying capabilities

16" or 18" Coverage Factory-Applied Sealant 2" 2" 2" Factory-Applied Sealant Factory-Applied Sealant Flat Pan with Pencil Ribs

with Striations 16" or 18" Coverage 16" or 18" Coverage Factory-Applied Sealant Factory-Applied Sealant Factory-Applied Sealant 16" or 18" Coverage 2" 2" 2" Flat Pan with Pencil Ribs

with Striations 16" or 18" Coverage 16" or 18" Coverage Factory-Applied Sealant Factory-Applied Sealant 16" Coverage 2" with Striations

• Structural standing seam roof system • Panel coverage: 16”

• Rib height: 2”

• Minimum radius: 20’-0” • Gauge: 24 ga. standard • Pre-applied side lap sealant • Mechanically seamed side lap

• Concealed clip designed for thermal movement

Magna-Loc

(6)

• Structural standing seam roof system • Panel coverage: 24”

• Factory-applied side lap sealant • Snap together panel system

• Concealed clip designed for thermal movement • Accommodates 1/2” to 6” blanket insulation • Applies over open framing or solid substrate

• Contact Metal Sales for load-carrying capabilities • Structural standing seam roof system

• Panel coverages: 24” or 18” • Rib height: 2-11/16”

• Factory-applied side lap sealant

• Pittsburgh double flat locking mechanically seamed side lap • Concealed clip designed for thermal movement

• Accommodates 1/2” to 6” blanket insulation • Applies over open framing or solid substrate

• Contact Metal Sales for load carrying capabilities • Structural standing seam roof system

• Panel coverages: 12”, 16”, or 18” • Rib height: 1-3/4”

• Gauges: 26 ga. and 24 ga. standard, 22 ga. optional • Snap-together panel system with factory-applied

side lap sealant

• Minimum roof slope over open framing 3:12 • Minimum roof slope over solid substrate 1:12

• Concealed clip designed for unlimited thermal movement • Accommodates up to 4” blanket insulation

• Contact Metal Sales for load carrying capabilities

24" Coverage 2-11/16" 18" Coverage 2-11/16" Factory-Applied Sealant Factory-Applied Sealant 24" Coverage 3"

Factory Applied Sealant

26

Snap-Loc 24

Seam-Loc 24®

Vertical Seam

12",16" or 18" Coverage 1-3/4" 12",16" or 18" Coverage 1-3/4" Factory-Applied Sealant Factory-Applied Sealant Flat Pan with Striations

(7)

Image II™

Mini-Batten

12" 16" or 18" Coverage 1" 12" 16" or 18" Coverage 1-1/2"

• Concealed direct-fastened roof system • Panel coverages: 12” or 16”

• Gauge: 24 ga. standard , 26 ga. optional • Minimum roof slope: 3:12

• Applies over solid substrate with 30# felt underlayment • Finishes: PVDF (Kynar 500®_{) and Acrylic Coated gavalume}®

• Contact Metal Sales for load-carrying capabilities • Standing seam roof system

• Panel coverages: 12”, 16”, or 18”

• Rib height: 1” and 1-1/2” utilizing a narrow batten cap • Gauges: 24 ga. standard, 22 ga. optional

• Minimum roof slope: 3:12

• Curved and tapered capability available for 1” Mini-Batten – Minimum radius: 4’-0” pan and batten

• Concealed clip designed for thermal movement • Applies over solid substrate with 30# felt underlayment • Finishes: PVDF (Kynar 500®_{) and Acrylic Coated galvalume}®

• Contact Metal Sales for load-carrying capabilities

12" or 16" Coverage 1" 16" Coverage 1" 1" 12" Coverage with Striations

with Minor Ribs

(8)

28

Concealed fastener wall systems from

Metal Sales provide a high-performance,

weathertight, and sleek exterior option.

Designers often choose this system

for a clean aesthetic, absent of visible

fasteners. Panel profiles in this category

are made in series, designed for mixing

and matching to create an infinite

variety of wall configurations. Several

panels have flat faces. All others feature

box-shaped ribs and/or reveals of

varying widths. These panels may be

installed either horizontally or vertically

and make for an excellent rainscreen

in back-ventilated wall design.

This catalog includes the most popular

fastener

wall systems

co n ce a l e d

Grand Canyon University

Phoenix, AZ Architect: Architekton Profiles: TLC-1 Wall

(9)

TL-17 Series

• Concealed direct-fastened panel for wall, soffit, fascia, or liner applications

• Applies over open framing or solid substrate • Panel coverages: 12” and 18”

• Panel depth: 1-1/2” • 22’-0” maximum length

• Optional material: stainless steel, aluminum, and copper • Gauges: 24 ga. standard, 22 ga., 20 ga., and 18 ga. optional • Custom capabilities include:

– Perforated panels for wind screens and liner panels • Standard Finish: PVDF (Kynar 500®₎

• Optional Finishes: Multi-pass PVDF, Print Coat Systems, Plastisol, and Polyester

12" Coverage 1-1/2" TL-17 12" Coverage 1-1/2" 4" TL-17C 12" Coverage 1-1/2" 6" TL-17A 12" Coverage 1-1/2" 1" TL-17D TL-1222 18" Coverage 1-1/2" TL-17 Wide 12" Coverage 1-1/2" 2" 2"

TL-1222

• Applies over open framing or solid substrate • Panel coverage: 12”

• Panel depth: 1-1/2”

• 25’-0” recommended maximum length

(10)

2

10

TLC Series

• Applies over open framing or solid substrate • Panel coverage: 12”

• Panel depth: 1-1/2” • 40’-0” maximum length*

• Optional material: stainless steel, aluminum, and copper • Gauges: 24 ga. standard, 22 ga. and 20 ga. optional • Custom capabilities include:

* Maximum length is limited only by the possibility of oil canning occurring at longer lengths. To minimize this potential, we recommend specifying 22 ga. or 20 ga. if a long length is desired. Please contact your Metal Sales representative for assistance.

12" Coverage 1-1/2" 12" Coverage 1-1/2" 12" Coverage 1-1/2" 12" Coverage 1-1/2" 12" Coverage 6" 1-1/2" 12" Coverage 6" 1-1/2" TLC-1 TLC-2 TLC-3 TLC-4 TLC-9 TLC-10

(11)

Soffit Panel

• Concealed direct-fastened system for wall, soffit, fascia, or liner applications

• Panel coverage: 12” • Panel Depth: 1”

• Gauge: 24 ga. standard and 0.032” aluminum • Applies over open framing or solid substrate

1" 12" Coverage 1" 12" Coverage Flat Pan with V-Grooves Proto Homes Baldwin Hills, CA Architect: Proto Homes Profile: TLC-1, T2, TL-1222 Wall

(12)

2

12

Metal Sales exposed fastener panels

offer designers the broadest range of

profiles, from corrugated to trapezoidal,

and box-shaped ribs of varying depths.

This provides a diverse palette for

unique textures, shapes, and shadow

lines. Panels in this category can be

used for roofing or installed either

vertically or horizontally for walls.

These panels may be curved or

perforated in highly customized ways

to meet the functional and aesthetic

needs of a building.

This catalog includes the most popular

fastener roof

& wall systems

ex p o s e d

UC San Diego East Campus Office Building San Diego, CA

Architect: gensler

(13)

IC72-Panel

7/8” Corrugated

• Exposed direct-fastened industrial panel for roof and wall applications

• Panel coverage: 36”

• Rib height: 1-1/2” at 7.2” centers • Minimum roof slope: 1:12

• Gauges: 24 ga. standard, 22 ga. and 20 ga. optional • Applies over open framing or solid substrate

36" Coverage

1-1/2"

7.2"

• Exposed direct-fastened panel for roof and wall applications • Panel coverages: 32” roof, 34-2/3” wall

• Rib height: 7/8” at 2-2/3” centers

• Gauges: 24 ga. standard, 22 ga. and 20 ga. optional • Optional material: stainless steel, aluminum, copper, and

weathering steel

• Custom capabilities include:

– Perforated panels for wind screen and liner panels • Minimum roof slope: 1:12

• Applies over open framing or solid substrate

2-2/3" 32" (Roof Coverage) 7/8" 2-2/3" 7/8" 34-2/3" (Wall Coverage) Wall Wall Roof Roof 36" Coverage 1-1/2" 7.2"

Perforated panels are an aesthetic design solution for windscreens, balcony railings, ventilation, and concealment

(14)

T10

• Exposed direct-fastened panel for roof, wall, soffit, fascia, and liner applications

• Applies over open framing or solid substrate • Panel coverage: 28”, 30”, and 36”

• Rib height: 1-1/2”

• 90° vertical box ribs on 4”, 6”, and 9”centers

2

14

24" Coverage 3" 6" C 24" Coverage 3" 8" C T13 T13-A

T13

• Exposed direct-fastened panel for roof and wall applications • Applies over open framing or solid substrate

• Panel coverage: 24” • Rib height: 3”

• Trapezoidal rib on 6” and 8” centers

• Optional material: stainless steel, aluminum, and copper • Gauges: 24 ga. standard, 22 ga., 20 ga., and 18 ga. optional • Minimum roof slope: 1:12

4" C 1-1/2" 28" Coverage 6" C 1-1/2" 30" Coverage 6" C 1-1/2" 30" Coverage 9" C 1-1/2" 36" Coverage T10-A T10-B T10-C T10-D

(15)

T16-E

• Panel coverage: 36” • Rib height: 3/4”

• Trapezoidal rib on 4-1/2” center

T2630

• Trapezoidal rib on 6” center

36" Coverage 4-1/2" C 3/4" 30" Coverage 2" 6" C

(16)

2

16

T2832

TDR-6

• Panel coverage: 18” • Rib height: 4-1/2”

32" Coverage 2" 8" C 18" Coverage 4-1/2" 6" C

(17)

T23

• Panel coverge: 32” • Rib height: 3”

T25

V-Line 32

• Panel coverage: 32” • Rib height: 1-3/8”

• Trapezoidal rib on 4-9/16” center

• Gauges: 24 ga. standard, 26 ga. and 22 ga. optional • Minimum roof slope: 1:12

C 32" Coverage 8" 3" 24" Coverage 4" C 12" C 32" Coverage 4-9/16" 1-3/8"

(18)

2

18

re t ro f i t

Charlotte Wood Middle SchoolDanville, CA

Profile: Magna-Loc Roof

Slope added to existing flat roof. The U.S. green Building Council reports that a majority of all

construction projects are retrofits and expects this trend to increase in the coming years. When your project calls for roof replacement to correct a failed system, increase wind load capabilities, or enhance aesthetic design, metal is the ideal platform for an integrated roof solution.

soLutions for existing fLat or sLoped roofs

Flat roofs are notoriously challenging. They leak, absorb and hold heat, and require frequent and costly maintenance. Whereas sloped Metal Sales roofs provide superior storm water runoff capabilities for a durable, weathertight, and energy efficient solution to last for decades.

With Metal Sales roofing retrofit systems, you can easily convert any flat roof to a sloped metal roof. The system includes heavy gauge steel framing to create the solid structure for the new roof, leaving the existing roof intact. This same system is also an excellent choice for retrofitting existing sloped roofs.

Choose from a variety of Metal Sales panel profiles for a system engineered and tested to meet or exceed the most stringent code requirements in north America for fire, impact, wind uplift, and snow loads.

When you retrofit your roof with Metal Sales, you extend the service life of your building.

opportunities for energy effiCienCy upgrades

Retrofit roofing offers the opportunity to add insulation to increase the building’s R-value or integrate a convective cooling system to reduce heat gain in the summer and heat loss in the winter.

renewabLe energy integration CapabiLities

The long service life of a durable Metal Sales roof system also provides an ideal platform for photovoltaic assemblies or wind microturbines, as compared to less permanent roof options that aren’t built to sustain the lifespans of renewable technologies. And for innovative rainwater catchment designs, metal is the preferred architectural material.

(19)

Metal Sales offers a wide variety of color

choices with our high performance PVDF

1

coating system. This system features

multi-layer protection and is warranted for

long lasting durability and chalk and fade

resistance.

Meet or exCeed Codes and standards

incorporating advancements in coating

technology, the energy performance

characteristics of Metal Sales finishes and

colors meet demonstrated requirements

established by EnERgy STAR

®

and the

Cool Roof Rating Council (CRRC) for solar

reflectance and thermal emittance for

steep sloped and/or low sloped buildings.

They may also comply with LEED

®

and

green globes rating requirements for

steep slope solar reflectance index (SRI).

2

benefits of CooL CoLors

Choose from a palette of light neutrals to

dark saturated colors to achieve your vision

while helping the environment. Cool roofs may

also contribute to strategies for optimizing

energy performance. Energy savings and

other direct benefits are contingent upon

building type, location, and use.

systems

materials

co at i n g

s u b s t rate

Metal Sales offers the most durable of substrate

materials available in steel, stainless steel,

weathering steel, copper, and aluminum.

Contact a Metal Sales representative for

Topcoat Exceptional color duarability and gloss retention Back coat Covers primer and ensures consistent color Primer Corrosion resistance and bonding Primer Pretreatment Adhesion, moisture and corrosion protection

Pretreatment Galvanized or Galvalume®

Inhibits corrosion

Galvanized or Galvalume®

Bare Steel

Mill certified to meet ASTM standards

1 _{PVDF is at least 70% Kynar 500® or Hylar 5000}

2 _{Contact Metal Sales or visit www.metalsales.us.com for a}

complete listing of finishes and colors, their energy performance characteristics, and compliance per organization’s requirements.

Steep Sloped Building Low Sloped Building Roof slope > 2:12 Roof slope ≤ 2:12

EnERgy STAR® _{initial Solar Reflectance}_≥_0.25 _{initial Solar Reflectance}_≥_0.65

3 year Solar Reflectance ≥0.15 3 year Solar Reflectance ≥0.50

CRRC® _{Solar Reflectance}_≥_0.20 _{Solar Reflectance}_≥_0.70

Thermal Emittance ≥ 0.7 Thermal Emittance ≥ 0.75

LEED®_SRi_≥₂₉ _SRi_≥₇₈

green globes SRi ≥ 29 SRi ≥ 78

(20)

Metal Sales is committed to advancing

sustainable design and building objectives,

including architectural strategies toward

energy efficiency, LEED certification, and

net-Zero.

Our portfolio of durable products containing

recycled and recyclable material is ideal for

use in high performance building, whether

new or retrofit. Metal Sales products optimize

energy efficiency, minimize construction waste,

and provide the most sensible platform for

renewable energy technology and rainwater

harvesting systems.

Metal Sales closely controls manufacturing

processes to capture all metal scrap for

recycling. Additionally, most of our facilities

have been retrofitted with high-output /

high-efficiency lighting systems. Our private

fleet of trucks meets the 2007 Highway Rule for

reduced engine emissions and is equipped with

systems that promote safer, more fuel-efficient

driving habits.

Build sustainably with Metal Sales.

commitment

s u s t a i n a b i l i t y

2

20

Redding School for the Arts Redding, CA

Architect: Trilogy Architects Profile: Magna-Loc Roof

(21)

buiLd with the worLd’s #1 Most reCyCLed MateriaL

By manufacturing our products from strong, durable steel – the world’s #1 most recycled material – out of coil containing a minimum of 25% post-consumer content, our products have low embodied energy compared to other building materials. Excess and scrap steel at the construction site can be easily redirected for recycling as part of a construction waste management program. Plus, durable Metal Sales products have a lifespan surpassing other conventional building materials.

siMpLe, effiCient, sustainabLe

Committed to environmentally responsible design, Metal Sales panels are never chemically or mechanically composited with plastic or foam. They are designed with material-efficiency in mind and to be used as the outermost component of a thermally efficient building envelope.

EnERgy STAR®_{listed panel colors improve energy efficiency and reduce the}

amount of energy needed for cooling. Advanced alloy and coating materials extend the aesthetics of our products for remarkable life-cycle performance and are backed by our industry leading 45 year finish warranty.

durabLe renewabLe energy

Metal outlasts other conventional roofing materials, making it the most sustainable choice for net-Zero design strategies. Metal Sales roof systems outpace the expected service life of photovoltaic technology, both film laminate and polycristalline. Our roof systems also create an ideal platform for rainwater harvesting, solar heating, and micro wind turbines, without penetrating the metal roof to ensure uncompromised weathertightness and durability.

environMentaLLy responsibLe partners

At Metal Sales, we know that achieving environmentally responsible and net-Zero construction requires associations with like-minded partners. That is why we affiliate with esteemed organizations like the The green Schoolhouse Series, the U.S. green Building Council, EnERgy STAR®_,_{and Cool Roof Rating Council}_.

Facebook’s first LEED®_{Gold building, the Prineville}

Data Center, trusts Metal Sales T2630 panels for their sustainable protection.

The Bullitt Center in Seattle, WA features 18,000 sq. ft. of TLC-1 wall panels. The building was designed and built to meet the standards of the Living Building Challenge and is considered the greenest commercial building in the world.

Enveloped in 7/8” Corrugated wall panels and Vertical Seam and Magna-Loc roof panels, the UC Davis West Village is the largest Net-Zero community in the U.S.

The Redding School for the Performing Arts in Redding, CA features polycrystalline photovoltaic panels attached to Magna-Loc roof system using clips to the metal ribs.

(22)

With the largest sales force and the most

manufacturing, sales, and distribution

facilities in the industry, Metal Sales is

positioned to offer responsive technical

support nationwide. Product information,

guide specifications, technical details,

AutoCad drawings, and BiM models are

easily accessed 24/7 on our website. Our

highly trained architectural consultants

are readily available to provide assistance.

Offering AiA Continuing Education programs,

we provide architects with learning opportunities

on high performance aspects of metal roof and

wall systems and their role in sustainable and

net-Zero design.

Metal Sales is committed to a positive

customer experience and offers in-house

architectural design and engineering

assistance – for classic or custom profiles –

as well as field support that is never far

away. We work closely with architects,

contractors, owners, and specifiers to

ensure that all questions are answered

quickly and with full attention to detail.

Contact Metal Sales

to schedule an AIA

continuing education

course.

support

te c h n i c a l

2

22

William R. Anton Elementary School Exceeds CHPS and Title 24 standards Los Angeles, CA

Architect: nadel inc. Profile: T16-L Wall

(23)

Test Category Test Protocol Description

WinD UL 580 Wind uplift resistance of roof assemblies

UL 1897 Wind uplift resistance of roof assemblies test as an extension of UL 580

ASTM E 1592 Determine ability of panel system including attachments to resist uniform static pressure ASTM E 330 Structural performance of exterior windows, curtain walls, and doors by uniform static air pressure difference

TAS 125 Standard requirements for metal roofing systems required by Florida Building Code and involves test methods UL580 and ASTM E 1592

FMg 4471 Factory Mutual global approval standard for Class 1 Roof panels requires meeting performance criteria in low fire spread, wind uplift resistance, strength, and durability in foot traffic and hail damage resistance

FiRE UL 790 Resistance to Fire Exposure from outside of the building

UL 263 Hourly Fire Resistance Ratings of a Roof and Wall Assemblies’ integrity when fire occurs inside a building

iMPACT UL 2218 Evaluation of impact resistance replicating the impact energy of large hailstones TAS-201 Missile impact test to determine resistance to wind-borne debris caused by hurricane is among the required testing for Florida Building Code and Miami-Dade County. SHEAR STREngTH ASTM E 455 Cantilever diaphragm test to calculate shear stiffness

ASTM E 564 Static Load Test for shear resistance of framed walls for buildings to calculate

shear stiffness.

AC 43 Acceptance Criteria for steel roof deck and floor systems to calculate the

shear stiffness.

ASAE 558 Load tests for metal-clad, wood frame diaphragms to calculate shear strength AiR AnD WATER ASTM E 283 Air leakage through exterior curtain walls; test is run in conjunction wilth ASTM E 331 ASTM E 331 Water penetration of exterior curtain walls

ASTM E 1680 Air leakage through exterior metal roof panel

ASTM E 1646 Water penetration of exterior metal roof panel; test is run in conjunction with

ASTM E 1680

TAS 100 Wind driven rain resistance TAS 114 Water submersion test

ASTM E 2140 Water penetration by static water pressure head

SOLAR PERFORMAnCE ASTM C 1549 Determine fraction of the solar flux reflected by a surface ranging from 0.00 to 1.00 ASTM C 1371 Determine thermal emittance

Metal Sales roof and wall systems undergo rigorous testing to ensure our products meet or exceed the latest industry standards for performance and quality control in manufacturing for a consistently uniform and reliable product or service. This chart summarizes performance oriented tests used to demonstrate the achievements of our panel systems. Specify Metal Sales products with confidence. When installed per manufacturer’s instructions they meet compliance criteria for international Building Code, including specific requirements for high velocity hurricane zones in the Florida Building Code and for Miami-Dade County.

produCts testing organizations and protoCoLs

(24)

[email protected]

PROUDLY MADE

IN TH E U.S.A.

UC Davis West Village Largest US net-Zero Community Davis, CA

Architects: Studio E Architects, MVE institutional,

Lim Chang Rohling & Associates Profile: 7/8” Corrugated Wall
