ANALYSIS OF SECURITY AND PRIVACY FEATURES IN MAPREDUCE ON CLOUDS

Volume 5, Issue 9, September 2016

2382

ANALYSIS OF SECURITY AND PRIVACY FEATURES

IN MAPREDUCE ON CLOUDS

M.KIRAN KUMAR

, P. KRISHNA REDDY

Associate Professor, Sree Venkateswara College Of Engineering, Nellore 1 Assistant Professor, Sree Venkateswara College Of Enginnering, Nellore 2

ABSTRACT:

MapReduce is a programming prototype that enables

for huge scalability across hundreds or thousands of servers in

a Hadoop. MapReduce is extensively used daily around the

world as an efficient distributed computation tool for a huge

class of problems such as search, clustering, log analysis,

different types of join operations, pattern matching, matrix

multiplication and analysis of social networks. Privacy and

security of data and MapReduce computations are significant

concerns when a MapReduce computation is implements in

public or hybrid clouds. In order to perform a MapReduce

functions in hybrid and public clouds, authentication of

mappers-reducers, privacy of data-computations, Integrity and

reliability of data-computations and freshness-correctness of

the outputs are mandatory. Satisfying these necessities defend

the operation from a number of types of attacks on data and

MapReduce computations.

Keywords:

Cloud computing, Hadoop, HDFS, hybrid cloud, public cloud, private cloud, MapReduce algorithms, distributed computing, privacy, security

1. INTRODUCTION

Cloud computing infrastructure provides on-demand,

easy, and scalable access to a shared pool of configurable

resources, without worrying about managing those resources.

Clouds provide three types of services, as follows:

(i) Infrastructure-as-a-service, IaaS, gives infrastructure

in terms of virtual machines, storage space, and networks with

some conditions. (ii) Platform-as-a-service, PaaS, provides a

scalable software platform allocating the implementation of

custom applications (iii) Software-as-a-service, SaaS, offers

software organization in clouds as a service, for instance, emails

and databases.

Fig.1: Cloud Services

Clouds can be classified into three types

(i) Public cloud: a cloud that make available services to a lot of

users and is not beneath the control of a single exclusive user.

(ii) Private cloud: a cloud that has its proprietary resources and is

beneath the control of a single exclusive user (iii) Hybrid cloud:

a grouping of public and private clouds.

Fig.2: Cloud Types

The mainly frequent platform-as-a-service computational

paradigm is MapReduce, introduced by Google in 2004.

MapReduce presents a well-organized and fault tolerant parallel

processing of significant data without any costly and dedicated

computing node similar to a supercomputer.

MapReduce is being organized on both public and hybrid

clouds, which are flat to several attacks and security threats. In

the present days, a number of public clouds, e.g., Amazon

Elastic MapReduce, IBM’s Blue Cloud, Google App Engine,

and Microsoft Azure, allow users to carry out MapReduce cloud

Volume 5, Issue 9, September 2016 software installations. Consequently, the deployment of

MapReduce in public clouds facilitates users to process

large-scale data space in a cost-effective approach and establishes a

connection between two independent entities, i.e., clouds and

MapReduce. As a negative aspect, the deployment of

MapReduce in hybrid and public cloud desires to deal with

various attacks on the communication networks and the cloud.

1.1.MapReduce Framework

MapReduce may be a process technique and a program

model for distributed computing supported java. The

MapReduce formula contains necessary tasks, specifically Map

and scale back. Map takes a collection of information and

converts it into another set of information, wherever individual

components square measure lessened into tuples (key/value

pairs). Secondly, scale back task, that takes the output from a

map as associate degree input and combines those knowledge

tuples into a smaller set of tuples. Because the sequence of the

name MapReduce implies, the scale back task is usually

performed once the map job. Parallel processing of large-scale

knowledge provides outputs in a very timely manner. However,

it constrains the computation thanks to node failure, ordering of

outputs, system quantify ability, transparency, load equalization,

fault tolerance, and synchronization among the nodes. A

user-defined program forks a master method and employee processes

at completely different nodes. The master method creates and

assigns map tasks and reduces tasks to idle employee processes.

An employee method deals with either a map task or a cut back

task.

The Map Phase: The given computer file is processed within

the map part, wherever the map perform is applied to knowledge

and produces intermediate outputs (of the shape (key, value)),

wherever the quantity of bits required to explain the worth in

every (key, value) combine isn't essentially identical. the

appliance of the map perform to one input (for example, a tuple

of a on-line database or a node during a graph) is termed a

plotter.

The Reduce Phase: The Reduce phase provides the ultimate

output of MapReduce computations. The cut back part executes

the cut back perform on intermediate outputs. The appliances of

the cut back perform to one key and its associated list of values

is termed a reducer.

Fig 3: A general execution of a MapReduce algorithm.

Word count is a conventional example to demonstrate a

MapReduce computation, where the assignment is to count the

number of incidences of each word in a collection of documents.

The unique input data is a collection of documents. Every

mapper takes a document and implements a map task that results

in a set of (key, value) pairs ({(w1, 1), (w2, 1), . . . , (wn, 1)}),

Where each key, wi, represents a word in the document, and

each value is 1. The reduce task is executed subsequently where

the reduce task adds up all the values equivalent to a key.

Exclusively, a reducer for a key wi takes all the (key, value)

pairs equivalent to the key (or word) wi and outputs a (wi ,mi)

pair, where m is the total number of incidences of the word wi in

all the given documents.

Applications and models of MapReduce: A lot of applications

in special areas are there already for MapReduce. Amongst

them: matrix multiplication, detection of near-duplicates,

interval join, similarity join, spatial join, pattern matching, data

cube processing, graph processing, skyline queries,

k-nearest-neighbors finding, star-join, theta-join, and

image-audio-video-graph processing are a few applications of MapReduce in the

real world.

1.2.

Hadoop and HDFS

Apache Hadoop is the most known and widely used open-source

software implementation of MapReduce for distributed storage

space and distributed processing of large-scale information on

clusters of nodes. Hadoop contains three most important

Volume 5, Issue 9, September 2016

2384 scalable and fault-tolerant distributed storage space system, (ii)

Hadoop MapReduce (iii) Hadoop Common, the common

utilities, which support the other Hadoop modules. Hadoop

cluster contains a master node (that runs a JobTracker and a

NameNode) and several slave nodes (where each slave node

runs a TaskTracker and a DataNode); JobTracker and

TaskTrackers present an environment for a MapReduce job

implementation. Particularly, JobTracker accepts a MapReduce

job from a user, executes the job on TaskTrackers, gets outputs

from TaskTrackers, and presents outputs to the user.

TaskTrackers carry out assigned jobs, provide outputs to

JobTracker, and periodically throw heartbeat messages to

JobTracker to show its presence and workload

Fig 4: Structure of a Hadoop cluster with one master node

and 2 slave nodes

NameNode and DataNodes present a distributed file system,

named Hadoop Distributed File System, which supports write,

read and delete operations on files, delete and create operations

on directories. NameNode deals with the cluster metadata and

DataNodes, which store up the data. NameNode keeps

information of files and directories using Inodes. Inodes store

several attributes of files and directories, for example

modification and access times, permissions and disk space

quotas. In HDFS, information is divided into small splits, called

blocks, (64MB and 128MB are most frequently used sizes).

Each block is separately replicated at multiple DataNodes, and

block replicas are developed by mappers and reducers. Each

DataNode stores the equivalent block replicas, and two files in the local host’s resident file system are used to signify each

block replica. The first file grasps the data itself, and the second file holds the block’s metadata.

2. SECURITY AND PRIVACY CHALLENGES IN MAPREDUCE

Privacy and Security design challenges for MapReduce

computations in the cloud are mainly size of input data and its

storage, highly distributed nature of MapReduce computations,

Data flow. MapReduce computations require a complex data

flow among dissimilar storage space nodes, different computing

nodes, and different clouds, The black-box nature of public

clouds supporting MapReduce, Scalability, fault tolerance, and

transparency, Economical issues, un trusted data access.

3.

The security of information and computations plays a

major role in MapReduce computations on each hybrid and

public clouds. While not security, MapReduce computations

similarly as MapReduce infrastructures are often tormented by

many varieties of attacks. We have a tendency to gift security

threats and security necessities for MapReduce computations.

Notice that even if some security threats and security necessities

area unit common for MapReduce and for generic cloud

computing, we'll concentrate on security threats and security

necessities within the context of MapReduce. 3.1. Security Threats in MapReduce

Distributed and replicated data processing in

MapReduce open an opportunity for a wide range of attacks.

While those attacks follow the same ideas as attacks in different

cloud computation models, the exact application is different for

MapReduce paradigm. Notice that most of these attacks are

specific to MapReduce deployments in public clouds, as

physical security and separation of private cloud deployments

significantly reduce the risk of attacks and allow a physical

separation of resources from attackers.

A) Impersonation attack.

Definition: An impersonation attack happens when an adversary

successfully pretends to be a legitimate user of a system by a

brute-force attack on weak passwords, pathetic encryption

schemes, or other means.

MapReduce context: After a victorious impersonation attack an

opponent can act on behalf of a officially permitted user and can

execute MapReduce jobs that may effect in data leakage, data

and computations tampering, or wrong computations on

information. In addition, on public clouds under impersonation

Volume 5, Issue 9, September 2016 while the impersonated user is tariffed for data storage, the

communication rate and computation time.

B) Denial-of-Service (DoS) attack.

Definition: A DoS attack happens once associate soul causes a

system and therefore the network to become non-functional and

non-accessible by legal users.

MapReduce context: A DoS attack happens once associate soul

makes a node, mapper, or reducer to be functional and

non-accessible by physical punishment undesirable and useless tasks.

Moreover, a compromised node, mapper, or reducer could end in

non-functionality of different non-compromised nodes, mappers,

or reducers by repeatedly causing task requests for them to

execute. Additionally, if associate aggressor compromises

enough nodes during a Hadoop cluster, it should end in the

failure of the full MapReduce framework and therefore the

network overload.

C) Replay attack.

Definition: A replay attack occurs when an opponent resends (or

replays) a captured valid message to the nodes.

MapReduce context: A replay attack occurs when an adversary

assigns a number of old tasks to the nodes, building them

constantly busy. In addition, an adversary can replay users

qualifications to access the framework, and it may guide to

impersonation and DoS attacks by spinning extreme amount of

nodes.

D) Eavesdropping.

Definition: An eavesdropping attack occurs when an adversary

monitors the network and the nodes without consent.

MapReduce context: An eavesdropping attack occurs when an

adversary observes input data, intermediate outputs, the last

outputs, and MapReduce computations without any permission

from the data and computation’s owner.

3.2. Security Requirements in MapReduce: Dynamic

deployment and pattern of mappers and reducers for each

MapReduce computation identify different security requirements

in MapReduce as evaluated to the traditional parallel processing

and cloud computing. Particularly, the allocation of different

heterogeneous resources for dissimilar MapReduce

computations, variability in the locations of resources, and

different trust levels for dissimilar jobs are a only some

parameters that complicate the security of MapReduce. To

defeat security challenges in MapReduce computations, a secure

MapReduce have got to provide authenticated and authorized

access, privacy (a secure storage and computation), integrity (a

fair execution and storage), and accounting-auditing of data,

information and computations.

Fig 5: Security necessities in MapReduce setting on the cloud.

A) Authorization, Authentication, and access control of reducers and mappers:

Authentication presents a way to recognize an

adversarial mapper, reducer, or user. Authentication is a

procedure by which only those mappers and reducers that

include rights to process information execute assigned tasks, and

all the additional mappers and reducers who are not permitted to

access information and the framework are denied. Previously

mappers and reducers are authenticated; authorization of

mappers and reducers permits them to access and process data

by inspecting their right to use privileges to that data. Access

control presents pre-configured policies that restrict an

unauthorized user to access data and to right to use the

framework. An adversarial mapper, reducer, or user mimics a

authorized mapper, reducer, or user, while commit a breach

authentication and authorization. Attacks on authentication and

authorization methods are impersonation and replay attacks. The

framework and information cannot be processed by any

adversarial mappers, reducer, when authorization,

authentication, and access control of mappers and reducers are

functioning correctly.

B) Availability of data, mappers, and reducers:

Data, mappers, and reducers are supposed accessible to

authenticated and authorized users without interruption. An

adversarial code may build mappers-reducers and the network

Volume 5, Issue 9, September 2016

2386 convey data, respectively. An attack on availability of data,

mappers, and reducers be able to interrupt MapReduce

computations. Particularly, an attack such as Denial-of-Service

is an attack on accessibility of data, mappers, and reducers. For

example, a single adversarial user in multi-users cloud-based

MapReduce setting can considerably collision job completion

times of the entire cluster even when using not as much of than

10% of cluster possessions.

C) Confidentiality of computations and data: Confidentiality

of computations and information refers to the protection of

computations and information, which can be in-transit from the user’s location to the placement of computations or could also be

hold on at public clouds, from unauthorized users and also the

public cloud itself. An attack on confidentiality of computations

and information is interception (man-in-the-middle attacks and

eavesdropping). By making certain confidentiality, one cannot

intercept computations and information throughout the

transmission and following transmission on public clouds

themselves. Verification of outputs is a not easy task in

MapReduce due to a huge parallel processing and a huge amount

of input/output data. Verification makes certain completeness,

correctness, and freshness of outputs

4

SECURITY

There are numerous possible adversarial models in security, and

thus, we will concentrate only on a limited set of adversarial

models involved in MapReduce security.

A) Honest-but-Curious adversary:

An honest-but-curious human executes a MapReduce job

properly and doesn't interfere with the duty furthermore as data;

but, it performs some further computations for understanding the

total information and also the job. For instance, a public cloud

doesn't interfere a MapReduce job and information; however it

will observe the duty and information.

B) Malicious adversary:

A malicious somebody will execute any computation for

stealing, corrupting, and modifying knowledge still because the

original MapReduce computation. for instance, a malicious

mappers or reducer might not perform a computation or could

offer wrong outputs Malicious adversaries in distributed settings,

like MapReduce, area unit divided into 2 varieties, as follows: (i)

non-collusive malicious somebody: a non-collusive malicious

adversary works severally, and hence, provides wrong outputs

while not consulting different malicious adversaries. during this

case, if a homogenous task is allotted to 2 nodes and a minimum

of one among them is non-collusive, then the malicious behavior

of the node will be simply detected by scrutiny their outputs; (ii)

conniving malicious somebody: a conniving malicious adversary

communicates with all the opposite malicious adversaries before

providing outputs. During this case, once a conniving somebody

is allotted a task, it consults different conniving adversaries to

seek out if they're allotted a homogenous task. If yes, then all the

conniving adversaries offer a homogenous wrong output that

creates it more durable to notice them.

5. PROPOSED SOLUTIONS FOR SECURING

MAPREDUCE

5.1. Authentication, authorization, and access control based approaches:

An validation mechanism for Hadoop using Kerberos

and three unusual types of tokens, namely delegation token, job

token, block access token is presented. The communication

between a user and HDFS is divided into two parts: (i) a user accesses NameNode using Hadoop’s distant procedure call

(RPC) libraries, and all RPCs attach using Simple

Authentication and Security Layer that utilizes Kerberos,

DIGEST-MD5, or a delegation token and (ii) a user accesses

DataNodes by means of a streaming socket connection that is

secured using a chunk access token. The working of the three

types of tokens is as follows:

Delegation token: A delegation token is a secret key among a

user and NameNode. After authenticating a user, a delegation

token is produced by NameNode using Kerberos, and the token

is worn for subsequent authentication of the user by NameNode

exclusive of involving Kerberos.

Volume 5, Issue 9, September 2016

Fig 6.b: Block Access Token

Block access token: A block access token offers authentication

policies to DataNodes by passing authorization data from

NameNode to DataNodes and is generated by NameNode

employing a symmetric-key theme wherever NameNode and

every one of the DataNodes share a secret key; once a user

desires to access a go in HDFS, it requests NameNode for block

ids and locations of the file. In response, NameNode sends block

ids and also the locations with a block access token for every

block, if NameNode verifies credibleness and authority of the

user. The user sends the block id with the block access token to

the corresponding DataNode, and also the DataNode verifies the

block access token before permitting access thereto block. 6. APPROACHES FOR SECURITY AND INTEGRITY OF STORAGE

A) iBigTable.

An development of BigTable, named iBigTable,

guarantees the integrity of data using decentralized valid data

structures. Two approaches are suggested for storing genuine

data that is used to verify the integrity of data. Both the

approaches build a Merkle Hash Tree (MHT) support

authenticated data structure for the source table, the metadata

tables, and the client tables. MHT permits capable and protected

verification of contents of large-scale data, where non-leaf nodes

are labeled with the jumble of the labels of their child nodes.

b) HDFS-RSA and HDFS-Pairing.

In order to store knowledge in a very confidential manner in

HDFS, 2 advances supported hybrid cryptography. The hybrid

cryptography approaches, use a block cipher and a stream cipher

block ciphers and stream ciphers. Knowledge is split into

fixed-sized blocks, d1, d2, . . . , dn, in keeping with a block cipher, and

therefore the remaining a part of knowledge becomes block

dn+1. The blocks d1, d2, . . . , dn square measure encrypted

employing a random key k and a block cipher, and therefore the

block dn+1 is encrypted mistreatment the key k and a stream

cipher. The key, k, is, then, encrypted employing a public key

scheme. the primary approach, known as HDFS-RSA, uses the

RSA cryptography scheme and AES, and therefore the second

approach, known as HDFS-pairing, uses a pairing-based

cryptography.

7. CONCLUSIONS AND FUTURE SCOPE

Security attacks during MapReduce impersonation,

denial-of-services, replay, and eavesdropping, man-in-the-middle, and

repudiation attacks area unit presented. We have a tendency to

believe four sorts of adversarial models, specifically

honest-but-curious, hateful, knowledgeable, and network and nodes access

opponents, and therefore the collision a MapReduce

computation and therefore the Framework for making certain

security and privacy within the scope of MapReduce. Existing

algorithms and frameworks achieve success in resolution the

precise security and privacy issues in MapReduce. The

consequence verification is completed by replication of tasks;

and privacy is ensured mistreatment information anonymization,

differential privacy, and personal data retrieval. Privacy

conserving analysis remains battling providing a high utilization

of MapReduce framework. Extending MapReduce algorithms

with privacy preserving support and these include support for

secure computations between reducers and across clusters. Also,

privacy policies, which define exactly what kind of aggregated

or anonym zed data can be output, need to be defined. 8. REFERENCES

[1] Ren, Yulong, and Wen Tang. "A Service Integrity Assurance Framework For Cloud Computing Based On Mapreduce."Proceedings of IEEE CCIS2012. Hangzhou: 2012, pp 240 – 244, Oct. 30 2012-Nov. 1 2012

[2] N, Gonzalez, Miers C, Redigolo F, Carvalho T, Simplicio M, de Sousa G.T, and Pourzandi M. "A Quantitative Analysis of Current Security Concerns and Solutions for Cloud Computing.". Athens: 2011., pp 231 – 238, Nov. 29 2011- Dec. 1 2011

[3] Hao, Chen, and Ying Qiao. "Research of Cloud Computing based on the Hadoop platform.". Chengdu, China: 2011, pp. 181 – 184, 21-23 Oct 2011.

Volume 5, Issue 9, September 2016

2388 [5] A, Katal, Wazid M, and Goudar R.H. "Big data: Issues,

challenges, tools and Good practices.". Noida: 2013, pp. 404 – 409, 8-10 Aug. 2013.

[6] Lu, Huang, Ting-tin Hu, and Hai-shan Chen. "Research on Hadoop Cloud Computing Model and its Applications.". Hangzhou, China: 2012, pp. 59 – 63, 21-24 Oct. 2012.

[7] Wie, Jiang , Ravi V.T, and Agrawal G. "A Map-Reduce System with an Alternate API for Multi-core Environments.". Melbourne, VIC: 2010, pp. 84-93, 17-20 May. 2010.
