The software platform for storing, preserving and sharing very large data sets.

(1)

The software platform for storing,

preserving and sharing very large data sets

(2)

ACTIVE CIRCLE HIGHLIGHTS

Media asset management option

In addition to the file mode, the Active Media Explorer is an

inte-grated media asset management application for indexing,

browsing and retrieving rich-content data such as video, audio

and images.

The easiest solution for storing

and archiving very large data sets!

Simplified access

Active Circle is visible on the network as a virtual NAS. You provide your users with easy access to their ﬁles.

Cope with data growth

You can grow each share capacity up to several petabytes, without any downtime.

Protect and preserve your data

All ﬁles are protected by replication and versioning policies. There is no need for a third-party backup tool.

Automated archiving

Old ﬁles are automatically archived while still being acces-sible. You oﬄoad your disk storage tiers for new data.

Better quality of service

Thanks to the multi-node architecture, the ﬁles are still accessible even in case of a server failure. You provide better service to the users.

Software-based storage solution

for massive data sets

Active Circle is a software solution for storing and archiving very large ﬁle volumes. Active Circle helps IT organizations reduce storage costs, simplify storage administration, and provide users with easy access to their ﬁles.

Hardware-agnostic

With the Software-Deﬁned Storage concept, the data administration is separated from the storage administra-tion. Physical storage devices are virtualized as pools. You can easily switch from one storage vendor or technology to another.

Simplified administration

Thanks to policy-based data management, storage admi-nistration is simpliﬁed. You deﬁne the lifecycle for your data and Active Circle implements the policies.

Reduced storage cost

Tiered storage moves old data to ‘cold’, less expensive storage, while keeping it accessible to users. Your storage budget is optimized.

Easy management of distributed sites

(3)



Eliminate hardware dependencies



Reduce storage costs



Simplify storage administration and save time



Provide users with easier access to their files

INTE

RFACES

STOR A G

E

Disk

storage

Tape or optical

_storage

Cloud

storage

File Interface

HTTP

Rest

Active Media

Explorer

NFS, CIFS, FTP

(4)

Integrity Check

Data integrity check using electronic signatures and comparison with the original. Based on MD5 or SHA-1 algorithm.

Global namespaces

A share can be physically distributed but remains a single logical namespace. A distributed lock manager ensures data consistency.

Versioning

When activated, this feature records versions of modiﬁed ﬁles according to the versioning policy. This feature also protects against deletion.

Scalability

A share can grow non-disruptively by adding storage capacity to storage pools. You can also add storage nodes to increase performance.

MAIN FEATURES

Architecture

Software-based storage virtualization system designed for providing secondary storage space for ﬁles. It is tiered, distributed and policy-based, and supports standard servers (Nodes) and any kind of storage technology. Data from the logical spaces (Shares) are placed in the physical storage (Pools) by the policies.

Tiered Storage

Policy-based tiering based on data retention. Oldest data is moved to deeper disk or tape storage.

Distributed

Storage nodes can be installed in various locations on the network. A set of connected nodes is called a Circle. The shares are accessible from any node.

Replication

The number and location of the physical copies are deﬁned by the storage policies, according to the required level of protection against failures or disasters.

COMPATIBILITY

Server

Standard server running RedHat or CentOs linux; contact Active Circle for detailed prerequisites. Storage

Any disk technology with NAS or SAN connection, or direct-attached.

Supported library vendors: Overland Storage, Quantum, Dell, HP, Grau Data Storage, IBM, Oracle-STK, Sony, Tandberg Data, Spectra Logic.

User Directories

Compatible with Active Directory, LDAP, NIS

(5)



NAS / File Access

Active Circle shares can be mounted as NFS or

CIFS shares, or accessed via FTP.



File Explorer

Advanced explorer for massive ﬁle transfer

optimized according to storage location.



Active Media Explorer

A web interface for indexing, searching and

browsing media ﬁles.



Web Services API

A set of web services designed to easily

inte-grate Active Circle with a data-intensive

appli-cation.

INTERFACES

LICENSE MODE

Purchase of a license for on-premises installation. Annual maintenance contract covering:

• technical support

• remote connection from the support team for troubleshooting

• minor and major updates

SUBSCRIPTION MODE

License and maintenance are merged into a single annual or quarterly subscription. The service is similar to the standard maintenance contract.

MANAGED SERVICES

This extension of the standard maintenance contract allows you to save time and focus on your core business. This remote service covers monitoring, reporting and system maintenance.

(6)

The software platform for storing, preserving and sharing very large data sets.
