5 ways to leverage the
free VMware hypervisor
Contents
Inside VMware’s free
hypervisor
Free vSphere reporting
tools
Free ESXI monitoring
tools
Free VM backup that
works with vSphere
Hypervisor
Extra features lure
allegiance away from
free virtualization
While a free VMware virtualization setup only
provides a limited list of features and functionalities, the
shortcomings may be worth the cost-savings it delivers for
organizations operating on a tight IT budget.
So, what complimentary products and services does VMware
offer and how can you get the most from them?
Inside this exclusive guide, explore essential insights on the
free virtualization tools available for unlimited business use
and discover expert tips for leveraging them to build a viable
virtualization infrastructure for your IT environment.
Inside VMware's free hypervisor
By David Davis
A VMware enterprise-grade Tier-1 hypervisor has been free since 2008, debuting as Free ESXi 3.5. Today, the free VMware hypervisor is called vSphere Hypervisor and includes:
Graphical management interface with the vSphere client;
Memory over commitment and memory management techniques like memory ballooning, transparent page sharing, compression and swapping;
The VMware VMFS file system;
Thin provisioning of virtual machine disks;
Snapshot and restore capabilities;
Hardened device drivers that are VMware-certified and tested for reliability and performance;
Virtual guest OS support with Microsoft OS (18 versions), Linux (54 versions), Mac OS X 10, Solaris and FreeBSD;
Virtual networking; and
Contents
Inside VMware’s free
hypervisor
Free vSphere reporting
tools
Free ESXI monitoring
tools
Free VM backup that
works with vSphere
Hypervisor
Extra features lure
allegiance away from
free virtualization
VMware limits its free hypervisor platform to a maximum of 8 virtual CPUs per virtual machine (VM) and 32GB physical RAM per server. Although you can run as many VMs as needed, the RAM limitation will keep you to about 10 to 12 VMs per host, depending on each VM's actual memory utilization.
Enterprise-grade virtualization features commonly associated with vSphere -- vMotion and Storage vMotion, High Availability, Distributed Resource
Scheduler and vSphere Data Protection -- are noticeably absent from the free hypervisor.
Without centralized management, it is difficult to maintain a high number of vSphere hosts at once. You can't solve this problem by purchasing vCenter; it won't work with the free version of vSphere ESXi.
Third-party tools can help to build a more complete virtual infrastructure, keeping the $0 price tag. At minimum, a viable virtualization setup needs the hypervisor, reporting to get a consolidated view of operations, performance and capacity monitoring, and an application for backup and recovery.
Free vSphere reporting tools
By David Davis
So you have a VMware virtual infrastructure on the free vSphere Hypervisor platform. How many hosts do you have? How many VMs do you have? What is their configuration? Normally all of this would be found in vCenter, which you cannot use with the free VMware hypervisor. However, beyond vCenter, there are some free vSphere reporting tools that can help.
With vCenter and other expensive reporting tools ruled out, you likely will not have a consolidated view into the infrastructure. Try exporting data to keep more detailed tabs on the environment.
RV Tools from Robware.net produces reports on vSphere hosts for free. The report data are organized into a spreadsheet with multiple tabs, each
Contents
Inside VMware’s free
hypervisor
Free vSphere reporting
tools
Free ESXI monitoring
tools
Free VM backup that
works with vSphere
Hypervisor
Extra features lure
allegiance away from
free virtualization
easily exported to Excel. Repeat the process for multiple vSphere hosts, then consolidate the information in Excel and you'll have a complete, free virtual infrastructure inventory.
Veeam One Free is a reporting and performance/capacity tool. The free edition only keeps 24 hours of performance data and does not offer capacity management.
Free ESXi monitoring tools
By David Davis
No With some basic vSphere reporting information coming in, it's time to determine if your free VMware virtualization infrastructure has adequate performance and capacity for the future. The VMware vSphere client can provide basic host and VM utilization information, but free third-party ESXi monitoring tools can help.
Veeam One serves a reporting and performance monitoring function, or you can implement Dell Foglight for Virtualization Free (previously known as vKernel vOPS Server Explorer). Foglight provides information about your virtual infrastructure inventory, storage, virtual infrastructure changes and snapshots, with a search and reporting functionality under SearchMyVM.
The free VMware PowerCLI command line interface for PowerShell commands, with the VMware Community Power Pack and the free
PowerGUI tool, also delivers reporting and configuration options. PowerShell scripts can do just about anything on vSphere, and it's always totally free.
Free VM backup that works with vSphere Hypervisor
By David Davis
Contents
Inside VMware’s free
hypervisor
Free vSphere reporting
tools
Free ESXI monitoring
tools
Free VM backup that
works with vSphere
Hypervisor
Extra features lure
allegiance away from
free virtualization
most backup solutions use. However, there are some free VM backup tools that use the older, pre-VADP transport method. It may be slower than a VADP-based product, but it will still work.
Consider Veeam Backup and Replication Free Edition, which works with the free VMware hypervisor. Veeam's free edition backs up VMs with the old file-based secure-copies (SCP) transfer method, and backups are
crash-consistent. Without the VADP, Veeam Backup Free cannot use the same technology as its commercial edition, meaning you'll miss out on scheduled backup, incremental backups and replication.
Trilead VM Explorer (VMX) also can back up the free vSphere Hypervisor, again without VADP support. Don't expect to be able to snapshot VMs or use Changed Block Tracking to reduce the backup burden on your systems. This means VM backups must be crash-consistent and you'll need to make time for full backups without the convenience of a scheduler.
Thinware.net's vBackup has the same VADP-shutout limitations, but is a useful backup tool in its own right because it offers snapshot functionality. For vBackup, the company wrote their own snapshot functionality to work with vSphere Hypervisor. They can take snapshots of virtual machines for backup purposes, achieving zero-downtime backups. For a totally free backup product, snapshot functionality is a unique capability.
While I would hate to give up image-level virtualization-style backups, perhaps the best way to perform scheduled backups in a zero-cost VMware environment would be to use native OS tools such as Windows Server Backup.
Extra features lure allegiance away from free virtualization
By David Davis
Are the free VMware hypervisor and supporting tools worth the limitations? If you want advanced virtualization features, you can buy the vSphere
Contents
Inside VMware’s free
hypervisor
Free vSphere reporting
tools
Free ESXI monitoring
tools
Free VM backup that
works with vSphere
Hypervisor
Extra features lure
allegiance away from
free virtualization
centralized management with vCenter. With vCenter and the ability to exploit VADP, you can still keep costs down by choosing from numerous free tools at their full functionality, such as Veeam Backup or free VMturbo Community Edition and others.
Still, low-cost virtualization isn't free virtualization, and the money isn't always available. Perhaps a remote location needs to virtualize some servers and company executives won't authorize any expenditures to do it. The free vSphere Hypervisor is a powerful Type-1 hypervisor with strong memory management techniques and easy deployment.
If you compare vSphere Hypervisor to the vSphere Essentials kit, you could save $560. Consider that the Essentials kit just supports up to three servers and two sockets for each kit. If you compare the free hypervisor to vSphere Enterprise Plus at $3495 per socket and vCenter Server Standard at $4995, you could save more than $25,965 just on the initial software purchase. This calculation doesn't include the yearly service and support subscription.
While the small investment in vSphere Essentials is likely to pay off for many small or medium-sized businesses, building a completely free vSphere infrastructure is possible. And you can start with free and plan to invest more once virtualization is established, to take advantage of full backup
