Data Center Network Infrastructure
The Smart Choice For Your Data Center
Network Infrastructure Expertise
Unrivaled Quality, Service, and Support
Innovative Solutions
Data Center Technology Alliances
Leviton works closely with the biggest names in networking technology to create scalable, high-density data center networks. When combined with the latest data center switches from Arista, Brocade, Cisco, and Extreme Networks, our cable assemblies and connectivity give you extra design flexibility for your equipment architecture.
Learn how Leviton connectivity connects with the latest solutions at leviton.com/alliances.
Every data center has a unique set of network priorities, from consolidation and cost control to quick deployment and zero downtime. You can count on Leviton to ensure your data center’s infrastructure meets your specific requirements. We have experience serving all types of customers, including telecom providers, Fortune 100 e-commerce companies, universities, and high-security government installations.
Network Infrastructure Expertise
Leviton has infrastructure experts to
help with everything from day-to-day
challenges to long-term planning.
Our data center designers and engineers have extensive experience with the most popular active equipment, network topologies, and transmission methods. Many of them are active members on standards bodies that define future data center networks, including TIA 42.7 for 40 GbE copper and IEEE 802.3bm for next generation 40/100 GbE optical fiber.
With service and support from initial planning through post-installation, we have you covered at every point in the life of your data center.
Unrivaled Quality, Service, and Support
Responsive Customer Service
Talk to one of our many knowledgeable and friendly customer service reps to answer questions about your purchase, get you a quote on a product, or direct you to the right data center specialist or distributor in your area.
Knowledgeable Technical Support
Our technical service reps can assist with data center products and network troubleshooting, whether over the phone or through our online live chat. More than 90% of tech support issues are resolved on the first call.
Global Reach
Whether your data center is in California, Korea, Dubai, or Colombia, you’ll get the same quality and service. Our team of Global Account Managers will work with customer service to deliver the products and support you need.
Extended Warranty
Leviton systems are backed by a limited extended warranty when installed and tested by a Leviton Certified Contractor. Our warranties have covered more that 1 million copper and
Intact™ Intelligent Port Management System Real-time network documentation with alerts for faults or unplanned changes
4
40/100G MTP® Systems
Ideal migration path to 40/100 GbE speeds
3
1
11
7
2
9
8
3
6
5
10
HDX Fiber Distribution System Used in MDA to consolidate patching and reduce footprint, freeing up valuable space
2
4
1
e2XHD Snap-In Cassette Patching System Fast deployment and simple maintenance
Cat 6A Premium UTP System
Best-in-class component-rated UTP system with crosstalk prevention technology
8
Power Distribution Units Provide reliable power distribution into racks and cabinets with outlet power ranging from 2.0 kW to 12.5 kW
11
Cable Management
Vertical, horizontal, and overhead cable management with standard equipment racks and cabinets*
5
Secure Connectivity Physical port security with copper RJ and fiber LC assemblies
6
Pre-terminated Copper & Fiber Trunks Provide backbone connections between entrance facility, MDA/Core, SAN, and HDA
9
Cable
Extensive selection of fiber optic and copper cable to support high-density applications
7
Leviton technologies cover every area of thedata center – from the entrance room and computer room to the telecommunications room (TR) and support offices.
Data Center Solutions
* Product availability varies by region.Contact your local sales representative for details.
Fiber Optic Systems, Enclosures, and Accessories High-density enclosures can be custom configured with cassettes, adapter plates, and pre-terminated solutions. Systems can deliver an unprecedented 300-meter link length for 40 GbE connections
We’ve made building the exact data center product or system quicker and easier than ever with our Make-To-Order Program.
The program offers custom-configurable options for enclosures, cassettes, cable assemblies, and PDUs. Our ISO-certified facilities in Seattle and Chicago can build and ship these products in some of the fastest turnaround times in the industry. Selecting a custom solution is easy with our innovative online configurators. Choose from a wealth of options to create the ideal solution for your needs. Then take the resulting model number or part number and submit your quote request to your local Leviton distributor. To see a full range of custom-configurable products, visit
Leviton.com/configurator.
Custom Products
NEED A
UNIQUE
SOLUTION?
Our engineers will work with you to design and manufacture a solution that meets your specific application needs. For questions or assistance
configuring your products, please call Network Solutions Support at
Suspended Basket Leviton Overhead Infrastructure Platform Labor $27,248 $2,880 Material $3,850 $8,778 Total $31,098 $11,658
$ Savings
$19,440
% Savings
63%
REDUCE BUILDING
RENOVATIONS
63%
Savings
Dollars saved using Overhead Infrastructure Platform vs. traditional ladder and basket systems
Learn more at leviton.com/OIP.
When planning for data center upgrades, expansions, or new construction, data center managers are often challenged to keep capital and operating expenditures in check. We can help you justify data center investments with solutions that deliver a significant and measurable ROii™ savings.
Strong Return on Infrastructure Investment
Smart Choice Savings
with the
Overhead Infrastructure Platform
150 Server Cabinet Example Traditional Racks in MDA Leviton HDX in MDA # of Frames / Cabinets 20 12 Square Footage 213 48 Total $128,040 $28,800
$ Savings
$99,240
% Savings
345%
SAVE SPACE IN
YOUR MDA
345%
Savings
Dollars saved using HDX Fiber Distribution System vs. traditional cabinets.
Calculate your savings with the ROii™ Calculator at
apps.leviton.com/hdxcalculator.
Smart Choice Savings
with the
HDX Fiber Distribution System
We invent the industry’s best technologies. We build them to last. And we stand behind every product and every installation – delivering industry-leading performance and unbeatable service and support – throughout the life of your structured cabling system. Add in the peace of mind that comes from working with a stable, century-old supplier and you get far and away the highest return on infrastructure investment in the industry.
High-performance connectivity backed by the
industry’s best service and support
THE SMART CHOICE FOR
A BETTER NETWORK
