WAN Development and Challenge
As more Enterprise services are deployed on IT systems and transmitted over IP networks,
Enterprise networks are expanding to support more service types.
Data processing
Information sharing
Comprehensive service
Computer interconnection & file sharing
Office system Wireless access Video conferencing Desktop Telepresence Cloud storage BYOD Spontaneous Telepresence Desktop cloud Enterprise application store Mobile video Cloud computing Internet of Things Voice call Multimedia Cloud Mobile
Service network
Enterprise service informatizationEnterprise informatization
Development of enterprise IT applications
Enterprise networks are vital for ensuring service availability; therefore, network reliability, security, and maintainability must be guaranteed to ensure uninterrupted services.
The bandwidth demands of Enterprise services on network resources is increasing, especially on Wide Area Network (WAN) bandwidth; however, WAN bandwidth is limited and network resources must be allocated logically to ensure optimal user experience of key applications and to minimize investment costs.
Solution Overview
Huawei Agile WAN Solution architecture
Huawei has launched its Agile WAN Solution to solve the challenges of insufficient bandwidth,
poor reliability, lack of security, and maintainability.
Stable network architecture, agile service provisioning, comprehensive network security, and unified
network management are the core characteristics of Huawei’s Agile WAN Solution.
■ Stable network architecture – Huawei’s Agile WAN Solution provides device-level and protocol-level reliability. Huawei-developed core chips enable easy upgrades. IPv6 technologies or a transition solution from IPv4 enable network architecture evolution.
■ Agile service provisioning– Huawei’s Agile WAN Solution implements unified traffic scheduling based on Software-Defined Networking (SDN) to links that transmit multimedia and cloud services. A variety of load-balancing technologies and WAN-acceleration products are used to maximize link efficiency and ROI. Additionally, Huawei’s solution provides differentiated service experience for users through refined bandwidth management based on Quality of Service (QoS) policies..
■ Comprehensive network security – Huawei’s Agile WAN Solution provides refined service identification and multi-dimensional policies to provide border security and defend against malicious attacks and unauthorized access.
■ Unified network management – Huawei’s Agile WAN Solution supports unified management of IP and optical networks, implements visualized monitoring and Operations and Maintenance (O&M) of network traffic, which provides high quality through a simplified, unified Network Management System (NMS).
Agile Network
Enable Networks to Be More Agile for Services
Industries
Solution Highlights
Product Family
Government Enterprise Energy Smart Grid Transportation Finance
Stable network
architecture Agile service provisioning network securityComprehensive Unified network management
High reliability, performance, and
scalability and smooth evolution
SDN-based traffic scheduling, HQoS Bandwidth management,
UCMP load balancing, WAN acceleration
Border protection, high quality & security, service management, and traffic
optimization
Traffic monitoring, quality monitoring, visualized O&M, and collaborative
management
Stable Network Architecture
Huawei’s Agile WAN Solution provides a comprehensive collection of Enterprise networking
products, including optical transmission/Ethernet/WLAN/WAN access routers, aggregation/core
routers, network security products, and NMS for a complete End-to-End (E2E) fundamental
network solution. Huawei’s Agile WAN Solution provides device-level, network-level, and
topology-level network reliability.
■ Device-level reliability:
• Hardware redundancy design: Dual power supplies, dual Main Processing Units (MPUs), and hot-swappable cards.
• In-Service Software Upgrade (ISSU): Hot patches.
• Single-point failure recovery: Non-Stop Forwarding (NSF) and non-stop routing (NSR).
■ Protocol-level reliability:
• Network link and node fault detection technologies: Static/dynamic Bidirectional Forwarding Detection (BFD), single hop/multi-hop BFD, and IPv6 BFD.
• Industry-leading quick switchover technologies: IP Fast Reroute (FRR), Label Distribution Protocol (LDP) FRR, and VPN FRR.
■ Topology-level reliability:
• Dual-plane network
• Double node dual link
• Networks of two carriers
Device-level reliability: Dual MPUs for routers, NSF, and NSR
Protocol-level reliability: FRR and BFD
Topology-level reliability: Dual systems, dual planes, dual uplinks, and UCMP.
WAN SDN traffic scheduling
Agile Service Provisioning
Huawei’s Agile WAN Solution features the following advantages for agile service provisioning:
■ SDN-based traffic scheduling improves WAN link efficiency by three times. Huawei’s Agile WAN Solution introduces its Agile Controller to automatically compute service paths and optimize bandwidth efficiency based on network states and service requests. In addition, this solution fully displays service network characteristics through network state and service priority awareness; it implements path planning and computing over the entire network, which improves link efficiency to over 90 percent.
■ Provides various types of QoS to guarantee support for multi-service transmission. Hierarchical Quality of Service (HQoS) schedules queues at the physical, logical, and application/service level using different traffic policies. This implements hierarchical traffic management as well as management of different users and services.
Huawei supports 5-level HQoS scheduling, and each DS-TE supports eight CTs, providing a refined E2E QoS solution.
■ Unequal-Cost Multi-Path Routing (UCMP) and load balancing allocate traffic to backup links based on their bandwidth capacities. This permits more logical use of backup links, eliminates an idle high-bandwidth link and packet loss on the low bandwidth link.
■ WAN acceleration products compress traffic based on application characteristics to increase network bandwidth utilization. The WAN acceleration module significantly increases transmission speed and reduces bandwidth requirements by 60 to 70 percent, saving up to 38 percent on costs.
Tianjin Nanjing Shanghai Hongkong Guangzhou Shenzhen Beijing
Comprehensive Network Security
Huawei’s high-efficiency WAN solution offers the following security protection advantages:
■ Provides major security functions, such as anti-virus, Intrusion Prevention System (IPS), URL filtering, IPSec VPN, SSL VPN, GRE VPN, and anti-spam.
■ Comprehensive authentication modes and refined service identification realize multi-dimensional policy configuration and execution.
■ An advanced traffic management and control solution filters attack and non-service traffic to ensure high-efficiency service provisioning.
Application identification Malicious website detection Web site classification Anti-virus IPS Malicious URL detection • Support 1200+ types of protocols. • Detects encrypted P2P applications.
• Size of Botnet library: 350+. Detects 500+ worms.
• Accurate Botnet/worm detection
• System weakness analysis and intelligent weakness protection
• Size of loophole signature library:
6500+ • Virus SDB: Used in
150 million systems around the world.
• > 65 million classified websites • > 130 types of websites in 12 languages. • Malicious URL >2M • Phishing websites: • Active > 50,000 • Accuracy > 90%
Comprehensive security
Unified Network Management
Huawei high-efficiency WAN solution provides aunified network management system (NMS):
■ The Huawei U2000 realizes unified management of optical transmission and IP networks.
■ Huawei eSight supports the maximum number of third-party devices in the industry. It can manage 675 device types from more than 20 vendors, as well as many types of pre-defined IT and IP devices.
■ Supports management of customized devices (alarm, performance, and panel).
■ Supports visualized management for telepresence and Multi-Protocol Label Switching (MPLS) VPN to realize end-to-end visualized network quality detection.
Visualized Network Management
VolP VolP VolP Telepresence Telepresence Telepresence Desktop cloud Desktop
cloud Desktop cloud
Video surveillance
Video
surveillance surveillanceVideo
Branch Headquarters Branch WAN SLA component NTA traffic Analysis component MPLS VPN component LAN LAN LAN
Customer Benefits
■ Provides customers with the most complete WAN products (IP network products + optical network products + security/NMS products) through a unified solution.
■ Multiple types of service assurance technologies ensure highly efficient multi-service provisioning. Multiple types of load balancing and WAN acceleration technologies maximize bandwidth utilization, reducing Total Cost of Ownership (TCO).
■ Supports comprehensive authentication modes with refined service identification and multi-dimensional policies to provide secure solutions.
Why Huawei?
Huawei is a leading IP network solutions and equipment provider. Huawei has deployed IP networks that serve one-third of the world's seven billion people in more than 140 countries and regions. The Huawei high-efficiency WAN solution is a highly reliable and scalable solution that supports stable network architecture, highly efficient service assurance, comprehensive security, and unified network management. Boasting many years of experience in the Information Communications Technology (ICT) field, Huawei can help enterprises build WANs and deploy services around the world.
