Technical Data Valid for model year The new Caddy

(1)

Technical Data

Valid for model year 2016

(2)

– Engines with emission standard Euro 6 – The new Caddy The new Caddy – Engines with emission standard Euro 6 –

Engines with emission standard Euro 6.

1.2 l TSI engine with 62 kW (84 bhp) 1.4 l TSI engine with 92 kW (125 bhp)

Engine design/valves per cylinder 4-cylinders petrol engine/4 4-cylinders petrol engine/4

Injection/turbocharging Direct injection/turbocharger Direct injection/turbocharger

Displacement in cm3 _1,197 _1,395

max. output in kW (bhp) at 1/min 62 (84) at 4,300 – 5,300 92 (125) at 5,000 – 6,000

max. torque in Nm at 1/min 160 at 1,400 – 3,500 220 at 1,500 – 3,500

Fuel type Premium unleaded, min. ROZ 95 in accordance with DIN EN 2285) _{Premium unleaded, min. ROZ 95 in accordance with DIN EN 228}5)

Gearbox variant 5-speed manual gearbox 6-speed manual gearbox or 7-speed dual clutch gearbox DSG

Drive type Front-wheel drive Front-wheel drive

2.0 l TDI engine with 55 kW (75 bhp) with SCR/AdBlue®6) _{2.0 l TDI engine with 75 kW (102 bhp) with SCR/AdBlue®}6)

Engine design/valves per cylinder 4-cylinders diesel engine/4 4-cylinders diesel engine/4

Injection/turbocharging Common Rail/exhaust-gas turbocharger Common Rail/exhaust-gas turbocharger

Fuel type Diesel, min. 51 CZ in accordance with DIN 590 Diesel, min. 51 CZ in accordance with DIN 590

Taxation is in accordance with the code numbers laid down by the German Federal Motor Transport Authority. For detailed explanations on the footnote numbers listed here, please refer to the page “notes”.

160 Nm 62 kW

62 kW

1000 2000 3000 4000 7000 100 90 80 70 60 50 40 30 20 10 200 150 100 50 5000 6000 tor que [Nm ] engine speed [rpm] output [kW] 1.2 l TSI (Euro 6)

92 kW

1000 2000 3000 4000 7000 100 90 80 70 60 50 40 30 20 10 200 150 100 50 5000 6000 250 220 Nm 92 kW tor que [Nm ] engine speed [rpm] output [kW] 1.4 l TSI (Euro 5)

55 kW

1000 2000 3000 4000 5000 100 90 80 70 60 50 40 30 20 10 250 200 150 100 50 225 Nm 55 kW tor que [Nm ] engine speed [rpm] output [kW] 2.0 l TDI (Euro 6)

75 kW

1000 2000 3000 4000 5000 100 90 80 70 60 50 40 30 20 10 250 200 150 100 50 300 250 Nm 75 kW tor que [Nm ] engine speed [rpm] output [kW] 2.0 l TDI (Euro 6)

(3)

The new Caddy – Engines with emission standard Euro 6 –

– Engines with emission standard Euro 6 – The new Caddy

Engines with emission standard Euro 6.

2.0 l TDI engine with 90 kW (122 bhp) with SCR/AdBlue®6) _{2.0 l TDI engine with 110 kW (150 bhp) with SCR/AdBlue®}6)

Drive type Four-wheel drive 4MOTION Front-wheel drive

1.4 l TGI engine with 81 kW (110 bhp)

Engine design/valves per cylinder 4-cylinders CNG engine/4 Injection/turbocharging quasimonovalent7)

Displacement in cm3 _1,395

max. output in kW (bhp) at 1/min 81 (110) at 4,800 – 6,000 max. torque in Nm at 1/min 200 at 1,500 – 3,500

Fuel type CNG (L or H gas) or bio gas/premium unleaded, min. ROZ 95 in accordance with DIN EN 2285)

Gearbox variant 6-speed manual gearbox

Drive type Front-wheel drive

Taxation is in accordance with the code numbers laid down by the German Federal Motor Transport Authority. For detailed explanations on the footnote numbers listed here, please refer to the page “notes”.

90 kW

1000 2000 3000 4000 5000 100 90 80 70 60 50 40 30 20 10 250 200 150 100 50 300 Nm 90 kW 300 350 tor que [Nm ] engine speed [rpm] output [kW] 2.0 l TDI (Euro 6)

110 kW

1000 140 90 80 70 60 50 40 30 20 250 200 150 100 50 300 350 400 10 100 110 120 130 2000 3000 4000 5000 340 Nm 110 kW tor que [Nm ] engine speed [rpm] output [kW] 2.0 l TDI (Euro 6)

81 kW

1000 2000 3000 4000 7000 100 90 80 70 60 50 40 30 20 10 200 150 100 50 5000 6000 250 200 Nm 81 kW tor que [Nm ] engine speed [rpm] output [kW] 1.4 l TGI (Euro 6)

(4)

– Engines with emission standard Euro 5 plus – The new Caddy The new Caddy – Engines with emission standard Euro 5 plus –

Engines with emission standard Euro 5 plus.

1.6 l TDI engine with 55 kW (75 bhp) 1.6 l TDI engine with 75 kW (102 bhp)

max. output in kW (bhp) at 1/min 55 (75) at 3,000 – 4,000 75 (102) at 4,400

2.0 l TDI engine with 81 kW (110 bhp) 2.0 l TDI engine with 103 kW (140 bhp)

max. output in kW (bhp) at 1/min 81 (110) at 4,200 103 (140) at 4,200

(only with four-wheel drive 4MOTION)

Drive type Four-wheel drive 4MOTION Front-wheel drive or four-wheel drive 4MOTION

55 kW

1000 2000 3000 4000 5000 100 90 80 70 60 50 40 30 20 10 250 200 150 100 50 300 225 Nm 55 kW tor que [Nm ] engine speed [rpm] output [kW]

1.6 l TDI (Euro 5 plus)

75 kW

81 kW

103 kW

1000 140 90 80 70 60 50 40 30 20 250 200 150 100 50 300 400 350 10 100 110 120 130 2000 3000 4000 5000 320 Nm 103 kW tor que [Nm ] engine speed [rpm] output [kW]

(5)

– Fuel consumption, CO2 emissions and performance – The new Caddy The new Caddy – Fuel consumption, CO2 emissions and performance –

Fuel consumption, CO

₂

emissions and performance.

BMT = BlueMotion Technology DSG = dual clutch gearbox DSG

*Information on fuel consumption: line 1 in kg/100 km (CNG), line 2 in m3_{/100 km (CNG).}

For detailed explanations on the footnote numbers listed here, please refer to the page “notes”.

Caddy Delivery Van and Caddy Delivery Van Trendline

Engine Gearbox Output

maximum

in kW (bhp)

Emission standard Fuel consumption2), 3) urban/extra-urban/ combined, in l/100 km CO2 emissions3) combined in g/km Acceleration 0 –100 km/h (s) Top speed in km/h

1.2 l TSI BMT 5-speed manual gearbox 62 (84) Euro 6 7.2 – 6.8/5.1 – 4.7/5.9 – 5.5 137 – 127 13.6 157

1.4 l TSI BMT 7-speed DSG 92 (125) Euro 6 6.8 – 6.4/5.3 – 5.1/5.8 – 5.6 136 – 128 10.3 183

2.0 l TDI BMT 5-speed manual gearbox 55 (75) Euro 6 5.7 – 5.3/4.2 – 3.9/4.7 – 4.4 123 – 114 16.4 152

2.0 l TDI BlueMotion 5-speed manual gearbox 75 (102) Euro 6 4.8 – 4.7/3.7 – 3.6/4.1 – 4.0 109 – 106 12.0 172

2.0 l TDI BMT 6-speed DSG 75 (102) Euro 6 5.9 – 5.7/4.7 – 4.5/5.1 – 4.9 135 – 129 12.1 170

2.0 l TDI BMT 4MOTION 6-speed manual gearbox 90 (122) Euro 6 6.7 – 6.5/4.9 – 4.7/5.5 – 5.3 146 – 139 10.8 178

1.4 l TGI BlueMotion* 6-speed manual gearbox 81 (110) Euro 6 5.2 – 5.0/3.6 – 3.4/4.2 – 4.0 8.0 – 7.7/5.5 – 5.2/6.4 – 6.1

115 – 109 12.2 174

1.6 l TDI 5-speed manual gearbox 55 (75) Euro 5 plus 6.6 – 6.5/5.2 – 5.1/5.7 – 5.6 149 – 147 16.7 150

1.6 l TDI BMT 5-speed manual gearbox 55 (75) Euro 5 plus 5.9 – 5.8/4.9 – 4.8/5.3 – 5.2 139 – 136 16.7 151

1.6 l TDI 7-speed DSG 75 (102) Euro 5 plus 6.6 – 6.4/5.3 – 5.1/5.8 – 5.6 152 – 147 12.3 168

2.0 l TDI 4MOTION 6-speed manual gearbox 81 (110) Euro 5 plus 7.8 – 7.7/5.7 – 5.6/6.5 – 6.4 171 – 168 12.2 170

(6)

The new Caddy – Fuel consumption, CO2 emissions and performance –

– Fuel consumption, CO2 emissions and performance – The new Caddy

Fuel consumption, CO

₂

emissions and performance.

Caddy Maxi Delivery Van and Caddy Maxi Delivery Van Trendline

maximum

in kW (bhp)

Emission standard Fuel consumption2), 3) urban/extra-urban/ combined, in l/100 km CO2 emissions3) combined in g/km Acceleration 0 –100 km/h (s) Top speed in km/h

1.4 l TSI BMT 7-speed DSG 92 (125) Euro 6 6.8 – 6.6/5.3 – 5.2/5.8 – 5.7 136 – 132 10.8 183

2.0 l TDI BMT 4MOTION 6-speed manual gearbox 90 (122) Euro 6 6.7 – 6.6/4.9 – 4.8/5.5 – 5.4 146 – 143 11.4 178

1.4 l TGI BlueMotion* 6-speed manual gearbox 81 (110) Euro 6 5.3 – 5.1/3.7 – 3.5/4.3 – 4.1 8.1 – 7.9/5.6 – 5.3/6.5 – 6.2

117 – 111 13.0 174

2.0 l TDI 4MOTION 6-speed manual gearbox 81 (110) Euro 5 plus 7.9 – 7.8/5.8 – 5.7/6.6 – 6.5 174 – 171 12.6 170

(7)

– Fuel consumption, CO2 emissions, efficiency categories and performance – The new Caddy The new Caddy – Fuel consumption, CO2 emissions, efficiency categories and performance –

Fuel consumption, CO

₂

emissions, efficiency categories and performance.

Caddy Kombi

maximum

in kW (bhp)

Emission standard Fuel consumption2), 3) urban/extra-urban/ combined, in l/100 km

CO2 emissions3) combined in g/km

Efficiency category4) _Acceleration 0 –100 km/h (s)

Top speed

in km/h

1.2 l TSI BMT 5-speed manual gearbox 62 (84) Euro 6 6.9/4.8/5.6 131 C 14.7 157

1.4 l TSI BMT 7-speed DSG 92 (125) Euro 6 6.7/5.2/5.8 133 B 10.9 183

2.0 l TDI BMT 5-speed manual gearbox 55 (75) Euro 6 5.5/4.0/4.6 120 – 119 B – A 17.6 152

2.0 l TDI BMT 5-speed manual gearbox 75 (102) Euro 6 5.3/4.1/4.6 120 – 119 A 12.9 172

2.0 l TDI BMT 6-speed DSG 75 (102) Euro 6 5.8 – 5.7/4.6 – 4.5/5.0 131 – 130 B 13.0 170

2.0 l TDI BMT 4MOTION 6-speed manual gearbox 90 (122) Euro 6 6.5/4.8/5.4 143 B 11.5 178

2.0 l TDI BMT 6-speed manual gearbox 110 (150) Euro 6 6.0/4.3/4.9 129 B 9.9 194

2.0 l TDI BMT 6-speed DSG 110 (150) Euro 6 5.8/4.6/5.0 132 B 9.9 192

1.4 l TGI BlueMotion* 6-speed manual gearbox 81 (110) Euro 6 5.2/3.6 – 3.5/4.1 7.9/5.4/6.3

113 – 112 A 12.9 174

Caddy Maxi Kombi

maximum

in kW (bhp)

Emission standard Fuel consumption2), 3) urban/extra-urban/ combined, in l/100 km

CO2 emissions3) combined in g/km

Efficiency category4) _Acceleration 0 –100 km/h (s)

Top speed

in km/h

1.4 l TSI BMT 7-speed DSG 92 (125) Euro 6 6.7/5.3/5.8 133 B 11.3 183

2.0 l TDI BMT 5-speed manual gearbox 75 (102) Euro 6 5.5 – 5.4/4.2/4.7 123 – 122 A 13.3 172

2.0 l TDI BMT 6-speed DSG 75 (102) Euro 6 5.9/4.7 – 4.6/5.1 134 – 133 B 13.4 170

2.0 l TDI BMT 4MOTION 6-speed manual gearbox 90 (122) Euro 6 6.6/4.9/5.6 146 B 11.8 178

2.0 l TDI BMT 6-speed manual gearbox 110 (150) Euro 6 6.1/4.4/5.0 132 B 10.3 194

2.0 l TDI BMT 6-speed DSG 110 (150) Euro 6 5.9/4.6/5.1 135 B 10.3 192

1.4 l TGI BlueMotion* 6-speed manual gearbox 81 (110) Euro 6 5.3/3.6/4.3 8.1/5.6/6.5

116 A+ _13.7 ₁₇₄

(8)

– Weights – The new Caddy The new Caddy – Weights –

Weights.

Caddy Delivery Van and Caddy Delivery Van Trendline

maximum

in kW (bhp)

Emission standard Gross vehicle weight

in kg Unladen weight minimum8) in kg Payload maximum8) in kg

Axle load limit front/rear in kg Trailer weight braked 12 % gradient/ unbraked in kg Gross train weight 12 % gradient in kg

1.2 l TSI BMT 5-speed manual gearbox 62 (84) Euro 6 2,034 1,272 762 1,050/1,230 1,300/630 3,300

1.4 l TSI BMT 7-speed DSG 92 (125) Euro 6 2,095 1,333 762 1,050/1,230 1,500/660 3,595

2.0 l TDI BMT 5-speed manual gearbox 55 (75) Euro 6 2,127 1,365 762 1,075/1,230 1,400/680 3,527

2.0 l TDI BlueMotion 5-speed manual gearbox 75 (102) Euro 6 2,000 1,381 619 1,075/1,100 1,300/690 3,300

2.0 l TDI BMT 6-speed DSG 75 (102) Euro 6 2,177 1,415 762 1,100/1,230 1,500/700 3,677

2.0 l TDI BMT 4MOTION 6-speed manual gearbox 90 (122) Euro 6 2,251 1,489 762 1,140/1,230 1,500/740 3,751

1.4 l TGI BlueMotion 6-speed manual gearbox 81 (110) Euro 6 2,225 1,463 762 1,100/1,250 1,300/730 3,500

1.6 l TDI 5-speed manual gearbox 55 (75) Euro 5 plus 2,135 1,390 745 1,075/1,230 1,400/690 3,535

1.6 l TDI BMT 5-speed manual gearbox 55 (75) Euro 5 plus 2,135 1,390 745 1,075/1,230 1,400/690 3,535

1.6 l TDI 7-speed DSG 75 (102) Euro 5 plus 2,174 1,429 745 1,075/1,230 1,500/710 3,674

2.0 l TDI 4MOTION 6-speed manual gearbox 81 (110) Euro 5 plus 2,266 1,521 745 1,150/1,230 1,500/750 3,766

2.0 l TDI 4MOTION 6-speed DSG 103 (140) Euro 5 plus 2,280 1,547 733 1,150/1,230 1,500/750 3,780

Roof load limit in kg 100

(9)

The new Caddy – Weights –

– Weights – The new Caddy

Weights.

BMT = BlueMotion Technology DSG = dual clutch gearbox DSG *Figures in brackets apply to “increased payload” (optional extra).

Caddy Maxi Delivery Van and Caddy Maxi Delivery Van Trendline

maximum

in kW (bhp)

1.4 l TSI BMT 7-speed DSG 92 (125) Euro 6 2,255 (2,368)* 1,423 832 (945)* 1,050/1,300 (1,150/1,300)* 1,500/710 3,650

2.0 l TDI BMT 6-speed manual gearbox 110 (150) Euro 6 2,312 (2,425)* 1,480 832 (945)* 1,150/1,300 (1,200/1,300)* 1,500/730 3,800

2.0 l TDI 4MOTION 6-speed manual gearbox 81 (110) Euro 5 plus 2,350 1,612 738 1,200/1,250 1,450/750 3,800

2.0 l TDI 4MOTION 6-speed DSG 103 (140) Euro 5 plus 2,350 1,638 712 1,200/1,250 1,450/750 3,800

(10)

– Weights – The new Caddy The new Caddy – Weights –

Weights.

BMT = BlueMotion Technology DSG = dual clutch gearbox DSG *1.4 l TGI Blue Motion 7-seater and above have no trailer nose weight.

Caddy Kombi

maximum

in kW (bhp)

(11)

The new Caddy – Weights –

– Weights – The new Caddy

Weights.

Trailer nose weight in kg* 75

BMT = BlueMotion Technology DSG = dual clutch gearbox DSG *1.4 l TGI Blue Motion 7-seater and above have no trailer nose weight.

Caddy Maxi Kombi

maximum

in kW (bhp)

(12)

– Dimensions – The new Caddy The new Caddy – Dimensions –

Dimensions.

The dimensional drawings partially show optional extras. All measurements listed are based on series vehicles. The height measurements listed may vary by ± 50mm depending on equipment fitted. The information about the degree of slope angle front and rear as well as the ramp angle each refer to the loaded condition of the vehicle in consideration of the gross vehicle weight. The vehicle drawings are not to scale.

Caddy Delivery Van and Caddy Delivery Van Trendline Caddy Maxi Delivery Van and Caddy Maxi Delivery Van Trendline

2682 4408 4506 879 W1 W3 W2 847 B1 B2 1793 2065 L1 H2 H1 H5 _H3 H4 879 3006 993 4878 4976 H2 H1 W1 W3 W2 B1 B2 H5 _L1 1793 2065 H3 H4 Model/ Dimensions

Caddy Maxi Caddy Maxi 4MOTION

Caddy Maxi TGI BlueMotion

B1/B2 load compartment width, min./max. (mm) 1,168/1,532 H1 ground clearance (measured

underneath the engine guard) (mm) 163 162 149 H2 loading sill over stationary level (mm) 588 652 588

H3 vehicle height (mm) 1,836 1,886 1,836

H4 vehicle height incl. roof railing (mm) 1,872 1,922 1,872

H5 loading height (mm) 1,259

L1 load compartment floor length (mm) 2,249

W1/W2 approach and departure angle, front/rear (°) 16.7/14.8 15.2/20.1 16.7/14.8

W3 ramp angle (°) 12.1 12.7 10.5

side sliding door(s),

width x height (mm) 701 x 1,092 tailgate, width x height (mm) 1,183 x 1,134 load compartment volume (m3₎ _4.2

load compartment volume with

Flex Plus seat package (m3₎ _4.7 minimum turning circle, approx. (m) 12.2

Model/ Dimensions Caddy Caddy TDI BlueMotion Caddy 4MOTION Caddy TGI BlueMotion

underneath the engine guard) (mm) 166 125 151 124 H2 loading sill over stationary level (mm) 577 547 642 577

H3 vehicle height (mm) 1,823 1,793 1,873 1,823

H4 vehicle height incl. roof railing (mm) 1,860 – 1,909 1,860

L1 load compartment floor length (mm) 1,779

W1/W2 approach and departure angle, front/rear (°) 17.1/17.3 13.2/18.1 15.3/23.1 17.1/17.3

W3 ramp angle (°) 14.0 12.3 15.0 12.8

width x height (mm) 701 x 1,097 tailgate, width x height (mm) 1,183 x 1,134 load compartment volume (m3₎ _3.2

load compartment volume with

Flex Plus seat package (m3₎ _3.7 minimum turning circle, approx. (m) 11.1

(13)

The new Caddy – Dimensions –

– Dimensions – The new Caddy

Dimensions.

The dimensional drawings partially show optional extras. All measurements listed are based on series vehicles. The height measurements listed may vary by ± 50mm depending on equipment fitted. The information about the degree of slope angle front and rear as well as the ramp angle each refer to the loaded condition of the vehicle in consideration of the gross vehicle weight. The vehicle drawings are not to scale.

Caddy Kombi (5-/7-seater) Caddy Maxi Kombi (5-/7-seater)

1793 2065 26824408 4506 879 W1 W3 W2 847 L3 L2 L1 B1 B2 H2 H1 H5 _H3 H4 L2 _L3 L1 1793 2065 879 30064878 993 4976 W1 W3 W2 B1 B2 H2 H1 H5 _H3 H4 Model/ Dimensions

Caddy Maxi Caddy Maxi 4MOTION

Caddy Maxi TGI BlueMotion

L1/L2/L3 load compartment floor length,

behind 1st_/2nd_/3rd_{row of seats} _(mm) _{2,250/1,566/644}

W3 ramp angle (°) 12.1 12.6 12.1

width x height (mm) 701 x 1,084 tailgate, width x height (mm) 1,183 x 1,134 load/passenger compartment

volume, for 2-/5-/7-seater (m3_{) [l]} _{4.1/1.6/0.5 [4,130/1,650/530]} minimum turning circle, approx. (m) 12.2

Model/ Dimensions Caddy Caddy 4MOTION Caddy TGI BlueMotion

L1/L2/L3 load compartment floor length,

behind 1st_/2nd_/3rd_{row of seats} _(mm) _{1,781/1,095/224}

W3 ramp angle (°) 13.5 14.8 13.2

width x height (mm) 701 x 1,086 tailgate, width x height (mm) 1,183 x 1,134 load/passenger compartment

volume, for 2-/5-/7-seater (m3_{) [l]} _{3.2/0.9/0.2 [3,200/918/190]} minimum turning circle, approx. (m) 11.1

(14)

– Tyre label – The new Caddy The new Caddy – Tyre label –

Tyre label.

Placing an order for a specific tyre brand is not possible due to logistical and production process reasons.

Caddy and Caddy Maxi

Summer tyres Size Rolling resistance Wet grip External rolling noise Noise emission

195/65 R 15 E – B C – A 72 – 69 dB

205/55 R 16 E – B C – B 73 – 69 dB –

205/50 R 17 E – B E – B 72 – 69 dB –

All seasons tyres Size Rolling resistance Wet grip External rolling noise Noise emission

195/65 R 15 E E 70 dB

205/55 R 16 E E 69 dB

Winter tyres Size Rolling resistance Wet grip External rolling noise Noise emission

195/65 R 15 F – E E – B 73 – 68 dB –

205/55 R 16 E C 67 dB

Fuel efficiency – the right tyre type can help you save on fuel. Wet grip – a shorter braking distance increases safety.

(15)

– Notes – The new Caddy The new Caddy – Notes –

Notes.

1) (Footnote not included in this document.)

2) Fuel tank capacity for models with Euro 6 emission standard: petrol (except for TGI) or diesel approx. 55 l, AdBlue® (for TDI) approx. 9 l. Fuel tank capacity for TGI: CNG approx. 26 kg (Caddy) or approx. 37 kg (Caddy Maxi), petrol approx. 13 l. Fuel tank capacity for models with Euro 5 plus emission standard: diesel approx. 60 l.

3) The fuel consumption and emission values listed here have been ascertained in accordance with the measuring method stipulated. These figures do not refer to a particular specific vehicle and do not constitute part of the offer but are purely for comparison purposes between the various types of vehicle. In addition to the fuel efficiency of a vehicle, driving behaviour as well as other non-technical factors (such as environmental conditions) play a role in determining a vehicle’s fuel consumption and CO₂ emissions. In addition to weather and traffic conditions, extra equipment and accessories (attachment parts, tyres, etc.) may change vehicle parameters such as the weight, rolling resistance of the tyres and the aerodynamics and thus influence the fuel consumption and driving performance values. Where a range of values is given for fuel consumption and CO₂ emissions, the figures depend on the tyre size and optional extras selected. Please note that, in accordance with the version of directive 1999/94/EC currently valid, further information on the official fuel consumption and official specific CO₂ emissions of new passenger cars is given in a guide containing data on fuel consumption, CO₂ emissions and power consumption for new passenger car models. It is available free of charge at every point of sale in the European Union or, for prospective buyers in Germany, at DAT Deutsche Automobil Treuhand GmbH, Hellmuth-Hirth-Strasse 1, 73760 Ostfildern, and under www.dat.de.

4) Efficiency classes evaluate vehicles on the basis of CO₂ emissions, taking into account the vehicle’s unladen weight. Vehicles corresponding with the average are given a D rating. A+_{, A, B or C ratings are given to vehicles which} are better than the present-day average, and E, F or G to those below this average.

5) The use of 95 RON unleaded sulphur-free super petrol in accordance with DIN EN 228 is recommended. The use of 91 RON sulphur-free petrol in accordance with DIN EN 228 is possible, in this case a slight decrease in performance or higher fuel consumption must be reckoned with. Fuel quality unleaded with 95 RON with a maximum ethanol blend of 10 percent (E10) is generally suitable. For detailed information on E10 fuel compatibility, please refer to www.volkswagen.de or www.dat.de/e10liste/e10vertraeglichkeit. The performance and fuel consumption figures listed are based on the use of 95 RON unleaded sulphur-free super petrol in accordance with DIN EN 228.

6) This engine is fitted with a multi-step exhaust gas after-treatment system (diesel particulate system and SCR catalytic converter). The SCR catalytic converter (Selective Catalytic Reduction) selectively converts nitrogen oxide (NO_X) exhaust components into diatomic nitrogen (N₂) and water (H₂O). The conversion is carried out with the help of a synthetically-produced, water-based urea solution such as AdBlue® (ISO 22241-1/AUS 32), which is stored in an auxiliary tank. Depending on the vehicle, the customer must also refill the AdBiue® independently or have it refilled at an authorized workshop between service intervals.

7) Primary operation with natural gas (CNG); only powered by petrol in reserve mode.

8) The unladen weight listed here includes 68 kg for the driver, 7 kg for the luggage, all operating fluids and fuel tank 90 % full, determined in accordance with directive 92/21/EEC or directive 97/27/EEC currently valid. Equipment or equipment lines may affect the unladen weight. A vehicle’s actual payload, which results from calculating the difference between the gross vehicle weight and the unladen weight, can only be determined by weighing the individual vehicle.

(16)

– General and additional information – The new Caddy

General and additional information.

Please note that some of the special equipment and optional extras listed here are bound to specific combinations and/or cannot be combined and may be subject to certain legal requirements. Volkswagen will explicitly not be held liable for the improper use of such optional equipment. Certain special equipment and optional extras may lead to longer delivery periods. Please discuss your individual requirements with your Volkswagen Commercial Vehicles dealer. Only your Volkswagen Commercial Vehicles dealer is able to check the necessary combination requirements as well as verify the accuracy and completeness of data in the purchasing system.

TSI®, TDI®, TGI®, DSG®, 4MOTION® and BlueMotion® are registered trademarks of Volkswagen AG and other companies in the Volkswagen Group in Germany and in other countries.

The fact that a character in this document is not marked with ® does not mean that it is not a registered trademark and/or that this character may be used without the written approval of the Volkswagen AG. The product name AdBlue® is a registered trademark of the Verband der Automobilindustrie e.V (VDA). iPod/iPhone are registered trademarks of Apple Computer International.

Our vehicles are equipped with summer tyres as standard. As of 04.12.2010 you are required by law in the Federal Republic of Germany to equip your vehicle with M+S tyres or all-weather tyres in wintry weather conditions with black ice, packed snow, slush, ice or slippery frost. Please contact your Volkswagen Commercial Vehicles dealer for assistance.

All details in this document are based on the features of the German market and are in accordance with the information available at the time of going to print. Subject to change without notice.

Additional information:

Service dates at Volkswagen are divided up into “oil change service” and “inspection service”. The service interval indicator on the display of the instrument cluster serves to remind you of the next service date. Service intervals:

– Oil change service: according to the flexible service interval indicator, no later than every 2 years with maintenance interval extension or 15,000 km and/or no later than 1 year without maintenance interval extension, whichever occurs first.

– Inspection service: first inspection service after 2 years or 30,000 km, whichever occurs first; then annually or after 30,000 km, whichever occurs first.

Take-back and recycling of end of life vehicles:

Volkswagen meets the challenges of modern society and takes them into consideration in all new products of the Volkswagen brand. This naturally also applies to protection of the environment and resources. All new Volkswagens can therefore be recycled in an environment-friendly way and can be returned free of charge, subject to fulfilment of national legislation. For details concerning take-back and recycling of end of life vehicles, please contact your Volkswagen Commercial Vehicles dealer, refer to the Internet on www.volkswagen.de or call the hotline +49 800 - Volkswagen (+49 800 865 579 2436), free for callers in Germany.

(17)

565.1190.01.18 • Printed in Germany Subject to change without notice Issue: May 2015

www.volkswagen-commercial-vehicles.com
