Everything You Need to

Know About Oracle Exadata

Backup and Recovery:

Best Practices

Andrew Babb,

Consulting Member of Technical

Staff, Oracle

Donna Cooksey

, Principal Product Manager, Oracle

Harpreet Singh

, Vice President, Database

Management, Fidelity Investments

(2)

The following is intended to outline our general product direction. It is intended

for information purposes only, and may not be incorporated into any contract.

It is not a commitment to deliver any material, code, or functionality, and should

not be relied upon in making purchasing decisions. The development, release,

and timing of any features or functionality described for Oracle’s products

remains at the sole discretion of Oracle.

(3)

Program Agenda



Evolving IT Infrastructure



Recovery, Recovery, Recovery



Architecting Your Backup Infrastructure



Customer Case Study – Fidelity Investments



New Modern Cloud Paradigm

(4)

Evolution of Data Protection



IT consumers are increasingly involved in technology decisions

–

The flexible, fast moving opportunities of the “3

rd

Platform” translate to

more IT initiatives being driven by Line of Businesses (LOB)

–

Applications, storage, servers … even data protection?



Technology in stealth mode makes a sound data protection even

more important !

Business Requirements Meeting IT Head-on

Greater Complexity Causing More Data Center Downtime:

(5)

Critical Databases Get Poor Protection Today

What Business Wants



Never lose business data



Keep critical apps available

What IT Wants



Private and public cloud solution



Ensured end-to-end protection

What Business Gets



Data loss on restore, typically full day



End-user slowdown during backup

What IT Gets



Sprawl of non-scalable solutions



Uncertain protection, poor visibility

(6)

Primary Causes of Downtime

2012 IOUG Survey – Enterprise Data and The Cost of Downtime*

Human

Error

Storage

Failure

Application

Errors

Network

Outages

Server

Failure

Recovery plan /

Training /

Oversight

Interoperability /

Scalability /

Performance

Failover /

Fallback

capabilities

System

Monitoring

Unplanned

Downtime

*http://www.oracle.com/us/products/database/

(7)

Bad News Travels Faster Than Good

What is The Cost of Downtime?

NASDAQ HALTS TRADING FOR THREE HOURS:

http://www.businessinsider.com/nasdaq-options-market-halted-2013-8

NASDAQ HALTS TRADING FOR THREE HOURS:

http://www.businessinsider.com/nasdaq-options-market-halted-2013-8

NASDAQ HALTS TRADING FOR THREE HOURS:

(8)

Recovery, Recovery,

Recovery

(9)

What are Your Recovery Requirements?

Four Key Points to Define

1

2

3

4 Recovery Point

Objective (RPO)

Retention

Period

Recovery Time

Objective (RTO)

Disaster

Recovery

(onsite/offsite)

(10)

Group Databases Into Protection Tiers

Basic Grouping Strategy - Example

Gold

Silver

Bronze

RTO

Seconds

< 6 Hours

Up to 24 hours

RPO

Current

Up to 3 hours*

Up to 6 hours*

Backup

Retention

Critical

Restores

Up to one week

One day

One day norm / not

critical

Retention

7 Years

6 months

1 month

DR /

Long-term

Two sites for one

week

Offsite copy within 3

days

No specific DR

requirement

(11)

Exadata Environments



The criticality and workloads of typical Exadata databases makes

recovery strategies especially important:

–

Batch load / NOLOGGING operation went south

–

Long-term, periodic archival backups (keep forever / until)

–

Application patches and upgrades

–

Backing out a bad transaction

(12)

Oracle Recovery Strategies

Complementary and Integrated Technologies

Technology / Solution

Recovery Time

Objective (RTO)

Recovery Point

Objective (RPO)

Physical Data Protection

• Recovery Manager (RMAN)

• Oracle Secure Backup (OSB)

Days/Hours

As of last backup

• Data Guard or Active Data Guard

_{Minutes/Seconds}

_Current

Logical Data Protection

• Flashback Technologies

Hours/Minutes

Minutes

Recovery Analysis

• Data Recovery Advisor (DRA)

• Minimizes time for problem

identification & recovery planning

(13)

Oracle Logical Data Protection Technologies



Flashback Technologies are a suite of logical error investigation and correction

capabilities built-in the Oracle database:

–

Error investigation:

Flashback query, version query and transaction query

–

Error correction:

Flashback database, table, drop and transaction



Flashback Database operates on physical data blocks and is similar in effect to

point-in-time recovery - other Flashback features operate at logical level

–

Only Flashback feature which must be explicitly enabled by user as it generates logs



In applicable scenarios, Flashback features are more efficient than media

recovery

Complements Physical Data Protection Strategy

(14)

Restore Points



Restore point is a user-defined name assigned to an SCN or specific point in time

– a user-friendly “bookmark”



FLASHBACK DATABASE TO RESTORE POINT 'before_upgrade';



User-defined restore point names may be used as aliases for SCN with the

following supported commands:

–

RECOVER DATABASE and FLASHBACK DATABASE commands in RMAN

–

FLASHBACK TABLE in SQL

What They Are and Why Use Them



There are two types of restore points – Normal and Guaranteed



Guaranteed must be explicitly deleted by the user



Normal age out of the control file



For archival backups, use the PRESERVE key word to retain the

restore point until backup expiration

(15)

Flashback Database VS Point-in-Time Recovery

Different Approaches and Multiple Use Cases

Flashback Database

Traditional Point-in-Time Recovery

Rewinds the database to SCN

Restores then recovers the database to SCN

Advantages

• Significantly faster than point-in-time recovery - No

restore and only limited redo needed

• Useful during database upgrades, application

deployments, and efficient alternative to rebuilding a

failed primary database after a Data Guard failover

• Provides continuous data protection

• Compatible with restore points

 Works at the database or tablespace level

 No additional logs necessary beyond redo

 Compatible with restore points

Disadvantages

 Requires Flashback logs and associated storage

 Works at whole database level only

 Flashback logging has some (minimal) overhead on

database server

 Time consuming especially for larger databases

 Database is down until fully recovered

(16)

Data Recovery Advisor (DRA)



Oracle Database tool that automatically diagnoses data failures, presents

repair options, and executes repairs at the user's request



Determines failures based on symptoms

–

Failure Information recorded in diagnostic Automatic Diagnostic Repository (ADR)

–

Flags problems before user discovers them, via automated health monitoring



Intelligently determines recovery strategies

–

Aggregates failures for efficient recovery, presents only feasible recovery

options and indicates any data loss for each option



Can automatically perform selected recovery steps



Accessed via RMAN or EM

(17)

How Good is Your Backup Infrastructure?

1. Documented recovery plan

for database and object level recovery

2. Perform periodic (i.e. regularly) recovery tests for various recovery

scenarios

:

1. Full database

2. Objects

3. Control file

3. Refresh test environments with RMAN

4. If hardware isn’t available to perform full database recovery tests,

use RMAN RESTORE VALIDATE

You Never Know – Unless Your Periodically Test It !

(18)

Architecting Your Backup

Infrastructure

(19)

Full Backup

 Two types of RMAN full backups:

 Image copy – Disk only

 Same size as the database less temp

files

 Backupset – Disk or tape

 Smaller than image copy full

 Can be compressed and/or encrypted

by RMAN

 Full backup consumes more overhead on the

production server and take more time than an

incremental backup

 Restoration may be faster than an incremental

RMAN Traditional Backup Strategies

Full / Incremental Schedule

 Backupset backups – Disk or tape

 Typical schedule – Week full with daily incremental

backups

 Typical retention:

– Days to weeks – On disk

– Weeks to years – On tape

– Full and corresponding incremental backup

should be treated as a group

• Reduces backup window and overhead on servers

• Ideal with low-medium change rate e.g. <20%

• Database must be in archived log mode

(20)

RMAN Incremental Forever Strategy

Oracle Database 10g Release 2 Enterprise Edition >

Incremental forever after initial full image copy

Full image copy is rolled forward on user-defined schedule

• Roll-forward / merge does incur overhead on server

• Offers SWITCH TO COPY capability

Typical retention – One to seven days

Backup full or incremental to tape

(21)

Processing Offloaded From Database Nodes



Block Change Tracking (BCT) enables fast incremental backups

–

RMAN tracks 32k data file sections which include a changed block(s)

–

During an incremental backup, RMAN scans these 32k file sections to

determine which block(s) have changed



Only these changed blocks are included in the incremental backup

Incremental Backup Scans Occur on Exadata Storage Cells

Note: Incremental backup without Block Change Tracking (BCT) enabled –

all database blocks are scanned to determine what has changed

Database Server

Exadata

Scan of blocks occurs

on the database server

Scan of blocks is

offloaded

to the

(22)

Backup of Compressed Data



Compressed data remains compressed in the backup

–

This data will not benefit from further compression during the

backup (e.g. RMAN backup or tape drive compression)

–

Deduplication software cannot deduplicate compressed data

Effects on Sizing and Processes

HCC Data

OLTP Compressed Tables

SecureFiles

Compressed/Deduplicated



RMAN backup compression is effective on non-compressed database files



Avoid using RMAN backup compression on HCC tablespaces by separating the

backups as shown below:



Restore is no different than if the backups had not been separated

CONFIGURE EXCLUDE FOR TABLESPACE historical_data;

CONFIGURE COMPRESSION ALGORITHM 'low’;

BACKUP TABLESPACE historical_data;

(23)

Protecting Exadata Operating System Files



On the Exadata Storage Cells, the internal USB stick provides the

backup



On the Exadata database nodes, backup the operating system(OS)

files in the same manner as with any other database server

Please refer to the documentation for more information:

(24)

Exadata Backup Targets



20 – 25 TB / hour



All Exadata smart

features

Considerations - Performance and Cost Trade-offs

Highest Performance

High Performance and Added Flexibility

Cost – Varies with hardware configuration

Exadata

Storage

Exadata

Storage

Expansion

Rack

ZFS

Storage

Appliance

(ZFS/SA)

StorageTek

Tape

Library



27 TB / hour



Fastest Backup and Restore



ILM Historical Archive



Second DATA2 Disk Group



13 TB / hour



Backups of database &

non-database files



Snapshots



Clones



9 TB hour*



Backup of database and

non-database files



Offsite Backups

(25)

Oracle-Integrated Backup to Disk and/or Tape

Multi-media Strategy: Disk-to-Disk-to-Tape (D2D2T)

Fast Recovery Area

RMAN Disk Backup

Backup to Tape

BACKUP RECOVERY AREA;

BACKUP BACKUPSET;

D2D2T

Exadata

StorageTek

Tape Library

• Fast Recovery Area should reside on Exadata storage – slower storage

could degrade production database performance

• Online redo, archived logs, Flashback logs, controlfile

ZFS Storage

Appliance

(26)

Expanding Exadata Environments

Connectivity Considerations

FRA

RMAN Disk

Backup

Exadata

ZFS Storage

FRA

What happens when a

2 nd

_{Exadata is added?}

InfiniBand

What about a 3

rd

Exadata?

FRA

10Gigabit Ethernet

The two Exadatas MUST be

configured with different

InfiniBand Subnets.

The 3

rd

_{Exadata would be}

connected via 10Gigabit

Refer to the MAA white paper:

http://www.oracle.com/technetwork/database/features/availab

ility/maa-wp-dbm-zfs-backup-1593252.pdf

(27)

Customer Case Study –

Fidelity Investments

(28)

Oracle Open World

Exadata Backups

September 24, 2013

Harpreet Singh

Vice President, Database Management

Fidelity Investments

(29)

Transition To Exadata – A Huge Success!

Challenges with traditional infrastructure

• 300TB of storage with over 60% annual growth rate

• Performance challenges

• Cost reduction pressures

• Need to make failover/recovery more robust

Benefits gained with Exadata

• 42x performance gains for reporting & 40% for OLTP

• Reduced storage by 30% using compression

• Consolidated physical servers from 10 to 4

• Reduced direct/indirect chargebacks by 30%

(30)

(31)

Pre-Exadata Backup Challenges

Over 60%

annual data

growth rate

Business

needs growing

and becoming

more complex

Expensive

software/hardw

are licenses

Costly to keep

backups on the

disk

Backups

hurting

database

performance

Complicated

recovery with

“no-logging”

Concerns

around

non-logical DR

software

(32)

Fundamental Data Protection Strategy

1 st

_{Line of}

Defense

• Flashback: 48

hours

• data deletion

• logical corruption

• user errors

2 nd

_{Line of}

Defense

• Disk Backup: 24

Hours

• application

• system

3 rd

_{Line of}

Defense

• Standby Database

(DR)

• Building/site, region

• HW failure

Last Line of

Defense

• Tape: 35 Days

• Offsite

• multi-site failures

(33)



Pros



Faster recovery



Data recovery from tables, schema, or entire database



Roll database back and forth repeatedly within the

flashback window for complex data restore



Cons



Same location as production

–

No protection from storage failure



No protection from physical corruption

Flashback

Disk Backup

Standby Database

Tape Backup

• Oracle Flashback Database

• Primary and Standby Sites

Flashback

Retention Period:

48 Hours

Restore Time:

< 1 Hour

(34)

Flashback

Disk Backup

Standby Database

Tape Backup



Pros



Protect against physical/logical database corruption



Faster backup and restore



Minimal overhead to the production database



Cons



Shorter protection window (24 hours)



Same location as production so no protection from DR

or catastrophic storage failure

• Exadata Fast Recovery Area

• Incrementally Updated

Disk Backup

Retention Period:

24 Hours

Backup Rate:

1.2 TB/hour

Restore Rate:

1 TB/hour

Type:

RMAN

Online

Daily

Normal

Redundancy

(35)

Flashback

Disk Backup

Standby Database

Tape Backup



Pros



Great for any data recovery when combined with Flashback

Database



Complete data protection if primary site is lost



Protection from physical corruption



Can be turned into snapshot standby database temporarily

and used for QA/Dev database refreshes through RMAN



Cons



Resources (another set of servers/storage)

• Data Guard

• Asynchronous

• No Delay Apply

• 48 Hour Flashback Database

setup

• 700 miles between Primary

and Standby sites

(36)

Flashback

Disk Backup

Standby Database

Tape Backup



Pros



Longer term offsite retention than disk and standby



Media is relatively cheap



Cons



Slower backup and restore than disk



Media is less reliable

Tape Backup

Retention

Period:

35 Days (Offsite)

Channels:

2-4

Nodes:

1 Backup Rate:

1TB/hour (2 channels)

Restore Rate:

800GB/hour (2 channels)

RTO:

3 Days

Type:

RMAN

CommVault

Archived Redo

Logs Retention

3 Days on disk

Archived Redo

Logs Backup

Every 30 minutes

(37)

Planning a Comprehensive Backup Strategy

• Consider full backups once a week with daily

incremental

Determine disk backup

strategy

• Implement Oracle suggested RMAN backup

strategy as it is great protection against data loss

Develop tape backup

process

• At least annually

Test different restore

processes

• Should be centrally managed

Consolidate tape backup

system

(38)

Implementation Recommendations

Optimal performance

• Configure Exadata backup over

InfiniBand for better throughput

• Configure number of channels

based on database size and SLAs

• Use one RMAN channel per tape

drive for better throughput

• Enable block change tracking for

fast RMAN incremental backups

Data protection and

disaster recovery

• Backup Archived Log every 30

minutes for better data protection

• Encrypt the data before writing to

tape for data security

• Set-up Flashback on both primary

and standby databases

• Utilize Data Guard broker

Monitoring

• Use Oracle Enterprise Manager to

monitor:

• Disk backup

• Tape backup

• Data Guard

• Flashback

(39)

Summary



Have clear and well communicated recovery SLAs



Build your strategy around the business needs



Revisit a well-documented, multi-level strategy

periodically



Be conservative and prepare for the worst



Test

(40)

The New Modern Cloud

Paradigm

(41)

Oracle Database Backup Logging Recovery Appliance

Please refer to Oracle.com for additional information:

http://www.oracle.com/us/corporate/features/database-backup-logging-recovery-appliance/index.html
