Network Peripheral. Network Peripheral. Sharing Resource Everywhere at Business and Home. > Network Storage Server...

Network Peripheral

Network Peripheral

Sharing Resource Everywhere

at Business and Home

>

Network Storage Server

...

>

Print Server

...

>

KVM Switch

...

>

IP Power Manager

...

>

Ethernet Adapter

PL ANET Net work Peripheral saves the additional cost for users to create an effective net-work environment with most convenient net work periph-eral devices, such as installing a print ser ver to share one printer to all users in the of-fice. It also allows the Inter-net users to login and print their documents. The Internet management helps net work administrators to monitor the power status and turn on/off the remote connected devices without being in the computer room.

Network Peripheral

NAS-7102

1-Bay SATA NAS Server

• The Administrator can Limit the Amount of Available Disk Space to Individual Users

• 1 Standard USB 2.0 Port for External USB HDD & Print Server Sharing

• Supports Windows Utility and Web Base Manage

• Share Music, Pictures, Movies and Data over Network

• Supports BT Download

• DLNA compatible

• Interface: 10/100/1000Base-TX(Auto MDI/MDI-X), supports auto crossover detection

• Supports most popular OS including Windows VISTA/XP/2000, Mac OS x v10.2 or later

NAS-7400

4-Bay SATA NAS RAID Server

• Up to four hot-swappable SATA II 3.5-inch disk drivers up to 6TB

• 10/100/1000M - Gigabit Ethernet port

• RAID level support: RAID 0, 1, 5 and 10

• Multi-protocol system support for Windows, UNIX, Linux and Macintosh

• The Administrator can Limit the Amount of Available Disk Space Available to Individual Users

• NAS-to-NAS data synchronization and backup

• User, group and folder quota control

• Support UPnP Auto-IP and DHCP client

• 2 Standard USB 2.0 Port for External USB HDD and Print Server Sharing

• Multi-language support and user friendly web management interface

• UPnP and DLNA certified Digital Media Server, iTunes Media Server

NAS-7201

2-Bay SATA NAS RAID Server • Supports RAID O/1 and JBOD

• Supports 10/100/1000Base-TX, Auto-MDI / MDIX network interface

• 2 Standard USB 2.0 ports for external USB HDD and print server sharing

• Windows utility and web base management interface

• UPnP-AV to share music, pictures, movies and data over network (DLNA1.5)

• PHP supported for web station

• Download function: BT, FTP and HTTP

• Powerful backup function from / to other servers

• Windows Vista LLTD, PnP-X,

Media Server function: iTunes, MP3 broadcast

Network Storage Server

NAS-7400

Model NAS-7400 NAS-7201 NAS-7102

Product Image

CPU 400MHz 300MHz 250MHz

RAM 128MB 128MB 32MB

Hard Disk Tray SATA I/II x 4 SATA I/II x 2 SATA I/II x 1

Scalability Up to 6TB Up to 2TB Up to 1TB

Network Interface Gigabit x 1 Gigabit x 1 Gigabit x 1

RAID Support RAID 0, 1, 5, 10 RAID 0, 1

FTP Support   

Market Position Enterprise SMB/SOHO SOHO

User Management  - Download Management    iTunes    MP3 Broadcase - - BT/FTP/HTTP Download - BT  DLNA  -  NAS-7201 NAS-7102

Network Peripheral

FPS-1011

USB2.0 GDI Print Server

• Standard USB2.0 interface supported

• Support for most popular NOS

• Automatically detect the connected cable type while it connects to different LAN devices

• Intuitive utility of management supports Windows 95/98/2000/ Me/NT/XP/Server 2003/Vista or Web-Base Management

• Acts as IPP (Internet Printing Protocol) Server. It allows your clients, suppliers, or colleagues to operate your printers from anywhere on the Internet

• Compliant with GDI printers and share the printer on your network

FPS-1012N

802.11n Wireless USB MFP Print Server • Support for most popular NOS

• Supports 10/100Mbps Auto-Nway, Automatically Negotiates optimal mode

• Auto detects the connected cable type while connecting to different LAN devices

• Intuitive management utility provided for Windows 98/2000 /Me/NT/XP/Server 2003/Vista/Windows7 or Web-Base Management

• IPP (Internet Printing Protocol) Server, allowing your clients, suppliers, and colleagues to operate your printers from anywhere on the Internet

• support most of the MFP of the market, such as HP, Canon, EPSON, Lexmark, SamSung and etc

• Supports GDI interface

• IEEE 802.b/g/n interface compatible

FPS-1012N FPS-1011

FPS-3121 / FPS-3121G

Multi-Port Print Server

• Supports NetWare, Windows 98/NT/2000/Me/XP/Server 2003, Linux, Unix, and MAC OS

• Supports 10/100Mbps Auto-Nway, Automatically Negotiates optimal mode with Auto MDI/MDI-X

• 2 parallel and 1 USB interface to printer connected

• Supports up to 7 logical printers for TCP/IP networks

• Intuitive management utility provided for Windows 98/

NT/2000/Me/XP and Server 2003/Vista, Web-Base Management, SNMP Supported

• Compatible with IEEE 802.11b/g interface (FPS-3121G)

FPS-3121G

FPS-1101

Direct Attach Print Server

• Slim size and direct attach to your printer without additional cable

• Compliant with standard DB-36 port

• Compatible with Windows 95/98/Me/2000/NT/XP/Server 2003/ Vista, Novell, Linux, Unix, and MAC OS

• Supports TCP/IP, IPX/SPX, AppleTalk, Bi-Directional protocol

• Supports 10/100Mbps Auto-Nway, Automatically Negotiates optimal mode with Auto MDI/MDI-X

• Intuitive utility of management supports Windows 98/2000/ Me/NT/XP/Server 2003/Vista and Web-Base Management

• HP Web JetAdmin compatible

FPS-1101

Print Server

FPS-3300

Multi-Port Print Server

• Supports with 3 standard DB-36 port

• Compatible with Windows 95/98/Me/2000/NT/XP/ Server 2003/Vista, Novell, Linux, Unix, and MAC OS

• Supports TCP/IP, IPX/SPX, AppleTalk, Bi-Directional protocol

• Supports 10/100Mbps Auto-Nway, Automatically Negotiates optimal mode with Auto MDI/MDI-X

• Intuitive utility of management supports Windows 98/ 2000/Me/NT/XP/Server 2003/Vista and Web-Base Management

• HP Web JetAdmin compatible

Switch Windows Linux MAC

FPS-3300

Internet

Network Peripheral

KVM-E500

KVM CAT5 Extender

• Use CAT5, CAT5e, or CAT6 Ethernet cable to connect Transmitter and Receiver units

• Extension distance is up to 500 feet (150M)

• The provided local and remote consoles allow users to perform the management nearby or faraway

• Administrator can control the local PC and remote servers in local console

• No software is required

• Compatible with DOS, Windows, Linux, Unix and Netware

KVM-210 / KVM-410

2/4 Port Combo KVM Switch

• Complex connections with PCs via either way of PS/2 and/or USB arbitrarily

• Emulates a keyboard on each PC to allow your computers to boot normally without a keyboard error

• Supports hot-swap. All devices connected to the KVM can be added or removed at any time without shutting the unit down

• VGA resolutions up to 2048 x 1536 @ 85HZ

• Self powered through PS/2 and/or USB connection

KVM-210 / KVM-410

DKVM-1700

Drawer KVM Console with 17” LCD • Easy to install, single rail design

• Supports Sun native resolution

• Supports 17 keyboard languages (continually increase)

• Bright Active TFT display

• Provides different KVM modules for installation, integration with 4 model of KVM switches

• PS/2 module built-in one extra daisy chain port to cascade with KVM-800/1600

IKVM-8000

8 Port IP KVM Switch • 19” rack mount size design

• Compliant with DOS, Win3.X, Win95/98/98SE/NT/2000/Me/XP/ Server2003/Vista, Netware, Unix, Linux

• Compliant with iMAC, Power MAC and Sun Microsystems with USB port (Need work with USB-PS/2 adapter)

• High Video Quality - Resolution Up To 1920 x 1440 (local side), 1280 x 1024 (remote side)

• No Software Required - easy PC selection via On Screen Dis play (OSD) menu, Push Buttons, Hot Keys

• Supports SSL protocol for any encrypted network traffic be tween itself and a connected client

• Built-in daisy chain to cascade with KVM-800/1600

• Built-in 8-Port KVM switch

DKVM-1700

KVM-201 / KVM-401

2/4 Port PS/2 KVM Switch

• Supports for DOS, Windows 3.x/95/98/98SE/Me/NT/2000/XP/ Server 2003/Vista, Unix, Linux

• Hot-Plugging of PCs for maintenance without powering down the KVM Switch or PCs

• Push button or hot key control for easy computer selection

• Plug-and-play, no Windows driver software needed for PS/2 keyboard and PS/2 operation

• LED indicators for easy status monitoring

KVM-800 / KVM-1600

8/16 Port Stackable PS/2 KVM Switch

• No software required easy PC selection via Push button and Hot key functions

• 19” rack mount size design

• Daisy chain up to 7 additional units to control up to 128 computers from single console

• OSD (On Screen Display) supported visualize computer management

• Auto scan mode for monitoring PC

• Plug and play system configuration

KVM-1600 KVM-800 IKVM-8000 KVM-E500

KVM Switch

DKVM-PS8 / DKVM-PS16 8/16 Port PS/2 Module for DKVM-1700

DKVM-CF8 / DKVM-CF16 8/16 Port Combo-Free Module for DKVM-1700

Accessories KVM-800 / KVM-1600

USB-PS2 USB to PS/2 Converter

Accessories IKVM-8000

USB-PS2 USB to PS/2 Converter

Network Peripheral

IP Power Manager

IPM-8001 / IPM-8002

IP Power Manager

• Eight power outlets that can be turned on or off in multiple ways, with easy monitoring of current consumption

• Actives extended devices via digital outputs

• Monitors and manages connected devices and sensors remotely

• Intelligent turn on/off devices based on event occurrence or planned schedule

• Comprehensive power management and flexible configuration

through web browser, NMS, Telnet, SNMP, or HyperTerminal (console port)

• User-friendly interface to display input and output status

• Event notification through SNMP trap or Email alerts

• Daily history report through Email

• Supports SSL V3 and SSH V1 protocol

• Available in 100V, 220V and 240V models

Ethernet Adapter

Model ENW-3504FC ENW-9503/_ENW-9504 ENW-9605A ENW-9700 ENW-9800 ENW-9801

Product Image

Attached Interface _CardBus32-Bit _{PCI 2.2}32-Bit _{PCI 2.2}32-Bit x1 PCI Express PCI Express 1.1a PCI Express 1.1a Network Interface 10/100Base-TX 10/100Base-TX 10000Base-FX 10000Base-FX Media Interface RJ-45 RJ-45 RJ-45 RJ-45 2xSFP+(SFF-8431) 1xSFP+(SFF-8431)

BootROM Socket - -  - -

Wake on LAN - (ENW-9503)   -

OS Support Windows 2000     - -Windows XP       Windows 2003       Vista       Linux       IPM-8001 / IPM-8002

Accessories IPM-8001 / IPM-8002

IPM-EMD Environmental Monitoring Device

IPM-8001

PC PDA SMS/ WAP E-mail

EMD Smoke

Detector Door OpenDetector

Router PC Server Printer AC AC AC I/O

Power Line (AC)

AC

I/O

DI/DO

100Base-TX UTP
