Edition 2 MATERIALS HANDLING

MATERIALS HANDLING

Edition 2

Attached Lidded Boxes

YEARS ESTABLISHED NT937 - AHAL43265 Solid - 22 Ltrs Ext: 400 x 300 x 265mm Int: 336 x 252 x 240mm Colour: Blue Pallet Quantity: 135 NT1870 - AHAL43265R Solid - 22 Ltrs Ext: 400 x 300 x 265mm Int: 336 x 252 x 240mm Colour: Recycled Black* Pallet Quantity: 135 NT936 - AHAL43310 Solid - 25 Ltrs Ext: 400 x 300 x 310mm Int: 332 x 249 x 285mm Colour: Blue Pallet Quantity: 135

A full range of heavy duty lidded boxes moulded in first grade polypropylene fitted with a clear

cardholder on one short side and integral tamper evident hinged lids.

Voyager

Alison stock a variety of colours in the Voyager range.

NT681 - VOYAGER Solid - 54 Ltrs Ext: 600 x 400 x 310mm Int: 517 x 349 x 283mm Colour: Orange Pallet Quantity: 60 Dolly to fit AHDOL 03

NT637 - VOYAGER Colour: Blue NT619 - VOYAGER Colour: Yellow NT638 - VOYAGER Colour: Black NT620 - VOYAGER Colour: Green NT627 - VOYAGER Colour: Red

NT953BLUE - Rivet Blue NT953RED - Rivet Red

Attached Lidded Boxes

* Recycled material not suitable for food use

NT1869 - AHAL43310R

Solid - 25 Ltrs Ext: 400 x 300 x 310mm Int: 332 x 249 x 285mm Colour: Recycled Black* Pallet Quantity: 135 NT1871 - AHAL64250 Solid - 40 Ltrs Ext: 600 x 400 x 250mm Int: 533 x 355 x 230mm Colour: Blue Pallet Quantity: 60 Dolly to fit AHDOL 03

NT1872 - AHAL64250R

Solid - 40 Ltrs Ext: 600 x 400 x 250mm Int: 533 x 355 x 230mm Colour: Recycled Black* Pallet Quantity: 60 Dolly to fit AHDOL 03

NT1040R - AHAL64310R

Solid - 54 Ltrs Ext: 600 x 400 x 310mm Int: 517 x 349 x 283mm Colour: Recycled Black* Pallet Quantity: 60 Dolly to fit AHDOL 03

NT779 - AHAL64365 Solid - 65 Ltrs Ext: 600 x 400 x 365mm Int: 512 x 345 x 338mm Colour: Blue Pallet Quantity: 60 Dolly to fit AHDOL 03

NT1797 - AHAL64365R

Solid - 65 Ltrs Ext: 600 x 400 x 365mm Int: 512 x 345 x 338mm Colour: Recycled Black* Pallet Quantity: 60 Dolly to fit AHDOL 03

NT775 - AHAL64400 Solid - 70 Ltrs Ext: 600 x 400 x 400mm Int: 508 x 343 x 373mm Colour: Blue Pallet Quantity: 60 Dolly to fit AHDOL 03

NT1798 - AHAL64400R

Solid - 70 Ltrs Ext: 600 x 400 x 400mm Int: 508 x 343 x 373mm Colour: Recycled Black* Pallet Quantity: 60 Dolly to fit AHDOL 03

LA1184 - AT10A804R

Solid - 80 Ltrs Ext: 710 x 460 x 368mm Int: 597 x 374 x 327mm Colour: Recycled Black* Pallet Quantity: 60 Dolly to fit PA217

Maxinest

®

Baskets

YEARS

ESTABLISHED

The innovative Maxinest design has been developed to make maximum use of space. Filled

containers stack securely when in use yet nest up to 76% when empty saving valuable storage space

and return transport costs. Included in the range are two multi height trays offering alternative

capacities in the one tray by means of a multi positional nylon stacking bar.

* Please Note: Colours of bars may vary * Recycled material not suitable for food use LA1216 - SN431802 Perforated - 15 Ltrs Ext: 400 x 300 x 180mm Int: 364 x 264 x 144mm Colour: Blue Pallet Quantity: 300

LA1218 - DH641002 Dual height Perforated - 10 & 16 Ltrs Ext: 600 x 400 x 106mm Int: 552 x 352 x 80mm Int: 552 x 352 x 50mm Colour: Blue Pallet Quantity: 225

LA1155 - DH641602 Dual height Perforated - 21 & 26 Ltrs Ext: 600 x 400 x 167mm Int: 546 x 352 x 160mm Int: 546 x 352 x 110mm Colour: Blue Pallet Quantity: 215 SN641902 Perforated - 35 litres Ext: 600 x 400 x 199mm Int: 546 x 349 x 172mm Colours: Pallet Quantity: 180 LA1212 - SN641902R Perforated - 35 Ltrs Ext: 600 x 400 x 199mm Int: 546 x 349 x 172mm Colour: Recycled Black* Pallet Quantity: 180 SN642402 Perforated - 44 Ltrs Ext: 600 x 400 x 253mm Int: 548 x 352 x 226mm Colours: Pallet Quantity: 125 LA1213 - SN642402R Perforated - 44 Ltrs Ext: 600 x 400 x 253mm Int: 548 x 352 x 226mm Colour: Recycled Black* Pallet Quantity: 125

Maxinest Clip

Stack/Nest Swing Bar Containers

LA1098 - SN642202AA

Perforated - Bail Arm - 38 Ltrs Ext: 600 x 400 x 225mm Int: 525 x 347 x 200mm Colour: Blue

Pallet Quantity: 100

LA1192 - DH701802 Dual height Perforated - 54 or 34 Ltrs Ext: 600 x 400 x 302mm Int: 570 x 370 x 270mm Int: 570 x 370 x 182mm Colour: Blue Pallet Quantity: 75

LA1088 - DH701807 Dual height Solid - 54 or 34 Ltrs Ext: 600 x 400 x 302mm Int: 570 x 370 x 270mm Int: 570 x 370 x 182mm Colour: Blue Pallet Quantity: 75 LA1101 - SN643007AG Solid - 54 Ltrs Ext: 600 x 400 x 300mm Int: 540 x 344 x 273mm Colour: Recycled Black* Pallet Quantity: 75

PA217 - 74SDOL

Ext: 680 x 436 x 200mm 4 Swivel 100mm Ø Castors Colour: Grey

Dolly to fit LA1094

LA1091 - SN64002AH

Perforated - 54 Ltrs Ext: 600 x 400 x 300mm Int: 540 x 344 x 273mm Colour: Recycled Black* Pallet Quantity: 75

LA1094 - DH740002 Dual height Perforated - 43 or 28 Ltrs Ext: 691 x 441 x 194mm Int: 635 x 391 x 168mm Int: 635 x 391 x 110mm Colour: Blue Pallet Quantity: 75 LA1121 - DO795904

Double Dolly fits 2 600 x 400 Boxes or 1 800 x 600 Box

Ext: 798 x 598 x 171mm 2 Fixed & 2 Swivel 100mm Ø Castors Colour: Black

LA1208 - SN101804AA Solid - 18 Ltrs Ext: 600 x 400 x 117mm Int: 458 x 338 x 102mm Colour: Grey/Grey Pallet Quantity: 135 LA1209 - SN102001AA Perforated - 18 Ltrs Ext: 600 x 400 x 117mm Int: 458 x 338 x 102mm Colour: Grey/Grey Pallet Quantity: 135 LA1224 - SN110305AA Solid - 32 Ltrs Ext: 600 x 400 x 200mm Int: 457 x 338 x 177mm Colour: Grey/Red Pallet Quantity: 150 *LA1166 - Grey/Grey LA1153 - SN110301AA Perforated - 32 Ltrs Ext: 600 x 400 x 200mm Int: 457 x 338 x 177mm Colour: Grey/Grey Pallet Quantity: 150 LA1144 - SN105105AC Solid - 50 Ltrs Ext: 600 x 400 x 300mm Int: 460 x 340 x 270mm Colour: Grey/Red Pallet Quantity: 100 *LA1145 - Grey/Grey LA1188 - SN105201AA Perforated - 50 Ltrs Ext: 600 x 400 x 300mm Int: 460 x 340 x 270mm Colour: Grey/Grey Pallet Quantity: 100 LA1165 - SN106505AC Solid - 70 Ltrs Ext: 600 x 400 x 400mm Int: 460 x 340 x 370mm Colour: Grey/Grey Pallet Quantity: 70 LA1196 - SN106601AA Perforated - 70 Ltrs Ext: 600 x 400 x 400mm Int: 460 x 340 x 370mm Colour: Grey Pallet Quantity: 70

Stack/Nest 180° Containers

YEARS ESTABLISHED

AHSN64200S Solid - 32 Ltrs Ext: 600 x 400 x 200mm Int: 490 x 332 x 195mm Colours: Pallet Quantity: 160 AHSN64200P Perforated - 32 Ltrs Ext: 600 x 400 x 200mm Int: 490 x 332 x 195mm Colours: Pallet Quantity: 160 AHSN64300S Solid - 50 Ltrs Ext: 600 x 400 x 300mm Int: 490 x 332 x 295mm Colours: Pallet Quantity: 120 AHSN64300P Perforated - 50 Ltrs Ext: 600 x 400 x 300mm Int: 490 x 332 x 295mm Colours: Pallet Quantity: 120 AHSN64400S Solid - 70 Ltrs Ext: 600 x 400 x 400mm Int: 490 x 332 x 395mm Colours: Pallet Quantity: 80 AHSN64400P Perforated - 70 Ltrs Ext: 600 x 400 x 400mm Int: 490 x 332 x 395mm Colours: Pallet Quantity: 80 AHSN-LID

Lid for 600 x 400 above range Ext: 610 x 410mm

Colours:

Stack/Nest 180° Containers

AHDOL 03

Dolly for 600 x 400 above range Ext: 640 x 440 x 160mm 4 Swivel 75mm Ø Castors Colours:

Alison’s Range of 180° stacking and nesting containers are moulded in a range of colours to allow

companies to colour code their factories.

Solid Stacking Containers

LA1013 - ES210004 Solid - 5 Ltrs Ext: 300 x 200 x 118mm Int: 257 x 159 x 108mm Colour: Grey Pallet Quantity: 288 LA1016 - ES100604 Solid - 6 Ltrs Ext: 400 x 300 x 74mm Int: 355 x 255 x 64mm Colour: Grey Pallet Quantity: 300 LA1018 - ES210104 Solid - 10 Ltrs Ext: 400 x 300 x 118mm Int: 355 x 255 x 105mm Colour: Grey Pallet Quantity: 160 LA1020 - ES102704 Solid - 15 Ltrs Ext: 400 x 300 x 175mm Int: 355 x 255 x 164mm Colour: Grey Pallet Quantity: 110 LA1022 - ES210204 Solid - 20 Ltrs Ext: 400 x 300 x 235mm Int: 355 x 255 x 220mm Colour: Grey Pallet Quantity: 80 LA1025 - ES103004 Solid - 30 Ltrs Ext: 400 x 300 x 319mm Int: 355 x 255 x 300mm Colour: Grey Pallet Quantity: 60 LA1026 - ES100804 Solid - 8 Ltrs Ext: 600 x 400 x 50mm Int: 555 x 355 x 40mm Colour: Grey Pallet Quantity: 200 LA1027 - ES101304 Solid - 12 Ltrs Ext: 600 x 400 x 73mm Int: 555 x 355 x 62mm Colour: Grey Pallet Quantity: 135 LA1030 - ES102104 Solid - 21 Ltrs Ext: 600 x 400 x 118mm Int: 555 x 355 x 105mm Colour: Grey Pallet Quantity: 80 YEARS ESTABLISHED

LA1034 - ES200204 Solid - 28 Ltrs Ext: 600 x 400 x 150mm Int: 555 x 355 x 139mm Colour: Grey Pallet Quantity: 60 LA1038 - ES103304 Solid - 33 Ltrs Ext: 600 x 400 x 175mm Int: 555 x 355 x 164mm Colour: Grey Pallet Quantity: 55 LA1042 - ES2A0404 Solid - 45 Ltrs Ext: 600 x 400 x 235mm Int: 555 x 355 x 220mm Colour: Grey Pallet Quantity: 40 LA1046 - ES210504 Solid - 54 Ltrs Ext: 600 x 400 x 280mm Int: 555 x 355 x 265mm Colour: Grey Pallet Quantity: 35 LA1047 - ES210605 Solid - 60 Ltrs Ext: 600 x 400 x 319mm Int: 555 x 355 x 300mm Colour: Grey Pallet Quantity: 45 LA1051 - ES200805 Solid - 75 Ltrs Ext: 600 x 400 x 412mm Int: 555 x 355 x 394mm Colour: Grey Pallet Quantity: 20 LA1053 - ES210905 Solid - 87 Ltrs Ext: 800 x 600 x 235mm Int: 755 x 555 x 205mm Colour: Grey Pallet Quantity: 16 LA1054 - ES211305 Solid - 125 Ltrs Ext: 800 x 600 x 319mm Int: 755 x 555 x 295mm Colour: Grey Pallet Quantity: 12 LA1055 - ES211605 Solid - 162 Ltrs Ext: 800 x 600 x 412mm Int: 755 x 555 x 382mm Colour: Grey Pallet Quantity: 8

LA1017 - ES210001 Perforated - 10 Ltrs Ext: 400 x 300 x 118mm Int: 355 x 255 x 105mm Colour: Grey Pallet Quantity: 160 LA1024 - ES102606

Perf Sides Solid Base - 20 Ltrs Ext: 400 x 300 x 235mm Int: 355 x 255 x 220mm Colour: Grey

Pallet Quantity: 80

LA1039 - ES103806

Perf Sides Solid Base - 33 Ltrs Ext: 600 x 400 x 175mm Int: 555 x 355 x 162mm Colour: Grey Pallet Quantity: 55 LA1028 - ES101401 Perforated - 12 Ltrs Ext: 600 x 400 x 73mm Int: 555 x 355 x 62mm Colour: Grey Pallet Quantity: 135 LA1033 - ES102101 Perforated - 21 Ltrs Ext: 600 x 400 x 118mm Int: 555 x 355 x 105mm Colour: Grey Pallet Quantity: 80 LA1035 - ES200201 Perforated - 28 Ltrs Ext: 600 x 400 x 150mm Int: 555 x 355 x 139mm Colour: Grey Pallet Quantity: 60 LA1041 - ES2A0401 Perforated - 45 Ltrs Ext: 600 x 400 x 235mm Int: 555 x 355 x 215mm Colour: Grey Pallet Quantity: 40 LA1045 - ES105501 Perforated - 52 Ltrs Ext: 600 x 400 x 280mm Int: 555 x 355 x 255mm Colour: Grey Pallet Quantity: 35 LA1050 - ES210601 Perforated - 60 Ltrs Ext: 600 x 400 x 319mm Int: 555 x 355 x 300mm Colour: Grey Pallet Quantity: 45

Perforated Stacking Containers

YEARS

ESTABLISHED

LA1071 - ES210901 Perforated - 87 Ltrs Ext: 800 x 600 x 235mm Int: 755 x 555 x 205mm Colour: Grey Pallet Quantity: 16 LA1072 - ES211306

Perf - Solid base - 125 Ltrs Ext: 800 x 600 x 319mm Int: 755 x 555 x 295mm Colour: Grey

Pallet Quantity: 12

LA1073 - ES211606

Perf - Solid base - 162 Ltrs Ext: 800 x 600 x 412mm Int: 755 x 555 x 382mm Colour: Grey

Pallet Quantity: 8

LA1139 - DOJ90501

Suits most 600 x 400 Boxes Ext: 604 x 402 x 162mm 4 Swivel 100mm Ø Castors Colour: Red

AHDOL 03

Dolly for 600 x 400 Boxes Ext: 640 x 440 x 160mm 4 Swivel 75mm Ø Castors Colours:

AHDOL 07

Double Dolly fits 2 600 x 400 Boxes Ext: 800 x 600 x 252mm 2 Fixed & 2 Swivel 125mm Ø Castors Colours:

Fitted with 1 Brake Castor

Perforated Stacking Containers

LA1121 - DO795904

Double Dolly fits 2 600 x 400 Boxes or 1 800 x 600 Box

Ext: 798 x 598 x 171mm 2 Fixed & 2 Swivel 100mm Ø Castors Colour: Black

Lids & Dividers

LA1056 - LI610204

Solid - Drop on Lid Ext: 400 x 300mm Colour: Grey

To suit 400 x 300mm Boxes

LA1026 - OTPE9004

Stainless steel card clip

LA1057 - LI106004

Solid - Drop on Lid Ext: 600 x 400mm Colour: Grey

To suit 600 x 400mm Boxes

LA1058 - LI108704

Solid - Drop on Lid Ext: 800 x 600mm Colour: Grey To suit 800 x 600mm Boxes LA1075 - OT800404 Divider strips Ext: 1104 x 45mm Colour: Grey Pack of 60 LA1100 - OT800804 Divider strips Ext: 1104 x 88mm Colour: Grey Pack of 30 LA1119 - OT801504 Divider strips Ext: 1100 x 150mm Colour: Grey Pack of 20 LA1207 - OT801904 Divider strips Ext: 1100 x 190mm Colour: Grey Pack of 20 YEARS ESTABLISHED

Euro Lidded Containers

LA1059 - ES0C1004AF Solid - 10 Ltrs Ext: 400 x 300 x 129mm Int: 355 x 255 x 105mm Colour: Grey Pallet Quantity: 150 LA1060 - ES1C2704AH Solid - 15 Ltrs Ext: 400 x 300 x 186mm Int: 355 x 255 x 164mm Colour: Grey Pallet Quantity: 100 LA1061 - ES1C2004AE Solid - 20 Ltrs Ext: 400 x 300 x 246mm Int: 355 x 255 x 220mm Colour: Grey Pallet Quantity: 70 LA1062 - ES1C3004AD Solid - 30 Ltrs Ext: 400 x 300 x 330mm Int: 355 x 255 x 300mm Colour: Grey Pallet Quantity: 50 LA1063 - ES0C2804AD Solid - 28 Ltrs Ext: 600 x 400 x 161mm Int: 555 x 355 x 139mm Colour: Grey Pallet Quantity: 60 LA1064 - ES1C3304AI Solid - 33 Ltrs Ext: 600 x 400 x 186mm Int: 555 x 355 x 164mm Colour: Grey Pallet Quantity: 50 LA1065 - ES1C4504AD Solid - 45 Ltrs Ext: 600 x 400 x 246mm Int: 555 x 355 x 220mm Colour: Grey Pallet Quantity: 35 LA1066 - ES1C5404AC Solid - 54 Ltrs Ext: 600 x 400 x 291mm Int: 555 x 355 x 265mm Colour: Grey Pallet Quantity: 30 LA1067 - ES0C8505AF Solid - 75 Ltrs Ext: 600 x 400 x 423mm Int: 555 x 355 x 394mm Colour: Grey Pallet Quantity: 20

Alison Stackers

LA1229 - SK43175S Solid - 15 Ltrs Ext: 400 x 300 x 175mm Int: 354 x 254 x 162mm Colour: Grey Pallet Quantity: 120 LA1194 - SK43235S Solid - 20 Ltrs Ext: 400 x 300 x 235mm Int: 354 x 254 x 222mm Colour: Grey Pallet Quantity: 90 LA1230 - SK64075S Solid - 12 Ltrs Ext: 600 x 400 x 75mm Int: 556 x 356 x 62mm Colour: Grey Pallet Quantity: 125 YEARS ESTABLISHED

A range of heavy duty stacking boxes moulded in first grade polypropylene in a wide choice of

colours for colour co-ordinating your factory.

LA1178 - SK64175S Solid - 34 Ltrs Ext: 600 x 400 x 175mm Int: 556 x 356 x 162mm Colour: Red Pallet Quantity: 50 Dolly to fit AHDOL 03

LA1175 - SK64175S Colour: Blue LA1176 - SK64175S Colour: Yellow LA1177 - SK64175S Colour: White LA1219 - SK64175S Colour: Green LA1173 - SK64175S Colour: Grey

LA1170 - SK64075P Perforated - 12 Ltrs Ext: 600 x 400 x 75mm Int: 556 x 356 x 62mm Colours: Pallet Quantity: 125 LA1186 - SK64120S Solid - 23 Ltrs Ext: 600 x 400 x 120mm Int: 556 x 356 x 107mm Colours: Pallet Quantity: 75 LA1231 - SK64120P Perforated - 23 Ltrs Ext: 600 x 400 x 120mm Int: 556 x 356 x 107mm Colour: Grey Pallet Quantity: 75 LA1172 - SK64175P Perforated - 34 Ltrs Ext: 600 x 400 x 175mm Int: 556 x 356 x 162mm Colours: Pallet Quantity: 50 LA1180 - SK64235S Solid - 46 Ltrs Ext: 600 x 400 x 235mm Int: 556 x 356 x 222mm Colours: Pallet Quantity: 45 LA1076 - RB240205 Solid - 25Ltrs Ext: 360 x 360 x 250mm Int: 330 x 330 x 234mm Colour: Red Pallet Quantity: 42 LA1149 - SN290401 Perforated - 50 Ltrs Ext: 550 x 366 x 295mm Int: 518 x 333 x 260mm Colour: Tan Pallet Quantity: 30 LA1217 - SK64400S Solid - 78 Ltrs Ext: 600 x 400 x 400mm Int: 556 x 356 x 387mm Colour: Grey Pallet Quantity: 20

Alison Stackers

Bread Baskets

YEARS ESTABLISHED LA1079 - RB410401AA Perforated - 43 Ltrs Ext: 750 x 450 x 165mm Int: 724 x 425 x 138mm Colour: Brown Pallet Quantity: 39 Dolly to fit AHDOL 05

LA1080 - RB410401AB Perforated - 43 Ltrs Ext: 750 x 450 x 165mm Int: 724 x 425 x 138mm Colour: White Pallet Quantity: 39 Dolly to fit AHDOL 05

LA1009 - LI301804

Lid to suit confectionary tray Ext: 762 x 457mm Colour: Grey AHDOL 05 Ext: 860 x 550 x 200mm 4 Swivel 100 mm Ø Castors Colours: LA1011 - SN121202AC

12 Loaf Stack/Nest Basket Perforated - 65 Ltrs Ext: 762 x 508 x 216mm Int: 697 x 463 x 190mm Colour: Grey

Pallet Quantity: 54 Dolly to fit LA1074

LA1154 - SN121202BA

12 Loaf Stack/Nest Basket Perforated - 65 Ltrs Ext: 762 x 508 x 216mm Int: 697 x 463 x 190mm Colour: Purple Pallet Quantity: 54 Dolly to fit LA1074

LA1010 - SN150201AA

15 Loaf Stack/Nest Basket Perforated - 68 Ltrs Ext: 788 x 617 x 190mm Int: 723 x 569 x 165mm Colour: Blue

Pallet Quantity: 50 Dolly to fit PA211

LA1189 - SN151501AA

15 Loaf Stack/Nest Basket Perforated - 63 Ltrs Ext: 772 x 627 x 176mm Int: 716 x 586 x 149mm Colour: Grey

Confectionary Trays

LA1000 - RB318301 Perforated - 22 Ltrs Ext: 762 x 457 x 92mm Int: 715 x 412 x 72mm Colours: Pallet Quantity: 66 Dolly to fit AHDOL 05

LA1003 - RB318304 Solid - 22 Ltrs Ext: 762 x 457 x 92mm Int: 715 x 412 x 72mm Colours: Pallet Quantity: 66 Dolly to fit AHDOL 05

LA1006 - RB318306 Semi Perf - 22 Ltrs Ext: 762 x 457 x 92mm Int: 715 x 412 x 72mm Colour: Natural Pallet Quantity: 66 Dolly to fit AHDOL 05

LA1001 - RB318501 Perforated - 32 Ltrs Ext: 762 x 457 x 123mm Int: 715 x 412 x 103mm Colour: Natural Pallet Quantity: 45 Dolly to fit AHDOL 05

LA1004 - RB318504 Solid - 32 Ltrs Ext: 762 x 457 x 123mm Int: 715 x 412 x 103mm Colour: Natural Pallet Quantity: 45 Dolly to fit AHDOL 05

LA1007 - RB318506 Semi Perf - 32 Ltrs Ext: 762 x 457 x 123mm Int: 715 x 412 x 103mm Colour: Natural Pallet Quantity: 45 Dolly to fit AHDOL 05

LA1002 - RB318701 Perforated - 48 Ltrs Ext: 762 x 457 x 176mm Int: 715 x 412 x 156mm Colour: Natural Pallet Quantity: 30 Dolly to fit AHDOL 05

LA1005 - RB318704 Solid - 48 Ltrs Ext: 762 x 457 x 176mm Int: 715 x 412 x 156mm Colour: Natural Pallet Quantity: 30 Dolly to fit AHDOL 05

LA1008 - RB318706 Semi Perf - 48 Ltrs Ext: 762 x 457 x 176mm Int: 715 x 412 x 156mm Colour: Natural Pallet Quantity: 30 Dolly to fit AHDOL 05

Heavy Duty Meat Stacking Trays

YEARS

ESTABLISHED

Heavy duty meat stacking trays are available in two depths and a variety of styles, all of which stack

together.

ST1010 - AHM104B Solid Stacker - 28 Ltrs Ext: 640 x 385 x 150mm Int: 600 x 340 x 145mm Colours:

Also available with hand holes

ST1015 - AHM118B

Solid Stacker - 38 Ltrs Ext: 640 x 385 x 205mm Int: 600 x 340 x 200mm Colours:

Also available with hand holes

LA1223 - RB155004 Solid Stacker - 28 Ltrs Ext: 654 x 395 x 155mm Int: 585 x 325 x 139mm Colour: White Pallet Quantity: 60 ST1013 - AHM8104 LID

Suitable to fit both of the above trays. Only available in White

ST1014 - AHM1104 DOLLY

Ext: 650 x 395 x 130mm 4 Swivel 100mm Ø Nylon Castors Only available in Black

*Will not interstack with the above range

*Also available in perforated *Also available in perforated

Plastic Dollies

AHDOL 03

Suits most 600 x 400 Boxes Ext: 640 x 440 x 160mm 4 Swivel 75mm Ø Castors Colours:

AHDOL 05

Suits Confectionery Tray Range Ext: 860 x 550 x 200mm 4 Swivel 100mm Ø Castors Colours:

Also suits LA1079, LA1080

LA1121 - DO795904

Double Dolly fits 2 600 x 400 Boxes or 1 800 x 600 Box

Ext: 798 x 598 x 171mm 2 Fixed & 2 Swivel 100mm Ø Castors Colour: Black

Fitted with 1 Brake Castor

AHDOL 07

Double Dolly fits 2 600 x 400 Boxes Ext: 800 x 600 x 252mm 2 Fixed & 2 Swivel 125mm Ø Castors Colours:

Fitted with 1 Brake Castor

EX1011 - AHM001X

Ext: 440 x 440 x 178mm 4 Swivel 75mm Ø Castors Colours:

Suits All Interstacking Bins

PA211 - PT15 Ext: 822 x 676 x 142mm 4 Swivel 75mm Ø Castors Colours: Suits LA1010 PA210 - HNDOL Ext: 477 x 477 x 181mm 4 Swivel 75mm Ø Castors Colours: Suits CR1018 &CR1019 74SDOL - PA217 Ext: 680 x 436 x 200mm 4 Swivel 100mm Ø Castors Colours:

Also suits LA1094& LA1184

LA1074 - RB DOL

Ext: 762 x 508 x 207mm 4 Swivel 100mm Ø Castors Suits LA1011

Ingredients Storage

YEARS

ESTABLISHED

ALL AVAILABLE IN COLOURS

PA204 - ID21 Ingredient Dispenser - 21 Ltrs Ext: 205 x 474 x 424mm Colours: Choice of 11 PA220 - CH50 Churn - Solid - 50 Ltrs Ext: DIA 350 x 762mm With screw top lid + handles

PA218 - DH2 Sink & Lid

Solid - 225 Ltrs Ext: 940 x 762 x 838mm Int: 819 x 642 x 447mm Includes drainage outlet with plug

PA205 - ID61 Ingredient Dispenser - 63 Ltrs Ext: 280 x 616 x 674mm Colours: Choice of 11 PA206 - ID90 Ingredient Dispenser - 90 Ltrs Ext: 410 x 675 x 67 mm Colours: Choice of 11

The Original Paxton Ingredient Dispensers

Alison can now supply the original Paxton Ingredient Dispensers in a range of colours and capacities.

The dispensers feature an internal restricting plate which regulates the flow rate according to the

density of the ingredient.

The dispensers are filled at the top and emptied at the bottom via a transparent front access flap

ensuring good ingredient rotation.

Besides widespead usage within the food idustry, the dispensers are ideal to dispense small

components in the Electronic, Pharmaceutical and Packing industries.

Ingredients Storage

WE ALSO OFFER A RANGE OF SCOOPS

AVAILABLE IN PACKS OF 10

Ingredient Mobiles

Moulded in food grade MD Polythene complete with a removable lid for cleaning and refilling and a

transparent front access flap.

Fitted with 4 off 75mm diameter nylon swivel castors.

ALL AVAILABLE IN COLOURS

Ingredient Dispensers

Moulded in food grade MD Polythene with a drop on lid and transparent front access flap.

• Ensures good ingredient rotation

• Avoids spillage, waste and ingredient cross contamination

• Translucent design gives replenishment level indication

EX1000 - AHDIS 00 Ingredient Dispenser - 8 Ltrs Ext: 295 x 250 x 400mm Colours: Choice of 11 EX1001 - AHDIS 01 Ingredient Dispenser - 15 Ltrs Ext: 250 x 500 x 500mm Colours: Choice of 11 EX1002 - AHDIS 02 Ingredient Dispenser - 65 Ltrs Ext: 300 x 640 x 685mm Colours: Choice of 11 EX1056 - AHING 07 Ingredients Mobiles - 61 Ltrs Ext: 590 x 290 x 740mm Colours: Choice of 11 EX1057 - AHING 08 Ingredients Mobiles - 87 Ltrs Ext: 590 x 380 x 740mm Colours: Choice of 11 EX1058 - AHING 09 Ingredients Mobiles - 132 Ltrs Ext: 590 x 530 x 740mm Colours: Choice of 11

Interstacking Bins

YEARS

ESTABLISHED

Ingredient Capacities Guide

Capacity (KG) EX1004 EX1005 EX1006 EX1007

CURRENTS 11.8 17.2 29 41.7 FAT 12.7 25.4 38.1 50.8 FLOUR 7.3 14.5 24.5 38.1 SUGAR 12.7 23.6 36.3 49.9 SULTANAS 12.7 19 31.7 45.4 EX1004 - AHB0001 Interstacking Bin - 18 Ltrs Ext: DIA 430 x 185mm Colours: Choice of 11 EX1005 - AHB0003 Interstacking Bin - 31 Ltrs Ext: DIA 430 x 310mm Colours: Choice of 11 EX1006 - AHB0005 Interstacking Bin - 46 Ltrs Ext: DIA 430 x 435mm Colours: Choice of 11 EX1007 - AHB0007 Interstacking Bin - 67 Ltrs Ext: DIA 430 x 640mm Colours: Choice of 11 EX1011 - AHM001X

Dolly to suit the above range Ext: 440 x 440 x 178mm Colours: Choice of 11

EX1008 - AHB LID

Interstacking Bin Lid Lid to suit the above range Colours: Choice of 11

ALL AVAILABLE IN COLOURS

1.EX1034 - AHTB 20

Tapered Bin - 20 Ltrs Ext: DIA 350 x 390mm Lid to fit EX1035

Dolly to fit EX1011

2.EX1036 - AHTB 45

Tapered Bin - 45 Ltrs Ext: DIA 460 x 520mm Lid to fit EX1037

Dolly to fit EX1011

3.EX1038 - AHTB 65

Tapered Bin - 65 Ltrs Ext: DIA 510 x 585mm Lid to fit EX1039

Dolly to fit EX1011

1.EX1028 - AH0011

Tapered Bin - 70 Ltrs Ext: DIA 610 x 520mm Lid to fit EX1029

Dolly to fit EX1011

2.EX1030 - AH0012

Tapered Bin - 95 Ltrs Ext: DIA 490 x 625mm Lid to fit EX1064

Dolly to fit EX1011

3.EX1031 - AH0006

Tapered Bin - 80 Ltrs Ext: DIA 460 x 585mm Lid to fit EX1065

Dolly to fit EX1011

4.EX1040 - AHTB 110A

Tapered Bin - 110 Ltrs Ext: DIA 575 x 650mm Lid to fit EX1041

5.EX1042 - AHTB 110B

Tapered Bin - 110 Ltrs Ext: DIA 540 x 775mm Lid to fit EX1043

6.EX1044 - AHTB 215

Tapered Bin - 215 Ltrs Ext: DIA 700 x 890mm Lid to fit EX1045

ALL AVAILABLE IN COLOURS

Heavy duty bins with galvanised handles

1. 2. 3. 4. 5. 6. 1. 2. 3.

Tapered Bins

Tapered Bins

YEARS

ESTABLISHED

Hygienic tapered bins moulded in food grade HDPE complete with moulded in handles.

CR1016 Solid - 40 Ltrs Ext: DIA 420 x 445mm Int: DIA 370 x 425mm Colour: Natural Lid to fit - CR1011 CR1017 Solid - 50 Ltrs Ext: DIA 420 x 540mm Int: DIA 370 x 520mm Colour: Natural Lid to fit - CR1011 CR1018 Solid - 75 Ltrs Ext: DIA 515 x 530mm Int: DIA 455 x 512mm Colour: Natural Lid to fit - CR1020

Dolly to fit - PA210

CR1019 Solid - 110 Ltrs Ext: DIA 515 x 733mm Int: DIA 460 x 725mm Colour: Natural Lid to fit - CR1020

Dolly to fit - PA210

PA219 - PA308FSG

Solid - 68 Ltrs Ext: DIA 616 x 520mm

Int: DIA 489 x 476mm

Colours:

Dolly to fit - EX1011

Fitted with galvanised handles

Mobile Stand with Mixing Bowl

Solid - 73 Ltrs Ext: DIA 604 x 850mm

Bowl: DIA 604 x 464mm

Colours:

3 Swivel 100mm Ø Castors Frame manufactured in Stainless Steel

NT1707 - Basket

Perforated - 45 Ltrs Ext: DIA 428 x 492mm Colour: Blue Dolly to fit - EX1011

NT1578 - Basket

Perforated - 45 Ltrs Ext: DIA 428 x 492mm Colour: Red Dolly to fit - EX1011

PA210 - HNDOL

Ext: 477 x 477 x 181mm 4 Swivel 75mm Ø Castors Colours:

Racks & Trollies

6 Box Fat Rack

Ext: 795 x 410 x 1480mm Box Size: 456 x 366 x 270mm Colours:

Fits 6 Boxes & Lids 4 Swivel 100mm Ø Castors

Frame manufactured in Stainless Steel

135 Ltr Chassis Truck

Ext: 630 x 540 x 750mm Tank Size: 620 x 530 x 590mm Colours:

4 Swivel 100mm Ø Castors

Frame manufactured in Stainless Steel Lid available on request

3 Box Fat Rack

Ext: 430 x 410 x 1480mm Box Size: 456 x 366 x 270mm Colours:

Fits 3 Boxes & Lids 4 Swivel 100mm Ø Castors

Frame manufactured in Stainless Steel

*Other sizes available on request

198 Ltr Mobile Trough

Ext: 1170 x 690 x 800mm

Trough Body Size: 1070 x 690 x 375mm Colours:

4 Swivel 100mm Ø Castors

Frame manufactured in Stainless Steel Lid available on request

*Other sizes available on request

Plastic Mobiles

YEARS

ESTABLISHED

Tapered heavy duty watertight mobiles moulded in tough food grade polythene.

AH70TR/AH100TR fitted with reinforced plastic base sheet for added strength.

Paxton Mobiles

The strengthening of the base of these mobiles allows for the removal of the plastic base sheet which

eliminates food waste becoming trapped.

EX1012 - AH16TR Solid - 72 Ltrs Ext: 460 x 460 x 510mm Int: 410 x 410 x 410mm 4 Swivel 75mm Ø Castors Colours: Choice of 11 Lid to fit EX1013

EX1014 - AH26TR Solid - 118 Ltrs Ext: 460 x 460 x 760mm Int: 410 x 410 x 660mm 4 Swivel 75mm Ø Castors Colours: Choice of 11 Lid to fit EX1013

EX1015 - AH30TR Solid - 135 Ltrs Ext: 620 x 530 x 690mm Int: 550 x 465 x 580mm 4 Swivel 75mm Ø Castors Colours: Choice of 11 Lid to fit EX1016

EX1017 - AH45TR Solid - 200 Ltrs Ext: 825 x 480 x 750mm Int: 740 x 410 x 645mm 4 Swivel 100mm Ø Castors Colours: Choice of 11 Lid to fit EX1018

EX1019 - AH70TR

Solid - 320 Ltrs Ext: 1010 x 685 x 725mm Int: 905 x 585 x 595mm 2 Fixed & 2 Swivel 100mm Ø Castors Colours: Choice of 11

Lid to fit EX1020

EX1021 - AH100TR

Solid - 455 Ltrs Ext: 1345 x 730 x 755mm Int: 1225 x 595 x 620mm 2 Fixed & 2 Swivel 100mm Ø Castors Colours: Choice of 11

Lid to fit EX1022

PA200 - MT14

Solid - 100 Ltrs Ext: 584 x 450 x 685mm Int: 444 x 310 x 584mm 2 Fixed & 2 Swivel 75mm Ø Castors Colours: Choice of 11

Lid to fit PA201

PA202 - MT21

Solid - 145 Ltrs Ext: 800 x 450 x 685mm Int: 660 x 310 x 584mm 2 Fixed & 2 Swivel 75mm Ø Castors Colours: Choice of 11

Lid to fit PA203

EX1032 - AHMOB 01 Solid - 305 Ltrs Ext: 990 x 686 x 762mm Int: 902 x 597 x 622mm 4 Swivel 100mm Ø Castors Colours: Choice of 11 Lid to fit EX1033

ALL AVAILABLE IN COLOURS

Plastic Mobiles

Nestable bar trucks moulded in food grade MD Polythene all fitted with 4 Swivel 50mm Ø Castors.

1.EX1023 - AH0111 Solid - 135 Ltrs Ext: 700 x 490 x 650mm Int: 610 x 400 x 550mm 2.EX1024 - AH0113 Solid - 150 Ltrs Ext: 660 x 500 x 750mm Int: 560 x 400 x 700mm 3.EX1025 - AH0115 Solid - 165 Ltrs Ext: 870 x 500 x 610mm Int: 760 x 400 x 550mm 4.EX1026 - AH0119 Solid - 185 Ltrs Ext: 720 x 640 x 620mm Int: 610 x 560 x 550mm 5.EX1027 - AH0118 Solid - 165 Ltrs Ext: 1020 x 420 x 620mm Int: 915 x 330 x 550mm 1. 3. 5. 4. 2. 1.EX1012R - AH16TR Solid - 72 Ltrs Ext: 460 x 460 x 510mm Int: 410 x 410 x 410mm 4 Swivel 75mm Ø Castors 2.EX1014R - AH26TR Solid - 118 Ltrs Ext: 460 x 460 x 760mm Int: 410 x 410 x 660mm 4 Swivel 75mm Ø Castors 3.EX1015R - AH30TR Solid - 135 Ltrs Ext: 620 x 530 x 690mm Int: 550 x 465 x 580mm 4 Swivel 75mm Ø Castors 4.EX1017R - AH45TR Solid - 200 Ltrs Ext: 825 x 480 x 750mm Int: 740 x 410 x 645mm 4 Swivel 100mm Ø Castors 5.EX1019R - AH70TR Solid - 320 Ltrs Ext: 1010 x 685 x 725mm Int: 905 x 585 x 595mm 2 Fixed & 2 Swivel 100mm Ø Castors

6.EX1021R - AH100TR

Solid - 455 Ltrs Ext: 1345 x 730 x 755mm Int: 1225 x 595 x 620mm 2 Fixed & 2 Swivel 100mm Ø Castors

* Recycled material not suitable for food use Lids available on request 1.

2.

3.

4. 6.

5.

Dolav

YEARS

ESTABLISHED

Alison holds in stock the original Classic Dolav one piece solid pallet box with two runners, available

in six colours. Perforated versions also available on request. The Dolav Classic pallet box is capable

of carrying loads up to 700kg and can stack up to 6 high with a total load of 4000kg.

NT984 - D1210S

Solid - 600 Ltrs

Ext: 1200 x 1000 x 740mm Int: 1120 x 920 x 600mm Colour: Grey

Lids available to suit

NT1140 - D1210S Colour: Green NT1141 - D1210S Colour: Brown NT1139 - D1210S Colour: Blue NT1085 - D1210S Colour: Yellow NT1190 - D1210S Colour: Red

D1210L - Drop on stacking lid

Ext: 1200 x 1000mm Colours:

• Reinforced base to prevent sagging

• Anti-slip stacking locations

Dolav

D1208S Solid - 500 Ltrs Ext: 1200 x 800 x 740mm Int: 1120 x 720 x 600mm Colours:

Lids available to suit

DA1210S

Solid - 620 Ltrs

Ext: 1200 x 1000 x 740mm Int: 1120 x 928 x 605mm Colours:

Lids available to suit

is a Super performance box manufactured from high molecular weight structural foam polyethylene.

The one piece moulded three runner pallet box has been designed to offer added safety when

tipping. The Dolav Ace pallet box is available in solid and perforated versions and in a variety of

colours. The Dolav Ace pallet box is capable of carrying loads up to 900kg.

Folding Bulk Containers

YEARS ESTABLISHED LA1167 - FL097520 Solid - 780 Ltrs Ext: 1200 x 1000 x 975mm Int: 1118 x 918 x 760mm Folded Height: 1200 x 1000 x 400mm Colour: Black Pallet Quantity: 5

Folding Large Containers (FLCs) have revolutionised the storage and distribution of bulk loads in

many industries. Our robust units are moulded in tough structural foam HDPE and are designed to

withstand impact expected in day to day use offering excellent product protection. The units can

carry up to 500 kg (evenly distributed) and stack 5 high as well as stack 16 high when folded.

• Two adjacent drop doors provide

easy access to empty contents.

• Plastic material is weather resistant

and kind to users.

• Modular design allows for easy low

cost repairs.

• Folds down to under 40% of its

erected height saving valuable

space and return logistics costs.

• Slam latches enable quick and easy

assembly and knock down.

• 1200 x 1000 x 595mm size is also

available on request.

LA1185 - Drop on stacking lid

Ext: 1200 x 1000mm Colour: Black

Bulk Containers

LA1134 - GB725004 Solid - 260 Ltrs Ext: 1000 x 600 x 662mm Int: 929 x 544 x 519mm Colour: Brown/Red Pallet Quantity: 6 LA1133 - GB760101 Perforated - 543 Ltrs Ext: 1200 x 1000 x 750mm Int: 1110 x 910 x 545mm Colour: Brown/Red Pallet Quantity: 4 LA1162 - GB760604 Solid - 543 Ltrs Ext: 1200 x 1000 x 750mm Int: 1110 x 910 x 545mm Colour: Brown/Red Pallet Quantity: 4 AH441.300 Solid - 620 Ltrs Ext: 1200 x 1000 x 790mm Int: 1110 x 910 x 610mm Colour: Grey Pallet Quantity: 4 AH4401.150

Solid - Drop door - 620 Ltrs Ext: 1200 x 1000 x 760mm Int: 1110 x 910 x 610mm Colour: Grey

Pallet Quantity: 4

IPS1400S Also available perforated Solid - 1400 Ltrs

Ext: 1300 x 1150 x 1250mm Int: 1150 x 990 x 1090mm

Colour: Blue (Also available in recycled black) Pallet Quantity: 2

*Non Food *Lid available on request

*Lid available on request

*Lid available on request *Lid available on request *Lid available on request

Alison have a range of bulk containers to suit a variety of applications, including rigid pallet boxes

with drop doors or some which can be fitted with castors.

Plastic Pallets

YEARS ESTABLISHED CR1009 - CR2 Perforated Ext: 800 x 600 x 160mm Static Load: 2000Kg Dynamic Load: 500Kg Colour: Grey AP1009 - LP1208 Perforated - Nestable Ext: 1200 x 800 x 150mm Static Load: 1000Kg Dynamic Load: 800Kg Colour: Black AP1002 - LP1210 Perforated - Nestable Ext: 1200 x 1000 x 150mm Static Load: 1000Kg Dynamic Load: 800Kg Colour: Black AP1003 - MP1210 Perforated - 3 Runners Ext: 1200 x 1000 x 152mm Static Load: 2000Kg Dynamic Load: 1000Kg Colour: Black CR1002 - H3-R Perforated - 3 Runners Ext: 1200 x 1000 x 160mm Static Load: 5000Kg Dynamic Load: 1250Kg Racking Load 850Kg

Colour: Black - Regrantulated HDPE

CR1000 - TC3-5

Solid - Full perimeter base - 7mm top rim Ext: 1200 x 1000 x 160mm

Static Load: 7500Kg Dynamic Load: 1500Kg Racking Load 1000Kg Colour: Grey

A full range of plastic pallets. They are easily cleaned and user friendly (no splinters, nails or staples).

*Not suitable for racking *Not suitable for racking

Plastic Pallets

Hygenic pallet rotationally moulded in food grade M D Polythene with top retaining rim.

All round smooth surfaces to allow for easy cleaning.

CR1001 - CR3-5

Perforated - Full perimeter base - Anti slip top deck Ext: 1200 x 1000 x 160mm Static Load: 5000Kg Dynamic Load: 1250Kg Racking Load: 1000Kg Colour: Brown CR1001R - CR3-5R

Perforated - Full perimeter base - Anti slip top deck Ext: 1200 x 1000 x 160mm

Static Load: 5000Kg Dynamic Load: 1250Kg Racking Load: 1000Kg

Colour: Black - Regrantulated HDPE

ST1037 - R800L

Solid with 9 feet Ext: 1200 x 800 x 175mm Static Load: 1000Kg Dynamic Load: 1000Kg Colours:

ST1036 - R1000L

Solid with 9 feet

Ext: 1200 x 1000 x 175mm Static Load: 1000Kg Dynamic Load: 1000Kg Colours:

Hygenic Pallets

Parts Bins

YEARS ESTABLISHED TC2 Solid - 1.27 Ltrs Ext: 165 x 100 x 75mm Int: 154 x 88 x 63mm Colours: Supplied in packs of 20's TC3 Solid - 4.6 Ltrs Ext: 240 x 150 x 132mm Int: 223 x 128 x 120mm Colours: Supplied in packs of 10's TC4 Solid - 9.1 Ltrs Ext: 350 x 205 x 132mm Int: 330 x 179 x 117mm Colours: Supplied in packs of 10's TC5 Solid - 12.8 Ltrs Ext: 350 x 205 x 182mm Int: 330 x 177 x 167mm Colours: Supplied in packs of 10's TC6 Solid - 28.3 Ltrs Ext: 375 x 420 x 182mm Int: 350 x 378 x 164mm Colours: Supplied in packs of 5’s TC7 Solid - 31.4 Ltrs Ext: 520 x 310 x 200mm Int: 470 x 270 x 188mm Colours: Supplied in packs of 5’s

Back plates

Available upon request

*Also black conductive boxes are available on request

*Please note only blue and red are kept in stock at our Kirkham warehouse

TC semi open fronted containers.

A simple and efficient small parts storage system for wide range of applications. Manufactured from

Polypropylene, they can be stacked for increased flexibility. To be used with our range of back plates.

TC6

TC7

TC5

TC3 TC4 TC2

Wheelie Bins

We supply a comprehensive range of high quality plastic injection moulded waste containers.

The range of two and four wheeled containers are manufactured to DIN EN 840 specification.

140, 360 and 660 litre bins available on request.

CR1007

Solid - 120 Ltrs Ext: 480 x 550 x 920mm Colours:

CR1024

Solid - 1100 Ltrs Flat Top Ext: 1400 x 1090 x 1330mm Colours:

CR1015

Solid - 1100 Ltrs Roll Top Ext: 1360 x 1080 x 1350mm Colour: Green CR1008 Solid - 240 Ltrs Ext: 580 x 740 x 1070mm Colours:

*Paper or can slot options available

Can Slot

Plastic Racking Systems

YEARS

ESTABLISHED

Plastic rack systems are available in standard units but can be custom built if required. The units are

easy to clean.The rack is built from a number of shelves (various widths) plus H frames. The H frames

determine the depth betweenthe shelves and the height from floor to first shelf.

STANDARD UNITS - DOUBLE UNITS

are available in a choice of:-• 3 Widths of shelves 400/500/600mm • 2 Overall length of shelves 1000, 1200mm • 3, 4 or 5 shelves per bay

• Height between shelves is 350mm • Other heights available to order • Height to first shelf 200mm • Units are static

• Mobile units available upon request • 200kg load bearing per metre of shelf • Meets HACCP regulations

• Resistant to salts and acids

OVERALL LENGTH

DEPTH OF SHELF 400mm NUMBER OF SHELVES PER BAY

DEPTH OF SHELF 500mm NUMBER OF SHELVES PER BAY

DEPTH OF SHELF 600mm NUMBER OF SHELVES PER BAY

3 4 5 3 4 5 3 4 5 1000 PRS1043 PRS1044 PRS1045 PRS1053 PRS1054 PRS1055 PRS1063 PRS1064 PRS1065 1200 PRS1243 PRS1244 PRS1245 PRS1253 PRS1254 PRS1255 PRS1263 PRS1264 PRS1265 1500 PRS1543 PRS1544 PRS1545 PRS1553 PRS1554 PRS1555 PRS1563 PRS1564 PRS1565 2000 PRS2043 PRS2044 PRS2045 PRS2053 PRS2054 PRS2055 PRS2063 PRS2064 PRS2065 OVERALL HEIGHT 1050mm 1450mm 1850mm 1050mm 1450mm 1850mm 1050mm 1450mm 1850mm

Plastic Racking Systems

Trolleys

Changing Room Benches

IDEAL FOR CHANGING AREAS IN FOOD FACTORIES

• All plastic construction

• Food approved recyclable and cadmium free

• Corrosion free

• Smooth splinter free surfaces

• Temperature range -40°c to +80°c

• Durable

• High impact strength & load bearing properties

RE1000 - E235L

4 Tier Trolley

Fitted with 2 Brake Castors and 2 Swivel Castors Ext: 660 x 540 x 1413mm

Fits 4 of 600 x 400 x 235mm Containers *Containers to be purchased separately

WBS200S

Single sided wardrobe bench 2000 x 570 x 1800mm Seat fitted with 6 lengths bars for comfort Coat rack has 8 plastic coat hooks

Top shelf 30cm wide for storage of sports bags etc

BS200

Bench seat 2000 x 400 x 450mm Fitted with 5 length bars for comfort Other lengths available on request

RE1001 - E120L

8 Tier Trolley

Fitted with 2 Brake Castors and 2 Swivel Castors Ext: 660 x 540 x 1593mm

Fits 8 of 600 x 400 x 120mm Containers *Containers to be purchased separately

Drum Spill Pallets

YEARS

ESTABLISHED

Drum spill pallets to carry 2 or 4 drums manufactured from polyethylene with removable non slip

platform ideal for static spill containment - remove drums before fork lifting (compatable with most

forklift and hand pallet trucks).

Drum Rack ideal for easy dispensing and storage. Compatible with most forklifts

Drum Rack only to be used with Drum Rack Base

Drum Rack / Base

JN1000

2 Drum spill pallet

Containment Capacity 250 Ltrs Ext: 1300 x 750 x 440mm Colour: Yellow/Black

JN1000BLKBlack/Black

JN1002

Drum rack base

Containment Capacity 450 Ltrs Ext: 1375 x 1350 x 635mm Colour: Yellow JN1002BLKBlack JN1008 Drum rack - 450 Ltrs Ext: 1375 x 940 x 390mm Colour: Yellow JN1008BLKBlack JN1001

4 Drum spill pallet

Containment Capacity 250 Ltrs Ext: 1380 x 1290 x 280 Colour: Yellow/Black

JN1001BLKBlack/Black

Spill Trays & Grit Bins

Grit Bins

JN1006 Spill tray - 60 Ltrs Ext: 1000 x 600 x 175mm Colour: Yellow/Black EX1046 - GB1 Solid - 200 Ltrs - 7cu ft Ext: 720 x 750 x 710mm Fitted with 1 Hasp & Clasp

EX1047 - GB2

Solid - 400 Ltrs - 14cu ft Ext: 1260 x 750 x 710mm Fitted with 2 Hasps & Clasps

JN1007

Spill tray - 100 Ltrs Ext: 1200 x 800 x 175mm Colour: Yellow/Black

Spill/drip trays manufactured from polyethylene with non slip removable platform.

100% recyclable.

JN1003 Spill tray - 20 Ltrs Ext: 600 x 400 x 155mm Colour: Yellow/Black JN1004 Spill tray - 30 Ltrs Ext: 805 x 405 x 155mm Colour: Yellow/Black JN1005 Spill tray - 40 Ltrs Ext: 800 x 600 x 155mm Colour: Yellow/Black

A L I S O N H A N D L I N G S E R V I C E S LT D

Andrea House, Freckleton Road, Kirkham, Lancashire PR4 3RB

T: 01772 687940 F: 01772 685400 E: [email protected]

www.alisonhandling.com

Whilst every effort has been made to ensure product specifications, including capacities and dimensions are correct, they are given for guidance only. Where a specification is critical customers are advised to check with our sales team on 01772 687940.

Alison reserve the right to change specifications and prices without prior notice.

THE UK’S LARGEST STOCKIST OF NEW AND USED PLASTIC

BOXES, TRAYS, PALLETS AND PALLET BOXES
