IS Series. Commercial & Security IP Video Intercom System. For centralized security management

Commercial & Security

IP Video Intercom System

IS Series

Make Security Manageable World Wide!

The IS Series can be used as a hardwired network system for

for a central controlled system across a number of facilities.

What IS Series can do

Assists onsite visitors from any offsite Master Station.

Up to 160 Master Stations, 160 Video Door Stations, 960 Room Sub Stations can be combined per site. High performance color video intercom features.

Your PC can be used as a Master Station.

OFFICE 1

WAREHOUSE

IS-IPMV

IP Master Station

IS-RS

Room Sub Station

IS-IPDV

IP Vandal-resistant V

ideo Door Station, Surface Mount

IS-IPDVF

IP Vandal-resistant V

ideo Door Station, Flush Mount IS-SS V andal-resistant D oor Station, Flush Mount 1

a small application, or as an IP network system

OFFICE 2

FACTORY

IS Series Features

From small to large facilities

Zoom & PanTilt

Panoramic wide angle view and Zoom & PanTilt for higher security

IP-based security system works beyond distance

The IS Series is designed to be used for a variety of facilities: commercial buildings, hospitals, educational institutions, and more. It can flexibly adapt to a variety of scales and conditions. Optional devices, such as security cameras and alarms can be added to complete your system.

You can change the camera angle and zoom in the image to see exactly where you want.

To provide effective security, the IS Series features a wide angle camera enabling you to see a panoramic view! People standing on the sides and people of all heights can be easily identified.

Facilities with IP networks can be controlled from a distance. It can make centralized security management simple and easy.

Wide Mode Zoom & PanTilt Mode

With conventional series

Innovative Wide View of Approx.

170°

Hardwired Network Systemd

Audio Sub Station is available

Your PC can be used as the Master Station (IS-SOFT)

Schedule Chime

Customize Sounds

Emergency Broadcasts

Browser Based Set-up

Create Unique System Settings

Paging

Forward Unanswered Calls Automatically

Transfer Video Calls

Other Functions

Sub Station. There are 2 styles available, a handset or a hands-free option.

You can use your PC just like the Master Station by installing the IS software.

* It may not be available depending on your PC or OS version.

Program daily Chime by the day, week, or month. Create different schedules for holidays, breaks, or after hours.

Create zones to broadcast emergency announcements quickly.

Simply use a browser to get on-line and set-up, change, or customize the IS systems.

Save system settings, then export and upload them to another system.

You can make a page from the Master Station to other Master Stations, Door Stations, and Room Sub Stations.

If a Master Station is not answered, have the call forwarded to another Master, or a group of Masters.

Call-ins from a Video Door Station can be transferred to any standard or PC Master Station on the network for easy identification.

Load up to 15 Pre-recorded messages or sound source. IS-RS IS-SS

Solutions for Your Security Needs.

Large Corporations

Airports

Schools

Shopping Mall

Hospitals

Parking Garages

Protect staff by giving them the advantage to safely confirm the identity of visitors and vendors before granting access into the building.

Communications between several departments at separate area of the facility.

Broadcast messages throughout the school or to a particular classroom with the choice of either a hands-free or handset Room Sub Station.

Prompt action in emergency conditions, such as quick call to a disaster control center, is easy using internal communication between tenants.

Increase staff efficiency by controlling various entrances from a central location. Easily transfer responsibilities to another location or individual.

Assist visitors and monitor multiple garage entrances from remote locations during or after hours.

IS-IPMV

Parking 5 Parking 1 Parking 2 Parking 3 Parking 4

Usage Example

For offices

For schools, factories, etc.

For unattended parking garages

The IS Series allows you to manage your door entry security via a LAN/WAN network and gives you the

freedom to choose your security system.

Identify or help visitors at reception desk during office hours, and then from another location, such as a security office, after hours. Automatic start and end times for transferring can be set using the time schedule settings.

Up to 160 Master Stations, 160 Video Door Stations, and 960 Room Sub Stations can be combined per site.

* Depending on combinations, the number above may not be applied. See the “MUXIMUM SETTING NUMBER” on page 10 for the details.

Announce emergencies from any Master Station to other Master Stations/Room Sub Station on the network (Should not be a return here).

You can also page and program daily announcements/chimes by day, week, month, or year.

Control multiple garage entrances from remote control center.

Hardwired network

Hardwired network

IP network

Office hours

After hours

Transfer

No need to be

there to answer

the door.

Make an emergency call

from any Master Station.

Security office Security office

Security office

System Components

IP Master Stations

PC IP Master Stations

Master Stations

For IP System

IP Control Unit

Control Unit

For Hardwired System

IP Video Door Stations

Audio Stations

Up to 32 units / site

Up to 32 units / site

Up to 32 units can be connected in a site

Up to 8 units / sites

Master Stations

_{Power Supplies}

Rack

Up to 960 units / site

Up to 160 units / site

System Configuration

IP System

WAN system

Site.1

Site.4

Site.2

Hardwired system

Hardwired system

-‡,- -‡-- -‡,- -‡---‡6 -‡6 -‡1 -‡1 -‡* -‡* Hub Hub Hub Router

Internet

Site.3

Hardwired system

speaker buttonCall Monitor recorderAudio

or or or or or ‡£Ó-Max.4 Max.2 Max.4 Max.8 Max.30 PA speaker PA speaker Strobe light or or Max.8 : AC transfarmer : IS-PU-UL, IS-PU-S : IS-PU-UL, IS-PU-S : PS-2420, PS-2420S, PS-2420UL -‡-"/ PS24 PS24 PS24 Max.4

œV>Ê-ÞÃÌi“ *Ê iÌܜÀŽÊ-ÞÃÌi“ œV>Ê-ÞÃÌi“ *Ê iÌܜÀŽÊ-ÞÃÌi“ œV>Ê-ÞÃÌi“ *Ê iÌܜÀŽÊ-ÞÃÌi“

IS-IPMV - ÎÓÉ-ˆÌi*Ó _{IS-MV Óä £ÈäÉ-ˆÌi*}£ _{IS-CCU £ nÉ-ˆÌi*}£

IS-IPDV - ÎÓÉ-ˆÌi*Ó _{IS-DV Óä £ÈäÉ-ˆÌi*}£ _{IS-SCU Ó £ÈÉ-ˆÌi*}£

IS-IPDVF - ÎÓÉ-ˆÌi*Ó _{IS-DVF Óä £ÈäÉ-ˆÌi*}£ _{IS-RCU { ÎÓÉ-ˆÌi*}£

IS-SOFT - *ÊΣÉ-ˆÌi*Ó _{IS-RS £Óä ™ÈäÉ-ˆÌi*}£

Maximum Setting Number

PS24 IS-PU or PoE or PoE or PoE -‡,1 -‡,- -‡---‡1 -‡6 -‡6 -‡6 -‡6 -‡---‡6 -‡,--‡6 -‡-1 PT

QB53024ACZ Distributed by :

IS(E)1102A

$OOULJKWVUHVHUYHG$OOVWDWHPHQWVYDOLGDWWLPHRISULQWLQJ7KHGHVLJQDQGVSHFLÀFDWLRQVDUHVXEMHFWWRFKDQJHZLWKRXWQRWLFHIRULPSURYHPHQW

The image on the monitor is simulated to explain the functions. It is different from the actual image.

(WIDE) (ZOOM) approx. 105cm approx. 105cm approx. 105cm approx. 75cm approx. 95cm 130cm 150cm 50cm 50cm approx. 70cm DSSUR[Ý approx. 90cm 189 215 265 265 85 83 199 280 265 250 167 300 162 UNIT DIMENSIONS(mm) CAMERA POSITION approx. 180cm approx. 200cm IS-MV, IS-IPMV

IS-DV, IS-IPDV IS-DVF, IS-IPDVF

IS-RS

IS-SS IS-RACK

IS-PU IS-CCU, IS-SCU, IS-RCU, IS-lPC

PS-2420 250 105 150 150 425 130 52 90 480 15 80 420 50 28 42 42 116.5 59 64 40 38 Mounting height 150cm Mounting height 130cm FUNCTIONAL SPECIFICATION

Video Door Station Audio Station Master Station IP Video Door IP Master Station PC appication

Item Features Hands-free Press-to-talk Handset Talk transfer

Video identification at door call Answering to door call Door release (contact output) Call forwarding on door call Absence transfer on door call Zone page to door station Direct Voice call and talk-back Monitor of door camera image / microphone Answering to master call

Answering to PC master call Zone paging

Zone chime of external sound source Zone chime of internal sound source E-mail at set trigger (small number of addresses) Normal or error status supervision Notification on contact input Video output
