VoLTE: Better Voice, More Profitable Data

The writing is on the wall for the traditional mobile service business model. Revenues from voice services, the industry’s “bread and butter” for decades, comprise a smaller percentage of the total each year. Data traffic continues to explode, taxing networks without fully offsetting losses on the voice side.

Also, the ability of mobile operators to capitalize on the rising popularity of smartphones, tablets, video, and Rich Communications Services (RCS) is compromised by “over the top” providers. OTT players piggy-back VoIP, messaging, chat, and location services on top of operators’ networks, often for free.

ARCChart predicts that by 2016 the installed base of OTT mobile VoIP subscribers alone will exceed 500 million.1 _{Skype and GoogleTalk have nearly a billion registered users worldwide.} By offering increased functionality at little to no cost, these services raise user tolerance for lower-grade performance while serving to relegate multi-million-dollar networks to providing the “pipes.”

Needless to say, mobile operators worldwide have gone on the offensive. Many have embarked on aggressive, innovative strategies to:

• Protect their share of diminishing voice revenues

• Improve the economics of service delivery and average revenue per user (ARPU) • Profit from the growth of data by fast-tracking their own compelling new services VoLTE stands to protect existing revenues while reducing opex and staunching the flow of revenues to OTT players—if providers can guarantee quality. Needless to say, the road is long, with many more decisions and challenges looming large.

Validating VoLTE: A “Lab to Live” Challenge

As they roll out VoLTE services, mobile operators need new ways of ensuring maximum quality and high ROI. Both can be accomplished by validating designs and performance in the lab, before and after deployment. From early on in the planning and prototype stages through the day-to-day monitoring of live production networks, life-cycle strategies are now needed to achieve predictable service delivery and optimize visibility.

Why Read This Book?

To extract the needed benefits from investments in VoLTE, and LTE in general, operators need to get deployments right the first time. To that end, this book presents a step-by-step guide for validating VoLTE implementations cost-effectively in the lab prior to deployment. This includes evaluating:

• Device and network performance • Interoperability

• Quality of Service and Quality of Experience • Network visibility and monitoring

Before embarking on the 40+ detailed test procedures contained in the Test Case section, let’s begin by taking a closer look at the current state of VoLTE, operator deployment plans, and the elements needed to optimize deployments.

About Ixia

The most trusted names in networking trust Ixia solutions to optimize equipment, networks, services, and applications. We help deliver innovative, differentiated offerings, improve management and visibility, and ensure a high-quality, always-on user experience.

Leading mobile operators worldwide use Ixia’s award-winning LTE solutions to accelerate and optimize 4G deployments and speed new services to market. A comprehensive suite of products and services are used to test, assess, and optimize key technology initiatives:

• Network performance, compliance, and security • Visibility into applications and services that

accelerates troubleshooting and enhances monitoring performance

• Securing mission-critical networks and services against attack • Cloud /virtualization and data center initiatives

For more information about Ixia, visit www.ixiacom.com. Also check out our groundbreaking new book, Small Cells, Big Challenge: A Definitive Guide to Designing and Deploying HetNets.
