U.S. Product Specifications Reference PSREF. Version 467, January ThinkVision Monitors. Visit for the latest version

(1)

Product Specificat

ions Reference

PSREF

Visit

www.lenovo.com/psref

for the latest version

U.S.

_{Version 467, Januar}

y 2015

(2)

Summary of Changes ... 1

LenovoThinkVisionE1922 Wide... 2

LenovoThinkVisionE2223s Wide ... 3

LenovoThinkVisionE2323 Wide... 4

LenovoThinkVision LT1421 Wide Mobile Monitor ... 5

LenovoThinkVision LT1423p Mobile Touch Monitor (Wired) ... 6

LenovoThinkVision LT1423p Mobile Touch Monitor (Wireless) ... 7

LenovoThinkVision LT1713p ... 8

LenovoThinkVision LT1913p Square ... 9

LenovoThinkVision LT1952p Wide ... 10

LenovoThinkVision LT1953 Wide ... 11

LenovoThinkVision LT2013s Wide ... 13

LenovoThinkVisionLT2024 Wide ... 14

LenovoThinkVision LT2223z Wide ... 16

LenovoThinkVision LT2323z Wide ... 19

LenovoThinkVision LT2423 Wide ... 20

LenovoThinkVision Pro2820 Wide ... 22

LenovoThinkVision Pro2840m Wide ... 23

LenovoThinkVision 28 ... 24

LenovoThinkVisionT2014 Wide ... 25

Withdrawn Product Books ... 26

Legal Information and Trademarks ... 27

(3)

Summary of Changes

This section describes the technical changes made in this edition.

This edition might also include minor corrections and editorial changes which are not identified.

January 28, 2015 - Version 467

Additions in this update

► New product(s)

Lenovo ThinkVision T2014 new product announced

► Others

None

Changes in this update

► None

Withdrawals in this update

► None

(4)

Name Case color Type-model Panel

Viewable image size Max view area (W x H) Native resolution Aspect ratio Pixel pitch (mm) Dot/Pixel per Inch Brightness Contrast ratio Pixel response time Color gamut Viewing angle at 10:1 CR Stand Bezel width Dimensions (HxWxD) Power supply Weight Limited warranty4 Available date VESA-compliant2 Power management Ergonomics Emission standards Environmental Preset resolutions

Presets / user settings Viewing adjustments Rotating screen On screen display Control features Multiple input Monitor connectors Signal cables Mounting features Security Ship group

Lenovo

ThinkVision

E1922 Wide

 Lenovo (E1922) February 2014 See footnotes for important warranty information

US model announced February 18, 2014

Product Specifications Reference (PSREF)

Limited Warranty

See details at http://support.lenovo.com/en_US/guides-and-manuals/de-tail.page?DocID=UM008281

Accessories

Kensington_MicroSaver_{Cable Lock} _73P2582

Kensington Twin Head Cable Lock 45K1620

See details at www.lenovo.com/support/monitoraccessories

See all monitors at www.lenovo.com/thinkvision ThinkVision E1922 Wide Monitor

Features

• Widescreen 18.5-inch monitor

• Supports HD 1366x768 resolution

• Supports VESA mount (100mm)

• Mercury free panel and arsenic free glass • Kensington lock slot ready for enhanced security

• Support Lenovo Tiny PC via VESA mount

• Microsoft_Windows_{7 certified}

• Microsoft Windows 8 / Windows 8.1 certified

E1922 Wide Flat Panel Monitor Business black

60B8AAR6US

TFT-LCD, twisted nematic (TN), White LED backlight

18.5" (470mm) diagonal 16.1" x 9.1" / 409.8mm x 230.4mm 1366x768 16:9 .300mm 85 dpi 250 nits or cd/m2_(typical) 1000:1 (typical) 5ms (typical) 72% 170° (+/- 85°) horizontal, 160° (+/- 80°) vertical Tilt adjustable stand

Sides: 0.73" (18.5mm)

13.44" H x 17.65" W x 6.58" D; 341.5mm H x 448.4mm W x 167.2mm D 13.7 watts typical, 17 watts maximum, <0.5 watts standby/suspend, universal, integrated (no external brick-like power supply) 6.03 lb; 2.74 kg

3 year (includes backlight)

March 2014

VESA DPMS-compliant ENERGY STAR_6.0 ISO 9241-307 FCC Class B

TCO (TCO Displays 6.0), WEEE, RoHS,

EPEATTM_{Gold rating}

VGA: 640x350, 640x480, 720x400 SVGA: 800x600, 832x624 XGA: 1024x768, 1152x864 SXGA: 1280x1024 WXGA: 1366x768 Standard presets: 15 user settings: 16

Tilt: 20° backward, -5° forward

None

On screen display with digital user controls (8 languages)

Direct access (control buttons on front) for automatic image setup and adjustment for brightness None

VGA 15-pin D-shell, analog, blue

detachable, VGA 15-pin D-shell at each end, analog, 1.8 meter

Wall or desk mounting using the Extend Arm or third-party accessories meeting the VESA FPMPMI_{(100mm mount)} Security keyhole for attachment of optional cable lock (Kensington_{lock-compatible)}

(5)

Viewable image size Max view area (W x H) Native resolution Aspect ratio Pixel pitch (mm) Dot/Pixel per Inch Brightness Contrast ratio Pixel response time Color gamut Viewing angle at 10:1 CR Stand Bezel width Dimensions (HxWxD) Power supply Weight Limited warranty4 Available date Power management Ergonomics Emission standards Environmental Preset resolutions

Lenovo

ThinkVision

E2223s Wide

 Lenovo (E2223s) March 2014 See footnotes for important warranty information

Accessories

See all monitors at www.lenovo.com/thinkvision ThinkVision E2223s Wide Monitor

Features

• Supports FHD 1920x1080 resolution

• Kensington lock slot ready for enhanced security

• Microsoft Windows 8 certified

E2223s Wide Flat Panel Monitor Business black

60AFHAR1US

21.5" (546mm) diagonal 18.7" x 10.5" / 476.1mm x 267.8mm 1920x1080 16:9 .248mm 102 dpi 200 nits or cd/m2_(typical) 600:1 (typical) 5ms (typical) 72% 90° (+/- 45°) horizontal, 50° (+/- 25°) vertical Tilt adjustable stand

Sides: 0.72" (18.3mm)

14.94" H x 20.60" W x 6.58" D; 379.4mm H x 514.5mm W x 167.2mm D 19 watts typical, 22 watts maximum, <0.5 watts standby/suspend, universal, integrated (no external brick-like power supply) 7.52 lb; 3.4 kg

March 2014 ENERGY STAR_6.0 ISO 9241-307 FCC Class B

WEEE, RoHS, EPEATTM_{SILVER rating}

VGA: 640x350, 640x480, 720x400 SVGA: 800x600, 832x624 XGA: 1024x768, 1152x864 SXGA: 1280x1024 WXGA: 1366x768 WXGA+: 1440x900, 1600x900 WSXGA+: 1680x1050 Full HD: 1920x1080 Standard presets: 26 user settings: 26

None

Direct access (buttons on front) for automatic image setup, dual input and brightness

Dual input (two different PCs attach to two different connectors; one PC shows image; select via button) (1) VGA 15-pin D-shell, analog, blue

(2) Digital Visual Interface (DVI-D), digital, white, HDCP-compliant

(1) detachable, VGA 15-pin D-shell at each end, analog, 1.8 meter (2) detachable, DVI-D at each end, digital, 1.8 meter

(6)

Viewable image size Max view area (W x H) Native resolution Aspect ratio Pixel pitch (mm) Dot/Pixel per Inch Brightness Contrast ratio Pixel response time Color gamut Viewing angle at 10:1 CR Stand Bezel width Dimensions (HxWxD) Power supply Weight Limited warranty4 Available date Power management Ergonomics Emission standards Environmental Preset resolutions

Lenovo

ThinkVision

E2323 Wide

 Lenovo (E2323) March 2014 See footnotes for important warranty information

US model announced January 7, 2014

Accessories

See all monitors at www.lenovo.com/thinkvision ThinkVision E2323 Wide Monitor

Features

• Widescreen 23-inch monitor

• Supports FHD 1920x1080 resolution

• Kensington lock slot ready for enhanced security

E2323 Wide Flat Panel Monitor Business black

60B0HAR1US

23" (584mm) diagonal 20.0" x 11.3" / 509.2mm x 286.4mm 1920x1080 16:9 .265mm 96 dpi 250 nits or cd/m2_(typical) 1000:1 (typical) 5ms (typical) 72% 170° (+/- 85°) horizontal, 160° (+/- 80°) vertical Tilt adjustable stand

Sides: 0.73" (18.6mm)

January 2014 ENERGY STAR_6.0 ISO 9241-307 FCC Class B

TCO (TCO Displays 6.0), WEEE, RoHS,

EPEATTM_{SILVER rating}

VGA: 640x350, 640x480, 720x400 SVGA: 800x600, 832x624 XGA: 1024x768, 1152x864 SXGA: 1280x1024 WXGA: 1366x768 WXGA+: 1440x900, 1600x900 WSXGA+: 1680x1050 Full HD: 1920x1080 Standard presets: 26 user settings: 26

None

(7)

Viewable image size Max view area (W x H) Optimum resolution Aspect ratio Pixel pitch (mm) Dot/Pixel per Inch Brightness Contrast ratio Pixel response time Color gamut Viewing angle at 10:1 CR Stand Bezel width Dimensions (HxWxD) Power supply Weight Limited warranty4 Available date VESA-compliant2 Power management Emission standards Environmental Preset resolutions Protective Screen Cover

Viewing adjustments Screen control Input Monitor connectors Signal cables Mounting features Security Ship group  Lenovo (LT1421) November 2011 See footnotes for important warranty information

US model announced August 16, 2011

➫ 3 year limited warranty4 ➫ International Warranty Service5

➫ Replacement normally arrives in two business days, excluding holidays

➫ Lenovo pays all shipping costs for valid warranty claims6 ➫ Service upgrade options:7

• 3 year, on site exchange, Mon-Fri 9-5 with next day response

(Lenovo Services part number 41C9209)

•4 year, on site exchange, Mon-Fri 9-5 with next day response (41C9233)

•4 year, mail exchange (51J0589)

➫ 24x78_{day toll-free support for warranty issues during the warranty period}4

Accessories

Kensington Twin Head Cable Lock 45K1620 See details at www.lenovo.com/support/monitoraccessories

See all monitors at www.lenovo.com/thinkvision ThinkVision LT1421 Wide Mobile Monitor

with ThinkPad Edge E420s Features

• Widescreen 14-inch mobilemonitor designed for ThinkPad

• Light and Slim

• Super low power (<5 watts)

• Supports 1366x768 resolution

• Ergonomic stand tilts, provides a 12° - 40° backward tilt

adjustment for comfortable viewing

• Detachable USB cable for power and signal

LT1421 Wide Mobile Monitor Raven black

1452-DS6 (withProtective Screen Cover)

14.0" (355.6mm) diagonal 12.2" x 6.9" (310.8mm x 175.3mm) 1366x768 16:9 .227mm 112 dpi 200 nits or cd/m2_(typical) 400:1 (typical) 8ms (typical) 45% 90° (+/- 45°) horizontal, 50° (+/- 25°) vertical Tilt adjustable stand

Sides: 0.476" (12.1mm)

8.58" H x 13.19" W x 0.37-0.85" D; 217.9mm H x 335mm W x 9.3-21.5mm D 4.2 watts typical, 5 watts maximum,

<0.1 watts standby/suspend, universal,

USB 2.0 cable (no external brick-like power supply)

monitor only: 1.91 lb; 0.87 kg;

with Protective Screen Cover: 2.31 lb; 1.05 kg

September 2011

VESA DDC2B/CI,VESA DPMS-compliant ENERGY STAR3 _5.1

FCC Class B WEEE, RoHS

Display mode and resolution auto setup Polycarbonate Snap-On Cover protects the LCD Screen while not in use

Tilt: 12° - 40° backward

Brightness (16 levels) USB input

USB 2.0

detachable, USB Y-Type cable, 1.8 meter None

Security keyhole for attachment of optional cable lock (Kensington_{lock-compatible)}

ThinkVision LT1421 Wide Mobile Monitor

Monitor, attached tile stand that cannot be removed, Setup poster, Safety and Warranty Information, CD with multilingual User's Guide and monitor installation files, 1.8 meter USB Y-Type cable,Protective Screen Cover

ThinkVision LT1421 with Protective Screen Cover

Lenovo

ThinkVision LT1421 Wide Mobile Monitor

(8)

Viewable image size Max view area (W x H) Optimum resolution Aspect ratio Pixel pitch (mm) Dot/Pixel per Inch Brightness Contrast ratio Pixel response time Color gamut Viewing angle at 10:1 CR Stand Bezel width Dimensions (HxWxD) Power supply Weight Limited warranty4 Available date VESA-compliant2 Power management Emission standards Environmental Preset resolutions

Presets / user settings Build in typing Stand Touch Screen Digitizer Pen Input Monitor connectors Signal cables Mounting features Security

Protective glass layer Simple Cover Stand Digital Control key Battery

Ship group

 Lenovo (LT1423P) September 2013 See footnotes for important warranty information

US model announced September 3, 2013

Accessories

See all monitors at www.lenovo.com/thinkvision Features

• Widescreen 13.3-inch mobile Touch monitor

• Supports 10-point touch

• Supports ThinkPad Digitizer pen

• Detachable USB cable for power and signal

• Arsenic/Mercury free

LT1423p Mobile Touch Monitor w/pen Raven black

60A3UAR2US (with Digitizer pen)

TFT-LCD, AH-IPS, White LED backlight

13.3" (337.8mm) diagonal 11.57" x 6.50" (293.8mm x 165.2mm) 1600x900 16:9 .184mm 138 dpi 200 nits or cd/m2_(typical) 500:1 (typical) 35ms (typical) 45% 150° (+/- 75°) horizontal, 150° (+/- 75°) vertical Bulid in typing stand

Sides: 1.04" (26.5mm);

top: 1.16" (29. 5mm);

bottom: 1.16" (29. 5mm)

8.87" H x 13.70" W x 0.26-0.50" D; 225.4mm H x 348.0mm W x 6.7-12.7mm D 6.0 watts typical, 7.0 watts maximum, <1.5 watts standby/suspend, universal,

USB 3.0 cable (no external brick-like power supply) 1.87 lb; 0.85 kg

September 2013 None None FCC Class B RoHS SVGA: 800x600 XGA: 1024x768 SXGA: 1280x1024 WXGA: 1280x720, 1280x800, 1366x768 WXGA+: 1440x900, 1600x900 7 Yes 10-point touch ThinkPad Digitizer pen USB input

USB 3.0

detachable, USB to mini-USB cable, 100cm detachable, USB Y-Type cable, 45cm None

Gorilla glass Yes

3 digital control keys None

Monitor, build in typing stand that cannot be removed, Setup poster, Safety and Warranty Information, 100cm USB to mini-USB cable, 45cm USB Y-Type cable, Simple Cover Stand, ThinkPad Digitizer pen

ThinkVision LT1423p

(9)

Viewable image size Max view area (W x H) Optimum resolution Aspect ratio Pixel pitch (mm) Dot/Pixel per Inch Brightness Contrast ratio Pixel response time Color gamut Viewing angle at 10:1 CR Stand Bezel width Dimensions (HxWxD) Power supply Weight Limited warranty4 Available date VESA-compliant2 Power management Emission standards Environmental Preset resolutions

Presets / user settings Build in typing Stand Touch Screen Digitizer Pen Input Monitor connectors Signal cables Mounting features Security

Protective glass layer Simple Cover Stand Digital Control key Battery

Ship group

Lenovo

ThinkVision LT1423p Mobile Touch Monitor (Wireless)

 Lenovo (LT1423P1) October 2013 See footnotes for important warranty information

US model announced October 15, 2013

Accessories

See all monitors at www.lenovo.com/thinkvision Features

• Widescreen 13.3-inch mobile Touch monitor (Wireless)

• 8m wireless range and up to 4 hours battery

• Supports 10-point touch

• Supports ThinkPad Digitizer pen

• Arsenic/Mercury free

LT1423p Mobile Touch Monitor w/pen (Wireless) Raven black

60ACUAR2US (with Digitizer pen)

TFT-LCD, AH-IPS, White LED backlight

13.3" (337.8mm) diagonal 11.57" x 6.50" (293.8mm x 165.2mm) 1600x900 16:9 .184mm 138 dpi 200 nits or cd/m2_(typical) 500:1 (typical) 35ms (typical) 45% 150° (+/- 75°) horizontal, 150° (+/- 75°) vertical Bulid in typing stand

Sides: 1.04" (26.5mm);

top: 1.16" (29. 5mm);

bottom: 1.16" (29. 5mm)

8.87" H x 13.70" W x 0.50" D; 225.4mm H x 348.0mm W x 12.7mm D 13.0 watts typical, 16.0 watts maximum, <0.5 watts standby/suspend, universal,

USB 3.0 cable (no external brick-like power supply) 2.86 lb; 1.30 kg

October 2013 None None FCC Class B RoHS SVGA: 800x600 XGA: 1024x768 WXGA: 1280x720, 1280x800, 1366x768 WXGA+: 1440x900, 1600x900 7 Yes 10-point touch ThinkPad Digitizer pen

WiFi 802.11 a/b/g/n and USB input USB 3.0

detachable, USB to mini-USB cable, 100cm detachable, USB Y-Type cable, 45cm None

Gorilla glass Yes

4 digital control keys 8120 mAh

Monitor, build in typing stand that cannot be removed, Setup poster, Safety and Warranty Information, 100cm USB to mini-USB cable, 45cm USB Y-Type cable, USB WiFi dongle, Simple Cover Stand, ThinkPad Digitizer pen

(10)

Viewable image size Max view area (W x H) Optimum resolution Aspect ratio Pixel pitch (mm) Dot/Pixel per Inch Brightness Contrast ratio Pixel response time Color gamut Viewing angle at 10:1 CR Stand Bezel width Dimensions (HxWxD, including stand) Power supply Weight Limited warranty4 Available date VESA-compliant2 Power management Ergonomics Emission standards Environmental Preset resolutions

Lenovo

ThinkVision LT1713p

 Lenovo (LT1713P) January 2014 See footnotes for important warranty information

US model announced December 17, 2013

Accessories

Kensington Twin Head Cable Lock 45K1620 Lenovo Easy Reach Monitor Stand 55Y9258

See all monitors at www.lenovo.com/thinkvision ThinkVision LT1713p Monitor

Features

• 17-inch Square LCD monitor

• Supports SXGA 1280x1024 resolution

• Includes dual input connection for attachment to two systems concurrently (analog and digital)

• Arsenic free glass

• Supports Lenovo Tiny PC and 3rd party thin client via optional Lenovo bracket

• Microsoft Windows 8.1 certified

LT1713p Square Flat Panel Monitor Business black

60B3HAR2US

TFT-LCD, twisted nematic (TN), LED backlight

17.0" (432mm) diagonal 13.3" x 10.6" (337.9mm x 270.3mm) 1280x1024 5:4 0.264mm 96 dpi 250 nits or cd/m2_(typical) 1000:1 (typical) 5ms (typical) 72% 170° (+/- 85°) horizontal, 160° (+/- 80°) vertical Tilt height adjustable stand

Sides: 0.60" (15.3mm); top: 0.73" (18.4mm); bottom: 1.10" (28.1mm)

16.0" H x 14.6" W x 6.5" D;

405.7mm H x 370.0mm W x 165.2mm D 13.0 watts typical, 16.0 watts maximum, <0.5 watts standby/suspend, universal, integrated (no external brick-like power supply) 7.90 lb; 3.60kg

January 2014

VESA DDC2B/CI, VESA DPMS-compliant ENERGY STAR_6.0

ISO 9241-307 FCC Class B

TCO Displays 6.0, TCO Certified Edge 1.2, WEEE, RoHS, EPEAT Gold rating

VGA: 640x350, 640x480, 640x500, 720x400 SVGA: 800x600 XGA: 1024x768, 1152x864, SXGA: 1280x1024 Standard presets: 17; user settings: 22

Tilt: 22° back, -3° forward; lift: 4.3" (110mm)

None

On screen display with digital user controls (8 languages) Direct access (buttons on front) for automatic image setup

Monitor and stand, Setup poster, Safety and Warranty Information, 1.8 meter analog signal cable, 1.8 meter digital signal cable, 1.8 meter black power cord

(11)

Viewable image size Max view area (W x H) Optimum resolution Max pixel rate Aspect ratio Pixel pitch (mm) Dot/Pixel per Inch Brightness Contrast ratio Pixel response time Color gamut Viewing angle at 10:1 CR Stand Bezel width Dimensions (HxWxD) Power supply Weight Limited warranty4 Available date VESA-compliant2 Power management Ergonomics Emission standards Environmental Preset resolutions

Presets / user settings

Viewing adjustments Rotating screen On screen display Control features Multiple input Monitor connectors Signal cables Mounting features Security Ship group

Lenovo

ThinkVision LT1913p Square

 Lenovo (LT1913P) August 2013 See footnotes for important warranty information

US model announced July 30, 2013

Accessories

Kensington MicroSaver Cable Lock 73P2582 Kensington Twin Head Cable Lock 45K1620 Lenovo Security Cable Lock 57Y4303 Lenovo Easy Reach Monitor Stand 55Y9258 See details at www.lenovo.com/support/monitoraccessories

See all monitors at www.lenovo.com/thinkvision ThinkVision LT1913p Square Monitor

Features

• 19-inch Square IPS LED backlit panel

• Support Lenovo Tiny PC via optional Lenovo bracket

• Mercury and arsenic free glass

• Low Halogen

• Recycled content in plastic material

LT1913p Square Flat Panel Monitor Business black

60AAHAR1US

TFT-LCD, In-Plane Switching (IPS), White LED backlight

19" (480.0mm) diagonal 14.76" x 11.80" (374.8mm x 299.8mm) 1280x1024 205MHz (VGA), 165MHz (DVI) 5:4 0.0976 (H) x 0.2928 (V) mm 86.8 dpi 250 nits or cd/m2_(typical) 1000:1 (typical) 7ms (typical) 72% 178° horizontal, 178° vertical

Tilt, swivel, pivot, and height adjustable stand

Sides: 0.69" (17.4mm); top: 0.69" (17.4mm); bottom: 0.69" (17.4mm)

14.89" H x 16.18" W x 8.74" D; 378.3mm H x 411.0mm W x 221.9mm D 24 watts typical, 27 watts maximum, <0.5 watts standby/suspend, universal, integrated (no external brick-like power supply) 10.03 lb; 4.55kg

August 2013

VESA DDC2B/CI, EDID 1.3 ENERGY STAR_6.0 ISO 9241-307 FCC Class B

TCO Displays 6.0, TCO Certified Edge 1.1, WEEE, RoHS, EPEAT Gold rating, ULE Gold

VGA: 640x350, 640x480, 720x400 SVGA: 800x600, 823x624 XGA: 1024x768, 1152x864, 1152x900 SXGA: 1280x1024 Standard presets: 20; user settings: 20

Tilt: 30° back, -5° forward; lift: 4.3" (110mm); swivel: +/- 45°

Screen pivots 90 degrees from landscape to portrait On screen display with digital user controls (8 languages)

Direct access (buttons on front) for automatic image setup, input switch, and brightness

Monitor, attached stand, Setup poster, Safety and Warranty Information, 1.8 meter analog signal cable, 1.8 meter DVI-D cable, 1.8 meter black power cord

(12)

Viewable image size Max view area (W x H) Optimum resolution Max pixel rate Aspect ratio Pixel pitch (mm) Dot/Pixel per Inch Brightness Contrast ratio Pixel response time Color gamut Anti-reflective Viewing angle at 10:1 CR Stand Bezel width Dimensions (HxWxD) Power supply Weight Limited warranty4 Available date VESA-compliant2 Power management Ergonomics Emission standards Environmental Preset resolutions

Lenovo

ThinkVision LT1952p Wide

 Lenovo (LT1952P) September 2011 See footnotes for important warranty information

US model announced September 13, 2011

Accessories

DisplayPort to DisplayPort Monitor Cable 0A36537 Kensington MicroSaver Cable Lock 73P2582 Kensington Twin Head Cable Lock 45K1620 Lenovo Security Cable Lock 57Y4303 ThinkCentre Extend Arm 57Y4352 Lenovo Easy Reach Monitor Stand 55Y9258 See details at www.lenovo.com/support/monitoraccessories

See all monitors at www.lenovo.com/thinkvision ThinkVision LT1952p Wide Monitor

Features

• Ergonomic stand tilts, swivel, and provides a 4.3" (110mm) range height adjustment for comfortable viewing

• Cable Management for better user experience

• Privacy Filter Slot

LT1952p Wide Flat Panel Monitor Business black

2448-MB6

19" (482.6mm) diagonal 16.07" x 10.05" (408.2mm x 255.2mm) 1440x900 137MHz 16:10 0.2835mm 89.4 dpi 250 nits or cd/m2_(typical) 1000:1 (typical) 5ms (typical) 72% Anti-reflective, anti-glare 170° horizontal, 160° vertical

Tilt, swivel, and height adjustable stand

15.66-19.99" H x 17.36" W x 6.74" D; 397.7-507.7mm H x 440.9mm W x 171.3mm D 13 watts typical, 17 watts maximum, <0.5 watts standby/suspend, universal, integrated (no external brick-like power supply) 9.49 lb; 4.30kg

September 2011 VESA DDC2B/CI ENERGY STAR_5.1 ISO 9241-307 MPR-2, FCC Class B

TCO Displays 5.2,TCO Certified Edge 1.1, WEEE, RoHS, EPEAT Gold rating, ULE Gold

VGA: 640x350, 640x480, 720x400 SVGA: 800x600 XGA: 1024x768, 1152x864 SXGA: 1280x1024 WXGA: 1280x768, 1366x768 WXGA+: 1440x900 Standard presets: 22; user settings: 22

Tilt: 20° back, -3° forward; lift: 4.3" (110mm); swivel: +/-180°; detachable stand

None

Triple input (three different PCs attach to three different connectors; one PC shows image; select via button) (1) VGA 15-pin D-shell, analog, blue

(2) DisplayPort, digital, black, HDCP-compliant

Note: DisplayPort cable is not included; use optional DisplayPort to DisplayPort Monitor Cable (0A36537)

Monitor, attached stand, Setup poster, Safety and Warranty Information, 1.8 meter analog signal cable, 1.8 meter DVI-D cable, 1.8 meter black power cord

(13)

Viewable image size Max view area (W x H) Optimum resolution Max pixel rate Aspect ratio Pixel pitch (mm) Dot/Pixel per Inch Brightness Contrast ratio Pixel response time Color gamut Viewing angle at 10:1 CR Stand Bezel width Dimensions (HxWxD, excluding stand) Dimensions (HxWxD, including stand) Power supply Weight Limited warranty4 Available date VESA-compliant2 Power management Ergonomics Emission standards Environmental Preset resolutions

Lenovo

ThinkVision LT1953 Wide

 Lenovo (LT1953) March 2013 See footnotes for important warranty information

Latin America model announced March 5, 2013 (This model is not available in the US)

Accessories

Kensington MicroSaver Cable Lock 73P2582 Kensington Twin Head Cable Lock 45K1620 Lenovo Security Cable Lock 57Y4303

See all monitors at www.lenovo.com/thinkvision ThinkVision LT1953 Wide Monitor

Features

• VGA and DVI connections

• Arsenic free glass

• Support Lenovo Tiny PC via VESA mount

• 85% PCC plastic resins

LT1953 Wide Flat Panel Monitor Business black

1453-HB1 (Latin America)

19" (482.6mm) diagonal 16.07" x 10.05" (408.2mm x 255.2mm) 1440x900 205MHz(VGA), 165MHz(DVI) 16:10 0.2835mm 89.4 dpi 250 nits or cd/m2_(typical) 1000:1 (typical) 5ms (typical) 72% 170° horizontal, 160° vertical Tilt stand Sides: 0.66" (16.8mm); top: 0.66" (16.8mm); bottom: 0.66" (16.8mm) 11.42" H x 17.45" W x 1.99" D; 290.2mm H x 443.2mm W x 50.5mm D 13.94" H x 17.45" W x 6.33" D; 354.0mm H x 443.2mm W x 160.7mm D 17 watts typical, 20 watts maximum, <0.5 watts standby/suspend, universal, integrated (no external brick-like power supply) 6.61 lb; 3.00kg

March 2013 VESA DDC2B/CI ENERGY STAR_6.0 ISO 9241-307 MPR-2, FCC Class B

VGA: 640x350, 640x480, 720x400 SVGA: 800x600, 832x624 XGA: 1024x768, 1152x864 SXGA: 1280x1024 WXGA+: 1440x900 Standard presets: 20; user settings: 20

Tilt: 22° back, -5° forward

None

Monitor, tilt stand, Setup poster, Safety and Warranty Information, 1.8 meter analog signal cable, 1.8 meter DVI-D cable, 1.8 meter black power cord

(14)

Viewable image size Max view area (W x H) Optimum resolution Aspect ratio Pixel pitch (mm) Dot/Pixel per Inch Brightness Contrast ratio Pixel response time Color gamut Viewing angle at 10:1 CR Stand Bezel width Dimensions (HxWxD, excluding stand) Dimensions (HxWxD, including stand) Power supply Weight Limited warranty4 Available date VESA-compliant2 Power management Ergonomics Emission standards Environmental Preset resolutions

Presets / user settings Viewing adjustments Rotating screen On screen display Control features USB hub Multiple input Monitor connectors Signal cables Mounting features Security Ship group

Lenovo

ThinkVision LT2013p Wide

 Lenovo (LT2013P) March 2013 See footnotes for important warranty information

US model announced March 12, 2013

Accessories

Kensington Twin Head Cable Lock 45K1620 Lenovo Security Cable Lock 57Y4303 Lenovo Easy Reach Monitor Stand 55Y9258 ThinkCentre Extend Arm 57Y4352

Features

• HD support, HDCP-compliant

• Ergonomic stand tilts, swivels, pivots and provides a 4.3" (110mm) range height adjustment for comfortable viewing

• Compliance with ENERGY STAR 6.0

• Support Lenovo Tiny PC and 3rd party thin client via optional Lenovo bracket

• Arsenic/Lead/Mercury free

• EPEAT Gold certified

60A0MAR1US

19.5" (494mm) diagonal 17.05" x 9.44" / 433.0mm x 239.8mm 1600x900 16:9 .27mm 94 dpi 250 nits or cd/m2_(typical) 1000:1 (typical) 5ms (typical) 72% 170° (+/- 85°) horizontal, 160° (+/- 80°) vertical Tilt, swivel, pivot, and height adjustable stand (tooless detachable) Sides: 0.66" (16.8mm); top: 0.66" (16.8mm); bottom: 0.66" (16.8mm) 10.82" H x 18.39" W x 2.07" D; 274.8mm H x 467.0mm W x 52.8mm D 13.25" H x 18.39" W x 7.87" D; 336.5mm H x 467.0mm W x 200.0mm D 17 watts typical, 36 watts maximum, <1.0 watts sleep/off (w/o USB hub); <0.5 watts switch off (w/o USB hub)

integrated (no external brick-like power supply) 9.70 lb; 4.40kg (excluding stand)

March 2013

ISO 9241-307 MPR-2, FCC Class B

TCO Displays 6.0, TCO Certified Edge 1.1, RoHS,

EPEAT Gold rating

VGA: 640x350, 640x480, 720x400 SVGA: 800x600, 832x624 XGA: 1024x768, 1152x864 SXGA: 1280x1024 WXGA: 1366x768 WXGA+: 1440x900 WSXGA+: 1600x900 Presets: 24; user settings: 24

Screen pivots 90 degrees from landscape to portrait (requires image rotation support from graphics controller,

do not support image rotation under dual image modes) On screen display with digital user controls (8 languages)

Direct access (buttons on front) for automatic image setup, input switch, and brightness USB 2.0 Hub (1 port into PC, 4 ports for accessories)

(2) DisplayPort, digital, black, HDCP-compliant

(3) HDMI (1.4), digital, HDCP-compliant

(1) detachable, VGA 15-pin D-shell at each end, analog, 1.8 meter

Wall or desk mounting using the Extend Arm or third-party asccessories meeting the VESA FPMPMI_{(100mm mount)} Security keyhole for attachment of optional cable lock (Kensington_{lock-compatible)}

Monitor, tooless detachable stand, Quick start and safety poster, analog signal cable, 1.8 meter USB cable, 1.8 meter black power cord

(15)

Viewable image size Max view area (W x H) Optimum resolution Aspect ratio Pixel pitch (mm) Dot/Pixel per Inch Brightness Contrast ratio Pixel response time Color gamut Viewing angle at 10:1 CR Stand Bezel width Dimensions (HxWxD, excluding stand) Dimensions (HxWxD, including stand) Power supply Weight Limited warranty4 Available date VESA-compliant2 Power management Ergonomics Emission standards Environmental Preset resolutions

Lenovo

ThinkVision LT2013s Wide

 Lenovo (LT2013S) July 2013 See footnotes for important warranty information

US model announced July 10, 2013

Accessories

See all monitors at www.lenovo.com/thinkvision ThinkVision LT2013s Wide Monitor

Features

• EPEAT Silver certified

LT2013s Wide Flat Panel Monitor Business black

60ABAAR1US

19.5" (494mm) diagonal 17.08" x 9.30" / 433.9mm x 236.3mm 1600x900 16:9 .27 (H) x .26 (V) mm 281/94 dpi 200 nits or cd/m2_(typical) 600:1 (typical) 5ms (typical) 72% 90° (+/- 45°) horizontal, 50° (+ 15/- 35°) vertical Tilt stand Sides: 0.62" (15.85mm); top: 0.73" (18.55mm); bottom: 0.73" (18.55mm) 10.83" H x 18.41" W x 2.09" D; 274.8mm H x 467.0mm W x 53.0mm D 13.50" H x 18.41" W x 6.33" D; 342.4mm H x 467.0mm W x 160.7mm D 17 watts typical, 19 watts maximum, <0.5 watts sleep/off;

<0.5 watts switch off

integrated (no external brick-like power supply) 5.50 lb; 2.50kg (excluding stand)

July 2013

VESA DDC2B/CI, EDID 1.3 ENERGY STAR_6.0 ISO 9241-307 FCC Class B

RoHS, EPEAT Silver rating

VGA: 640x350, 640x480, 720x400 SVGA: 800x600, 832x624 XGA: 1024x768, 1152x864 SXGA: 1280x1024 WXGA: 1366x768 WXGA+: 1440x900 WSXGA+: 1600x900 Presets: 24; user settings: 24

Tilt: 22° back, -5° forward

None

Direct access (buttons on front) for automatic image setup, input switch, and brightness None

VGA input

(1) VGA 15-pin D-shell, analog, blue

(16)

Viewable image size Max view area (W x H) Native resolution Aspect ratio Pixel pitch (mm) Dot/Pixel per Inch Brightness Contrast ratio Pixel response time Color gamut Viewing angle at 10:1 CR Stand Bezel width Dimensions (HxWxD) Power supply Weight Limited warranty4 Available date VESA-compliant2 Power management Ergonomics Emission standards Environmental Preset resolutions

Lenovo

ThinkVision

LT2024 Wide

 Lenovo (LT2024) February 2014 See footnotes for important warranty information

Accessories

See all monitors at www.lenovo.com/thinkvision ThinkVision LT2024 Wide Monitor

Features

• Includes dual input connection for attachment to two systems concurrently (analog and digital)

• Arsenic / Mercury free glass

• Support Lenovo Tiny PC and 3rd party thin client

LT2024 Wide Flat Panel Monitor Business black

60B9HAR1US

20.0" (508mm) diagonal 17.4" x 9.8" (442.8mm x 249.1mm) 1600x900 16:9 .276mm 92 dpi 250 nits or cd/m2_(typical) 1000:1 (typical) 5ms (typical) 72% 170° (+/- 85°) horizontal, 160° (+/- 80°) vertical Tilt adjustable stand

Sides: 0.567" (14.4mm)

March 2014

VESA DDC2B/CI ENERGY STAR_qualified ISO 9241-307

FCC Class B

TCO Displays 6.0, TCO Certified Edge 1.2, WEEE, RoHS, EPEATTM_{Gold rating}

VGA: 640x350, 640x480, 720x400 SVGA: 800x600, 832x624 XGA: 1024x768, 1152x864 SXGA: 1280x1024 WXGA: 1366x768 WXGA+: 1440x900, 1600x900 Standard presets: 24 user settings: 24

None

(17)

Viewable image size Max view area (W x H) Optimum resolution Aspect ratio Pixel pitch (mm) Dot/Pixel per Inch Brightness Contrast ratio Dynamic Contrast ratio Pixel response time Color gamut Viewing angle at 10:1 CR Stand Bezel width Dimensions (HxWxD, excluding stand) Dimensions (HxWxD, including stand) Power supply

Weight (including stand) Weight (Head only) Limited warranty4 Available date VESA-compliant2 Power management Ergonomics Emission standards Environmental Preset resolutions

Lenovo

ThinkVision LT2223p Wide

 Lenovo (LT2223P) March 2013 See footnotes for important warranty information

Accessories

B ba r

Features

• 1080p full HD support

• Integrated USB Hub (4 USB 2.0)

• Supports VGA, DisplayPort 1.2 and HDMI 1.4 interfaces (HDCP-compliant)

• Support Lenovo Tiny PC and 3rd party thin client via optional

• Lenovo bracket

ThinkVision LT2223p

21.5-inch FHD LED Backlit LCD Monitor Business black

60A1MAR2US

21.5" (546mm) diagonal 18.74" x 10.54" / 476.1mm x 267.8mm 1920x1080 16:9 0.248mm 103 dpi 250 nits or cd/m2_(typical) 1000:1 (typical) 2000000:1 5ms (typical) 72% 170° (+/- 85°) horizontal, 160° (+/- 80°) vertical Tilt, swivel, pivot, and height adjustable stand (tooless detachable) Sides: 0.68" (17.3mm); top: 0.68" (17.3mm); bottom: 0.68" (17.3mm) 11.97" H x 20.18" W x 2.22" D; 304.1mm H x 512.6mm W x 56.4mm D 14.29" H x 20.18" W x 8.60" D; 362.9mm H x 512.6mm W x 218.4mm D 23 watts typical, 27 watts maximum, <0.5 watts standby/suspend, universal, integrated (no external brick-like power supply) 10.94 lb; 4.96kg

6.77 lb; 3.07kg

March 2013

VGA: 640x350, 640x480, 720x400 SVGA: 800x600, 832x624 XGA: 1024x768, 1152x864 SXGA: 1280x1024 WXGA: 1366x768 WXGA+: 1440x900 WSXGA+: 1600x900, 1680x1050 Full HD: 1920x1080

Presets: 27; user settings: 20

Direct access (buttons on front) for automatic image setup, input switch, and brightness USB 2.0 Hub: 1 port into PC (USB 2.0); 4 ports for accessories (4 USB 2.0)

(2) DisplayPort (1.2), digital, black, HDCP-compliant

Monitor, tooless detachable stand, Quick start and safety poster, analog signal cable, 1.8 meter USB cable, 1.8 meter black power cord

(18)

Viewable image size Max view area (W x H) Optimum resolution Aspect ratio Pixel pitch (mm) Dot/Pixel per Inch Brightness Contrast ratio Dynamic Contrast ratio Pixel response time Color gamut Viewing angle at 10:1 CR Stand Bezel width Dimensions (HxWxD, excluding stand) Dimensions (HxWxD, including stand) Power supply

Weight (including stand) Weight (Head only) Limited warranty4 Available date VESA-compliant2 Power management Ergonomics Emission standards Environmental Preset resolutions

Presets / user settings Viewing adjustments Rotating screen On screen display Control features USB hub Multimedia Camera Multiple input Monitor connectors Signal cables Mounting features Security Ship group

Lenovo

ThinkVision LT2223z Wide

 Lenovo (LT2223Z) March 2013 See footnotes for important warranty information

Accessories

Kensington Twin Head Cable Lock 45K1620 Lenovo Security Cable Lock 57Y4303 Lenovo Easy Reach Monitor Stand 55Y9258 ThinkCentre Extend Arm 57Y4352 See details at www.lenovo.com/support/monitoraccessories

See all monitors at www.lenovo.com/thinkvision ThinkVision LT2223z Wide Monitor

Features

• 1080p full HD support

• Integrated camera (FHD), speakers & dual digital microphone

• Integrated USB 3.0 Hub (2 USB 3.0)

• Supports VGA, DisplayPort 1.2 and HDMI 1.4 interfaces (HDCP-compliant)

ThinkVision LT2223z

21.5-inch FHD LED Backlit LCD VoIP Monitor Business black

60A2MAR2US

21.5" (546mm) diagonal 18.74" x 10.54" / 476.1mm x 267.8mm 1920x1080 16:9 0.248mm 103 dpi 250 nits or cd/m2_(typical) 1000:1 (typical) 2000000:1 5ms (typical) 72% 170° (+/- 85°) horizontal, 160° (+/- 80°) vertical Tilt, swivel, pivot, and height adjustable stand (tooless detachable) Sides: 0.68" (17.3mm); top: 1.33" (33.8mm); bottom: 1.88" (47.8mm) 13.82" H x 20.18" W x 2.12" D; 351.1mm H x 512.6mm W x 56.4mm D 14.94" H x 20.18" W x 8.60" D; 379.4mm H x 512.6mm W x 218.4mm D 24 watts typical, 28 watts maximum, <0.5 watts standby/suspend, universal, integrated (no external brick-like power supply) 11.98 lb; 5.43kg

7.79 lb; 3.53kg

April 2013

VGA: 640x350, 640x480, 720x400 SVGA: 800x600, 832x624 XGA: 1024x768, 1152x864 SXGA: 1280x1024 WXGA: 1366x768 WXGA+: 1440x900 WSXGA+: 1600x900, 1600x1050 Full HD: 1920x1080 Presets: 25; user settings: 20

Direct access (buttons on front) for MIC mute, speaker mute and hook switch buttons USB 3.0 Hub: 1 port into PC (USB 3.0); 2 ports for accessories (2 USB 3.0) Integrated digital speakers (3 watts x 2)

Integrated camera (FHD) and digital dual microphone array, with Camera lock button for security

(2) DisplayPort (1.2), digital, black, HDCP-compliant

Monitor, tooless detachable stand, Quick start and safety poster, analog signal cable, 1.8 meter USB 3.0 cable, 1.8 meter black power cord

(19)

Viewable image size Max view area (W x H) Optimum resolution Max pixel rate Aspect ratio Pixel pitch (mm) Dot/Pixel per Inch Brightness Contrast ratio Pixel response time Color gamut Anti-reflective Viewing angle at 10:1 CR Stand Bezel width Dimensions (HxWxD) Power supply Weight Limited warranty4 Available date VESA-compliant2 Power management Ergonomics Emission standards Environmental Preset resolutions

Presets / user settings Viewing adjustments Rotating screen On screen display Control features USB hub Camera Multiple input Monitor connectors Signal cables Mounting features Security Ship group

Lenovo

ThinkVision LT2252p Wide

 Lenovo (LT2252P) January 2014 See footnotes for important warranty information

US model announced September 13, 2011 or December 18, 2012 US model 2572-MB6 withdrawn effective October 31, 2013

Accessories

DisplayPort to DisplayPort Monitor Cable 0A36537 Kensington_MicroSaver_{Cable Lock} _73P2582

Kensington Twin Head Cable Lock 45K1620 Lenovo Security Cable Lock 57Y4303 ThinkCentre Extend Arm 57Y4352 Lenovo Easy Reach Monitor Stand 55Y9258

Features

• Cable Management for better user experience

• Privacy Filter Slot

• Model 2572-MB1 supports Lenovo Tiny PC via optional Lenovo bracket

2572-MB6 / 2572-MB1

22" (559mm) diagonal 18.7" x 11.7" (473.8mm x 296.1mm) 1680x1050 205MHz 16:10 0.282mm 90 dpi 250 nits or cd/m2_(typical) 1000:1 (typical) 5ms (typical) 72% Anti-reflective, anti-glare 170° horizontal, 160° vertical

Tilt, swivel, pivot, and height adjustable stand

14.46-18.79" H x 19.92" W x 9.50" D; 367.3-477.3mm H x 506mm W x 241.2mm D 20 watts typical, 26 watts maximum, <0.5 watts standby/suspend, universal, integrated (no external brick-like power supply) 12.97lb; 5.89kg

September 2011 / December 2012 VESA DDC2B/CI ENERGY STAR_{5.1 (2572-MB6)} ENERGY STAR_{6.0 (2572-MB1)} ISO 9241-307 MPR-2, FCC Class B

VGA: 640x350, 640x480, 720x400 SVGA: 800x600 XGA: 1024x768, 1152x864 SXGA: 1280x1024 WXGA: 1280x768, 1280x800, 1366x768 WXGA+: 1440x900 1600x900 WSXGA+: 1680x1050

Standard presets: VGA/DisplayPort: 26; DVI-D: 25; user settings: 25

Tilt: 30° back, 0° forward; lift: 4.3" (110mm); swivel: +/-45°; detachable stand

Screen pivots 90 degrees from landscape to portrait (requires image rotation support from graphics controller)

Direct access (buttons on front) for automatic image setup, input switch, and brightness None

None

(3) Digital Visual Interface (DVI-D) for digital attach [white], HDCP-compliant

Monitor, attached stand, cable cover, Setup poster, Safety and Warranty Information, 1.8 meter analog signal cable, 1.8 meter DVI-D cable,1.8 meter black power cord

(20)

Viewable image size Max view area (W x H) Optimum resolution Aspect ratio Pixel pitch (mm) Dot/Pixel per Inch Brightness Contrast ratio Pixel response time Color gamut Anti-reflective Vertical frequency Horizontal frequency Viewing angle at 10:1 CR Stand Bezel width Dimensions (HxWxD) Power supply Weight Limited warranty4 Available date VESA-compliant2 Power management Ergonomics Emission standards Environmental Preset resolutions

Lenovo

ThinkVision LT2323p Wide

 Lenovo (LT2323P) May 2012 See footnotes for important warranty information

US model announced May 1, 2012

Accessories

isplayPo r isplayPo r Mon isplayPo r ba

Features

• 1080p full HD support, HDCP-compliant

• Built-in VGA, DVI and DisplayPort connectors for attachment to three systems concurrently

• Compliance with ENERGY STAR 6.0 DRAFT

LT2323p Wide Flat Panel Monitor Raven black

3024-HC1

23.0" (584mm) diagonal 18.65" x 11.66" / 473.8mm x 296.1mm 1920x1080 16:9 .265mm 96 dpi 250 nits or cd/m2_(typical) 1000:1 (typical) 5ms (typical) 72% Anti-reflective, anti-glare 50 to 75Hz 30 to 83kHz 170° (+/- 85°) horizontal, 160° (+/- 80°) vertical Tilt, swivel, pivot, and height adjustable stand (tooless detachable) Sides: 0.68" (17.2mm); top: 0.70" (17.7mm); bottom: 0.94" (24.0mm) 14.66" H x 21.49" W x 2.06" D; (excluding stand) 372.3mm H x 546.0mm W x 52.3mm D 20 watts typical, 38 watts maximum, <0.5 watts standby/suspend, universal, integrated (no external brick-like power supply) 12.65 lb; 5.74kg (excluding stand)

May 2012

VESA DDC2B/CI,VESA DPMS-compliant ENERGY STAR_{6.0 DRAFT}

TCO (TCO Certified Edge 1.1), WEEE, RoHS,

VGA: 640x350, 640x480, 720x400 SVGA: 800x600 XGA: 1024x768, 1152x864 SXGA: 1280x1024 WXGA: 1280x768, 1360x768 WXGA+: 1440x900 WSXGA+: 1680x1050 Full HD: 1920x1080 Presets: 26; user settings: 25

Direct access (buttons on front) for automatic image setup, input switch, and brightness USB 2.0 Hub (1 port into PC, 4 ports for accessories)

Monitor, tooless detachable stand, Quick start and safety poster, analog signal cable, DVI-D cable, 1.8 meter USB cable, 1.8 meter black power cord
