Feasibility Study for an Aquatic Ecosystem Earth

Observing System Version 1.2.

Arnold G. Dekker, Nicole Pinnel, Peter Gege, Xavier Briottet, Andy Court,

Steef Peters, Kevin R. Turpie, Sindy Sterckx, Maycira Costa, Claudia

Giardino, et al.

To cite this version:

Arnold G. Dekker, Nicole Pinnel, Peter Gege, Xavier Briottet, Andy Court, et al.. Feasibility Study for an Aquatic Ecosystem Earth Observing System Version 1.2.. Feasibility Study for an Aquatic Ecosystem Earth Observing System, CEOS, 2018. �hal-02172188�
