Replication and Consistency in Cloud File Systems

(1)

A. Reinefeld, F. Schintke, ZIB 1

Replication and Consistency

in Cloud File Systems

Alexander Reinefeld und Florian Schintke

Zuse-Institut Berlin

(2)

Let’s start with a little quiz

Who invented Cloud Computing?

a) Werner Vogels

b) Ian Foster

c) Konrad Zuse

The correct answer is … c)

“Schließlich werden auch Rechenzentren über

Fernmeldeleitungen miteinander vernetzt werden, …”

Konrad Zuse in „Rechnender Raum“ (1969)

Konrad Zuse 22.06.1910-18.12.1995

(3)

Zuse Institute Berlin

Research institute for applied mathematics

and computer science • Peter Deuflhard

chair for scientific computing, FU Berlin

• Martin Grötschel

chair for discrete mathematics, TU Berlin

• Alexander Reinefeld

(4)

HPC Systems @ ZIB

1987 Cray X-MP 471 MFlops 1994 Cray T3D 38 GFlops 1997 Cray T3E 486 GFlops 2002 IBM p690 2,5 TFlops 1984 Cray 1M 160 MFlops

1.000.000-fold performance increase in 25 years

1984 2009

2008/09 SGI ICE, XE

(5)

H

L

R

N

2 sites 98 computer racks 26112 CPU cores 128 TB memory 1620 TB disk 300 TF peak perf.

(6)

S

T

O

R

A

G

E

3 SL8500 robots 39 tape drives 19000 slots

(7)

What is Cloud Computing?

Cloud Computing = Grid Computing on Datacenters?

• not that simple …

Cloud and Grid both abstract resources through interfaces.

• Grid: via new middleware.

Requires Grid APIs.

• Cloud: via virtualization.

Allows legacy APIs.

Software as a Service (SaaS)

Applications Application Services

Platform as a Service (PaaS)

Programming Environment Execution Environment

Infrastructure as a Service (IaaS)

Infrastructure Services Resource Set

(8)

Alexander Reinefeld, ZIB 8

Why Cloud?

Pros

• It scales

because it‘s their resources, not yours

• It‘s simple

because they operate it

• Pay for what you need

don‘t pay for empty spinning disks

Cons

• It‘s expensive

Amazon S3 charges $.15 / GB / month. = $1800 / TB / year

• It‘s not 100% secure

S3 now allows to bring your own

RSA key-pair. But: Would you put your bank account into the cloud?

• It‘s not 100% available

S3 provides “service credits“ if availability drops (10% for 99.0-99.9% availability)

(9)

File System Landscape

ext3, ZFS, NTFS NFS, SMB AFS/Coda Lustre, Panasas, GPFS, CEPH... Cloud/Grid Cluster FS/ Datacenter Network FS/ Centralized PC, local system GDM "gridftp" Grid File System

(10)

Consistency, Availability, Partition tolerance:

Pick two of three!

Consistency: All clients have the same view of the data.

Availability: Each client can always read and write.

Partition tolerance: Operations will complete, even if individual components are unavailable.

Brewer, Eric. Towards Robust Distributed Systems. PODC Keynote, 2004.

A

C

P

A + P Amazon S3 Mercurial Coda/AFS C + A single server, Linux HA (one data center)

C + P

distributed databases, distributed file systems

(11)

Which semantic do you expect?

Distributed file systems should provide C + P

(12)

Grid File System

• provides access to heterogeneous

storage resources, but

• middleware causes additional complexity, vulnerability

• requires explicit file transfer

• whole file: latency to 1st _access,

bandwidth, disk storage

• also partial file access (gridftp) and pattern access (falls)

• no consistency among replicas

• user must take care

(13)

Cloud File System: XtreemFS

Focus on • data distribution • data replication • object based Key features • MRCs are separated from OSDs

• fat Client is the “link”

MRC = metadata & replica catalogue

OSD = object storage device

(14)

A closer look at XtreemFS

• Features

• distributed, replicated POSIX compliant file system

• Server software (Java) runs on Linux, OS X, Solaris • Client software (C++) runs on Linux, OS X, Windows

• _{secure: X.509 and SSL}

• _{open source (GPL)}

• Assumptions

• synchronous clocks with max. time drift (needed for OSD lease

negotiation, reasonable assumption in clouds)

• upper limit on round trip time

(15)

(16)

File access protocol

XtreemFS Client (fuse) User appl.

(Linux VFS) MRC OSD

FileSize = 128k Update(Cap, FileSize=128k)

(17)

Client

• gets list of OSDs from MRC

• get a capability (signed by MRC) per file

• selects best OSD(s) for parallel I/O

• various striping policies: scatter/gather, RAIDx, erasure codes

• scalable and fast access

• no communication between OSD and MRC needed

(18)

MRC – Metadata and Replication Catalogue

• provides

• open(), close(), readdir(), rename(), …

• attributes per file: size, last access, access rights, location (OSDs), …

• capability (file handle) to authorize a client to access objects on OSDs

• implemented with a key/value store (BabuDB)

• fast index

• append-only DB

(19)

OSD – Object Storage Device

• serves file content operations

• read(), write(), truncate(), flush(), …

• implements object replication

• also partial replicas for read-access

• data is filled on demand

• gets OSD list from MRC

• slave OSD redirects to master OSD

• write ops only on master OSD

(20)

OSD – Object Storage Device

• Which OSD to select?

• object list

• bandwidth

• rarest first

• network coordinates, datacenter map, …

(21)

OSD – Object Storage Device

• implements concurrency control for replica consistency

• POSIX compliant

• master/slave replication with failover

• group membership service provided by MRC

• lease service “Flease”: distributed, scalable and failure-tolerant

• 50,000 leases/sec with 30 OSDs

(22)

Quorum consensus

• Basic algorithm

• When a majority is informed, each other majority has at least one

member with up-to-date information.

• A minority may crash at any time.

• Paxos Consensus

• 1 Step: Check whether a consensus c was already established

• 2 Step: Re-establish c or try to establish own proposal

x

x x

(23)

Proposer

Init

r = 1 // lokale Runden-Nr

r_latest= 0 // Nr der höchsten bestätigten Runde

latest_v= ⊥ // Wert d. höchsten bestätigten Runde // Neues Proposal senden

ack_num= 0 // Anzahl gültiger Bestätigungen

Sende prepare(r) an alle acceptors

Empfange ack(r_ack,v_i,r_i) von acceptor i Falls r == r_ack

ack_num++ Falls r_i> r_latest

r_latest= r_i // jüngere akzeptierte Runde

latest_v= v_i // jüngerer Wert

Falls ack_num≥maj Falls latest_v== ⊥

schlage selbst einen Wert latest_v≠ ⊥vor sende accept(r, latest_v) an alle acceptors

Learner

num_accepted= 0 // Anzahl gesammelter accepts

Empfange accepted(r, v) von acceptor i Wenn r steigt: num_accepted= 0

num_accepted++

Falls num_accepted== maj

decide v; inform client // v ist Konsens

Acceptor

Init

r_ack = 0 // zuletzt bestätigte Runde

r_accepted= 0 // zuletzt akzeptierte Runde

v = ⊥ // aktueller lokaler Wert

Empfange prepare(r) von proposer

Falls r > r_ack ∧r > r_accepted // höhere Runde

r_ack= r

Sende ack(r_ack, v, r_accepted) an Proposer

Empfange accept(r, w) Falls r ≥r_ack∧r > r_accepted

r_accepted= r v = w

Sende accepted (r_accepted, v) an Learners

(24)

Striping Performance on Cluster

• Striping

• parallel transfer from/to

many OSDs

• bandwidth scales with the

number of OSDs

• client is the bottleneck:

(slower reads are caused by TCP ingress problem) R E A D W R IT E

One client writes/reads a single 4GB file using

asynchr. writes, read-ahead, 1MB chunk size, 29 OSDs. Nodes are connected with IP over IB (1.2 GB/s).

(25)

Snapshots & Backups

Metadata snapshots (MRC)

• need atomic operation without service interrupt

• asynchronous consolidation in background

• granularity: subdirectories or volumes

• implemented by BabuDB or Scalaris

File snapshots (OSD)

• taken implicitly when file is idle

or explicitly when closing file or fsync()

(26)

Atomic Snapshots in MRC

• implemented with BabuDB backend

• a large-scale DB for data that exceeds the system’s main memory

• 2 components:

• small mutable overlay trees (LSM trees)

• large immutable memory-mapped index on disk

• non-transactional key-value store

• prefix and range queries

• primary design goal: Performance!

• 300,000 lookups/sec (30M entries)

• fast crash recovery

(27)

Log Structured Merge Trees: .

(28)

Replicating MRC, OSDs

Master/Slave Scheme

• Pros

• fast local read

• no distributed transactions

• easy to implement

• Cons

• master is performance bottleneck

• interrupt when master fails: needs stable master election

Replicated State Machine (Paxos)

• Pros

• no master, no single point of failure

• no extra latency on failure

• Cons

• slower: 2 round trips per op

(29)

XtreemFS Features

Release 1.2.1 (current)

• RAID and parallel I/O

• POSIX compatibility

• Read-only replication

• Partial replicas (on-demand)

• Security (SSL, X.509)

• Internet ready

• Checksums

• Extensions

• OSD and replica selection (Vivaldi, datacenter maps)

• Asynchronous MRC backups

• Metadata caching

• Graphical admin console

• Hadoop file system driver (experimental)

Release 1.3 (very soon)

• DIR and MRC replication with automatic failover

• Read/write replication

Release 2.x

• Consistent Backups

• Snapshots

• Automatic replica creation, deletion and maintenance

(30)

Source Code

• XtreemFS

• http://code.google.com/p/xtreemfs

• 35.000 lines of C++ and Java code

• GNU GPL v2 license

• BabuDB

• http://code.google.com/p/babudb

• 10.000 lines of Java code

• new BSD license

• Scalaris

• http://code.google.com/p/scalaris

• 28.214 lines of Erlang and C++ code

(31)

Summary

• Cloud file systems require replication

• availability

• fast access, striping

• Replication requires consistency algorithm

• when crashes are rare: use master/slave replication

• with frequent crashes: use Paxos
