Page 3. Page 8. Page 6-7

(1)

Page 8

Page 6-7

(2)

TO ORDER, CALL

1-800-922-9048

2

22

2

2 Easy Ordering!

Easy Ordering!

From your local S&L Representative.

They keep a supply in stock for quick delivery!

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

Inside This

Issue . . .

Check Valve History

A look back on page 3.

Spring-Loaded, Non-Slamming Check Valves

• 3-D Drawings on page 4. • Key Advantages on page 5. • Sizing Chart on page 5.

How to Change a Wafer Check Valve

Step-by-step tips on pages 6-7.

Tough 4” & 6”

Wafer Check Valves

All the right parts on page 8.

Repair or Replace?

Expert Advice on page 8.

8”, 10” & 12”

Wafer Check Valves

Parts on page 9.

FORMULA X®_{4” & 6”}

Wafer Check Valves

Parts on page 9.

Wafer Check Valve Repair Parts

4”, 6”, 8”, 10” & 12” on pages 10-11.

What Makes S&L Check Valves Special?

Analysis on page 12. .

No part of this catalog, or the catalog in its entirety, may be reproduced by any means, electronics or otherwise, without explicit prior written authorization from Smith & Loveless, Inc.

Published by the After Market Division of Smith & Loveless, Inc. 14040 Santa Fe Trail Drive • Lenexa, KS 66215 • Ph: (913) 888-5201 • Toll Free in US: (800) 922-9048, Option 5 • Fax: (913) 748-0106.

Description Part No. Page No.

FORMULA X®_{Check Valve - 4” RH} _2L153T ₉

FORMULA X®_{Check Valve - 4” RH, Painted} _2L153T-304 ₉

FORMULA X®_{Check Valve - 4” LH} _2L153S ₉

FORMULA X®_{Check Valve - 4” LH, Painted} _2L153S-304 ₉

FORMULA X®_{Check Valve - 6” RH} _2L153R ₉

FORMULA X®_{Check Valve - 6” RH, Painted} _2L153R-304 ₉

FORMULA X®_{Check Valve - 6” LH} _2L153Q ₉

FORMULA X®_{Check Valve - 6” LH, Painted} _2L153Q-304 ₉

Spring Loaded Non-Slamming Check Valve, 4”x4” RH 2L34A 5 Spring Loaded Non-Slamming Check Valve, 4”x4” LH 2L34AA 5 Spring Loaded Non-Slamming Check Valve, 4”x6” RH 2L35A 5 Spring Loaded Non-Slamming Check Valve, 4”x6” LH 2L35AA 5 Spring Loaded Non-Slamming Check Valve, 4”x8” RH 2L35B 5 Spring Loaded Non-Slamming Check Valve, 4”x8” LH 2L35AB 5 Spring Loaded Non-Slamming Check Valve, 4”x8” LH 2L35AB 5 Spring Loaded Non-Slamming Check Valve, 5”x8” RH 2L35C 5 Spring Loaded Non-Slamming Check Valve, 5”x8” LH 2L35CC 5 Spring Loaded Non-Slamming Check Valve, 6”x8” RH 2L35D 5 Spring Loaded Non-Slamming Check Valve, 5”x8” LH 2L35DD 5 Wafer Check Valve - 4” RH 2L153P 8 Wafer Check Valve - 4” RH, Painted 2L153-300 8 Wafer Check Valve - 4” LH 2L153N 8 Wafer Check Valve - 4” LH, Painted 2L153N-300 8 Wafer Check Valve - 6” RH 2L153R 8 Wafer Check Valve - 6” RH, Painted 2L153R-300 8 Wafer Check Valve - 6” LH 2L153RQ 8 Wafer Check Valve - 6” LH, Painted 2L153Q-300 8 Wafer Check Valve - 8” RH 2L161F 9 Wafer Check Valve - 8” RH, Painted 2L161F-300 9 Wafer Check Valve - 8” LH 2L161E 9 Wafer Check Valve - 8” RH, Painted 2L161E-300 9 Wafer Check Valve - 10” RH 2L151H 9 Wafer Check Valve - 10” RH, Painted 2L151H-300 9 Wafer Check Valve - 10” LH 2L151G 9 Wafer Check Valve - 10” LH, Painted 2L151G-300 9 Wafer Check Valve - 12” RH 2L151K 9 Wafer Check Valve - 12” RH, Painted 2L151K-300 9 Wafer Check Valve - 12” LH 2L151J 9 Wafer Check Valve - 12” LH, Painted 2L151J-300 9 Wafer Check Valve Replacement Parts - 4” 2L153A, B, E, F, N P, S & T 11 Wafer Check Valve Replacement Parts - 6” 2L153C, D, G, H, L, M, Q & R 11 Wafer Check Valve Replacement Parts - 8” 2L161E, 2L161F 11 Wafer Check Valve Replacement Parts - 10” 2L161G, 2L161H 11 Wafer Check Valve Replacement Parts - 12” 2L161J, 2L161K 11

Late Spring 2007 Catalog Index

○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ®

(3)

Pipe Plug

STYLE A:

2L153A, 2L153B, 2L153C, 2L153D

Casted tapered Arm with one rounded end, 2 spring hole nubs and the spring connects directly to the arm.

STYLE B:

2L153E, 2L153F, 2L153G, 2L153H

Square bar stock Arm with eye bolt screwed into arm. The spring connects to the eye bolt.

STYLE C:

2L153E*, 2L153F*, 2L153N, 2L153P, 2L153L, 2L153M Looks exactly like Style B. The only difference: there are 2 pin holes in the shaft, viewed when the pipe plug is removed. If you have only 1 hole, you have Style B.

* For a brief time, some of the 2L153E & 2L153F were shipped with two pin holes. You may have also retrofitted your check valve recently to the two pin hole shaft.

OBSOLETE:

2L139

Back to 90 degree casted arm, only thinner for easy grip.

OBSOLETE:

2L161

New, square bar stop arm.

3

33

3

3 Order locally from your

Smith & Loveless Representative

Just how do you tell which style of Smith & Loveless Wafer Check Valve you have installed? The first two units are no longer found in the field, but are shown here for historical reference.

Your wafer check valve will be either Style A, B or C.

W

Wafer Check V

afer Check V

afer Check Valve Evolution

afer Check V

alve Evolution

Add Your Name to Our

Catalog Mail List

or Let Us Know Your New Mailing Address

Want the catalog mailed to you? Sign up online. Have you moved or changed jobs and want to start receiving the catalog again. Let us know your new address by noting Address Change. Want to remove yourself from the mailing list, type in the address to be removed and click the remove from list box. The online catalog sign-up a great way to let us stay in touch with you.

www.smithandloveless.comparts_cat_request_form.htm

HISTORICAL REFERENCE

(4)

TO ORDER, CALL

1-800-922-9048

4

44

4

4 These two 3-D drawings of the Smith & Loveless Spring-Loaded

Non-Slamming Check Valves highlight some of their key features.

Spring-Loaded

Non-Spring-Loaded Non-

Spring-Loaded

Non-Spring-Loaded Non-

Spring-Loaded Non-Slamming

Slamming

Check V

Check Valves

alves

Double Stainless Roll Pins Double O-Rings _Stainless Steel Shaft Stainless Steel Roll Pin

Bronze Arm Bronze Renewable Seat Ring Bronze Clapper Disc Bronze Castellated

Nut Stainless SteelCotter Pin

Hi-Tensile Cast Iron Arm Vent Plug

Hi-Tensile

Cast Iron Body _{Spring Bracket}

Hi-Carbon Steel Spring

Spring Adjustment

(5)

Dimension Drawing Keys

5

55

5

5 Order locally from your

Smith & Loveless Representative

○○○○○○○○○○○○○○○○○○○○○○

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

Key Advantages

• Eliminates the need for increasing fittings — saving space, materials and labor cost.

• Spring-loaded gate, non-slamming design.

• Highest quality construction with cast iron body, bronze and stainless steel fittings.

• Lubricated dual “O” ring shaft seals for easy opening and longer service life.

• Shaft extension allows right or left hand mounting of lever and spring assembly.

• Simple design and operation — all parts accessible through cover.

Smith & Loveless’ Spring-Loaded

Non-Slamming Check Valves

SIZE

SIZE-IT!

-IT!

Part # 2L34A 2L34AA 2L35A 2L35AA 2L35B 2L35BB 2L35C 2L35CC 2L35D 2L35DD Size of Valve 4” x 4” 4” x 4” 4” x 6” 4” x 6” 4” x 8” 4” x 8” 5” x 8” 5” x 8” 6” x 8” 6” x 8” A 13-5_/ 16 13-5_/ 16 13-5_/ 16 13-5_/ 16 18-1_/ 4 18-1_/ 4 18-1_/ 4 18-1_/ 4 18-1_/ 4 18-1_/ 4 B₁ 15_/ 16 15_/ 16 15_/ 16 15_/ 16 15_/ 16 15_/ 16 15_/ 16 15_/ 16 1 1 B₂ 15_/ 16 15_/ 16 15_/ 16 15_/ 16 1-1_/ 8 1-1_/ 8 1-1_/ 8 1-1_/ 8 1-1_/ 8 1-1_/ 8 C₁ 9 9 9 9 9 9 10 10 11 11 C₂ 9 9 11 11 13-1_/ 2 13-1_/ 2 13-1_/ 2 13-1_/ 2 13-1_/ 2 13-1_/ 2 D₁ 7-1_/ 2 7-1_/ 2 7-1_/ 2 7-1_/ 2 7-1_/ 2 7-1_/ 2 8-1_/ 2 8-1_/ 2 9-1_/ 2 9-1_/ 2 D₂ 7-1_/ 2 7-1_/ 2 9-1_/ 2 9-1_/ 2 11-3_/ 4 11-3_/ 4 11-3_/ 4 11-3_/ 4 11-3_/ 4 11-3_/ 4 E₁ 5_/ 8 5_/ 8 5_/ 8 5_/ 8 5_/ 8 5_/ 8 3_/ 4 3_/ 4 3_/ 4 3_/ 4 E₂ 5_/ 8 5_/ 8 3_/ 4 3_/ 4 3_/ 4 3_/ 4 3_/ 4 3_/ 4 3_/ 4 3_/ 4 F 10 10 10 10 13-1_/ 2 13-1_/ 2 13-1_/ 2 13-1_/ 2 13-1_/ 2 13-1_/ 2 G 10 10 13-1_/ 2 13-1_/ 2 13-1_/ 2 13-1_/ 2 13-1_/ 2 13-1_/ 2 13-1_/ 2 13-1_/ 2 H 6-1_/ 4 6-1_/ 4 6-1_/ 4 6-1_/ 4 8-3_/ 4 8-3_/ 4 8-3_/ 4 8-3_/ 4 8-3_/ 4 8-3_/ 4 I 7-3_/ 16 7-3_/ 16 7-3_/ 16 7-3_/ 16 9-1_/ 2 9-1_/ 2 9-1_/ 2 9-1_/ 2 9-1_/ 2 9-1_/ 2 Wt. In Lbs. 125 125 130 130 225 225 235 235 240 240 RH Vs. LH RH LH RH LH RH LH RH LH RH LH

Dimension Chart

Join S&L at

WEFTEC ‘07 in

San Deigo, CA

Smith & Loveless will make its fourth consecutive appearance at WEFTEC this fall. Please join us in sunny San Diego, CA for a week of fun, education and companionship! Look for S&L in booth number 5851 and come visit with the industry’s top experts about pumping, treatment and more!

More information is coming soon, so watch your mailboxes!

San Diego

Convention Center

Booth # 5851

October 15 - 17, 2007

For more info, visit:

www.weftec.org

(6)

20

3.

Loosen the (4) volute ears. This will allow the pump to rotate slightly when the all-thread is added, making the check valve removal a snap.

4.

Make sure all bolts are loose and out of the way.

5.

Put both 3/8" nuts on the 3/ 8" all thread and rotate the two nuts from the end to the center.

6.

Washers may be required for larger pumps and piping.

7.

Insert the all-thread, nut, and washer assembly just under the check valve arm.

8.

Insure that there are no obstructions.

9.

Rotate the all-thread out until the pump begins to rotate.

Easy Steps On How T

Easy Steps On How Tooooo

RRRRReplace Y

eplace Y

eplace Your

eplace Y

our

W

Wafer Check V

afer Check V

afer Check Valve

alve

1.

Close the Plug Valves.

DANGER: Disconnect and lock out power before servicing equipment. Failure

to do so could result in serious bodily injury or death.

2.

Loosen check valve bolts and nuts.

TO ORDER, CALL

1-800-922-9048

6

66

6

• 1/2" Drive Rachet • 15/16 Socket • 15/16" Wrench • 3/8" All Thread • Two 3/8" Nuts • Assorted Sized Washers For Larger Bolt Holes • New Baskets • Non-Hardening

Permatex Silicone • New Valve, if

(7)

7

77

7

7 Order locally from your

Smith & Loveless Representative

10.

This will allow for easy check valve removal.

11.

Inspect the check valve for damage.

12.

Remove the old gaskets.

13.

Install a new gasket with PERMATEX non-hardening silicone.

14.

Install 2 bolts and 2 nuts in the lowest holes. This will cradle the valve for easy installation.

16.

Install the check valve. Make sure the gasket is not damaged or slides out of position.

15.

Silicone the outside of both the gaskets with PERMATEX non-hardening silicone.

17.

Insert bolts and nuts and then tighten them.

20.

Open the plug valve. Restore power and check operation.

You have now successfully removed and replaced the Smith & Loveless check valve.

19.

Finally, tighten the volute ears.

18.

If all the bolts, noted in Step 17, do not align, use the all thread to rotate the pump slightly.

(8)

TO ORDER, CALL

1-800-922-9048

8

88

8

PART # SHAFT SIZE REPLACES

2L153N 4” Left Hand Wafer Check Valve 2L153E & 2L153A

2L153N-300 Painted 4” Left Hand Wafer Check Valve 2L153E & 2L153A

2L153P 4” Right Hand Wafer Check Valve 2L153F & 2L153B

2L153P-300 Painted 4” Right Hand Wafer Check Valve 2L153F & 2L153B

2L153Q 6” Left Hand Wafer Check Valve 2L153L, 2L153G, 2L153C

2L153Q-300 Painted 6” Left Hand Wafer Check Valve 2L153L, 2L153G, 2L153C

2L153R 6” Right Hand Wafer Check Valve 2L153M, 2L153H, 2L153D

2L153R-300 Painted 6” Right Hand Wafer Check Valve 2L153M, 2L153H, 2L153D

Now engineered for even tougher operation, Smith & Loveless’ 4” and 6” Wafer Check Valves now feature a new seat design which gives them one of the most robust seat arrangements on the market today! The 4” and 6” Wafer Check Valves are found on all of Smith & Loveless’ suction lift pump stations.

Even T

Even Tougher 4” & 6” W

ougher 4” & 6” W

ougher 4” & 6” Wafer Check V

ougher 4” & 6” W

afer Check V

afer Check Valves

afer Check V

alves

New larger diameter O-Ring Seat.

1/4” of metal — a 200% increase of metal seat area between hole and O-Ring Seat groove for an even more ffective and robust seal. Stainless steel shaft and brass clapper and arm — all built from noncorrosive materials. Larger diameter brass clapper

provides an even larger seat area.

New dovetail groove has a rugged gripping action that keeps the larger diameter O-Ring Seat securely in place without the use of adhesive. Arm and Shaft drilled with double pin holes to securely hold the arm and shaft in place, offering more arm and shaft strength.

Designed to pass a 3”

sphere.

When should you repair a check valve versus replace it? S&L’s Customer Service Team notes most customers rebuild a check valve when the check valve is in need of: Pin, Shaft, O-Rings, Clapper & Arm.

When it comes to seat problems, learn the check valve’s age. If you have a newer one, most customers will change the seat through repair. If you have a check valve that’s 10+ years in age with seat problems, it’s time to replace the check valve.

Repair vs. Replacement

P/N: 2L153N, P, Q & R

(9)

9

99

9

9 Order locally from your

Smith & Loveless Representative

8”, 10” and 12” Check V

8”, 10” and 12” Check Valves

alves

PART # SHAFT SIZE

2L161E 8” Left Hand Wafer Check Valve

2L161E-300 Painted 8” Left Hand Wafer Check Valve

2L161F 8” Right Hand Wafer Check Valve

2L161F-300 Painted 8” Right Hand Wafer Check Valve

2L161G 10” Left Hand Wafer Check Valve

2L161G-300 Painted 10” Left Hand Wafer Check Valve

2L161H 10” Right Hand Wafer Check Valve

2L161H-300 Painted 10” Right Hand Wafer Check Valve

2L161J 12” Left Hand Wafer Check Valve

2L161J-300 Painted 12” Left Hand Wafer Check Valve

2L161K 12” Right Hand Wafer Check Valve

2L161K-300 Painted 12” Right Hand Wafer Check Valve

○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○

FORMULA X

®

®®

WWMPS Check V

WWMPS Check Valves

alves

PART # SHAFT SIZE

2L153S 4” Left Hand Wafer Check Valve

2L153S-304 Painted 4” Left Hand Wafer Check Valve

2L153T 4” Right Hand Wafer Check Valve

2L153T-304 Painted 4” Right Hand Wafer Check Valve

2L153Q 6” Left Hand Wafer Check Valve

2L153Q-304 Painted 6” Left Hand Wafer Check Valve

2L153R 6” Right Hand Wafer Check Valve

2L153R-304 Painted 6” Right Hand Wafer Check Valve

P/N: 2L161E, F, G, H, J & K

P/N: 2L153S, T, Q & R

Now you can call Smith & Loveless’ Customer Service Technicians at:

(800) 922-9048,

then Option 7. This will take you to the first available Technician

Monday-Friday, 7:45 a.m. to 4:30 p.m. Central Standard Time.

For evening or weekend emergencies, it will automatically transfer you directly to our Technician On Call’s cell phone. This is just one more Smith & Loveless benefit.

Call S&L Customer Service T

Call S&L Customer Service Toll Free!

oll Free!

One of S&L’s Customer Service Technicians available to answer your questions at

(800) 922-9048, option 7.

(10)

TO ORDER, CALL

1-800-922-9048

10

10 6” W

6” W

6” Wafer Check V

afer Check V

afer Check Valve R

alve R

alve Repair P

alve R

epair P

epair Parts

epair P

arts

Tech Tip: Two 11L1C Flange Gaskets

are recommended if you have removed the 6 inch 2L153 Wafer Check Valve.

Parts Tip: The 2L153C & D were

replaced by the 2L153G & H. The 2L153G & H were replaced by the 2L153L & M. The 2L153L & M have now been replaced by the 2L153Q & R. You can purchase repair parts for all revision levels (see below).

4” W

4” Wafer Check V

afer Check V

afer Check Valve R

alve R

alve Repair P

alve R

epair P

epair Parts

epair P

arts

5 4 3 9 6 14 9 8 8 7 ₁₁ 10 12 15 13 4 2

Parts Tip: The 2L153A & B were replaced by

the 2L153E & F. The 2L153E & F have been replaced by the 2L153N & P. You can purchase repair parts for all revision levels (see below).

Tech Tip: Two 11L1A Flange Gaskets are

recommended if you have removed the 4 inch 2L153 Wafer Check Valve.

5 4 3 9 6 14 9 8 8 7 ₁₁ 10 12 15 13 4 2 ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○

8”, 10” and 12” W

8”, 10” and 12” Wafer Check V

afer Check V

afer Check Valve R

afer Check V

alve R

alve Repair P

alve R

epair P

epair Parts

arts

Tech Tip: Two Flange Gaskets are

recommended if you have removed the 8”, 10” or 12” wafter Check Valve.

P/N: 11L1D 8”

P/N: 11L1E 10”

(11)

11

11 Order locally from your

Smith & Loveless Representative

○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ 8” 2L161 E&F PART # 2L161E-1M 2L161E-2M 2L161E-3M 2L161E-4M 2L161E-5M 2L161E-6M 2L161E-7M 2L161E-8M 2L161E-9M 2L161E-10M DRAWING # 1 2 3 4 5 6 7 8 9 10 10” 2L161 G&H PART # 2L161G-1M 2L161G-2M 2L161G-3M 2L161G-4M 2L161G-5M 2L161G-6M 2L161G-7M 2L161G-8M 2L161G-9M 2L161G-10M DESCRIPTION Body Disc Disc Arm Shaft Bushing Packing Packing Gland Spring Arm Seat Spring 12” 2L161 J&K PART # 2L161J-1M 2L161J-2M 2L161J-3M 2L161J-4M 2L161J-5M 2L161J-6M 2L161J-7M 2L161J-8M 2L161J-9M 2L161J-10M 2L153 A & B PART # 55A30 55A40 55B28 6L184A 2L153A6 55B44/55B32 55A34 2L153A9 55B30 2L153A11 6L55N 11L104N 1L69B 6L55M 2 3 4 5 6 7 8 9 10 11 12 13 14 15 55A38A 55A40 55B28 6L184A 2L153A6 55B44/55B32 55A34 2L153A9 55A36 2L153D11 6L55N 11L104N 1L69B 6L55M Seat O-Ring Brass Arm* Brass Clapper S.S. Shoulder Bolt S.S. Pin S.S. Shaft*

Bronze Bushing (2 Required) Shaft O-Ring (2 Required) Steel Bar Handle

S.S. Pin

Eye Bolt, (from body to spring) S.S. Spring

Pipe Plug

Eye Bolt, (from handle to spring) Flange Gasket (2 required per valve) 11L207F 55A32 55B39 6L184A 2L153A6 55B32 55A34 2L153A9 55A36 2L153D11 6L55N 11L104N 1L69B 6L55M 2L153 E, F PART # 2L153 N, P PART # DESCRIPTION DRAWING #

*NOTE: The Arms and Shafts are now drilled to accommodate double roll pins (2L153A6). 11L207F 55A32 55B39 6L184A 2L153A6 55B32 55A34 2L153A9 55A36 2L153D11 6L55N 11L104N 1L69C 6L55M 11L1A 2L153 S, T PART # 2L153 C & D PART # 55A31 55A33 55B29 6L184B 2L153C6 55B34 55A35 2L153C9 55B30 2L153A11 6L55N 11L104N 1L69B 6L55M DRAWING # 2 3 4 5 6 7 8 9 10 11 12 13 14 15 2L153 G, H PART # 55A38B 55A33 55B29 6L184B 2L153C-12 55B34 55A35 2L153C9 55A37 2L153A11 6L55N 11L104M 1L69B 6L55M Seat O-Ring Brass Arm* Brass Clapper S.S. Shoulder Bolt S.S. Pin S.S. Shaft*

Bronze Bushing (2 Required) Shaft O-Ring (2 Required) Steel Bar Handle

S.S. Pin

Eye Bolt (from body to spring) S.S. Spring

Pipe Plug

Eye Bolt (from handle to spring) Flange Gasket (2 required per valve)

2L153 Q & R PART # 11L207G 55A39 55B40 6L184B 2L153C-12 55B37 55A35 2L153C9 55A37 2L153A11 6L55N 11L104M 1L69B 6L55M 11L1A 2L153 L & M PART # 55A38B 55A39 55B29 6L184B 2L153C-12 55B37 55A35 2L153C9 55A37 2L153A11 6L55N 11L104M 1L69B 6L55M

*NOTE: The Arms and Shafts are now drilled to accommodate double roll pins (2L153C6 OR 2L153C-12)

DESCRIPTION

Classic Wet Well Mounted Pump

Station & Recessed FORMULA X

®

Classic Wet Well Mounted Pump

Station & Recessed FORMULA X

®

Classic, Recessed and CAPSULAR®

(12)
