UNLOCKING TECHNOLOGY IVECO

(1)

UNLOCKING

TECHNOLOGY

(2)

APPLICATIONS

ADS136

IVECO

3 ADS177

IVECO

CAN

3 DIAGNOSTIC SOCKETS LOCATIONS

IVECO

4 GENERAL

OPERATION

5 SPECIAL

FUNCTIONS

6 PAGE

IVECO - CONTENTS

(3)

DAILY

29L 10, 11, 12, 14

 05

    ADC100+ADC146 A ADC100+ ADC146 DAILY

35S 10, 11, 12, 13, 14,

17

 05

    ADC100+

ADC146 A ADC100+ ADC146 DAILY

35C 10, 11, 12, 13, 14,

17

 05

    ADC100+

ADC146 A ADC100+ ADC146 DAILY

40C 10, 11, 12, 13

 05

45C 10, 13

 05

50C 11, 13, 14, 17

 05

60C 15

 05

65C 15, 17

 05

    ADC100+ADC146 A ADC100+ ADC146

1234

PRO AD100

IVECO - ADS136

APPLICATIONS

DAILY

_{Euro 4}

06 





ADC250

A

N/A

ECODAILY

Euro 5

06 

EEV





ADC250 A

N/A

1234

PRO AD100

(4)

IVECO

DIAGNOSTIC SOCKET LOCATIONS

DAILY

(5)

The immobiliser system fitted to the Iveco Daily provides theft protection using the ignition key and transponder device with a rolling code. There is an immobiliser symbol on the dashboard that indicates the status of the immobiliser. The system consists of an aerial fitted around the ignition barrel, an immobiliser ECU and a separate remote (plip) ECU. The keys and remotes have to be programmed separately as they are controlled by individual ECU’s.

IMPORTANT: Both the immobiliser ECU and remote ECU normally have the same security code. However if either one of the ECU’s has been replaced then it is possible that they haven’t both been re-programmed with the same security code, in these cases two separate security codes will be required.

(6)

SPECIAL FUNCTIONS

IVECO - >2005

PROGRAM KEYS

VEHICLE SELECTION + FIAT + GENERLA MOTORS + HONDA + HYUNDAI + IVECO + JEEP VEHICLE SELECTION + CHASSI CAB + VAN VEHICLE SELECTION IMMOBILISER REMOTE FUNCTIONS SWITCH IGNITION ON

PRESS ENTER KEY ECU IDENTIFICATION

IVECO IMMOBILISER HARDWARE V X.X SOFTWARE X.X PRODUCTION X.X

PRESS ENTER KEY

DIAGNOSTIC MENU

PROGRAM KEYS

KEYS PROGRAMMED

PRESS ENTER KEY

NOTE : USE GENUINE KEYS ONLY NOTE 2 : ANY KEYS NOT AVAILABLE WILL BE DELETED,

AND WILL NEED TO BE PROGRAMMED LATER. NOTE 3 : KEYS MUST BE VRIGIN, AND ARE 1 TIME PROGRAM ONLY

WEB SECURITY

DIAGNOSTIC MENU

ECU IDENTIFICATION FAULT CODES

SPECIAL FUNCTIONS

PRESS ENTER KEY

DIAGNOSTIC MENU

WARNING

KEYS NOT AVAILABLE WILL BE DELETED

CONTINUE

YES = ENTER NO = BACK

PRESS ENTER KEY

PROGRAMMING KEYS

SWITCH IGNITION OFF

PRESS ENTER KEY PROGRAMMING KEYS

SWITCH IGNITION ON

X KEYS STORED MAX 3/ MIN 2 KEYS PROGRAM AVAILABLE

OLD KEY FIRST CONTINUE

YES=ENTER NO=BACK

NOTE : IF THE KEY USED IS ALREADY PROGRAMMED THE EDC

INJECTOR SYMBOL AND IMMO WARNING LIGHT WILL GO OUT 3

SECONDS AFTER IGNITION IS SWITCHED ON. IF KEY IS UNPROGRAMMED THEN IMMO LIGHT WILL FLASH SLOWLY

AND EDC LIGHT QUICKLY

PLEASE ENTER NO. OF OLD KEYS TO

PROGRAM

PLEASE ENTER NO. OF NEW KEYS TO

PROGRAM NUMBER OF OLD KEYS

_ _ _ _

1 2 3 4 5

6 7 8 9 0

NUMBER OF NEW KEYS _ _ _ _

1 2 3 4 5

6 7 8 9 0

ENTER NUMBER OF OLD KEYS REQUIRED. THIS ALLOWS DELETED KEYS TO BE

RE-PROGRAMMED. IF YOU DON’T WANT TO RE-PROGRAM OLD KEYS (IE

(7)

SECURITY CODE _ _ _ _

1 2 3 4 5

6 7 8 9 0

PROGRAMMING KEYS X OLD KEYS X NEW KEYS IS THIS CORRECT ? YES=ENTER NO=BACK SECURITY CODE 22BC IS CODE CORRECT?





SPECIAL FUNCTIONS

IVECO - >2005

TOO MANY KEYS SELECTED

SWITCH IGNITION ON

PLEASE WAIT UP TO A MINUTE

X KEYS STORED

PRESS ENTER KEY

SWITCH IGNITION OFF

IGNITION OFF

PRESS ENTER KEY

ENTER KEY #2

PRESS ENTER KEY

FINISHED

PRESS ENTER KEY

FINISHED

NOTE : EDC AND IMMO LIGHTS SHOULD STOP FLASHING AT THIS

POINT. IF TOTAL NUMBER OF OLD KEYS

ENTERED IS >3, THEN YOU WILL BE ADVISED THAT TOO MANY

KEYS HAVE BEEN SELECTED. YOU WILL BE ASKED TO RE-ENTER THE NUMBER OF OLD & NEW KEYS

AGAIN

ENTER THE SECOND KEY IN THE IGNITION TO BE PROGRAMMED. THIS IS REPEATED FOR THE

NUMBER OF KEYS TO BE PROGRAMMED

SWITCH IGNITION ON

PRESS ENTER KEY

ENTER 5 DIGIT NUMERIC SECURITY CODE (SAME CODE FOR

REMOTES)

NOTE: IF THE IMMOBILISER ECU (DIFFERENT TO REMOTE ECU) HAS BEEN CHANGED, ENSURE THE CODES ARE STILL THE SAME,

FROM THE DEALER. IF NOT THEN TWO SEPARATE CODES ARE

REQUIRED.

AT THIS STAGE THE EDC SYMBOL WILL FLASH (IF NEW KEYS ARE

PROGRAMMED). IMMOBILISER SYMBOL

(8)

SPECIAL FUNCTIONS

IVECO - >2005

DIAGNOSTIC MENU

PROGRAM KEYS KEYS PROGRAMMED

PRESS ENTER KEY

KEYS PROGRAMMED

DISPLAYS THE NUMBER OF KEYS STORED.

KEYS STORED

REMOTES STORED: X

(9)

SPECIAL FUNCTIONS

IVECO - >2005

PROGRAM REMOTES

VEHICLE SELECTION + FIAT + GENERLA MOTORS + HONDA + HYUNDAI + IVECO + JEEP VEHICLE SELECTION + CHASSI CAB + VAN VEHICLE SELECTION IMMOBILISER REMOTE FUNCTIONS SWITCH IGNITION ON

PRESS ENTER KEY

DIAGNOSTIC MENU

PROGRAM REMOTES

REMOTES PROGRAMMED

PRESS ENTER KEY

NOTE : ANY REMOTES NOT AVAILABLE WILL BE DELETED,

AND WILL NEED TO BE PROGRAMMED LATER.

DIAGNOSTIC MENU

SPECIAL FUNCTIONS

PRESS ENTER KEY

PROGRAMMING REMOTES

WARNING

REMOTES NOT AVAILABLE WILL BE DELETED

CONTINUE

PRESS ENTER KEY

PLEASE ENTER NO. OF REMOTES TO PROGRAM

MAX 3 REMOTES

PRESS ENTER KEY

ACCESS GAINED

PRESS ENTER KEY PROGRAMMING REMOTES WITHIN 30 SEC PRESS REMOTE 1 ECU IDENTIFICATION IVECO REMOTES HARDWARE RELEASE WK : XX HARDWARE RELEASE VR : XX SOFTWARE RELEASE WK : XX SOFTWARE RELEASE VR : XX

PRESS ENTER KEY

NUMBER OF REMOTES _ _ _ _

1 2 3 4 5

6 7 8 9 0

PROGRAMMING REMOTES X REMOTE/S IS THIS CORRECT ? YES=ENTER NO=BACK SECURITY CODE _ _ _ _

1 2 3 4 5

6 7 8 9 0

SECURITY CODE 22BC IS CODE CORRECT?





REMOTES)

REQUIRED.

AFTER PRESSING ENTER, IF MORE REMOTES WERE REQUESTED THEN THE SCREEN

WILL PROMPT YOU TH PRESS REMOTE 2 & 3.

(10)

SPECIAL FUNCTIONS

IVECO - >2005

FOLLOW THE INSTRUCTIONS ON THE SCREEN.

TURN IGNITION OFF / ON / OFF (ALLOW 3 SECONDS AT EACH

STAGE) REMOVE THE KEY. TEST EACH REMOTE

IGNITION OFF /ON / OFF REMOVE KEY

TEST REMOTE OPERATION

PRESS ENTER KEY PROGRAMMING REMOTES

X REMOTES STORED

PRESS ENTER KEY

FINISHED

DIAGNOSTIC MENU

PROGRAM REMOTES REMOTES PROGRAMMED

PRESS ENTER KEY

REMOTES PROG

DISPLAYS THE NUMBER OF REMOTES STORED.

REMOTES STORED

REMOTES STORED: X

(11)

SPECIAL FUNCTIONS

IVECO DAILY - 2006 >

PROGRAM KEYS

VEHICLE SELECTION + FIAT + GENERLA MOTORS + HONDA + HYUNDAI + IVECO + JEEP VEHICLE SELECTION + DAILY + EUROCARGO + EUROTRAKKER + STRALIS + EUROFIRE SWITCH IGNITION ON

PRESS ENTER KEY ECU IDENTIFICATION

VIN: XXXXXXXXXXXXXXXXX

PRESS ENTER KEY

DIAGNOSTIC MENU

PROGRAM KEYS

PROGRAM REMOTES

PRESS ENTER KEY

NOTE : USE GENUINE KEYS ONLY NOTE 2 : ANY KEYS NOT

AVAILABLE WILL BE PERMANENTLY DELETED, NOTE 3 : KEYS MUST BE VRIGIN, AND ARE 1 TIME PROGRAM ONLY

DIAGNOSTIC MENU

SPECIAL FUNCTIONS

PRESS ENTER KEY

DIAGNOSTIC MENU

WARNING

ALL KEYS WILL BE CLEARED

CONTINUE

PRESS ENTER KEY

INSERT KEY TO PROGRAM SWITCH IGNITION ON

PRESS ENTER KEY

NUMBER OF KEYS _

1 2 3 4 5

6 7 8 9 0

VEHICLE SELECTION -> 2005 2006 -> IMPORTANT ORIGINAL KEYS NEED TO BE PROGRAMMED IN DURING THIS

PROCEDURE.

IF THEY ARE NOT PROGRAMMED IN AT THIS STAGE THEY WILL BE

PERMANENTLY DELETED

DIAGNOSTIC MENU

WARNING

PREVIOUSLY PROGRAMMED KEYS NOT PROGRAMMED DURING THIS PROCEDURE WILL BE PERMANETLY DELETED

PRESS ENTER KEY

CONTINUE = ENTER EXIT = BACK

SECURITY CODE _ _ _ _ _

1 2 3 4 5

6 7 8 9 0





NUMBER OF KEYS 2





INSERT NEXT KEY SWITCH IGNITION ON

PRESS ENTER KEY DIAGNOSTIC MENU

IMMOBILISER REMOTES

(12)

SWITCH IGNITION OFF

PRESS ENTER KEY

SPECIAL FUNCTIONS

IVECO DAILY - 2006 >

PROGRAM KEYS

PROGRAMMING KEYS PLEASE WAIT 25 SEC ******* SWITCH IGNITION ON

PROCEDURE COMPLETE

PRESS ENTER KEY

PROGRAM REMOTES

SWITCH IGNITION ON

PRESS ENTER KEY DIAGNOSTIC MENU

PROGRAM REMOTES

REMOTES PROGRAMMED

PRESS ENTER KEY

WARNING PREVIOUSLY PROGRAMMED REMOTES NOT PROGRAMMED

DURING THIS PROCEDURE WILL BE PERMANTELY DISABLED

CONTINUE?





SECURITY CODE _ _ _ _

1 2 3 4 5

6 7 8 9 0





KEYS)

REQUIRED.

WHEN REQUESTED TO DO SO PRESS AND HOLD THE UNLOCK

BUTTON ON EACH REMOTE. ACTION MUST BE COMPLETE

WITHIN 5 SEC. CONTINUE?





PROGRAM REMOTES

PRESS AND HOLD UNLOCK BUTTON ON THE FIRST REMOTE

REMOTES PROGRAMMED: 1 DO YOU WANT TO PROGRAM

MORE REMOTES?





PROGRAM REMOTES

PRESS AND HOLD UNLOCK BUTTON ON THE NEXT REMOTE

REMOTES PROGRAMMED: 2 DO YOU WANT TO PROGRAM

MORE REMOTES?





PROGRAM REMOTES PROCEDURE COMPLETE REMOTES PROGRAMMED: 2

(13)

_{TIPS & HINTS}

1.

Both the immobiliser ECU and remote ECU normally have the same security code. However if either one of the ECU’s has been replaced then it is possible that they haven’t both been re-programmed with the same security code, in these cases two separate security codes will be required.

2. Use genuine keys only.

3. Once programmed they can only be re-programmed to the same vehicle.

4. All programmed keys or remotes will be deleted when programming. If required, they must be re-programmed in during the programming sequence
