PDU’s Básicas

PDU Basiques

(2)

Regletas de conexión en formatos 19”,1U o montaje vertical “Zero U”. Construcción modular, perfil de aluminio con acabado aislante y toma de tierra. Conectores en PA reforzado UL94V0 y escuadras de fijación reversibles en PC UL94V0. Conexionado interior sobre placa continúa de latón (Bus-bar)

Cable de alimentación con distintas opciones de conectores. Conexión mediante Wieland GST-3A. Homologaciones: CE/VDE

Acabado: Perfil de aluminio lacado color natural. Bases y escuadras fijación negro similar a RAL9004. Entrega: unitaria en caja de cartón.

Power distribution units in 19”, 1U format or vertical assembly “Zero U's” Modular construction, manufactured in insulated aluminium profile.

Connections bases in reinforced PA UL94V0 and reversible brackets in PC UL94V0 Internal connections on brass Bus-bar.

Power cable with different connector options. Connections through Wieland GST-3A connectors. CE/VDE

Aluminium profile in natural colour. Connectors and brackets in black similar to RAL9004 Delivery: 1 unit packed in a cardboard box.

Homologations: Finish:

Réglettes de connexion 1U, 19'' ou en montage vertical “Zero U”. Construction modulaire en profilé d'aluminium isolant.

Connecteurs en PA UL94V0 renforcé et équerres de fixation en PC UL94V0 Connexions intérieures sur plaque continue en laiton (Bus-bar).

Câble d'alimentation avec différentes options de connecteurs. Connexion a travers de Wieland GST-3A. CE / VDE

Profilé d'aluminium naturel, connecteurs et équerres de fixation coloris noir similaire à RAL 9004. Emballage : Unitaire en carton individuel.

Homologations : Finition :

RX - SCHUKO DIN 49441

Code 19” U/HE Base/Socket/Prise Nº Protección/Protection/Protection Cable Connector

24155306 * 1 Schuko 6 Thermal Circuit Breaker 2m x 1,5 mm2 Schuko/UTE DIN49441

24155318 * 1 Schuko 8 Green Led indicator 2m x 1,5 mm2 Schuko/UTE DIN49441

24155308 * 1 Schuko 8 ON/OFF light switch 2m x 1,5 mm2 Schuko/UTE DIN49441 24155338 * 1 Schuko 8 Green Led indicator Check table code Wieland GST-3P

F (SCHUKO)

DIN 49-440 10-16A - 250V

(3)

24155346 * 1 Schuko 6 Ammeter Check table code Wieland GST-3P

24155326 * 1 Schuko 6 Surge Protector 2m x 1,5 mm2 Schuko/UTE DIN49441

24155625 * 1 Schuko 6 RFI Filter + ON/OFF light switch 2m x 1,5 mm2 Schuko/UTE DIN49441

24155348 * 1 Red Schuko 8 Green Led indicator 2m x 1,5 mm2 IEC320-C14

24155339 1 Schuko 16 Green Led indicator and overload 2m x 1,5 mm2 Schuko/UTE DIN49441 24155349 1 Schuko 16 Green Led indicator and overload Check table code Wieland GST-3P

(4)

24155812 * 1 IEC320-C13 12 Led and fuse 2m x 1,5 mm2 IEC320-C14

RX - IEC320 C13/14

24155846 * 1 IEC320-C13 8 Ammeter Check table code Wieland GST-3P 24155849 * 1 IEC320-C13 12 Led and fuse Check table code Wieland GST-3P

24155836 1 IEC320-C13 24 Led and overload Check table code Wieland GST-3P

24155850 1 IEC320-C13 24 Ammeter Check table code Wieland GST-3P 24155856 1 IEC320-C13/C19 18C13+4C19 Ammeter and overload Check table code Wieland GST-3P

C13 (IEC 320)

(5)

24155426 * 1 Schuko 6 Surge Protector 2m x 1,5 mm2 Schuko/UTE DIN49441

24155406 * 1 Schuko 6 Thermal Circuit Breaker 2m x 1,5 mm2 Schuko/UTE DIN49441

24155646 * 1 Schuko 6 Ammeter Check table code Wieland GST-3P

24155418 * 1 Schuko 8 Green Led indicator 2m x 1,5 mm2 Schuko/UTE DIN49441

24155408 * 1 Schuko 8 ON/OFF light switch 2m x 1,5 mm2 Schuko/UTE DIN49441 24155438 * 1 Schuko 8 Green Led indicator Check table code Wieland GST-3P

24155448 * 1 Red Schuko 8 Green Led indicator 2m x 1,5 mm2 IEC320-C14

RX - UTE (France-Belgium)

E (UTE)

10/16A - 250V B, F, L

(6)

24155439 1 Schuko 16 Green Led indicator and overload 2m x 2,5 mm2 Schuko/UTE DIN49441

24155449 1 Schuko 16 Ammeter and overload Check table code Wieland GST-3P 24155440 1 Schuko 16 Green Led indicator and overload Check table code Wieland GST-3P

24155508 * 1 IEC320-C19 8 Led Check table code Wieland GST-3P

RX - IEC320 C19/20

24155545 * 1 IEC320-C19 5 Ammeter Check table code Wieland GST-3P

C19 (IEC 320)

(7)

24155619 * 1 IEC320-C19 8(4+4) 2 Branch circuits 2 ammetesr 2 fuses 3m x 4 mm2 IEC60309-32A

RX - 32 Amp 1 Phase

24155620 * 1 Schuko 8(4+4) 2 Branch circuits 2 ammeters 2 fuses 3m x 4 mm2 IEC60309-32A

24155621 1 IEC320-C13 12(6+6) 2 Branch circuits 2 ammeters 2 fuses 3m x 4 mm2 IEC60309-32A

24155622 1 IEC320-C13 12(6+6) 2 Branch circuits 2 thermal bipole circuit breakers 3m x 4 mm2 IEC60309-32A

24155623 1 Schuko 12(6+6) 2 Branch circuits 2 thermal bipole circuit breakers 3m x 4 mm2 IEC60309-32A

24155624 1 IEC320C13-C19 24(12+12)C13 + 4(2+2)C19 2 Branch circuits 2 ammetesr 2 fuses 3mx4 mm2 IEC60309-32A

Posterior /Rear/ Arrière

(8)

24155626 * 1 Schuko 6(2+2+2) 3 Branch circuits 3 thermal bipole circuit breakers and leds 3m x 4 mm2 IEC60309-16A

RX - 16A 3 Phases

24155627 * 1 IEC320-C19 6(2+2+2) 3 Branch circuits 3 thermal bipole circuit breakers and leds 3m x 4 mm2 IEC60309-16A

24155628 * 1 Schuko 6(2+2+2) 3 Branch circuits 3 ammeters, fuses and leds 3m x 4 mm2 IEC60309-16A

24155629 * 1 IEC320-C19 6(2+2+2) 3 Branch circuits 3 ammeters, fuses and leds 3m x 4 mm2 IEC60309-16A

24155630 1 IEC320-C13/C19 30(10+10+10)C13+6(2+2+2)C19 3 Branch circuits 3 ammeters, fuses and leds 3m x 4 mm2 IEC60309-16A

(9)

24155631 * 1 Schuko 6(2+2+2) 3 Branch circuits 3 thermal bipole circuit breakers and leds 3m x 4 mm2 IEC60309-32A

RX - 32A 3 Phases

24155632 * 1 IEC320-C19 6(2+2+2) 3 Branch circuits 3 thermal bipole circuit breakers and leds 3m x 4 mm2 IEC60309-32A

24155633 * 1 Schuko 6(2+2+2) 3 Branch circuits 3 ammeters, fuses and leds 3m x 4 mm2 IEC60309-32A

24155634 * 1 IEC320-C19 6(2+2+2) 3 Branch circuits 3 ammeters, fuses and leds 3m x 4 mm2 IEC60309-32A

24155906 1 Schuko 18(6+6+6) 3 Branch circuits and leds 3m x 4 mm2 IEC60309-32A

(10)

24155745 * 1 UK 5 Ammeter 2m x 1,5mm2 BS UK

RX - BS (UK)

24155717 * 1 UK 7 Green led indicator 2m x 1,5mm2 BS UK

24155706 * 1 UK 6 ON/OFF light switch 2m x 1,5mm2 BS UK 24155739 1 UK 16 Green led and overload 2m x 2,5mm2 BS UK

24155635 1 IEC320-C13/C19 30(10+10+10)C13+6(2+2+2)C19 3 Branch circuits 3 ammeters, fuses and leds 3m x 4 mm2 IEC60309-32A

G (BS 1363)

10/16A - 250V

24155939 * 1 NEMA 5-20R 10 Led indicator and overload 10 feet 12/3 NEMA 5-20P

RX - NEMA (US)

24155949 1 NEMA 5-20R 12 Led indicator and overload 10 feet 12/3 NEMA 5-20P

B (NEMA 5-15)

(11)

24155228 * 1 Household 8 ON/OFF light switch 3m x 1,5 mm2 Household

RX HOUSEHOLD / IT (Denmark)

24155018 * 1 Household 8 Green led indicator 3m x 1,5 mm2 Household 24155322 1 Household 12 ON/OFF light switch 3m x 1,5 mm2 Household 24155108 * 1 Household 8 ON/OFF light switch 10m x 1,5 mm2 Household 24155112 1 Household 12 ON/OFF light switch 10m x 1,5 mm2 Household

24155208 * 1 IT 8 Green led indicator 3m x 1,5 mm2 IT

24155959 * 1 NEMA 5-20R 8 Ammeter + Overload 10 feet 12/3 NEMA 5-20P 24155969 1 NEMA 5-20R 12 Ammeter + Overload 10 feet 12/3 NEMA 5-20P

24155212 1 IT 12 Green led indicator 3m x 1,5 mm2 IT 24155008 * 1 IT 8 Green led indicator 10m x 1,5 mm2 IT 24155012 1 IT 12 Green led indicator 10m x 1,5 mm2 IT

K (Household)

10/16A - 250V

DK 2-5A (IT)

(12)

Code Cable Connector

24010063 3m x 1,5 mm2 Household (DK) to Wieland GST-3P 24010067 3m x 1,5 mm2 NEMA 5-15R (US) to Wieland GST-3P 24010062 3m x 1,5 mm2 IT (DK) to Wieland GST-3P

Fast and secure connection with Wieland GST-3A. 3 meters long cable.

Connexion rapide et sécurisée par connecteur Wieland GST-3A. Longueur câble :3 mètres. Conexión rápida y segura a través de conector Wieland GST-3A. Longitud de cable 3 metros.

24010061 3m x 1,5 mm2 Schuko/UTE to Wieland GST-3P

24010065 3m x 1,5 mm2 IEC320-C20 to Wieland GST-3P

24010066 3m x 1,5 mm2 Bs1363 (UK) to Wieland GST-3P

24010068 3m x 1,5 mm2 CETAC16A s1 phase to Wieland GST-3P

Code Cable Connector

24010064 3m x 1,5 mm2 IEC320-C14 to Wieland GST-3P B (NEMA 5-15) 10/16A - 120V K (Household) 10/16A - 250V Danish DK 2-5A (IT) 10/16A - 250V
