ekey net finger scanners Network access solutions

(1)

(2)

ekey was founded in 1999 and is now Europe's No. 1 for fingerprint access solutions. ekey puts authorization into the customer's hands! Keys, cards, codes, etc. can be lost, for

-gotten, or stolen. "Your finger is always on hand!" ekey's wide range of products includes finger scanners for doors, gates, alarm systems and time recording.

The international company currently has 70 employees at its 5 locations in Austria, Germany, Liechtenstein/Switzerland, Italy, and Slovenia and exports its products to over 70 coun

-tries, with exports making up 73% of its business. ekey's main sales markets include Spain and the USA, in addition to Austria, Germany, Switzerland, Slovenia, and Italy.

QUALITY

All ekey products undergo a rigorous endurance test before they reach the market. The test involves intensive simula

-tions of blazing heat, biting cold, and high humidity, and ev

-ery finger scanner is subjected to these conditions, along with all of its components, countless times before reaching

the customer.

Our quality formula comprises the highest standards of func

-tionality, reliability, and security, which are refined by means of extensive testing.

Quality-tested products from ekey – you can count on us!

CERTIFIED QUALITY MADE IN AUSTRIA:

• Extensive production, manufacturing, and functional testing (zero tolerance)

• Testing for environmental and temperature resistance

•

Vibration- and shock-tested

•

Tested for penetration of water and mechanical parts

•

Quality management system in accordance with EN ISO 9001:2008

(3)

ekey net

05

Step 1:

Which license do you need? 7–8 Step 2:

Select a suitable finger scanner. 9–16 Step 3:

Which control panel is right for you? 17 Step 4:

How many ekey net

converter LANs do you need? 18 Step 5:

Do you want to connect ekey net to

external systems? 19 Step 6:

Which power supplies do you need? 20 Step 7:

Commissioning and customer service 21 Step 8:

System requirements

Enrollment stations 22

Overview 04

ekey lock 3.0

23

Tips and Tricks

25

Wiring diagrams

27

Unique comfort with highest security

More than 1 million satisfied customers in over 70 countries around the world prove that ekey products are quickly becoming widespread among end users and companies. The many benefits of the finger scanner speak for themselves.

User-friendly!

• Easy installation and administration

Unrivaled convenience!

• Your key is always on hand! • It is impossible to lock yourself out!

Maximum security!

• No lost or stolen keys

• Maximum protection against forgery

Intelligent software!

The intelligent software is learning all the time – it can detect the growth of children's fingers as well as minor injuries and changes to users' habits.

5-year quality guarantee

for all ekey products!

Unique design!

to choose ekey finger

scanners

(4)

CP mini

CV LAN

4 finger scanners are managed by a single

control panel.

• can store up to 99 fingerprints • supports up to 4 finger scanners • can be used to control up to 4 functions • programmable time slots

• access log recording for every finger scanner • user-friendly operation via control panel • central user administration

• user permissions can be assigned on a per-sonalized basis

ekey multi

Multi-point access solutions.

The computer-controlled access control system for projects of all sizes.

• each scanner can store up to 2,000 finger

-prints

• supports up to 80 finger scanners

• programmable time slots

• access log recording for every finger scanner

• supports cross-site administration

• calendar function

ekey net

Network access solutions.

For details of our stand-alone/extended stand-alone solutions, please see catalog

(5)

Network access solutions.

Short facts:

• capable of storing up to 2000 fingerprints per finger

scanner

• up to 80 finger scanners can be managed on a single

network

• can be used to control up to 4 functions per finger scanner (e.g. open door or gate, deactivate alarm system, etc.)

• all finger scanners optionally available with RFID function

• supports cross-site administration

• access log recording for every finger scanner

• individually programmable time slots

• calendar functions

• interfaces for establishing external connections (e.g. building control, time recording, printer management, and WIEGAND systems, etc.)

• central administration vie the ekey net admin (PC) soft

-ware and enrollment via USB finger scanner ekey bit 2.0

The sophisticated access solution for

companies, associations and

high-end households.

ekey net is a networkable access control system for up to 80 finger scanners. It allows you to manage all your access zones centrally via a PC – from the entrance door of your of

-fice and the server room right through to the lab. Individual users are enrolled in the system with a user-friendly soft

-ware, where they can be clearly organized thanks to freely definable user groups. ekey net supports a range of interfac

-es so you can connect it to external systems (e.g. building management systems, time and attendance systems, printer management, and WIEGAND systems, etc.).

(6)

Computer

in Berlin in New YorkComputer

Central computer in Vienna

(7)

Step 1:

Which license do you need?

To cater for the broad range of possible applications, the ekey net software is available with 2 different license variants:

• ekey net business – full version

• ekey net light – basic access functions

ekey net upgrade license available on request

Functions available in ekey net business light

Finger scanner variants (S = 40, M = 200, L = 2,000 fingerprints) S, M, L S, M Number of finger scanners that can be managed in the system 80 80

Number of time slots UNLIMITED 3

Number of entries per time slot 31 12

Attendance list YES NO

Calendar UNLIMITED 1

Terminal groups UNLIMITED 1

User groups UNLIMITED 1

Concierge mode YES NO

WIEGAND YES NO

Ability to change basic settings (essentially those that are pre-defined) YES NO

Customer-specific device definition (action, event conversion) YES NO

CSV sending YES Positive only

ODBC (SQL) sending YES NO

HTML sending YES NO

UDP sending YES YES

ekey reporting YES NO

Terminal servers (e.g. in the case of multiple locations) 10 1

Time-controlled anti-passback (min) YES YES

Opening via cell phone with a single-use PIN for added security YES YES

Simultaneous switching of up to 2 functions YES YES

Daytime switching operation with first entry YES YES

Daytime switching operation without first entry (automatic time-controlled

operation) YES NO

(8)

Example

You have 14 finger scanners. Your part no. is 170 014

Example

You have 7 finger scanners. Your part no. is 171 007

Example for 7 finger scanners Part no. 171 007 Part no. 170 014 Example for 14 finger scanners

(9)

Step 2:

Select a suitable finger scanner ...

REL

Radio frequency identification

The finger scanner has an integrated RFID card reader.

Medium

max. 200 fingerprints*

outlet-mounted (OM)

for integration in door stations or switch frames

Standard

ekey finger scanner without any additional functionality

Small

max. 40 fingerprints*

wall-mounted (WM)

for easy mounting on walls Relay on board

The finger scanner has the switching relay already built in. Consequently, no additional control panel is required. For security reasons, the finger scanner is only suitable for internal use because it is not tamper-proof.

Large

max. 2,000 fingerprints*

integra

ideal for flush in-wall mounting

S

M

L

*This is the maximum number of fingerprints that can be stored on the finger scanner.

We recommend storing at least 2 fingerprints for each user.

... based on function!

... based on storage capacity!

(10)

WM 2.0

ekey finger scanner WM 2.0

For wall-mounting and easy retrofitting.

Finger scanner

Technical specifications

• FAR: 1:10,000,000/FRR: 1:100

• Dimensions W x H x D: 45 x 81.6 x 60.3 mm

• Power consumption: approx. 1 W

• Supply voltage: 8-24 VDC

• Temperature range: -25°C to +70°C

• IP code: IP44

• Recommended mounting height: 135 cm (lower edge)

• Display: 3 multicolored LEDs

• Functions: Tamper-proof, data retained in the event of a power failure, bus termination can be switched on device

Part no. Description Version

101 390 ekey net FS S WM 2.0 - 40 fingerprints

FS WM 2.0 for wall mounting,

steel-gray

101 391 ekey net FS M WM 2.0 - 200 fingerprints 101 392 ekey net FS L WM2.0 - 2,000 fingerprints 101 393 ekey net FS S WM 2.0 RFID - 40 fingerprints

FS WM 2.0 with RFID card reader for wall mounting, steel-gray

101 394 ekey net FS M WM 2.0 RFID - 200 fingerprints 101 395 ekey net FS L WM 2.0 RFID - 2,000 fingerprints 101 396 ekey net FS S WM 2.0 REL - 40 fingerprints

FS WM 2.0 with integrated switching relay for wall mounting, steel-gray 101 397 ekey net FS M WM 2.0 REL - 200 fingerprints

101 398 ekey net FS L WM 2.0 REL - 2,000 fingerprints

101 399 ekey net FS S WM 2.0 RFID + REL - 40 fingerprints _FS_{WM 2.0}_{with RFID card reader} and integrated switching relay for wall mounting, steel-gray

101 400 ekey net FS M WM 2.0 RFID + REL - 200 fingerprints 101 401 ekey net FS L WM 2.0 RFID + REL - 2,000 fingerprints

REL

(11)

Accessories

Part no. Description

101 406 ekey weather shield WM 2.0 ST, brushed stainless steel •Dimensions W x H x D:

110 x 170 x 95 mm

•Recommended mounting height: 130 cm (lower edge)

•Scope of delivery:

Weather shield ST, 4 chipboard screws 4 x 35, 4 screw anchors S5, 3 countersunk head screws M3 x 16, 3 Torx countersunk head screws M3 x 6 GU

101 418 ekey cover WM 2.0 ST, brushed stainless steel •Dimensions W x H x D:

89 x 87 x 103 mm

•Recommended mounting height: 110 cm (lower edge)

•Scope of delivery: Stainless steel housing, 4 chipboard screws, 4 x 35, 4 screw anchors S5, 3 countersunk head screws M3 x 16, 3 Torx countersunk head screws M3 x 6 GU

100 875 ekey net RFID card, with printed ekey logo, ISO 15693 100 916 ekey net RFID card, white, ISO 15693

100 662 ekey net RFID fob, black, round-cut, ISO 15693 100 659 ekey net RFID fob, white, ISO 15693

(12)

Finger scanner

Technical specifications • FAR: 1:10,000,000 • FRR: 1:100 • Dimensions W x H x D: 50.4 x 50.4 x 30.1 mm

• Recommended mounting height: 155 cm (lower edge) Be sure that the device remains easy to access and oper -ate

• Functions: Tamper-proof, data retained in the event of a power failure, bus termination can be switched on device, compatible with numerous door station build-in modules, letterboxes, in-wall sets, etc.

101 350 ekey net FS S OM I - 40 fingerprints

FS OM I for integration without design element (door station)

101 351 ekey net FS M OM I - 200 fingerprints 101 352 ekey net FS L OM I - 2,000 fingerprints 101 353 ekey net FS S OM I RFID - 40 fingerprints

FS OMI with RFID card reader for integration without design element (door station)

101 354 ekey net FS M OM I RFID - 200 fingerprints 101 355 ekey net FS L OM I RFID - 2,000 fingerprints

ekey finger scanner OM I

(13)

Accessories

Door station build-in modules GIRA 101 380 ekey Modul GIRA TX44 AL, aluminum color

101 381 ekey Modul GIRA TX44 AN, anthracite

101 382 ekey Modul GIRA TX44 PW, pure white

Door station build-in modules SIEDLE 101 376 ekey Modul SIEDLE Vario DG, dark gray 101 378 ekey Modul SIEDLE Vario W, white

101 379 ekey Modul SIEDLE Vario SM, silver metallic 101 618 ekey Modul SIEDLE Vario WH, high gloss white

101 619 ekey Modul SIEDLE Vario SH, high gloss black 101 620 ekey Modul SIEDLE Vario BG, micaceous amber

Door station build-in modules Elvox 101 552 ekey Modul Elvox 8000 Series GR, gray

Door station build-in modules bticino 101 533 ekey Modul bticino Sfera AME, allmetal

101 534 ekey Modul bticino Sfera AWH, allwhite

101 535 ekey Modul bticino Sfera AST, allstreet

101 536 ekey Modul bticino Sfera ROB, robur

Door station build-in modules URMET

101 410 ekey Modul URMET Sinthesi AL, aluminum color

Door station build-in modules Comelit On

request!

ekey Modul Comelit ikall BL, black, ekey finger scanner OM I built-in ekey Modul Comelit ikall WH, white, ekey finger scanner OM I built-in ekey Modul Comelit metal, metallic, ekey finger scanner OM I built-in

! Important: availability of build-in modules varying from country to country!

101 726 ekey net FS S OM I REL - 40 fingerprints _FS_{OM I}_{with integrated switching relay} for integration without design element (door station)

101 727 ekey net FS M OM I REL - 200 fingerprints 101 728 ekey net FS L OM I REL - 2,000 fingerprints

101 729 ekey net FS S OM I RFID + REL - 40 fingerprints _FS_{OM I}_{with RFID card reader and in} -tegrated switching relay for integration without design element (door station) 101 730 ekey net FS M OM I RFID + REL - 200 fingerprints

101 731 ekey net FS L OM I RFID + REL - 2,000 fingerprints

REL

(14)

ekey finger scanner OM E

For integration into switch frames by well-known manufacturers.

ekey finger scanners are compatible with switch frames from many well-known manufacturers:

Finger scanner

Technical specifications •FAR: 1:10,000,000 •FRR: 1:100 •Dimensions W x H x D: 50.4 x 50.4 x 30.1 mm

•Power consumption: approx. 1 W

•Supply voltage: 8-24 VDC

•Temperature range: -25°C to +70°C

•IP code: IP31/IP43

(depending on switch range) and IP64 (with cover OM ST)

Be sure that the device remains easy to access and operate

• Functions: Tamper-proof, data retained in the event of a power failure, bus termination can be switched on device, compatible with numerous 50 x 50 mm

switch ranges.

101 150 ekey net FS S OM E - 40 fingerprints

FS OM E for switch ranges with bezel, pure

white

101 151 ekey net FS M OM E - 200 fingerprints 101 152 ekey net FS L OM E - 2,000 fingerprints 101 153 ekey net FS S OM E RFID - 40 fingerprints

FS OM E with RFID card reader for switch ranges with bezel, pure white

101 154 ekey net FS M OM E RFID - 200 fingerprints 101 155 ekey net FS L OM E RFID - 2,000 fingerprints

(15)

Cavity wall box

101 166 ekey bezel OM PW 50 x 50, plastic,pure white 101 167 ekey bezel OM AL 50 x 50, plastic, aluminum color 101 168 ekey bezel OM AN 50 x 50, plastic,anthracite color

101 372 ekey cover OM ST, brushed stainless steel

• Dimensions W x H x D:

85x85x7.2 mm • Function: Cover provides the device with IP44 protection for use outdoors on exterior rendering with max. 1.5 mm masonry graining around the electrical outlet.

101 702 ekey frame OM GL WH, glass white

101 703 ekey frame OM GL BL, glass black 101 704 ekey frame OM GL MI, glass mint

101 705 ekey frame OM 503 GL WH, glass white

101 706 ekey frame OM 503 GL BL, glass black 101 707 ekey frame OM 503 GL MI, glass mint

100 304 ekey in-wall mounting frame OM ST, brushed stainless steel

101 511 ekey in-wall mounting frame OM ST LED, brushed stainless steel, with alarm LEDs •Dimensions W x H x D:

In-wall mounting frame: 88 x 88 x 42 mm Electric gang box: 73 x 73 x 57 mm

•Recommended mounting height: 135 cm •Scope of delivery: In-wall mounting frame and

electric gang box. A standard electric gang box is not suitable.

101 156 ekey net FS S OM E REL - 40 fingerprints

FS OM E with integrated switching relay for switch ranges with bezel, pure white 101 157 ekey net FS M OM E REL - 200 fingerprints

101 158 ekey net FS L OM E REL - 2,000 fingerprints

101 159 ekey net FS S OM E RFID + REL - 40 fingerprints _FS_{OM E}_{with RFID card reader and} integrated switching relay for switch ranges with bezel, pure white 101 160 ekey net FS M OM E RFID + REL - 200 fingerprints

101 161 ekey net FS L OM E RFID + REL - 2,000 fingerprints

Bezel/frame accessories

In-wall mounting frame accessories

REL

! Important: Available for delivery from Q3 2015

(16)

Finger scanner

IN 2.0 E

Technical specifications • FAR: 1:10,000,000 • FRR: 1:100 • Dimensions W x H x D: Housing 43.6 x 89 x 17.3 mm

With design element: 45.5 x 91.5 x 17.3 mm

• IP code: IP54

• Functions: Tamper-proof, data retained in the event of a power failure, bus termination can be switched on device

101 248 ekey net FS S IN 2.0 E - 40 fingerprints

FS integra 2.0 with stainless steel design element (ST) and 24 cm connection cable 101 249 ekey net FS M IN 2.0 E - 200 fingerprints

101 250 ekey net FS L IN 2.0 E - 2,000 fingerprints

101 251 ekey net FS S IN 2.0 E RFID - 40 fingerprints _FS_{integra 2.0}_{with RFID card reader and} stainless steel design element (ST) and 24 cm connection cable 101 252 ekey net FS M IN 2.0 E RFID - 200 fingerprints

101 253 ekey net FS L IN 2.0 E RFID - 2,000 fingerprints

Design element 2.0 E accessories

101 304 ekey design element integra 2.0, white, not suitable for RFID Part no. Description

RFID accessories

ekey finger scanner IN 2.0 E

Flush-mounted with stainless steel accessories.

(17)

Step 3:

Which control panel is right

for you?

100 666 ekey net control panel mini 1, 1 relay

100 667 ekey net control panel mini 2, 2 relays • Dimensions W x H x D:

25 x 60 x 42 mm (1 HP)

• Temperature range: -20°C to 70°C

• IP code: IP20

• Relays: CP mini 1, 1 x potential-free CP mini 2, 2 x potential-free

• Max. relay voltage, max. relay current: 42 VAC/DC; 1 A

• 1 input for door status (only with 100 666)

100 326 ekey net control panel wall-mounted 3, 3 relays

• Dimensions W x H x D: 180 x 110 x 39.2 mm

• IP code: IP20

• Relays: 3 x potential-free

• Max. relay voltage, max. relay current: 250 VAC/5 A; 30 VDC/5 A

• Control panel mini 1/2, can be mounted on a DIN rail to provide 1 or 2 functions • Control panel wall-mounted 3, ideal for upgrading to a maximum of 3 functions

• Control panel DRM 4, can be mounted on a DIN rail in a switch cabinet to provide up to 4 functions

Control panels

101 302 ekey in-wall set IN 2.0 ST, stainless steel

101 301 ekey in-wall set IN 2.0 ST LED, stainless steel, with alarm LEDs

housing: W x H x D: 60 x 122 x 36 mm Faceplate W x H x D: 96 x 142 x 2 mm 101 147 ekey weather shield IN 2.0 ST, stainless steel, incl. in-wall set

housing W x H x D: 60 x 122 x 36 mm Faceplate W x H x D: 126 x 142 x 65 mm 101 300 ekey wall mounting box IN 2.0, for flush-mounting installation, 0.5 mm sheet metal

housing W x H x D: 42 x 87 x 25 mm

In-wall set accessories

(18)

100 340 ekey net CV LAN with RS-485/LAN connection

• The finger scanners/control panels – which communicate using the RS-485 protocol – are connected to the net

-work (Ethernet) using the ekey net converter LAN.

• A single ekey net converter LAN is capable of managing up to 4 ekey net S finger scanners (40 fingerprints) or ekey net M finger scanners (200 fingerprints) plus 4 ekey net control panels. This means that each bus segment (CV LAN) can have up to 8 components. The individual components (finger scanners/control panels) must be connected in series. Star-type wiring between the ekey net converter LAN and the individual components is not permitted.

• If you opt for an ekey net L finger scanner (2,000 fingerprints), you will need a separate ekey net converter LAN for each access point.

• For maximum operational reliability, a separate ekey net converter LAN for each door is also recommended in the case of the ekey net S and ekey net M finger scanners.

For the exact wiring diagram,

see page 27 onwards.

! See diagram on page 29.

Technical specifications • Dimensions W x H x D:

25 x 60 x 42 mm (1 HP)

(19)

100 340 ekey net CV LAN with RS-485/LAN connection

Step 5:

Do you want to connect

ekey net to external systems?

ekey net offers interfaces for connection to external systems (such as building automation or alarm systems).

The UDP interface can be activated in the ekey net software and all it takes is a few clicks. The data packet is sent to a configurable IP address via the ekey net CV LAN (see page 18).

1 0012 7 80198504120001 1 6

Packet

type User ID FingerID Serial number offinger scanner Action Event "net" protocol

100 669 ekey net CV WIEG RS-485

Functions: The Wiegand converter converts the RS-485 protocol used by ekey into

a Wiegand protocol. Three options are available: the 26-bit standard protocol, the 39-bit Pyramid protocol, or a protocol with freely selectable ID bit lengths.

Interfaces

! The following interfaces are also supported: ODBC, CSV, HTML

Interfaces for connecting the equipment to alarm systems or other

access control systems

Interfaces for connecting the equipment to building

automation systems

Technical specifications • Dimensions W x H x D:

25 x 60 x 42 mm (1 HP)

•Supply voltage: 8-24 VDC

•Temperature range: -25°C to +75°C

(20)

101 700 ekey PS WPS 230 VAC/12 VDC/800 mA, wall power supply

• Dimensions W x H x D: 52 x 78.5 x 45 mm

• Supply voltage: 230 VAC

• Output voltage, output current: 12 VDC; 800

mA

• Cable length: 3.5 m 100 204 ekey PS OM 230 VAC/12 VDC/1.5 A, outlet-mounted power supply

• Dimensions Ø x H: 54 x 31 mm

• Output voltage, output current: 12 VDC; 1.5 A

• Temperature range: -5°C to 50°C 100 205 ekey PS DRM 230 VAC/12 VDC/2 A, DIN-rail mounted

• Dimensions W x H x D: 58x98x68.5 mm (3 HP)

• Output voltage, output current: 12 VDC; 2 A

• IP code: IP20 100 891 ekey PS DRM 230 VAC/24 VDC/2 A, DIN-rail mounted*

• Dimensions W x H x D: 72 x 93 x 68.5 mm (4 HP)

! *Important: Not compatible with ekey net CP WM 3 (100 326)

UPS DRM

101 559 ekey UPS DRM 230/12 VDC/4 Ah, DIN-rail mounted

• Dimensions W x H x D: UPS: 140 x 93 x 66.5 mm (8 HP) Battery: 157 x 93 x 66.5 mm (9 HP)

• Supply voltage: 100-240 VAC

• 2 parts: UPS (switched-mode power supply) and battery

• Function display: LED

• Advantage: Replaces line voltage power sup

-ply; ensures a reliable power supply to the system for several hours. Suitable for use in conjunction with a motorized lock.

101 593 ekey UPS DRM 230/24 VDC/4 Ah, DIN-rail mounted*

• Dimensions W x H x D:

UPS: 210 x 93 x 66.5 mm (12 HP) Battery: 157 x 93 x 66.5 mm (9 HP)

• Supply voltage: 100-240 VAC

• 3 parts: UPS (switched-mode power supply) and 2 x batteries

• Function display: LED

• Advantage: Replaces line voltage power sup

-ply; ensures a reliable power supply to the system for several hours. Suitable for use in conjunction with a motorized lock.

The uninterruptible power supply (UPS) comprises a switched-mode power supply and a battery. In the event of a power failure, it can be relied upon to supply power to the finger scanner, the control panel, and the motorized lock for several hours.

(21)

Step 7:

Commissioning

On request, you can arrange to have the system commissioned by an expert ekey partner in your country. However, if no local partner is available, you can also opt for REMOTE commissioning over the Internet, for which ekey charges

(22)

TCP/IP v4 must be activated. ekey net does not support TCP/IP v6.

Name resolution (DNS) It must be possible to mutually resolve the names (NetBI

-OS and DNS name) of all computers used in the ekey net system via DNS.

MSMQ, DNS

Routing It must be possible to access all computers involved in

the ekey net system in both directions via TCP and UDP. MSMQ, UDP, HTTP Local time on the

computer All computers involved in the ekey net system must be run with the same system time. Deviations of ±3 s between the computers are not tolerated.

ekey net services, ekey net admin

• x86 or x64 processor with at least 1.0 GHz

• 40 GB hard disk with at least 200 MB memory space available

• 256 MB RAM (minimum)

• Ethernet port with at least 10 Mbit/s

Windows Vista x86 SP1; Windows Vista x64 SP1; Windows 7 x86 SP1; Windows 7 x64 SP1; Windows 8 x86; Windows 8 x64; Windows 8.1 x86; Windows 8.1 x64; Windows Server 2003 x86 SP2; Windows Server 2003 x64 SP2; Windows Server 2003 R2 x86 SP2; Windows Server 2003 R2 x64 SP2; Windows Server 2008 x86 SP2; Windows Server 2008 x64 SP2; Windows Server 2008 R2 x64 SP1; Windows Server 2012 x64; Windows Server 2012 R2 x64

Minimum computer requirements

Operating system

101 449 ekey bit 2.0, USB finger scanner

For reading fingerprints into the ekey net system via a USB connection 101 333 ekey net enrollment station with RFID function

For reading fingerprints and RFID cards into the ekey net system via a LAN connection

Enrollment stations

(23)

ekey lock 3.0 radio cylinder

Retrofitting solution for all ekey systems.

No more keys ...

The ekey lock 3.0 radio cylinder makes it easy to retrofit existing doors with finger scanners. Say goodbye to heavy bunches of keys and lost keys. Finger scanners are the safe and secure alternative to keys, which can be easily lost, for

-gotten, or stolen.

Benefits of ekey lock:

• for internal, external, and glass doors • no cables inside the door

• easy mounting

• suitable for single-point and multi-point locks • take it with you when you move house • existing fittings are retained

Short facts:

• radio range indoors up to 10 m

• encrypted communication (frequency 868 MHz)

• standby time approx. 6 years

• ergonomically optimized mechanical knob

• “Made in Germany” durable cylinder mechanism

• long battery life (approx. 75,000 cycles)

• batteries are easy to replace

(24)

Determine cylinder length

Cut out the measuring gauge from page 36 Part no. Description

150 017 ekey lock wireless transponder 3.0

Key for emergency opening; backup if there is no 2nd entrance. 150 018 ekey lock RFID card set 3.0

incl. installation card, battery replacement card, and service card 150 021 ekey lock electric strike

Scope of delivery: electric strike 10-24 V ACDC, flat shield 25 x 250 x 3 mm

Accessories

100 893 ekey lock radio module 3.0 Scope of delivery:

• 1 module knob (MOK)

• 1 radio emitting module (REM)

• 1 short antenna (SANT)

•1 card set

•2 batteries (CR2 type) •1 battery replacement clamp

Cylinders available in lengths ranging from 30/30 to 70/70 in 5 mm increments (see price sheet)

Scope of delivery:

• 1 mechanical knob (MEK) with permanently assembled cylinder

Basic set

Part no.: 100 893 Part no.: various e.g. ekey net _{FS WM 2.0} e.g. ekey net _{CP WM 3} e.g. ekey net _{CV LAN} 230 VAC/12 VDC/0.8 e.g. ekey PS WPS

A

Optional:

• ekey lock wireless transponder for emergency opening

• ekey lock electric strike

! Important: Use a measuring gauge to determine the correct cylinder length. See price list for cylinder lengths.

(25)

Installation position and mounting height Sensor and finger surface

Installation position: Finding the right position for the finger scanner will make the finger swipe technique much easier to master and will improve finger recogni

-tion. The finger scanner works just as well whether you are right-handed or left-handed!

It is important to have enough moving space when standing in front of the finger scanner. Straining to reach the scanner will produce poor results.

Mounting height: The scanner can only be used ergonomically if it is mounted at the right height.

Finger scan

From experience, the best fingers to use are as follows:

1. Middle finger, 2. Index finger, 3. Ring finger.

The thumb and the little finger should not be used. Each person will have fingers that are more or less suitable for scanning. It is a good idea to use the hand you write with (right-handed/left-handed), as you will have more feeling in this hand. You should choose a clean finger without any cuts or grazes. If your finger has very few lines due to abrasion or for genetic reasons, it will not be detected by the sensor. Clearly visible lines will make it easier to recognize.

Children should use their index finger or whichever finger they instinctively choose to use. Use the fingers that are most comfortable for you and those that are recognized the quickest.

The sensor is the narrow strip across the bottom part of the finger swipe area. You must swipe the front phalanx fully over the sensor in order to achieve optimal results. The sensor must not be subjected to any mechanical stress other than operation with a finger and clearing with a soft cloth.

Do not scratch the sensor

with your fingernail. Never

clean the sensor with the

rough side of a sponge or with any aggressive cleaning agents. Damaged sensors must be replaced.

Type Minimum mounting height, _{lower edge}

WM (wall-mounted) 135 cm OM (outlet-mounted) 155 cm IN (integra) 155 cm Recommended finger surface

Congratulations on purchasing your ekey product!

Your finger is now also your key! These little tips and tricks will help you to make the best possible use of your ekey finger scanners.

(26)

The amount of pressure required will vary according to your skin type. Soft skin will require less pressure, dry skin will require more. Test a few different methods to see how you can achieve the best possible scan results for you. To begin with, the finger swipe technique takes a bit of practice. You will soon learn the best way to operate the scanner.

fingers, skin cream or sweat after sport) or when operated under unfavorable conditions.

Children's fingers: Children's fingers generally work from around school age. Using the multiple storage option described above, however, it is sometimes possible to enroll younger children's fingers too. The specified mounting height for IN 2.0, WM 2.0 and OM must be observed in order to ensure correct operation. If, when you swipe your finger over the sensor, the LEDs immediately turn red for a short period without flashing yellow first, this indicates that you have swiped your finger incorrectly or you have waited too long. You must swipe your finger downwards as soon as you place it on the sensor. The software interrupts the scan process and this is indicated by the LEDs briefly lighting up red.

Support

Enrolling fingers and using the scanner is usually a straightforward process. However, if this information does not help you, please contact us:

(27)

Terminal configuration

(28)

(29)

(30)

(31)

(32)

(33)

(34)

(35)

(36)

ekey lock measuring gauge:

Cut out the measuring gauge and read off the required cylinder length.

Cylinder length A

(outside) Cylinder length B(inside)

2. Read off the required length of the cylinder on both sides.

Attention: A is the outside measurement! 3. Add the fittings to the calculation and round

up to the nearest 5 mm.

Attention: Both knobs must have a little room to move.

+

(37)

(38)

Subject to optical and technical modifications, an

Austria (headquarters) ekey biometric systems GmbH Lunzerstraße 89

A-4030 Linz

Phone: +43 732 890 500 2000 [email protected]
