Full text

(1)

www.exor-rd.com

(2)

© 2014 Exor International - All rights reserved 2

04/04/2014 2

04/04/2014

Germany

USA

Italy

India

Switzerland

(3)

© 2014 Exor International - All rights reserved 3 04/04/2014

eTOP Series 500

The ideal choice for all demanding HMI applications

• High-performance touchscreen HMI‘s

• Solid with die-cast housing

• Brilliant displays with LED backlight

• ARM Cortex A8 CPU, 600MHz and 1GHz

• Enhanced storage capabilities with USB and SD card slot

• Dual Ethernet port with switch

• Optional Plug-in modules

(4)

© 2014 Exor International - All rights reserved 4 04/04/2014

Series 500 Technical Data

4 04/04/2014

504 506 507 510 512 513 515

Display 4.3’’

Wide 5.7’’ Wide 7’’ 10.4’’ 12.1’’ 13.3’’ Wide 15’’

Colors 64K colors

Portrait Portrait installation supported

Brightness Brightness regulation to 0%

Ethernet 2 10/100 (switch)

Serial 1 multistandard programmable port

USB 1 Host 2 Host

Plug-in 1 2 2 2 2 2 2

SD 1 SD slot

CPU ARM A8 600MHz ARM A8 1GHz

(5)

© 2014 Exor International - All rights reserved 5

04/04/2014 5

04/04/2014

Series 500 Glass

A solution for outdoor applications and installation in

harsh environments

• Available with 7’’ and 15’’ display

• Projected Capacitive Touchscreen • Sunlight readable

• Extended operating temperature (-20 to +60°C) • IP69K

• DNV

• ATEX 2/22

(6)

© 2014 Exor International - All rights reserved 6 04/04/2014

eTOP507MG

High-performance CPU for demanding applications

• 1GHz ARM A8 CPU, 256MB Flash

• 7’’ widescreen display, 400 cd/m2

• PCAP touchscreen, display bonding, AR treatment

• Sunlight readable

• Glass surface resistant to scratch, chemicals and UV

• Extended operating temperature range -20 to +60°C

• Protection degree IP69K

(7)

© 2014 Exor International - All rights reserved 7 04/04/2014

High-Performance Products

507G 507MG 515G

Display 7’’ Wide 7’’ Wide 15’’

400 Cd/m2 400 Cd/m2 1500 Cd/m2

Colors 64K colors

Portrait Portrait installation supported

Brightness Brightness regulation to 0%

Touchscreen PCAP

Ethernet 2 10/100 (switch)

Serial 1 multistandard programmable port

USB 2 Host

Plug-in 2 2 2

SD 1 SD slot

CPU ARM A8 600MHz ARM A8 1GHz

(8)

© 2014 Exor International - All rights reserved 8 04/04/2014

HMI & Control

Optimal integration for compact control

systems

Expanding the power of the HMI by embedding a fast and efficient PLC (and I/O’s) into a

single, integrated system.

Support for local and remote I/O including CANopen and Ethernet I/O.

(9)

© 2014 Exor International - All rights reserved 9 04/04/2014

Extendability through Modularity: Plug-in Modules

9 04/04/2014

Compact I/O

Communication

Multifunction I/O

Communication

Compact I/O

Combination of modules optimize system price/performance and functionality. Modules are mechanically very compact, with up to 4 modules per panel.

The Digital I/O module can be used without the internal PLC by mapping Inputs and Outputs to system variables.

(10)

© 2014 Exor International - All rights reserved 10 04/04/2014

CODESYS V3 for JMobile

• CODESYS V3 runtime will be available as an optional feature for eTOP Series 500 products.

• Online license activation procedure. Does not require hardware as for CODESYS V2

• Integrates 3S CANopen stack and 3S Modbus/TCP protocols (client/server)

• Fully compatible with PLCM01, PLIO03, PLIO06

• Communication with Jmobile is based on the existing CoDeSys 3 ETH protocol. Symbol import is already available.

(11)

© 2014 Exor International - All rights reserved 11 04/04/2014

Ultra-compact Handheld Terminal

by

Wired and wireless handheld provides high performance solutions for automation

systems.

(12)

eTOP Series 600

True glass HMI. More comfort from a natural user interface .

• PCAP true glass touchscreen

• Ready for multitouch/gesture interfaces.

• Optimal optical performance

• Ruggedized front surface

• Superior aesthetic design

• Widescreen displays in all products

• Wide operating temperature range

• Low Power Consumption

• High reliability from industrial grade components

• Modular System design

• Scalable in performance - optional PC Module

12

(13)

eTOP Series 600

13 04/04/2014

eTOP605 eTOP607 eTOP610 eTOP615 eTOP621

Size 5“ wide 7” wide 10,1“ wide 15,6“ wide 21,5“ wide

Backlight LED, 200 cd/m2 LED, 300 cd/m2 LED, 300 cd/m2 LED, 300 cd/m2 LED, 300 cd/m2 Resolution 800x480 pixel (WVGA) 800x480 pixel (WVGA) 1280x800 pixel (WXGA) 1366x768 pixel (WVXGA) 1920x1080 (Full HD)

Colors 64K 64K 64K 64K 16M

Touchscreen PCAP PCAP PCAP PCAP PCAP

Front Glass Glass Glass Glass Glass

Processor ARM Cortex-A8

ARM Cortex-A8 ARM Cortex-A8 Dual-core ARM Cortex-A9 ARM Cortex-A8 or Dual-core ARM Cortex-A9 PC Module

option - - - Intel ATOM BayTrail PC Module Intel ATOM BayTrail PC Module

OS WInCE 6.0 R3 WInCE 6.0 R3 WInCE 6.0 R3 WinCE 6.0 R3 or Win7/8

or Linux Win7/8 or Linux TCP/IP 2 Ethernet ports 2 Ethernet ports 2 Ethernet ports 2 Ethernet ports (TBC) 2 Ethernet ports (TBC) USB 1 USB Host ports 2 USB Host ports 2 USB Host ports 2 USB Host ports (TBC) 2 USB Host ports (TBC)

SD SD Card Slot SD Card Slot SD Card Slot SD Card Slot SD Card Slot

Serial 1 RS-232/422/485 1 RS-232/422/485 1 RS-232/422/485 1 RS-232/422/485 1 RS-232/422/485 Certification CE, DNV, cULus CE, DNV, cULus CE, DNV, cULus CE, DNV, cULus CE, DNV, cULus

(14)

Modular and Scalable Architecture – an Overview

14

(15)
(16)

© 2014 Exor International - All rights reserved 16 04/04/2014

Jmobile V1.90

Complete HMI Software Solution

Suite of software components that provides a complete solution for connecting equipment and visualizing data.

• Programming Software

• Multiplatform run-time

• Communication drivers

• PC based Client Application

(17)

JMobile V1.90

• Advanced Graphics and Animations

• Full vector graphics with complete dynamic object properties support

• Templates and Dialog pages

• Online and Offline Simulation

• Print reports, alarms and events from the runtime. Printing to PDF files is included

• Advanced Data transfer interface

• Media Player (products with 1 GHz CPU or Win32)

• PDF Viewer

• IP video with streaming HTTP/MJPEG support

• Scatter diagram/XY graph presentation

• Scripting language (JavaScript)

• Screensaver

• Widget browser with HTML5 capability

© 2014 Exor International - All rights reserved 17

(18)

JMobile V1.90

© 2014 Exor International - All rights reserved 18

(19)

JMobile V1.90 JM4web

With JM4web you can have immediate and easy Web access to Jmobile applications based on the Web server included in all JMobile runtime systems.

We use the same drag and drop interface to create web pages, no need to write code. JMobile Studio generates the web version of the application with one click and you can

immediately access the screens using any HTML5-capable browser. No apps are needed when operating from mobile devices!

© 2014 Exor International - All rights reserved 19

(20)

JMobile V1.90 – Available Protocols

Number of available protocols for JMobile is constantly increasing.

© 2014 Exor International - All rights reserved 20

04/04/2014

A-B DF1 GE Intelligent Platforms SRTP Modbus TCP Server

A-B DH-485 Hitachi ETH NMEA 0183

A-B ENET Hitachi SER Omron FINS ETH

BACnet Jetter Ext ETH Omron FINS SER

Baldor NextMove Keyence KV Panasonic FP

Beckhoff ADS KNX TP ProConOS ETH

CANopen HMI Koyo DL Profibus DP

CODESYS V2 ETH Lenze CANopen Profibus DP S7

CODESYS V3 ETH Mitsubishi FX ETH SAIA Ethernet

CT Modbus CMP ETH Mitsubishi FX SER SAIA S-BUS

Ethernet/IP CIP Mitsubishi Q/L ETH Simatic S7 ETH

Fatek FACON ETH Modbus RTU Simatic S7 MPI

Fatek FACON SER Modbus RTU Server Simatic S7 PPI

(21)

Tag Import from A-B, CoDeSys ...

© 2014 Exor International - All rights reserved 21

(22)

Data Transfers

• The HMI panel becomes a data gateway providing better system integration

• Move data between different controllers in a fully programmable way

• Bi-directional transfers can be programmed

• Data transfers are executed on COV or based on a trigger condition

© 2014 Exor International - All rights reserved 22

(23)

www.exor-rd.com

www.exor-rd.com

www.jmobile.net
