DIGI-TOUCH Color Touch Screen Controller

Download (0)

Full text

(1)
(2)

The DIGI-TOUCH Color Touch Screen Controller is built around a high performance core with integrated functionality. This core allows the DIGI-TOUCH to perform many of the normal features of the paradigm range touch screen controllers while improving and adding new features. The DIGI-TOUCH allows a user to easily view and access information through the 5.7”(145 mm) touch screen and through Internet Explorer using a PC. In addition the DIGI-TOUCH features USB for fast downloads and access to trending and Data Logging information. The DIGI-TOUCH is a web enabled controller and allows remote access using the internet through the Ethernet port.

Specification:

• 5.7”(145 mm) Ultra-STN Passive Matrix Resistive Analog Touch screen • 256 Color QVGA 320 X 240 pixel LCD

• Brightness of 165 cd/m2 and backlight 20,000 HR TYP.

• Pt-100 RTD Class A sensor used for dry bulb and wet bulb readings. • Display of temperature in OC and Humidity in %RH.

(3)

•Three front panel LED indicators.

•Power unit from 24VDC ±20% supply.

• Lithium coin type CR2025 Battery back up.

• Steel rear metal enclosure with NEMA 4X/IP66 aluminum front plate for indoor use only.

Features:

• Instant profile preview of set value

and process value. • Security settings for user level rights.

• SMS (Optional)

• Diagnostics History for complete event log.

(4)

•Operation modes with Quick program options. Hot, Cold and Break Starts for power

resumption options. Delay start and program links for flexible programming options.

•Process Mimic indicating the components and the status.

•Internet access of controller using Internet explorer from any location. (Internet connection with Static IP to be provided)

(5)

Certifications and Compliances:

• UL Recognized Component, File #E179259, UL61010-1, CSA 22.2 No.61010-1 Recognized to U.S. and Canadian requirements under the Component Recognition Program of Underwriters Laboratories, Inc. • UL Recognized Component, File #E211967, UL61010-1, CSA 22.2 No.61010-1 CSA 22.2 No. 213-M1987 LISTED by Und. Lab. Inc. to U.S. and Canadian safety standards

• Type 4X Enclosure Rating Face only UL50

• IECEE CB Scheme Test certificate #US/9737A/UL

• IEC 61010-1, EN 610101-1: Safety requirements for electrical equipment and measurement control, and laboratory use Part 1.

• IP66 Enclosure rating (Face Only) IEC 529.

• Emissions and immunity to EN 61326: Electrical equipment for measurement control and Laboratory use.

• Electro Static Discharge – EN 61000-4-2 Criterion A 4kV contact discharge 8kV air discharge.

• Electro Magnetic RF Fields – EN 61000-4-3 Criterion A 10V/m.

• Fast transients (Burst) – EN 61000-4-4 Criterion A 2kV power 1kV signal. • Surge – EN 61000-4-5 Criterion A 1kV L-L 2kV L&N-E power.

• RF conducted interference – EN 61000-4-6 Criterion A 3 V/rms. Emissions EN55011 Class A

(6)
