Dimensions for Non-Metallic Flat Gaskets

to EN 1514-1 to suit EN 1092 Flanges

Ring Gasket

Full Face Gaskets

10mm 39 18 75 18 50 11 4 15mm 44 22 80 22 55 11 4 20mm 54 27 90 27 65 11 4 25mm 64 34 100 34 75 11 4 32mm 76 43 120 43 90 14 4 40mm 86 49 130 49 100 14 4 50mm 96 61 140 61 110 14 4 65mm 116 77 160 77 130 14 4 80mm 132 89 190 89 150 18 4 100mm 152 115 210 115 170 18 4 125mm 182 141 240 141 200 18 8 150mm 207 169 265 169 225 18 8 200mm 262 220 320 220 280 18 8 250mm 317 273 375 273 335 18 12 300mm 373 324 440 324 395 22 12 350mm 423 356 490 356 445 22 12 400mm 473 407 540 407 495 22 16 450mm 528 458 595 458 550 22 16 500mm 578 508 645 508 600 22 20 600mm 679 610 755 610 705 26 20 700mm 784 712 - - - - -800mm 890 813 - - - - -900mm 990 915 - - - - -1000mm 1090 1016 - - - - -1200mm 1307 1220 - - - - -1400mm 1524 1420 - - - - -1600mm 1724 1620 - - - - -1800mm 1931 1820 - - - - -2000mm 2138 2020 - - - - -2200mm 2348 2220 - - - - -2400mm 2558 2420 - - - - -2600mm 2762 2620 - - - - -2800mm 2972 2820 - - - - -3000mm 3172 3020 - - - - -3200mm 3382 3220 - - - - -3400mm 3592 3420 - - - - -3600 3804 3620 - - - -

-Nominal

Bore

Flat Ring

OD

Flat Ring

ID

Full Face

OD

Full Face

ID

Full Face

PCD

Bolt Hole

Diameter

Number of

Bolt Holes

®

(2)

Dimensions for Non-Metallic Flat Gaskets

to EN 1514-1 to suit EN 1092 Flanges

Ring Gasket

Full Face Gaskets

10mm 46 18 90 18 60 14 4 15mm 51 22 95 22 65 14 4 20mm 61 27 105 27 75 14 4 25mm 71 34 115 34 85 14 4 32mm 82 43 140 43 100 18 4 40mm 92 49 150 49 110 18 4 50mm 107 61 165 61 125 18 4 65mm 127 77 185 77 145 18 8 80mm 142 89 200 89 160 18 8 100mm 168 115 235 115 190 22 8 125mm 194 141 270 141 220 26 8 150mm 218 169 285 169 240 22 8 200mm 273 220 340 220 295 22 12 250mm 328 273 395 273 350 22 12 300mm 378 324 445 324 400 22 12 350mm 438 356 505 356 460 22 16 400mm 489 407 565 407 515 26 16 450mm 539 458 615 458 565 26 20 500mm 594 508 670 508 620 26 20 600mm 695 610 780 610 725 30 20 700mm 810 712 895 712 840 30 24 800mm 917 813 1015 813 950 33 24 900mm 1017 915 1115 915 1050 33 28 1000mm 1124 1016 1230 1016 1160 36 28 1100mm 1231 1220 1340 1220 1270 39 32 1200mm 1341 1420 1455 1420 1380 39 32 1400mm 1548 1620 1675 1620 1590 42 36 1500mm 1658 1820 1785 1820 1700 42 36 1600mm 1772 2020 1915 2020 1820 48 40 1800mm 1972 2220 2115 2220 2020 48 44 2000mm 2182 2420 2325 2420 2230 48 48 2200 2384 2620 - - - -

-Nominal

Bore

Flat Ring

OD

Flat Ring

ID

Full Face

OD

Full Face

ID

Full Face

PCD

Bolt Hole

Diameter

Number of

Bolt Holes

®

(3)

Dimensions for Non-Metallic Flat Gaskets

to EN 1514-1 to suit EN 1092 Flanges

Ring Gasket

Full Face Gaskets

10mm 46 18 90 18 60 14 4 15mm 51 22 95 22 65 14 4 20mm 61 27 105 27 75 14 4 25mm 71 34 115 34 85 14 4 32mm 82 43 140 43 100 18 4 40mm 92 49 150 49 110 18 4 50mm 107 61 165 61 125 18 4 65mm 127 77 185 77 145 18 8 80mm 142 89 200 89 160 18 8 100mm 162 115 220 115 180 18 8 125mm 192 141 250 141 210 18 8 150mm 218 169 285 169 240 22 8 200mm 273 220 340 220 295 22 12 250mm 329 274 405 274 355 26 12 300mm 384 324 460 325 410 26 12 350mm 444 356 520 356 470 26 16 400mm 495 407 580 407 525 30 16 450mm 555 458 640 458 585 30 20 500mm 617 508 715 508 650 33 20 600mm 734 610 840 610 770 36 20 700mm 804 712 910 712 840 36 24 800mm 911 813 1025 813 950 39 24 900mm 1011 915 1125 915 1050 39 28 1000mm 1128 1016 1255 1016 1170 42 28 1100mm 1228 1120 1355 1120 1270 42 32 1200mm 1324 1220 1485 1220 1390 48 32 1400mm 1542 1420 1685 1420 1590 48 36 1500mm 1654 1520 1820 1520 1710 56 36 1600mm 1764 1620 1930 1620 1820 56 40 1800mm 1964 1820 2130 1820 2020 56 44 2000mm 2168 2020 2345 2020 2230 62 48

Nominal

Bore

Flat Ring

OD

Flat Ring

ID

Full Face

OD

Full Face

ID

Full Face

PCD

Bolt Hole

Diameter

Number of

Bolt Holes

®

(4)

Dimensions for Non-Metallic Flat Gaskets

to EN 1514-1 to suit EN 1092 Flanges

Ring Gasket

Full Face Gaskets

10mm 46 18 90 18 60 14 4 15mm 51 22 95 22 65 14 4 20mm 61 27 105 27 75 14 4 25mm 71 34 115 34 85 14 4 32mm 82 43 140 43 100 18 4 40mm 92 49 150 49 110 18 4 50mm 107 61 165 61 125 18 4 65mm 127 77 185 77 145 18 8 80mm 142 89 200 89 160 18 8 100mm 168 115 235 115 190 22 8 125mm 195 141 270 141 220 26 8 150mm 224 169 300 169 250 26 8 200mm 284 220 360 220 310 26 12 250mm 340 274 425 274 370 30 12 300mm 400 324 485 324 430 30 16 350mm 457 356 555 356 490 33 16 400mm 514 407 620 407 550 36 16 450mm 564 458 670 458 600 36 20 500mm 624 508 730 508 660 36 20 600mm 731 610 845 610 770 39 20 700mm 833 712 960 712 875 42 24 800mm 942 813 1085 813 990 48 24 900mm 1042 915 1185 915 1090 48 28 1000mm 1154 1016 1320 1016 1210 56 28 1100mm 1254 1120 1420 1120 1310 56 32 1200mm 1364 1220 1530 1220 1420 56 32 1400mm 1578 1420 1755 1420 1640 62 36 1500mm 1688 1520 1865 1520 1750 62 36 1600mm 1798 1620 1975 1620 1860 62 40 1800mm 2000 1820 2195 1820 2070 70 44 2000mm 2230 2020 2425 2020 2300 70 48

Nominal

Bore

Flat Ring

OD

Flat Ring

ID

Full Face

OD

Full Face

ID

Full Face

PCD

Bolt Hole

Diameter

Number of

Bolt Holes

®

(5)

Dimensions for Non-Metallic Flat Gaskets

to EN 1514-1 to suit EN 1092 Flanges

Ring Gasket

Full Face Gaskets

10mm 46 18 90 18 60 14 4 15mm 51 22 95 22 65 14 4 20mm 61 27 105 27 75 14 4 25mm 71 34 115 34 85 14 4 32mm 82 43 140 43 100 18 4 40mm 92 49 150 49 110 18 4 50mm 107 61 165 61 125 18 4 65mm 127 77 185 77 145 18 8 80mm 142 89 200 89 160 18 8 100mm 168 115 235 115 190 22 8 125mm 195 141 270 141 220 26 8 150mm 224 169 300 169 250 26 8 200mm 290 220 375 220 320 30 12 250mm 352 273 450 273 385 33 12 300mm 417 324 515 324 450 33 16 350mm 474 356 580 356 510 36 16 400mm 546 407 660 407 585 39 16 450mm 571 458 685 458 610 39 20 500mm 628 508 755 508 670 42 20 600mm 747 610 890 610 795 48 20

Nominal

Bore

Flat Ring

OD

Flat Ring

ID

Full Face

OD

Full Face

ID

Full Face

PCD

Bolt Hole

Diameter

Number of

Bolt Holes

®
