(1)Single RAN Course Code: LT1203. Duration: 2 days. Technical Level: 2. LTE courses include: LTE. Engineering Overview. LTE. Evolved Packet Core Network. LTE. Air Interface. LTE. Radio Access Network. Cell. Planning for LTE Networks. LTE. Parameters and Tuning. LTE. Voice Options and Operations. LTE. Technologies, Services and Markets. 4G. Air Interface Technologies. www.wraycastle.com.

(2)

(3) SINGLE RAN. First published 2012 WRAY CASTLE LIMITED BRIDGE MILLS STRAMONGATE KENDAL LA9 4UB UK. Yours to have and to hold but not to copy The manual you are reading is protected by copyright law. This means that Wray Castle Limited could take you and your employer to court and claim heavy legal damages. Apart from fair dealing for the purposes of research or private study, as permitted under the Copyright, Designs and Patents Act 1988, this manual may only be reproduced or transmitted in any form or by any means with the prior permission in writing of Wray Castle Limited. All of our paper is sourced from FSC (Forest Stewardship Council) approved suppliers. © Wray Castle Limited.

(4) Single RAN. ii. © Wray Castle Limited. LT1203/v1.1.

(5) SINGLE RAN. CONTENTS Section 1. Single RAN Concepts. Section 2. Multi-Standard Cell Sites. Section 3. Single RAN Backhaul. Section 4. Core Networks. Section 5. Single RAN Implementation. LT1203/v1.1. © Wray Castle Limited. iii.

(6) Single RAN. iv. © Wray Castle Limited. LT1203/v1.1.

(7) Single RAN. SECTION 1. SINGLE RAN CONCEPTS. LT1203/v1.1. © Wray Castle Limited. 1.i.

(8) Single RAN. 1.ii. © Wray Castle Limited. LT1203/v1.1.

(9) Single RAN Concepts. CONTENTS Defining the Single RAN . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.1 3GPP Evolution . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.2 Multi-RAT Single RAN . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.3 Multi-Operator Single RAN . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.4 Multi-RAT, Multi-Operator Single RAN . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.5 Core Network Sharing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.6 Potential Benefits of Single RAN Implementation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.7 Potential Dangers of Single RAN Implementation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.8. LT1203/v1.1. © Wray Castle Limited. 1.iii.

(10) Single RAN. 1.iv. © Wray Castle Limited. LT1203/v1.1.

(11) Single RAN Concepts. OBJECTIVES At the end of this section you will be able to: ■■. define the term ‘Single RAN’ in a generally accepted way. ■■. identify the key aspects of the evolution of 3GPP networks that have facilitated the development of Single RAN techniques. ■■. describe the main features of the Multi-RAT and Multi-Operator Single RAN concepts. ■■. outline ways in which core network resources may be shared in Multi-Operator environments. ■■. identify some of the potential benefits and dangers attendant upon the deployment of a Single RAN solution. LT1203/v1.1. © Wray Castle Limited. 1.v.

(12) Single RAN. 1.vi. © Wray Castle Limited. LT1203/v1.1.

(13) Single RAN Concepts. Defining the Single RAN The term ‘Single RAN’ is one that has several interpretations. For many, the Single RAN concept provides a blueprint for multi-RAT (Radio Access Technology) access networks in which 2G, 3G and 4G cells and services are combined into a single access solution, with user equipment free to make use of 2G GERAN (GSM EDGE Radio Access Network), 3G UTRAN (UMTS Terrestrial Radio Access Network) and 4G E-UTRAN (Evolved UTRAN) connectivity as need and coverage dictates. Multi-RAT single RAN services are often implemented by deploying ‘multi-standard’ base stations, which are capable of generating 2G, 3G and 4G cells simultaneously from a single base station node. Other terms often used to describe this concept are Multi-Standard RAN, Multi-Generation RAN and Combined RAN. An extension of the ‘multi-RAT’ version of the Single RAN concept sees the combination of both fixed and mobile broadband services into one coherent access environment. An operator may therefore use the Single RAN concept as a way of converging their legacy fixed and mobile broadband access networks to support a UC (Unified Communications) service. The term is sometimes used in association with some form of network sharing agreement between operators. The concatenation of the ‘multi-RAT’ and ‘multi-operator’ concepts in the Single RAN environment most often occurs when network operators seek to undertake a rollout of new multi-standard base stations as part of the process of implementing a network sharing arrangement with a partner operator. Most equipment vendors use the term Single RAN to refer to their multi-standard RAN products – Huawei, for example, have a SingleRAN product range, NSN (Nokia Siemens Networks) have a product range called Single RAN Advanced and Ericsson has a product range named Evo RAN, all of which offer multi-standard (GSM, WCDMA, LTE) base stations and associated equipment. The ‘multi-RAT’ definition of the term Single RAN will be discussed in this course.. Further Reading: Huawei SingleRAN: http://www.huawei.com/en/products/radio-access/signleran/index.htm Ericsson Evo RAN: hugin.info/1061/R/1290464/291045.pdf NSN: http://www.nokiasiemensnetworks.com/portfolio/products/mobile-broadband/single-ran-advanced. LT1203/v1.1. © Wray Castle Limited. 1.1.

(14) Single RAN. 3GPP Evolution A high level view of the generic architecture of 2G GSM/GPRS/EDGE, 3G UMTS/HSPA and 4G LTE networks is shown in the diagram to highlight the differences and similarities between the three generations of network. 2G GSM/GPRS networks consist of a GERAN access component connected to separate CS (Circuit Switched) and PS (Packet Switched) core networks. GERAN RRM (Radio Resource Management) functions are performed by the BSC (Base Station Controller), each of which coordinates the activities of numerous base stations. The air interface technique employed by GSM/GPRS/EDGE networks was TDMA (Time Division Multiple Access), which supported low numbers of users per channel and offered limited data rates. Transmission and connectivity in GSM/GPRS networks is based on a mix of TDM (Time Division Multiplexing) and IP-based bearers. A similar architectural model was followed when designing 3G UMTS/HSPA networks. In these, user connectivity to the CS and PS core networks is provided via the UTRAN, in which RRM functionality is managed by an RNC (Radio Network Controller). The UMTS air interface was based on WCDMA (Wideband Code Division Multiple Access), which offers high capacity and high user data rates, and inter-node connectivity is based on a mix of ATM (Asynchronous Transfer Mode) and IP links. LTE networks, by contrast, employ a ‘flatter’ more simplified architecture. The LTE E-UTRAN (Evolved UTRAN) access network consists of only the eNB (E-UTRAN Node B) base stations and the backhaul links that connect them to the core network, there is no equivalent of the BSC or RNC controller node. This flatter architecture is designed to offer far lower latency levels for both user traffic and signalling, as there are fewer devices on the path between the user terminal and the data’s destination. The LTE EPC (Evolved Packet Core) is an all IP environment and does not support or replicate the functionality of the legacy CS core. CS-type services, such as voice or video calling, can be provided by a legacy CS core or via an IMS (IP Multimedia Subsystem). The LTE air interface is based on OFDMA, which can offer very high capacity and very high user data rates. All inter-node network connectivity is based on IP.. Further Reading: www.3gpp.org/Tutorials. 1.2. © Wray Castle Limited. LT1203/v1.1.

(15) Single RAN Concepts. Multi-RAT Single RAN As cellular services have evolved many operators have found themselves in a position where they have several generations of radio access network technologies deployed and in use simultaneously. Traditionally, each RAT required its own bespoke access solution, leading to networks often deploying separate 2G GSM/EDGE, 3G UMTS/HSPA and 4G LTE/LTE-Advanced base stations to the same sites. A number of recent developments have allowed equipment vendors to release multi-standard base stations, which are capable of generating 2G, 3G and 4G cells simultaneously, offering operators the opportunity to replace multiple separate base stations per site with a single, combined node. The main advances that have led to this include: Common base station design initiatives, such as OBSAI (Open Base Station Architecture Initiative) and CPRI (Common Public Radio Interface), which have produced a homogeneous set of functional blocks and internal interfaces for base stations irrespective of whether those nodes support 2G, 3G or 4G transmission. SDR (Software Defined Radio) techniques have been developed which move much of the bespoke radio signal processing effort undertaken by a base station away from technology-specific hardware units and onto standard DSP (Digital Signal Processing) chips. The difference between a base station generating a GSM signal and one generating WCDMA is now largely a matter of software and configuration rather than of hardware capabilities. The speed and capabilities of the processor and DSP chips employed in modern base station nodes allow each device to undertake a wider and more complex set of duties than traditional single-RAT nodes would have been capable of. Packet-based backhaul technologies, typically based on IP (Internet Protocol) and/or Ethernet have been deployed which are capable of carrying traffic for multiple radio access types, have largely replaced the specific backhaul technologies (E1/T1 TDM and ATM) employed by legacy 2G and 3G deployments 3GPP began specifying the radio characteristics of MSR (Multi-Standard Radio) devices such as base stations in the 37 series of specifications, published from Release 9 onwards.. Further Reading: http://www.3gpp.org/ftp/Specs/html-info/37-series.htm . LT1203/v1.1. © Wray Castle Limited. 1.3.

(16) Single RAN. Multi-Operator Single RAN The less-commonly encountered definition of Single RAN relates to the sharing of a radio access environment between two or more operators. Other terms more commonly employed to describe this scenario include RAN Sharing and MORAN (Multi-Operator RAN). In a multi-operator environment RAN and/or core network elements may be shared in a variety of methods. The simplest forms of RAN sharing involve sharing cell site locations and possibly cell site infrastructure, such as power feeds, towers and even backhaul connections. More complex forms of RAN sharing involve the use of combined base stations, which can be used to serve customers of the partnered networks. Shared base stations may operate in a ‘separate frequency’ manner, in which separate cells are generated per operator, or in a ‘shared frequency’ manner, in which the partnered operators share the same cells and frequencies. Site sharing schemes are often described as being ‘passive’ or ‘active’. In a passive sharing scheme, each operator maintains their own base station elements - radio units, power amplifiers, signal processors – but share key site infrastructure and may even share base station enclosures. In an active sharing scheme operators share sites, infrastructure and key base station elements such as signal processors, radio units and even radio frequencies.. 1.4. © Wray Castle Limited. LT1203/v1.1.

(17) Single RAN Concepts. Multi-RAT, Multi-Operator Single RAN One of the reasons why there are two definitions of the term ‘Single RAN’ in use is that many networks encounter the concept as part of a combined RAN consolidation and RAN sharing process. In these situations partnered networks have elected to combine the process of deploying a single RAN (multi-RAT base station) solution with the implementation of a RAN or network sharing agreement with each other. In such a multi-RAT, multi-operator scenario, newly deployed multi-RAT base stations could be configured to serve multiple operators (via either separate or shared core networks), leading to a shared Single RAN. GSM, UMTS and LTE all have schemes that allow for RAN sharing by multiple (up to 6) operators.. Further Reading: 3GPP TS 23.236. LT1203/v1.1. © Wray Castle Limited. 1.5.

(18) Single RAN. Core Network Sharing RAN sharing can be associated with two different kinds of core network sharing, known as MOCN (MultiOperator Core Networks) and GWCN (Gateway Core Networks). In MOCN configurations, the shared RAN nodes – sharing is implemented at the BSC level in the GERAN, the RNC level in the UTRAN and the eNB level in the EUTRAN – are connected to fully separate core networks. Supporting UEs (e.g. UEs (User Equipment) that support the additional control mechanisms) would perform PLMN (Public Land Mobile Network) Selection on Attach and the Iu/S1-flex function performed by the RAN node would select an MSC-S/SGSN/MME (Mobile-services Switching Centre Server/ Serving GPRS Support Node/ Mobility Management Entity) in the chosen PLMN to forward Attach Requests on to. Non-supporting UEs will function using legacy techniques but may be redirected to a different core network element once they have Attached to the network. In GWCN configurations, the shared RAN nodes are connected to a set of shared MSC-S/SGSN/MMEs, which in turn connect to a set of separate core networks. Supporting UEs would again perform PLMN selection but the RAN node would perform Iu/S1-flex functions towards a single, combined set of MSC-S/ SGSN/MMEs. The selected core network node would then perform separate core network gateway selection per PLMN and would support interfaces to a different set of HLR/HSS (Home Location Register/ Home Subscriber Server) nodes per PLMN. The diagram illustrates core network sharing arrangements for LTE networks; similar arrangements also exist for legacy CS and PS core networks which allow for MSC Server and SGSN pool sharing.. Further Reading: 3GPP TS 23.251, 23.236 (Iu-Flex), 23.401 (S1-Flex). 1.6. © Wray Castle Limited. LT1203/v1.1.

(19) Single RAN Concepts. Potential Benefits of Single RAN Implementation The potential benefits that can be expected from a Single RAN deployment could include: ■■. ■■. ■■ ■■. ■■. ■■. ■■. ■■. ■■. ■■. simplification – a single RAN is simpler to build than multiple RANs leading to CAPEX (Capital Expenditure) savings organizational savings – a shared network often requires fewer people to run it than separate networks would, leading to rationalizations and OPEX (Operational Expenditure) savings cost savings – combined sites are less expensive to deploy and maintain than separate sites energy saving – a single combined base station can be expected to consume less energy due to the removal of duplication in areas such as processor units and transmission cards coverage improvements – combining multi-RAT resources can lead to better penetration and wider mobile broadband coverage, especially in rural areas, as lower frequency channels become available for 3G and 4G use capacity improvements – combining multi-RAT resources can lead to increases in capacity, especially in urban areas, as 3G and 4G technologies become available in smaller cells spectrum pooling – multi-RAT deployments can pool the operator’s spectrum resources and lead to greater general capacity frequency evolution – operators are able to deploy multi-RAT services into the same MSR bands, allowing base stations to serve multiple RATs in the same frequency band convergence – a Single RAN solution will typically employ a shared, IP-based backhaul network, allowing operators to converge all generations of RAT onto a modern IP basis software simplification – a multi-standard base station can be expected to run from a single, combined software package that supports the functionality of all RATs, therefore reducing the development, testing and deployment load associated with software updates. Each Single RAN deployment can be expected to be different, as different operators will be starting from their own specific architectures and will build their environment to meet their specific requirements, meaning that each operator might only benefit from a subset of the above mentioned benefits.. LT1203/v1.1. © Wray Castle Limited. 1.7.

(20) Single RAN. Potential Dangers of Single RAN Implementation The potential dangers that should be considered when implementing a Single RAN deployment could include: ■■. ■■. ■■. ■■. introduction of single points of failure into operators’ RAN environments – if a multi-standard base station fails then all cells (and RATs) supported by that site also fail vendor dependency – in the past, when operators have sourced different generations of RAN from different suppliers, they have been able to play vendors off against each other to obtain the best deals. A Single RAN generally means a single supplier, meaning that operators run the risk of becoming dependent upon a single vendor antenna system complexity – depending upon the site configurations that operators select and deploy they may find that the complexity of their cell site antenna systems increases as additional combiners, duplexers and/or splitters are added. increased interference – co-location of transmitters serving different RATs could lead to an increase of interference (from spurious emissions and intermodulation) of each RAT to the others. Each of these potential risks can be mitigated, if managed effectively. In urban areas the overlap created by neighbouring sites may nullify the ‘single point of failure’ risk, whilst effective supplier-management and price benchmarking should overcome the ‘vendor dependency’ issue. The ‘antenna complexity’ risk may only be an issue if a site is being converted from single-RAT to multi-RAT operation and operators may equally find that the configuration of existing multi-RAT sites is simplified by the deployment of Single RAN equipment. 3GPP TS 37.104 contains strict guidelines related to the total amounts of interRAT interference that are permitted, allowing the risk of reduced quality due to interference and intermodulation to exist within predictable boundaries that allow for a reasonable degree of mitigation.. 1.8. © Wray Castle Limited. LT1203/v1.1.

(21) Single RAN. SECTION 2. MULTI-STANDARD CELL SITES. LT1203/v1.1. © Wray Castle Limited. 2.i.


(23) Multi-Standard Cell Sites. CONTENTS Typical Site Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2.1 MSR Base Stations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2.2 GSM Radio Interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2.3 UMTS Radio Interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2.4 LTE Radio Interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2.5 Carrier Aggregation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2.6 Software Defined Radio . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2.7 Multi-Standard Band Sharing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2.8 MSR Band Category 1 (3G/4G) Example . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2.9 MSR Band Category 2 (2G/3G/4G) Example . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2.10 MSR Base Station Architecture . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2.11 OBSAI and CPRI . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2.12 Localized vs Distributed Cell Sites . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2.13 Remote Radio Heads . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2.14 Distributed Cell Site Examples . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2.15 C-RAN . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2.16 Multi-RAT Deployment Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2.17 Infrastructure Sharing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2.18 Base Station Sharing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2.19 MSR Base Station Sharing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2.20 Frequency Band Sharing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2.21 Potential RF Issues . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2.22 Single RAN Architectures . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2.23. LT1203/v1.1. © Wray Castle Limited. 2.iii.


(25) Multi-Standard Cell Sites. OBJECTIVES At the end of this section you will be able to: ■■. highlight the main similarities and differences between traditional cell site configurations and those employed to support Single RAN deployments. ■■. describe the main features of an MSR base station. ■■. outline the main features of the 2G TDMA, 3G WCDMA and 4G OFDMA air interface technologies. ■■. describe the main features of the SDR (Software Defined Radio) concept and its applicability to MSR base stations. ■■. identify the arrangements that have been developed to support multi-standard band sharing in 3GPP networks. ■■. describe the basic architecture of a multi-standard base station. ■■. outline the functionality supported by the OBSAI and CPRI initiatives and identify the role they play in enabling distributed base station architectures. ■■. describe some of the multi-RAT deployment options that exist including techniques that support passive and active base station sharing. ■■. identify some of the potential RF issues that might be associated with MSR operation, including interference and intermodulation. ■■. LT1203/v1.1. describe some basic Single RAN network architectures. © Wray Castle Limited. 2.v.


(27) Multi-Standard Cell Sites. Typical Site Configuration The typical configuration of a legacy ‘single RAT’ base station site is outlined in the diagram. In this model each base station supports just one RAT and can be assumed to be using radio units whose hardware and/or software is dedicated to supporting that single radio technology. A network operator who followed this model but who also wished to deployed multi-RAT services would usually be required to deploy multiple base stations (one per required RAT) to each cell site.. LT1203/v1.1. © Wray Castle Limited. 2.1.

(28) Single RAN. MSR Base Stations 3GPP, in TS 371.04, defines an MSR base station as being a “Base Station characterized by the ability of its receiver and transmitter to process two or more carriers in common active RF (Radio Frequency) components simultaneously in a declared RF bandwidth, where at least one carrier is of a different RAT than the other carrier(s)”. To decode some of the more obscure parts of this definition: ‘common active RF components’ means that signals belonging to two or more RATs (to GSM and UMTS, for example) are being processed or served by the same radio elements simultaneously, this is sometimes described as ‘active sharing’. A ‘declared RF bandwidth’ could be a specific frequency band, like the 1800 MHz band, for example. The example MSR base station depicted in the diagram is simultaneously managing 2G, 3G and 4G cells as part of a Single RAN deployment. Traffic for all RATs/cells shares the same packet-based backhaul connection and is processed by a shared transmission card. Traffic (user plane, control plane and O&M (Operation and Maintenance)) for all RATs/cells is managed by the same shared processor/controller unit. Digital versions of the downlink RF signals to be transmitted in each RAT/cell are created in the same shared DSP unit (even if traffic for each specific RAT and cell is managed by a different logical part of the DSP array). Uplink traffic for all RATs/cells is also processed by the shared DSP resource. When multi-RAT carriers are sharing the same frequency band, the DSP can in theory create a single multi-carrier signal that carries the combined traffic of multiple cells of multiple RATs. Sites that employ different frequency bands for each RAT, or where the bandwidth allocations are in the same band but are widely non-contiguous, may require multiple radio units. Each physical radio sector generated by the site is served by a shared radio unit, which converts the digital versions of the downlink carriers to analogue RF signals, up-converts them to the appropriate band and amplifies them before passing them to the antennas for transmission. The radio units also handle the reception, down conversion and sampling of uplink signals. 3GPP has defined a range of frequency bands that are available for MSR operation in which limited combinations of 2G, 3G and 4G carriers may be transmitted within the same band using MSR techniques.. Further Reading: 3GPP TS 37.104. 2.2. © Wray Castle Limited. LT1203/v1.1.

(29) Multi-Standard Cell Sites. GSM Radio Interface A recap of some of the basic features of the GSM/EDGE air interface is provided in the diagram.. Further Reading: 3GPP TS 45.001. LT1203/v1.1. © Wray Castle Limited. 2.3.

(30) Single RAN. UMTS Radio Interface A recap of some of the basic features of the UMTS/HSPA air interface is provided in the diagram.. Further Reading: 3GPP TS 25 series. 2.4. © Wray Castle Limited. LT1203/v1.1.

(31) Multi-Standard Cell Sites. LTE Radio Interface A recap of some of the basic features of the LTE air interface is provided in the diagram.. Further Reading: 3GPP TS 36 series. LT1203/v1.1. © Wray Castle Limited. 2.5.

(32) Single RAN. Carrier Aggregation CA (Carrier Aggregation) is the most prominent feature of Release 10 LTE-Advanced. It offers an inverse multiplexing facility that allows a UE to substantially increase the overall data rate it can achieve by allowing an eNB to schedule capacity for it on multiple cells (or ‘carriers’) simultaneously. Each carrier (either downlink or uplink) assigned for use by a UE is known as a CC (Component Carrier) and the set of CCs allocated to a UE at any one time forms a Carrier Aggregate. R10 CA permits up to two CCs to be bound into a Carrier Aggregate. However, the specifications will ultimately support five CCs, potentially providing a suitably-equipped UE with up to 100 MHz of bandwidth and an aggregate downlink data rate of over 3 Gbit/s. The lowest level of carrier aggregation allows a UE to connect via just one cell. The radio connectivity of this cell is described as the PCC (Primary Carrier Component) and the cellular service it offers is known as the PCell (Primary Serving Cell). The PCell carries NAS (Non-Access Stratum) and RRC (Radio Resource Control) services for a UE and is also the carrier measured by the UE to support functions such as quality feedback and handover measurements. A Release 8/9 UE (or an R10 UE that didn’t require CA services) would just connect via the PCell and would not be assigned any additional carriers. An R10, CA-capable UE that did require a CA service would be scheduled with capacity on between one and four SCells (Secondary Serving Cells), each of which would be carried by an SCC (Secondary Component Carrier). The PCC and any SCCs aggregated to provide a CA service for a UE must all be under the control of the same eNB, but the terms ‘primary’ and ‘secondary’ used in relation to CA carriers are determined from the point of view of each UE – different UEs in the same area may have selected different cells to be their PCell and may therefore regard an assigned cell as an SCC which may be employed by another UE as a PCC. A PCell is always used in a bidirectional manner, as befits the cell that carries NAS and RRC traffic, but an SCell may be used in either a bidirectional or unidirectional manner depending upon local configuration and current requirements. If an SCell is used unidirectionally then it is only able to operate in ‘downlink-only’ mode, there is no provision for cells to operate in ‘uplink-only’ mode.. 2.6. © Wray Castle Limited. LT1203/v1.1.

(33) Multi-Standard Cell Sites. Software Defined Radio The technical advance that lies at the heart of the Single RAN concept is the emergence of SDR (Software Defined Radio). Traditional HDR (Hardware Defined Radio) systems employed hardware-based techniques to create radio signals and encode data onto them. A GSM base station form the 1990s, for example, would have contained a separate radio unit (usually known as a TRX or transceiver) for each radio carrier managed by the site. The TRX would contain hardware elements that generated a carrier frequency and then performed the specific modulations that allowed the signal to carry digital data. Different designs of TRX would have been required to support different forms of radio signal, so the evolution of a basic GSM base station into one that also supported GPRS or EDGE would have required a new physical TRX to be fitted to the base station. SDR, in contrast, happens in software on a DSP (Digital Signal Processor) and the modulation and signal generation techniques required for a particular radio system are controlled by a bespoke mathematical algorithm. A change in radio techniques would typically require only a change in software. The SDR element in a cellular base station (or ‘baseband’) will accept downlink input in the form of traffic streams arriving from higher layers and will receive uplink input in the form of digital samples of the received radio channel taken by the associated radio unit. DSP functions are usually deployed to pools of FPGA (Field-Programmable Gate Array) elements and each FPGA will manage an instance of the required SDR algorithm for a given carrier. The SDR process will take downlink data and create a virtual, mathematical representation of that data as it passes through the stages of formatting, precoding, modulation, Fourier transform and up-conversion that would have been employed as physical processes in an HDR system. The result, on the downlink, is a stream of complex-valued symbols that can be passed to an RF frequency synthesizer in one of the base station’s radio units that will create a physical analogue signal that matches the virtual description provided by the DSP. The radio unit will also contain the power amplifier, filters and other physical elements required to generate a useable radio signal before passing it on to the antenna system. The uplink process works in reverse, starting with samples taken in the radio unit. In a Single RAN environment, the output of different SDR processes, one for each carrier and each RAT in use, can be summed into a combined signal within the DSP before being passed to a multi-standard radio unit, thus allowing all carriers on a sector to be generated by the same combined process. LT1203/v1.1. © Wray Castle Limited. 2.7.

(34) Single RAN. Multi-Standard Band Sharing 3GPP has laid out the radio transmission and reception for MSR and Multi-Carrier/Multi-RAT base stations in specifications 37.104 and 37.900 respectively. Amongst other technical information, these documents specify the frequency bands that are available for MSR operation, as shown in the diagram. MSR frequency band sharing is only mandated in certain combinations of band and the level of MultiRAT sharing that can be supported is classified into three Band Categories (BC). BC1 specifies the frequency bands that are available for MSR sharing (meaning that the noted combinations of RATs may be simultaneously generated by the same MSR base station) by combined 4G LTE (E-UTRA-FDD (Evolved Universal Terrestrial Radio Access-Frequency Division Duplex)) and 3G UMTS (UTRA (Universal Terrestrial Radio Access)-FDD) base stations. BC2 specifies the frequency bands that are available for MSR sharing by combined 4G LTE (EUTRAFDD), 3G UMTS (UTRA-FDD) and 2G GSM/EDGE base stations. BC3 specifies the sharing options for combined LTE TDD and UMTS TDD base stations, but is not detailed in the diagram. A Single RAN network that combines support for 2G, 3G and 4G services is therefore able to operate in four bands (MSR Bands 2, 3, 5 and 8), which fortunately coincides with the 1900, 1800, 850 and 900 MHz bands in which GSM is typically deployed anyway. This means that the operator would be able, if their licences permitted, to deploy a combination of GSM900, UMTS900 and LTE900, for example, simultaneously from the same MSR base stations.. Further Reading: 3GPP TS 37.104, 37.900. 2.8. © Wray Castle Limited. LT1203/v1.1.

(35) Multi-Standard Cell Sites. MSR Band Category 1 (3G/4G) Example The example in the diagram shows a base station using MSR Band Category 1 to transmit LTE and UMTS cells on adjacent carriers in the 2100 MHz band, which is referred to as MSR Band 1. The LTE cell uses EUTRAN Band 1 and transmits a symmetrical 5 MHz FDD cell that is described using the appropriate EARFCNs. The UMTS cell uses UTRAN Band I and transmits an FDD cell that is described using the appropriate UARFCNs (UMTS Absolute Radio Frequency Channel Numbers). If SDR techniques are employed by the base station it is possible that the different downlink carriers were generated in the same DSP and may, depending upon power output requirements and power amplifier capabilities, be transmitted via the same radio unit and antenna. The total radio bandwidth utilized by the MSR base station is known as the Base Station RF Bandwidth, which is defined in 3GPP TS 37.104 as being ‘the bandwidth in which a Base Station transmits and receives multiple carriers and/or RATs simultaneously’. The bandwidth occupied by the transmitted LTE and UMTS carriers is termed a Sub-Block, which is defined in 37.104 as being ‘… one contiguous allocated block of spectrum for use by the same Base Station. There may be multiple instances of sub-blocks within an RF bandwidth’.. Further Reading: 3GPP TS 25.104, 36.104, 37.104. LT1203/v1.1. © Wray Castle Limited. 2.9.

(36) Single RAN. MSR Band Category 2 (2G/3G/4G) Example In this example, a Single RAN base station is configured to manage 2G, 3G and 4G cells and must therefore utilize Band Category 2 resources in MSR Band 8. The GSM cell uses the GERAN E-GSM (900 MHz) band and transmits an FDD cell that is described using the appropriate ARFCN. The UMTS cell uses UTRAN Band VIII and transmits an FDD cell that is described using the appropriate UARFCNs. The LTE cell uses E-UTRAN Band 8 and transmits a symmetrical 10 MHz FDD cell that is described using the appropriate EARFCNs (E-UTRAN Absolute Radio Frequency Channel Number). The Base Station RF Bandwidth in this case hosts two Sub-Blocks, one that covers a single GERAN carrier and another that covers GERAN, UTRAN and EUTRAN carriers.. Further Reading: 3GPP TS 45.005, 25.104, 36.104, 37.104. 2.10. © Wray Castle Limited. LT1203/v1.1.

(37) Multi-Standard Cell Sites. MSR Base Station Architecture Modern Single RAN base stations typically employ SDR techniques and follow 3GPP MSR guidelines, which allow them to operate in multi-standard, multi-RAT modes. A high-level view of the generic layout of a hypothetical MSR base station is shown in the diagram. The transmission element connects the base station to a shared, packet-based backhaul, which carries traffic for all supported RATs. The central processor/control element maintains signalling connections with the supported access controllers and core networks and routes traffic between backhaul channels and DSP Pools. In this example, a separate DSP instance from the baseband DSP Pool has been assigned to handle each RAT transmitted in each sector, so each sector has one DSP dedicated to handling a GSM cell, another for a UMTS cell and a third for an LTE cell. Each DSP will perform the SDR functions required to take the received user traffic and signalling and turn it into a transmitted downlink signal. The set of downlink signals created for a given radio unit may be summed. They will also take the signals received on the uplink and extract from them the user traffic and signalling to pass on to the appropriate access controller or core network. The links between baseband and radio units carry digital traffic. This consists of complex-valued samples representing the carriers to be transmitted on the TX side and high-rate sample streams describing the received RF signal on the uplink side. Each sector, in this example, requires its own radio unit to manage the physical RF TX and RX functions. On the transmit side the radio unit performs DAC (Digital to Analogue Conversion) and turns the stream of complex-valued data symbols generated by the baseband DSPs into a physical analogue RF signal with the same characteristics. An LPA (Linear Power Amplifier) then boosts the RF signal to the required output power. In this example a single multi-carrier, multi-RAT LPA is employed to amplify all RATs simultaneously before the signal is passed through a TX filter to remove any out-of-band components. On the RX side, the received signal is passed through an RX bandpass filter to limit it to the required bandwidth and is then passed through an LNA (Low Noise Amplifier) which boosts the signal, partly to overcome the loss experienced on its journey from the antenna. The RF receiver and ADC (Analogue to Digital Convertor) receive and sample the incoming RF signal at a very high rate to be passed to the baseband.. LT1203/v1.1. © Wray Castle Limited. 2.11.

(38) Single RAN. OBSAI and CPRI A key feature of SDR-based architectures is that the link between the baseband and the radio units is typically carried by a digital interface, as opposed to the analogue RF interface that would have been used in a legacy base station. In the early 2000s two similar but competing initiatives, known as OBSAI and CPRI, were launched that specified an open-standards architecture for this interface. OBSAI (Open Base Station Architecture Initiative), was an industry-sponsored initiative that sought to define a standardized layout for cellular base stations, with a set of common component modules connected by open interfaces. An OBSAI base station consists of four main modules (Transport, Control & Clocking, Baseband and RF) linked by a set of RP (Reference Point) internal interfaces, with external interfaces that connect to UEs on one side and network controllers on the other. The main objective of OBSAI was to promote a design blueprint for base stations which would provide commonality between different suppliers’ modules, allowing vendors to act more like integrators by assembling base stations from compatible modules provided by a variety of third parties. The backers of the CPRI (Common Public Radio Interface) put forward a more modest architectural model that defined a common interface between an REC (Radio Equipment Controller) and the RE (Radio Equipment). The REC equates to the transport/controller/baseband sections of a base station and the RE is the RF unit. From a deployment point of view, the most useful feature of both OBSAI and CPRI is the digital interface that exists between the baseband and the radio unit. The legacy analogue connections that used to serve this interface imposed limits on the design of base stations, in the sense that, due to the losses associated with analogue transmission, the RF units always had to be located within a few metres of the baseband unit. A digital baseband-RF link can, in theory, be any length the designers want it to be, as long as the digital information is carried over a medium such as optical fibre. Base stations with digital baseband-RF interfaces can be designed in a ‘distributed’ way that allows RRH (Remote Radio Head) RF units to connect to a centralized baseband/control unit across distances of anything up to a few kilometres.. Further Reading: www.obsai.com, www.cpri.info. 2.12. © Wray Castle Limited. LT1203/v1.1.

(39) Multi-Standard Cell Sites. Localized vs Distributed Cell Sites Base stations that follow the OBSAI/CPRI models, or that employ a similar vendor-specific solution, offer network planners two main site design choices that can be described as localized and distributed. A localized design employs traditional antenna connectivity in the form of analogue feeder cables. Typical configurations employ mast head downlink amplifiers, which are commonly abbreviated as MHAs (Mast Head Amplifiers), TMAs (Tower Mounted Amplifiers) or some other vendor-specific acronym and are used to boost the strength of downlink signals to offset some of the losses that signals can expect to experience as they travel down the feeder. Power for an MHA can be fed up the feeder itself by installing a ‘Bias T’ unit at the base station end of the cable. The loss associated with analogue feeders typically limits the maximum distance between the RF units and the antennas to something less than 120 m, even with MHAs. A distributed design makes use of RRH techniques and can greatly extend the maximum distance between base station and antenna. If the digital baseband-RF interface is carried by optical fibre cables (usually the less expensive multimode fibres are used) then the typical maximum distance the antennas can be from the base station goes up to something in the order of 20 km. The main challenges associated with a distributed model relate to the need to provide a local power feed for the RRH units at the antenna site and the difficulties associated with routing an optical fibre cable between the connected nodes.. LT1203/v1.1. © Wray Castle Limited. 2.13.

(40) Single RAN. Remote Radio Heads Different vendors have adopted a variety of designs for their particular RRH units, which may incorporate a range of different elements. Most RRH designs include at least the DAC/ADC elements that allow the digital baseband-RF interface to connect to the analogue RF components and all will incorporate an RF transceiver. Some RRH types include radio up/down conversion elements that position that radio signal into the correct part of the spectrum, although other designs handle this functionality in SDR back in the baseband. The transmitter side of the RRH includes the LPA and TX filter, while the receive side includes the RX filter and LNA. Both sides are typically connected to an RF combiner/diplexer, which allows the RRH to support both main and diverse TX/RX feeder cables, which would be used if the RRH was connected to, for example, a cross-polarized antenna panel. Many cellular antennas have some form of remote tilt control fitted – either electrical downtilt control or motor that allows the antenna to be remotely panned or tilted. This allows the operator to optimize or adjust the orientation of the antenna without sending an engineer to the site. The RRH will typically need to be connected to a local power source.. 2.14. © Wray Castle Limited. LT1203/v1.1.

(41) Multi-Standard Cell Sites. Distributed Cell Site Examples Examples of some of the distributed cell site models made possible by the use of RRH units are shown in the diagram. The first example shows a central base station connected to a set of RRH units that are serving a city centre or a business district. Each antenna site, in this configuration, would typically occupy less space and would require less infrastructure than a traditional base station site would, so the benefits associated with the use of a distributed model would include lower site rental and power costs. The second example shows a central base station and a set of RRHs serving a section of motorway. Each mast along the route creates a traditional three-sector site but uses RRHs to achieve this, meaning that each site does not require a full base station deployment.. LT1203/v1.1. © Wray Castle Limited. 2.15.

(42) Single RAN. C-RAN A further evolution of the distributed base station and Single RAN concepts is provided by the so-called C-RAN – ‘Cloud RAN’ or ‘Centralized RAN’. In this innovation a network operator is able to deploy their base stations at centralized sites, such as core network centres. A fibre-optic DWDM (Dense Wavelength Division Multiplexing) can then be used to distribute CPRI signals to a network of RRH (Remote Radio Heads). Some vendors deploy separate physical base stations at the central site, whereas other vendors specify the use of ‘virtualized’ base stations – base station applications running on virtual servers. The Cloud RAN concept has the potential benefit of further reducing the footprint and power requirements of each cell site, needing only enough space and power to handle the RRH and optical transmission equipment at each site. There can also be large savings made on deployment and maintenance costs, as repairs to base stations would not necessitate the use of field engineers. As the all of the ‘base stations’ (whether physical or virtual) serving an area are co-located at the same site it means that any X2 interfaces between LTE eNBs become low-latency local connections, which could significantly improve handover completion times. The C-RAN concept has been largely driven by China Mobile, with work also undertaken by the NGMN (Next Generation Mobile Network) Alliance.. Further Reading: http://labs.chinamobile.com/cran/wp-content/uploads/C-RAN%20NGMN-GSMA-2012-Feb-Bill-v16(1).pdf (China Mobile) www.ngmn.org/workprogramme/centralisedran.html (NGMN). 2.16. © Wray Castle Limited. LT1203/v1.1.

(43) Multi-Standard Cell Sites. Multi-RAT Deployment Options Multi-RAT operation can be supported in a number of different ways. In what could be termed the ‘traditional’ deployment model, an operator might deploy different RATs at the same or different sites in a way that shares little if any cell site infrastructure between the various base stations – the model shown in the diagram, where the base stations on a site even have their own separate mast can be seen as an exaggerated example of this concept. A more realistic example of separate RAN deployment can be seen in the ‘Site Sharing – infrastructure sharing’ option. In this model an operator would deploy different RATs to a site in separate base stations but would share site resources such as power, BBU (Battery BackUp) and transmission and would also share a single mast between the different services. Infrastructure sharing of this kind may or may not extend to antenna system sharing; in some models each RAT would have its own set of antennas, in others a system of duplexers and splitters would be used to share antennas between RATs. As multi-RAT deployments began to evolve towards the Single RAN model, operators began sharing not only site resources between RATs but even whole base stations. Base station sharing is often categorized into two options; passive and active. In passive sharing a single base station chassis could house equipment dedicated to serving different RATs. Common elements such as power supplies might be shared but radio and baseband elements would all be kept separate. Active sharing methods allow key components such as transmission links, baseband processors and even radio units to be shared between RATs and is very much the deployment model made possible by the adoption of OBSAI/CPRI techniques supported by the use of SDR, RRH units and distributed site architectures.. LT1203/v1.1. © Wray Castle Limited. 2.17.

(44) Single RAN. Infrastructure Sharing The diagram shows an example of passive infrastructure sharing. Separate 2G and 3G base stations have been co-located to a site and some resources are shared, such as site power and transmission. The mast and antennas are also shared, which assumes that the base stations are either sharing the same frequency band or that the antennas are capable of multi-band operation. To reduce the number of feeder cables that need to be run up the tower, the site configuration employs duplexers and/or diplexers at the top and bottom of the feeders. The duplexers/diplexers combine (at one end) and separate (at the other) the RF signals belonging to the two different RATs and allow a single feeder to be shared by both RATs per sector. Duplexers are used to combine/split signals from the same frequency band and diplexers are used to combine/split signals from different frequency bands. More complex arrangements may be required if the 3G base station employs MHA/TMA devices.. 2.18. © Wray Castle Limited. LT1203/v1.1.

(45) Multi-Standard Cell Sites. Base Station Sharing The diagram shows an example of Base Station sharing in which one physical base station has been configured to support two different RATs. The level of integration employed in this example is fairly low, as only some of the base station’s elements are being actively shared by the RATs – the power, transmission, control and baseband elements are shared but each RAT still has its own separate RF unit per sector. Each RAT, in this example, has been deployed in a different frequency band, meaning t hat this could be an example of a single base station supporting separate GSM900 and UMTS2100 operation. Diplexers are still required to support antenna sharing between the RATs.. LT1203/v1.1. © Wray Castle Limited. 2.19.

(46) Single RAN. MSR Base Station Sharing The diagram shows a further example of Base Station sharing but this time one in which one physical base station has been configured to support three different RATs using a combination of separate RAT and MSR radio units. This example is based on the assumption that the operator has deployed LTE in the same band as their existing GSM service – an operator that uses GSM1800 and LTE1800, for example. The 2G and 4G cells can therefore share MSR radio units, whilst the 3G cells (based in this example on UMTS2100) uses a separate single-RAT radio unit. Diplexers are still required to support antenna sharing between the 2G/4G and 3G signals.. 2.20. © Wray Castle Limited. LT1203/v1.1.

(47) Multi-Standard Cell Sites. Frequency Band Sharing In this example the operator has elected to deploy 2G, 3G and 4G cells in the same frequency band and so is able to take advantage of the full range of MSR techniques. A single baseband pool of DSP resources serves all three RATs and the transmitted signals for each sector are generated in a single, shared radio unit per sector. This configuration and real-world configurations like it sit at the heart of the Single RAN solutions being deployed by operators around the world.. LT1203/v1.1. © Wray Castle Limited. 2.21.

(48) Single RAN. Potential RF Issues Multi-RAT deployments, whether they follow traditional co-location models or more recent Single RAN models, all face a similar set of potential RF-related issues. All of these issues relate to the fact that a multi-RAT deployment necessarily entails generating radio signals belonging to different services at the same site or even within the same base station. The set of typical RF issues that may be caused by co-location and base station sharing include: Interference caused by spurious emissions – a spurious emission is any unwanted signal component generated by a transmitter and may include noise introduced by the transmitter, amplifier or antennas system, harmonics of the signal(s) being transmitted and intermodulation products. Harmonics are an unavoidable by-product of the carrier transmission and modulation process and cause peaks of noise to appear at predictable intervals above and below the carrier frequency. Intermodulation occurs when signals of different frequencies are combined, for example in an amplifier or duplexer/diplexer. Intermodulation products cause noise to appear in frequencies above and below the transmitted carriers, like harmonics, but unlike harmonics intermodulation products are less predictable and are therefore more difficult to plan against. Most forms of co-location-related interference can be mitigated by employing appropriate transmit and/or receive filters on the effected units.. Further Reading: http://www.ericsson.com/mx/res/thecompany/docs/publications/ericsson_review/2003/2003024.pdf. 2.22. © Wray Castle Limited. LT1203/v1.1.

(49) Multi-Standard Cell Sites. Single RAN Architectures MSR or Single RAN base stations will logically support the functions of the legacy base stations that they have replaced, so each could perform the functions associated with a GSM BTS (Base Transceiver Station), a UMTS Node B and/or an LTE eNB. These combined base station devices are deployed within a wider combined access network environment. One of the benefits of the MSR/Single RAN approach is that all RATs served by a base station are able to share the same packet-based backhaul connectivity, this usually equates to backhaul connections that carry IP traffic over an Ethernet bearer. The shared backhaul connection will usually be terminated at a SeGW (Security Gateway) which will distribute the separate RATs’ logical interface traffic to the appropriate nodes. GSM A-bis interface traffic will be passed from the SeGW to a BSC and UMTS Iub interface traffic will be passed to an RNC. LTE base stations support two interfaces that are typically carried via backhaul links; S1 interface traffic will be routed from the SeGW to the EPC network, while any X2 interfaces will be routed on to the backhaul connections that lead to the target eNBs. In keeping with the combined nature of the Single RAN base station, many vendors produce combined ‘multi-RAT controller’ platforms that perform the separate logical functions of BSC and RNC nodes within the same physical device. The benefits associated with the use of multi-RAT controller nodes include reduced space requirements (as a single node may be replacing multiple separate nodes), reduced power consumption, reductions in the numbers of transmission cables required and others.. LT1203/v1.1. © Wray Castle Limited. 2.23.

(50) Single RAN. 2.24. © Wray Castle Limited. LT1203/v1.1.

(51) Single RAN. SECTION 3. SINGLE RAN BACKHAUL. LT1203/v1.1. © Wray Castle Limited. 3.i.


(53) Single RAN Backhaul. CONTENTS Backhaul Networks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3.1 Backhaul Architectures . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3.2 1st Mile Backhaul Sharing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3.3 Aggregation Network Sharing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3.4 SeGW (Security Gateway) Deployment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3.5 Backhaul Transmission Technologies . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3.6 Carrier Ethernet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3.7 MPLS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3.8 IP RAN Backhaul Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3.9 Single RAN Synchronization Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3.10 Redundancy and Protection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3.11 RAN QoS Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3.12 Backhaul Protocol Stacks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3.13 Single RAN Protocol Stacks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3.14 VLANs and Dot 1q . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3.15 Backhaul VLANs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3.16 Backhaul VLAN Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3.17 Backhaul VLAN Scenarios . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3.18 Single RAT VLAN Scenario . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3.19 Multi-RAT, Multi-RAN VLAN Scenario . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3.20 Multi-RAT, Single-RAN VLAN Scenario . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3.21. LT1203/v1.1. © Wray Castle Limited. 3.iii.


(55) Single RAN Backhaul. OBJECTIVES At the end of this section you will be able to: ■■. describe the basic services provided by a backhaul network. ■■. outline some of the architectural models commonly employed in backhaul networks including the separation of backhaul into ‘access’ and ‘aggregation’ zones. ■■. identify the key functions performed by the SeGW (Security gateway) in IP-based backhaul networks. ■■. list some of the transmission technologies commonly employed in modern backhaul networks. ■■. outline the functionality of popular backhaul technologies such as Carrier Ethernet and MPLS. ■■. describe some of the techniques employed to facilitate synchronization, redundancy and QoS in IP-based backhaul networks. ■■. describe the layers of the protocols stacks employed by both legacy and Single RAN backhaul interfaces. ■■. describe the operation of the VLAN (Virtual LAN) concept in relation to backhaul for Single RAN networks. LT1203/v1.1. © Wray Castle Limited. 3.v.


(57) Single RAN Backhaul. Backhaul Networks The backhaul service provided to a network’s remote access nodes can be generically divided into several basic areas: The access node itself will generally be a cellular base station (BTS, Node B, eNode B), the backhaul link supplied to the access node is termed the ‘first’ or ‘last’ mile connection and forms part of the Access Transport Network. Unless a backhaul link operates in pure point-to-point mode, in which case it will connect directly to one of the operator’s core network sites, the access link will connect to an ‘aggregation’ point. These nodes are referred to differently by different operators but they are commonly known as ‘transmission high sites’, Point of Concentration (PoC) ‘aggregation sites’ or even ‘first aggregation sites’. In networks that employ microwave access links the first aggregation node is often equipped with a tall tower or is located on a hill or tall building (hence the term ‘high site’); this allows it to act as a hub for microwave links emanating from local base station sites. First aggregation points generally aggregate traffic from multiple low capacity access links onto a smaller number of high capacity microwave or fibre connections that lead further back into the operator’s network. Some network designs incorporate further levels of aggregation in the access network, leading to ‘second aggregation points’ and ‘second mile’ connections. In legacy 2G and 3G radio access networks backhaul links often connected to remote BSC or RNC sites, which served as the radio resource management nodes for an area of the access network. In addition to signalling and management functions, these sites provided a further aggregation point for access traffic as all access connections for nodes in a given area would be routed to the controller site. In more modern network designs the access network controller has either been moved backwards to a core network site or doesn’t exist at all but many networks have kept the remote sites operational to continue to act as traffic aggregation points, with high capacity fibre connections to the core network. The high capacity connections established between the first/second aggregation points and the network controller site is often termed the ‘metro transport network’. Connections between remote network controller sites and the core network can also be carried by the metro network.. LT1203/v1.1. © Wray Castle Limited. 3.1.

(58) Single RAN. Backhaul Architectures Backhaul transmission links may be configured in many ways. Some methods offer lower cost of deployment but little in the way of redundancy, whilst others sacrifice capacity at the expense of resilience. The choice of which method to use is generally dictated by the type of network being built, by the importance of the individual sites being connected and by operator policy. A selection of the most common backhaul architecture types is shown in the diagram, as is an indication of the trade-off between capacity, resilience and cost inherent in each option.. 3.2. © Wray Castle Limited. LT1203/v1.1.

(59) Single RAN Backhaul. 1st Mile Backhaul Sharing The architecture employed by an operator when implementing a Single RAN backhaul scheme can vary widely, especially when it comes to deciding where the sharing should stop. The example in the diagram shows a scenario in which an operator has elected to share the initial access backhaul or 1st Mile connection between the deployed RATs at each site. A common backhaul Ethernet connection carries traffic for all RATs to an aggregation node (which may also be acting as a SeGW), from where separate 2G, 3G and 4G traffic streams are forwarded over appropriate routes. 2G traffic is forwarded via a BSC to the 2G core networks, 3G traffic is forwarded via an RNC to the 3G core networks and 4G traffic is forwarded directly to the EPC. All core network interfaces shown here share the same aggregation network but are carried as separate traffic streams. This approach may be particularly useful in networks that have previously decided to deploy ‘remote’ BSC/RNC nodes. The aggregation node/SeGW in these cases might be co-located with the access controllers and could take advantage of the existing backhaul network site configuration.. LT1203/v1.1. © Wray Castle Limited. 3.3.

(60) Single RAN. Aggregation Network Sharing In this example the operator has elected to keep the traffic for all RATs at a site combined within the same backhaul connection all the way back to the core network. Single RAN traffic will therefore be sharing logical connections across both the access and aggregation networks. The logical connections employed for this purpose could, for example, consist of a Carrier Ethernet private virtual line or an MPLS VPN (Multi-Protocol Label Switching Virtual Private Network). This configuration would be attractive in scenarios where the operator has previously elected to deploy BSC/RNC nodes at core network sites.. 3.4. © Wray Castle Limited. LT1203/v1.1.

(61) Single RAN Backhaul. SeGW (Security Gateway) Deployment The SeGW is a generic node that could be deployed in the backhaul environment to manage connection security functions. 3GPP abbreviate the Security Gateway as SeGW in some documentation and SEG in others, most notably in the specifications that deal with NDS (Network Domain Security) 33.210 and 33.310. The SeGW is mainly responsible for the creation and management of IPsec SA (Security Association) relationships with access nodes such as base stations. Packet-based cellular backhaul links are typically protected using the IPsec ESP (Encapsulating Security Payload) mode with Mutual Authentication enabled. A single backhaul IPsec tunnel is typically created per base station that carries all backhaul traffic to the SeGW. Any access node-access node interfaces, such as the X2 interface in LTE networks and the Iur/ Iurh/Iur-g interfaces optionally configured in UTRAN and GERAN networks, may be routed via the SeGW, as shown in the diagram. The main benefit to be derived from the use of the SeGW is enhanced security for a network’s backhaul connections. Disadvantages related to the use of the SeGW generally relate to the potential traffic bottleneck that each SeGW could become and the additional access network latency that traversal of the security protocols could induce into connections.. Further Reading: 3GPP TS 33.210, 33.310. LT1203/v1.1. © Wray Castle Limited. 3.5.

(62) Single RAN. Backhaul Transmission Technologies The backhaul transmission solutions employed in early mobile networks generally used systems based on PDH (Plesiochronous Digital Hierarchy) data rates. E1 (2 Mbit/s) was the primary rate PDH interface type in Europe and many other regions, whilst T1/JT1 (1.5 Mbit/s) was the base standard employed in the US, Japan and several other countries. Higher-order transmission was deployed as multiples of the primary rate, either as direct multiples (2xE1, 4xE1, 8xE1, etc) or in the steps dictated by the PDH standards in use. In Europe these would have been E1 (2 Mbit/s), E2 (8 Mbit/s), E3 (34 Mbit/s) and E4 (140 Mbit/s) and in the US they would have been T1 (1.5 Mbit/s), T2 (6 Mbit/s), T3 (45 Mbit/s), T4 (275 Mbit/s). Legacy TDM microwave and copper-based transmission solutions were typically scaled to fit in with the strictures of the PDH standards, although more modern systems were designed to use the higher data rates, more efficient multiplexing services and improved inter-working capabilities of SDH (Synchronous Digital Hierarchy), which is known as SONET (Synchronous Optical Network) in the USA. SDH offers transmission capacities calculated in units known as STMs (Synchronous Transport Modules); STM-1 operated at 155 Mbit/s and was capable of multiplexing up to 63 E1 tributaries or a similar quantity of data structured in some other format. Higher order multiplexing options were STM-4 (622 Mbit/s), STM16 (2.5 Gbit/s) STM-64 (10 Gbit/s) and STM-256 (40 Gbit/s). The highest order multiplexing versions of SDH were only available over fibre connections. SDH microwave systems were available that offered STM-1 or STM-4 and copper-based SDH systems generally topped out at STM-1. Fibre optical transmission systems are available that operate in a variety of frequency/wavelength bands but generally conform to one of two physical fibre types: Multi-mode fibres which have a comparatively large cross-sectional area of around 50–60µm and are applicable to short distance (of up to a few hundred metres) communication using relatively inexpensive equipment; single-mode fibres which are thinner, around 10µm, but are able to operate over much longer distances using more expensive transmission equipment. Data rates of 100 Gbit/s or more are possible with optical fibre transmission, especially when WDM (Wavelength Division Multiplexing) techniques are employed. The graph in the diagram provides an indication of the popularity of the three basic backhaul physical layer options prior to the commencement of large-scale LTE rollouts.. 3.6. © Wray Castle Limited. LT1203/v1.1.

(63) Single RAN Backhaul. Carrier Ethernet ‘Carrier Ethernet’ is the term used to describe one of the options that exist to turn Ethernet, which was initially designed to support LAN (Local Area Network) services into a technology that can be employed to support WAN (Wide Area Network) functionality. Ethernet provides a relatively cheap, simple and wellunderstood transmission protocol that is flexible enough to carry just about any form of digital traffic. This makes it ideal for use as the bearer in a combined backhaul network that serves a Single RAN deployment. Carrier Ethernet functionality makes use of VLAN (Virtual LAN) techniques in which Ethernet frames are ‘tagged’ to indicate the VLAN to which they belong, the tag values affect the switching decisions made by Ethernet nodes when attempting to deliver those frames. Source and destination customer networks assign ‘C-tag’ VLAN tags to frame for local switching purposes, whilst Carrier Ethernet providers assign ‘S-tags’ to frames to allow them to be switched to the appropriate destination node or network. In this example a mobile network operator has contracted with a Carrier Ethernet provider to receive backhaul aggregation services. The provider’s Ethernet network offers connectivity between the operator’s core network sites and their remote aggregation sites. Onward connectivity from the aggregation site to each base station site is carried by operator-owned Ethernet-based backhaul transmission such as GigE Microwave. The base station in this example has been configured to belong to the operator’s VLAN 3, so traffic destined for that site will be tagged by core network Ethernet switches with VLAN ID 3. When outbound Ethernet frames pass through the Carrier Ethernet service provider’s gateway they are provided with an additional tag. The existing tag now becomes the C-Tag and the new tag pushed on at the gateway becomes the S-Tag. The service provider has assigned VLAN ID 1027 to this customer virtual connection, which is the value carried in the S-Tag. The S-Tag allows the frame to be switched through the provider’s network to the appropriate cell site or aggregation site gateway, where the S-Tag is popped from the frame and the original, single tagged frame is available to be forwarded to the destination cell site.. LT1203/v1.1. © Wray Castle Limited. 3.7.

(64) Single RAN. MPLS MPLS predates Carrier Ethernet and offers an alternative way of configuring Layer 2 services such as Ethernet to act as a bearer for WAN services. Whereas Carrier Ethernet inserts VLAN tags into Ethernet frames to identify the service flows to which particular frames belong, MPLS inserts one or more ‘shim headers’ between the Ethernet frame header and the frame payload, which is typically an IP packet. The shim header carries a label that identifies the path over which the frame should be switched, which is known as an LSP (Label Switched Path). Shim headers may be ‘stacked’ in a frame, allowing multiple layers of path switching and aggregation to take place and giving an MPLS network the ability to scale as required. LSPs are setup and cleared down using label distribution techniques that are similar in effect to the signalling protocols employed in legacy circuit-switched networks. MPLS introduces some new terminology for Layer 2 switching. An LSR (Label Switched Router) is an MPLS Layer 2 switch, which also has the appropriate control plane functions to participate in setting up and tearing down LSPs. An LSP is an end-to-end MPLS virtual connection between a pair of edge-LSRs, and across a network of LSRs. This is similar to ATM Virtual Circuits and Virtual Paths. An edge-LSR is a special LSR that originates or terminates LSPs, and can classify IP traffic for forwarding across the most appropriate LSP by placing the packet in a FEC (Forwarding Equivalence Class). An FEC is a collection of different packets that are treated identically by the MPLS network. So, for example, in a best-endeavour Internet, all packets to the same aggregate network prefix would typically be within the same FEC.. 3.8. © Wray Castle Limited. LT1203/v1.1.

(65) Single RAN Backhaul. IP RAN Backhaul Requirements Cellular networks were originally designed to make use of traditional backhaul transmission technologies, such as E1/T1 links, which provided a default set of services and characteristics. The migration to IP-based backhaul technologies has meant that those services and characteristics must now be provided by IP, by a Layer 2 bearer technology or by some additional protocols. The main functions that need to be provided in addition to the physical backhauling of RAN traffic include the following: ■■. Synchronization. ■■. Security. ■■. Scalability. ■■. QoS (Quality of Service) Management. ■■. Redundancy and Protection. Multiple protocol options exist that enable each of these services to be configured in an IP-based environment.. LT1203/v1.1. © Wray Castle Limited. 3.9.
