ISSN: 2278 – 1323 All Rights Reserved © 2015 IJARCETNoise Reduction in camera captured
images in android application
Sumit Debnath
[1]Aditya Waghdhare
[2]Dashrath Mane
[3]VES Institute of Technology,
Chembur, Mumbai
Abstract- This paper presents innovative approach towards design, development and implementation of android application which performs the noise reduction operation compatible to android mobile devices or tablets. Noise reduction is not much been done in android as it requires the help of a lot of native libraries like OpenCV, ImageJ etc.Android application development is comparatively new in the existing field for developers. The processing of these images for noise reduction is done in a systematic approach described in this paper.
Introduction
Digital "noise" is a common problem in digital cameras today. Noise in a digital camera is that often annoying grainy look that makes your photos seem like they were shot in a dust storm or printed on an old dot matrix printer. Getting unwanted noise in your images is something that most of us have struggled with. Digital noise usually represents itself as speckled pixels of colour in your images or as a grainy effect, and is generally considered undesirable.
If you have a digital camera, whether you have an advanced top of the line DSLR or a simple point and shoot, you will at some point get images with small dots all over the image. Those small dots might not be very noticeable when you look at the image on the back of the camera, but when you zoom in and view the image on your PC, or the a print out of the image then, they all of a sudden become quite visible.
Image noise is random (not present in the object imaged) variation of brightness or colour information in images, and is usually an aspect of electronic noise. In digital photographs, “noise” is the
commonly-used term to describe visual distortion. While most people turn to post-production software such as Photoshop to reduce the negative effects of noise, there are also a lot of things you can do before that point to help solve the problem.
Causes of Noise
Noise is added to an image usually at the time of the image capturing process. There are different causes for the adding of noise in the image. The amount of pixel corrupted in an image represents the amount of noise included in an image.
There are a few major factors responsible for noise in a digital image:
The environmental situation affects the camera sensors resulting in adding Thermal Noise in the image.
Low light around the camera at the time of image capturing.
Change in the temperature around the camera sensors causes the addition of noise in the image.
Dust particles around the camera lenses in the environment causes noisy image.So we divided our process of noise reduction into two parts
1.
Pre-Processing operation.2.
Post-Processing operation.Pre-Processing Operation
As the unwanted effects in the captured image is the noise in the image.
The noise is the undesirable effects produced in the image during image acquisition of the image. At the time of the image capturing process if there are not adequate conditions available there are chances of the noise being elevated in the image.
2655
ISSN: 2278 – 1323 All Rights Reserved © 2015 IJARCETThus providing with the perfect setting according to the environment is a very essential process even before the image is acquired.
The following changes in the camera setting has to be made for good image acquisition
1. Spread the focus area all across the document.
2. Set the shutter speed of the camera to the minimum.
3. Set the focus of the camera all still capture of images without being effected of motion blur.
4. Set the camera to its maximum exposure.
5. Set the ISO of the camera to the maximum.
6. Make sure that the environment has enough light spread continuously across the document.
7. The flash must be set off as it flashes light only to a particular part of the document, which makes the other parts of the document dim.
So we provide a custom camera with the above setting already done in it, as expecting the user to do the above setting to the camera is not expected n more over all the mobile phone cameras come with a lot of setting in it.
[image:2.612.81.281.439.706.2]The above setting of the camera is possible with the help of the API provided by the android called the Camera API. This Camera API allows us to pass the appropriate camera parameters while the camera is being opened.
Fig. 1- Original captured image
Post-Processing Operation
The Image acquired at the pre-processing operation now has to be operated so as to reduce the noise in the image.
I.Separating the image into 4x4 parts. II.Calculating the greyscale frequency. III.Calculate the Moving Average the
greyscale frequency.
IV.Calculate the Rate of Change of the Moving Average Frequency.
V.Calculate the 2nd
Derivative of the Moving Average of the Frequency
VI.Calculate the Crossover of the Two Derivatives.
VII.Clean Up the Image
VIII.Overlaying all the 4x4 Images as One Image
I Separating the image into 4x4 parts.
The image is divided into a matrix of 4x4 parts, as the noise is not equally spread across the whole image so each part of the image has different levels of noise in it.So for linear affect of the noise reduction of the whole image this operation is applied to 4x4 parts of the image instead of one single image.
II Calculating the greyscale frequency.
Now each 4x4 part of the image is considered as one single image. The Gary value intensity of every pixel of the image is stored and its frequency is calculated.
Fig. 2- Greyscale frequency graph(Histogram of Image)
III Calculate the Moving Average the greyscale frequency.
[image:2.612.325.573.471.633.2]2656
ISSN: 2278 – 1323 All Rights Reserved © 2015 IJARCETSfi = (f(i-4)+f(i-3)+f(i-2)+f(i-1)+f(i)+f(i+1)+f(i+2)+f(i+3)+f(i+4))/9
Where
Sfi is the Smooth Frequency of the ith gray value.
i is the gray values ranging from 0-255. f is the frequency of the gray value.
This is done so the frequency is represented in a smooth way, so as the noise parts is easily distinguished in the image histogram.
Fig. 3- Moving Average
IV Calculate the Rate of Change of the Moving Average Frequency.
Rate of change of the Smoothened frequency is calculated.
DyDiff1(i) = f(i)-Sf(i)
Where
DyDiff1 is the rate of change of the Moving Average Frequency ie the 1st Derivative of it.
Sfi is the Smooth Frequency of the ith gray value.
i is the gray values ranging from 0-255.
This calculated so as the change in the Moving Average Frequency is clearly represented
Fig. 4- 1st Derivative of Moving Average
V Calculate the 2nd Derivative of the Moving Average of the Frequency
This is the rate of change of the rate of change of the Moving Average.
DyDiff2(i) = DyDiff1(i)-DyDiff1(i-1) Where
DyDiff2 is the rate of change of the rate of change of the Moving Average Frequency ie the 2nd Derivative of it.
DyDiff1 is the rate of change of the Moving Average Frequency ie the 1st Derivative of it.
i is the gray values ranging from 0-255.
Fig. 4- 2nd Derivative of Moving Average
2657
ISSN: 2278 – 1323 All Rights Reserved © 2015 IJARCETThe crossover point is the point where there is drastic change in the movements of the frequency and can be recognised as noise in the image. So the crossover point of the two derivatives ie DyDiff2 and DyDiff1 is found out by the following way:
if(((((DyDiff2 (i))>0) AND (DyDiff2(i+1))>0) AND (DyDiff2(i+2))>0) AND
(DyDiff1(i)* DyDiff1(i+2))<0.0) Where
DyDiff2 is the rate of change of the rate of change of the Moving Average Frequency ie the 2nd Derivative of it.
DyDiff1 is the rate of change of the Moving Average Frequency ie the 1st Derivative of it.
i is the grey values ranging from 0-255.
Then the start point of the noisy section of the image has been found.
VII Clean Up the Image
The cleanup of the image is an algorithm of making the image sharper as the important and the good pixels of the images are shifted to the 0 side of the Greyscale and the noise is shifted to the 255 side of the Greyscale, without losing any pixel.
if (pix[x][y] <= (float) (CrossoverPoint)) {
red =( ( (pixel >>16) & 0xff ) *.05); green =( ( (pixel >>8 ) & 0xff ) *.05); blue =( ( (pixel ) & 0xff ) *.05); }
else
{
red =(Math.min(255,( ( pixel >> 16 ) & 0xff ) *2) ); green =(Math.min(255,( ( pixel >> 8 ) & 0xff ) *2) ); blue =(Math.min(255,( ( pixel ) & 0xff ) *2) ); }
Where
pix is the pixel value of the image at a specific point. x is the point on the x axis of the image ranging from 0-image Width.
y is the point on the y axis of the image ranging from 0-image Height.
Crossover Point is the point at which the noise of the image starts.
VIII Overlaying all the 4x4 Images as One Image
[image:4.612.322.540.71.364.2]All the 4x4 images are then taken together and shown as one single image.
Fig. 6- final processed image
CONCLUSION
Different image processing tasks can be done in java as well as open cv, it will be new research field to develop and test these applications on mobile phones. Since more new hardware platforms for the android operating system are being released every month, it will also be important to test the
erences
[1]
EE368 Digital Image Processing, ”Tutorial On Using Android for Image Processing Projects”, Spring 2012, Windows Version.[2]
J.R.Parker. Algorithms for Image Processing and Computer Vision, John Wiley and Sons, 1997.2658
ISSN: 2278 – 1323 All Rights Reserved © 2015 IJARCET[4]
Wrox Programmer to Programmer,”Beginning Android Application Development”.[5]
L.K.Huang and M.J.Wang. “Image Thresholding by Minimizing The Measures of Fuzziness”, Pattern Recognition, vol 28, p. 41-51,1995[6]
C. A. B. Mello et al., “Image Segmentation of Ovitramps for Automatic Counting of Aedes Aegypti Eggs”, in 30th Annu. International Conf. of the IEEE Engineeringin Medicine and Biology Society, Vancouver, 2008, pp. 3103-3106.
