Documentation. HiPath 8000 OpenStage 40. Quick Reference Guide. Communication for the open minded

(1)

Documentation

HiPath 8000

OpenStage 40

(2)

Using Your Telephone

2

Using Your Telephone

Function Keys and Audio Keys

5-way navigator

Programmable sensor keys on the display

r Activate/deactivate forwarding

N Service/Applications menu

O Voicemails/Call lists

p Turn microphone on/off

o Turn headset on/off

, Redial

s End (disconnect) call

n Turn speaker on/off

+ Depending on situation,

-set volumes for ringer or speaker Press m key: - Scroll upwards Press l key: - Scroll downwards Press g key:

- Call up the context menu - Go down a level Press h key: - Cancel function - Delete character left of cursor - Go up a level Press i key: - Confirm input - Perform action Keys Label S inactive R lit T flashing Peter Mirea, Ch.

(3)

Using Your Telephone

Display

Components

Entering Phone Numbers and Text

Keypad

In situations where text entry is possible, you can use the dial keys to enter text, punctua-tion and special characters. To do this, press the numerical keys repeatedly.

Extra asterisk and pound key functions:

Key Function during text input Function when held down

* Write special characters Deactivate the ring tone. # Switch between upper/lower case and digit entry. Activate telephone lock.

Status bar

Programmable sensor key list

Context-dependent displays Level 2 Mirea, Ch. Toussaint. Rüscher Stahl, Ing Iller, Zin 10:29 am Wed 11/17/06 Company name 07 01234567

(4)

Important Operating Procedures

4

Important Operating Procedures

In Idle State

Answering a call with the handset

ZZ_^

Answering a call in speakerphone mode

ZZ_n Rejecting a call

ZZ_f "Reject" i

Deflecting a call

ZZ_f "Deflect" iZj destination phone number i

Dialing from the caller list

O

Z_f "CallLog" iZf "Missed", "Dialled", "Received" or "Forwarded" i

Z_fdesired entry i

Activating callback

j destination phone number iZ if no answer or busy: f "Call back" i

Saving a phone number to a key

S Hold down programmable key Zf "Normal" or "Shifted" i

Z_f "Selected dialling" iZf „Label“ iZj Enter name, e.g. Peter

Z_f "Setting:" iZj destination number i Zf "Option = Save & Exit" i

Z_f "Save & Exit" i ZN

Dialing a saved number

S saved phone number Zn loudspeaker turns on automatically or ^

^ Lift handset j Enter text or number

\ Replace handset f Select entry [ Conduct call g Open context menu

(5)

Saving a function to a key

S Hold down programmable key Zf "Normal" or "Shifted" i

Z_f select function i (for funnctions with phone number: Zf "Setting:" i

Z enter the phone number) Zf "Option = Save & Exit" i Zf "Save & Exit" i ZN

Redialing a number

,

"Repeat dialling" Zf desired number iZ^

Programming call forwarding

rZ_f "Edit call forwarding" iZf "Destination" (e. g. under "All calls") i

Z "Edit favourites" iZf "Destination 1" iZj phone number i

Z Selected forwarding type, e.g. f "All calls" iZgZf "On" i

Z_f "Options = Save & Exit" iZf "Save & Exit" i ZN

Turning call forwarding on/off for all calls

Requirement: Forwarding destination for "All calls" was programmed.

(6)

6

During Calls with a Party A

Switching to speakerphone mode

Hold down n Z\ (US only: nZ\)

Consultation

gZ "Consultation" iZj phone number for party B iZ[ party B Zg

Z "Disconnect & return" iZ[ party A

Accepting call waiting

Z call waiting tone Zf"Accept" iZ[ party B Zf party B Zg

Z_f "Disconnect & return" iZ[ party A

Deflect call on call waiting

Z Call waiting tone Zf "Deflect" iZj phone number for party B iZ[ party A

Start conference

gZ "Consultation" iZj phone number for party B iZ[ party B Zg

Z_f "Conference" iZ[ party A and B

Start conference on call waiting

Z call waiting tone Zf "Accept" iZ[ party B ZgZf "Conference" i

Z_[ party A and B

Blind transfer to party B

gZ_f "Consultation" iZj destination phone number iZ\

Transfer after consultation

(7)

80200 München Deutschland Siemens Enterprise

Communications GmbH & Co. KG is a Trademark Licensee of Siemens AG Reference No:
