(1)

System Components

Options

The GLPHASE SpaceBuilder system is ideal for medium-sized spaces that require

additional options such as expansion modules for more load types, touch screens,

additional sensors, and shade and AV integration.

SpaceBuilder allows you to specify all the necessary features and operations for an autonomous

lighting control system specifically designed for the needs of your space. Start by selecting

the load types and accessories and finish by defining how each interface should function

to control lighting levels, vacancy sensing, daylight harvesting, shades, and AV.

GLPHASE

Available in 4 or 8 zone versions to control both

forward or reverse phase dimming loads. All

GLPHASE systems can be expanded to easily

add more zones of lighting.

Keypads

Up to 4 keypads can be added to a GLPHASE

space. Refer to page 4 for standard sequence

of operations to specify the button operations

and standard engravings.

Occupancy Sensors

Up to 4 dual technology occupancy sensors can be

added to each GLPHASE space for both occupancy

and vacancy sensing. Each sensor offers coverage for

spaces up to 2,000 square feet.

Daylight Sensors

Up to 4 open-loop daylight sensors can be

added to each GLPHASE space for daylight

harvesting control.

Touch Screens

An optional 7” color touch screen can be added

to each to provide the user with full scene control,

dynamic load control, and schedule adjustments.

Loads

Any system can be expanded to include additional

loads for 0-10V, switching, phase control, or switched

plug loads.

AV Integration

The GLPHASE system can easily integrate with AV

systems by adding a serial control module. If this option

is selected, Crestron will also supply prepackaged

code for the AV contractor to connect the systems.

Shade Integration

Integrate with Crestron, Mecho, and other leading

shading solutions. Control for up to 4 local shade

motors can be included with each GLPHASE system.

Networking

Any Crestron SpaceBuilder system can be networked

to provide centralized monitoring, management,

and master control. This includes direct integration

with BMS and reporting, alerts, global time clock

management, and maintenance and automation

via Crestron Fusion

®

.

SpaceBuild Specification Worksheet

(2)

Zone #

Zone Description

Fixture Tag

Circuit #

Voltage

Load Type

Emergency /

Life Safety

Dim (Y/N)

Fixture

Watts

Quantity

Total Watts

Example Downlights A H2-1 120 VAC Reverse Phase Dimmed N/A Yes 25 4 100

1 2 3 4 5 6 7 8

Date:___________________ Project:_____________________________________________________________

Quantity:_________________

Space Name:__________________________________________________________

Space Number(s): ___________________________________________________________________________________

GLPHASE______-______KP-______KP-______KP-______KP-______OS-______DS-_______-_______-_______-_______-_______-_______

©2015 Crestron Electronics, Inc. WS_2015_01

›

Page 2 of 6

Specification Worksheet

|

GLPHASE System

GLPHASE SpaceBuilder Load Schedule

INTERFACE COLOR

NETWORKING

ADD A ZONE

TOUCH SCREEN

SHADE QUANTITY

SHADE MOTOR TYPE

AV

BLANK . . . .STAND-ALONE SPACE

NET . . . .NETWORKED SPACE

BLANK . . . NONE

PL . . . 20A 120V PLUG LOAD

BLANK . . . .NO TOUCH SCREEN

TS . . . 7” TOUCH SCREEN

BLANK . . . .NO SHADES

1 . . . 1 SHADE

2 . . . 2 SHADES

3 . . . 3 SHADES

4 . . . 4 SHADES

BLANK . . . .NO SHADES

RS232 . . . .RS-232/CONTACT

RLY . . . 120V RELAY

CN . . . .CRESTRON QMT MOTOR

BLANK . . . NO AV

AV . . . .RS-232 AV

PACKAGE

KEYPADS

OCCUPANCY SENSORS

DAYLIGHT SENSORS

4

. . . .FWD. OR REV. PHASE ZONES

8

. . . .FWD. OR REV. PHASE ZONES

GLPHASE

-

KP -

KP -

KP

-BLANK . . . WHITE

BLK. . . .BLACK

ALMD . . . .ALMOND

BLANK

. . . NO KEYPADS

A

. . . KEYPAD STYLE A

B

. . . KEYPAD STYLE B

C

. . . KEYPAD STYLE C

D

. . . KEYPAD STYLE D

E

. . . KEYPAD STYLE E

F

. . . KEYPAD STYLE F

G

. . . KEYPAD STYLE G

H

. . . KEYPAD STYLE H

X

. . . CUSTOM KEYPAD SOO

Please contact Crestron to add more than 4 keypads

BLANK

. . . .NO SENSORS

1

. . . 1 SENSOR

2

. . . 2 SENSORS

3

. . . 3 SENSORS

4

. . . 4 SENSORS

BLANK

. . . .NO SENSORS

1

. . . 1 SENSOR

2

. . . 2 SENSORS

3

. . . 3 SENSORS

4

. . . 4 SENSORS

KP -

OS-

DS--

-

--

-120 VAC 2-Wire Forward Phase Dimmed Reverse Phase Dimmed

N/A Partial Zone Complete Zone

Yes No

Example: GLPHASE4 - AKP - DKP - 1OS - 1DS - TS - AV - NET - PL

N/A N/A N/A N/A N/A N/A N/A N/A

(3)

GLPHASE SpaceBuilder Schematic Riser

Specification Worksheet

|

GLPHASE System

CN CN CN CN CN CN CN CN CN CN CN CN CN CN CN CN CN CN CN CN CN CN CN CN CN OVERCURRENT PROTECTION 20A (MAX) BY OTHERS

(QTY. 2)

120 VAC ONLY

BRANCH CIRCUIT

GLPHASE

CN CN ENET ENET CRESNET 0-10V DALI ETHERNET SENSOR (CRESNET OR 3-#18)

CABLE TYPES:

(NOT ALL TYPES ARE USED ON ALL PROJECTS)

120VAC (WITH PHASE CONTROL)

TO BUILDING LAN (F.B.O) FOR INTERSYSTEM ETHERNET

COMMUNICATIONS REMOTE & LOCAL PROGRAM

UPLOADS LOAD LOAD LOAD LOAD LOAD LOAD LOAD LOAD LOAD TYPE: LOAD TYPE: LOAD TYPE: LOAD TYPE: LOAD TYPE: LOAD TYPE: LOAD TYPE: LOAD TYPE:

FWD / REV PHASE DIM

STATION ID: LOCATION: DWG. #: C2N-CBD-P C2N-CBD-P CKP-1 SEE PLANS 2-8 BUTTONS STATION ID: LOCATION: DWG. #: C2N-CBD-P C2N-CBD-P CKP-2 SEE PLANS 2-8 BUTTONS STATION ID: LOCATION: DWG. #: C2N-SDC C2N-SDC

FEED: 120VAC TO DEVICES C2N-SDC DOWN UP DOWN UP NETNET PWRNETSETUP 24 Y Z G 24 Y Z G SDC-1 SEE PLANS SHADE/DRAPE/SCREEN #1 SHADE/DRAPE/SCREEN #2 STATION ID: LOCATION: DWG. #: C2N-CBD-P C2N-CBD-P CKP-3 SEE PLANS 2-8 BUTTONS STATION ID: LOCATION: DWG. #: C2N-CBD-P C2N-CBD-P CKP-4 SEE PLANS 2-8 BUTTONS ENET ENET

7" TOUCH

SCREEN

ENET ENET STATION ID: LOCATION: DWG. #: C2N-IO C2N-IO RELAY 12 COM IR S G PWR NET SETUP NET HI NET ID LO C2N-IO 24 Y Z G24 Y Z G RS-232 TO A/V SYSTEM AV-1 SEE PLANS

ADD A

ZONE

FWD / REV PHASE DIM

FWD / REV PHASE DIM

FWD / REV PHASE DIM

FWD / REV PHASE DIM

FWD / REV PHASE DIM

FWD / REV PHASE DIM

FWD / REV PHASE DIM

CN CN CN STATION ID: LOCATION: DWG. #: GLS-ODT-C-CN GLS-ODT-C-CN OS-1 SEE PLANS STATION ID: LOCATION: DWG. #: GLS-ODT-C-CN CN GLS-ODT-C-CN OS-2 SEE PLANS STATION ID: LOCATION: DWG. #: GLS-ODT-C-CN CN GLS-ODT-C-CN OS-3 SEE PLANS STATION ID: LOCATION: DWG. #: GLS-ODT-C-CN CN GLS-ODT-C-CN OS-4 SEE PLANS OPEN LOOP DAYLIGHT SENSOR SEE PLANS DS-1 OPEN LOOP DAYLIGHT SENSOR SEE PLANS DS-2 OPEN LOOP DAYLIGHT SENSOR SEE PLANS DS-3 OPEN LOOP DAYLIGHT SENSOR SEE PLANS DS-4

DAYLIGHT SENSORS CONNECT TO INPUTS ON KEYPADS OR OCCUPANCY SENSORS. IF INSUFFICIENT INPUTS ARE PRESENT ON THE PROJECT, GLS-SIM INTERFACES WILL BE ADDED.

CN CN

(4)

C2N-CBD-P KEYPAD ENGRAVING SHEET

MODIFIED KEYPAD LAYOUTS

2 BUTTON STYLE 48 1 2 3 4 5 6 7 8 8 BUTTON STYLE 1 1 2 3 4 6 7 7 BUTTON STYLE 2 5 6 BUTTON STYLE 8 2 1 3 4 5 6 6 BUTTON STYLE 9 1 2 3 4 5 6 6 BUTTON STYLE 10 1 3 2 4 5 6 6 BUTTON STYLE 11 1 2 5 6 3 4 5 BUTTON STYLE 22 1 5 2 4 3 5 BUTTON STYLE 23 3 1 2 4 5 6 BUTTON STYLE 17 1 5 6 3 4 5 BUTTON STYLE 24 2 1 3 4 5 5 BUTTON STYLE 25 1 2 3 4 5 1 2 7 BUTTON STYLE 4 6 7 4 5 3 2 6 BUTTON STYLE 15 5 6 3 4 2 7 BUTTON STYLE 5 6 7 4 5 3 1 3 7 BUTTON STYLE 6 6 7 4 5 2 1 6 BUTTON STYLE 16 5 6 3 4 2 1 1 2 5 BUTTON STYLE 29 3 4 5 2 1 5 BUTTON STYLE 30 3 4 5 1 2 5 BUTTON STYLE 31 2 4 5 1 3 4 BUTTON STYLE 32 2 1 3 4 4 BUTTON STYLE 35 1 4 3 2 4 BUTTON STYLE 41 3 4 1 2 4 BUTTON STYLE 42 1 2 3 4 4 BUTTON STYLE 43 2 1 3 4 3 BUTTON STYLE 46 3 1 2 1 2 3 3 BUTTON STYLE 44 1 2

PLEASE USE THESE STYLES AS A GUIDE TO FILL OUT THE MODIFIED KEYPAD LAYOUT &

ENGRAVING FORMS ON THE NEXT PAGE

NOTE THAT SEVERAL STYLES HAVE BEEN REMOVED FROM THIS SHEET, BUT STYLE NUMBERS ARE UNCHAINED TO MAINTAIN COMPATIBILITY WITH OLDER SHEETS.

DEVICE:

C2N-CBD-P CAMEO

KEYPAD

"MODIFIED" LAYOUT

DRAWING:

4 OF 5

15 Volvo Drive Rockleigh

NJ 07647

Tel: 888-273-7876 Fax: 201-767-6011 www.crestron.com

PART #:

DESCRIPTION:

REVISION:

NOTES:

D

ATE:

C2N-CBD-P

C2N-CBD-P MODIFIED L

AYOUT & ENGR

AVING

007

3/10/2014

UPD

ATE

AVAILABLE STYLES- OTHER STYLES NOT

RENUMBERED

ON

OFF

C2N-CBD-P KEYPAD ENGRAVING SHEET

MODIFIED KEYPAD LAYOUTS

2 BUTTON STYLE 48 1 2 3 4 5 6 7 8 8 BUTTON STYLE 1 1 2 3 4 6 7 7 BUTTON STYLE 2 5 6 BUTTON STYLE 8 2 1 3 4 5 6 6 BUTTON STYLE 9 1 2 3 4 5 6 6 BUTTON STYLE 10 1 3 2 4 5 6 6 BUTTON STYLE 11 1 2 5 6 3 4 5 BUTTON STYLE 22 1 5 2 4 3 5 BUTTON STYLE 23 3 1 2 4 5 6 BUTTON STYLE 17 1 5 6 3 4 5 BUTTON STYLE 24 2 1 3 4 5 5 BUTTON STYLE 25 1 2 3 4 5 1 2 7 BUTTON STYLE 4 6 7 4 5 3 2 6 BUTTON STYLE 15 5 6 3 4 2 7 BUTTON STYLE 5 6 7 4 5 3 1 3 7 BUTTON STYLE 6 6 7 4 5 2 1 6 BUTTON STYLE 16 5 6 3 4 2 1 1 2 5 BUTTON STYLE 29 3 4 5 2 1 5 BUTTON STYLE 30 3 4 5 1 2 5 BUTTON STYLE 31 2 4 5 1 3 4 BUTTON STYLE 32 2 1 3 4 4 BUTTON STYLE 35 1 4 3 2 4 BUTTON STYLE 41 3 4 1 2 4 BUTTON STYLE 42 1 2 3 4 4 BUTTON STYLE 43 2 1 3 4 3 BUTTON STYLE 46 3 1 2 1 2 3 3 BUTTON STYLE 44 1 2

PLEASE USE THESE STYLES AS A GUIDE TO FILL OUT THE MODIFIED KEYPAD LAYOUT &

ENGRAVING FORMS ON THE NEXT PAGE

NOTE THAT SEVERAL STYLES HAVE BEEN REMOVED FROM THIS SHEET, BUT STYLE NUMBERS ARE UNCHAINED TO MAINTAIN COMPATIBILITY WITH OLDER SHEETS.

DEVICE:

C2N-CBD-P CAMEO

KEYPAD

"MODIFIED" LAYOUT

DRAWING:

4 OF 5

15 Volvo Drive Rockleigh

NJ 07647

Tel: 888-273-7876 Fax: 201-767-6011 www.crestron.com

PART #:

DESCRIPTION:

REVISION:

NOTES:

D

ATE:

C2N-CBD-P

C2N-CBD-P MODIFIED L

AYOUT & ENGR

AVING

007

3/10/2014

UPD

ATE

AVAILABLE STYLES- OTHER STYLES NOT

RENUMBERED

ON

▲

OFF ▼

C2N-CBD-P KEYPAD ENGRAVING SHEET

MODIFIED KEYPAD LAYOUTS

2 BUTTON STYLE 48 1 2 3 4 5 6 7 8 8 BUTTON STYLE 1 1 2 3 4 6 7 7 BUTTON STYLE 2 5 6 BUTTON STYLE 8 2 1 3 4 5 6 6 BUTTON STYLE 9 1 2 3 4 5 6 6 BUTTON STYLE 10 1 3 2 4 5 6 6 BUTTON STYLE 11 1 2 5 6 3 4 5 BUTTON STYLE 22 1 5 2 4 3 5 BUTTON STYLE 23 3 1 2 4 5 6 BUTTON STYLE 17 1 5 6 3 4 5 BUTTON STYLE 24 2 1 3 4 5 5 BUTTON STYLE 25 1 2 3 4 5 1 2 7 BUTTON STYLE 4 6 7 4 5 3 2 6 BUTTON STYLE 15 5 6 3 4 2 7 BUTTON STYLE 5 6 7 4 5 3 1 3 7 BUTTON STYLE 6 6 7 4 5 2 1 6 BUTTON STYLE 16 5 6 3 4 2 1 1 2 5 BUTTON STYLE 29 3 4 5 2 1 5 BUTTON STYLE 30 3 4 5 1 2 5 BUTTON STYLE 31 2 4 5 1 3 4 BUTTON STYLE 32 2 1 3 4 4 BUTTON STYLE 35 1 4 3 2 4 BUTTON STYLE 41 3 4 1 2 4 BUTTON STYLE 42 1 2 3 4 4 BUTTON STYLE 43 2 1 3 4 3 BUTTON STYLE 46 3 1 2 1 2 3 3 BUTTON STYLE 44 1 2

PLEASE USE THESE STYLES AS A GUIDE TO FILL OUT THE MODIFIED KEYPAD LAYOUT &

ENGRAVING FORMS ON THE NEXT PAGE

NOTE THAT SEVERAL STYLES HAVE BEEN REMOVED FROM THIS SHEET, BUT STYLE NUMBERS ARE UNCHAINED TO MAINTAIN COMPATIBILITY WITH OLDER SHEETS.

DEVICE:

C2N-CBD-P CAMEO

KEYPAD

"MODIFIED" LAYOUT

DRAWING:

4 OF 5

15 Volvo Drive Rockleigh

NJ 07647

Tel: 888-273-7876 Fax: 201-767-6011 www.crestron.com

PART #:

DESCRIPTION:

REVISION:

NOTES:

D

ATE:

C2N-CBD-P

C2N-CBD-P MODIFIED L

AYOUT & ENGR

AVING

007

3/10/2014

UPD

ATE

AVAILABLE STYLES- OTHER STYLES NOT

RENUMBERED

ON

OFF

C2N-CBD-P KEYPAD ENGRAVING SHEET

MODIFIED KEYPAD LAYOUTS

2 BUTTON STYLE 48 1 2 3 4 5 6 7 8 8 BUTTON STYLE 1 1 2 3 4 6 7 7 BUTTON STYLE 2 5 6 BUTTON STYLE 8 2 1 3 4 5 6 6 BUTTON STYLE 9 1 2 3 4 5 6 6 BUTTON STYLE 10 1 3 2 4 5 6 6 BUTTON STYLE 11 1 2 5 6 3 4 5 BUTTON STYLE 22 1 5 2 4 3 5 BUTTON STYLE 23 3 1 2 4 5 6 BUTTON STYLE 17 1 5 6 3 4 5 BUTTON STYLE 24 2 1 3 4 5 5 BUTTON STYLE 25 1 2 3 4 5 1 2 7 BUTTON STYLE 4 6 7 4 5 3 2 6 BUTTON STYLE 15 5 6 3 4 2 7 BUTTON STYLE 5 6 7 4 5 3 1 3 7 BUTTON STYLE 6 6 7 4 5 2 1 6 BUTTON STYLE 16 5 6 3 4 2 1 1 2 5 BUTTON STYLE 29 3 4 5 2 1 5 BUTTON STYLE 30 3 4 5 1 2 5 BUTTON STYLE 31 2 4 5 1 3 4 BUTTON STYLE 32 2 1 3 4 4 BUTTON STYLE 35 1 4 3 2 4 BUTTON STYLE 41 3 4 1 2 4 BUTTON STYLE 42 1 2 3 4 4 BUTTON STYLE 43 2 1 3 4 3 BUTTON STYLE 46 3 1 2 1 2 3 3 BUTTON STYLE 44 1 2

PLEASE USE THESE STYLES AS A GUIDE TO FILL OUT THE MODIFIED KEYPAD LAYOUT &

ENGRAVING FORMS ON THE NEXT PAGE

NOTE THAT SEVERAL STYLES HAVE BEEN REMOVED FROM THIS SHEET, BUT STYLE NUMBERS ARE UNCHAINED TO MAINTAIN COMPATIBILITY WITH OLDER SHEETS.

DEVICE:

C2N-CBD-P CAMEO

KEYPAD

"MODIFIED" LAYOUT

DRAWING:

4 OF 5

15 Volvo Drive Rockleigh

NJ 07647

Tel: 888-273-7876 Fax: 201-767-6011 www.crestron.com

PART #:

DESCRIPTION:

REVISION:

NOTES:

D

ATE:

C2N-CBD-P

C2N-CBD-P MODIFIED L

AYOUT & ENGR

AVING

007

3/10/2014

UPD

ATE

AVAILABLE STYLES- OTHER STYLES NOT

RENUMBERED

ON

OFF

DIM

KEYPAD TYPE A

Typical ApplicationsOffice, Restroom, Storage/Utility Room, Corridor, Basic Classroom

KEYPAD TYPE B

Typical ApplicationsOffice, Conference Room, Classroom, Library

KEYPAD TYPE C

Typical ApplicationsOffice, Conference Room, Classroom, Library

KEYPAD TYPE D

Typical ApplicationsOffice, Conference Room, Classroom, Library

Date:___________________ Project:_____________________________________________________________

Quantity:_________________

Space Name:__________________________________________________________

Space Number(s): ___________________________________________________________________________________

GLPHASE______-______KP-______KP-______KP-______KP-______OS-______DS-_______-_______-_______-_______-_______-_______

©2015 Crestron Electronics, Inc. WS_2015_01

›

Page 4 of 6

GLPHASE SpaceBuilder Sequence of Operations

Continued on page 5

Specification Worksheet

|

GLPHASE System

Button 1 Functionality: ON

›

Turn all lights on and enable daylight harvesting

›

If daylight sensor is not present, lights will turn on to 100%

Button 2 Functionality: OFF

›

Turn all lights off to 0% and disable daylight harvesting

Button 1 Functionality: ON

›

Turn all lights on and enable daylight harvesting

›

If daylight sensor is not present, lights will turn on to 100%

›

Press and hold will raise all dimmable lighting

Button 2 Functionality: OFF

›

Turn all lights off to 0% and disable daylight harvesting

›

Press and hold will lower all dimmable lighting

Button 1 Functionality: ON

›

Turn all lights on and enable daylight harvesting

›

If daylight sensor is not present, lights will turn on to 100%

Button 2 Functionality: OFF

›

Turn all lights off to 0% and disable daylight harvesting

Button 3 Functionality: DIM

›

Toggle to dim load up and down

Button 1 Functionality: ON

›

Turn all lights on and enable daylight harvesting

›

If daylight sensor is not present, lights will turn on to 100%

Button 2 Functionality: ▲

›

Dim lights up

Button 3 Functionality: ▼

›

Dim lights down

Button 4 Functionality: OFF

(5)

C2N-CBD-P KEYPAD ENGRAVING SHEET

MODIFIED KEYPAD LAYOUTS

1 2 3 4 5 6 7 8 8 BUTTON STYLE 1 1 2 3 4 6 7 7 BUTTON STYLE 2 5 6 BUTTON STYLE 8 2 1 3 4 5 6 6 BUTTON STYLE 9 1 2 3 4 5 6 6 BUTTON STYLE 10 1 3 2 4 5 6 6 BUTTON STYLE 11 1 2 5 6 3 4 5 BUTTON STYLE 22 1 5 2 4 3 5 BUTTON STYLE 23 3 1 2 4 5 6 BUTTON STYLE 17 1 5 6 3 4 5 BUTTON STYLE 24 2 1 3 4 5 5 BUTTON STYLE 25 1 2 3 4 5 1 2 7 BUTTON STYLE 4 6 7 4 5 3 2 6 BUTTON STYLE 15 5 6 3 4 2 7 BUTTON STYLE 5 6 7 4 5 3 1 3 7 BUTTON STYLE 6 6 7 4 5 2 1 6 BUTTON STYLE 16 5 6 3 4 2 1 1 2 5 BUTTON STYLE 29 3 4 5 2 1 5 BUTTON STYLE 30 3 4 5 1 2 2 4 5 1 3 2 1 3 4 1 4 3 2 3 4 1 2 1 2 3 4 2 1 3 4 3 1 2 1 2 3 1 2

NJ 07647

PART #:

DESCRIPTION:

REVISION:

NOTES:

D

ATE:

C2N-CBD-P

C2N-CBD-P MODIFIED L

AYOUT & ENGR

AVING

007

3/10/2014

UPD

ATE

AVAILABLE STYLES- OTHER STYLES NOT

RENUMBERED

ON SCENE 1 SCENE 2 SCENE 3 ALL OFF ▲ ▼

KEYPAD TYPE F

Typical ApplicationsOffice, Conference Room, Classroom, Library

KEYPAD TYPE X

Typical ApplicationsAll applications needing a custom keypad button configuration and functionality

Date:___________________ Project:_____________________________________________________________

Quantity:_________________

Space Name:__________________________________________________________

Space Number(s): ___________________________________________________________________________________

GLPHASE______-______KP-______KP-______KP-______KP-______OS-______DS-_______-_______-_______-_______-_______-_______

GLPHASE SpaceBuilder Sequence of Operations, Continued

Specification Worksheet

|

GLPHASE System

C2N-CBD-P KEYPAD ENGRAVING SHEET

MODIFIED KEYPAD LAYOUTS

2 BUTTON STYLE 48 1 2 3 4 5 6 7 8 8 BUTTON STYLE 1 1 2 3 4 6 7 7 BUTTON STYLE 2 5 6 BUTTON STYLE 8 2 1 3 4 5 6 6 BUTTON STYLE 9 1 2 3 4 5 6 6 BUTTON STYLE 10 1 3 2 4 5 6 6 BUTTON STYLE 11 1 2 5 6 3 4 5 BUTTON STYLE 22 1 5 2 4 3 5 BUTTON STYLE 23 3 1 2 4 5 6 BUTTON STYLE 17 1 5 6 3 4 5 BUTTON STYLE 24 2 1 3 4 5 5 BUTTON STYLE 25 1 2 3 4 5 1 2 7 BUTTON STYLE 4 6 7 4 5 3 2 6 BUTTON STYLE 15 5 6 3 4 2 7 BUTTON STYLE 5 6 7 4 5 3 1 3 7 BUTTON STYLE 6 6 7 4 5 2 1 6 BUTTON STYLE 16 5 6 3 4 2 1 1 2 5 BUTTON STYLE 29 3 4 5 2 1 5 BUTTON STYLE 30 3 4 5 1 2 5 BUTTON STYLE 31 2 4 5 1 3 4 BUTTON STYLE 32 2 1 3 4 4 BUTTON STYLE 35 1 4 3 2 4 BUTTON STYLE 41 3 4 1 2 4 BUTTON STYLE 42 1 2 3 4 4 BUTTON STYLE 43 2 1 3 4 3 BUTTON STYLE 46 3 1 2 1 2 3 3 BUTTON STYLE 44 1 2

PLEASE USE THESE STYLES AS A GUIDE TO FILL OUT THE MODIFIED KEYPAD LAYOUT &

ENGRAVING FORMS ON THE NEXT PAGE

NOTE THAT SEVERAL STYLES HAVE BEEN REMOVED FROM THIS SHEET, BUT STYLE NUMBERS ARE UNCHAINED TO MAINTAIN COMPATIBILITY WITH OLDER SHEETS.

DEVICE:

C2N-CBD-P CAMEO

KEYPAD

"MODIFIED" LAYOUT

DRAWING:

4 OF 5

15 Volvo Drive Rockleigh

NJ 07647

Tel: 888-273-7876 Fax: 201-767-6011 www.crestron.com

PART #:

DESCRIPTION:

REVISION:

NOTES:

D

ATE:

C2N-CBD-P

C2N-CBD-P MODIFIED L

AYOUT & ENGR

AVING

007

3/10/2014

UPD

ATE

AVAILABLE STYLES- OTHER STYLES NOT

RENUMBERED

DIMMING ON / OFF ▲ SWITCHING ON / OFF ▼

KEYPAD TYPE G

Typical Applications: Office, Conference Room, Classroom, Library, Applications where dimming and switching both exist and need separate control

KEYPAD TYPE H

Typical Applications: Office, Conference Room, Classroom, Library, Applications where shades control is needed

Button 1 Functionality: DIMMING ON/OFF

›

Toggle dimmable zones on or off with feedback if any lights are on

›

Toggle to turn daylight harvesting on or off

›

If daylight sensor is not present, lights will turn on to 100%

Button 2 Functionality: ▲

›

Dim lights up

Button 3 Functionality: ▼

›

Dim lights down

Button 4 Functionality: SWITCHING ON/OFF

›

Toggle dimmable zones on or off with feedback if any lights are on

Button 1 Functionality: ALL ON

›

Turn all lights on and enable daylight harvesting

›

If daylight sensor is not present, lights will turn on to 100%

Button 2 Functionality: SCENE 1

›

Recalls scene 1 settings with feedback

Button 3 Functionality: SCENE 2

›

Recalls scene 2 settings with feedback

Button 4 Functionality: ALL OFF

›

Turn all lights off to 0% and disable daylight harvesting

Button 5 Functionality: SHADES

›

Activates up and down arrows to control shades.

After 5 seconds of inactivity, up and down arrows revert

back to dimming lights up and down.

Button 6 Functionality: ▲

›

Dim lights up (shades up when SHADES button is active)

Button 7 Functionality: ▼

›

Dim lights down (shades down when SHADES button is active)

C2N-CBD-P KEYPAD ENGRAVING SHEET

MODIFIED KEYPAD LAYOUTS

2 BUTTON STYLE 48 1 2 3 4 5 6 7 8 8 BUTTON STYLE 1 1 2 3 4 6 7 7 BUTTON STYLE 2 5 6 BUTTON STYLE 8 2 1 3 4 5 6 6 BUTTON STYLE 9 1 2 3 4 5 6 6 BUTTON STYLE 10 1 3 2 4 5 6 6 BUTTON STYLE 11 1 2 5 6 3 4 5 BUTTON STYLE 22 1 5 2 4 3 5 BUTTON STYLE 23 3 1 2 4 5 6 BUTTON STYLE 17 1 5 6 3 4 5 BUTTON STYLE 24 2 1 3 4 5 5 BUTTON STYLE 25 1 2 3 4 5 1 2 7 BUTTON STYLE 4 6 7 4 5 3 2 6 BUTTON STYLE 15 5 6 3 4 2 7 BUTTON STYLE 5 6 7 4 5 3 1 3 7 BUTTON STYLE 6 6 7 4 5 2 1 6 BUTTON STYLE 16 5 6 3 4 2 1 1 2 5 BUTTON STYLE 29 3 4 5 2 1 5 BUTTON STYLE 30 3 4 5 1 2 5 BUTTON STYLE 31 2 4 5 1 3 4 BUTTON STYLE 32 2 1 3 4 4 BUTTON STYLE 35 1 4 3 2 4 BUTTON STYLE 41 3 4 1 2 4 BUTTON STYLE 42 1 2 3 4 4 BUTTON STYLE 43 2 1 3 4 3 BUTTON STYLE 46 3 1 2 1 2 3 3 BUTTON STYLE 44 1 2

PLEASE USE THESE STYLES AS A GUIDE TO FILL OUT THE MODIFIED KEYPAD LAYOUT &

ENGRAVING FORMS ON THE NEXT PAGE

NOTE THAT SEVERAL STYLES HAVE BEEN REMOVED FROM THIS SHEET, BUT STYLE NUMBERS ARE UNCHAINED TO MAINTAIN COMPATIBILITY WITH OLDER SHEETS.

DEVICE:

C2N-CBD-P CAMEO

KEYPAD

"MODIFIED" LAYOUT

DRAWING:

4 OF 5

15 Volvo Drive Rockleigh

NJ 07647

Tel: 888-273-7876 Fax: 201-767-6011 www.crestron.com

PART #:

DESCRIPTION:

REVISION:

NOTES:

D

ATE:

C2N-CBD-P

C2N-CBD-P MODIFIED L

AYOUT & ENGR

AVING

007

3/10/2014

UPD

ATE

AVAILABLE STYLES- OTHER STYLES NOT

RENUMBERED

ON SCENE 1 SCENE 2 SCENE 3 OFF

KEYPAD TYPE E

Typical ApplicationsOffice, Conference Room, Cafeteria, Library, Multipurpose Room, Lobby, Ballroom

Button 1 Functionality: ON

›

Turn all lights on and enable daylight harvesting

›

If daylight sensor is not present, lights will turn on to 100%

Button 2 Functionality: SCENE 1

›

Recalls scene 1 settings with feedback

Button 3 Functionality: SCENE 2

›

Recalls scene 2 settings with feedback

Button 4 Functionality: SCENE 3

›

Recalls scene 3 settings with feedback

Button 5 Functionality: OFF

›

Turn all lights off to 0% and disable daylight harvesting

Button 1 Functionality: ALL ON

›

Turn all lights on and enable daylight harvesting

›

If daylight sensor is not present, lights will turn on to 100%

Button 2 Functionality: SCENE 1

›

Recalls scene 1 settings with feedback

Button 3 Functionality: SCENE 2

›

Recalls scene 2 settings with feedback

Button 4 Functionality: SCENE 3

›

Recalls scene 3 settings with feedback

Button 5 Functionality: ALL OFF

›

Turn all lights off to 0% and disable daylight harvesting

Button 6 Functionality: ▲

›

Dim lights up

Button 7 Functionality: ▼

›

Dim lights down

Custom Keypad SOO

C2N-CBD-P KEYPAD ENGRAVING SHEET

MODIFIED KEYPAD LAYOUTS

1 2 3 4 5 6 7 8 8 BUTTON STYLE 1 1 2 3 4 6 7 7 BUTTON STYLE 2 5 6 BUTTON STYLE 8 2 1 3 4 5 6 6 BUTTON STYLE 9 1 2 3 4 5 6 6 BUTTON STYLE 10 1 3 2 4 5 6 6 BUTTON STYLE 11 1 2 5 6 3 4 5 BUTTON STYLE 22 1 5 2 4 3 5 BUTTON STYLE 23 3 1 2 4 5 6 BUTTON STYLE 17 1 5 6 3 4 5 BUTTON STYLE 24 2 1 3 4 5 5 BUTTON STYLE 25 1 2 3 4 5 1 2 7 BUTTON STYLE 4 6 7 4 5 3 2 6 BUTTON STYLE 15 5 6 3 4 2 7 BUTTON STYLE 5 6 7 4 5 3 1 3 7 BUTTON STYLE 6 6 7 4 5 2 1 6 BUTTON STYLE 16 5 6 3 4 2 1 1 2 5 BUTTON STYLE 29 3 4 5 2 1 5 BUTTON STYLE 30 3 4 5 1 2 2 4 5 1 3 2 1 3 4 1 4 3 2 3 4 1 2 1 2 3 4 2 1 3 4 3 1 2 1 2 3 1 2

NJ 07647

PART #:

DESCRIPTION:

REVISION:

NOTES:

D

ATE:

C2N-CBD-P

C2N-CBD-P MODIFIED L

AYOUT & ENGR

AVING

007

3/10/2014

UPD

ATE

AVAILABLE STYLES- OTHER STYLES NOT

RENUMBERED

ON SCENE 1 SCENE 2 ALL OFF SHADES ▲ ▼

(6)

LOAD RATINGS

Dimmer Channels

DIN-1DIMU4: 4

Maximum Per Channel

5 Amps @ 120 to 240 Volts AC, 50/60 Hz

600 Watts @ 120 Volts AC

1150 Watts @ 230 Volts AC

1200 Watts @ 240 Volts AC

Load Types

Forward Phase (leading edge) or Reverse Phase (trailing edge)

Electronic Low Voltage, Incandescent, Neon/Cold Cathode,

Magnetic Low Voltage, Dimmable 2 Wire Fluorescent, and

Non-Dim Lighting

ENCLOSURE

Surface mount metal box enclosure, suitable for

mounting in plenum airspace

ENVIRONMENTAL

Temperature

32° to 104°F (0° to 40°C)

Humidity

10% to 90% RH (non-condensing)

DIMENSIONS

Height

23.5 in (597 mm)

Width

14.375 in (366 mm)

Depth

4.438 in (113 mm)

ELECTRICAL REGULATORY CERTIFICATIONS

Relays tested and certified for Electronic Ballasts according

to UL508, Section 41 (Endurance Test) and Section 61C

(Electronic Ballasts)

IEC60669-2-1, Section 19.102 (Contact mechanisms

incorporated in electronic switches, intended for fluorescent

lamp circuits or other capacitive loads)

CEC Title 24 2013 Compliant

›

4 channels of forward or reverse phase dimming

›

Auto load detection

›

120 to 240 Volt 50/60 Hz operation

GLPHASE Specifications

Date:___________________ Project:_____________________________________________________________

Quantity:_________________

Space Name:__________________________________________________________

Space Number(s): ___________________________________________________________________________________

GLPHASE______-______KP-______KP-______KP-______KP-______OS-______DS-_______-_______-_______-_______-_______-_______

©2015 Crestron Electronics, Inc. WS_2015_01

›

Page 6 of 6

Specification Worksheet

|

GLPHASE System

Products in this system can include:

DIN-1DIMU4: 4 Channel Universal Dimmer

GLS-ODT-C-CN: Dual Technology Ceiling Mount Occupancy Sensor

GLS-LOL: Open Loop Daylight Sensor

TSW-750: 7” Touch Screen

C2N-CBD: Keypad

For technical specifications on all other products in this system,

please visit

www.crestronlighting.com

For more information or to access digital specification forms for all Crestron

SpaceBuilder systems, visit

www.crestronspacebuilder.com

or call

855-644-7643

References

Download now ( PDF - 6 Page - 1.54 MB )

Related documents

BEGINNERS GUIDE TO HORSE RACING

Just like the flat, there are handicap races for hurdlers and for steeplechasers with the better class horses carrying the highest weights (usually 11st 12lb) right down to the

Automated assessment of programming assignments : visual feedback, assignment mobility, and assessment of students' testing skills

Author Petri Ihantola Name of the doctoral dissertation Automated Assessment of Programming Assignments: Visual Feedback, Assignment Mobility, and Assessment of Students' Testing

Professional Development Supports for Home Visitors and Supervisors

Our findings are based on multiple data sources, including a thorough scan of published literature and online resources; in-depth interviews with home visiting program

Technology Implementation Plan

administrators, teachers, supervisors, and the Technology Advisory Council, we have conceptualized and created a technology implementation plan which is meant to be understood as

Augmenting Mobility Simulation by Public Transport: A Case Study for the ONE Simulator

Apart from that, we have developed a bunch of tools to facilitate converting GTFS data, the most popular timetable for- mat used by public transit agencies in the world, into

The implications of growing cross-border interdependence for systems of innovation

It has been suggested that economic growth is a function of the rate of innovation and the national technological advantage, and that it is affected by the international trade

How to Painlessly Audit Your Firewalls

To maintain an effective firewall audit program, IT organizations must define network access policies, retrieve configuration data, map network interfaces, analyze configurations

The longitudinal association between homelessness, injection drug use, and injection-related risk behavior among persons with a history of injection drug use in Baltimore, MD

Homelessness and other time-varying covariates were lagged one visit to ensure temporality between these factors and subsequent injection drug use, and subsequent injection-related
