Managing security compliance
You can manage security compliance for your Power Systems™server running Linux.
Security compliance on PowerLinux
The Linux security compliance (comply) command allows you to manage security compliance on Power Systems servers running Linux. It also provides the information that is needed for security or compliance audit reports for your server.
The Linux security compliance (comply) command is a security hardening and auditing command. comply supports compliance with portions of the Payment Card Industry Data Security Standard (PCI-DSS) and Health Insurance Portability and Accountability Act (HIPAA) standards. These standards can be
implemented through automated operating system configuration.
Companies require the ability to configure systems according to government and industry compliance rules to do business in many fields. These companies need to be able to ensure that their systems have the appropriate compliance settings. In addition, they also must be able to generate reports concerning system compliance in order to satisfy audit requirements.
The comply command package is included with the following products: v IBM® PowerSC™Express Edition 1.1.3 or later
v IBM PowerSC Standard Edition 1.1.3 or later
Security compliance command requirements
The Linux security compliance (comply) command has software prerequisites. v Audit-libs libraries for audit framework
v Bash command processor
v Gettext internationalization and localization system – For Red Hat Enterprise Linux: gettext
– For SUSE Linux Enterprise Server: gettext-runtime v Libpthread.so library
v Linux Standard Base (LSB)
– For Red Hat Enterprise Linux: redhat-lsb-core – For SUSE Linux Enterprise Server: lsb-release v Java™SE
Security compliance command supported distributions
This information lists the Linux distributions that are supported by the Linux security compliance (comply) command.
The comply command is supported on the following Linux distributions: v SUSE Linux Enterprise Server 11 SP3, and any subsequent service packs v Red Hat Enterprise Linux 6.4, and any subsequent updates
Security compliance process overview
This topic provides an overview of the process for Linux security compliance using the comply command. In addition, it describes compliance profiles used by and reports produced by the comply command.
The following is an overview of the process for Linux security compliance:
1. Use a provided configuration profile or create a configuration profile that contains the security settings.
2. Run the comply command with the -f option. 3. The security settings are applied.
v The applied settings are recorded in the applied rules file. v A log file is created.
4. When needed, check the security setting by running the comply command with the -c option. 5. When an audit is requested, create a report in CSV format by running the comply command with the
-ror -R option. Optionally, use the -t option to convert to text format.
Profiles for PCI-DSS and HIPAA compliance are provided in the comply command package. After you install the package, you can find the profiles in the /etc/security/comply/core/language_code directory, where language_code is the two character ISO 639 language code, for example, “en”. The provided profiles are the following:
v Linux_PCI.xml, for compliance with the PCI-DSS standard. v Linux_Hipaa.xml, for compliance with the HIPAA standard.
You can also create your own compliance profile, either based on these profiles or based on your own unique requirements.
Reports can be output in CSV (comma-separated values) format to enable easy importing by spreadsheet applications, or in text format. Reports are stored in the /etc/security/comply/log directory, with the time stamp reflected in the file name.
Installing the comply command package
The comply command package is encapsulated in a shell archive for distribution with PowerSC. This topic provides instructions for installing the package. When updates or fixes are available, you can also use these instructions to upgrade.
Before you begin
Ensure that you have installed all the packages listed in “Security compliance command requirements” on page 1.
About this task
To unpack and install or upgrade the package, complete the following steps:
Procedure
1. Ensure that you are logged in as root user.
2. Mount the PowerSC media. On a terminal command line, enter the following command: mount -t iso9660 -r ro /dev/cdrom /media
3. Enter the following command: bash /media/comply-version-distro.ppc64.sh. In this command: v version is the version of the comply command package.
v distro is the distribution. For example:
bash /media/comply-1.0-rhel6.ppc64.sh
The license text is displayed.
Results
The installed RPM can be managed just like other RPMs. This means that it can be uninstalled with rpm -e comply run with root privileges.
comply
command
Name
The comply command aids the system administrator in setting the security configuration on systems running Linux.
Synopsis
comply -ffilename [ -p ] comply -c[ -p ] comply -c -R[ -t ] comply -c -r[ -t ] comply -dDescription
The comply command sets various system configuration settings to enable the wanted security profile. After major system changes, such as installing or updating software, run the comply command again.
Options
-c Checks the security settings against the previously applied set of rules. If the check against a rule fails, the previous versions of the rule are also checked. This process continues until the check passes, or until all of the instances of the failed rule in the /etc/security/comply/core/appliedrules.xml file are checked.
-d Displays the document type definition (DTD).
-f Applies the security settings that are provided in the specified filename configuration file. Specifying the -f option allows security settings to be consistently applied from system to system when the same profile XML is transferred to each system. The successfully applied rules are written to the /etc/security/comply/core/appliedrules.xmlfile.
-p Specifies that the output of the security rules is displayed by using verbose output. The -p option logs the rules that are processed into the audit subsystem if the system is configured for auditing.
-r Reports existing settings of the system. The output is intended to be used in security or compliance audit reports. The report describes each setting, how it might relate to a regulatory compliance requirement, and whether the check passed or failed.
The check fails if the operating system configuration does not match the last successfully applied xml profile rules that were applied to the system.
The output also includes the command or script name and arguments used. By default, the output of the report is in CSV (comma-separated values) format to enable easy importing by spreadsheet applications. The CSV output file is created in the /etc/security/comply/log directory with a file name in the format report.yyyymmmdd.HHMMSS.csv, where:
v yyyymmmdd represents the year in digits, the month in a three-character abbreviation, and the day of the month in digits.
v HHMMSS represents the hour, minute, and seconds in digits.
-R Produces the same output as the -r option, but also appends a description about each script or program that was used to implement the configuration setting. Compliance or security audits might require this level of detailed reporting.
-t Changes the -r and -R options default reporting output from CSV (comma-separated values) format to text format.
The text output file is created in the /etc/security/comply/log directory with a file name in the format report.yyyymmmdd.HHMMSS.txt, where:
v yyyymmmdd represents the year in digits, the month in a three-character abbreviation, and the day of the month in digits.
v HHMMSS represents the hour, minute, and seconds in digits.
Parameters
filename
The configuration file, in xml format, that contains the security settings. Root permission is required to access this file.
Security
The comply command is executable only by root.
Examples
1. To apply the security settings from a configuration file, use the following command:
comply -f /etc/security/comply/core/myPreferredSettings.xml
2. To check the security settings that were applied to the system, and to log the rules that failed in to the audit subsystem, use the following command:
comply -c -p
Location
/usr/sbin/comply
Contains the comply command.
Files
/etc/security/comply/core/language_code/Linux_Hipaa.xml
Profile that is provided with for comply command package for compliance with the HIPAA standard.
/etc/security/comply/core/language_code/Linux_PCI.xml
Profile that is provided with for comply command package for compliance with the PCI-DSS standard.
/etc/security/comply/core/appliedrules.xml
Contains an xml listing of applied security.
/etc/security/comply/log/comply.log
Contains a trace log of applied security settings. The logging method does not use syslog. The
complycommand writes directly to the file. The file has read/write permissions, and requires root security.
/etc/security/comply/log/report.yyyymmmdd.HHMMSS.csv
Contains the report output from the comply command in CSV format.
/etc/security/comply/log/report.yyyymmmdd.HHMMSS.txt
Contains the report output from the comply command in text format.
Additional information about Linux on Power security
Additional security information is provided by each Linux distribution. Refer to the following links to stay up-to-date with additional information about security for Linux on Power®systems.
Security information for Red Hat Enterprise Linux
If you are an entitled Red Hat Enterprise Linux user, you can subscribe to Red Hat security advisories. If you are not an entitled user, you can monitor the Red Hat Security Advisory list archive.
To download security updates and check that they are applied to particular machines, you can subscribe to the Red Hat Network (RHN).
Security information for SUSE Linux Enterprise Server
Security alerts, patches, and announcements for SUSE Linux Enterprise Server are available from the SUSE Linux Enterprise Server Security page.
Security information for Ubuntu
Security notices for Ubuntu are available from the Ubuntu security notices page.
IBM Product Security Incident Response (PSIRT)
The IBM PSIRT website contains important information regarding security vulnerabilities that may affect IBM products and solutions.
