For Desktop Virtualization and Cloud Computing

(1)

For Desktop Virtualization

and Cloud Computing

(2)

Introducing SyncMaster Cloud

the evolution of the Monitor is Complete

SyncMaster Cloud is a whole new class of professional-grade monitors specially designed for

desktop virtualization and cloud computing. The SyncMaster Cloud connects directly to the network

so there is no need for a separate PC or thin-client at the employee’s desk – just the Cloud display.

With Cloud displays, employees can access their computing resources from a slim, clutter-free and

energy-efficient monitor. Organizations can centralize sensitive data into the data center or cloud

where it can be protected. Cloud displays also improve productivity by centralizing IT support and

minimizing employee downtime.

(3)

Key Benefits

Strengthen Data Security

Centralize sensitive data to a secure,

managed environment where it can be

protected and backed up. The SyncMaster

Cloud does not have a disk drive to store

data, so confidential data is protected from

hackers and unauthorized users.

Lower Support Costs

With Cloud displays, most maintenance and

support tasks can be performed centrally

– no need to visit the employee’s desk.

Software patches and upgrades can be made

simultaneously to all Cloud displays.

Cloud displays require very little on-site support

so most issues can be fixed remotely to minimize

employee disruption. Improve employee work

areas by eliminating the bulky PCs which take up

precious space and clutter the work area with a

tangle of cables.

Reduce Electricity Use by 60%

Reduce electricity use by eliminating the need for

a separate PC. The SyncMaster Cloud connects

directly to the network so there is no need for a

power-hungry PC. Electricity can be cut by at

least 60% when compared to a traditional PC

and monitor setup.

Rely on Legendary

Samsung Quality

SyncMaster Cloud displays are engineered

with the latest display technologies and

built with high quality components by the

world leader in displays.

Migrate Seamlessly to Desktop Virtualization

Samsung has partnered with leading desktop virtualization companies

including VMware

®

_{, Citrix}

™

_{, Cisco}

™

_{, Microsoft}

®

_{and Teradici}

™

_to

provide the widest choice in desktop virtualization platforms. Cloud

displays can be deployed quickly and are available in a variety of

sizes and form factors for maximum flexibility.

(4)

All-in-One Design

Create more workspace

by

eliminating the need for

a separate PC or thin-client.

Only the monitor, keyboard and

mouse are on th

e desk.

Enhanced Connectivity

Connect peripherals right from

the display. Cloud displays have

multiple ports to connect to most

peripherals.

Superior Ergonomics

A Height-Adjustable Stand (HAS)

that also tilts and swivels ensures

adjusability that accomodates

any user

.

Integrated Speakers

(optional)

Create a sleek, compact design and

reduce cable clutter even further with

integrated speakers.

MagicRMS

™

_{Pro Software}

Manage the thin-client Cloud displays

from a central location with Samsung’s

MagicRMS Pro software. Zero-client

Cloud displays can be managed with

Teradici management console.

MagicRMS Pro Remote Control Status Monitoring Reporting S/W Installation Easy To Use Asset Mgmt.

Key Features

Universal Power

Over Ethernet

Power the display directly from the

Ethernet cable with Samsung’s

Cloud display model NC220P, which

works with Cisco’s Universal Power

Over Ethernet (UPOE

™

_{) technology.}

This requires connection to Cisco

Catalyst 4500E switch.

(5)

Cloud displays are ideal for organizations that want to improve productivity, lower support costs and protect sensitive data.

Ideal Sectors & Deployments

HealtHcare

Ideal For:

Provide doctors with high-resolution, professional-grade displays for viewing

charts and images. Create more work space in crowded areas. Secure

confidential medical records in the data center while providing medical staff

roaming profiles as they make their rounds. Minimize IT-related disruption in

patient areas by centralizing most support tasks.

• Nurses’ Stations

• Emergency Rooms

• Patient Rooms/Wards

• Admissions/Administration

• Labs and Exam Rooms

BusIness

Ideal For:

Improve IT and employee productivity while cutting operating costs. Employees

enjoy a clutter-free work space with high-quality monitors and ergonomic

features for a more productive work environment. IT reduces service calls and

centralizes end-user computing. And management enjoys dramatically lower

electricity and support costs.

• Customer Support Centers

• Administrative Offices

• Branch/Remote Offices

• Factories

• Warehouses

educatIon

Ideal For:

Expand computing access to students by deploying more computing stations

in crowded computer labs, classrooms and libraries. Reduce maintenance

and support costs by managing the entire student and faculty computing

infrastructure from a centralized location. Lower the risk of breakage or theft by

replacing the PC/monitor with just the Samsung SyncMaster Cloud.

• Computer Labs

• Classrooms

• Libraries

• Administration

• Common Areas

FInancIal servIces

Ideal For:

Migrate to Virtual Desktop Infrastructure (VDI) with the SyncMaster Cloud.

Provide bank tellers and loan officers with secure clutter-free computing

that requires minimal on-site maintenance. Provide power traders with high

availability computing and dual-monitor displays. Provide customer service reps

ergonomic displays that can be adjusted to their personal needs.

• Bank Branches

• Trading Floors

• Customer Contact Centers

• General Offices

• Disaster Recovery Sites

Government

Ideal For:

Harden data security by centralizing sensitive data to a secure cloud or data

center. Reduce IT staff’s end-client workload so they can focus on more critical

IT priorities. Improve employee productivity by reducing work space clutter

and providing high-resolution displays that can be adjusted to each

employee’s needs.

• State and Local Services

• Federal and Central Agencies

• Emergency Response Centers

• Military/Intelligence Analysis

• Remote Locations

(6)

(7)

VGA In (Mirrored Monitor Support) DVI Out (Dual Monitor Support)

Audio In Mic In Headphones Out 1 2 3 7 8 9 10 DC 14V RJ45 LAN RJ45 LAN Hub 6 4 5 6 7 8 9 10 1 2 3 4 5

Monitor Left Side Monitor Right Side

RS-232C Serial Port USB 1.1

Zero-Client Cloud Displays: NC Series

Category Features NC Series System Processor Teradici Tera1100

Graphics N/A

RAM 128MB

Memory N/A

Ethernet Gigabit Ethernet

Software Server OS Support N/A

Remote Management Teradici Management Console

Panel Viewable Sizes 19”, 22”, 24”

Backlight Type 19” (CCFL), 22” (LED), 24” (CCFL) Brightness (typical) 250 cd/m2

Contrast Ratio (typical) 1000:1

Viewing Angle (H/V) 170º / 160º (CR≥10) 178º / 178º (CR≥5) Response Time (G to G) 5 ms

Maximum Resolution (H x V) 1680 x 1050 (22") Colors Supported 16.7 million

Ergonomics Tilt / Pivot / Swivel / Height Adjustable

Connectivity Input / Output VGA In (Mirrored Monitor Support) DVI Out (Dual Monitor Support) RJ45 Ethernet LAN RJ45 LAN Hub USB 1.1 RS-232C Serial Port Headphones Out Audio In Mic In

Power Typical 38 watts

Standby 0.8 watts

Accesory

(optional) Speaker 1.0 w x 2

Wall Mount Bracket VESA 100 x 100

ConneCtivity

(8)

Category Features NS Series System Processor Teradici Tera1100

Graphics N/A

RAM 128MB

Memory N/A

Software Server OS Support N/A

Remote Management Teradici Management Console

Panel Viewable Sizes 19", 21.5", 24" Backlight Type LED Brightness (typical) 250 cd/m2

Contrast Ratio (typical) 1000:1 Viewing Angle (H/V) 170 º / 160º Response Time (G to G) 5 ms Maximum Resolution (H x V) 1440 x 900 (19")

1920 x 1080 (21.5") 1920 x 1200 (24") Colors Supported 16.7 million

Ergonomics Tilt / Pivot / Height Adjustable

Connectivity Input / Output VGA In

VGA Out (Mirrored Monitor Support) RJ45 Ethernet LAN USB 1.1 Headphones Out Audio Out Mic In DVI In DVI Out RS-232C (9 pin D-SUB)

Power Typical 35 ~ 45 watts

Standby 1.5 watts

Accesory

(optional) Speaker None

Zero-Client Cloud Displays: NS Series

ConneCtivity

11 10 12 13 14 8 9 7 1 2 3 DVI In VGA In DC 14V In (connects to ) 1 2 Mic In Headphones Out USB 1.1 3 4 5 6 USB 1.1 RS-232C Serial Port RJ45 LAN Audio Out 7 8 9 10

VGA Out (Mirrored Display) DVI OUT DC 14V Out DC 14V In 11 12 13 14

Monitor Side Stand Side Stand Back

13

4 5 6

(9)

Thin-Client Cloud Displays: TS Series

Category Features TS Series

System Processor AMD Ontario 1.0GHz Dual Core Graphics AMD Radeon HD6290

RAM 1GB DDR3 (Citrix), 2GB DDR3 (WES7)

Memory 8GB SSD

Software Client Support TSXXXW

OS: Windows Embedded Standard 7 Client SW:

- Microsoft RDP/RemoteFX - Citrix Online Plug-in - VMware - Enhanced Write Filter - Internet Explorer - Media Player

TSXXXC

OS: Linux

Client SW: Citrix Receiver 11.1 Server Support TSXXXW

Citrix XenApp/Citrix Presentation Server, XenDesktop, VMware View, MS Windows TS2003 2008 RT

TSXXXC

Citrix XenApp/Citrix Presentation Server, XenDesktop Remote Management MagicRMS Pro

Panel Viewable Sizes 19", 21.5", 24"

Backlight Type LED

Brightness (typical) 250 cd/m2

Contrast Ratio (typical) 1000:1 Viewing Angle (H/V) 170º / 160º Response Time (G to G) 5 ms Maximum Resolution (H x V) 1440 x 900 (19")

1920 x 1080 (21.5") 1920 x 1200 (24") Colors Supported 16.7 million

Ergonomics Tilt / Pivot / Height Adjustable

Connectivity Input / Output VGA In

VGA Out (Mirrored Monitor Support) RJ45 Ethernet LAN

USB 2.0 RS-232C Serial Port Headphones Out/Audio In/Mic In DVI In/DVI Out

Power Typical 25 ~ 35 watts

Standby 0.8 watts

ConneCtivity

Processor built in base of stand

10 116 8 9 7 12 13 DVI In VGA In DC 14V In (connects to ) 1 2 Mic In Headphones Out USB 2.0 3 4 5 6 USB 2.0 RJ45 LAN Audio Out 7 8 9 VGA Out (Mirrored Display) 11 1 2 3 4 5 6 7 8 9 11 1 2 3 4 5 6 7 8 9 10 DVI OUT 11 DC 14V Out 12 DC 14V In 13

Monitor Side Stand Side Stand Back

13 13 12

(10)

ConneCtivity

Cloud Stand Series Options

Category Features WS Stand (Zero Client) TB-WH / TB-CH (Thin Client) System Processor AMD Ontario 1.0GHz Dual AMD Ontario 1.6GHz Dual

Graphics AMD Radeon HD6250 AMD Radeon HD6310

RAM 2GB DDR3 TB-WH

2GB DDR3

TB-CH

1GB DDR3

Memory 8GB SSD 8GB SSD

Ethernet Gigabit Ethernet Gigabit Ethernet

Software Client Support OS: Windows Standard 2009 Client SW:

- Microsoft RDP - Citrix Online Plug-in - VMware - Enhanced Write Filter - Internet Explorer - Media Player

TB-WH

OS: Windows Standard 2009 Client SW:

- Microsoft RDP - Enhanced Write Filter - Citrix Online Plug-in - Internet Explorer - VMware - Media Player

TB-CH

OS: Linux

Client SW: Citrix Receiver 11.1 Server Support Citrix XenApp/Citrix Presentation Server,

XenDesktop, VMware View, MS Windows TS2003 2008 RT

TB-WH

Citrix XenApp/Citrix Presentation Server, XenDesktop, VMware View, MS Windows TS2003 2008 RT

TB-CH

Citrix XenApp/Citrix Presentation Server, XenDesktop

Remote Management MagicRMS Pro MagicRMS Pro

Ergonomics Simple Pivot / Height Adjustable

Connectivity Input / Output RJ45 Ethernet USB 2.0

Headphones Out/Audio In/Mic In VGA Out, DVI Out (Dual Monitor Support)

RJ45 Ethernet USB 2.0

Power Typical 15~30 watts 25~40 watts

Standby 1.8 watts 1.8 watts

Accesory

(optional) Wall Mount Bracket VESA 100 x 100 VESA 100 x 100, 75 x 75

7 86

5 6

4 9

Stand Side Stand Back

1 2 3 Mic In Headphones Out USB 2.0 USB 2.0 RJ45 LAN Audio Out VGA Out DVI OUT

(Dual Monitor Support) DC 14V In 1 2 3 4 6 7 8 9 5

TB-WH / TB-CH

WS-Stand

(11)

ConneCtivity

Zero-Client Cloud Displays: NB Series Cloud Stand

Desktop Virtualization Alliances

Category Features NB-NH (Zero Client) System Processor Teradici Tera1100

Graphics N/A

RAM XDR 128MB

Memory N/A

System Client Support OS: N/A Server Support VMware View Remote Management MagicRMS Pro

Ergonomics Pivot, Height Adjustable

Connectivity Input / Output RJ45 Ethernet USB 2.0

Power Typical 20 watts

Standby 1.5 watts

Accesory

(optional) Wall Mount Bracket VESA 100 x 100, 75 x 75

All Samsung Cloud displays are VMware Ready certified.

VMware Ready is a comprehensive validation program

that ensures customers that the products have passed

VMware-specified integration or interoperability criteria.

EMC Corporation is a global leader in enabling businesses

to transform operations. Samsung and EMC are driving

VDI adoption with integrated offerings in various

industries throughout the world.

All thin-client Cloud displays are Citrix Ready certified.

Citrix XenDesktop delivers high-performance computing

sessions with the user-experience of a traditional PC,

but optimized for network resources.

All thin-client Cloud displays include RDP and

Microsoft® RemoteFX™ support. RemoteFX enables

the delivery of a full Windows user experience. The

thin-client Cloud displays are available with Windows

Embedded Standard 7.

Samsung Cloud display model NC220P is the first

integrated zero-client display in the world to take

advantage of Cisco’s Universal Power Over Ethernet

(UPOE). When connected to a UPOE-enabled switch, the

NC220P is powered directly from the LAN cable.

The zero-client Cloud displays use the Tera1100 chipset

and PCoIP protocol which support high resolution, full

frame rate 3D graphics, HD media, full USB peripheral

connectivity, and high definition audio.

Mic In Headphones Out USB 1.1 USB 1.1 RS-232C Serial Port RJ45 LAN Audio Out VGA Out DVI OUT

(Dual Monitor Support) DC 14V In 1 2 3 4 6 7 8 9 10 5 5 6 7 8 9 10 1 2 3 4 Stand Back Stand Side

(12)

Product Support: 1-866-SAM-4BIZ • 1-800-SAMSUNG

©2012 Samsung Electronics America, Inc. Samsung is a registered mark of Samsung Electronics Corp., Ltd. Specifications and design are subject to change without notice. Non-metric weights and measurements are approximate. All brand, product, service names and logos are trademarks and/or registered trademarks of their respective manufacturers and companies. Printed in the USA on 50% recycled (25% post-consumer waste) paper using soy inks. MON-CLOUDDISPLAYBRO-APR12T
