TANK TRUCK FLEET & WORKFORCE
MANAGEMENT SOLUTION
High Security Locks & Keys
Access Control
Time & Attendance
Key Management
Company Profile
Acsys is a global leader in the emerging field of mechatronics access
control. With technology originating from two famous French defense
contractors in 1999, Acsys products and solutions provide a powerful
means to control who goes where and when, indoors and outdoors,
without wiring and without reliance on a power supply.
A highly specialized international team delivers world-unique, patented
solutions. From the Code Generation System (CGS) and Keypad Key to
remote staff management via the AcsysMobile App, the modular and
solution-oriented approach sets Acsys apart from other security
competitors. With top-tier clients in the public and private sectors
extending across telecommunications, banking, power, mining, logistics,
luxury shops, aviation and more. Acsys proves why it’s all about security
& productivity!
Market Scope
MINING
MILITARY
MUSEUMS
OFFICES
PORTS
LOGISTICS
RETAIL
GOVERNMENTWATER
COMPANIES
ATM
WAREHOUSES
AIRPORTS
HOSPITALS
POWER
STATIONS
TELECOM
BANKS
GUARDING
RAIL
&METRO
RESIDENTIAL
CONTAINER
HOUSES
Acsys Solution
Decide and Control Who Goes Where and
When Access Control System
Verify What Work was Done, Where, and
When No Copied Keys
No Picked Locks
No More Tracking of Lost/Stolen Keys and Lock
Changes
High Security Lock & Key System Key Management System
Acsys System Introduction
LED light on the Acsys Keys gives user information:
GREEN– ACCESS GRANTED
ORANGE – ACCESS DENIED AT THIS TIME RED – ACCESS DENIED
4 blinks (color depending on the above) – LOW BATTERY
AcsysLocks CANNOT be
BUMPED or PICKED and
are very hard to DRILL
The COMMUNICATION between locks, keys, software and all its data is encrypted using 128-bit
AES ENCRYPTION, making the keys IMPOSSIBLE to COPY
Since there is no power in the locks. We can offer Euro – DIN cylinders and padlocks in
various sizes All models are
Wire-Free EASY to Install EASY to Maintain
The ONLY power source for the Acsys system comes from the key. Typical Battery life-time =
2 years
Acsys Keys have a built-in CLOCK and CALENDAR So we can assign temporary access rights (Mon-Fri) and also limited in time (08:00 – 18:00)
The key has a chip that can be programmed to open one or up to 100,000 locks
The lock has a built-in chip that can be programmed to accept the entry of
1,000,000 keys
The key and lock each have a built-in MEMORY that keeps track of the last
1,000 events, WHO went WHERE and WHEN
LOST/STOLEN KEYS can be DELETED from the system and
from the locks where it had access
The Acsys keypad key is the best protection against lost/stolen keys. If someone finds a lost/stolen key, they cannot use it as a PIN is needed to be entered on to the key before usage. If someone inputs
Activity Reports Acsys Keys can be fitted with a Proximity / RFID
coil allowing the user to use the key as a badge (optional)
Acsys Mechatronic VS Traditional Mechanical
• Keys are usually distributed to users or stored in a central location, which requires people spend time to collect, return and manage those keys.
• Keys are often copied leading to theft/degradation and as a result unbudgeted maintenance, leading to service interruption.
• Once distributed there is no control over where and when the mechanical key is used.
• There is little or no traceability on how long the user spent on a site and this can have serious financial impact on operations, especially on remote sites.
• Mechanical locks are not safe and can be easily bumped/picked providing no security for the site.
• Technicians sometimes leave the doors open, making it easy for thieves to enter and degrade/steal from the site.
• Despite security measures such as high walls, barbed wire and guards, thefts still occur on a daily basis as they are usually inside jobs.
Acsys Mechatronic Solutions
• The Acsys solution offers controlled and secured access rights distribution. • Acsys locks CANNOT be picked or bumped and are very difficult to drill.
• Keys are programmed ONLY when they need to be used and their access rights are TIME-BASED. The main advantage is that keys can ONLY be used during the time the operator has configured them to work.
• The Key memory will tell the operator WHEN the key was used (date/time) and when the lock was opened and closed, giving the operator CONTROL over the amount of time spent by suppliers on sites (and the cost of the intervention). • Keys cannot be copied, so no access is possible outside the access rights working
hours.
• If someone TRIES to access without having rights, that will be stored in the key and lock.
• Access can be granted to SPECIFIC SITES and SPECIFIC ASSETS on those sites. • If 3 WRONG codes are entered on the Keypad/CGS key it will automatically DISABLE
Why Acsys ?
USE ONE KEY FOR EVERY TRUCK ONE SOLUTION FOR EVERY PLACE EASY TO INSTALL & MAINTAIN
EASY TO CHECK WHERE THE KEY
WAS USED AND WHEN LOST ACSYSKEY=NO LOCK CHANGE LOST MECHANICAL KEY=LOCK CHANGE CONTROL WHERE AND WHEN USERS CAN OPEN THE LOCK VERIFY WHERE AND WHEN USERS OPEN THE LOCK
Activity Reports Activity
Reports
Office Gates Truck Assets
Mon– Fri
24hrs 365Days 24hrs 08:00-20:00 Mon—Fri
Where and When was it used?
Tank Truck Fleet and
Workforce Management Solution
Project Background
A state-owned petroleum company with the core business in oil, gas, renewable and new energy.
Currently, there are needs to upgrade the existing passive one-time used security seal/tape solution on tank truck to
improve the monitoring and control of the goods and assets throughout the whole distribution process.
Secondly, despite some trucks have already fitted with GPS monitoring system, there is no correlation and
computerized automation and integration with the security seal/tag solution. This makes the total fleet management
solution less secure and less effective.
•Data:
–
650 tank trucks in CITY A and only a small amount is fitted with GPS In-vehicle system
–
Each tank truck has 2-5 compartments and each needs 2 Padlocks
–
1 deport in CITY A
Key Components of the Solution
Acsys
Logistics
is a GPS location-based fleet and
workforces management solution for enterprise.
Through Acsys in-house GPS location system or by
integration with an existing GPS system, AcsysLogistics
provides the administrator a Live Dashboard (G.I.S.)
showing WHERE about and WHAT status are the vehicles
in real-time.
The Live Dashboard also provides up-to-date real time
information of keys and locks activities. The dashboard
identifies the location of each locks, the location of each
key user and their activities on and off the job sites.
Through the power of the integrated Google maps GIS
system, the control center can quickly pin-point where
and by whom the activity is taking place.
AcsysLogistics means SECURITY, VISIBILITY, EFFICIENCY
& PRODUCTIVITY and FLEXIBILITY in managing the
SECURITY
•
Key lost/stolen/no return = lock change
•
Key is easy to be copied
•
Key is copied = Lock change
•
Locks can be bumped/picked easily
•
Padlocks in used can be “pretended” to be closed
•
Key lost/stolen/no return = No need change lock
•
Key cannot be copied
•
Locks cannot be picked, bumped and hard to drill
•
Each open/close of lock is clearly visible and recorded
in the system
•
AES 128-bit encryption
VISIBILITY
•
Many keys are in used and hard to manage and
control usage
•
Cannot control who Attempts to open the
unauthorized lock(s) and no record on such
attempts
•
Record who, when, where and use the key for how
long
•
Access logs on both keys and locks show who
attempts to open the unauthorized lock(s)
•
Key auto-blocked after 5 attempts to open
unauthorized lock(s)
EFFICIENCY &
PRODUCTIVITY
•
Operators need different keys for different locks for
different fuel brand trucks
•
Operators need to collect/return keys before/after
used
•
No Record information about who goes where,
when for how long
•
One key per operator
•
One key can open all locks depending on the Access
Rights (No picking and breaking of lock due to
lost/no return keys)
FLEXIBILITY
•
Specific locks only can be used on specific trucks to
specific destinations
•
Specific key only can open specific lock
•
Any lock can be used on any truck to any
destination
•
One key for any lock(s)
Advantages
Acsys solutions answer to …
Advantages
SECURITY
VISIBILITY
EFFICIENCY &
PRODUCTIVITY
FLEXIBILITY
•
Where are the trucks/assets?
•
Is the truck locked (Locks closed)?
•
Is the truck
loaded/unloaded/half-loaded?
•
“ALARM” Why is an unlocked and
loaded truck moving? E.g. theft,
violation of work process etc.
•
“ALARM” Why is a locked and
loaded truck not moving? E.g.
accident on site, broken down etc.
Monetary Benefits of Implementing Acsys Solutions
• As any Acsys lock can be used on any truck to any destination, no more time/energy/money wasted in collecting/returning/managing lock-key matching.
• The control center now has control over which trucks/sites need servicing and when and can verify how much time users spent on doing specific jobs, which allows to set KPI’s for certain tasks to increase operational efficiency.
• As Acsys keys are impossible to copy and Acsys locks are impossible to pick/bump or even vandalized, there is no more need to have security guards on site, unauthorized access is eliminated. As well as to prevent vandalism to gain access to any assets.
Efficiency
Safety
• With mechanical systems when keys are lost/stolen/misplaced/copied, usually time, energy and money needs to be spent changing the locks. With the Acsys system, keys can only be activated through the software meaning that if a key is lost / stolen / unreturned only the software needs to be updated.
• As the access to every oil truck is now remotely controlled, we see a great reduction in theft, which is often inside jobs due to the fact that keys are copied and then used illegally. • Since Acsys locks require no
maintenance and Acsys keys only need battery replacement 1x/year, the OPEX cost of running the Acsys system is minimal meaning little or no recurrent expenditure after deployment.
• Through a better management , insurance premiums in some countries can be significantly lowered as the risk for the insurance company is reduced.
Cost Reduction
Data
• The control center can view how long the users have spent on doing specific jobs, giving them a complete overview over billable hours. • Through implementation of the
Acsys solution access to site/assets is simplified but now also logged in real-time, so adherence to SLA’s can now be verified.
• The software reports allow the control center to detect abnormal patterns of user behavior and act upon them, collusion between employees to circumvent the system is impossible.
Acsys Keys are “SMART”
Key Features:
•One key can open up to 100,000 locks
•
Keys keep track of the last 1,000 events (WHEN, WHERE, HOW LONG)
•
Keys are encrypted with AES 128bit so they cannot be copied
•
Keys power the lock. Typical battery life is 1 year or 25,000 times of access
•Keys can be programmed to work at different times and/or days for
different locks
•
Keypad key (optional) only works after correct passcode/PIN is entered to
prevent unauthorized people from using the key
•Keys can be fitted with Mifare® coil (optional) and used as badges in
traditional access control system
Applications:
• Time & Attendance: Record user’s activities
•
Access control: Access locks depending on Access Rights
Acsys Keys are “SMART”
Key Features:
•A special key for Security Guard only
•
GKey CANNOT open/close locks
•
Guard uses GKey to verify and download the Access Logs of locks (WHO,
WHEN, WHERE, HOW LONG, WHAT), i.e. lock opened/closed by who at
what time and for how long
•
GKeys can access 250 locks each time
•
Gkeys are encrypted with AES 128bit so they cannot be copied
•
GKeys power the lock. Typical battery life is 1 year or 25,000 times of
access
•GKeys can be programmed to work at different times and/or days for
different locks
•
GKeys can be fitted with Mifare® coil (optional) and used as badges in
traditional access control system
Applications:
•
Time & Attendance: Record Guard’s activities
• Access Monitoring: Verify and download Access Logs from locks to get
computerized record of WHO, WHEN, WHRE, HOW LONG and WHAT
•
Patrol Guard: Guard uses key for regular patrol tour operations
Acsys Keys are “SMART”
Key Features:
•One key can open up to 100,000 locks
•
Keys keep track of the last 1,000 events (WHEN, WHERE, HOW LONG)
•
Keys are encrypted with AES 128bit so they cannot be copied
•
Keys power the lock. Typical battery life is 1 year or 25,000 times of access
•Keys with patented keypad to prevent unauthorized usage. Two-factor
authentication for enhance security
•
Keys work on a random, single-usage, time-limited passcode generated by
the Acsys’s patented CGSPlus system only
•User must request the passcode from the system and enter to the key
before usage
•
Keys can be fitted with Mifare® coil (optional) and used as badges in
traditional access control system
Applications:
•
Access control: Access locks depending on time-limited, random and lock
specific passcode. Administrator has full control of user’s key usage and
access rights can be issued on demand based only.
Work Processes
A: Depot GATE IN
B: Depot GATE OUT
C: Field Stations
D: In Transit (Accidental /
Emergency Open)
A: Depot GATE IN
1. Operator A arrives at work & logs-in his attendance with key and gets access rights for the day
3. At preset intervals or at end of duty, the operator logs-out his attendance
To Refilling Zone 2. Operator A can ONLY OPEN locks to which he was given access
4. Control center receives daily detailed report of key usage
Activity Reports
ADMINISTRATOR CONTROL SERVER CENTER
B: Depot GATE OUT
3. Guard visually check RED marks on locks and inserts GKey to each lock to VERIFY locks are properly closed 1. . Operator B arrives at work & logs-in
his attendance with key and gets access rights for the day. Guard arrives at work & logs-in his attendance with his GKey.
2. Operator B can ONLY CLOSE locks to which he was given access
5. GPS will detect and monitor the movement of the truck. The software
GPS System
“ALARM”
6. Control center receives daily detailed report of key usage (WHEN, WHERE,
ADMINISTRATOR CONTROL SERVER CENTER
Activity Reports
CONTROL CENTER
GEO-FENCE
4. After verifying all locks on truck(s), Guard inserts GKey to programmer to
GEO-FENCE
C: Field Station
1. Truck is fitted with GPS location tracking system and Acsys In-vehicle Programmer
2. GPS verifies truck at correct location. Field Station operator inserts key to In-vehicle Programmer to get access rights for locks
GPS System
3. Operator ONLY OPEN/CLOSE locks which he is authorized and this based on location
ADMINISTRATOR CONTROL SERVER CENTER
IN-VEHICLE GPS
TERMINAL USB/RS232/RS485 DATA GPRS
5. GPS detects truck moves out of the GPS “GEO-FENCE” (i.e. Field Station), the software will ALARM if not all locks are locked
GPS System
“ALARM”
4. After job done and insert key to programmer, Access logs are automatically uploaded and any
IN-VEHICLE PROGRAMMER
Activity Reports
D: In Transit
D: In Transit (Accidental / Emergency Open)
ADMINISTRATOR CONTROL SERVER CENTER
2. Driver has a CGSPlus passcode key but NO passcode
REAL-TIME REAL-TIME
3. Driver CALL/SMS Administrator for a random, single-usage, time-limited passcode to OPEN/CLOSE locks
4. Driver ONLY OPEN/CLOSE locks which he is authorized
Consolidated Reporting
System
CONSOLIDATED REPORT
Consolidated Reporting System
Acsys
Logistics
GPS
Fleet
Management
Reports on trucks
•
Positions
•
Speed
•
Routing
•
Driving behavier
•
Etc.
Acsys Solution Architecture
and
Acsysware Architecture
Multi-Site/Region/Operator
Region A
Region B
Region C
Region D
HQ CONTROL CENTER
Sub-region 1 Sub-region 2 Sub-region 1 Sub-region 2 Sub-region 1 Sub-region 2 Sub-region 1 Sub-region 2
Program
and
Audit
keys in a combination of
USB/LAN/CGS/BLUETOOTH/3G depending on operational needs
Global access and audit Reports
Regional access and audit Reports
Sub-regional access and audit Reports
Request & validation
Req ues t & v al id at io n Si te A cc es s
Local Programming (USB/IP)
Control Center Acsys software
Country HQ LAN/WAN ZONE A LAN/WAN ZONE B Regional HQ 1 VPN VPN
USB
IP
USB Computer Activity Reports Regional HQ Refueling company Maintenance company Guarding companyCENTRAL LOCATION
MUTIPLE LOCATION
Regional HQ Refueling company Maintenance company Guarding companyCENTRAL LOACTION PROGRAMMING(USB):
The most basic way to program Acsys locks and keys is using a programmer connected directly to the USB port on any computer running the Acsysware client. This requires the physical presence of the key at the time of programming. Access rights are created in the software and uploaded to the programmer. By simply inserting the key into the programmer, access rights are downloaded to the key’s memory. Logs of the key’s usage can be uploaded to the database in
MUTIPLE LOCATION PROGRAMMING(IP):
IP Programmers allow for distributing access rights across a virtual private network (VPN). It allows for access rights to be created and downloaded later, as well as real-time notification of site access by a user. As each programmer has its own IP address, an access right can be assigned to one specific programmer (to require presence at a specific location) or to all programmers across a company’s operations (for convenient downloading/uploading).
Acsys Locks Acsys Keys
Local Programming (USB/IP)
1. The user has an Acsys key
with NO access rights 2. Access rights are downloaded to the key when inserted into the USB/IP Programmer
3. The key downloads the TIME LIMITED access right
from the USB/IP programmer (ex 8:00-12:00 lock 24/25/32)
4. The user opens the lock within the fixed time (ex 08:00-12:00)
8. Access logs are automatically uploaded and any remaining rights are deleted from the key
7. The user goes back to the office inserts the key into the USB/IP programmer
6. The user finishes work and
close locks 5. The user carries out the task (ex 8:00 - 12:00)
Activity Reports
Activity Reports
ADMINISTRATOR CONTROL SERVER CENTER
The Acsys Code Generating System Plus (CGSPlus) is a simple, yet powerful way to manage access to remote sites and assets in real-time. Through a phone and an Acsys CGSPlus Key with Keypad, the control center can grant access rights in real-time and be notified of site arrival and exit and accessing of assets.
The patented CGSPlus solution is offered exclusively by Acsys and is a unique approach to remote site access control.
The concept is simple, every user now has a key but none of the keys can be used UNTIL a random, single-usage, time-limited code is created by the software for the key(s).
Whenever a user requires access to a site or asset, he needs to request the code by call/SMS to the control center. Upon verification of user credentials the code will be issued to the user, who in turn enters it on the key, granting him access and ONLY on the site and assets that the control center wants the user to access.
The Acsys CGSPlus solution is the safest and most convenient way to control access to remote sites without the need for picking-up or returning keys.
Acsys CGSPlus Solution (Remote Key Activation)
CGS Working Principle
ANY
PHONE PHONE ANY
SMS
OPERATOR
Remote key Activation (Call/SMS)
1. The user has a passcode key and needs access to some locks
2. The user calls the operator, gives his PIN, then receives a code to use the key
4. The user can now use the key on the specified locks for a defined duration (5min/30min/1HR/8HRS)
3. The user inserts code to use the key, GREEN FLASH= can use the key
1. The user has a passcode key and needs access to some locks
2. The user sends SMS and his PIN requesting access, then gets a code to use the key
4. The user can now use the key on the specified locks for a defined duration (5min/30min/1HR/8HRS)
3. The user inserts code to use the key, GREEN FLASH= can use the key
CALL
CODE
CODE
Acsysware Introduction
Acsysware is a Key and Lock Management System specifically designed for industrial clients. It manages electronic keys and mechatronic locks patented by Acsys Technologies Ltd.
Acsysware provides an intuitive and comprehensive user interface which allows a user to easily manage the keys and the locks.
Acsys system solves all issues related to mechanical locking systems such as bumping locks, lost keys. Furthermore it provides a revolutionary platform to control who, where, when and how each lock is accessed by a key user. Acsys hardware and software is protected with the most powerful and standardized encryption methods ,AES-128 bit, which prevents key duplication.
Acsysware is supported by one of the most scalable and most stable databases, MS SQL Server 2008 R2, which permits the software platform to be installed across the network. Acsysware’s wizard-like experience is designed to carry out error-free management of the keys and the locks.
The reporting tool provides up-to-date information about all activities performed on the hardware and the software such as: access logs, keys and locks list, deleted keys and locks list, transfer keys operations, account operations, and user code requests. All reports can be exported in multiple formats such as PDF, XLS and CSV formats.
Furthermore ,with the new email notification services the reports can be sent to individual users or user groups on a
Prevent Locks Swapping
Cording
A
B
Fix the lock to truck by
welding the shackle and metal chain
Fix the lock to truck by
Acsys GPS Padlock Solution
• The Acsys GPS padlock is a standard PL5 padlock that is equipped with an additional GPS module that will transmit its position at pre-set intervals • The GPS padlock solution allows you to secure any asset, control when the asset is being used and by whom, but also allows you to monitor its position and track it when it is being moved • The GPS padlock is battery-operated but should the battery be drained, the padlock will still function as its power supply is coming from the key and not from the GPS unit
• As standard the GPS padlock is able to send up to 10 status positions within one day giving a clear overview of its position on the web-service mapping software. The battery autonomy is 10 days. Should less status positions be required (ex not on weekends) then its autonomy can be increased to about 25 days using only 3 status positions per weekday.
All data is encrypted using 128-bit AES ENCRYPTION Independent GPS module
with SIM card and battery inside.
Acsys lock CANNOT be BUMPED OR PICKED and very hard to DRILL
TRACK YOUR ASSETS ANYTIME, ANYWHERE
Control Center CLOUD Remotely Control Position Remotely Control Access GPS/SMS CGS/SMS
Acsys Keys Specifications
• Key is impossible to copy
• Key in Reinforced ABS, UV proof, IP55,RoHS • Stainless steel blade
• Powered by 2x LR1 batteries
• Battery autonomy 2 years/25k openings • Operating Temperature from -10°C to +65°C • Logs last 1000 operations
• 4 Status LED (Access/No access/Restricted Access/Low battery)
AKEY CGSPlus
(Driver Key)
AKEY GuardKey
(Guard Key)
=
ACSYS KEY PROXIMITY/RFID ACSYS PROXKEY
OPTIONAL : USE YOUR KEY AS A BADGE
AKEY NORMAL
Acsys Cylinder Locks Specifications
• Locks are impossible to pick/bump • Brass with stainless steel plating • Power comes from key (no battery) • No Wiring
• EURO-DIN standard
• Operating temperature -20°C to +85°C • Logs last 1000 operations
Padlocks
Cylinder Locks
Button Lock
Double Lock
Acsys Padlocks Specifications
• Padlocks are impossible to pick/bump • Brass with chrome plating with plastic cover
finished
• Power comes from Key (no battery) • Operating temperature from -20°C to
+85°C
• Logs last 1000 operations
PL2
PL5
• Padlocks are impossible to pick/bump • Brass with chrome plating
• Power comes from Key (no battery) • Operating temperature from -20°C to
+85°C
Programmers Specifications
• Reinforced ABS, UV proof • IP 55, RoHS
• Powered by USB (USB)
• Powered by externalDC Power supply (IP version)
In-vehicle Programmer
USB/IP Programmer
• Reinforced ABS, UV proof • IP 55, RoHS
• Powered by 16 volt power adapter or built-in battery
Other Products Specifications
Mobile Programmer (MoPro)
USB/IP Programmer
• Reinforced ABS, UV proof • IP 55, RoHS
• Optional belt clip • Recharge able battery
3G Programmer
• Reinforced ABS, UV proof • IP 55, RoHS
• Powered by 6 Volt power adapter or by built-in battery
• Reinforced ABS, UV proof • IP 55, RoHS
• Powered by USB (USB) • Powered by externalDC Power
Quality Assurance and Awards
Acsys Technologies Ltd follows the strictest manufacturing codes and QC procedures. For example, Acsys locks are guaranteed for 100,000 openings yet have been successfully tested for over 400,000.
Acsys is the only mechatronic lock manufacturer to have completed 96 hours of salt spray testing on its locks. Water testing, drop testing, and more are all conducted to ensure smooth performance under the most rugged conditions. Locks are under warranty for 2 years and keys for 1 year. Warranty can be extended if combined with an Acsys SLA.
Our chief engineers come from varied disciplines, yet offer over 20 years of combined mechatronic lock and key expertise. We follow ISO standards and our products comply with CE, RoHS, EN, GA and FCC is certifications.
The greatest testament to our standards of excellence are the 10s of 1000s of locks deployed across telecom, government, and military clients in Europe, Africa, and the Middle East over recent years.
CONTROL & SECURE REAL
TIME UNIQUE WORLD WIRE FREE
Acsys KEY
