SPECIAL REPORT: CLEAN FUELS
41
ViewpointKey representatives from the energy industry present their insight on how to achieve balanced energy policy, what is the future for alternative fuels, what part will renewable/biofuels play in the transportation fuel mix, and more
51
Consider total value when optimizing catalytic cracking unitsLow rare-earth catalysts balance activity and selectivity against cost S. Ismail
57
Increase energy efficiency for your refineryBehavioral and organization changes are needed to effectively maximize operating profits Z. Milosevic
61
Use advanced catalysts to improve xylenes isomerizationThis refiner wanted to increase ethylbenzene conversion while limiting aromatics losses G. Shouquan and J. Chua
65
Improve diesel quality through advanced hydroprocessingNew upgrading technologies help meet fuel quality specifications C. Peng, X. Huang, T. Liu, R. Zeng, J. Liu and M. Guan
69
Debottleneck crude-unit preheat exchanger network inefficienciesSimulation models can be effectively used to optimize heat transfer and boost operational performance E. Bright, S. Roy and S. Al-Zahrani
Cover During the 1940s, the focus of the US refining industry shifted to producing quality transportation and aviation fuels needed by the military. The US federal government sponsored several construction projects to increase refining capacity to support war efforts on two different fronts. This expansion program involved the construction of fluid catalytic cracking units (FCCUs)—a process needed to blend 100-octane aviation fuel—along with the building of new isomerization and alkylation units. Over $900 million was invested in refining construction projects from 1943 to 1945. This month’s cover is a photo of the dedication ceremony for the Texas Co.’s two new FCCUs, held on Feb. 29, 1944 (see pg. 11). This Port Arthur, Texas refinery is still in operation and owned under Motiva, a joint venture between Shell Oil and Saudi Aramco. This refinery is completing another major expansion and is scheduled to come onstream in early 2012. It will have a crude distillation capacity of 600,000 bpd and rank among the 20 largest global refineries.
