advanced hot runner temperature control.

(1)

advanced hot runner

temperature control.

(2)

precise control for every need

Mold-Masters®_{TempMaster-Series}_{™ hot runner temperature controllers}

are specifically designed to meet the most demanding requirements.

With a controller to suit every need – from low-cavity applications to

240-zone multi-cavity control systems – the TempMaster-Series™ utilizes the most advanced technology to deliver perfect, precise control.

Our commitment to quality ensures your multi-cavity tools can produce

the finest finish, the lowest vestiges and the best cosmetics for your

customers.

maximize control for

superior performance.

your partner for quality and service

Every Mold-Masters®_{hot runner temperature control system is}

delivered completely assembled, inspected and tested. Mold-Masters®

has been the global leader in hot runner technology for 40 years, and

(3)

XL

controller line

lower cost of ownership for low-cavity applications.

latest advancements

The TempMaster-Series™ XL line of hot runner temperature controllers provides superior accuracy for today’s low-cavitation

molding processes. The XL control module’s latest technology

includes a digital micro-processor control, bright LED display and

multiple process indicators.

simple operator interface

The TempMaster-Series™ XL control module is easy to use. Compatible with global industry

standards and equipped with a universally

understood operator interface, XL features

clearly legible numbers and instantly

recognizable graphic operator commands. All

functions can be quickly learned. This control

module allows precise, error-free operation

anywhere in the world.

maximum flexibility

XL cabinets are available in three configurations (2, 6 and 9 modules).

All cabinets are fully wired to allow easy future expansion, and include

accessible fuses and integral ventilation fans for use in any industrial

environment. Options available include a heavy-duty operating stand

(4)

MZ

controller line

higher performance for high-cavity applications.

more control with less effort

The TempMaster-Series™ MZ controller line, with its touch-screen technology and built-in LAN capabilities, is designed for maximum

flexibility. The console can be operated and supported remotely through

a wireless control screen. Control up to 240 zones using the system’s

easy-to-access graphs, drawings and Tool-Store. Several zones can be selected, grouped and controlled at the same time. Actual control

meters can be viewed live and monitored anywhere on the system,

providing ease of operation and precise control. Troubleshooting is

swift and simple. Automatic tuning criteria can manage even the most

challenging applications, while the auto-diagnostic routine can easily

test your serviced mold.

information at your fingertips

Advanced touch-screen technology simplifies interaction with the system.

Features include point-and-set control modules, touch-and-rotate 3-D

perspective graphs and page selection tabs. Realistic needle meters

indicate the deviation for each zone. Visual prompts are easy to follow:

just point and select.

slim stand save precious floor space direct mounting cabinet mounted on the machine integrated stand an all-in-one unit SVG control sequential valve gate control wireless control plant-wide mobility

(5)

® Mold-Masters and Mold-Masters Academy are Registered Trademarks of Mold-Masters Limited. ™ Master-Series, TempMaster-Series and MasterCARE are Trademarks of Mold-Masters Limited.

“Out of the several controllers we tested, we found the

TempMaster-Series

™

to be the

best controller

on the market today. The performance/value

ratio and the ease of maintenance and operation is

outstanding

.”

ANS BEAULIEU MOLD DESIGN ENGINEER MEGA-BLOKS
