How Much Power Oversubscription is

Safe and Allowed in Data Centers?

1_{EECS @ University of Tennessee, Knoxville} 2_{ECE @ The Ohio State University}

3_{IBM Research, Austin}

(2)

Introduction

Power: a first-class constraint in data center design

Power oversubscription by power capping

Improves power facility utilization Improves server performance

Power capping at different levels

Servers, racks, and data centers

However, they all share a common assumption

Power should

never

exceed the rated power capacity?

Otherwise the circuit breaker (CB) would trip?

(3)

Trip curve of a typical

How Much Power Subscription is Safe?

A CB trips or not depends on

Magnitude of the overload

Duration of the overload

Ideal upper bound?

Lower bound of the tolerance band

This paper

Investigates CB trip features

Proposes adaptive power control to

1. Fully utilizes the allowed overload interval for maximized server perf. 2. Safely hosts more servers without

upgrading power facilities

Two minutes

(4)

Proposed Solution: CB-Adaptive

More than just a standalone controller

A methodology that adapts the parameters of existing power controllers to engineer their settling times

Example: adapts a server power controller

[Lefurgy ICAC’07]

1. Obtain the tripping time from the CB tripping curve 2. The desired settling time should be the tripping time

3. Adapt controller parameter K to enforce the settling time

Server

CPU frequency Power measured Power Cap

Error

K _×Error

(5)

CB-Adaptive Design Details

System model

p(k) is the power of the server

d(k) is the change to the CPU frequency

A is a hardware-specific parameter when the server runs LINPACK

How to adapt the controller parameter?

The relationship between the parameter and the settling time The parameter is a function of the measured power, the rated

current of CB, and the control period.

(

1)

( )

(6)

Two CB-Adaptive Improvements

Temperature-aware CB-Adaptive

The CB trip curve is impacted by the ambient temperature.

The rated current of CB is a linear function of the temperature.

K is also a function of ambient temperature.

CB-Proactive

Delicately increases DVFS level in a proactive way Further improves the server performance

When and to what extent the DVFS level is increased? CB enters the long-delay region

Increase the frequency to the highest level

0.9 1 1.1 1.2 10 20 30 40 50 Temperature T h e r a te d c u rr e n t

(7)

Discussion on Power Oversubscription

Possible applications of CB-Adaptive

Hosting additional servers

Safety issues

A typical power delivery system

Every component can tolerate overloads like CBs

Overload capacity: power beyond which permanent damage occurs to the component

(8)

More Discussion

Components other than CBs do not experience

overloads frequently.

It is less likely that many servers reach their peak power simultaneously.

Evidenced by a real Google data center [Fan ISCA’07]

When only a branch circuit is overloaded

CB-Adaptive can be applied directly

When multiple branch circuits are overloaded

CB-Adaptive needs to consider the tripping time of components other than CBs.

(9)

Hardware Testbed

Dell OptiPlex 380 Rockwell Allen-Bradley 1489-A Industrial CB Workloads SPEC CPU2006 SPEC JBB LINPACK

(10)

Baselines

NoControl

Estimates the peak power consumption of a server

No power caps

Unsafe and conservative

P-Control

Measures the power in every control period

A non-adaptive proportional controller calculates frequency changes to enforce a power budget.

P-Control-CB

The power budget is different from that of P-Control

(11)

Power Control Comparison

NoControl causes the CB trips. Unsafe

P-Control & P-Control-CB

Unsafe and conservative

CB-Adaptive fully utilizes overload intervals of CBs. Raise CPU freq for

higher performance

50 100 150

0 10 20 30 40 50 60 70 80 90 100 Control Period (5sec)

P o w e r Co n s u m p ti o n (W a tt )

NoControl Rated Limit Long-Delay Upper Limit

50 100 150

0 10 20 30 40 50 60 70 80 90 100

Control Period (5sec)

P o w e r C o n s u m p ti o n (W a tt )

P-Control-CB Long-Delay Upper Limit P-Control

50 100 150

0 10 20 30 40 50 60 70 80 90 100 Control Period (5sec)

P o w e r C o n s u m p ti o n (W a tt )

CB-Adaptive Rated Limit Long-Delay Upper Limit

Converge to 80W after hours

50 100 150 P o w e r C o n s u m p ti o n (W a tt )

CB-Proactive Rated Lim it Long-Delay Uppe r Lim it

Converge to 80W

NoControl

(12)

Performance Comparison

CB-Adaptive outperforms

P-Control by

66%, for LINPACK

29 % to 49%, for SPEC CPU 2006 74%, for SPEC JBB 0.0 0.4 0.8 1.2 1.6 2.0 P-C ontr ol P-C ontr ol-C B CB-A dapt ive CB-P roac tive L IN P A C K P e rf o rm a n c e (G fl o p s ) 0 5000 10000 15000 20000 25000 30000 35000 S P E C J B B P e rf o rm a n c e (b o p s ) LINPACK SPECJBB 0 3 6 9 12 15 18 sphi nx3 wrf lbm _tonto Gem sFD TD calc ulix povr ay sopl ex deal II nam d lesl ie3d cact usA DM grom acs zeus mp milc gam ess bwav es xala ncbm k asta r om netp p h264 ref libqu antu m sjen g hm mer gobm k mcf gcc _bzip2 perlb ench SPEC2006 benchmarks P e rf o rm a n c e ( B a s e R a ti o )

(13)

Impact of Temperature

Temperature impacts the trip time significantly.

Temperature-blind solutions P-Control-CB,

CB-Adaptive and CB-Proactive are

not

safe

.

200 250 300 350 400 450 500 NoCo ntrol (21.7 ℃ ℃℃ ℃ ) NoCo ntrol (26.4 ℃ ℃℃ ℃ ) NoCo ntrol (31.6 ℃ ℃ ℃ ℃ ) NoCo ntrol (34.8 ℃ ℃ ℃ ℃ ) P-Con trol-C B (45 ℃ ℃ ℃ ℃ ) CB-Ad aptiv e (45 ℃ ℃ ℃ ℃ ) CB-Pr oactive (45 ℃ ℃℃ ℃ )

Temperature (degree Celsius)

T ri p T im e ( S e c )

(14)

Temperature-Aware CB-Adaptive

As the temperature increases, the performance

of servers decreases.

(15)

Power Provisioning Analysis

NoControl

The estimation is too conservative 7 servers hosted per branch

P-Control

Enforce a power budget instead of an estimation of power 13 servers hosted per branch

CB-Adaptive

Enforce a higher power budget than P-Control 20 servers hosted per branch

Rated power of the CB The number of servers

estimated server power =

(16)

Conclusions

A common assumption of existing power capping

Peak power should never exceed the rated CB capacity

This paper

Systematically studies the CB tripping characteristics

Identifies ideal upper bound of safe power oversubscription Proposes two adaptive power control strategies

Evaluation on safe power oversubscription

A single server: 38% performance improvement

Circuit branch: host 54% more servers without upgrading power infrastructure

(17)

Questions?

Acknowledgements

NSF CAREER Award CNS-0845390 NSF CSR Grant CNS-0720663

NSF SHF Grant CCF-1017336

Prof. Leon Tolbert at the University of Tennessee

(18)

(19)

Control Theoretic Analysis

How to adapt the controller parameter?

Details of the derivation

Z transform of the system model Z-domain controller

Calculate the close loop transfer function Reverse Z transform

1

m

0.02 K

A

−

=

(20)

Power Provisioning Analysis

UPS cannot tolerate overloads

Not a problem because each UPS run at 50% its capacity
