A low-sulfur world
INSIDE THIS ISSUE
8
Business Trends.Nations around the world are implementing stringent emissions standards and low-sulfur transportation fuel specifications. These regulations are an effort to curb airborne pollutants and provide “cleaner fuels” for
consumers. HP examines major clean fuel projects and initiatives being implemented around the world.
41
Special Report.With the right tools and experienced personnel, a real-time environmental data management system with advanced analytics can assist in developing in-house metrics for operations, and foster a necessary dialogue between plant operators and plant environmental specialists.
49
Outlook. In Part 2 ofHP’s Industry Leaders’ Viewpoints, industry leaders and esteemed colleagues in the industry provide HP with their insights into growing regions of activity, technological advances and how the downstream industry can innovate in 2016 and beyond.
59
Process Optimization. A case study, wherein the operation of a vacuum tower was corrected, highlights the importance of understanding the entire vacuum system, of field observation and of the interpretation of operating vs. design data. Basic concepts to help understand and troubleshoot a steam ejector system are presented.69
Instrumentation.Honeywell Advanced Solutions and PKN ORLEN discuss utilizing advanced process control solutions to resolve hydrocracker conversion optimization challenges. As the world continues to welcome
more vehicles on the road, and as emerg-ing economies invest in civil, industrial and energy projects, global fuels demand is forecast to increase through the end of the decade.
More vehicles on the road equates to higher emissions rates and, in turn, more airborne pollutants. To combat these ef-fects, legislation mandating decreased emissions and lower levels of airborne pollutants is coming into effect. In re-sponse, refiners are implementing opera-tional and processing changes to reduce sulfur levels in transportation fuels.
The refining industry has already made incredible strides in reducing sulfur in transportation fuels. As shown in FIG. 1, sulfur levels in diesel fuel have been cut dramatically around the globe within the past decade. Refiners have invested, and continue to invest, billions of dollars in new units, upgrades/retrofits and expan-sions to meet new sulfur and emisexpan-sions regulations. These investments promote the reduction of airborne pollutants in both diesel and gasoline passenger vehi-cles, help produce higher-quality trans-portation fuels and continue to move the industry toward a low-sulfur world.
>5,000 and above >2,000 - 5,000 >500 - 2,000 Conflicting/missing data 15 and below* >15 - 50 >50 - 500
* Information in parts per million (ppm)
FIG. 1. Sulfur levels in diesel fuel: global status 2005 (top) vs. 2015 (bottom). Source: United Nations Environment Program, PCFV Secretariat.
>5,000 and bbove >2,000 - 5,000 >500 - 2,000 Conflicting/missing data 15 and below* >15 - 50 >50 - 500
Over the past decade, the refining industry has taken incredible steps to reduce sulfur levels in transportation fuels. Refiners have invested billions of dollars in new units, upgrades/retrofits and expansions to meet new sulfur and emissions regulations. These investments promote the reduction of carbon monoxide, nitrogen oxide, hydrocarbons and particulate matter in both diesel and gasoline vehicles. New technologies are moving the refining industry toward a low-sulfur world. New regulations and fuel standards are acting as catalysts for additional clean fuels projects to develop higher-quality transportation fuels.
Photo: Essar Oil’s 20-MMtpy refinery is located in Vadinar, Gujarat, India. The facility concluded a planned maintenance turnaround in 4Q 2015 that included the completion of the D-Max Project. Part of Essar’s Optima Plus program, the project included the conversion of the vacuum gasoil hydrotreater unit into a mild hydrocracking unit, as well as the addition of new installations in the diesel hydrotreating unit. Photo courtesy of Essar Oil.
Hydrocarbon Processing | FEBRUARY 20169
LEE NICHOLS, EDITOR/ASSOCIATE PUBLISHER
Business Trends
Clean fuels—a global shift toward a low-sulfur world
Around the world, legislation mandat-ing decreased emissions and lower levels of airborne pollutants is coming into effect. In response, refiners are implementing op-erational and processing changes to reduce sulfur levels in transportation fuels. New technologies are moving the downstream hydrocarbon processing industry toward cleaner, lower-sulfur transportation fuels.
A low-sulfur world doesn’t come cheap, though. Refiners are investing bil-lions of dollars in new units, upgrades/ret-rofits and expansions to meet new sulfur and emissions regulations. These invest-ments will help produce high-quality fuels that meet Euro 4, Euro 5 and Euro 6 speci-fications. Many refiners around the globe have adopted European standards for fuel quality, as Europe has been the frontrun-ner on regulations for low-sulfur, “clean” transportation fuels. European passenger vehicle emission standards for Euro 4, Euro 5 and Euro 6 are detailed in TABLE 1 and TABLE 2. These standards promote the reduction of carbon monoxide (CO), ni-trogen oxide (NOx), hydrocarbons (HCs) and particulate matter (PM) in both diesel and gasoline passenger vehicles. As shown in FIG. 1, many nations around the world already produce transportation fuels that meet Euro-4 specifications. Other re-gions, such as the Middle East, are invest-ing heavily to increase the production of Euro 4 and Euro 5 standard fuels.
The following is an overview of ma-jor clean fuels projects and trends being implemented around the world. Each re-gion is investing in the implementation of new technologies to meet cleaner fuel re-quirements. These new processing units will help produce higher-quality trans-portation fuels.
US/Canada. The US transportation fuel market is the world’s largest. The coun-try's government will begin to enforce the new Tier 3 program starting in 2017. This program will set new vehicle
emis-sions standards and lower the sulfur con-tent in gasoline. According to the US En-vironmental Protection Agency (EPA), sulfur content in gasoline will be limited to 10 parts per million (ppm). This is a reduction from Tier 2 standards, which limited the sulfur content in gasoline to 30 ppm. The program maintains the cur-rent refinery gate per-gallon content of 80 ppm and the 95-ppm downstream dis-tribution cap. The EPA forecasts that the new rule will significantly reduce vehicle pollutants into the atmosphere. For ex-ample, the EPA forecasts that NOx emis-sions will be reduced by about 260,000 tons in 2018 alone.
Large US refineries (those producing greater than 75 Mbpd) must comply with Tier 3 standards by 2017. Refiners pro-ducing below 75 Mbpd must meet Tier 3 regulation standards by 2020. To comply with new regulations, US refiners have invested in additional units, such as hy-drotreaters, to reduce the sulfur content in transportation fuels.
In Canada, petroleum fuels consti-tute 95% of Canada’s transportation en-ergy needs. The country has aligned it-self closely with US fuel standards and is making strides to continually reduce sul-fur levels in transportation fuels. This in-cludes the introduction of stringent Tier 3 fuel regulations for passenger vehicles and light-duty trucks. These fuel
stan-dards will begin in 2017, which coincides with the startup of US Tier 3 regulations. Canadian refiners have already invested over $8 B over the past decade to reduce sulfur levels in gasoline and diesel fuels. Since 2005, sulfur levels in gasoline and diesel have decreased by more than 90% and 97%, respectively. New Tier 3 stan-dards would be instrumental in continu-ing to reduce sulfur in transportation fu-els, as well as reducing vehicle emissions to nearly zero over the life of the vehicle. China. To help curb air pollution, the country has set aggressive fuel economy standards through 2020. China is imple-menting its National V fuel quality stan-dard, which equates to Euro 5 standard transportation fuels. Euro 5 caps sulfur content in gasoline and diesel at 10 ppm. Recent regulations required refiners to produce Euro 4 standard transportation fuels nationwide by the end of 2015. Euro 5 standard transportation fuels will be required for the automotive industry by 2017. These new regulations are being implemented one year ahead of schedule. The implementation of National V fuel quality standards for non-automotive die-sel has been pushed back one year to Janu-ary 2018. This includes “general” diesel used in agriculture and industry. General diesel will need to meet Euro 5 standard requirements within this time frame.
Up-TABLE 1. EU emissions standards for passenger vehicles (gasoline)
CO, g/km HC, g/km NOx, g/km PM, g/km
Euro 4 1.0 0.10 0.08 –
Euro 5 1.0 0.10 0.06 –
Euro 6 1.0 0.10 0.06 0.005
TABLE 2. EU emissions standards for passenger vehicles (diesel)
CO, g/km HC + NOx, g/km NOx, g/km PM, g/km
Euro 4 0.50 0.30 0.25 0.025
Euro 5 0.50 0.23 0.18 0.005
grading the nation’s fuel quality could cost Chinese refiners over $7 B.
India. The country has 22 major refiner-ies in operation, with a total throughput capacity of 4.3 MMbpd. To satisfy increas-ing demand for transportation fuels, India is investing upward of $30 B in additional refining projects through 2020. Capital ex-penditures are expected to be even higher
due to new regulations to curb air pollution and produce Euro 4 and Euro 5 standard fuels by 2020. In January, Road Transport Minister Nitin Gadkari announced that Indian refiners will need to invest $4.5 B to produce Bharat Stage 6 (BS-6) standard fuels by 2Q 2020. BS-6 fuels are equiva-lent to Euro 6 fuel specifications. These new regulations are being imposed four years ahead of schedule and call for a 68%
reduction in NOx emissions. Cars sold in the country are subject to BS-4 standards. India’s new regulations will bypass the BS-5 stage and move directly to BS-6.
The proposed clean fuels bill was in response to a World Health Organization study that found that 13 of the world’s dirtiest cities were in India. The instal-lation of secondary units to comply with new fuel standards could cost Indian refin-ers over $17 B.
Indonesia. Southeast Asia’s biggest economy is the world leader in the pro-duction of palm oil, and is promoting its use as a biofuel. The country boosted the mandated amount of blending in diesel in 2014 from 7.5% to 10%, and subse-quently to 15% in 2015. Indonesia raised the blending requirement to 20% this year and plans to increase it to 30% in 2020. According to the Indonesian Biofuel Pro-ducers Association, Indonesia’s biodiesel consumption will increase from 1.1 kiloli-ters in 2015 to 7.9 kilolikiloli-ters in 2016. The additional usage of biofuels is expected to decrease vehicle emissions substantially. FIG. 1. Vehicle emissions standards: global status as of February 2015. Source: United Nations
Environment Program, PCFV Secretariat.
