3.0 INTRODUCTION
Inventory control systems are used for managing the stocks of companies and big distribution organisations. In this unit we will discuss about OOM for invention control systems. We will cover class diagram design, object diagram different kind of relationships, which include generalization, association and collaboration. We will also discuss use case diagrams activities and events.
3.1 OBJECTIVES
After going through this unit, you should be able to:
• explain class diagram and object diagram of Inventory control System; • describe generalization and Specialization of the system;
• describe collaboration diagram of the system;
• explain different activities and events of the systems, and • explain deployment Diagram.
3.2 CLASS
DIAGRAM
You know that a class is represented in a box like figure. Here we are taking the case study of Inventory Control System.
Let us first set an idea of the Inventory Control System. It is the system in which you can manage the stock of the products that a company sells. Basically, this system is stock oriented where it makes sure that the quantity-in-stock does not reach the danger level (Qty-ordered>Qty-in-stock).
In any system when we reach this level, we place a new order. To avoid this situation, when in our system Qty-in-stock reaches a minimum level called the Reorder-level then a new order is placed. Here, in this case study, you will see various diagrams.
41
Case Study: Inventory Control System CUSTOMER Customer-id Cust-name Cust-address Cust-city Cust-state Cust-pincode Cust-contact-no ADD MODIFY DELETE VIEW SUPPLIER Supplier-id Supp-name Supp-address Supp-city Supp-state Supp-pincode Supp-status Supp-Contact No1 Supp-phone 2 ADD MODIFY DELETE VIEW
Figure 1: Class diagram represents the static structure of a System
You know that a class is represented in a box like Figure which can have at the most three regions. • Class Name • List of Attributes • List of Operations/Methods Class Methods Attributes/properties
Class Name ORDER
Order-id
Description No. of items product-id order date NEW () EXISTING () SALE Receipt-no Sale-of- sale Qty-sold
Detailed Item Sale () Daily Report Sale () Generate () View () INVOICE Invoice-no Invoice-date Customer-id Supplier-id Payment-status Generate () View () PRODUCTS Product-id Name-of-product Category-id Description price Qty-in-stock Danger-level Last-modification-date Manufacturing-date ADD MODIFY DELETE VIEW
Figure 2: Class diagram
3.3 OBJECT
DIAGRAM
Object Diagram is an instance of a class. It describes the static structure of a system at a particular time and are used to test the accuracy of classes.
Implementation Generate Report Enter Product Details Prod. No PRODUCT INVOICE Bills of Material SUPPLIER Invoice No. Order by ORDER details Order- no by Cust Code EXISTING Old NEW New realise CUSTOMER Name address Places an order Update Identifies details Validation Order Order-no Cost-no Prod-no Validate Order Order received Updates Files Update Stock Qty-Stock Dispatch Order Order Details Figure 3: Object Diagram
3.4 GENERALIZATION AND ASSOCIATION
DIAGRAM
Generalisation: This is another name for inheritance, or an “is a” relationship. It
refers to a relationship between two classes where one class is a specialized version of another.
43
Case Study: Inventory Control System
Sub Type 1
Regular Customer Customer
PRODUCT
New Product Existing Product CUSTOMER
Name: string Credit ()
Figure 4: Generalisation of customer and product Sub Type 2
Super Type
Association: This represents static relationship between classes.
Roles represent the way the two classes see each other.
Class B Class A name 1 n m n n m SUPPLIER Supplier Details CUSTOMER Customer details ORDER
Date-of order: date Order-no
n role 1 role
Figure 5: Association of Order and customer
Aggregation: This denotes a strong ownership between class A, the whole, and class
B, and its part.
Hollow Diamond Simple Aggregation Filled Diamond Strong Aggregation
SUPPLIER ORDER ORDER CUSTOMER INVOICE PRODUCT Figure 6: Aggregation
Ternary Association for Customer Supplier
PRODUCT
SUPPLIER CUSTOMER
Implementation
3.5 COLLABORATION
DIAGRAM
This represents the interactions between objects as a series of sequenced messages. Collaboration diagrams describe both the static structure and the dynamic behaviour of a system.
Representation
Figure 8 a: Collaboration diagram for inventory control system
Object: Class 2.3 [Condition] Message Actor Object: Class 1. Message 2. Message 3. Message 1.2: [Condition] Message Object: Class Object: Class SUPPLIER 3.0 Delivery new () : SUPPLIER : STOCK : PRODUCT : ORDER New product 1 [In order] 1.1 [In Stock] Customer 1 places an order 2.0 [SUPPLIER] Invoice
Figure 8 b: Collaboration diagram for the inventory control system
3.6 ACTIVITY DIAGRAM AND EVENTS
STATECHART DIAGRAM
This describes the dynamic behaviour of a system in response to external stimuli • Basically, states are triggered by specific events.
Representation:
Final state Initial state
State
event/actionActivity Diagram
This illustrates the dynamic nature of a system by modeling the flow of control from activity to activity, or you can say operation on some class that results in a change in the state of the system.
45
Case Study: Inventory Control System
• Basically, this shows the workflow model, or business process and the internal operation
: Class
Activity Activity
: Class
Figure 9: Activity flow
Synchronization and Splitting of Control
• A short heavy bar with two transitions entering it represents a synchronization of Control.
• Splitting of Control that creates multiple states.
Splitting of Control Synchronization
Payment Made Demand Occurred Regular Delivery Overnight Delivery Reverse Order [else] [Rush order]
Place the Order Validate the Order
[Valid demand] Check QTY-in-stock Cancel Demand [Valid] Demand Occurred
Figure 10: Activity diagram
Events
Actions taken in Inventory Control System: 1) Order is placed by the CUSTOMER 2) Order is received by the SUPPLIER
3) Checking of Quantity-in-Stock and Reorder-level 4) Checking of Inventory Status
Order
INVOICE
Implementation 6) Generating the INVOICE VOUCHER
7) Updating Inventory Status File
Main screen Do: display Customer/Supplier
Validation Do: Verify the Order
Do:
Place the Order
Select Order Order OK Order Rejected Sector the Order Rejected Order Do: reject the
Min Qty >qty-in-stock Reorder Level Do: check
min. Qty-in-stock
Cancel Do: cancel the Order
Display
Do: finish process
Do: Display Bad Message Generation Do: Generate Generate Do: Generate Bills of Material (BOM) Update Do: Update Inventory Status File
47
Control System Case Study: Inventory <<uses>> Place an Order Generate INVOICE <<extends>> <<extends>> <<uses>> <<uses>> Invoice of the item for Supplier Update Inventory
Status File Invoice of an item for Customer Generate Receipt Receipt for Supplier Receipt of an item for Customer <<uses>> Check Qty-in-stock <<uses>> <<uses>> Validate the order Place an Order
Figure 12: Adding details
Data Flow Diagram for System
2.1 Reject the Order Inventory File 5.0 Update Inventory Status trans details Transaction File Validation Order 4.0 Generate Bills of Material OK Qty-in-stock Validated ROL 8.0 Generate Invoice Voucher 2.0 Valid ROL & Qty-in-stock 1.2 Check Reorder level Order Invalid 2.0 Display error Msg
Order Master File
Check Order details 1.0 Validate the order demand Places CUSTOMER 1.0 Places an order
Implementation
3.7 USE CASE DIAGRAM
A “uses” relationship indicates that the use case is needed by another in order to perform a task
• An “extends” relationship indicates alternative options under a certain use case. • Use case diagrams model the functionality of a system using actors and use
cases.
• Use cases are services or functions provided by the system to its users.
Use Case Use Case
(Actor)
Use Case
Figure 14: Use Case diagram
For Inventory Control System the initial design is:
SUB DIAGRAM INVENTORY CONTROL SYSTEM Place an Order Generate INVOICE Update Inventory Status File Generate BOM Update Inventory Status File Generate
INVOICE Generate BOM
<<uses>> <<uses>> <<uses>> Actor (Customer) Place an Order
49
Case Study: Inventory Control System USER INTERFACE To View Set Order Qty Set Qty-in-stock 60 Sec without input Setup Set Program Set Order Qty Set Qty-in-stock
Run Program Interactive Display
Run Program
HOLD Set upon Order
Select
Set supplier & Customer code
Run entries are set
Display Order Screen do: show order details
Display Supplier Screen
Do: show supplier button
enter Display
Menu Screen do: show Customer
Operate
Power on
Load Standard Program
Generating report mode
Press Report Button Invoice Card Button Press Run Button Generate Inventory Status Report Generate Invoice Voucher Generate Bills of Material entry Report
Figure 16: User interface
3.8 DEPLOYMENT
DIAGRAM
Deployment diagram: This shows the hardware for your system, the software that is installed on that hardware, and the middleware that is used to connect the machines to one another.
Implementation • Deployment diagrams depicts the physical resources in a system including
nodes, components and connections, where a node is a physical resource that executes code components.
Node Component Figure 17: Deployment JDBC <<JDBC>> {order=order} <<Device>> DB Server Inventory DB <<databases>> Web Server INVENTORY CONTROL SYSTEM <<JSPs>> <<Deployment Space.>> Placing of Order Execution: thread Nested Transaction: True <<EJBs>> Servlets PRODUCTS SUPPLIER CUSTOMER Inventory Control Series <<Web Services>> M <<Device>> :App” Server Inventory gmt. jar : EJB Container customes. ear supplier. ear product. ear order..xml <<deployment space>> <<JDBC>> Inventory DB <<JDBC>> Web Server Inventory Control War
51
Case Study: Inventory Control System
3.9 SUMMARY
In this unit different diagram are design to represent OOM of inventory control system. These diagrams are:
• Class diagram • Object diagram
• Generalization and association • Collaboration diagram
• Activity diagram • State diagram • Dataflow diagram • Use case diagram
