1
0BINTRODUCTION
This series of Optimization Guidelines cover all main topics regarding
•
Performance Monitoring & Analysis• Configuration settings
• Troubleshooting
Refer to the internal Claro document Ref. ####.## , Optimization Process, for a summary of 3G WCDMA Radio Access Network Optimization Basics.
This specific document focuses on RETAINABILITY and its specifics in NSN infrastructure (Release RU10).
Target users for this document are all personnel requiring a detailed description of this process (Retainability Optimization), as well as configuration managers who require details to control the functions and optimize parameter settings. It is assumed that users of this document have a working knowledge of 3G telecommunication and are familiar with WCDMA.
Document Revision Control
Revisio
n Date Author Changes
Draft0
2
1BRETAINABILITY
Retainability is the ability of a service to be kept – once it was accessed – under given conditions for a requested period of time. In other words, it is the probability that a service, once obtained, will continue to be provided under given conditions for a given time duration.
Target is to get a 100% Retainability, i.e., all connections maintained until their normal release. Poor Retainability is typically due to
•
Handover performance (soft/softer/Iur/IFHO/IRAT) and missing neighbor cell• UL/DL imbalance
• Incorrect parameter settings (power, admission, release)
• Congestion
•
Radio environment impact (corner effect, fast Ec/No drop, Pilot pollution, etc)•
Node Hardware/Software failure•
Iub (E1s) CongestionRetainability is to be monitored independently for the different RAB types (e.g. Speech, CS Video, PS Interactive R99, PS Interactive HSDPA, etc.) as in certain situations only one of the RAB types will be affected.
2.1
6BCell Update
In 3G a new mechanism is available to rescue some dropped calls (both CS and PS) due to RL Failure:
Call Reestablishment by Cell Update procedure. Refer to ANNEX I for further details.
If timer T314 is set higher than 0, Voice calls that suffer from a RL Failure are not considered “dropped” till timer T314 expires and the call could not be reestablished by the Cell Update Procedure.
Similarly, if timer T315 is set higher than 0, PS calls that suffer from a RL Failure are not considered “dropped” till timer T315 expires and the call could not be reestablished by the Cell Update Procedure. We could say that in both cases, CS and PS, those RL Failures that can be rescued are just
system-perceived drops, but not user-system-perceived drops, as the user does not have to perform any additional
manual operations like for example manual re-activation of the PDP context. In reality, during the Cell Update procedure (T314 or T315 seconds), Voice calls will be perceived as “silent” by the user, and PS data sessions may suffer from delays and lower throughputs, but the fact is that the call does not drop, and it is not counted by the RAB releases counters (and therefore, neither as a drop).
In NSN infrastructure, T314=0 is hardcoded, and T315=30 sec (changeable), i.e., this Cell Update mechanism is only available for PS data calls (not for Voice calls).
•
In terms of Voice Calls, this means that all RL Failures in DL will finally lead to a drop (user and system perceived, and RAB release counters –and drops- increased).•
In terms of PS Calls, those RL Failures that are rescued will be system but not user-perceived, and the abnormal RAB release counter (=drops) will not be increased.As some other vendors may have the Cell Update mechanism de-activated for PS, the optimization team should keep in mind these considerations when comparing PS DCR (%) in different vendors: usually worst in those ones with this functionality disabled. Nevertheless, this worst behavior in the KPI usually does not match the user perception (that is typically good) thanks to additional implicit re-establishment mechanisms (Paging/Service Request).
2.2
6BCS drop versus PS drop
One important difference between the Circuit Switched (CS) and Packet Switched (PS) domains is that in the CS domain, the end-to-end services (voice, video-telephony, CS data) can be maintained only if all lower layer links are maintained. For example, if the Radio Bearer is broken during a voice call, the
network may allow only limited time (T314) to perform a Cell Update before terminating the end-user application.
For PS data, to accommodate the bursty nature of the traffic, links from different layers can be independent. For example, the Packet Data Protocol (PDP) context is preserved, while the Radio and Radio Access Bearers are reconfigured or disconnected during low activity periods. The behavior of an FTP session is another example; when Radio Bearers are dropped or experience a high block error rate, the FTP might time out, even if the PDP context is active.
The interdependence between layers complicates data service optimization; all layers must be considered.
A single PS call (= a single PS RAB) goes dynamically through different “phases” (DCH R99, HSDPA, EUL, Cell_FACH) based on different radio configurations. It may also go to IDLE (with “pdp context preserved”) due to inactivity periods. It is the system that re-establishes the lower layer connections, with no user intervention.
When the PS call goes to Idle with “pdp context preserved” due to inactivity, the PS RAB is considered normally released, and there will be a new process of call establishment starting with an RRC connection request, and RAB establishment, etc. (but without the UPLINK DIRECT TRANSFER [SM: Activate PDP Context Request] as it was preserved).
In case there is a RL Failure, the pdp context is also preserved and either Cell Update or implicit re-establishment mechanisms (Paging/Service Request) will re-establish the lower layer connections with no user intervention. User does not notice the call drop (but typically experiences low throughput or delay). So in terms of “user perception” (or Data Application DCR %, or Data Session DCR %, or PDP context DCR %), the retainability is not impacted. These latest metrics (from an operational point of view) can only be derived from PS CORE (GGSN) counters.
In terms of Abnormal RAB Releases due to RL Failure, typically those vendors with CU enabled (NSN & Huawei, for example) will not increase the counter (in fact, they will not increase any RAB Release counter – nor normal neither abnormal-; RAB is not released); those ones with CU disabled will (Ericsson, for instance). So, as already anticipated, you can expect a worst KPI PS DCR % performance in these last ones.
3
2BRETAINABILITY KPIs (Key Performance Indicators)
Below the main metrics used for Retainability Monitoring of a 3G WCDMA/UMTS Network, and their implementation with NSN counters.
Refer to “SMART Documentation” for further details on the actual implementation of these KPIs in the tool, together with the additional considerations regarding:
• Treatment of zeros in the denominators
• Differentiation of PS: Global, R99, HS, EUL KPIs.
•
Considerations regarding SRNS Relocations and Outgoing Hard Handover3.1
8BHigh Level KPIs
3.1.1 14BRetainability Rate - RR (%)
Based in statistical counters, it is possible to count every time a RAB is normally released, e.g.:
• Call ended by UE or user control
(user generates a “disconnect” towards the CN or UE Signaling Connection Release)
• Call ended because of any problem or action on the other part
(the monitored user receives a “disconnect” from the CN)
•
Connection ends because of user inactivity (PS calls only)•
Connection ends because the call is successfully transferred to another system (IRAT handover)and abnormally released (= DROP):
•
Call ended by the network for any other reason than NORMAL.A global Retainability Rate (%) can be calculated as follows:
However, it is common practice to use the Non Retainability Rate (NRR) instead, a.k.a. Dropped Call Rate (%), that we will use throughout this document:
As already stated, target is to keep Retainability Rate, RR (%) as closed as possible to 100%, while target for NRR (%) is to keep the DCR (%) as closed as possible to 0%.
3.1.2 15BDropped Call Rate - DCR (%)
It is the most common KPI for Retainability.
The value is dependent on the call duration: the shorter is the average call duration, the lower shall be the drop call rate and vice versa. Any changes in the network that modify the call duration shall impact on the Drop Call Rate (e.g. IRAT Handover thresholds for speech or inactivity timers for PS calls).
Counters available in NSN for the Normal and Abnormal RAB Releases are:
No of Normal RAB Releases No of Abnormal RAB Releases
+Noof Abnormal RABReleases) Releases RAB Normal of (No Releases RAB Normal of No * 100
+Noof Abnormal RABReleases) Releases RAB Normal of (No Releases RAB Abnormal of No * 100
RAB_ACT_COMP_CS_VOICE +
RAB_ACT_REL_CS_VOICE_SRNC RAB_ACT_REL_CS_VOICE_P_EMP + RAB_ACT_REL_CS_V_UNSPE_ER_CN + RAB_ACT_FAIL_CS_VOICE_IU + RAB_ACT_FAIL_CS_VOICE_RADIO + RAB_ACT_FAIL_CS_VOICE_BTS + RAB_ACT_FAIL_CS_VOICE_IUR + RAB_ACT_FAIL_CS_VOICE_RNC + RAB_ACT_FAIL_CS_VOICE_UE RAB_ACT_COMP_CS_CONV +
RAB_ACT_REL_CS_CONV_SRNC RAB_ACT_REL_CS_CONV_P_EMP + RAB_ACT_REL_CS_C_UNSPE_ER_CN + RAB_ACT_FAIL_CS_CONV_IU + RAB_ACT_FAIL_CS_CONV_RADIO + RAB_ACT_FAIL_CS_CONV_BTS + RAB_ACT_FAIL_CS_CONV_IUR + RAB_ACT_FAIL_CS_CONV_RNC + RAB_ACT_FAIL_CS_CONV_UE RAB_ACT_COMP_CS_STREA +
RAB_ACT_REL_CS_STREA_SRNC RAB_ACT_REL_CS_STREA_P_EMP + RAB_ACT_REL_CS_S_UNSPE_ER_CN + RAB_ACT_FAIL_CS_STREA_IU + RAB_ACT_FAIL_CS_STREA_RADIO + RAB_ACT_FAIL_CS_STREA_BTS + RAB_ACT_FAIL_CS_STREA_IUR + RAB_ACT_FAIL_CS_STREA_RNC + RAB_ACT_FAIL_CS_STREA_UE RAB_ACT_COMP_PS_CONV +
RAB_ACT_REL_PS_CONV_SRNC RAB_ACT_REL_PS_CONV_P_EMP + RAB_ACT_REL_PS_C_UNSPE_ER_CN + RAB_ACT_FAIL_PS_CONV_IU + RAB_ACT_FAIL_PS_CONV_RADIO + RAB_ACT_FAIL_PS_CONV_BTS + RAB_ACT_FAIL_PS_CONV_IUR + RAB_ACT_FAIL_PS_CONV_RNC + RAB_ACT_FAIL_PS_CONV_UE RAB_ACT_COMP_PS_STREA +
RAB_ACT_REL_PS_STREA_SRNC RAB_ACT_REL_PS_STREA_P_EMP + RAB_ACT_REL_PS_S_UNSPE_ER_CN + RAB_ACT_FAIL_PS_STREA_IU + RAB_ACT_FAIL_PS_STREA_RADIO + RAB_ACT_FAIL_PS_STREA_BTS + RAB_ACT_FAIL_PS_STREA_IUR + RAB_ACT_FAIL_PS_STREA_RNC + RAB_ACT_FAIL_PS_STREA_UE RAB_ACT_COMP_PS_INTER +
RAB_ACT_REL_PS_INTER_SRNC RAB_ACT_REL_PS_I_UNSPE_ER_CN + RAB_ACT_FAIL_PS_INTER_IU + RAB_ACT_FAIL_PS_INTER_RADIO + RAB_ACT_FAIL_PS_INTER_BTS + RAB_ACT_FAIL_PS_INTER_IUR + RAB_ACT_FAIL_PS_INTER_RNC + RAB_ACT_FAIL_PS_INTER_UE
RAB_ACT_COMP_PS_BACKG +
RAB_ACT_REL_PS_BACKG_SRNC RAB_ACT_REL_PS_B_UNSPE_ER_CN + RAB_ACT_FAIL_PS_BACKG_IU + RAB_ACT_FAIL_PS_BACKG_RADIO + RAB_ACT_FAIL_PS_BACKG_BTS + RAB_ACT_FAIL_PS_BACKG_IUR + RAB_ACT_FAIL_PS_BACKG_RNC + RAB_ACT_FAIL_PS_BACKG_UE
NSN considers 3 possibilities for a RAB in the “ACTIVE” phase:
•
RAB_ACT_COMP_<RAB type>: Normal Release (counter updated when the RNC sends an RANAP:RAB ASSIGNMENT RESPONSE or RANAP: IU RELEASE COMPLETE to the CN after normal RAB release for a certain type of RAB)
•
RAB_ACT_FAIL_<RAB type>_<Reason>: Abnormal Release due to some abnormal reason related toIu-interface, Radio, BTS, Iur-Iu-interface, RNC or UE.
•
RAB active releases, the cause of which has been either inter-system handover, intra-system hardhandover, SRNS relocation, pre-emption or "unspecified failure”. Pre-emption for conversational and streaming and all releases with "unspecified failure" cause received from CN have been considered “Abnormal Releases”.
All above counters are in Measurement “Service Level”, so all DCR (%) KPIs we can derive from them are available at cell level. Also, as expected for a High Level KPI, they can be aggregated at nation, market/vendor, region, city, RNC, cluster,… levels.
3.1.2.1 32BUSpeech DCR (%)
High value (e.g. >2%) indicates retainability issues for Speech connections.
3.1.2.2 33BUVideo DCR (%)
E _ U E
I L _ C S _ V O I C
