Chapter 2: The Normal Distributions

Section 2.1: Measures of Relative Standing & Density Curves

Z-scores (Measures of Relative Standing)

Suppose there is one spot left in the University of Michigan class of 2014 and the admissions department has the decision narrowed down to 2 applicants. Everything about these 2 students is similar except their GPAs. Ferris has a 2.8 while Cameron has a 3.1. Now on paper it seems like Cameron has the higher GPA, but what about the difference in academic rigor of the student’s respective high schools. That must count for something. And it does. Ferris’ high school mean GPA is a 2.41 and the standard deviation is 1.09. Cameron’s high school mean GPA is 2.91 with a .87 standard deviation. An important assumption to make is the distribution of GPAs is approximately symmetrical. So the question is who deserves the spot?

Often times we are asked to compare the scores of two pieces of data that do not come from the same distribution. In order to decide which score is in fact higher, we must first standardize the scores.

If x is an observation from a distribution that has a mean μ and a standard deviation σ, then the standardize value of x (often called the z-score) is:

z= x−mean

standard deviation

The z-score tells us how many standard deviations a particular piece of data is away from the mean of the distribution. It therefore allows us to make comparisons across distributions. A z-score is very, very, very useful in statistics.

(2)

Percentile (Measuring Relative Standing)

If you are trying to find the percentile corresponding to a certain score x:

Percentiles are used often when reporting academic scores such as SAT scores. Let’s say you get a 620 on the math portion of the SAT. It might also indicate that you are in the “78th_{percentile”. That means} that you scored better than 78% of all students taking that particular SAT.

A few miscellaneous facts:

is the notation for the kth percentile

is the notation for the nth quartile

Example: Here are the scores of 25 students on the chapter 1 test in AP Calculus

79 81 80 77 73 74 93 78 80 75 67 73 83

77 83 86 90 79 85 83 89 84 82 77 72

The score that is bolded is Eli Manning’s score. How did Eli do relative to his classmates?

Question: Is there a simple way of converting a z-score to a percentile? Answer: YES, but it depends on the shape of the distribution

For example, if on a test, if your grade was exactly the mean grade of the entire class, what would your z-score be?

(3)

Chebyshev’s Inequality

In ANY distribution, the percent of observations falling within k standard deviations of the mean is at

least (100)

(

1−1

k2

)

Fill in the blank using Chebyshev’s Inequality for k = 1 through 5

k at least (100)

(

1−1

k2

)

of observations fall within k standard deviations of mean

1 at least _________% of observations fall within 1 standard deviation of mean.

2 at least _________% of observations fall within 2 standard deviations of mean.

Foreshadowing comment:

(4)

Density Curves

So far we have worked only with jagged histograms and stem plots to analyze data. As we begin to explore more fully the many statistical calculations and analyses one can perform on data it will become clear that working with smooth curves is much easier than jagged histograms. These smooth curves are called Density curves.

Characteristics of a density curve

 A density curve is a smooth curve that describes the overall pattern of a distribution by showing what proportions of observations (not counts) fall into a range of values.

 Areas under a density curve represent proportions of observations

 The scale of a density curve is adjusted in such a way that the total area under the curve is always equal to 1

 The density curve is always on or above the horizontal axis.  The median of a density curve is the equal areas point.

(5)

 The mean and the median are equal in a symmetric density curve.

(6)

Section 2.2: Normal Distributions

A Particularly important class of density curves are normal distributions. A density curve that is normally distributed has the following characteristics:

 Symmetric  Single peak  Bell shape

The mean of a density curve (including the normal curve) is denoted by μ (the Greek lowercase letter mu) and the standard deviation is denoted by σ (the Greek lowercase letter sigma)

All Normal distributions have the same overall shape. Any differences can be explained by μ and σ.

Calculus connection:

On the normal curve, at a distance of σ on either side of the mean μ, are two points. These points are called inflection points and they signify where the curve changes concavity. The normal curve changes from concave up to concave down at these points. To find the inflection points, you would need to find the second derivative of the function.

An unbelievable property that all normal curves have is that they follow the 68-95-99.7 rule

In a normal distribution with mean μ and standard deviation σ :

(7)

The Standard Normal Distribution

All normal distributions share many common properties. In fact, all Normal distributions are the same if we measure in units of size σ about the mean μ as center. Changing these units requires us to standardize.

The standard Normal distribution is the Normal distribution N(0,1) with mean 0 and standard deviation 1.

(8)

Examples:

1.) Find the area under the standard normal curve to the left of z = 1.15

2.) Find the proportion of observations from the standard normal curve that are less than 1.15

3.) Find the probability of randomly selecting an individual from a normal population whose z-score is 1.15 or less.

4.) What percent of z-scores are less than or equal to 1.15?

In the last part of this course, we will be given a sample

data set and we will have to determine if the sample chosen

comes from a normal population. We will learn how to

figure that out right here. There are 3 methods.

ASSESSING NORMALITY

Method 1: Construct a histogram, stem and leaf plot or box plot to determine if the shape is

approximately bell shaped with symmetry about the mean. This is fairly easy because if you load the data into your calculator, you can check a histogram very quickly.

Method 2: Check the normal probability plot (on TI-83). This is an easy and quick way to check for normality. You are shooting for a normal probability plot that has a linear trend to it.

(9)

Example: The following are the heights of 50 of my former male students, randomly selected from my classes. Are male student heights at DHS normally distributed?

68, 68, 73, 74, 75, 68, 68, 66, 70, 72, 69, 63, 68, 69, 68, 65, 68, 67, 69, 70, 71, 68, 66, 72, 69, 69, 70, 67, 64, 69, 70, 71, 68, 68, 67, 67, 69, 65, 68, 70, 69, 67, 66, 61, 68, 69, 69, 71, 72, 70

Method 1:

Since the histogram looks approximately bell shaped and the boxplot looks somewhat symmetric, we can say the data comes from a normal distribution.

Method 2:

Since the normal probability plot looks approximately linear, we can say the data comes from a normal distribution.

(10)

Method 3:

¯x±1s=68 .56±2.59=(65 .97,71.15)

Percent of data falling in this interval: ____________

¯x±2s=68. 56±5 .18=(63.38,73.74)

Percent of data falling in this interval: _____________

¯x±3s=68 .56±7.77=(60.79,76.33)

Percent of data falling in this interval: ____________
