Wormian bones - a case report of post-mortem examination

Wróbel Grzegorz. Wormian bones - a case report of post-mortem examination. Journal of Education, Health and Sport. 2018;8(6):412-417. eISNN 2391-8306. DOI http://dx.doi.org/10.5281/zenodo.1442512

http://ojs.ukw.edu.pl/index.php/johs/article/view/6144

The journal has had 7 points in Ministry of Science and Higher Education parametric evaluation. Part B item 1223 (26/01/2017). 1223 Journal of Education, Health and Sport eISSN 2391-8306 7

© The Authors 2018;

This article is published with open access at Licensee Open Journal Systems of Kazimierz Wielki University in Bydgoszcz, Poland

Open Access. This article is distributed under the terms of the Creative Commons Attribution Noncommercial License which permits any noncommercial use, distribution, and reproduction in any medium, provided the original author (s) and source are credited. This is an open access article licensed under the terms of the Creative Commons Attribution Non commercial license Share alike.

(http://creativecommons.org/licenses/by-nc-sa/4.0/) which permits unrestricted, non commercial use, distribution and reproduction in any medium, provided the work is properly cited. The authors declare that there is no conflict of interests regarding the publication of this paper.

Received: 01.06.2018. Revised: 15.06.2018. Accepted: 30.06.2018.

Wormian bones - a case report of post-mortem examination

Grzegorz Wróbel1

1 _{Department of Anatomy, Faculty of Medicine and Health Sciences, Jan Kochanowski University, Kielce,}

Poland

Correspondence: Department of Anatomy, Faculty of Medicine and Health Sciences, Jan Kochanowski University, Al. IX Wieków Kielc 19A, 25-317 Kielce, Poland.

Abstract

Skull bones provide attachment to numerous facial expressions. Sometimes, as an anatomical variant, small irregular bones (ossicles) appear in the area already present and

located at the seams of the cranial skull. These asymmetrical bones are also called sutural

bones, which usually occur along the sutures.The observational study concerns bone material

located in the Department of Anatomy of the Jan Kochanowski University in Kielce. During the analysis of human skulls, the occurrence of additional bones within the cranial sutures was observed. Morphologically, these bones have different shapes (oval, oblong, round, quadrilateral, polygonal, triangular) and sizes. Wormian bones are more common in the human skull than previously reported, therefore doctors or radiologists should know about this anatomical variant not to confuse it with the clinical aspect during surgery or imaging the skull.

Keywords: skull, sutural bones, osteology

1. Introduction

2. Case presentation

The observational study concerns bone material located in the Anatomy Department of the Jan Kochanowski University in Kielce. During the analysis of human skulls, the occurrence of additional bones within the cranial sutures was observed. The first photo shows the presence of WB in a non-regular shape located near the sagittal suture and lambdoid suture (Figure 1). The second photograph shows WB located near the following sutures: lambdoid, occipitomastoid and parietomastoid (Figure 2). The third photograph shows a large WB located near the following sutures: lambdoid and occipitomastoid (Figure 3).

Figure 1. Posterior view of the skull vault with the presence of the sutural bone. WB – Wormian bone, SS – sagittal suture, LS – lambdoid suture, OB – occipital bone, LPB/RPB –

Figure 2. Side view of the skull with the presence of the sutural bone. WB – Wormian bone, PS – parietomastoid suture, LS – lambdoid suture, OS – occipitmastoid suture, OB –

occipital bone, LPB – left parietal bone, LTB – left temporal bone

(photographed by Grzegorz Wróbel)

Figure 3. Posterior view of the skull with the presence of the sutural bone. WB – Wormian bone, LS – lambdoid suture, OS – occipitmastoid suture, OB – occipital bone, LPB – left

3. Discussion

WB connects with the surrounding bones with sutures and their recesses are more complex outside than on the inner surface of the skull. Morphologically, these bones have different shapes (oval, oblong, round, quadrilateral, polygonal, triangular) and sizes that may have a diameter of less than 1 mm to 5 x 9 cm [8]. There is a moderate degree of sexual dimorphism among the bone wormian with respect to overall frequency, number and location [9]. The prevalence of wormian bones was reported by various authors. For example, Patil and Sheelavant [10], analyzing 180 dry human skulls, showed that the total incidence of bone vermilion was more in women (64.80%) than in male skulls (40.20%). Wb occurred more often at lambdoid suture (60%). WB are more common in the human skull than previously reported, therefore doctors or radiologists should know about this anatomical variant not to confuse it with the clinical aspect during surgery or imaging the skull [11].

References

1. Nayak SB. Multiple Wormian bones at the lambdoid suture in an Indian skull. Neuroanatomy 2008; 7:52–53.

2. Bellary SS, Steinberg A, Mirzayan N, Shirak M, Tubbs RS, Cohen-Gadol AA, Loukas

M. Wormian bones: a review.Clin Anat. 2013 Nov;26(8):922-7.

doi: 10.1002/ca.22262.

3. Vasanthi A, Adinarayana KPS, Pujitha S. Morphological study of wormian bones in

cadaver skulls. Journal of Evidence based Medicine and Healthcare. 2015; 2(12):

1757-1762

4. Jeanty P, Silva SR, Turner C. Prenatal diagnosis of wormian bones. J Ultrasound Med 2000; 19:863–869.

5. Murlimanju BV, Prabhu LV, Ashraf CM, Kumar CG, Rai R and Maheshwari C. Morphological and topographical study of Wormian bones in cadaver dry skulls. J. Morphol. Sci. 2011; 28(3): 176-179.

6. Hernandez FG, Echeverria GM. Frequency of skull bones with lambdoid in artificial deformation in Northern Chile. Int J Morphol. 2009;27:933-8.

7. Raja SK, Siva NR, Sundara S. Incidence of sutural bones at pterion south Indian dried skulls. Int J Anat Res. 2016;4:2099-101.

8. Reveron RR. Anatomical Classification of Sutural Bones. MOJ Anat&Physiol.

2017;3:101. Khan AA, Asari MA, Hassan A. Unusual presence of wormian (sutural)

9. Khan AA, Asari MA, Hassan A. Unusual presence of wormian (sutural) bones in human skulls. Folia Morphol. 2011; 70(4): 291-294.

10. Patil M, Sheelavant S. Sexual Dimorphism among the Wormian Bones In Adult

Human Skulls.J Indian Acad Forensic Med. 2012; 34(2):124-127.
