chapter05_section01.pps

(1)

Slide 1 of 26

(2)

Slide 2 of 26

Models of the Atom

The scale model shown is a physical model. However, not all models are physical. In fact, several theoretical models of the atom have been developed over the last few hundred

years. You will learn about the currently accepted model of

how electrons behave in atoms.

(3)

Models of the Atom >

Slide 3 of 26

The Development of Atomic Models

The Development of Atomic Models

What was inadequate about Rutherford’s atomic model?

(4)

Slide 4 of 26

Models of the Atom > The Development of Atomic Models

Rutherford’s atomic model could not explain the chemical properties of elements.

Rutherford’s atomic model could not explain why objects change color when heated.

(5)

Slide 5 of 26

The timeline shoes the development of atomic models from 1803 to 1911.

(6)

Slide 6 of 26

The timeline shows the development of atomic models from 1913 to 1932.

(7)

Slide 7 of 26

The Bohr Model

The Bohr Model

What was the new proposal in the Bohr model of the atom?

(8)

Slide 8 of 26

Models of the Atom > The Bohr Model

Bohr proposed that an electron is found only in specific circular paths, or orbits, around the nucleus.

(9)

Slide 9 of 26

Each possible electron orbit in Bohr’s model has a fixed energy.

•

The fixed energies an electron can have are called energy levels.

•

A quantum of energy is the amount of energy required to move an electron from one energy level to another energy level.

(10)

Slide 10 of 26

Like the rungs of the strange ladder, the

energy levels in an atom are not equally spaced.

The higher the energy level occupied by an

electron, the less energy it takes to move from

that energy level to the next higher energy level.

(11)

Slide 11 of 26

The Quantum Mechanical Model

The Quantum Mechanical Model

What does the quantum mechanical

model determine about the electrons in an atom?

(12)

Slide 12 of 26

Models of the Atom > The Quantum Mechanical Model

The quantum mechanical model

determines the allowed energies an

electron can have and how likely it is to find the electron in various locations

around the nucleus.

(13)

Slide 13 of 26

Austrian physicist Erwin Schrödinger (1887– 1961) used new theoretical calculations and results to devise and solve a mathematical equation describing the behavior of the

electron in a hydrogen atom.

The modern description of the electrons in atoms, the quantum mechanical model,

comes from the mathematical solutions to the Schrödinger equation.

(14)

Slide 14 of 26

The propeller blade has the same probability of being anywhere in the blurry region, but you cannot tell its location at any instant. The

electron cloud of an atom can be compared to a spinning airplane propeller.

(15)

Slide 15 of 26

In the quantum mechanical model, the probability of finding an electron within a certain volume of space surrounding the nucleus can be represented as a fuzzy

cloud. The cloud is more dense where the probability of finding the electron is high.

(16)

Slide 16 of 26

Atomic Orbitals

Atomic Orbitals

How do sublevels of principal energy levels differ?

(17)

Slide 17 of 26

Models of the Atom > Atomic Orbitals

An atomic orbital is often thought of as a region of space in which there is a high

probability of finding an electron.

Each energy sublevel

corresponds to an orbital of a different shape, which

describes where the electron is likely to be found.

(18)

Slide 18 of 26

Different atomic orbitals are denoted by letters. The s orbitals are spherical, and p

orbitals are dumbbell-shaped.

(19)

Slide 19 of 26

Four of the five d orbitals have the same shape but different orientations in space.

(20)

Slide 20 of 26

The numbers and kinds of atomic orbitals depend on the energy sublevel.

(21)

Slide 21 of 26

The number of electrons allowed in each of the first four energy levels are shown here.

(22)

Slide 22 of 26

Animation 5

Observe the characteristics of atomic orbitals.

(23)

Slide 23 of 26

Section Quiz

-or-Continue to: Launch:

Assess students’ understanding of the concepts in Section

5.1 Section Quiz.

(24)

Slide 24 of 26 5.1 Section Quiz.

1. Rutherford's planetary model of the atom could not explain

a. any properties of elements.

b. the chemical properties of elements.

c. the distribution of mass in an atom.

(25)

2. Bohr's model of the atom proposed that electrons are found

a. embedded in a sphere of positive charge.

b. in fixed positions surrounding the nucleus.

c. in circular orbits at fixed distances from the nucleus.

(26)

3. What is the lowest-numbered principal energy level in which p orbitals are found?

a. 1

b. 2

c. 3
