Optimizing real power loss and voltage stability limit of a large transmission network using firefly algorithm

Full Length Article

Optimizing real power loss and voltage stability limit of a large

transmission network using firefly algorithm

P. Balachennaiah

*

, M. Suryakalavathi

, Palukuru Nagendra

c_{Department of Technical Education, Government Polytechnic, Chandragiri, Chittoor, Andhra Pradesh 517101, India}

A R T I C L E I N F O Article history:

Received 21 July 2015 Received in revised form 13 October 2015 Accepted 20 October 2015 Available online 18 December 2015 Keywords:

Firefly algorithm (FA) Optimal power flow (OPF) Continuation power Flow (CPF) Interior point successive linear programming (IPSLP)

Real coded genetic algorithm (RCGA) Unified power flow controller (UPFC)

A B S T R A C T

This paper proposes a Firefly algorithm based technique to optimize the control variables for simulta-neous optimization of real power loss and voltage stability limit of the transmission system. Mathematically, this issue can be formulated as nonlinear equality and inequality constrained optimization problem with an objective function integrating both real power loss and voltage stability limit. Transformers taps, unified power flow controller and its parameters have been included as control variables in the problem for-mulation. The effectiveness of the proposed algorithm has been tested on New England 39-bus system. Simulation results obtained with the proposed algorithm are compared with the real coded genetic al-gorithm for single objective of real power loss minimization and multi-objective of real power loss minimization and voltage stability limit maximization. Also, a classical optimization method known as interior point successive linear programming technique is considered here to compare the results of firefly algorithm for single objective of real power loss minimization. Simulation results confirm the potenti-ality of the proposed algorithm in solving optimization problems.

© 2016, Karabuk University. Publishing services by Elsevier B.V.

1. Introduction

In recent years, the Optimal Power Flow (OPF) has become an essential tool in power systems planning, operation and control for both integrated and deregulated power industries. OPF is stated as a nonlinear, nonconvex, static optimization problem with both dis-crete and continuous variables. The OPF problem solution aims to optimize certain objective functions like Real Power Loss (RPL) through optimal adjustment of various control variables, while satisfying both equality and inequality constraints. RPL minimization, generation cost minimization and voltage stability enhancement are the dif-ferent objectives of OPF problem. The mathematical formulation of OPF problem was firstly presented by Dommel and Tinny[1]and then the issue has been handled by several researchers. In the lit-erature, there are many conventional techniques such as Newton based programming method[2], Linear programming method[3] and recently Interior point method[4]to solve the OPF problem.

With the development of Flexible AC transmission Systems (FACTS) technology, there is a possibility of controlling power flow to improve power system performance without generation resched-uling and topology changes. Among all the FACTS controllers, Unified

Power Flow Controller (UPFC) is a popular device that provides flexibility in OPF by means of shunt and series compensation[5,6]. Glanzman and Anderson[7]coordinated several FACTS devices to avoid congestion, to provide secure transmission with reduced RPL. But, it is a well known fact that a secure operation of power system is not possible unless the optimization problem takes into account the system voltage security in its solution. Continuation Power Flow (CPF), a powerful tool, gives the information about the percentage of overloading capability of the system without voltage collapse[8]. In Reference[9], Milano et al. successfully included CPF problem into an OPF problem to address simultaneously both the security and the voltage collapse issues. voltage stability limit (VSL) is defined as the maximum percentage overloading (λmax) capability the system

can withstand without voltage collapse, which is considered as another objective function along with the RPL minimization, thereby redefining the task as multi-objective optimization problem. The difficulty with the traditional techniques lies in the fact that they are more sensitive to initial points due to non monotonic solution surface and so not able to find the global optimum. To overcome the restrictions of traditional algorithms, meta-heuristic algo-rithms have been applied to work out OPF problems. Recently, nature inspired meta-heuristic algorithms show a powerful and efficient performance for dealing with high dimension nonlinear OPF prob-lems. In all meta-heuristic search techniques, much effort has been devoted to make an appropriate trade-off between exploration and * Corresponding author. Tel.:+91 9441112015; fax: (08565) 251864.

E-mail address:[email protected](P. Balachennaiah). Peer review under responsibility of Karabuk University. http://dx.doi.org/10.1016/j.jestch.2015.10.008

2215-0986/© 2016, Karabuk University. Publishing services by Elsevier B.V.

Contents lists available atScienceDirect

Engineering Science and Technology,

an International Journal

j o u r n a l h o m e p a g e : h t t p : / / w w w. e l s e v i e r. c o m / l o c a t e / j e s t c h

Press: Karabuk University, Press Unit ISSN (Printed) : 1302-0056 ISSN (Online) : 2215-0986 ISSN (E-Mail) : 1308-2043

Available online at www.sciencedirect.com ScienceDirect

exploitation in searching for the optimal solutions. Many meta-heuristic algorithms have been applied to solve OPF problems, such as Particle Swarm Optimization (PSO)[10], Tabu Search (TS) algo-rithm[11], Bacteria Foraging Algorithm (BFA)[12], Differential Evolution (DE) algorithm[13], and Gravitational Search Algorithm (GSA)[14]. More recently, harmony search algorithm[15,16], Krill Herd (KH) algorithm[17–22]and monarch butterfly optimization [23]perform powerfully and efficiently in solving highly non linear optimization problems.

In the present paper, a meta-heuristic algorithm known as FA is employed to solve the combined OPF and CPF problem of RPL min-imization and VSL maxmin-imization. The FA is developed by “Xin-She Yang”[24–32]based on the flashing behavior of the fireflies which are available in nature. A comprehensive review of FA and its merits and demerits is given in Reference[27]. In Reference[33], the authors have applied FA to solve Economic Load Dispatch Problem (ELDP) and recently it has been applied to solve OPF problem, incorporat-ing Thyristor Controlled Series Capacitor (TCSC) to enhance power transfer capability of transmission line[34]. In this work, the control variables like transformer tap positions, UPFC location and its vari-ables are optimized with the FA to optimize the single objective function of RPL minimization and multi-Objective of RPL minimi-zation and VSL maximiminimi-zation, keeping all the variables within the limits. For both cases of single and multiple objectives, the opti-mization is carried out in three ways. First, only transformer taps are optimized, second UPFC location and its variables are only op-timized with fixed opop-timized tap positions, and finally both the transformer taps and UPFC variables are simultaneously opti-mized. New England 39-bus system is considered as the test system for simulation purpose. The simulation results are compared with the results of IPSLP method and RCGA method to show the poten-tiality of the proposed algorithm.

The structure of this paper is organized as follows.Section 2 pres-ents the mathematical formulations of single and multi-objective optimization problems along with principle of operation of UPFC. Section 3describes global numerical optimization, the FA. The RCGA method is presented insection 4.Section 5describes IPSLP tech-nique. Insection 6, the results of the proposed FA are compared with the results of RCGA and IPSLP methods. Finally,section 7provides the conclusion and points out the path of the future work.

2. Statement of the problem

Problem:To solve single objective function problem of RPL min-imization and multi-objective function problem of RPL minmin-imization and maximization of VSL of the New England 39 bus test systems, connected with UPFC by using IPSLP, RCGA and FA. Here, both se-quential and simultaneous allocation of transformer taps and UPFC are carried out for comparison.

2.1. Problem formulation of OPF

Mathematically, OPF problem of RPL minimization can be for-mulated as follows: Minimize F x u Subject to g x u h x u , , ,

(

)

(

)

(

)

F(x, u)is the fitness function equating to the RPL of the test system. g(x, u) is a set of non linear equality constraints to repre-sent power flow, andh(x, u) is a set of nonlinear inequality constraints i.e., bus voltages, transformer tap setting values, line MVA limits, etc. Vectorxconsists of state variables or dependent vari-ables and vector u consists of independent varivari-ables or control

variables. In this research work, the control variables are trans-former tap values, which can vary in between 0.85 and 1.15 in step of 0.05, series injected voltage magnitude (Vse) of UPFC with the

ranges [0, 0.3 p.u.] and series injected voltage phase angle (δse) of

UPFC with the range [0,2π]. All these control variables are opti-mized with IPSLP, RCGA and FA to minimize the RPL of the test system. Here, the minimum and the maximum voltages of load buses are considered as 0.9 p.u. and 1.1 p.u. for the test system. 2.2. OPF formulation considering with VSL

The single objective function could be extended further with the inclusion of VSL, results a new fitness function. The VSL can be cal-culated through continuation power flow (CPF) technique which introduces load parameter (λ) stated as the percentage increase of load and generation from its base value. The resulting load and gen-eration equations in terms of the load parameter are given as follows:

PLi=PLi0

(

λ

)

QLi=QLi0

(

λ

)

PGi=PGi0

(

λ

)

The load parameter (λ) can be increased until the system soon reaches the edge of instability, which is also called as notch point (NP) of the P–V curve. So the maximum value of the load parameter (λmax)

is known as voltage stability limit (VSL). The objective is to

Optimize F x u Subject to g x u h x u , , , , max λ

(

)

(

)

(

)

Since both the RPL and voltage stability limits are in different range of values, the fitness function is formulated as a weighted sum. The reciprocal of VSL is sum to original cost function and overall cost function can be minimized. The fitness function to be opti-mized now can be represented as follows:

F x u

(

)

(

)

(

)

where G x u

(

)

(

)

W1 is the weight adjustment for RPL and W2 is the weight ad-justment for VSL. Ideally, W1 and W2 are adjusted so that the weighted values of RPL and VSL are similar in value. To find out this critical point in the system, the process of CPF[8]is carried out for each so-lution generated. The load is increased in steps, and for each increment, the values are calculated by the process of prediction and correction. 2.3. Unified power flow controller

The UPFC structure shown inFig. 1basically shares the same dc-link to operate the two switching converters supplied by a common energy stored dc capacitor. The shunt and series transformers are used to couple the switching converter 1 and switching converter 2 to the power system network respectively. The converter 1 is con-nected in shunt to busiwhile the converter 2 is connected in series between busiand busj. The series converter injects the necessary control voltage with the desired magnitude and phase angle through the coupling transformer to control the flow of required active and reactive power in the transmission line. The basic function of shunt converter is to interchange the real power with the power system network to maintain the energy stored at the common dc-link

capacitor. The shunt converter is also capable to interchange the re-active power with the power system network thereby providing independent control of shunt reactive power compensation. Only one UPFC with injection model[35,36]is connected in the test system for simultaneous optimization of RPL and VSL enhance-ment. The UPFC injection model is shown inFig. 2.

3. Firefly algorithm

3.1. Overview

Fireflies use flash signals to attract other fireflies for potential mates. Based on this behavior, a metaheuristic algorithm was de-veloped by Xin-She Yang[24–26]. All the fireflies are considered unisexual and their attraction is directly proportional to the inten-sity of their flash. Therefore, if a firefly particle had the choice of moving toward either of two fireflies, it will be more attracted toward the firefly with higher brightness and moves in that direction. If there are no fireflies nearby, the firefly will move in a random direction. The brightness of flash is associated with the fitness function. The light intensity also obeys the inverse square law as in Equation(7)

I r I

r

s

( )

whereI(r)is the light intensity at a distancerandIsis the

inten-sity at the source. For a given medium with fixed absorption coefficientγ, the light intensityIvaries with the distancerand is given in Equation(8)as

I₌I0exp

(

γ

)

Here,I0is the original light intensity,γis the absorption

coeffi-cient andris the distance between the fireflies. As a firefly’s attractiveness is proportional to the light intensity seen by adja-cent fireflies, the attractivenessβof a firefly can be defined as

β β

(

γ

)

(

)

whereβ0is the attractiveness atr=0. For two firefliesiandj,ris

calculated as rij _k xi k xj k x x d i j =

∑

(

)

Equation(10)is the distance between any two firefliesiandj atxiandxjrespectively. In each generation, the fireflies move to

nearby fireflies having more brightness as determined by Equa-tion(11)as

xi=xi+

β

(

γ

)

(

)

αε

2

exp (11)

where α is the randomization parameter and ε is the vector of random numbers taken from Gaussian distribution. Here α con-trols the step size. The valueαis chosen to be 0.3, which controls randomly. Movement of the fireflies at the end of each genera-tion, the fireflies are ranked based on their brightness, and the best firefly in each generation is found. The fireflies are made to move in subsequent generations and in each generation; the light inten-sities of each firefly is updated with respect to the fitness function. At the end of all the generations, the firefly with the highest bright-ness, i.e., the best fitness value, is concluded as the optimal solution to the problem. The algorithm is found to be effective in solving noisy problems too. The number of fireflies is usually 20–40; in this case, the number of fireflies is chosen to be 30. The randomness in the movement of the firefly can be controlled by varying the parame-ter δ. In the problem, the value of δ is chosen to be 0.97. A higher value will facilitate more random movement by the fireflies and assist them in avoiding convergence to a local minimum.

3.2. Main algorithm

The basic steps of the FA can be summarized as the following:

Step 1:Initialization of the firefly algorithm (i) The dimension of the problem (ii) The number of fireflies

(iii) The maximum number of iterations (iv) The values ofα,β,γandδare chosen.

(v) Iteration counteri=0

Step 2:Increment the iteration counteri=i+1

Step 3:Calculate the fitness of the fireflies in every iteration by using the fitness functions as given in Equations(1)and(6)and associate light intensity of each firefly to the same.

Step 4:Sort the fireflies with varying intensities and find the best firefly in each iteration.

Step 5:Vary the light intensity perception of all other fireflies based on the distance between them.

Step 6:Move the fireflies based on attraction, which depends on light intensities and also control parameters.

Step 7:If the stopping criteria in not reached, go back to step 2 else go to step 8.

Step 8:Display the results with the firefly particle of highest light intensity.

The parameters of the FA are given inTable 1and the flow-chart is shown inFig. 3.

Fig. 1. Device basic arrangement.

(

)

sin

p

= −

rb VV

θ

+

γ

(

)

cos

Q

= −

rb VV

θ

+

γ

( )

cos

Q

=

rb V

γ

X

V

∠

θ

V

∠

θ

4. Real coded genetic algorithm (RCGA)

4.1. Overview

Real coded Genetic Algorithm is chosen over standard GA owing to its advantages in solving optimization problem with continu-ous and discrete parameters. RCGA mimics the process of natural selection which results in evolution of organisms with better ad-aptation to the environment[37–39]. The same behavior is used to solve multi-dimensional complex problems. The method has been proven effective for solving problems than binary coded algo-rithm. The algorithm considers solutions as genes and performs gene manipulation. The discrete values are stored with preset resolu-tions, whereas the continuous values are encoded as they are. The control parameters of RCGA are as given inTable 2.

The probability of mutation is valued at 0.12. A higher value will result in chaotic nature and convergence is affected. A lower value results in convergence at local minima. The following steps are per-formed to solve the fitness function for optimal solution. 4.2. Main algorithm

The basic steps of the RCGA can be summarized as follows:

Step 1:Initialize the population with random solutions within the limits.

Step 2:Find the fitness value of the solutions using the fitness functions as given in Equations(1)and(6).

Step 3:Crossover:Two random solutionsXiandXjare chosen and

crossover function is performed, in which parts of two parents combine to form a new offspring. Unlike standard GA, in RCGA, this is done with real values asX_new=(1−λ)*Xi+λ*Xj, whereλ

is the crossover parameter.

Step 4:Mutation:A part of the solution is mutated to a new random value. This results in a new value which is different from the previous solution. This is controlled by a probability factor called probability of mutation.

Step 5:Elitism:The number of members in the population is maintained in every generation. The weakest members are re-placed by newer offspring/mutants that have better fitness in every generation

Step 6:Find the best member in every generation.

Step 7:Steps 2–6 are repeated until the number of iterations has reached a preset limit.

Step 8:The results are displayed for the best solution.

5. Interior point successive linear programming (IPSLP) technique

The OPF problem of RPL minimization can be formulated as follows: Minimize F x x u u Subject to g x x u u h x x u 0 0 0 0 0 0 0 ± ±

(

)

(

)

(

)

wherex0_,u0_{are the initial values ofxandu;}

Δx, Δuindicate the step length from initial point

and g,hindicate the linear approximation of non linear problem. IPSLP Algorithm:

Step 1: Solve the power flow problem.

Step 2: Linearize the Optimal power flow (OPF) problem and for-mulate it as fitness function.

Step 3: Linearize the incremental network model.

Step 4: Compute the linearly constrained OPF by primal–dual in-terior point method.

Step 5: Update the control variables byΔu; solve the exact non-linear power flow problem.

Step 6: Evaluate the cost function for the updated control variables.

Step 7: If the optimality solution is reached, then terminate the algorithm; otherwise, go to step 2 and continue.

6. Simulation results and discussion

The effectiveness of the proposed method has been tested on the New England 39 bus test system[40]shown inFig. 4. The test system Table 1

Parameters of FA.

S. No. Parameters Quantity

1 Number of fireflies 30 2 Maximum iterations 100 3 Randomness (α) 0.3 4 Absorption coefficient (γ) 1.0 5 Attractiveness (β) 0.2 Start Initialization of parameters

Generate random variables

While Iter < max

Evaluate light intensities based on fitness function

Find best firefly

Move fireflies based on attraction

Iter = iter+1

Terminate No

Yes

Fig. 3. The flowchart of FA.

Table 2

Parameters of RCGA.

S. No. Parameters Quantity

1 Population size (NP) 40

2 Number of generations 30

3 Cross over probability (Pc) 0.6

4 Lambda (λ) 0.5

characteristics are given inTable 3. The test system has 10 genera-tors at buses from 30 to 39 and 12 transformers T1to T12located

in the lines 2–30, 10–32, 12–11, 12–13, 19–33, 19–20, 20–34, 22–35, 23–36, 25–37, 29–38, 31–6 respectively.

A software program for IPSLP, RCGA and FA has written in MATLAB 8.3 version and run on core i5, 2.50 GHz and 4.0 GB RAM computer. Power flow is solved for the base case to find RPL and the VSL is obtained using CPF technique. For the test system with nominal values of taps, the RPL is 0.4378 p.u. and the VSL is 0.81. Next, the proposed methodology is applied to optimize only RPL (denoted as FAS) and simultaneously optimize the RPL and VSL (denoted as FAM) of power system. Simulation results for differ-ent cases are discussed below.

6.1. Case 1: transformer taps only optimized

6.1.1. Case 1.1: optimization of RPL only (single objective case) When only transformer taps are optimized with IPSLP tech-nique for single objective of RPL, the loss is reduced from 0.4378 p.u. to 0.4266 p.u. With the optimized taps, the CPF is run for

estimating the VSL and found the value of 0.78. For the same case with the RCGA, the RPL and VSL obtained are 0.42141 p.u. and 0.75 respectively. Similarly, the transformer taps are optimized with FA for the same single objective of RPL, the loss are further reduced to 0.4203 p.u. and the VSL is 0.81. The optimized transformer taps along with RPL and VSL are given inTable 4, which indicates the Fig. 4. New England 39 bus test system.

Table 3

Test systems characteristics.

S. No. Data Quantity

1 Number of buses 39 2 Generator buses 10 3 Load buses 29 4 Transmission lines 46 5 Transformers 12 6 Total load (MW) 6097.10 Table 4

Optimized transformer taps only (transformer taps as control variables). Control

variables

Optimization of only RPL (single objective case)

Optimization of both RPL and VSL (multi-objective case)

IPSLP RCGASa _FASb _RCGAMc _FAMd

T1 1.10 1.05 1.15 1.10 1.10 T2 1.10 1.15 1.10 1.05 1.05 T3 0.95 1.10 1.05 1.10 1.05 T4 1.10 1.05 1.05 1.05 1.05 T5 1.10 1.05 1.15 1.00 1.10 T6 1.00 1.05 1.10 1.10 1.10 T7 1.10 1.05 1.10 1.00 1.05 T8 1.10 1.10 1.10 1.10 1.10 T9 1.10 1.05 1.10 1.15 1.15 T10 1.10 1.05 1.10 1.05 1.05 T11 1.05 1.10 1.15 1.05 1.10 T12 1.10 1.10 1.10 1.10 1.10

RPL 0.4266p.u. 0.42141p.u. 0.4203p.u. 0.436912p.u. 0.43082p.u.

VSL 0.78 0.75 0.81 0.84 0.84

Bold font has been used to indicate the proposed algorithm and better performance. a

RCGA is applied to optimize only RPL denoted as RCGAS. b _{FA is applied to optimize only RPL denoted as FAS.}

c _{RCGA is applied to optimize both RPL and VSL denoted as RCGAM.} d

potentiality of the FA over the IPSLP and RCGA methods in loss re-duction. In the single objective case, VSL is not included in the fitness function.Figs. 5–7show the PV curves of the weakest bus for case 1.1 by IPSLP, RCGA and FA respectively. The performance charac-teristics of RCGA and FA are shown inFig. 8.

6.1.2. Case 1.2: optimization of both RPL and VSL (multi objective case)

When both RPL and VSL are optimized, the cost function is modi-fied. The reciprocal of VSL is added to the RPL and the optimization is carried out with RCGA and FA methods. Transformer tap values along with RPL and VSL are given inTable 4. From the results, it is seen that the VSL is improved but losses are increased marginally with both the methods. Even RPL is increased slightly, the overall multi-objective function that is the sum of RPL and recip-rocal of VSL is reduced with both the methods compared to single objective case. It is noticed here that with the proposed method the overall multi-objective function (RPL+1/VSL) is further reduced

showing a better performance than the RCGA.Figs. 9 and 10show the PV curve of the weakest bus for case 1.2 by RCGA and FA respectively.

6.2. Case 2: UPFC location and its variables are optimized by keeping the taps in fixed position

6.2.1. Case 2.1: optimization of RPL only (single objective case) With the optimized transformer tap values, the UPFC location and its parameters are optimized with IPSLP, RCGA and FA tech-niques. In the test system, only 32 lines were considered for connecting the UPFC as the remaining 14 lines consist transform-ers and feeding generator powtransform-ers to the network[39]. In IPSLP technique, the UPFC is connected in all the 32 lines considering one at a time, as it cannot be linearized through perturbation and so it is not a control variable. Here, the RPL are reduced from 0.4266 p.u. to 0.3798 p.u. with the best location and UPFC injection voltage in each succession of linearization. With optimized UPFC variables, the CPF is carried out to calculate the VSL and obtained value is 0.84.

0 0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0 0.2 0.4 0.6 0.8 1 1.2

Load parameter (Lambda)

V o lt a g e i n p .u IPSLP

Fig. 5. P–V curve of the weakest bus for case 1.1 (IPSLP).

0 0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0 0.2 0.4 0.6 0.8 1 1.2

Load parameter (Lambda)

V o lt a g e i n p .u RCGAS

Fig. 6. P–V curve of the weakest bus for case 1.1 (RCGAS).

0 0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9 0 0.2 0.4 0.6 0.8 1 1.2

Load parameter (Lambda)

V o lt a g e i n p .u FAS

Fig. 7. P–V curve of the weakest bus for case 1.1 (FAS).

0 5 10 15 20 25 30 35 42 42.2 42.4 42.6 42.8 43 43.2 43.4 43.6 43.8 Ite ra ti o n s F it n e s s F u n c ti o n V a lu e FA RCGA

In the case of RCGA and FA, the line at which UPFC should be con-nected is decided randomly out of 32 lines selected in the initial stage. So with RCGA and FA, the line number in which UPFC is to be connected also becomes a control variable along with others. With RCGA and FA methods, the UPFC location and its variables are op-timized keeping the opop-timized transformer taps fixed and found that the losses are reduced from 0.42141 p.u. to 0.37056 p.u. with RCGA and 0.4203 p.u. to 0.3545 p.u. with FA as given inTable 5along with optimized UPFC location and its parameters. The VSL values cal-culated from the two methods are also given inTable 5. From the results, it is clear that when a nonlinear device like UPFC is con-nected in the system, both RCGA and FA are able to find the global minimum, whereas IPSLP algorithm converges at local minimum only. As UPFC is connected in the system, there is further reduc-tion in the losses obtained with RCGA and FA compared to case 1.1. Moreover, the FA gives global value of RPL showing the strength in optimizing the losses compared to RCGA.Figs. 11–13show the PV curves of the weakest bus for case 2.1 by IPSLP, RCGA and FA methods

0 0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9 0 0.2 0.4 0.6 0.8 1 1.2

Load parameter (Lambda)

V o lt a g e i n p .u RCGAM

Fig. 9.P–V curve of the weakest bus for case 1.2 (RCGAM).

0 0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9 0 0.2 0.4 0.6 0.8 1 1.2

Load parameter (Lambda)

V o lt a g e i n p .u FAM

Fig. 10. P–V curve of the weakest bus for case 1.2 (FAM).

Table 5

Optimized UPFC parameters keeping optimized taps in fixed position. Control

variables

Optimization of only RPL (single objective case)

Optimization of both RPL and VSL (multi-objective case)

IPSLP RCGASa _FASb _RCGAMc _FAMd

UPFC series injected voltage (Vse)

0.0099 p.u. 0.0234 p.u. 0.0294 p.u. 0.0100 p.u. 0.0096 p.u.

UPFC series injected voltage phase angle (δse)

1.040 rad 1.6774 rad 1.9330 rad 1.000 rad 0.9134 rad

UPFC location

3–4 16–19 26–29 21–22 26–27

RPL 0.3798 p.u. 0.37056 p.u. 0.3545 p.u. 0.390307 p.u. 0.3742 p.u.

VSL 0.84 0.84 0.900 0.990 1.020

Bold font has been used to indicate the proposed algorithm and better performance. a

RCGA is applied to optimize only RPL denoted as RCGAS. b

FA is applied to optimize only RPL denoted as FAS. c

RCGA is applied to optimize both RPL and VSL denoted as RCGAM. d

FA is applied to optimize both RPL and VSL denoted as FAM.

0 0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9 0 0.2 0.4 0.6 0.8 1 1.2

Load parameter (Lambda)

V o lt a g e i n p .u IPSLP

Fig. 11. P–V cure of the weakest bus for case 2.1 (IPSLP).

0 0.2 0.4 0.6 0.8 1 1.2 0 0.2 0.4 0.6 0.8 1 1.2

Load parameter (Lambda)

V o lt a g e i n p .u RCGAS

respectively. The performance characteristics of the RCGA and FA for single objective case are also shown inFig. 14.

6.2.2. Case 2.2: optimization of both RPL and VSL (multi objective case)

With the optimized transformer taps in fixed position, the UPFC location and its parameters are optimized by RCGA and FA for multi objective case of RPL and VSL.Table 5shows the optimized UPFC location and its parameters along with RPL and VSL. Although the loss in this case is marginally increased compared to single objec-tive case, the overall multi-objecobjec-tive function i.e., the sum of RPL and reciprocal of VSL, is reduced with both RCGA and FA methods. Also, compared to case 1.2, the multi objective function (RPL+1/ VSL) is further reduced because of introduction of the UPFC. It is noticed here from the results that the reduction of RPL and im-provement of VSL, i.e., reduction of multi-objective function, is obtained with FA showing the efficacy over the RCGA. The PV curves for the weakest bus of RCGA and FA are shown inFigs. 15 and 16.

6.3. Case 3: simultaneous optimization of UPFC location and its variables along with taps

6.3.1. Case 3.1: optimization of RPL only (single objective case) With the IPSLP technique, the UPFC variables along with taps (12 transformer taps, UPFC series injected voltage magnitude and Phase angle) are simultaneously optimized and found that the RPL is 0.3947 p.u. and VSL is 0.87. Similarly, with RCGA and FA techniques, the UPFC location and its variables along with taps are simultane-ously optimized. The values of RPL and VSL along with optimized UPFC parameters and transformer taps are given inTable 6. It is ob-served from the simulation results that the losses obtained from FA technique are low as compared to IPSLP and RCGA techniques. Also it is noticed from the previous results of case 1.1 and case 2.1 that the losses are further reduced as in this case control variables are simultaneously optimized with RCGA and FA.Figs. 17–19show the PV curves of the weakest bus for single objective case by IPSLP, RCGA and FA respectively. The performance characteristics of RCGA and FA for single objective case are shown inFig. 20.

0 0.2 0.4 0.6 0.8 1 1.2 0 0.2 0.4 0.6 0.8 1 1.2

Load parameter (Lambda)

V o lt a g e i n p .u FAS

Fig. 13. P–V curve of the weakest bus for case 2.1 (FAS).

5 10 15 20 25 30 35 35 36 37 38 39 40 41 42 43 Iterations F it n e s s F u n c ti o n V a lu e RCGA FA

Fig. 14. Performance characteristics of RCGA and FA for case 2.1.

0 0.2 0.4 0.6 0.8 1 1.2 0 0.2 0.4 0.6 0.8 1 1.2

Load parameter (Lambda)

V o lt a g e i n p .u RCGAM

Fig. 15.P–V curve of the weakest bus for case 2.2 (RCGAM).

0 0.2 0.4 0.6 0.8 1 1.2 0 0.2 0.4 0.6 0.8 1 1.2

Load parameter (Lambda)

V o lt a g e i n p .u FAM

6.3.2. Case 3.2: optimization of both RPL and VSL (multi objective case)

With RCGA and FA techniques all the variables are simultane-ously optimized for multi-objective case and obtained the values of RPL and VSL given inTable 6. Here the losses are marginally in-creased compared to single objective case, but overall multi-objective function i.e., the sum of RPL and reciprocal of VSL, is reduced with both RCGA and FA methods. Compared to case 1.2 and case 2.2, the multi objective function (RPL+1/VSL) is further reduced as the control variables are simultaneously optimized. Also it is noticed here from the results that the reduction of RPL and Table 6

Simultaneously optimized parameters of UPFC along with transformers tap settings. Control

variables

Optimization of only RPL (single objective case)

Optimization of both RPL and VSL (multi-objective case)

IPSLP RCGASa _FASb _RCGAMc _FAMd

T1 1.00 1.00 1.10 1.10 1.00 T2 1.00 0.95 1.00 1.10 1.05 T3 1.05 0.95 1.00 1.15 1.05 T4 1.00 1.00 1.00 0.95 1.05 T5 1.05 1.05 1.00 1.00 1.10 T6 1.05 1.05 1.00 1.00 1.10 T7 1.05 1.00 1.00 1.15 1.05 T8 1.05 1.05 1.05 0.95 1.05 T9 1.05 1.10 1.00 1.00 1.00 T10 1.00 1.05 1.05 1.10 1.10 T11 1.05 0.95 1.05 1.00 1.05 T12 1.05 1.00 1.00 0.95 1.05 UPFC series injected voltage (Vse)

0.010 p.u. 0.012167 p.u. 0.0225 p.u. 0.030000 p.u. 0.0168 p.u.

UPFC series injected voltage phase angle (δse)

1.000 rad 0.937246 rad 1.2759 rad 1.000 rad 1.2544 rad

UPFC location

4–14 17–18 16–24 28–29 16–19

RPL 0.3947 p.u. 0.3694 p.u. 0.3463 p.u. 0.381822 p.u. 0.3617 p.u.

VSL 0.870 0.870 0.930 0.990 1.080

Bold font has been used to indicate the proposed algorithm and better performance. a_{RCGA is applied to optimize only RPL denoted as RCGAS.}

b _{FA is applied to optimize only RPL denoted as FAS.} c

RCGA is applied to optimize both RPL and VSL denoted as RCGAM. d

FA is applied to optimize both RPL and VSL denoted as FAM.

0 0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9 0 0.2 0.4 0.6 0.8 1 1.2

Load Parameter (Lambda)

V o lt a g e ( p .u ) IPSLP

Fig. 17. P–V curve of the weakest bus for case 3.1 (IPSLP).

0 0.2 0.4 0.6 0.8 1 1.2 0 0.2 0.4 0.6 0.8 1 1.2

Load parameter (Lambda)

V o lt a g e s i n p .u RCGAS

Fig. 18. P–V curve of the weakest bus for case 3.1 (RCGA).

0 0.2 0.4 0.6 0.8 1 1.2 0 0.2 0.4 0.6 0.8 1 1.2

Load parameter (Lambda)

V o lt a g e i n p .u FAS

Fig. 19. P–V curve of the weakest bus for case 3.1 (FAS).

5 10 15 20 25 30 35 34 35 36 37 38 39 40 Iterations F it n e s s F u n c ti o n V a lu e FA RCGA

improvement of VSL i.e., reduction of multi-objective function, is obtained with FA indicating potentiality and superiority over the RCGA. P–V curves of the weakest bus (multi objective case) are shown inFigs. 21 and 22.

6.4. Robustness evaluation

To test the robustness of FA, 10 trial runs were performed for New England 39 bus test system.Tables 7–9show the results of RPL values for case studies 1.1, 2.1 and 3.1. It can be seen here that the

optimal RPL obtained by the proposed FA for all the three cases is always nearer to the average value, which is also lesser than RCGA, showing the robustness and superiority of the proposed FA method for the OPF problem of RPL minimization.

7. Conclusion

FA method has been successfully implemented in this paper to find the optimum control variables for OPF problem of RPL mini-mization (single objective case) and for simultaneous optimini-mization of RPL and VSL (multi-objective case). Transformers tap settings, UPFC location, series injected voltage magnitude and phase angle of UPFC have been considered as control variables. From the results, it is ob-served that optimization of the control variables for single objective of RPL led to deterioration of VSL, but for multi-objective case, even though the loss has increased slightly, the combined cost function has reduced with significant improvement in VSL. Simulation results of the proposed method are compared with the results of the IPSLP method for single objective of RPL and found that the FA method is superior in loss minimization as the IPSLP technique is not able to find global optimum because non linear device like UPFC is in-troduced in the system. Also, to compare the simulation results of the proposed algorithm for both single and multi-objective cases, RCGA technique was considered. The results obtained with the FA in all the cases are much better and hence it is concluded that the proposed method has the ability to obtain near global solution with stable convergence characteristics for optimization problems. Thus, the proposed FA may be recommended as a promising algorithm for solving some more complex engineering optimization prob-lems for the future researchers.

Acknowledgement

The authors convey deep sense of gratitude to the manage-ment of Annamacharya Institute of Technology and Sciences for helping with required facilities to complete this work.

References

[1]H.W. Dommel, T.F. Tinny, Optimal power flow solution, IEEE Trans. Power Apparatus Syst. 30 (2002) 469–483.

[2]P. Nagendra, S.H. Dey, T. Datta, S. Paul, Voltage stability assessment of a power system incorporating FACTS controllers using unique network equivalent, Ain Shams Eng. J. 5 (2014) 103–111.

[3]P. Ristanovic, Successive linear programming based optimal power flow solution, optimal power flow solution techniques, requirements and challenges, IEEE Power Eng. Soc. (1996).

0 0.2 0.4 0.6 0.8 1 1.2 0 0.2 0.4 0.6 0.8 1 1.2

Load parameter (Lambda)

V o lt a g e s i n p .u RCGAM

Fig. 21. P–V curve of the weakest bus for case 3.2 (RCGAM).

0 0.2 0.4 0.6 0.8 1 1.2 0 0.2 0.4 0.6 0.8 1 1.2

Load parameter (Lambda)

V o lt a g e i n p .u FAM

Fig. 22. P–V curve of the weakest bus for case 3.2 (FAM).

Table 7

RPL values for New England 39 bus system for 10 trials (case study 1.1). S. No. Method RPL

Best loss value Worst loss value Average loss value 1 FA 0.4203 p.u. 0.43177 p.u. 0.42503 p.u. 2 RCGA 0.421419 p.u. 0.426628 p.u. 0.425843 p.u.

3 IPSLP 0.4266 p.u. NA NA

Bold font inTable 7indicates the results obtained from the proposed algorithm.

Table 8

RPL values for New England 39 bus system for 10 trials (case study 2.1). S. No. Method RPL

Best loss value Worst loss value Average loss value 1 FA 0.354563 p.u. 0.38934 p.u. 0.37124 p.u. 2 RCGA 0.37056 p.u. 0.39945 p.u. 0.37685 p.u.

3 IPSLP 0.3798 p.u. NA NA

Bold font inTable 8indicates the results obtained from the proposed algorithm.

Table 9

RPL values for New England 39 bus system for 10 trials (case study 3.1). S. No. Method RPL

Best loss value Worst loss value Average loss value 1 FA 0.3463 p.u. 0.37744 p.u. 0.36953 p.u. 2 RCGA 0.369446 p.u. 0.38967 p.u. 0.37374 p.u.

3 IPSLP 0.3947 p.u. NA NA

[4] J.L. Martinez, A. Ramous, G. Exposito, V. Quintana, Transmission loss reduction by interior point methods: implementation issues and practical experience, IEE Proc. Gener. Transm. Distrib. 152 (2005) 90–98.

[5] L. Gyugyi, The unified power flow controller: a new approach to power transmission control. Presented at 1994 IEEE Summer Meeting, paper No.94-SM 474-7. 1994.

[6] M. Noroozian, L. Angquist, M. Ghandhari, G. Anderson, Use of UPFC for optimal power flow controller, IEEE Trans. Power Deliv. 12 (1997) 1629–1634.

[7] G. Glanzman, G. Anderson, Coordinated control of FACTS based on optimal power flow, in: Proceedings of 37th annual North America Power Symposium Ames, IA, October 23–25, 2005.

[8] V. Ajjarpu, C. Christy, The continuation power flow: a tool for steady state voltage stability analysis, IEEE Trans. Power Syst. 7 (1992) 416–423.

[9] F. Milano, C.A. Canizares, A.J. Conejo, Sensitivity-based security constrained OPF market clearing model, IEEE Trans. Power Syst. 20 (2005) 2051–2060.

[10] M.A. Abido, Optimal power flow using particle swarm optimization, Electr. Power Energy Syst. 24 (2002) 563–571.

[11] M.A. Abido, Optimal power flow by using tabu search algorithm, Electr. Power Compon. Syst. 30 (2002).

[12] M. Tripathy, S. Mishra, L.L. Lai, Q.P. Zhang, Transmission loss reduction on FACTS and bacteria foraging algorithm, in: Parallel Problem Solving from Nature – PPSN IX, vol. 4193, 2006, pp. 222–231.

[13] A.A. Abou El Ela, M.A. Abido, S.R. Spea, Optimal power flow using differential evolution algorithm, Electr. Power Syst. Res. 80 (2010) 878–885.

[14] S. Duman, U. Guvenc, Y. Sonmez, N. Yorukeren, Optimal power flow using gravitational search algorithm, Energy Convers. Manag. 59 (2012) 86–95.

[15] G. Wang, L. Guo, H. Duan, H. Wang, L. Liu, M. Shao, Hybridizing harmony search with biogeography based optimization for global numerical optimization, J. Comput. Theor. Nanosci. 10 (2013) 2312–2322.

[16] G.-G. Wang, A.H. Gandomi, X. Zhao, H. Cheng, E. Chu, Hybridizing harmony search algorithm with cuckoo search for global numerical optimization, Soft Comput. (2014) doi:10.1007/s00500-014-1502-7.

[17] G. Wang, L. Guo, H. Wang, H. Duan, L. Liu, J. Li, Incorporating mutation scheme into krill herd algorithm for global numerical optimization, Neural Comput. Appl. 24 (2014) 853–871.

[18] G.-G. Wang, A.H. Gandomi, A.H. Alavi, An effective krill herd algorithm with migration operator in biogeography based optimization, Appl. Math. Model. 38 (2014) 2454–2462.

[19] G.-G. Wang, L. Guo, A.H. Gandomi, G.-S. Hao, H. Wang, Chaotic krill herd algorithm, Inf. Sci. (Ny) 274 (2014) 17–34.

[20] L. Guo, G.-G. Wang, A.H. Gandomi, A.H. Alavi, H. Duan, A new improved krill herd algorithm for global numerical optimization, Neurocomputing 138 (2014) 392–402.

[21] G.-G. Wang, A.H. Gandomi, A.H. Alavi, Stud krill herd algorithm, Neurocomputing 28 (2014) 363–370.

[22] G.G. Wang, A.H. Gandomi, A.H. Alavi, G.S. Hao, Hybrid krill herd algorithm with differential evolution for global numerical optimization, Neural Comput. Appl. 25 (2014) 297–308.

[23] G.-G. Wang, S. Deb, Z. Cui, Monarch butterfly optimization, Neural Comput. Appl. (2015) doi:10.1007/s00521-015-1923-y.

[24] X.S. Yang, Firefly algorithm, in: Nature Inspired Metaheuristic Algorithms, Luniver Press, Beckington, UK, 2008, pp. 81–89.

[25] X.S. Yang, Firefly algorithm: stochastic test functions and design optimization, Int. J. Bioinspired Comput. 2 (2010) 78–84.

[26] X.S. Yang, Firefly algorithm for multimodal optimization, SAGA 20 (5792) (2009) 169–178.

[27] I. Fister, I. Fister Jr., X.-S. Yang, J. Brest, A comprehensive review of firefly algorithms, Swarm Evol. Comput. 13 (2013) 34–46.

[28] S. Padhan, R.K. Sahu, S. Panda, Application of firefly algorithm for load frequency control of multi-area interconnected power system, Electr. Power Compon. Syst. 42 (2014) 1419–1430.

[29] G.-G. Wang, L. Guo, H. Duan, H. Wang, A new improved firefly algorithm for global numerical optimization, J. Comput. Theor. Nanosci. 11 (2014) 477– 485.

[30] S. Shamshirband, D. Petkovic, N.T. Pavlovic, C. Sudheer, T.A. Altameem, A. Gani, Support vector machine firefly algorithm based optimization of lens system, Appl. Opt. 54 (2015) 37–45.

[31] L. Olatomiwa, S. Mekhilef, S. Shamshirband, K. Mohammadi, D. Petkovic, C. Sudheer, A support vector machine-firefly algorithm based model for global solar radiation prediction, Sol. Energy 115 (2015) 632–644.

[32] I. Fister Jr., M. Perc, S.M. Kamal, I. Fister, A review of chaos-based firefly algorithm: perspectives and research challenges, Appl. Math. Comput. 252 (2015) 155–165.

[33] M.H. Sulaiman, M.W. Mustafa, Z.N. Zakaria, O. Alimano, S.R.A. Rahim, Firefly algorithm technique for solving economic dispatch problem, in: Power Engineering and Optimization Conference, Melaka, Malaysia, 6–7 June, 2012.

[34] B. Venkateswararao, G. Venakata Nagesh Kumar, Optimal location of Thyristor controlled series capacitor to enhance power transfer capability using firefly algorithm, Electr. Power Compon. Syst. 42 (2014) 1541–1552.

[35] M. Tripathy, S. Mishra, Bacteria foraging based solution to optimize both real power loss and voltage stability limit, IEEE Trans. Power Syst. 22 (2007) 1.

[36] E. Acha, C.R. Feurte Esquivel, H. Ambritz-Perez, C. Angeles-Camacho, Modeling and Simulation in Power Network, John Wiley and Sons Ltd., 2004.

[37] N. Amjady, H. Nasiri, Economic dispatch using an efficient real coded genetic algorithm, IET Gener. Transm. Distrib. 3 (2008) 266–278.

[38] A. Balnco, M. Delgado, M.C. Pegalair, A real coded genetic algorithm for training recurrent neural networks, Neural Netw. 14 (2001) 93–105.

[39] S. Panda, S.C. Swain, A.K. Baliarsingh, Real coded genetic algorithm for robust coordinated design of excitation and SSSC based controller, J. Electr. Eng. 8 (2008) 31–38.

[40] S. Mishra, M. Tripathy, J. Nanda, Multi-machine power system stabilizer design by rule based bacteria foraging, Electr. Power Syst. Res. 77 (2007) 1595– 1607.
