Performance Analysis and Tuning

in Windows HPC Server 2008

Xavier Pillons Program Manager Microsoft Corp. [email protected]

(2)

Introduction

• How to monitor performance on Windows ?

• What to look for ?

• How to tune the system ?

(3)

(4)

Performance Analysis • Cluster wide – Built in Diagnostics – The Heatmap • Local – Perfmon – xperf

(5)

Built-in Network Diagnostics

• MPI Ping-Pong (mpipingpong.exe)

– Launchable via HPC Admin Console Diagnostics

• Pro’s: Easy, Data is auto-stored for historical comparison • Con’s: No choice of network, no intermediate results

– Launchable via command line

• Command Line Features

– Tournament mode, ring mode, serial mode

– Output progress to xml, stderr, stdout

– Histogram, per-node, and per-cluster data

– Test throughput / latency or both

• Remember: Usually you want only1 rank per node 

(6)

(7)

Basic Network Troubleshooting

• Know Expected Bandwidths and Latencies

• Make sure drivers and firmware are up to date

• Use the product diagnostics to confirm

– Or Pallas Pingpong, etc.

Network Bandwidth Latency

IB QDR (ConnectX PCI-E 2.0) 2400MB/s 2µs IB DDR (ConnectX PCI-E 2.0) 1500MB/s 2µs IB DDR (ConnectX PCI-E 1.0) 1400MB/s 2.8µs IB DDR / ND 1400MB/s 5µs IB SDR /ND 950MB/s 6µs IB / IPoIB 200-400MB/s 30µs Gige 105MB/s 40-70µs

(8)

Cluster Sanity Checks

(9)

(10)

Basic Tools - Perfmon

Counter Tolerance Used For

Processor /%CPU time 95% User mode bottleneck

Processor / %Kernel Time 10% Kernel issues Processor / %DPC time 5% RSS, Affinity

Processor / %Interrupt Time 5% Misbehaving drivers Network / Output Queue Length 1 Network bottleneck

Disk / Average Queue Length 1 / platter Disk bottleneck Memory / Pages Per Sec 1 Hard Faults System/ Context Switches per sec 20,000 Locks, wasting

processing

(11)

(12)

Windows Performance Toolkit

• Official performance analysis tools from Windows

– Used to optimize Windows itself

• Wide support range

– Cross platform: Vista, Server 2008/R2, Win7 – Cross architecture: x86, x64, ia64

• Very low overhead – live capture on production systems

– Less than 2 % processor overhead for a sustained rate of 10,000 events/second on a 2GHz processor

• The only tool that lets you correlate most of the fundamental system

activity

– All processes and threads, both user and kernel mode

– DPCs and ISRs, thread scheduling, disk and file I/O, memory usage, graphics subsystem, etc.

• Available externally: part of Windows 7 SDK

(13)

(14)

(15)

NetworkDirect

• Verbs-based design for close fit with native, high-perf networking

interfaces

• Equal to Hardware-Optimized stacks for MPI micro-benchmarks

• NetworkDirect drivers for key high-performance fabrics:

– Infiniband [available now!]

– 10 Gigabit Ethernet

(iWARP-enabled) [available now!]

– Myrinet[available soon]

• MS-MPIv2 has 4 networking paths:

– Shared Memory between processors on a motherboard

– TCP/IP Stack (“normal” Ethernet)

– Winsock Direct for sockets-based RDMA

– New NetworkDirect interface

User Mode Kernel Mode TCP/Ethernet Networking Ke rn el By -P ass MPI App Socket-Based App MS-MPI Windows Sockets (Winsock + WSD) Networking Hardware Networking Hardware Networking Hardware Networking Hardware Networking Hardware _{Hardware Driver} Networking Hardware Networking Hardware Mini-port Driver TCP NDIS IP Networking Hardware Networking Hardware User Mode Access Layer

Networking Hardware Networking Hardware WinSock Direct Provider Networking Hardware Networking Hardware NetworkDirect Provider RDMA Networking OS Component HPCS2008 Component IHV Component (ISV) App

(16)

MS-MPI Fine tuning

• Lots of MPI parameters (mpiexec –help3) :

– MPICH_PROGRESS_SPIN_LIMIT

• 0 is adaptive, otherwise 1-64K

– SHM / SOCK / ND eager limit

• Switchover point for eager / rendezvous behaviour

– ND ZCOPY threshold

• Sets the switchover point between bcopy and zcopy

– Buffer-reuse and registration cost affect this ( registration ~= 32K bcopy )

– Affinity

(17)

Reducing OS Jitter

• Track Hard Fault with xperf

– Disable non used services (up to 42+)

– Delete Windows scheduled tasks

(18)

Tuning Memory Access

• Effective memory use is rule #1

• Processor Affinity is key here

• Need to know the Processor architecture

(19)

GigE Blade Chassis 8-core servers InfiniBand 16-core servers 32-core servers InfiniBand InfiniBand GigE 10 GigE 10 GigE

A big model (requires Large memory machines)

An ISV application (requires Nodes where the application is installed) APP C0 C1 M C2 C3 M Quad-core C0 C1 M C2 C3 |||||||| |||||||| |||||||| |||||||| M M M M M M M M P0 P1 P2 P3 32-core IO IO

4-way Structural Analysis MPI Job

A P P A P P A P P A P P A P P A P P Multi-threaded application (requires machine with many Cores) APP Numa Aware Capacity Aware Application Aware

node groups, job templates, filters, affinity

Process Placement

A P P A P P A P P A P P A P P A P P

(20)

MPI Process Placement

• Request resource with JOB:

/numnodes:N /numsockets:N /numcores:N /exclusive

• Control Placement with MPIEXEC:

– cores X

– n X

– affinity

Examples

• job submit /numcores:4

mpiexec foo.exe

• job submit /numnodes:2

mpiexec –c 2 –affinity foo.exe

Compute Node

http://blogs.technet.com/windowshpc/archive/2008/09/16/mpi-process-placement-with-windows-hpc-server-2008.aspx

(21)

Force Affinity

• mpiexec -affinity

• start /wait /b /affinity <mask> app.exe

• Windows API

– SetProcessAffinityMask

– SetThreadAffinityMask

(22)

Core and Affinity mask for woodcrest

Processor 2 Processor 1 Core 0 Core 1 L2 Cache Core 2 Core 3 L2 Cache System Bus

Bus Interface Bus Interface

0x01 0x02 0x04 0x08 0x03 0x0C 0x0F 0x00 0x00 0x00

Processor Affinity Mask L2 Cache Affinity Mask Core Affinity Mask

Core 4 Core 5 L2 Cache

Core 6 Core 7 L2 Cache Bus Interface Bus Interface

0x10 0x20 0x40 0x80

0x30 0xC0

(23)

Finer control of affinity

• to overcome hyperthreading on NH

• mpiexec setaff.cmd mpiapp.exe

@REM setaff.cmd – set affinity based on MPI Rank @IF "%PMI_SMPD_KEY%" == "7" set AFFINITY=1 @IF "%PMI_SMPD_KEY%" == "1" set AFFINITY=2 @IF "%PMI_SMPD_KEY%" == "5" set AFFINITY=4 @IF "%PMI_SMPD_KEY%" == "3" set AFFINITY=8 @IF "%PMI_SMPD_KEY%" == "4" set AFFINITY=10 @IF "%PMI_SMPD_KEY%" == "2" set AFFINITY=20 @IF "%PMI_SMPD_KEY%" == "6" set AFFINITY=40 @IF "%PMI_SMPD_KEY%" == "0" set AFFINITY=80 start /wait /b /affinity %AFFINITY% %*

(24)

(25)

Devs can't tune what they can't see

• MS-MPI Tracing:

Single, time-correlated log of MPI Events on All Nodes

• Dual purpose:

– Performance Analysis

– Application Trouble-Shooting

• Trace Data Display

– VAMPIR (TU Dresden)

– Intel Trace Analyzer

– MPICH Jumpshot (Argonne NL)

– Windows ETW tools

(26)

MS-MPI Tracing Overview

• MS-MPI includes “Built-In” Tracing

– Low Overhead

– Based on Event Tracing for Windows (ETW)

– No need to recompile your application

• Three Step Process

– Trace: mpiexec –trace [event category] MyApp.exe

– Sync: clocks across nodes (mpicsync.exe)

– Convert: to Viewing format

• Explained in excruciating detail in:

“Tracing MPI Apps with Windows HPC Server 2008”

• Traces can also be triggered via any ETW mechanism (Xperf, etc.)

(27)

Step 1 – Tracing and filtering

• mpiexec -trace MyApp.exe

• mpiexec -trace (PT2PT,ICND) MyApp.exe

– PT2PT : Point to point communication

– ICND : Network Direct Interconnect Communication

– These event groups are defined in the file

mpitrace.mof which resides in the %CCP_HOME%\bin\

folder

• log files written on each node in %userprofile%

– mpi_trace_{JobID}.{TaskID}.{TaskInstanceID}.etl

• Trace filename can be overriden with –tracefile

(28)

Step 2 – Clock synchronisation

• Use mpiexec and mpicsync to correct trace file

timestamps for each node used in a job

– mpiexec –cores 1 mpicsync mpi_trace_42.1.0.etl

• mpicsync uses uniquely trace (.etl) file data to

calculate CPU clock corrections

• mpicsync must be run as an MPI program

– mpiexec -cores 1 –wdir %%USERPROFILE%% mpicsync

(29)

Step 3 - Format the Binary .etl File For Viewing

• Format to TEXT, OTF, CLOG2

– tracefmt, etl2otf and etl2clog

– Format the event log and apply clock corrections

• Leverage the power of your cluster by using

mpiexec to translate all your .etl files

simultaneously on the compute nodes used for your trace job

– mpiexec -cores 1 -wdir %%USERPROFILE%% etl2otf mpi_trace_42.1.0.etl

• Finally collect trace files from all nodes in a single

(30)

Helper script TraceMyMPI.cmd

• Provided as part of the

tracing whitepaper

• Execute all the require

steps

(31)

(32)

(33)

Resources

• The windows performance toolkit is here

– http://www.microsoft.com/whdc/system/sysperf/perf tools.mspx

• Windows Internals series is very good

• Basic windows server tuning is here

– http://www.microsoft.com/whdc/system/sysperf/Perf _tun_srv.mspx

• Process Affinity in HPC Server 2008 SP1

– http://blogs.technet.com/windowshpc/archive/2009/ 10/01/process-affinity-and-windows-hpc-server-2008-sp1.aspx
