Influence of rolling parameters on dynamically recrystallized
microstructures in AZ31 magnesium alloy sheets
Lili Guo
a,*
, Fumio Fujita
ba
School of Materials Science and Engineering, Dalian Jiaotong University, Liaoning, Dalian, 116028, China
b
Department of Metallurgy, Graduate School of Engineering, Tohoku University, Aoba, Sendai, 980-8579, Japan Received 1 December 2014; revised 16 April 2015; accepted 21 April 2015
Available online 16 May 2015
Abstract
Conventional rolling experiments via the embedded pin in rolling sheet method were carried out at different reduction rates, starting rolling temperatures, and rolling speeds, and the effects of rolling parameters (i.e., temperature, equivalent strain, and rolling time) on dynamically recrystallized (DRX) microstructures of AZ31 alloy during hot rolling were studied quantitatively. The temperature-strain dependence of the high-angle grain boundary fraction (HAGB%) was examined through electron backscattered diffraction. Results showed that as-rolled micro-structures with high HAGB% may be obtained under average rolling temperatures of 270e320C, equivalent strains higher than 0.8, and a rolling speed of 246 mm/s. These results may be related to the DRX kinetics and dynamic recovery which are controlled by deformation temperature and strain. HAGB% decreased with increasing rolling time (decreasing rolling speed), which is attributed to dynamic recovery, and the recrystallized grain size decreased as rolling time increased. However, further increases in rolling time increased average grain sizes but decreased mean subgrain sizes; these results are attributed to increases in the low-angle grain boundary (LAGB) length per unit area with rolling time. LAGB formation was controlled by dynamic recovery, which consistently follows polygonization or formation of new subgrains inside larger grains; hence, average subgrain sizes decreased with the rolling time. The effect of dynamic recovery on HAGB and LAGB formation and their related mechanisms over a wide range of strains and temperatures were discussed in detail.
Copyright 2015, National Engineering Research Center for Magnesium Alloys of China, Chongqing University. Production and hosting by Elsevier B.V. All rights reserved.
Keywords: Magnesium alloys; Hot rolling; Dynamic recrystallization (DRX); Microstructure
1. Introduction
Magnesium alloys are the lightest commercial structural alloys currently available. These alloys have significant po-tential applications in the automotive and electronic industries because of their low density, high specific strength, and good damping characteristics. However, the use of wrought mag-nesium alloys is fairly limited because these materials also feature low ductility and formability at ambient temperature
[1e4]. As such, determining optimal processing parameters during hot deformation of magnesium alloys is necessary to enhance their ductility and formability. Conventional rolling is a suitable technique for producing large-sized sheets; such sheets do not require complex roll shapes and may potentially meet industrial needs [5]. To date, a significant amount of research has been performed to examine microstructural changes in magnesium alloys during hot rolling[6e11]. Both grain refinement and basal texture control during hot rolling are important to enhance the formability and ductile behavior of magnesium alloy sheets at room temperature [12,13]. Multi-pass rolling tests in previous studies were conducted by adopting different reductions per pass, thereby yielding marked differences in strain and rolling temperatures for
* Corresponding author. Tel.: þ86 411 84106527. E-mail address:[email protected](L. Guo).
Peer review under responsibility of National Engineering Research Center for Magnesium Alloys of China, Chongqing University.
