Hydraulic Pump&Motor Ref.guide

(1)

(2)

Machine Model:

Agricultural Tractors

...3

Articulated Trucks

...6

Backhoe Loaders

...8

Excavators

...10

Forest Machines

...28

Front Shovel Excavators

...30

Integrated Toolcarriers

...30

Landfill Compactors

...32

Motor Graders

...33

Off-Highway Trucks

...40

Paving Product — Asphalt Pavers

...43

Paving Product — Cold Planers

...44

Paving Product — Pneumatic Tired Compactors

...45

Paving Product — Road Reclaimers / Soil Stabilizers

...45

Paving Product — Vibratory Compactors

...46

Pipelayers

...48

Scrapers

...50

Soil Compactors

...69

Telehandlers

...70

Track Loaders

...70

Track-Type Tractors

...82

Tractors

...105

Wheel Loaders

...106

Wheel Tractors

...128

Class

...131

Part Number and Class

...176

(3)

Pumps and motors tend to be designed and manufactured in discreet sizes. Therefore, classifications for pumps

and motors can be assigned with reasonable assurance that the consists within each classification will have

few and minor variations. For example, a range of flows (displacements) for an entire series of vane type pumps can

be achieved by simply changing the profile ground into the cam ring. No other parts within the vane pump cartridge

change.

A similar situation exists for gear and piston type pumps and motors. Gear pumps and motors within a classification

have the same pitch diameter and tooth profile. The displacement is increased or decreased by lengthening or

shortening the gear tooth. Piston pumps and motors usually have the same rotating groups within a classification.

Variations are achieved by adjustments to swashplate angles and controls.

This guide does not include power train pumps and motors, or track motors and rotating groups in the HPCU of the Cat

Hydrostatic Track Type Loaders.

This guide will be improved and updated continually. Your comments and suggestions will be important in this process

and are strongly encouraged.

SECTION 1 (Model Listing)

Lists the pumps and motors, sorted by Cat machine family and Cat machine model. This list is cross-referenced to the

part number and classification. This section makes it easier for the parts and service sales representative to talk

knowledgeable to customers and present repair cost estimates.

SECTION 2 (Class)

Groups pumps and motors by classification, identifying the Cat machine model, serial number, system and part

number. This section helps the person responsible for repair options to prioritize the development of classifications

and to select the pump part numbers used to develop the repair option estimates.

SECTION 3 (Part Number to Class)

An alpha-numerical listing of all pump and motor part numbers in the guide, cross referenced to their classification.

With this section, a repair estimate can be made when only the part number is known.

SECTION 4 (Group Number to Reman Part/Group Number)

This section allows identification of remanufactured pump/motor part and group availability through pump/motor group

numbers.

(4)

AGRICULTURAL TRACTORS

35 Auxiliary 8DN1-UP 1082903 Pump Gear Fixed N/A

8DN1-UP 1240500 Pump Piston Variable N/A 8095 8DN1-UP 1274588 Pump Piston Variable 1

Multiple Applications 7DM1-UP 6E4947 Motor Piston Variable N/A 6075

45 Auxiliary 1DR1-UP 1082903 Pump Gear Fixed N/A

1DR1-UP 1240500 Pump Piston Variable N/A 8095 1DR1-UP 1274588 Pump Piston Variable 1

Multiple Applications 8DN1-UP 6E4947 Motor Piston Variable N/A 6075 55 Multiple Applications 1DR1-UP 6E4947 Motor Piston Variable N/A 6075

65 Steering 6GS1-UP 1010858 Motor Piston Variable N/A 6502

7YC1-467 1010858 Motor Piston Variable N/A 6502 7YC503-1899 1010858 Motor Piston Variable N/A 6502

Implement 7YC1-467 6E0355 Pump Gear Fixed 1 6652

7YC503-1899 6E0355 Pump Gear Fixed 1 6652 Multiple Applications 7YC1-467 6E0356 Pump Piston Variable 1 5500 7YC503-1899 6E0356 Pump Piston Variable 1 5500

7YC1-467 6E1288 Pump Gear Fixed 2 1016

7YC503-1899 6E1288 Pump Gear Fixed 2 1016 Application Unknown 7YC1-467 6E1333 Pump Piston Variable N/A 6100 7YC503-1899 6E1333 Pump Piston Variable N/A 6100

7YC1-467 6E1792 Pump Gear Fixed 3

7YC503-1899 6E1792 Pump Gear Fixed 3

Multiple Applications 7YC1-467 6E1826 Pump Piston Variable N/A 6100 7YC503-1899 6E1826 Pump Piston Variable N/A 6100

7YC1-467 6E4345 Pump Gear Fixed 2 1016

7YC503-1899 6E4345 Pump Gear Fixed 2 1016 Application Unknown 7YC1-502 6E4947 Motor Piston Variable N/A 6075 7YC503-1899 6E4947 Motor Piston Variable N/A 6075

6GS1-UP 7T7953 Pump Gear Fixed 1

7YC1-467 7T7953 Pump Gear Fixed 1

7YC1-502 9T1413 Pump Piston Variable 1 5500 7YC503-1899 9T1413 Pump Piston Variable 1 5500

Auxiliary 7YC1-502 9T4604 Pump Gear Fixed N/A

7YC503-1899 9T4604 Pump Gear Fixed N/A Application Unknown 7YC1-502 9T5119 Pump Gear Fixed 1 2005

7YC503-1899 9T5119 Pump Gear Fixed 1 2005 Auxiliary 7YC1-502 9T5426 Motor Piston Variable N/A 6075 7YC503-1899 9T5426 Motor Piston Variable N/A 6075 Application Unknown 7YC1-502 9T5743 Pump Piston Variable N/A

7YC503-1899 9T5743 Pump Piston Variable N/A 65B Steering 7YC1900-2200 1010858 Motor Piston Variable N/A 6502

Implement 7YC1900-2200 6E0355 Pump Gear Fixed 1 6652

Multiple Applications 7YC1900-2200 6E0356 Pump Piston Variable 1 5500 7YC1900-2200 6E1288 Pump Gear Fixed 2 1016 Application Unknown 7YC1900-2200 6E1333 Pump Piston Variable N/A 6100

(5)

65B (cont.) Application Unknown 7YC1900-2200 6E1792 Pump Gear Fixed 3

Multiple Applications 7YC1900-2200 6E1826 Pump Piston Variable N/A 6100 7YC1900-2200 6E4345 Pump Gear Fixed 2 1016 Application Unknown 7YC1900-UP 6E4947 Motor Piston Variable N/A 6075

7YC1900-UP 9T1413 Pump Piston Variable 1 5500

Auxiliary 7YC1900-UP 9T4604 Pump Gear Fixed N/A

Application Unknown 7YC1900-UP 9T5119 Pump Gear Fixed 1 2005 Auxiliary 7YC1900-UP 9T5426 Motor Piston Variable N/A 6075 Application Unknown 7YC1900-UP 9T5743 Pump Piston Variable N/A

65C Steering 2ZJ1-1964 1010858 Motor Piston Variable N/A 6502

Auxiliary 2ZJ1-678 1064711 Pump Piston Variable 1 2ZJ679-1964 1064711 Pump Piston Variable 1 9AM1-UP 1064711 Pump Piston Variable 1

Application Unknown 2ZJ1-678 1071246 Pump Piston Variable 1 5057 2ZJ679-1964 1071246 Pump Piston Variable 1 5057 Multiple Applications 2ZJ1-683 1071246 Pump Piston Variable 1 5057 Auxiliary 2ZJ1-678 1261184 Pump Piston Variable 1 5057 2ZJ679-1964 1261184 Pump Piston Variable 1 5057

2ZJ1-678 1274589 Pump Piston Variable 1 2ZJ679-1964 1274589 Pump Piston Variable 1 9AM1-UP 1274589 Pump Piston Variable 1

Application Unknown 2ZJ1-678 6E4946 Pump Piston Variable N/A 6100 2ZJ679-1683 6E4946 Pump Piston Variable N/A 6100 2ZJ1684-1964 6E4946 Pump Piston Variable N/A 6100 Multiple Applications 2ZJ1-683 6E4946 Pump Piston Variable N/A 6100 Application Unknown 2ZJ1-678 6E4947 Motor Piston Variable N/A 6075 2ZJ679-1683 6E4947 Motor Piston Variable N/A 6075 2ZJ1684-1964 6E4947 Motor Piston Variable N/A 6075 Multiple Applications 2ZJ1-683 6E4947 Motor Piston Variable N/A 6075 Application Unknown 2ZJ1-678 6E5329 Pump Gear Fixed 2 1016 2ZJ679-1683 6E5329 Pump Gear Fixed 2 1016 2ZJ1684-1964 6E5329 Pump Gear Fixed 2 1016 Multiple Applications 2ZJ1-683 6E5329 Pump Gear Fixed 2 1016 Application Unknown 2ZJ1-678 6E5477 Pump Piston Variable 1 5021 2ZJ679-1683 6E5477 Pump Piston Variable 1 5021 2ZJ1684-1964 6E5477 Pump Piston Variable 1 5021 Multiple Applications 2ZJ1-683 6E5477 Pump Piston Variable 1 5021 Application Unknown 2ZJ1-678 7T7953 Pump Gear Fixed 1

2ZJ679-1964 7T7953 Pump Gear Fixed 1

65D Steering 2ZJ1965-UP 1010858 Motor Piston Variable N/A 6502

Auxiliary 2ZJ1965-UP 1064711 Pump Piston Variable 1

Application Unknown 2ZJ1965-UP 1071246 Pump Piston Variable 1 5057 Auxiliary 2ZJ1965-UP 1261184 Pump Piston Variable 1 5057

2ZJ1965-UP 1274589 Pump Piston Variable 1

Application Unknown 2ZJ1965-UP 6E4946 Pump Piston Variable N/A 6100 2ZJ1965-UP 6E4947 Motor Piston Variable N/A 6075

(6)

65D (cont.) Application Unknown 2ZJ1965-UP 6E5329 Pump Gear Fixed 2 1016 2ZJ1965-UP 6E5477 Pump Piston Variable 1 5021

2ZJ1965-UP 7T7953 Pump Gear Fixed 1

70C Steering 2YL1-267 1010858 Motor Piston Variable N/A 6502

2YL266-1319 1010858 Motor Piston Variable N/A 6502 Auxiliary 2YL1-265 1064711 Pump Piston Variable 1

2YL266-1319 1064711 Pump Piston Variable 1

Application Unknown 2YL1-265 1071246 Pump Piston Variable 1 5057 2YL266-1319 1071246 Pump Piston Variable 1 5057 Multiple Applications 2YL1-267 1071246 Pump Piston Variable 1 5057 Auxiliary 2YL1-265 1261184 Pump Piston Variable 1 5057 2YL266-1319 1261184 Pump Piston Variable 1 5057

2YL1-265 1274589 Pump Piston Variable 1 2YL266-1319 1274589 Pump Piston Variable 1

Multiple Applications 2YL1-267 6E4946 Pump Piston Variable N/A 6100 2YL1-267 6E4947 Motor Piston Variable N/A 6075

2YL1-267 6E5329 Pump Gear Fixed 2 1016

Application Unknown 2YL1-265 7T7953 Pump Gear Fixed 1

2YL266-1319 7T7953 Pump Gear Fixed 1

75 Steering 4CJ1-634 1010858 Motor Piston Variable N/A 6502

Application Unknown 4CJ1-UP 6E0356 Pump Piston Variable 1 5500 Multiple Applications 4CJ1-634 6E0356 Pump Piston Variable 1 5500 Application Unknown 4CJ1-UP 6E1288 Pump Gear Fixed 2 1016 Multiple Applications 4CJ1-634 6E1288 Pump Gear Fixed 2 1016 Cooling - Implement 4CJ1-634 6E1324 Pump Gear Fixed 1 1014 Application Unknown 4CJ1-UP 6E1826 Pump Piston Variable N/A 6100 Multiple Applications 4CJ1-634 6E1826 Pump Piston Variable N/A 6100 Application Unknown 4CJ436-UP 6E4345 Pump Gear Fixed 2 1016 Multiple Applications 4CJ1-634 6E4345 Pump Gear Fixed 2 1016 Application Unknown 4CJ1-UP 6E4947 Motor Piston Variable N/A 6075

4CJ1-634 7T7953 Pump Gear Fixed 1

75C Steering 4KK1-UP 1010858 Motor Piston Variable N/A 6502

Auxiliary 4KK1-846 1064711 Pump Piston Variable 1 4KK847-UP 1064711 Pump Piston Variable 1

Application Unknown 4KK1-846 1071246 Pump Piston Variable 1 5057 4KK847-UP 1071246 Pump Piston Variable 1 5057 Multiple Applications 4KK1-866 1071246 Pump Piston Variable 1 5057 Auxiliary 4KK1-846 1261184 Pump Piston Variable 1 5057 4KK847-UP 1261184 Pump Piston Variable 1 5057

4KK1-846 1274589 Pump Piston Variable 1 4KK847-UP 1274589 Pump Piston Variable 1

Application Unknown 4KK1867-UP 6E4946 Pump Piston Variable N/A 6100 Multiple Applications 4KK1-866 6E4946 Pump Piston Variable N/A 6100 Application Unknown 4KK1867-UP 6E4947 Motor Piston Variable N/A 6075 Multiple Applications 4KK1-866 6E4947 Motor Piston Variable N/A 6075 Application Unknown 4KK1867-UP 6E5329 Pump Gear Fixed 2 1016 Multiple Applications 4KK1-866 6E5329 Pump Gear Fixed 2 1016

(7)

75C (cont.) Application Unknown 4KK1-846 6E5477 Pump Piston Variable 1 5021 4KK847-1866 6E5477 Pump Piston Variable 1 5021 4KK1867-UP 6E5477 Pump Piston Variable 1 5021 Multiple Applications 4KK1-866 6E5477 Pump Piston Variable 1 5021 Application Unknown 4KK1-846 7T7953 Pump Gear Fixed 1

4KK847-UP 7T7953 Pump Gear Fixed 1

75D Steering 5AR1-UP 1010858 Motor Piston Variable N/A 6502

Auxiliary 5AR1-UP 1064711 Pump Piston Variable 1

Application Unknown 5AR1-UP 1071246 Pump Piston Variable 1 5057 Auxiliary 5AR1-UP 1261184 Pump Piston Variable 1 5057

5AR1-UP 1274589 Pump Piston Variable 1 Application Unknown 5AR1-UP 7T7953 Pump Gear Fixed 1

75G Steering 6HS1-UP 1010858 Motor Piston Variable N/A 6502

Application Unknown 6HS1-UP 7T7953 Pump Gear Fixed 1

85 Steering 6JS1-UP 1010858 Motor Piston Variable N/A 6502

Application Unknown 6JS1-UP 7T7953 Pump Gear Fixed 1

85C Steering 9TK1-423 1010858 Motor Piston Variable N/A 6502

9TK424-UP 1010858 Motor Piston Variable N/A 6502 Auxiliary 9TK1-423 1064711 Pump Piston Variable 1

9TK424-UP 1064711 Pump Piston Variable 1

Application Unknown 9TK1-423 1071246 Pump Piston Variable 1 5057 9TK424-UP 1071246 Pump Piston Variable 1 5057 Multiple Applications 9TK1-400 1071246 Pump Piston Variable 1 5057 Auxiliary 9TK1-423 1261184 Pump Piston Variable 1 5057 9TK424-UP 1261184 Pump Piston Variable 1 5057

9TK1-423 1274589 Pump Piston Variable 1 9TK424-UP 1274589 Pump Piston Variable 1

Multiple Applications 9TK1-400 6E4946 Pump Piston Variable N/A 6100 9TK1-400 6E4947 Motor Piston Variable N/A 6075

9TK1-400 6E5329 Pump Gear Fixed 2 1016

9TK1-400 6E5477 Pump Piston Variable 1 5021 Application Unknown 9TK1-423 7T7953 Pump Gear Fixed 1

9TK424-UP 7T7953 Pump Gear Fixed 1

85D Steering 4GR1-UP 1010858 Motor Piston Variable N/A 6502

Auxiliary 4GR1-UP 1064711 Pump Piston Variable 1

Application Unknown 4GR1-UP 1071246 Pump Piston Variable 1 5057 Auxiliary 4GR1-UP 1261184 Pump Piston Variable 1 5057

4GR1-UP 1274589 Pump Piston Variable 1 Application Unknown 4GR1-UP 7T7953 Pump Gear Fixed 1

95 Steering 6KS1-UP 1010858 Motor Piston Variable N/A 6502

Application Unknown 6KS1-UP 7T7953 Pump Gear Fixed 1

ARTICULATED TRUCKS

D20D Power Train 9MG1-UP 1T1810 Pump Gear Fixed N/A

Steering 9MG1-UP 6E5290 Pump Gerotor Fixed 1 4500

Application Unknown 9MG1-118 7U7307 Pump Gerotor Fixed 1 5019 Multiple Applications 9MG1-UP 7U7307 Pump Gerotor Fixed 1 5019 Application Unknown 9MG1-118 7U7358 Pump Piston Variable 1 5019

(8)

D20D (cont.) Multiple Applications 9MG1-UP 7U7358 Pump Piston Variable 1 5019

Steering 9MG1-UP 9T9433 Pump Gerotor Fixed 1 4500

D25C Auxiliary 9YC1-1011 6U5329 Pump Gear Fixed N/A

D25D Steering 1HK1-UP 6C0570 Pump Gerotor Fixed 1 4700

Application Unknown 1HK1-UP 7U4172 Pump Gear Fixed 1

1HK1-UP 8P8208 Pump Gear Fixed 2

D30C Auxiliary 7ZC1-257 6U5329 Pump Gear Fixed N/A

D30D Application Unknown 3AJ1-UP 7U4172 Pump Gear Fixed 1

D35 HPC Application Unknown 3FD1-79 5U0558 Pump Vane Fixed 2 13525

Steering 3FD77-UP 6C0570 Pump Gerotor Fixed 1 4700

3FD1-76 6E6406 Pump Gerotor Fixed N/A 4500

D35C Auxiliary 2GD1-124 6U5329 Pump Gear Fixed N/A

Application Unknown 2GD1-UP 8P8208 Pump Gear Fixed 2

D35HPC Multiple Applications 3FD1-79 5U0558 Pump Vane Fixed 2 13525

D40D Application Unknown 2JJ1-100 5U0558 Pump Vane Fixed 2 13525 Multiple Applications 2JJ1-UP 5U0558 Pump Vane Fixed 2 13525

Auxiliary 2JJ1-100 7U4064 Pump Gear Fixed N/A

2JJ1-100 7U6666 Pump Gear Fixed N/A

Application Unknown 2JJ1-100 7U9191 Pump Gear Fixed N/A

D250B Steering 5WD1-UP 6C0570 Pump Gerotor Fixed 1 4700

Auxiliary 5WD1-550 6U5329 Pump Gear Fixed N/A

5WD1-550 6U8013 Pump Vane Fixed 2 13520

Application Unknown 5WD1-550 7U4172 Pump Gear Fixed 1

5WD1-UP 8P8208 Pump Gear Fixed 2

D250D Steering 6NG1-UP 6E5290 Pump Gerotor Fixed 1 4500

Application Unknown 6NG1-UP 7U6875 Pump Piston Variable 1 5019 6NG1-384 7U7307 Pump Gerotor Fixed 1 5019 Multiple Applications 6NG1-UP 7U7307 Pump Gerotor Fixed 1 5019 Application Unknown 6NG1-UP 8P8208 Pump Gear Fixed 2

Steering 6NG1-UP 9T9433 Pump Gerotor Fixed 1 4500

D250E Transmission 5TN1-UP 1178584 Pump Gear Fixed 2

D300B Auxiliary 4SD1-573 6U5329 Pump Gear Fixed N/A

4SD1-573 6U8013 Pump Vane Fixed 2 13520

Application Unknown 4SD1-573 7U4172 Pump Gear Fixed 1

D300D Steering 5MG1-UP 6E5290 Pump Gerotor Fixed 1 4500

Application Unknown 5MG1-509 7U4172 Pump Gear Fixed 1

Multiple Applications 5MG1-UP 7U6875 Pump Piston Variable 1 5019 Application Unknown 5MG1-509 7U7306 Pump Piston Variable 1 5019 Multiple Applications 5MG1-UP 7U7306 Pump Piston Variable 1 5019 Application Unknown 5MG1-UP 8P8208 Pump Gear Fixed 2

Steering 5MG1-UP 9T9433 Pump Gerotor Fixed 1 4500

D300E Transmission 7FN1-UP 1178584 Pump Gear Fixed 2

D350C Auxiliary 8XC1-404 6U5329 Pump Gear Fixed N/A

Application Unknown 8XC1-UP 8P8208 Pump Gear Fixed 2

D350D Steering 9RF1-UP 6C0570 Pump Gerotor Fixed 1 4700

Application Unknown 9RF1-UP 7U4172 Pump Gear Fixed 1

(9)

D350E Auxiliary 9LR1-UP 7U4064 Pump Gear Fixed N/A

9LR1-UP 7U6666 Pump Gear Fixed N/A

Application Unknown 9LR1-UP 7U9191 Pump Gear Fixed N/A

D400 Application Unknown 1MD1-246 5U0558 Pump Vane Fixed 2 13525

Steering 1MD1-UP 6E6406 Pump Gerotor Fixed N/A 4500

D400D Application Unknown 8TF1-1303 5U0558 Pump Vane Fixed 2 13525

Multiple Applications 8TF1-UP 5U0558 Pump Vane Fixed 2 13525

Steering 8TF1-UP 6C0570 Pump Gerotor Fixed 1 4700

Auxiliary 8TF1-1303 7U4064 Pump Gear Fixed N/A

8TF1-1303 7U6666 Pump Gear Fixed N/A

Application Unknown 8TF1-1303 7U9191 Pump Gear Fixed N/A

D400E Auxiliary 2YR1-UP 7U4064 Pump Gear Fixed N/A

2YR1-UP 7U6666 Pump Gear Fixed N/A

Application Unknown 2YR1-UP 7U9191 Pump Gear Fixed N/A

BACKHOE LOADERS

416 Auxiliary 5PC1-10761 1177760 Pump Piston Variable 1

5PC10762-16624 1177760 Pump Piston Variable 1

5PC1-4221 4T6895 Pump Piston Variable 1 5021

Steering 5PC1-10761 4T6896 Pump Gear Fixed 1 4500

5PC10762-UP 4T6896 Pump Gear Fixed 1 4500 Implement 5PC1-10761 9T4699 Pump Piston Variable 1 5027 5PC10762-16624 9T4699 Pump Piston Variable 1 5027 Implement & Steering 5PC1-4221 9T6857 Pump Piston Variable 1 5021 5PC4222-10761 9T6857 Pump Piston Variable 1 5021 5PC10762-UP 9T6857 Pump Piston Variable 1 5021 416B Application Unknown 8SG1-UP 1003259 Pump Piston Variable 1 6510 Multiple Applications 8ZK1-UP 1003259 Pump Piston Variable 1 6510

Steering 8SG12231-UP 1186796 Pump Gear Fixed 1

8SG1-11999 4T6896 Pump Gear Fixed 1 4500

416C Auxiliary 1AR1-UP 1126564 Pump Piston Variable 1 6510

1BR1-UP 1126564 Pump Piston Variable 1 6510 1KR1-UP 1126564 Pump Piston Variable 1 6510 1LR1-UP 1126564 Pump Piston Variable 1 6510 1WR1-UP 1126564 Pump Piston Variable 1 6510 1XR1-UP 1126564 Pump Piston Variable 1 6510 4ZN1-UP 1126564 Pump Piston Variable 1 6510 5YN1-UP 1126564 Pump Piston Variable 1 6510

426 Steering 7BC1-3476 4T6896 Pump Gear Fixed 1 4500

7BC3477-UP 4T6896 Pump Gear Fixed 1 4500

Implement & Steering 7BC1-1877 4T6962 Pump Piston Variable 1 5027 7BC1-3476 9T4833 Pump Piston Variable 1 5027 7BC3477-UP 9T4833 Pump Piston Variable 1 5027 426B Application Unknown 5YJ1-UP 1003259 Pump Piston Variable 1 6510 Multiple Applications 6KL1-UP 1003259 Pump Piston Variable 1 6510

Steering 5YJ1-2377 1058657 Pump Gear Fixed 1

6KL1-UP 1058657 Pump Gear Fixed 1

(10)

426B (cont.) Steering 5YJ1-2299 4T6896 Pump Gear Fixed 1 4500 Auxiliary 5YJ1-2377 6E5280 Pump Piston Variable 1 6510 6KL1-UP 6E5280 Pump Piston Variable 1 6510 Multiple Applications 5YJ1-UP 6E5280 Pump Piston Variable 1 6510

426C Auxiliary 1CR1-UP 1126564 Pump Piston Variable 1 6510

1ER1-UP 1126564 Pump Piston Variable 1 6510 1MR1-UP 1126564 Pump Piston Variable 1 6510 1NR1-UP 1126564 Pump Piston Variable 1 6510 1YR1-UP 1126564 Pump Piston Variable 1 6510 1ZR1-UP 1126564 Pump Piston Variable 1 6510 6XN1-UP 1126564 Pump Piston Variable 1 6510 7WN1-UP 1126564 Pump Piston Variable 1 6510

428 Auxiliary 6TC1-6563 1177760 Pump Piston Variable 1

6TC6564-11143 1177760 Pump Piston Variable 1

6TC1-1122 4T6895 Pump Piston Variable 1 5021

Steering 6TC1-6563 4T6896 Pump Gear Fixed 1 4500

6TC6564-UP 4T6896 Pump Gear Fixed 1 4500

Implement 6TC1-6563 9T4699 Pump Piston Variable 1 5027 6TC6564-11143 9T4699 Pump Piston Variable 1 5027 Implement & Steering 6TC1-1122 9T6857 Pump Piston Variable 1 5021 6TC1123-6563 9T6857 Pump Piston Variable 1 5021 6TC6564-UP 9T6857 Pump Piston Variable 1 5021 428B Multiple Applications 7EJ1-UP 1003259 Pump Piston Variable 1 6510

Steering 7EJ1-UP 1186796 Pump Gear Fixed 1

7EJ1-UP 4T6896 Pump Gear Fixed 1 4500

428C Auxiliary 1HR1-UP 1052156 Pump Piston Variable 1

1SR1-UP 1052156 Pump Piston Variable 1 2CR1-UP 1052156 Pump Piston Variable 1 8RN1-UP 1052156 Pump Piston Variable 1

1HR1-UP 1126564 Pump Piston Variable 1 6510 1SR1-UP 1126564 Pump Piston Variable 1 6510 2CR1-UP 1126564 Pump Piston Variable 1 6510 8RN1-UP 1126564 Pump Piston Variable 1 6510

436 Steering 5KF1-805 4T6896 Pump Gear Fixed 1 4500

5KF806-UP 4T6896 Pump Gear Fixed 1 4500

436B Application Unknown 6MJ808-UP 1003259 Pump Piston Variable 1 6510 Multiple Applications 6MJ1-UP 1003259 Pump Piston Variable 1 6510 7FL1-UP 1003259 Pump Piston Variable 1 6510

Steering 6MJ1-UP 1058657 Pump Gear Fixed 1

7FL1-UP 1058657 Pump Gear Fixed 1

6MJ808-UP 1186796 Pump Gear Fixed 1

6MJ1-807 4T6896 Pump Gear Fixed 1 4500

Auxiliary 6MJ1-UP 6E5280 Pump Piston Variable 1 6510 7FL1-UP 6E5280 Pump Piston Variable 1 6510

436C Auxiliary 1FR1-UP 1126564 Pump Piston Variable 1 6510

1GR1-UP 1126564 Pump Piston Variable 1 6510 1PR1-UP 1126564 Pump Piston Variable 1 6510

(11)

436C (cont.) Auxiliary 1RR1-UP 1126564 Pump Piston Variable 1 6510 2AR1-UP 1126564 Pump Piston Variable 1 6510 2BR1-UP 1126564 Pump Piston Variable 1 6510 8TN1-UP 1126564 Pump Piston Variable 1 6510 9JN1-UP 1126564 Pump Piston Variable 1 6510

438 Steering 3DJ1-827 4T6896 Pump Gear Fixed 1 4500

3DJ828-UP 4T6896 Pump Gear Fixed 1 4500

Implement & Steering 3DJ1-827 9T4833 Pump Piston Variable 1 5027 3DJ828-UP 9T4833 Pump Piston Variable 1 5027 438B Application Unknown 3KK1-UP 1003259 Pump Piston Variable 1 6510

Steering 3KK1-UP 1058657 Pump Gear Fixed 1

3KK3084-UP 1186796 Pump Gear Fixed 1

3KK1-2999 4T6896 Pump Gear Fixed 1 4500

438C Auxiliary 1JR1-UP 1126564 Pump Piston Variable 1 6510

1TR1-UP 1126564 Pump Piston Variable 1 6510 2DR1-UP 1126564 Pump Piston Variable 1 6510 9KN1-UP 1126564 Pump Piston Variable 1 6510

446 Application Unknown 6XF1-796 8E8658 Pump Gear Fixed 1

6XF951-975 8E8658 Pump Gear Fixed 1

Steering 6XF1-UP 9T1210 Pump Gerotor Fixed 1 4700

Multiple Applications 6XF1-UP 9T1211 Pump Piston Variable 2 5035 Implement & Steering 6XF1-UP 9T2108 Pump Piston Variable 1 5035

446B Application Unknown 5BL1-UP 8E8658 Pump Gear Fixed 1

Steering 5BL1-UP 9T1210 Pump Gerotor Fixed 1 4700

Multiple Applications 5BL1-UP 9T1211 Pump Piston Variable 2 5035

EXCAVATORS

215 Auxiliary 14Z1-UP 1U1987 Pump Gear Fixed 1

61Z1-UP 1U1987 Pump Gear Fixed 1

96L1-UP 1U1987 Pump Gear Fixed 1

96L1-UP 3G0302 Pump Gear Fixed 1 1020

Implement 14Z1-UP 4T7025 Pump Piston Variable N/A 7010 57Y1-UP 4T7025 Pump Piston Variable N/A 7010 61Z1-UP 4T7025 Pump Piston Variable N/A 7010 95Z1-UP 4T7025 Pump Piston Variable N/A 7010 96L1-UP 4T7025 Pump Piston Variable N/A 7010

Pilot 14Z1-UP 5C6600 Pump Gear Fixed 1 1002

61Z1-UP 5C6600 Pump Gear Fixed 1 1002

96L1-UP 5C6600 Pump Gear Fixed 1 1002

57Y1-UP 5C6601 Pump Gear Fixed 1 1002

96L1748-UP 5C6601 Pump Gear Fixed 1 1002

Implement 14Z1-UP 8J6848 Motor Piston Fixed N/A 7010

57Y1-UP 8J6848 Motor Piston Fixed N/A 7010 61Z1-UP 8J6848 Motor Piston Fixed N/A 7010

(12)

215 (cont.) Implement 95Z1-UP 8J6848 Motor Piston Fixed N/A 7010 96L1-377 8J6848 Motor Piston Fixed N/A 7010 96L378-UP 8J6848 Motor Piston Fixed N/A 7010

Track 14Z1-UP 8J6848 Motor Piston Fixed N/A 7010

57Y1-UP 8J6848 Motor Piston Fixed N/A 7010 61Z1-UP 8J6848 Motor Piston Fixed N/A 7010 95Z1-UP 8J6848 Motor Piston Fixed N/A 7010 96L1-377 8J6848 Motor Piston Fixed N/A 7010 96L378-UP 8J6848 Motor Piston Fixed N/A 7010 Application Unknown 14Z1-881 9J5448 Motor Gerotor Fixed N/A 4500

14Z1-UP 9J7900 Pump Gear Fixed 1 1002

96L1-UP 9J7900 Pump Gear Fixed 1 1002

Implement 14Z1-UP 9J7901 Pump Gear Fixed 1 1002

Pilot 14Z1-UP 9J8226 Pump Gear Fixed 1 1002

215B Track 4FC1-425 1U2767 Motor Piston Fixed N/A 7020

4JC1-UP 1U2767 Motor Piston Fixed N/A 7020 Implement 2XC1-UP 4T7025 Pump Piston Variable N/A 7010 4FC1-425 4T7025 Pump Piston Variable N/A 7010 4JC1-UP 4T7025 Pump Piston Variable N/A 7010

Pilot 2XC1-UP 5C6600 Pump Gear Fixed 1 1002

4FC1-425 5C6600 Pump Gear Fixed 1 1002

4JC1-UP 5C6600 Pump Gear Fixed 1 1002

2XC1-UP 5C6601 Pump Gear Fixed 1 1002

4FC1-425 5C6601 Pump Gear Fixed 1 1002

4JC1-UP 5C6601 Pump Gear Fixed 1 1002

Implement 2XC1-UP 8J6848 Motor Piston Fixed N/A 7010

4FC1-425 8J6848 Motor Piston Fixed N/A 7010 4JC1-UP 8J6848 Motor Piston Fixed N/A 7010

Track 2XC1-UP 8J6848 Motor Piston Fixed N/A 7010

4FC1-425 8J6848 Motor Piston Fixed N/A 7010 4JC1-UP 8J6848 Motor Piston Fixed N/A 7010 Application Unknown 2XC1-599 9J5448 Motor Gerotor Fixed N/A 4500

2XC1-UP 9J7900 Pump Gear Fixed 1 1002

4FC1-UP 9J7900 Pump Gear Fixed 1 1002

4JC1-UP 9J7900 Pump Gear Fixed 1 1002

(13)

215B (cont.) Implement 4FC1-UP 9J7901 Pump Gear Fixed 1 1002

Pilot 2XC1-UP 9J8226 Pump Gear Fixed 1 1002

4FC1-425 9J8226 Pump Gear Fixed 1 1002

Multiple Applications 4FC1-UP 9T0992 Pump Piston Variable 1 6508

Track 4FC1-UP 9T1062 Motor Piston Variable N/A 6502

Auxiliary 4FC1-426 9T1487 Pump Gear Fixed 1 1016

Implement 4FC1-900 9T1488 Pump Gear Fixed N/A 1020

Pilot 4FC1-UP 9T4713 Pump Gear Fixed 1 1002

Implement 4FC1-834 9T4731 Pump Piston Variable N/A 6508 Multiple Applications 4FC1-UP 9T7156 Pump Piston Variable 2 6508

215C Implement 9YB1-1371 4T7025 Pump Piston Variable N/A 7010

Pilot 9YB1-UP 5C6600 Pump Gear Fixed 1 1002

9YB1-1371 5C6601 Pump Gear Fixed 1 1002

Application Unknown 4HG1-UP 9J7900 Pump Gear Fixed 1 1002

9YB1-UP 9J7900 Pump Gear Fixed 1 1002

Implement 4HG1-UP 9J7901 Pump Gear Fixed 1 1002

4HG1-UP 9J7902 Pump Gear Fixed 1 1020

4HG1-UP 9J7903 Pump Gear Fixed 1 1020

Pilot 9YB1-1371 9J8226 Pump Gear Fixed 1 1002

Implement 4HG1-UP 9T0670 Motor Piston Fixed N/A 6502

9YB1-UP 9T0670 Motor Piston Fixed N/A 6502

Track 4HG1-UP 9T0670 Motor Piston Fixed N/A 6502

9YB1-UP 9T0670 Motor Piston Fixed N/A 6502

Implement 4HG1-UP 9T0891 Motor Piston Fixed N/A 6502

9YB1-UP 9T0891 Motor Piston Fixed N/A 6502 Multiple Applications 9YB1-1704 9T0992 Pump Piston Variable 1 6508

Auxiliary 4HG1-UP 9T1487 Pump Gear Fixed 1 1016

9YB1372-3158 9T1487 Pump Gear Fixed 1 1016 Multiple Applications 9YB1-3158 9T1487 Pump Gear Fixed 1 1016

Implement 4HG1-2919 9T1488 Pump Gear Fixed N/A 1020

9YB1-3420 9T1488 Pump Gear Fixed N/A 1020

4HG1-UP 9T1489 Pump Gear Fixed 1 1016

9YB1-3158 9T4731 Pump Piston Variable N/A 6508 Multiple Applications 4HG1-UP 9T6713 Pump Piston Variable 2 6508 9YB1-UP 9T7156 Pump Piston Variable 2 6508

(14)

215D (cont.) Track 9TF1-UP 9T0670 Motor Piston Fixed N/A 6502

Implement 9TF1-UP 9T0891 Motor Piston Fixed N/A 6502

9TF1-2394 9T1488 Pump Gear Fixed N/A 1020 Multiple Applications 9TF1-UP 9T9353 Pump Piston Variable 2 6508

219 Application Unknown 5CF1-UP 9J7900 Pump Gear Fixed 1 1002

Implement 5CF1-UP 9J7901 Pump Gear Fixed 1 1002

5CF1-UP 9J7902 Pump Gear Fixed 1 1020

5CF1-UP 9J7903 Pump Gear Fixed 1 1020

5CF1-UP 9T0891 Motor Piston Fixed N/A 6502

Track 5CF1-UP 9T1062 Motor Piston Variable N/A 6502

Implement 5CF1-1161 9T1488 Pump Gear Fixed N/A 1020

5CF1-UP 9T1489 Pump Gear Fixed 1 1016

Multiple Applications 5CF1-1161 9T6714 Pump Piston Variable 2 6508

219D Implement 5XG1-UP 9T0891 Motor Piston Fixed N/A 6502

Track 5XG1-UP 9T1062 Motor Piston Variable N/A 6502

Implement 5XG1-1107 9T1488 Pump Gear Fixed N/A 1020

Multiple Applications 5XG1-UP 9T9352 Pump Piston Variable 2 6508

225 Auxiliary 51U2832-UP 1U1986 Pump Gear Fixed 1 1016

61X381-UP 1U1986 Pump Gear Fixed 1 1016

76U1317-UP 1U1986 Pump Gear Fixed 1 1016

51U2832-UP 1U1987 Pump Gear Fixed 1

76U1-UP 1U1987 Pump Gear Fixed 1

51U2832-UP 3G0302 Pump Gear Fixed 1 1020

Multiple Applications 51U1-UP 3G0302 Pump Gear Fixed 1 1020

Swing 51U1-6170 3G0784 Motor Piston Fixed N/A 7020

61X1-413 3G0784 Motor Piston Fixed N/A 7020 76U1-UP 3G0784 Motor Piston Fixed N/A 7020

Track 51U1-6170 3G0784 Motor Piston Fixed N/A 7020

61X1-413 3G0784 Motor Piston Fixed N/A 7020 76U1-UP 3G0784 Motor Piston Fixed N/A 7020

Auxiliary 76U721-1199 3G2243 Pump Gear Fixed 2 1020

Multiple Applications 76U1-1199 3G2243 Pump Gear Fixed 2 1020

Pilot 51U1-UP 3G2875 Pump Gear Fixed 2 1020

61X1-UP 3G2875 Pump Gear Fixed 2 1020

Swing 51U1-UP 3G2875 Pump Gear Fixed 2 1020

Auxiliary 51U2832-4879 3G4466 Pump Gear Fixed 1 1002

61X381-406 3G4466 Pump Gear Fixed 1 1002

61X407-413 3G4466 Pump Gear Fixed 1 1002

76U1317-2483 3G4466 Pump Gear Fixed 1 1002 76U2484-5839 3G4466 Pump Gear Fixed 1 1002 Multiple Applications 51U1-4879 3G4466 Pump Gear Fixed 1 1002

(15)

225 (cont.) Multiple Applications 61X1-406 3G4466 Pump Gear Fixed 1 1002

76U1-2483 3G4466 Pump Gear Fixed 1 1002

Pilot 51U1-UP 3G7385 Pump Gear Fixed 1 1002

76U1-5839 3G7385 Pump Gear Fixed 1 1002

Implement 51U1-6257 4T7426 Pump Piston Variable N/A 7020 61X1-413 4T7426 Pump Piston Variable N/A 7020 76U1-UP 4T7426 Pump Piston Variable N/A 7020

Pilot 76U1-UP 5C6600 Pump Gear Fixed 1 1002

76U5840-UP 5C6601 Pump Gear Fixed 1 1002

Implement 51U1-2831 8J2059 Pump Gear Fixed 2 1020

61X1-380 8J2059 Pump Gear Fixed 2 1020

76U1-UP 8J2059 Pump Gear Fixed 2 1020

Pilot 51U1-2831 8J2059 Pump Gear Fixed 2 1020

61X1-380 8J2059 Pump Gear Fixed 2 1020

Application Unknown 51U1-6721 9J5448 Motor Gerotor Fixed N/A 4500 61X1-413 9J5448 Motor Gerotor Fixed N/A 4500

61X1-UP 9J7900 Pump Gear Fixed 1 1002

Implement 61X1-UP 9J7901 Pump Gear Fixed 1 1002

Pilot 76U1-UP 9J8226 Pump Gear Fixed 1 1002

Application Unknown 51U1-2831 9J9362 Pump Piston Variable N/A 7020 61X1-380 9J9362 Pump Piston Variable N/A 7020 76U1-575 9J9362 Pump Piston Variable N/A 7020 76U683-1199 9J9362 Pump Piston Variable N/A 7020

Implement 51U1-UP 9T0999 Motor Piston Fixed N/A 6502

61X1-UP 9T0999 Motor Piston Fixed N/A 6502 76U1-UP 9T0999 Motor Piston Fixed N/A 6502

Track 51U1-UP 9T0999 Motor Piston Fixed N/A 6502

61X1-UP 9T0999 Motor Piston Fixed N/A 6502 76U1-UP 9T0999 Motor Piston Fixed N/A 6502 Multiple Applications 51U1-6527 9T1054 Pump Piston Variable 2 6508 61X1-414 9T1054 Pump Piston Variable 2 6508

Pilot 51U1-UP 9T4704 Pump Gear Fixed 1 1016

Multiple Applications 51U1-6720 9T4732 Pump Piston Variable 2 6508 61X1-UP 9T4732 Pump Piston Variable 2 6508 76U1-UP 9T4732 Pump Piston Variable 2 6508 51U1-UP 9T5187 Pump Piston Variable 2 6508 51U1-6721 9T7460 Pump Piston Variable 2 6927 61X1-413 9T7460 Pump Piston Variable 2 6927

225B Auxiliary 2ZD550-628 1U1986 Pump Gear Fixed 1 1016

(16)

225B (cont.) Auxiliary 3YD1-UP 1U1987 Pump Gear Fixed 1

Pilot 2ZD1-UP 3G2875 Pump Gear Fixed 2 1020

Swing 2ZD1-UP 3G2875 Pump Gear Fixed 2 1020

Auxiliary 2ZD550-628 3G4466 Pump Gear Fixed 1 1002

Multiple Applications 2ZD1-628 3G4466 Pump Gear Fixed 1 1002

Pilot 2ZD1-UP 3G7385 Pump Gear Fixed 1 1002

2ZD1-UP 3G7386 Pump Gear Fixed 1 1002

3YD1-399 5C6600 Pump Gear Fixed 1 1002

3YD1-UP 5C6601 Pump Gear Fixed 1 1002

Application Unknown 2ZD1-1916 9J5448 Motor Gerotor Fixed N/A 4500

2ZD1-UP 9J7900 Pump Gear Fixed 1 1002

Implement 2ZD1-UP 9J7901 Pump Gear Fixed 1 1002

Pilot 3YD1-399 9J8226 Pump Gear Fixed 1 1002

Implement 2ZD1-UP 9T0999 Motor Piston Fixed N/A 6502

3YD1-UP 9T0999 Motor Piston Fixed N/A 6502

Track 2ZD1-UP 9T0999 Motor Piston Fixed N/A 6502

3YD1-UP 9T0999 Motor Piston Fixed N/A 6502

Implement 2ZD1-UP 9T1489 Pump Gear Fixed 1 1016

Pilot 2ZD1-549 9T4704 Pump Gear Fixed 1 1016

2ZD629-UP 9T4704 Pump Gear Fixed 1 1016

Multiple Applications 3YD1-UP 9T4732 Pump Piston Variable 2 6508 2ZD1-UP 9T5187 Pump Piston Variable 2 6508 2ZD1-1916 9T7460 Pump Piston Variable 2 6927 3YD1-2128 9T9350 Pump Piston Variable 2 6508

225D Auxiliary 2SJ1-UP 1U1987 Pump Gear Fixed 1

Pilot 2SJ1-UP 3G7385 Pump Gear Fixed 1 1002

Implement 2SJ1-UP 9T0999 Motor Piston Fixed N/A 6502

6RG1-UP 9T0999 Motor Piston Fixed N/A 6502

Track 2SJ1-UP 9T0999 Motor Piston Fixed N/A 6502

6RG1-UP 9T0999 Motor Piston Fixed N/A 6502

Pilot 2SJ1-UP 9T4704 Pump Gear Fixed 1 1016

Multiple Applications 6RG1-UP 9T4732 Pump Piston Variable 2 6508 2SJ1-53 9T5187 Pump Piston Variable 2 6508 2SJ1-1041 9T7460 Pump Piston Variable 2 6927 6RG1-1353 9T9350 Pump Piston Variable 2 6508 2SJ1-UP 9T9351 Pump Piston Variable 2 6508 Implement 2SJ1-UP 9T9604 Motor Piston Variable N/A 6502 6RG1-UP 9T9604 Motor Piston Variable N/A 6502

227 Swing 10W1-278 3G0784 Motor Piston Fixed N/A 7020

Track 10W1-278 3G0784 Motor Piston Fixed N/A 7020

Implement 10W1-UP 3G7611 Pump Gear Fixed 2 1020

Swing 10W1-306 4T3068 Motor Piston Variable N/A 7020 Track 10W1-306 4T3068 Motor Piston Variable N/A 7020 Implement 10W1-UP 4T7426 Pump Piston Variable N/A 7020

(17)

227 (cont.) Implement 10W1-UP 9T0999 Motor Piston Fixed N/A 6502

Track 10W1-UP 9T0999 Motor Piston Fixed N/A 6502

10W1-UP 9T1208 Motor Piston Fixed N/A 6502

229 Auxiliary 1GF1-380 1U1986 Pump Gear Fixed 1 1016

1AG1-UP 1U1987 Pump Gear Fixed 1

1GF1-UP 1U1987 Pump Gear Fixed 1

Pilot 1GF1-UP 3G2875 Pump Gear Fixed 2 1020

Swing 1GF1-UP 3G2875 Pump Gear Fixed 2 1020

Auxiliary 1GF1-380 3G4466 Pump Gear Fixed 1 1002

Pilot 1GF1-UP 3G7385 Pump Gear Fixed 1 1002

1GF1-UP 3G7386 Pump Gear Fixed 1 1002

Swing 1AG1-132 4T3068 Motor Piston Variable N/A 7020 Track 1AG1-132 4T3068 Motor Piston Variable N/A 7020

Pilot 1AG1-295 5C6600 Pump Gear Fixed 1 1002

1AG1-295 5C6601 Pump Gear Fixed 1 1002

Application Unknown 1GF1-613 9J5448 Motor Gerotor Fixed N/A 4500

1GF1-UP 9J7900 Pump Gear Fixed 1 1002

Implement 1GF1-UP 9J7901 Pump Gear Fixed 1 1002

Pilot 1AG1-295 9J8226 Pump Gear Fixed 1 1002

Implement 1AG1-UP 9T0999 Motor Piston Fixed N/A 6502

1GF1-UP 9T0999 Motor Piston Fixed N/A 6502

Track 1AG1-UP 9T0999 Motor Piston Fixed N/A 6502

1GF1-UP 9T0999 Motor Piston Fixed N/A 6502 Multiple Applications 1AG1-204 9T1054 Pump Piston Variable 2 6508

Track 1AG1-UP 9T1208 Motor Piston Fixed N/A 6502

1GF1-UP 9T1208 Motor Piston Fixed N/A 6502

Implement 1GF1-UP 9T1489 Pump Gear Fixed 1 1016

Pilot 1GF1-UP 9T4704 Pump Gear Fixed 1 1016

Multiple Applications 1GF1-UP 9T4732 Pump Piston Variable 2 6508 1GF1-UP 9T5187 Pump Piston Variable 2 6508 1GF1-613 9T7460 Pump Piston Variable 2 6927 1AG1-726 9T9350 Pump Piston Variable 2 6508

229D Track 2LJ1-UP 9T1208 Motor Piston Fixed N/A 6502

Multiple Applications 2LJ1-UP 9T9348 Pump Piston Variable 2 6508 231D Application Unknown 1NK1-320 1044401 Pump Piston Variable N/A

5WJ1-330 1044401 Pump Piston Variable N/A

Auxiliary 1NK1-UP 1U1987 Pump Gear Fixed 1

Pilot 1NK1-UP 3G7385 Pump Gear Fixed 1 1002

Auxiliary 1NK36-UP 6E2307 Motor Piston Variable N/A Power Train 1NK36-UP 6E3394 Motor Piston Variable N/A 7030

Track 5WJ1-UP 9T1208 Motor Piston Fixed N/A 6502

Pilot 1NK1-UP 9T4704 Pump Gear Fixed 1 1016

Power Train 1NK1-35 9T8408 Motor Piston Variable N/A Implement 1NK1-UP 9T9347 Motor Piston Variable N/A 6502

(18)

231D (cont.) Implement 5WJ1-UP 9T9347 Motor Piston Variable N/A 6502 Multiple Applications 1NK1-UP 9T9349 Pump Piston Variable 2 6508

235 Pilot 32K1-UP 3G1686 Pump Gear Fixed 2 1020

64R1-UP 3G1686 Pump Gear Fixed 2 1020

Swing 32K1-UP 3G1686 Pump Gear Fixed 2 1020

64R1-UP 3G1686 Pump Gear Fixed 2 1020

Pilot 32K1-UP 3G5958 Pump Gear Fixed 2 1020

Swing 32K1-UP 3G5958 Pump Gear Fixed 2 1020

Implement 32K1-UP 4T2507 Pump Piston Variable N/A 7030 62X1-UP 4T2507 Pump Piston Variable N/A 7030 64R1-UP 4T2507 Pump Piston Variable N/A 7030 81X1-UP 4T2507 Pump Piston Variable N/A 7030 83X1-UP 4T2507 Pump Piston Variable N/A 7030

Swing 32K1-UP 4T3068 Motor Piston Variable N/A 7020

62X1-UP 4T3068 Motor Piston Variable N/A 7020 64R1-UP 4T3068 Motor Piston Variable N/A 7020 81X1-UP 4T3068 Motor Piston Variable N/A 7020 83X1-UP 4T3068 Motor Piston Variable N/A 7020

Track 32K1-UP 4T3068 Motor Piston Variable N/A 7020

62X1-UP 4T3068 Motor Piston Variable N/A 7020 64R1-UP 4T3068 Motor Piston Variable N/A 7020 81X1-UP 4T3068 Motor Piston Variable N/A 7020 83X1-UP 4T3068 Motor Piston Variable N/A 7020 Application Unknown 62X1-UP 9J7900 Pump Gear Fixed 1 1002

Implement 62X1-UP 9J7901 Pump Gear Fixed 1 1002

235B Pilot 1FD1-UP 3G1686 Pump Gear Fixed 2 1020

4ED1-UP 3G1686 Pump Gear Fixed 2 1020

7WC1-UP 3G1686 Pump Gear Fixed 2 1020

9PC1-UP 3G1686 Pump Gear Fixed 2 1020

Swing 1FD1-UP 3G1686 Pump Gear Fixed 2 1020

Pilot 1FD1-UP 3G5958 Pump Gear Fixed 2 1020

(19)

235B (cont.) Pilot 7WC1-UP 3G5958 Pump Gear Fixed 2 1020

Swing 1FD1-UP 3G5958 Pump Gear Fixed 2 1020

Implement 1FD1-UP 4T0380 Pump Gear Fixed 1 1020

7WC1-UP 4T0380 Pump Gear Fixed 1 1020

1FD1-UP 4T2507 Pump Piston Variable N/A 7030 4ED1-UP 4T2507 Pump Piston Variable N/A 7030 7WC1-UP 4T2507 Pump Piston Variable N/A 7030 9PC1-UP 4T2507 Pump Piston Variable N/A 7030

Swing 1FD1-UP 4T3068 Motor Piston Variable N/A 7020

4ED1-UP 4T3068 Motor Piston Variable N/A 7020 7WC1-UP 4T3068 Motor Piston Variable N/A 7020 9PC1-UP 4T3068 Motor Piston Variable N/A 7020

Track 1FD1-UP 4T3068 Motor Piston Variable N/A 7020

4ED1-UP 4T3068 Motor Piston Variable N/A 7020 7WC1-UP 4T3068 Motor Piston Variable N/A 7020 9PC1-UP 4T3068 Motor Piston Variable N/A 7020 1FD1-UP 9T1208 Motor Piston Fixed N/A 6502 4ED1-UP 9T1208 Motor Piston Fixed N/A 6502 9PC1-UP 9T1208 Motor Piston Fixed N/A 6502

Implement 1FD1-UP 9T5557 Pump Gear Fixed 1 1020

7WC1-UP 9T5557 Pump Gear Fixed 1 1020

235C Pilot 2PG1-UP 3G1686 Pump Gear Fixed 2 1020

3WG1-UP 3G1686 Pump Gear Fixed 2 1020

4DG1-UP 3G1686 Pump Gear Fixed 2 1020

5AF1-UP 3G1686 Pump Gear Fixed 2 1020

Swing 2PG1-UP 3G1686 Pump Gear Fixed 2 1020

Pilot 2PG1-UP 3G5958 Pump Gear Fixed 2 1020

Swing 2PG1-UP 3G5958 Pump Gear Fixed 2 1020

Implement 3WG1-UP 4T0380 Pump Gear Fixed 1 1020

5AF1-UP 4T0380 Pump Gear Fixed 1 1020

2PG1-UP 4T2507 Pump Piston Variable N/A 7030 3WG1-UP 4T2507 Pump Piston Variable N/A 7030 4DG1-UP 4T2507 Pump Piston Variable N/A 7030 5AF1-UP 4T2507 Pump Piston Variable N/A 7030

(20)

235C (cont.) Swing 2PG1-UP 4T3068 Motor Piston Variable N/A 7020 3WG1-UP 4T3068 Motor Piston Variable N/A 7020 4DG1-UP 4T3068 Motor Piston Variable N/A 7020 5AF1-UP 4T3068 Motor Piston Variable N/A 7020

Track 2PG1-UP 4T3068 Motor Piston Variable N/A 7020

3WG1-UP 4T3068 Motor Piston Variable N/A 7020 4DG1-UP 4T3068 Motor Piston Variable N/A 7020 5AF1-UP 4T3068 Motor Piston Variable N/A 7020 Auxiliary 3WG283-UP 6E3683 Pump Piston Variable 1 6100 5AF1740-UP 6E3683 Pump Piston Variable 1 6100 Multiple Applications 3WG1-UP 6E3683 Pump Piston Variable 1 6100 5AF1-UP 6E3683 Pump Piston Variable 1 6100

Track 2PG1-UP 9T1208 Motor Piston Fixed N/A 6502

3WG1-UP 9T1208 Motor Piston Fixed N/A 6502 4DG1-UP 9T1208 Motor Piston Fixed N/A 6502 5AF1-UP 9T1208 Motor Piston Fixed N/A 6502

Implement 2PG1-UP 9T2507 Pump Piston Variable 1 6090

3WG1-282 9T2507 Pump Piston Variable 1 6090 4DG1-UP 9T2507 Pump Piston Variable 1 6090 5AF1-1739 9T2507 Pump Piston Variable 1 6090

Pilot 3WG1-UP 9T2794 Pump Gear Fixed 1 1016

Implement 3WG1-UP 9T5557 Pump Gear Fixed 1 1020

235D Implement 8KJ1-UP 4T0380 Pump Gear Fixed 1 1020

8KJ1-UP 4T2507 Pump Piston Variable N/A 7030 8TJ1-UP 4T2507 Pump Piston Variable N/A 7030

8KJ1-UP 6E3391 Pump Gear Fixed 1 1020

8KJ1-UP 6E3643 Pump Piston Variable N/A 7020 Application Unknown 8KJ1-UP 6E5385 Motor Piston Variable N/A 7020 8KJ1-423 6E5387 Motor Piston Variable N/A 7020

Track 8TJ1-UP 9T1208 Motor Piston Fixed N/A 6502

Implement 8KJ1-UP 9T3473 Motor Piston Fixed N/A 6502

8TJ1-UP 9T3473 Motor Piston Fixed N/A 6502

Steering 8KJ1-UP 9T3473 Motor Piston Fixed N/A 6502

8TJ1-UP 9T3473 Motor Piston Fixed N/A 6502

Implement 8KJ1-UP 9T5557 Pump Gear Fixed 1 1020

Application Unknown 8KJ1-UP 9T9932 Pump Gear Fixed 1 1016

8TJ1-UP 9T9932 Pump Gear Fixed 1 1016

Multiple Applications 8KJ1-423 9T9932 Pump Gear Fixed 1 1016

8TJ1-383 9T9932 Pump Gear Fixed 1 1016

245 Implement 82X1-841 3G1145 Pump Gear Fixed 1 1020

Pilot 82X1-UP 3G5995 Pump Gear Fixed 1 1020

94L1-UP 3G5995 Pump Gear Fixed 1 1020

Implement 82X1-841 3G8117 Pump Gear Fixed 2 1020

(21)

245 (cont.) Implement 84X1-UP 4T2506 Pump Piston Variable N/A 7030 94L1-UP 4T2506 Pump Piston Variable N/A 7030

Swing 82X1-UP 4T3068 Motor Piston Variable N/A 7020

84X1-UP 4T3068 Motor Piston Variable N/A 7020 94L1-UP 4T3068 Motor Piston Variable N/A 7020

Track 82X1-UP 4T3068 Motor Piston Variable N/A 7020

84X1-UP 4T3068 Motor Piston Variable N/A 7020 94L1-UP 4T3068 Motor Piston Variable N/A 7020 Auxiliary 82X491-647 4T3069 Motor Piston Variable N/A

84X1-UP 4T3069 Motor Piston Variable N/A 94L1-UP 4T3069 Motor Piston Variable N/A

Powertrain 82X1-841 6E2415 Pump Gear Fixed 1 1016

84X1-1134 6E2415 Pump Gear Fixed 1 1016

Application Unknown 82X1-841 6E3574 Pump Gear Fixed N/A 1016 82X1-542 8J4379 Pump Piston Variable N/A 84X1-553 8J4379 Pump Piston Variable N/A 94L1-177 8J4379 Pump Piston Variable N/A 94L178-441 8J4379 Pump Piston Variable N/A

Track 82X1-UP 9T1208 Motor Piston Fixed N/A 6502

84X1-UP 9T1208 Motor Piston Fixed N/A 6502 Application Unknown 82X543-UP 9T9796 Pump Piston Variable N/A 7020 84X554-UP 9T9796 Pump Piston Variable N/A 7020 94L442-UP 9T9796 Pump Piston Variable N/A 7020

245B Auxiliary 95V1-1246 1U4759 Pump Gear Fixed 1 2020

Implement 95V1-1246 3G1145 Pump Gear Fixed 1 1020

Pilot 1SJ1-712 3G5995 Pump Gear Fixed 1 1020

1SJ713-UP 3G5995 Pump Gear Fixed 1 1020

6MF1-512 3G5995 Pump Gear Fixed 1 1020

6MF513-UP 3G5995 Pump Gear Fixed 1 1020

95V1-UP 3G5995 Pump Gear Fixed 1 1020

Implement 95V1-1246 3G8117 Pump Gear Fixed 2 1020

1SJ1-712 4T2506 Pump Piston Variable N/A 7030 1SJ713-UP 4T2506 Pump Piston Variable N/A 7030 6MF1-512 4T2506 Pump Piston Variable N/A 7030 6MF513-UP 4T2506 Pump Piston Variable N/A 7030 95V1-554 4T2506 Pump Piston Variable N/A 7030 95V555-UP 4T2506 Pump Piston Variable N/A 7030 Swing 1SJ1-712 4T3068 Motor Piston Variable N/A 7020 1SJ713-UP 4T3068 Motor Piston Variable N/A 7020 6MF1-512 4T3068 Motor Piston Variable N/A 7020 6MF513-UP 4T3068 Motor Piston Variable N/A 7020 95V1-UP 4T3068 Motor Piston Variable N/A 7020 Track 1SJ1-712 4T3068 Motor Piston Variable N/A 7020 1SJ713-UP 4T3068 Motor Piston Variable N/A 7020 6MF1-512 4T3068 Motor Piston Variable N/A 7020 6MF513-UP 4T3068 Motor Piston Variable N/A 7020 95V1-UP 4T3068 Motor Piston Variable N/A 7020

(22)

245B (cont.) Auxiliary 95V795-1229 4T3069 Motor Piston Variable N/A Application Unknown 95V1-1246 6E1226 Pump Gear Fixed 1

Powertrain 1SJ1-712 6E2415 Pump Gear Fixed 1 1016

1SJ713-943 6E2415 Pump Gear Fixed 1 1016

6MF1-512 6E2415 Pump Gear Fixed 1 1016

95V1-1246 6E2415 Pump Gear Fixed 1 1016

Steering 6MF1-512 6E3118 Pump Gear Fixed 1 1016

Application Unknown 95V1-1246 6E3574 Pump Gear Fixed N/A 1016 6MF1-512 6E3752 Pump Piston Variable N/A 7020 6MF513-841 6E3752 Pump Piston Variable N/A 7020

95V1-224 8J4379 Pump Piston Variable N/A 95V225-668 8J4379 Pump Piston Variable N/A 95V669-959 8J4379 Pump Piston Variable N/A

Track 1SJ1-712 9T1208 Motor Piston Fixed N/A 6502

1SJ713-UP 9T1208 Motor Piston Fixed N/A 6502 6MF1-512 9T1208 Motor Piston Fixed N/A 6502 6MF513-UP 9T1208 Motor Piston Fixed N/A 6502 95V1-UP 9T1208 Motor Piston Fixed N/A 6502 Implement 1SJ1-712 9T2306 Pump Piston Variable 1 6090 1SJ713-UP 9T2306 Pump Piston Variable 1 6090 Steering 1SJ1-712 9T2306 Pump Piston Variable 1 6090 1SJ713-UP 9T2306 Pump Piston Variable 1 6090

Pilot 1SJ1-712 9T2794 Pump Gear Fixed 1 1016

1SJ713-UP 9T2794 Pump Gear Fixed 1 1016

Implement 1SJ1-712 9T3473 Motor Piston Fixed N/A 6502 1SJ713-UP 9T3473 Motor Piston Fixed N/A 6502 Steering 1SJ1-712 9T3473 Motor Piston Fixed N/A 6502 1SJ713-UP 9T3473 Motor Piston Fixed N/A 6502 Application Unknown 95V960-UP 9T9796 Pump Piston Variable N/A 7020

245D Power Train 4LK1-UP 6E2415 Pump Gear Fixed 1 1016

7ZJ1-UP 6E2415 Pump Gear Fixed 1 1016

Powertrain 4LK1-75 6E2415 Pump Gear Fixed 1 1016

7ZJ1-175 6E2415 Pump Gear Fixed 1 1016

Steering 4LK1-UP 6E3118 Pump Gear Fixed 1 1016

7ZJ1-UP 6E3118 Pump Gear Fixed 1 1016

Application Unknown 4LK1-UP 6E4324 Pump Piston Variable N/A 7020 7ZJ1-UP 6E4324 Pump Piston Variable N/A 7020 4LK1-UP 6E5963 Pump Piston Variable N/A 7030 7ZJ1-UP 6E5963 Pump Piston Variable N/A 7030

Track 4LK1-UP 9T1208 Motor Piston Fixed N/A 6502

7ZJ1-UP 9T1208 Motor Piston Fixed N/A 6502

Implement 7ZJ1-UP 9T3473 Motor Piston Fixed N/A 6502

Steering 7ZJ1-UP 9T3473 Motor Piston Fixed N/A 6502

307 Steering - Supplemental 2WM1-UP 6C5572 Pump Vane Fixed N/A 311 Multiple Applications 5PK1-UP 4I7638 Pump Piston Variable 2 9000

(23)

311 (cont.) Multiple Applications 9LJ1-UP 4I7638 Pump Piston Variable 2 9000 Steering - Supplemental 9LJ1-UP 6C5572 Pump Vane Fixed N/A

Multiple Applications 5PK1-UP 7I8264 Pump Piston Variable 2 9000 9LJ1-UP 7I8264 Pump Piston Variable 2 9000 Application Unknown 5PK1-UP 7I8267 Pump Piston Variable 1

9LJ1-UP 7I8267 Pump Piston Variable 1

312 Multiple Applications 6BL1-UP 4I7634 Pump Piston Variable 2 9000 6GK1-UP 4I7634 Pump Piston Variable 2 9000 7DK1-UP 4I7634 Pump Piston Variable 2 9000 Power Train 6BL1-UP 4I7646 Motor Piston Variable 1

Steering - Supplemental 6BL1-UP 6C5572 Pump Vane Fixed N/A

6GK1-UP 6C5572 Pump Vane Fixed N/A

Application Unknown 6BL1-UP 7I0149 Pump Piston Variable N/A 9000 Multiple Applications 6BL1-UP 7I8265 Pump Piston Variable 2 9000 6GK1-UP 7I8265 Pump Piston Variable 2 9000 7DK1-UP 7I8265 Pump Piston Variable 2 9000 Application Unknown 6BL1-UP 7I8267 Pump Piston Variable 1

6GK1-UP 7I8267 Pump Piston Variable 1 7DK1-UP 7I8267 Pump Piston Variable 1 315 Steering - Supplemental 3ZM1-UP 6C5572 Pump Vane Fixed N/A

4YM1-UP 6C5572 Pump Vane Fixed N/A

6XM1-UP 6C5572 Pump Vane Fixed N/A

7NM1-UP 6C5572 Pump Vane Fixed N/A

Application Unknown 3ZM1-UP 7I8267 Pump Piston Variable 1 4YM1-UP 7I8267 Pump Piston Variable 1 6XM1-UP 7I8267 Pump Piston Variable 1 7NM1-UP 7I8267 Pump Piston Variable 1 315L Steering - Supplemental 6YM1-UP 6C5572 Pump Vane Fixed N/A

8LM1-UP 6C5572 Pump Vane Fixed N/A

Application Unknown 6YM1-UP 7I8267 Pump Piston Variable 1 8LM1-UP 7I8267 Pump Piston Variable 1 317 Steering - Supplemental 4MM1-UP 6C5572 Pump Vane Fixed N/A

Application Unknown 4MM1-UP 7I8267 Pump Piston Variable 1 317N Steering - Supplemental 9SR1-2 6C5572 Pump Vane Fixed N/A

9SR244-UP 6C5572 Pump Vane Fixed N/A

Application Unknown 9SR1-2 7I8267 Pump Piston Variable 1 9SR244-UP 7I8267 Pump Piston Variable 1

320 Application Unknown 8LK1-UP 0874715 Motor Piston Variable N/A 9000 Multiple Applications 2DL1-UP 0874715 Motor Piston Variable N/A 9000 3XM1-UP 0874715 Motor Piston Variable N/A 9000 4ZJ1-UP 0874715 Motor Piston Variable N/A 9000 7GJ1-UP 0874715 Motor Piston Variable N/A 9000 Application Unknown 8LK1-UP 0874717 Pump Piston Variable N/A

4ZJ1-UP 0874824 Motor Piston Variable N/A 9000 Multiple Applications 2DL1-UP 0874824 Motor Piston Variable N/A 9000 3RK1-362 0874824 Motor Piston Variable N/A 9000 3XM1-UP 0874824 Motor Piston Variable N/A 9000

(24)

320 (cont.) Multiple Applications 7GJ1-UP 0874824 Motor Piston Variable N/A 9000 7WK1-UP 0874824 Motor Piston Variable N/A 9000 8LK1-UP 0874824 Motor Piston Variable N/A 9000 Application Unknown 4ZJ1-UP 0874827 Motor Piston Variable N/A

8LK1-UP 0874827 Motor Piston Variable N/A Multiple Applications 2DL1-UP 0874828 N/A N/A N/A N/A 6508

4ZJ1-UP 0874828 N/A N/A N/A N/A 6508

Auxiliary 2DL1-UP 1056596 Motor Gear Fixed N/A

Steering - Supplemental 2DL1-UP 6C5572 Pump Vane Fixed N/A

3RK1-362 6C5572 Pump Vane Fixed N/A

3XM1-UP 6C5572 Pump Vane Fixed N/A

4ZJ1-UP 6C5572 Pump Vane Fixed N/A

7GJ1-UP 6C5572 Pump Vane Fixed N/A

7WK1-84 6C5572 Pump Vane Fixed N/A

8LK1-1489 6C5572 Pump Vane Fixed N/A

320L Application Unknown 1KL1-UP 0874715 Motor Piston Variable N/A 9000 Multiple Applications 3XK1-UP 0874715 Motor Piston Variable N/A 9000 8HJ1-UP 0874715 Motor Piston Variable N/A 9000 9KK1-UP 0874715 Motor Piston Variable N/A 9000 Application Unknown 1KL1-UP 0874717 Pump Piston Variable N/A

3XK1-UP 0874824 Motor Piston Variable N/A 9000 Multiple Applications 1KL1-UP 0874824 Motor Piston Variable N/A 9000 1TL1-UP 0874824 Motor Piston Variable N/A 9000 4BK1-364 0874824 Motor Piston Variable N/A 9000 8HJ1-UP 0874824 Motor Piston Variable N/A 9000 9KK1-UP 0874824 Motor Piston Variable N/A 9000 Application Unknown 1KL1-UP 0874827 Motor Piston Variable N/A

3XK1-UP 0874827 Motor Piston Variable N/A Multiple Applications 3XK1-UP 0874828 N/A N/A N/A N/A 6508

9KK1-UP 0874828 N/A N/A N/A N/A 6508

Auxiliary 9KK1-UP 1056596 Motor Gear Fixed N/A

Steering - Supplemental 1KL1-483 6C5572 Pump Vane Fixed N/A

1TL1-388 6C5572 Pump Vane Fixed N/A

3XK1-UP 6C5572 Pump Vane Fixed N/A

4BK1-364 6C5572 Pump Vane Fixed N/A

4JM1-UP 6C5572 Pump Vane Fixed N/A

8HJ1-UP 6C5572 Pump Vane Fixed N/A

9KK1-UP 6C5572 Pump Vane Fixed N/A

320N Multiple Applications 1XM1-UP 0874715 Motor Piston Variable N/A 9000 9WG1-UP 0874715 Motor Piston Variable N/A 9000 Application Unknown 9WG1-UP 0874824 Motor Piston Variable N/A 9000 Multiple Applications 1XM1-UP 0874824 Motor Piston Variable N/A 9000 Application Unknown 1XM1-UP 0874827 Motor Piston Variable N/A

9WG1-UP 0874827 Motor Piston Variable N/A Multiple Applications 1XM1-UP 0874828 N/A N/A N/A N/A 6508

9WG1-UP 0874828 N/A N/A N/A N/A 6508

(25)

320N (cont.) Steering - Supplemental 9WG1-UP 6C5572 Pump Vane Fixed N/A 320S Application Unknown 6KM1-UP 0874824 Motor Piston Variable N/A 9000

Multiple Applications 6KM1-UP 0874828 N/A N/A N/A N/A 6508 Steering - Supplemental 6KM1-UP 6C5572 Pump Vane Fixed N/A

Application Unknown 6KM1-UP 7Y4260 Motor Piston Variable N/A 322 Application Unknown 7WL1-UP 1057463 Motor Piston Variable N/A 9000

Steering - Supplemental 7WL1-UP 6C5572 Pump Vane Fixed N/A 322L Application Unknown 8CL1-UP 0874827 Motor Piston Variable N/A

Auxiliary 9RL1-UP 1056596 Motor Gear Fixed N/A

Application Unknown 8CL1-UP 1057463 Motor Piston Variable N/A 9000 9RL1-UP 1057463 Motor Piston Variable N/A 9000 Steering - Supplemental 8CL1-UP 6C5572 Pump Vane Fixed N/A

8ML1-UP 6C5572 Pump Vane Fixed N/A

Application Unknown 9RL1-UP 6E5273 Pump Piston Variable N/A 6507 9RL1-UP 7Y4238 Motor Piston Variable N/A 9000

322LN Steering - Supplemental 4RM1-UP 6C5572 Pump Vane Fixed N/A

322N Steering - Supplemental 9JL1-266 6C5572 Pump Vane Fixed N/A

325 Auxiliary 6RM1-92 1056596 Motor Gear Fixed N/A

7TG1-75 1056596 Motor Gear Fixed N/A 8YK1-81 1056596 Motor Gear Fixed N/A

Swing 7TG1-UP 5I8728 Motor Piston Variable N/A 9000

Steering - Supplemental 5WK1-UP 6C5572 Pump Vane Fixed N/A

7TG1-75 6C5572 Pump Vane Fixed N/A

8JG1-UP 6C5572 Pump Vane Fixed N/A

8NL1-UP 6C5572 Pump Vane Fixed N/A

8YK1-81 6C5572 Pump Vane Fixed N/A

9SG1-255 6C5572 Pump Vane Fixed N/A

9ZK1-166 6C5572 Pump Vane Fixed N/A

Multiple Applications 5WK1-UP 7Y4002 Pump Piston Variable 2 6508 6RM1-UP 7Y4002 Pump Piston Variable 2 6508 7TG1-75 7Y4002 Pump Piston Variable 2 6508 8JG1-UP 7Y4002 Pump Piston Variable 2 6508 8NL1-UP 7Y4002 Pump Piston Variable 2 6508 8YK1-81 7Y4002 Pump Piston Variable 2 6508 9SG1-255 7Y4002 Pump Piston Variable 2 6508 9ZK1-UP 7Y4002 Pump Piston Variable 2 6508 Auxiliary 5WK1-UP 7Y4250 Motor Piston Variable N/A 9000 8JG1-UP 7Y4250 Motor Piston Variable N/A 9000 8NL1-UP 7Y4250 Motor Piston Variable N/A 9000 9SG1-255 7Y4250 Motor Piston Variable N/A 9000 9ZK1-166 7Y4250 Motor Piston Variable N/A 9000 Application Unknown 7TG1-UP 7Y4260 Motor Piston Variable N/A

9SG1-UP 7Y4260 Motor Piston Variable N/A Auxiliary 9SG1-UP 7Y4273 Motor Piston Variable N/A 9000

325L Auxiliary 2JK1-333 1056596 Motor Gear Fixed N/A

7LM1-1420 1056596 Motor Gear Fixed N/A 8NK1-1150 1056596 Motor Gear Fixed N/A

(26)

325L (cont.) Swing 7CJ1-UP 5I8729 Motor Piston Variable N/A 9000 Steering - Supplemental 2JK1-333 6C5572 Pump Vane Fixed N/A

2SL1-UP 6C5572 Pump Vane Fixed N/A

6KK1-UP 6C5572 Pump Vane Fixed N/A

7CJ1-UP 6C5572 Pump Vane Fixed N/A

7LJ1-327 6C5572 Pump Vane Fixed N/A

8NK1-1150 6C5572 Pump Vane Fixed N/A

9KL1-UP 6C5572 Pump Vane Fixed N/A

Application Unknown 2JK1-333 6E5273 Pump Piston Variable N/A 6507 7LM1-1420 6E5273 Pump Piston Variable N/A 6507 8NK1-1150 6E5273 Pump Piston Variable N/A 6507 Multiple Applications 7LM1-UP 6E5273 Pump Piston Variable N/A 6507 2JK1-333 7Y4002 Pump Piston Variable 2 6508 2SL1-UP 7Y4002 Pump Piston Variable 2 6508 6KK1-UP 7Y4002 Pump Piston Variable 2 6508 7CJ1-UP 7Y4002 Pump Piston Variable 2 6508 7LJ1-327 7Y4002 Pump Piston Variable 2 6508 7LM1-UP 7Y4002 Pump Piston Variable 2 6508 8NK1-1150 7Y4002 Pump Piston Variable 2 6508 9KL1-UP 7Y4002 Pump Piston Variable 2 6508 Application Unknown 7LM1-1420 7Y4238 Motor Piston Variable N/A 9000 8NK1-1150 7Y4238 Motor Piston Variable N/A 9000 Multiple Applications 7LM1-UP 7Y4238 Motor Piston Variable N/A 9000 Auxiliary 2SL1-UP 7Y4250 Motor Piston Variable N/A 9000 6KK1-UP 7Y4250 Motor Piston Variable N/A 9000 7CJ1-UP 7Y4250 Motor Piston Variable N/A 9000 7LJ1-327 7Y4250 Motor Piston Variable N/A 9000 8NK1-1150 7Y4250 Motor Piston Variable N/A 9000 9KL1-UP 7Y4250 Motor Piston Variable N/A 9000 Application Unknown 2JK1-UP 7Y4260 Motor Piston Variable N/A

7CJ1-UP 7Y4260 Motor Piston Variable N/A 7LJ1-UP 7Y4260 Motor Piston Variable N/A Auxiliary 2JK1-UP 7Y4273 Motor Piston Variable N/A 9000

7LJ1-UP 7Y4273 Motor Piston Variable N/A 9000

325LN Steering - Supplemental 3LL1-UP 6C5572 Pump Vane Fixed N/A

Multiple Applications 3LL1-UP 7Y4002 Pump Piston Variable 2 6508 Auxiliary 3LL1-UP 7Y4250 Motor Piston Variable N/A 9000 325N Steering - Supplemental 2SK1-450 6C5572 Pump Vane Fixed N/A

Multiple Applications 2SK1-450 7Y4002 Pump Piston Variable 2 6508 Auxiliary 2SK1-450 7Y4250 Motor Piston Variable N/A 9000 Application Unknown 2SK1-UP 7Y4260 Motor Piston Variable N/A

Auxiliary 2SK1-UP 7Y4273 Motor Piston Variable N/A 9000 330 Steering - Supplemental 6ZK1-UP 6C5572 Pump Vane Fixed N/A

8RL1-UP 6C5572 Pump Vane Fixed N/A

9NG1-UP 6C5572 Pump Vane Fixed N/A

9PJ1-UP 6C5572 Pump Vane Fixed N/A

(27)

330 (cont.) Application Unknown 6ZK1-UP 7Y4238 Motor Piston Variable N/A 9000 8RL1-UP 7Y4238 Motor Piston Variable N/A 9000 9NG1-UP 7Y4238 Motor Piston Variable N/A 9000 9PJ1-UP 7Y4238 Motor Piston Variable N/A 9000 9WJ1-41 7Y4238 Motor Piston Variable N/A 9000 Auxiliary 6ZK1-UP 7Y4250 Motor Piston Variable N/A 9000 8RL1-UP 7Y4250 Motor Piston Variable N/A 9000 9NG1-UP 7Y4250 Motor Piston Variable N/A 9000 9PJ1-UP 7Y4250 Motor Piston Variable N/A 9000 330L Auxiliary 5YM1-2101 0874752 Motor Piston Variable N/A 6504 8FK1-937 0874752 Motor Piston Variable N/A 6504 Multiple Applications 5YM1-UP 0874752 Motor Piston Variable N/A 6504

Auxiliary 2ZM1-52 1056596 Motor Gear Fixed N/A

5YM1-2101 1056596 Motor Gear Fixed N/A Swing 6WJ1-1000 5I8729 Motor Piston Variable N/A 9000 Steering - Supplemental 2EL1-UP 6C5572 Pump Vane Fixed N/A

6SK1-1000 6C5572 Pump Vane Fixed N/A

6SK1001-UP 6C5572 Pump Vane Fixed N/A

6WJ1-UP 6C5572 Pump Vane Fixed N/A

8FK1-937 6C5572 Pump Vane Fixed N/A

9ML1-UP 6C5572 Pump Vane Fixed N/A

Application Unknown 5YM1-2101 6E5273 Pump Piston Variable N/A 6507 8FK1-937 6E5273 Pump Piston Variable N/A 6507 Multiple Applications 5YM1-UP 6E5273 Pump Piston Variable N/A 6507 Application Unknown 2EL1-UP 7Y4238 Motor Piston Variable N/A 9000 2ZM1-52 7Y4238 Motor Piston Variable N/A 9000 5YM1-2101 7Y4238 Motor Piston Variable N/A 9000 6SK1-1000 7Y4238 Motor Piston Variable N/A 9000 6SK1001-UP 7Y4238 Motor Piston Variable N/A 9000 6WJ1-UP 7Y4238 Motor Piston Variable N/A 9000 8FK1-937 7Y4238 Motor Piston Variable N/A 9000 9ML1-UP 7Y4238 Motor Piston Variable N/A 9000 Multiple Applications 2ZM1-UP 7Y4238 Motor Piston Variable N/A 9000 5YM1-UP 7Y4238 Motor Piston Variable N/A 9000 Auxiliary 2EL1-UP 7Y4250 Motor Piston Variable N/A 9000 6SK1-1000 7Y4250 Motor Piston Variable N/A 9000 6SK1001-UP 7Y4250 Motor Piston Variable N/A 9000 6WJ1-UP 7Y4250 Motor Piston Variable N/A 9000 8FK1-937 7Y4250 Motor Piston Variable N/A 9000 9ML1-UP 7Y4250 Motor Piston Variable N/A 9000

330LN Steering - Supplemental 8CK1-UP 6C5572 Pump Vane Fixed N/A

Application Unknown 8CK1-UP 7Y4238 Motor Piston Variable N/A 9000 Auxiliary 8CK1-UP 7Y4250 Motor Piston Variable N/A 9000

350 Multiple Applications 2ZL1-UP 0874750 N/A N/A N/A N/A 9000

7RK1-UP 0874750 N/A N/A N/A N/A 9000

8HK1-UP 0874750 N/A N/A N/A N/A 9000

(28)

350 (cont.) Auxiliary 7RK1-UP 0874752 Motor Piston Variable N/A 6504 8HK1-154 0874752 Motor Piston Variable N/A 6504 Multiple Applications 8HK1-UP 0874752 Motor Piston Variable N/A 6504 Steering - Supplemental 7RK1-UP 6C5572 Pump Vane Fixed N/A

8HK1-154 6C5572 Pump Vane Fixed N/A

Application Unknown 2ZL1-UP 7Y4012 Pump Gear Fixed N/A 1004 Multiple Applications 7RK1-UP 7Y4012 Pump Gear Fixed N/A 1004

8HK1-UP 7Y4012 Pump Gear Fixed N/A 1004

350L Multiple Applications 3ML1-UP 0874750 N/A N/A N/A N/A 9000

9DK1-UP 0874750 N/A N/A N/A N/A 9000

9FL1-UP 0874750 N/A N/A N/A N/A 9000

Auxiliary 3ML1-UP 0874752 Motor Piston Variable N/A 6504 9DK1-UP 0874752 Motor Piston Variable N/A 6504 9FL1-UP 0874752 Motor Piston Variable N/A 6504 Steering - Supplemental 9DK1-UP 6C5572 Pump Vane Fixed N/A

9FL1-UP 6C5572 Pump Vane Fixed N/A

Application Unknown 3ML1-UP 7Y4012 Pump Gear Fixed N/A 1004 Multiple Applications 9DK1-UP 7Y4012 Pump Gear Fixed N/A 1004

9FL1-UP 7Y4012 Pump Gear Fixed N/A 1004

375 Swing 8XG1-UP 5I8728 Motor Piston Variable N/A 9000

Multiple Applications 6NK1-UP 7Y4005 Pump Piston Variable 1 6502 6XK1-UP 7Y4005 Pump Piston Variable 1 6502 8WJ1-UP 7Y4005 Pump Piston Variable 1 6502 8XG1-UP 7Y4005 Pump Piston Variable 1 6502 Auxiliary 6NK1-UP 7Y4007 Pump Piston Variable 1 6511 8WJ1-UP 7Y4007 Pump Piston Variable 1 6511 8XG1-UP 7Y4007 Pump Piston Variable 1 6511 Multiple Applications 6XK1-UP 7Y4007 Pump Piston Variable 1 6511 Application Unknown 8XG1-UP 7Y4012 Pump Gear Fixed N/A 1004 Multiple Applications 6NK1-UP 7Y4012 Pump Gear Fixed N/A 1004

6XK1-UP 7Y4012 Pump Gear Fixed N/A 1004

8WJ1-UP 7Y4012 Pump Gear Fixed N/A 1004

Application Unknown 8XG1-UP 7Y4246 Motor Piston Variable N/A 9000 Multiple Applications 6NK1-UP 7Y4246 Motor Piston Variable N/A 9000 6XK1-UP 7Y4246 Motor Piston Variable N/A 9000 8WJ1-UP 7Y4246 Motor Piston Variable N/A 9000 375L Multiple Applications 1JM1-UP 7Y4005 Pump Piston Variable 1 6502 6RL1-UP 7Y4005 Pump Piston Variable 1 6502 9WL1-UP 7Y4005 Pump Piston Variable 1 6502 Auxiliary 1JM1-UP 7Y4007 Pump Piston Variable 1 6511 6RL1-UP 7Y4007 Pump Piston Variable 1 6511 9WL1-UP 7Y4007 Pump Piston Variable 1 6511 Application Unknown 9WL36-UP 7Y4012 Pump Gear Fixed N/A 1004 Multiple Applications 1JM1-UP 7Y4012 Pump Gear Fixed N/A 1004

6RL1-UP 7Y4012 Pump Gear Fixed N/A 1004

9WL1-UP 7Y4012 Pump Gear Fixed N/A 1004

(29)

375L (cont.) Multiple Applications 6RL1-UP 7Y4246 Motor Piston Variable N/A 9000 9WL1-UP 7Y4246 Motor Piston Variable N/A 9000

M318 Auxiliary 6ES1-UP 1112054 Pump Gear Fixed N/A

8AL1-UP 1112054 Pump Gear Fixed N/A

M320 Auxiliary 6WL1-UP 1112054 Pump Gear Fixed N/A

FOREST MACHINES

508 Swing 2HD1-UP 4T5032 Motor Gerotor Fixed N/A 4500

Steering 2HD1-UP 4T5056 Pump Piston Variable 1 5504

9NC1-UP 4T5056 Pump Piston Variable 1 5504 Steering - Supplemental 2HD1-316 9T5140 Pump Gear Fixed 1 1002

9NC1-344 9T5140 Pump Gear Fixed 1 1002

515 Transmission 4LR1-UP 9U8019 Pump Gear Fixed 1

518 Steering 50S1-3492 1U2781 Pump Gear Fixed 1 1002

55U1-907 1U2781 Pump Gear Fixed 1 1002

94U2504-2521 1U2781 Pump Gear Fixed 1 1002 94U2590-2654 1U2781 Pump Gear Fixed 1 1002

95U3205-3240 1U2781 Pump Gear Fixed 1 1002 95U3404-3664 1U2781 Pump Gear Fixed 1 1002 Application Unknown 50S2446-UP 3G7634 Pump Vane Fixed 1 10025

94U537-2503 3G7634 Pump Vane Fixed 1 10025 94U2504-2589 3G7634 Pump Vane Fixed 1 10025 94U2590-UP 3G7634 Pump Vane Fixed 1 10025 Multiple Applications 50S1-UP 3G7634 Pump Vane Fixed 1 10025

94U1-2503 3G7634 Pump Vane Fixed 1 10025

Steering 55U1-UP 3G7636 Pump Vane Fixed 1 10025

95U1-3204 3G7636 Pump Vane Fixed 1 10025

95U3205-UP 3G7636 Pump Vane Fixed 1 10025

Transmission 50S1-3048 3P7958 Pump Gear Fixed 1

55U1-657 3P7958 Pump Gear Fixed 1

94U1-619 3P7958 Pump Gear Fixed 1

Steering - Supplemental 50S1-3492 7J8199 Pump Gear Fixed 1 1002

55U1-907 7J8199 Pump Gear Fixed 1 1002

94U2504-2521 7J8199 Pump Gear Fixed 1 1002 94U2590-2654 7J8199 Pump Gear Fixed 1 1002

95U3205-3240 7J8199 Pump Gear Fixed 1 1002 95U3404-3664 7J8199 Pump Gear Fixed 1 1002

Implement 95U1-3204 9T1763 Pump Vane Fixed 2 12520

95U3205-UP 9T1763 Pump Vane Fixed 2 12520

Steering 95U1-3204 9T1763 Pump Vane Fixed 2 12520

95U3205-UP 9T1763 Pump Vane Fixed 2 12520

518C Steering 1CL1-UP 1U2781 Pump Gear Fixed 1 1002

9HJ1-UP 1U2781 Pump Gear Fixed 1 1002

(30)

518C (cont.) Steering 9HJ1-816 3G7636 Pump Vane Fixed 1 10025 Application Unknown 1CL1-UP 3P1672 Pump Gear Fixed 1

520C Application Unknown 9YK1-UP 6E6012 Pump Piston Variable 1 5074

Transmission 9YK1-119 9U8019 Pump Gear Fixed 1

522C Application Unknown 2WL1-UP 6E6012 Pump Piston Variable 1 5074

Transmission 2WL1-104 9U8019 Pump Gear Fixed 1

525 Transmission 1DN1-UP 9U8019 Pump Gear Fixed 1

528 Steering 51S1-920 1U2781 Pump Gear Fixed 1 1002

78W1-375 1U2781 Pump Gear Fixed 1 1002

96C1-805 1U2781 Pump Gear Fixed 1 1002

Application Unknown 51S1-920 1V8793 Pump Gear Fixed N/A

Implement 51S1-UP 3G7635 Pump Vane Fixed 2 12520

78W1-UP 3G7635 Pump Vane Fixed 2 12520

96C1-859 3G7635 Pump Vane Fixed 2 12520

96C860-UP 3G7635 Pump Vane Fixed 2 12520

Steering 51S1-UP 3G7635 Pump Vane Fixed 2 12520

78W1-UP 3G7635 Pump Vane Fixed 2 12520

Transmission 51S1-UP 3P7958 Pump Gear Fixed 1

78W1-238 3P7958 Pump Gear Fixed 1

78W239-UP 3P7958 Pump Gear Fixed 1

Application Unknown 51S288-UP 6P4996 Pump Gear Fixed 1

96C1-859 6P4996 Pump Gear Fixed 1

96C860-UP 6P4996 Pump Gear Fixed 1

97C263-419 6P4996 Pump Gear Fixed 1

97C420-UP 6P4996 Pump Gear Fixed 1

Steering - Supplemental 51S1-920 7J8199 Pump Gear Fixed 1 1002

78W1-375 7J8199 Pump Gear Fixed 1 1002

96C1-805 7J8199 Pump Gear Fixed 1 1002

Implement 78W1-249 9J0476 Pump Gear Fixed 1 1020

528B Steering 8SJ1-UP 1U2781 Pump Gear Fixed 1 1002

Implement 8SJ1-UP 3G7635 Pump Vane Fixed 2 12520

Steering 8SJ1-UP 3G7635 Pump Vane Fixed 2 12520

530B Steering 5BK1-UP 1U2781 Pump Gear Fixed 1 1002

Application Unknown 5BK1-UP 6E4861 Pump Vane Fixed 3 12020

(31)

FB518 (cont.) Implement 8ZC1-UP 9T1763 Pump Vane Fixed 2 12520

Steering 8ZC1-UP 9T1763 Pump Vane Fixed 2 12520

FRONT-SHOVEL EXCAVATORS

5080 Multiple Applications 8SL1-UP 7Y4005 Pump Piston Variable 1 6502 Auxiliary 6XK1-UP 7Y4007 Pump Piston Variable 1 6511 8SL1-UP 7Y4007 Pump Piston Variable 1 6511 Multiple Applications 8SL1-UP 7Y4012 Pump Gear Fixed N/A 1004 8SL1-UP 7Y4246 Motor Piston Variable N/A 9000 5130 Application Unknown 5ZL1-UP 1003559 Pump Gear Fixed 1 1020 Multiple Applications 5ZL1-UP 1064308 N/A N/A N/A N/A 6502

5ZL1-UP 1064309 N/A N/A N/A N/A 6511

Auxiliary 5ZL1-UP 1249962 Pump Piston Variable 1 5074 Application Unknown 5ZL1-UP 6E5960 Motor Piston Variable N/A 6502 5ZL1-47 6E5980 Motor Piston Variable N/A 6502 Multiple Applications 5ZL1-UP 6E5980 Motor Piston Variable N/A 6502 Application Unknown 5ZL1-UP 6E6048 Pump Piston Variable 1 5074 Cooling - Implement 5ZL1-UP 6E6049 Motor Piston Variable N/A 6502

Lubrication 5ZL1-UP 9T0436 Pump Gear Fixed 1 1016

5230 Multiple Applications 7LL1-UP 1003559 Pump Gear Fixed 1 1020

7LL1-UP 1064308 N/A N/A N/A N/A 6502

Application Unknown 7LL1-UP 1083028 Motor Piston Variable 1 6502 Multiple Applications 7LL1-UP 6E5980 Motor Piston Variable N/A 6502 Cooling - Implement 7LL1-UP 6E6049 Motor Piston Variable N/A 6502 Auxiliary 7LL1-UP 6E6562 Pump Piston Variable 1 5131 7LL1-UP 6E6563 Pump Piston Variable 1 5131 Application Unknown 7LL1-UP 6E6588 Motor Piston Variable 1 6502 Multiple Applications 7LL1-UP 6E6590 Pump Piston Variable 2 6502

INTEGRATED TOOLCARRIERS

IT12 Auxiliary 2YC1-UP 4T8515 Pump Gear Fixed 2

4NC1-UP 4T8515 Pump Gear Fixed 2

Implement 2YC1-1622 4T8517 Pump Gear Fixed 2

4NC1-1781 4T8517 Pump Gear Fixed 2

Steering - Supplemental 2YC1-1622 8J9299 Pump Gear Fixed 1 1002

4NC1-1781 8J9299 Pump Gear Fixed 1 1002

Transmission 4NC1-1781 9P7239 Pump Gear Fixed 1

IT12B Steering 1KF1-819 6E5326 Pump Gear Fixed 1 1014

Application Unknown 1KF1-819 6E5470 Pump Gerotor Fixed N/A 4500

1KF1-819 6E6405 Pump Gear Fixed 2 1036

Steering 1KF1-819 6E6460 Pump Gerotor Fixed N/A 4500

Transmission 1KF1-819 6Y5000 Pump Gear Fixed 1

Application Unknown 1KF1-819 8E9970 Pump Gear Fixed 1

1KF1-819 9T5484 Pump Gear Fixed 1 1014

IT12F Steering 1KF820-UP 6E5326 Pump Gear Fixed 1 1014

Application Unknown 1KF820-UP 6E5470 Pump Gerotor Fixed N/A 4500 6RS1-UP 6E5470 Pump Gerotor Fixed N/A 4500

1KF820-UP 6E6405 Pump Gear Fixed 2 1036
