1979–2009
L
ASER
COMBAT READY OPTICS
for 30 years and counting
L
aser Devices, Inc. began as a vision over 40 years ago. In 1968, Heinz Thummel had just patented the first Helium Neon aiming laser designed for small arms weapons. Over the next decade his technical expertise, innova-tion and focus on manufacturing quality products in the U.S.A. led to the founding of Laser Devices, Inc. in 1979 with the world’s first laser gun sight, Laserscope.Over the past 30 years, Laser Devices has supplied professionals with superior products. We assemble 100% of our prod-ucts in our state-of-the-art manufacturing facility located in Monterey, California. Our aiming lasers, laser-based training systems and tactical lights are currently serving U.S., NATO and international allies’ Military, Law Enforcement and Special Forces personnel who demand tough, virtually indestructible products. From our homeland borders to the mountains of Afghanistan and the deserts of Iraq, our products deliver the reliability that literally spells the difference between life and death.
Laser Devices is a full-service company and holds several patents for its products. We engineer and manufacture sophisti-cated electro-optical devices from concept design through completion using the latest technology and custom made parts. In addition, we design and manufacture OEM modulated laser transmitters for companies throughout the world.
Laser Devices is an approved Govern-ment Contractor for multiple agencies within the U.S. Department of Defense and also serves the FMS market. In addition, we are the sole source of the AN/PEQ-15A, part of the Multi-Functional Aiming Light Contract awarded by the U.S. Army.
Laser Devices’ aiming lasers feature the brightest visible lasers allowed by law. Our new Ultra Power PointTM green
laser is designed to improve range and visibility in daylight and at night without the use of night vision. Our rugged, precision machined aircraft aluminum housings are hard black anodized and meet military standards for reliability in the most extreme environmental conditions. Currently in service on every type of small arms weapon system, our aiming
lasers provide pin-point accuracy and stay aligned while firing magazine after maga-zine of military grade ammunition.
Our tactical lights are simply the most durable and reliable that money can buy. Available with either a high pressure Xenon lamp that produces 95 lumens of stunning white light or an extremely powerful LED that produces an intense 150 lumens of blinding white light, our lights are fully operational from 20,000 feet above sea level to 66 feet below the surface. Designed with a patented recoil absorbing head and lamp assembly, our lights can be safely mounted on any weapon from a .50 caliber Barrett rifle to a .22 caliber pistol.
Additional products include laser bore-lights, the LaserBlaster-Z dry fire training system and the Accur-AimTM laser target.
We also carry a complete line of mounts, holsters, pouches and all of the accesso-ries needed to customize our products to meet any mission requirement.
As we enter our 30th year, we continue
to pursue our vision and commitment to manufacture the most reliable tactical products available.
IN THIS CATALOG
EOLADTM Laser with HWS 2–3
DBAL-A2TM Laser 4–5 ITAL-ATM Laser 6–7 OTAL-ATM Laser 6–7 DBALTM Laser 8 AR-2ATM Laser 9 HK MP5 & G3 Lasers 10 LAS/TACTM Laser 11
MP5 Tactical Light Foregrips 11 MOLADTM Laser & Tactical Light 12
BLAST 2TM Laser & Tactical Light 13
LAS/TAC 2TM Laser or Tactical Light 13
OPERATOR® Tactical Lights 14
OPERATIVE® Tactical Lights 15
BORELIGHTS 16
LASERBLASTER-ZTM Training Device 17
SHOT TRACKERTM Tracking Module 18–19
MOUNTS & ACCESSORIES 20 HOLSTERS & POUCHES 21
www.laserdevices.com
Mission Statement
O
ur mission is to empower our Militaryand Law Enforcement personnel with state-of-the-art, technically advanced laser aiming devices, laser based small arms training simulators, laser based and white light illumination systems and quality laser
diodes and power supplies.
GSA ADVANTAGE
Laser Devices’ products are available to GSA buyers through the GSA Advantage program. Please contact us for details.
“I want to thank you
and the personnel that work at Laser Devices. Everyone is courteous and shows care, concern and respect towards us Soldiers, Sailors, Marines and Air Force.”—Nick, SFC, U.S.A.
“I am extremely pleased
with your product. It is the best laser sight I have ever used.”
—James, Oakland Park, FL
U.S.A
Laser Devices, Inc. 2 Harris Court, Suite #A-4 Monterey, CA 93940
Tel 831-373-0701 • 800-235-2162 Fax 831-373-0903
EUROPE
T
echnik Consulting Alvade, S.L. C/ Sanchez Guerrero No 428043 Madrid SPAIN Tel +34 91 3810600 Fax +34 91 3819276 [email protected]
“Top of the line gear
for top of the line weapons.”—Bill, Dixon, IL
“Thanks for helping
those of
us
that were deployed to OIF, Kosovo and Bosnia. I will always speak highly of Laser Devices, Inc.”—Sgt., John H.“Easy-to-install and use.
Great products!”—Kevin, Scottsdale, AZ
“I am very impressed with all
of your products. I would never consider purchasing lights or lasers from another company after seeing your products.”
—Ben, Belmont CA
“I’ve used a lot of lights
and lasers
and have really found your products to be the best. Also, very helpful customer service. Thanks.”—Allen, via the Internet
LASER WITH HOLOGRAPHIC WEAPON SIGHT
LDI Patent No. 5,581,898
T
he impressive EOLAD combines the power and precision
of a Laser Devices’ laser with the speed and proven
ef-fectiveness of the L-3 EOTech 552 HWS combat optic. This
single, cutting-edge device provides lightening fast target
acquisition and delivers impeccable shooting accuracy in
ever-changing battlefield conditions.
Designed to military standards to withstand temperature,
shock and vibration, the EOLAD is the right combination to
handle the most extreme law enforcement and military
operations with ease.
Now available with a GREEN Ultra Power Point
TMlaser
designed to improve range and visibility in daylight and at
night. The new green laser offers faster target acquisition
and is over TWENTY times more visible than our
traditional red laser beam. Choice of <5mW or <120mW
output.
Choose from the following models and options:
•
EOLAD-2H
—IR Pointer (<40mW) and focusable
IR Illuminator (<40mW)
•
EOLAD-2S
—IR Pointer (<40mW) and Hi-Power
focusable IR Illuminator (<120mW)
•
EOLAD-2L
—IR Pointer (<5mW) and focusable
IR Illuminator (<40mW)
•
EOLAD-2VI
—Choice of red Visible Pointer (<5mW) or
green Visible Pointer (<5mW or <120mW) and
focusable IR Illuminator (<5mW, <40mW or <120mW)
•
EOLAD-1V
—Choice of red Visible Pointer (<5mW) or
green Visible Pointer (<5mW or <120mW )
•
EOLAD-1I
—Focusable IR Illuminator (<5mW, <40mW
or <120mW)
Export License Required. Class IIIb lasers are restricted
to government and law enforcement agencies only.
“
Combining the excellent EOTech sight with a high quality LDI laser
the operator has quick engagement capability for CQC, longer range engagement capability and low light engagement using one device. I’ve fired hundreds of rounds through a carbine equipped with the EOLAD and grow to appreciate its versatility more each time I take it to the range.”
—Leroy Thompson
LASER SPECIFICATIONS
Type: Lo-Power Visible Red / Green Pointer Laser Class IIIa Hi-Power Visible Green Pointer Laser Class IIIb IR Pointer / IR Illuminator Laser Class IIIb Power Output:
Lo-Power Visible Red / Green Pointer (Hi / Lo) <5mW / <1mW Hi-Power Visible Green Pointer (Hi / Lo) <120mW / <10mW Lo-Power IR Pointer (Hi / Lo) <5mW / <1mW Med-Power IR Pointer / IR Illuminator (Hi / Lo) <40mW / <1mW Hi-Power IR Illuminator (Hi / Lo) <120mW / <7mW Wavelength: Visible Red Pointer 635nm Visible Green Pointer 535nm IR Pointer / IR Illuminator 835nm Full Angle Beam Divergence:
Visible Red Pointer / IR Pointer 0.3 mrad Visible Green Pointer 0.5 mrad IR Illuminator 0.5–75 mrad Range/Visibility*:
Visible Red Pointer (Night / Day) 500 meters / 30 meters Lo-Pwr Visible Green Pointer (Night / Day) 2000 meters / 60 meters Hi-Pwr Visible Green Pointer (Night / Day) 4500 meters / 300 meters Lo-Power IR Pointer 600 meters Med-Power IR Pointer / IR Illuminator 2000 meters Hi-Power IR Illuminator 5000 meters
Battery: Two 1.5-volt AA
Battery Life: Up to 5 hours continuous
MECHANICAL SPECIFICATIONS
Limited Warranty: 2 Years
Material: Anodized aircraft aluminum 6061T-6 Weight (with battery) 16.8 oz. / 476.3 grams Size: L 5.5 in. x W 2.4 in. x H 2.4 in. L 14 cm x W 6 cm x H 6 cm Environment: Waterproof to 10 meters
Specifications may change without notice.
*Range may vary depending on light conditions.
EOLAD
TM
2
Optional Pattern Generators for Dual Beam Models
(set of 5 patterns)
NEW
EOLAD-1V
with Green
Laser
MEETS MIL-STD-810F FOR ADVERSE ENVIRONMENTAL CONDITIONS
NEW
EOLAD-2VI
with Green Laser & Simulated focusable IR Illuminator. Shown with our OP-6
Tactical Light, p. 14
EOLAD-2VI
Red Laser & Simulated focusable IR Illuminator
EOLAD-2H
Simulated IR Laser & focusable IR Illuminator“
By far the most superior device
I have ever used in 30 years of shooting. The EOLAD is rugged, accurate and dependable. Every U.S. soldier should receive one of these so they can have total advantage over our enemies.”—Jim J., Union City, IN
Laser Features include
► Hi- and Lo-Power modes of laser operation ► Activation & low battery indicator light ► Fully adjustable windage and elevation for
pin-point accuracy
► Remote cable pressure pad switch and integrated activation switch
• Single tap enables momentary laser activation
• Double tap instantly activates the laser in a continuous ON mode
► Supplied with
• EOTech 552 HWS
• Batteries
• 10” remote cable pressure pad switch
• Nylon pouch
► Optional pattern generators available for Dual Beam models
[email protected]
DBAL-A
2
DUAL BEAM AIMING LASER-ADVANCED
2
AN/PEQ-15A
•
HIGH POWER
LDI Patent No. 5,581,898
T
he powerful DBAL-A
2is equipped with focusable
infrared illuminator, infrared pointer and choice of red
or green visible laser—the brightest visible aiming laser
allowed by law. The DBAL-A
2is designed for maximum
operational versatility while keeping weight and size to
a minimum.
Now available with a GREEN Ultra Power Point
TMlaser
designed to improve range and visibility in daylight
and at night. The new green laser offers faster target
acquisition and is TWENTY times more visible than our
traditional red Super Power Point
TMlaser.
The standard DBAL-A
2is currently in service by special
operations forces worldwide and is also contracted by
the U.S. Department of Defense as AN/PEQ-15A (NSN
#5855-01-535-6166). The NEW High Power model offers
even more unbeatable advantages with the addition of a
120mW infrared illuminator.
When duty calls, the superior DBAL-A
2series is
com-bat-ready and considered the most innovative
multi-functional laser system available today.
Choose from two models and the following options:
DBAL-A
2• IR Pointer
• Focusable IR Illuminator (<40mW)
• Choice of Red or Green Visible Laser
• Color options: Foliage Green, Desert Sand or Black
NEW
DBAL-A
2H
• IR Pointer
• Focusable hi-power IR Illuminator (<120mW)
• Choice of Red or Green Visible Laser
• Color options: Foliage Green, Desert Sand or Black
Restricted to government and law enforcement
agencies only. Export License Required.
TM
DBAL-A
2NEW
Green Laser
, Simulated IR Laser &IR Illuminator shown in Foliage Green
4
“
Your DBAL-A
2is superior
to any
similar device.”
—Charlie Cutshaw, Writer, Editor & Firearms Instructor
“
Your DBAL-A
2is outstanding!
This is the most valuable piece of equipment on my weapon and a MUST for any agency that operates in the dark. The accuracy of the aiming lasers is dead on. The Low and High power modes are a prime tool for Stealth operations, CQC, “room clearing” and Field ops. This device is rugged, durable and can take on the punish-ment of any hostile environpunish-ment. The DBAL-A2 has changed the
rules of operating.”—Steve T., Security Specialist
“
I fired 1000 rounds of ammo
from
my Barrett with the DBAL-A2 mounted and never lost zero.
The only part I had to replace was the battery. THAT’S WHY I PURCHASED THEM FOR THE DEPARTMENT. Thank you. You have been a pleasure to deal with.”—Louis, via the Internet
Pattern Generators
(set of 5 patterns)
Features include
► Hi- and Lo-Power modes of laser operation ► Instantly switch between laser functions
• Visible Pointer only
• IR Pointer only
• IR Illuminator only
• IR Pointer & IR Illuminator combined ► Activation and low battery indicator light
► Single adjustment mechanism for both visible and infrared pointers
► Positive On/Off switch prevents accidental activation ► Remote cable pressure pad switch and integrated
momentary activation switch
• Single tap enables momentary activation
• Double tap instantly activates the laser in a continuous ON mode
► Fully adjustable windage and elevation for pin-point accuracy
► Supplied with
• Quick release throw lever mount
• Pattern generators
• Battery
• 7” remote cable pressure pad switch
• Nylon pouch
MEETS MIL-STD-810F FOR ADVERSE ENVIRONMENTAL CONDITIONS &
EXPLOSIVE ATMOSPHERE MEETS U.S. ARMY TOP 1-2-511 FOR
STATIC ELECTRICITY HAZARD— IMMUNE TO DAMAGE FROM ELECTRO STATIC DISCHARGE
DBAL-A
2Red Laser & Simulated IR laser and IR Illuminator. Shown
with our OP-6 Tactical Light, p. 14
“
Your DBAL-A
2is tremendous.
This device is becoming well known in both Iraq and Afghanistan and many units are asking for it. The performance is incredible and it’s perfect for directing Close Air Support.”—Rick, B. , Ammisville, VA
LASER SPECIFICATIONS
Type: Visible Pointer Laser Class IIIa IR Pointer / IR Illuminator Laser Class IIIb Power Output:
Visible Red / Green Pointer (Hi / Lo) <5mW / <1mW IR Pointer (Hi / Lo) <40mW / <1mW IR Illuminator (Hi / Lo) <40mW / <1mW Hi-Power IR Illuminator (Hi / Lo) <120mW / <7mW Wavelength: Visible Red Pointer 635nm Visible Green Pointer 535nm IR Pointer / IR Illuminator 835nm Full Angle Beam Divergence:
Visible Red Pointer / IR Pointer 0.3 mrad Visible Green Pointer 0.5 mrad IR Illuminator 0.5–75 mrad Range/Visibility*:
Visible Green Pointer (Night / Day) 2000 meters / 60 meters Visible Red Pointer (Night / Day) 500 meters / 30 meters IR Pointer 600 meters IR Illuminator 2000 meters Hi-Power IR Illuminator 5000 meters Battery: One 3-volt Lithium Battery Life: Up to 20 hours continuous
MECHANICAL SPECIFICATIONS
Limited Warranty: 1 Year
Material: Anodized aircraft aluminum 6061T-6 Weight (with battery): 8.2 oz. / 232 grams Size: L 3.4 in. x W 2.9 in. x H 1.9 in. L 8.5 cm. x W 7.4 cm x H 4.8 cm Environment: Waterproof to 20 meters
6
[email protected]
ITAL-A & OTAL-A
INLINE & OFFSET TACTICAL AIMING LASERS-ADVANCED
LDI Patent No. 5,581,898
NEW
ADVANCED
SERIES
Overall Features include
► Lo- and Hi-power modes of laser operation
► Compact design to minimize weight added to front of weapon ► Low profile allows the laser to be front mounted to
accommo-date scopes, holographic sights or night vision devices ► Remote cable pressure pad switch and built-in momentary
activation switch
• Single tap enables momentary activation
• Double tap instantly activates the laser in a continuous ON mode
► Supplied with
• Quick release throw lever mount
• Mounting holes for Docter Sight® Model MS02 or
MIL-SPEC-1913 rail adapter plate (both sold seperately)
• 7” remote cable pressure pad switch
• Battery
► Optional pattern generators available for infrared models ► Manufactured in the USA
ITAL-A Features include
► Specifically designed for flat top rifles
OTAL-A Features include
► Specifically designed for M-4 style rifles ► Laser won’t obscure iron sight
► Laser beam projects around the left side of the front sight MEETS MIL-STD-810F FOR
ADVERSE ENVIRONMENTAL CONDITIONS
This precision machined
adjustable focus laser allows users to easily change the beam diameter. One quick turn of the aperture adjusts the beam from a pin-point dot to a wide-angle flood.Optional Pattern Generators for Infrared Models
(set of 5 patterns)
TM
TM
T
he NEW ITAL-A and OTAL-A single module adjustable
focus lasers are rugged, compact, fully waterproof and
manufactured with the latest cutting-edge technology.
The A-series includes an adjustable focusing ring which
allows the operator to adjust the size of the laser beam
depending on mission requirements. When focused, the
laser provides a continuous beam along the weapon’s line of
fire for precise aiming. When defocused, the beam spreads
to provide improved illumination and situational
aware-ness. Additional features include a built-in double tap switch
which activates the laser in either a momentary (single tap)
or continuous ON mode (double tap).
ITAL’s mount on flat top rifles or with a cropped front
sight. The laser aligns with the center of the barrel. OTAL’s
mount behind the front sight on M-16 or M-4 style rifles
and the laser is offset to project around the front sight.
Laser Devices’ new GREEN Ultra Power Point
TMlaser is
designed to improve range and visibility in daylight and at
night. The green laser offers faster target acquisition and
is over TWENTY times more visible than our traditional red
laser beam. Choice of <5mW or <120mW output.
Choose from the following models and options:
•
ITAL-A Infrared
—Focusable IR laser (<5mW, <40mW
or <120mW)
•
ITAL-A Visible
—Choice of focusable red Visible Laser
(<5mW) or focusable Green Visible Laser (<5mW or
<120mW)
•
OTAL-A Infrared
—Focusable IR laser (<5mW, <40mW
or <120mW)
•
OTAL-A Visible
—Choice of focusable red Visible Laser
(<5mW) or focusable Green Visible Laser (<5mW or
<120mW)
Export License Required. Class IIIb lasers are restricted
to government and law enforcement agencies only.
NEW
ITAL-A Visible
with Green Laser
shown with Docter Sight MS02
LASER SPECIFICATIONS
Type:
Lo-Power Visible Red / Green Laser Laser Class IIIa Hi-Power Visible Green Laser Laser Class IIIb
IR Laser Laser Class IIIb
Power Output:
Lo-Power Visible Red / Green Laser (Hi / Lo) <5mW / <1mW Hi-Power Visible Green Laser (Hi / Lo) <120 mW / 10mW Lo-Power IR Laser (Hi / Lo) <5mW / <1mW Med-Power IR Laser (Hi / Lo) <40mW / <1mW Hi-Power IR Laser (Hi / Lo) <120mW / 7mW Wavelength:
Visible Red Laser 635nm
Visible Green Laser 535nm
IR Laser 835nm
Full Angle Beam Divergence: 0.5–75 mrad Range/Visibility*:
Visible Red Laser (Night / Day) 500 meters / 30 meters Lo-Pwr Visible Green Laser (Night / Day) 2000 meters / 60 meters Hi-Pwr Visible Green Laser (Night / Day) 4500 meters / 300 meters Lo-Power IR Laser 600 meters Med-Power IR Laser 2000 meters Hi-Power IR Laser 5000 meters Battery: One 3-volt Lithium Battery Life (depending on model): Up to 20 hours continuous
MECHANICAL SPECIFICATIONS
Limited Warranty: 1 Year
Material: Anodized aircraft aluminum 6061T-6 Weight (w/ battery & mount): 5.5 oz. / 138.9 grams Size: L 3.8 in. x W 1.8 in. x H 1.45 in
L 9.7 cm x W 4.6 cm x H 3.7 cm Environment: Waterproof to 20 meters
Specifications may change without notice. *Range may vary depending on light conditions
ITAL & OTAL CLASSIC MODELS
NEW
ITAL-A Infrared
with simulated IR Laser shown with Docter Sight MS02
(sold separately)
OTAL CLASSIC
Visible Laser
CLASSIC MODELS AVAILABLE WHILE SUPPLIES LAST!
SUPPLIED WITH THE FOLLOWING:
► Choice of visible red or infrared aiming laser (>5mW)
► Quick release throw lever mount or knurled thumb screw mount ► 7” remote cable pressure pad switch
► One 1.5-volt AA Battery
DBAL
TM
“Thanks for building a great device.
Myself and another one of my instructors both came out of the Army Special Forces and had extensive use with laser aiming devices. Your DBAL is a far superior system to the ones we were issued. Thanks for providing the military, federal, state and local officers with an invaluable tool which aids them in the day-to-day conduct of their duties.”—Kyle H., Brunswick, GA
T
he DBAL provides optimal power
with an infrared laser for use with
night vision devices and a Super
Power Point™ visible laser—the
brightest red laser allowed by law.
Operationally versatile, the durable,
battle-tested DBAL has a proven track
record to enhance the operating
capabilities of any law enforcement or
military unit.
Choice of long or short top rail;
or DBAL-IR with high power infrared
pointer and infrared illuminator for
the maximum advantage in low-light
confrontations.
Restricted to law enforcement
and government agencies only.
Export License Required.
Features include
► Instantly switch between visible laser and infrared laser
► Mounts on all MIL-SPEC-1913 rails ► Integrated top rail provides mounting
point for red dot and holosights, scopes and LDI tactical lights
► Fully adjustable windage and elevation for pin-point accuracy
► Lasers adjust independently— no tools needed
► Positive On/Off/Kill switch prevents accidental activation
► Supplied with
• Quick release throw lever mount or knurled thumb screw mount
• Battery
• 7” remote cable pressure pad switch
• Nylon belt pouch ► Manufactured in the U.S.A.
DUAL BEAM AIMING LASER
LDI Patent No. 5,581,898
LASER SPECIFICATIONS
Type: Visible Pointer Laser Class IIIa IR Pointer / IR Illuminator Laser Class IIIb Power Output:
Visible Pointer <5mW IR Pointer / IR Illuminator <1mW Hi-Power IR Pointer / IR Illuminator <40mW Wavelength: Visible Pointer 635nm IR Pointer / IR Illuminator 835nm Full Angle Beam Divergence:
Visible Pointer / IR Pointer 0.3 mrad IR Illuminator 40 mrad Range/Visibility*:
Visible Pointer (Night / Day) 450 meters / 30 meters IR Pointer / IR Illuminator 600 meters Hi-Power IR Pointer / IR Illuminator 2000 meters Battery: One 1.5-volt AA Battery Life: 5 hours continuous
MECHANICAL SPECIFICATIONS
Limited Warranty: 1 Year Material: Anodized aircraft aluminum 6061T-6 Weight (with battery): 7.5 oz. / 212.6 grams Size: L 2.8 in. x W 2.1 in. x H 1.1 in. L 7.1 cm x W 5.4 cm x H 2.7 cm Environment: Waterproof to 3 meters
Specifications may change without notice.
*Range may vary depending on light conditions.
8
DBAL
Visible Laser & Simulated IR Laser
[email protected]
DBAL
shown with OP-6 Tactical Light, p. 14
AR-2A
LASER WITH TACTICAL LIGHT MOUNT
Available for: M-16, AR-15 and M-4 Rifles
Patent No. 5,581,898
TM
MEETS MIL-STD-810F FOR ADVERSE ENVIRONMENTAL CONDITIONS
“I
personally carried one
of your
AR-2A lasers while in theatre. I was absolutely amazed by the range the device could be used at as well as its daytime capabilities. Your laser helps me and the rest of my unit in critical combat missions.”—Michael, Bellevue, OH
“Y
ou made my job and my life much easier
while I was in Iraq
.The AR-2A laser works better than I imagined. I was on the night shift patrol and used the laser to help designate targets for my fire teams. We also used it to warn people that they were under surveillance. It was so effective it saved lives—not only my squads, but Iraqi citizens, too. Thanks for helping those of us that were deployed. ”—Sgt. John H.
FEATURES INCLUDE
► No weapon modification required ► Lightweight—No rail equipped foregrip
or barrel mounting bracket required ► Laser won’t obscure iron sight
► Dual MIL-SPEC-1913 rails provide a sturdy mount for our OPERATOR tactical lights or other accessories ► Accommodates M-203 equipped rifles
with side sling mount
► Fully adjustable windage and elevation ► Supplied with
• Mounting hardware
• Battery
• 7” remote cable pressure pad switch ► Manufactured in the U.S.A.
O
UR MOST POPULAR
LAW ENFORCEMENT &
COMMERCIAL LASER SYSTEM
The AR-2A laser provides maximum
flexibility in critical situations. This
lightweight, rugged device meets
MIL-STD-810F requirements for
reli-ability under harsh environmental
conditions. Choice of red or green
visible laser—the brightest visible
lasers allowed by law.
Our new GREEN Ultra Power
Point
TMlaser is designed to improve
range and visibility in daylight and at
night. The green laser offers faster
tar-get acquisition and is TWENTY times
more visible than our traditional red
Super Power Point
TMlaser.
The AR-2A includes a sturdy
MIL-SPEC-1913 rail mount to
accommo-date our popular OPERATOR
®lights or
other accessories depending on your
mission requirements.
Available for M-4, M-16 and AR-15
rifles.
Export License Required.
Optional infrared lasers are
restricted to government and law
enforcement agencies only.
LASER SPECIFICATIONS
Type: Visible Pointers Laser Class IIIa IR Pointer Laser Class IIIb Power Output: Visible Pointers <5mW
IR Pointer <1mW
Wavelength: Visible Red Pointer 635nm Visible Green Pointer 535nm
IR Pointer 835nm
Full Angle Beam Divergence:
Visible Red Pointer / IR Pointer 0.3 mrad Visible Green Pointer 0.5 mrad Range/Visibility*:
Vis Green Pointer (Night / Day) 2000 meters / 60 meters Vis Red Pointer (Night / Day) 500 meters / 30 meters
IR Pointer 600 meters
Battery: One 1.5-volt AA Battery Life: 5 hours continuous
MECHANICAL SPECIFICATIONS
Limited Warranty: 1 Year Material: Anodized aircraft aluminum 6061T-6 Weight (with battery & mount): 5.6 oz. / 159 grams Size (excluding mount): L 4.9 in. x W .74 in. x H 1.7 in. L 12.4 cm x W 1.9 cm x H 4.3 cm Environment: Waterproof to 3 meters
Specifications may change without notice. Range may vary depending on light conditions.
NEW
Green Visible
Laser
HK MP5 & G3
LASERS FOR SUBMACHINE GUNS
LDI Patent No. 5,581,898
MEETS MIL-STD-810F FOR HARSH ENVIRONMENTAL CONDITIONS
Overall Features include
► Black oxide MIL-C-13924C stainless steel housing
► No weapon modification required ► Fully adjustable windage and elevation ► Supplied with batteries, alignment tool
and remote cable pressure pad switch (excludes grip laser)
► Manufactured in the U.S.A.
HK MP5 Dual Beam Features
► Select between visible or infrared laser ► Optional infrared laser with infrared
illuminator available
► Kill switch prevents accidental activation ► Aiming lasers have low parallax to sight
HK MP5 Single Beam Features
► Mounts with a single hex screw ► NATO approved—
NSN #1005-99-257-9852 (Visible laser); NSN #1005-99-973-1704 (Infrared laser)
HK MP5K Grip Features
► Custom designed to fit vertical foregrip ► Choice of single or dual beam lasers ► Built-in button switch offers momentary
activation
► Mounting rail for OPERATOR tactical lights available
L
aser Devices offers the largest
selection of lasers for the HK MP5,
MP5K and G3 weapons.
► MP5 Dual Beam Laser
—offers
maximum versatility for daytime
and night time operations. Choice
of red visible laser and infrared
laser or infrared laser and infrared
illuminator.
► MP5 Single Beam Laser
—fits snug
and secure inside the cocking
tube of the HK MP5. Choice of red
visible laser or infrared laser. NATO
approved!
► HK MP5K Grip Laser
—precision
manufactured using the Heckler
& Koch factory vertical foregrip.
Choice of dual beam with red
visible and infrared aiming lasers;
or single beam with red visible or
infrared aiming laser.
Infrared lasers are restricted to
government and law enforcement
agencies only. Export License
Required.
MP5K
Grip
MP5 Laser
shown with our Tactical Light Foregrips, p. 11
10
“
Easy-to-operate, zero and mount
both in training and actual operations. Overall product quality and reliability is very good. For SWAT members, equipment must be durable and most of all, reliable. The HK MP5 Dual Beam laser meets this criteria.”
—Special Weapons Team
LASER SPECIFICATIONS
Type: Visible Pointer Laser Class IIIa IR Pointer Laser Class IIIb Power Output: Visible Pointer <5mW
IR Pointer <1mW
Wavelength: Visible Pointer 635nm
IR Pointer 835nm
Full Angle Beam Divergence:
Visible Pointer / IR Pointer 0.3 mrad IR Illuminator 40 mrad Range/Visibility*:
Visible Pointer (Night / Day) 450 meters / 30 meters IR Pointer 600 meters Battery:
MP5 Dual Beam / MP5 / G3 One 6-volt PX28L Lithium MP5K One 3-volt 123A Lithium Battery Life: MP5 Dual Beam 1.5 hours continuous MP5/G3 1 hour continuous MP5K 24 hours continuous
Specifications may change without notice.
*Range may vary depending on light conditions
MECHANICAL SPECIFICATIONS
Limited Warranty: 1 Year Material: Stainless steel Weight (with battery):
MP5K (with grip) 5.7 oz. / 161 grams MP5 Dual Beam 4.1 oz. / 117 grams MP5 / G3 3.1 oz. / 87.9 grams Size: MP5K (with grip) L 3.9 in. x W 1.5 in. x H 4.9 in. L 9.9 cm x W 3.7 cm x H 12.5 cm MP5 Dual Beam L 1.6 in. x W 1.2 in. x H .95 in.
L 4.1 cm x W 3 cm x H 2.4 cm MP5 / G3 L 1.3 in. / 3.2 cm Environment: Waterproof to 3 meters
LAS/TAC
LASER SYSTEM
Available for: Rifles & MP5SD • LDI Patent No. 5,581,898
TM
TACTICAL
LIGHT
FOREGRIPS
LASER SPECIFICATIONS
Type: Visible Pointers Laser Class IIIa IR Pointer Laser Class IIIb Power Output: Visible Pointers <5mW IR Pointer <1mW Wavelength: Visible Red Pointer 635nm Visible Green Pointer 535nm IR Pointer 835nm Full Angle Beam Divergence:
Visible Red Pointer / IR Pointer 0.3 mrad Visible Green Pointer 0.5 mrad Range/Visibility*:
Vis Green Pointer 2000 meters (Night) / 60 meters (Day) Vis Red Pointer 500 meters (Night) /
30 meters (Day) IR Pointer 600 meters Battery: One 3-volt 123A Lithium Battery Life: 24 hours continuous
MECHANICAL SPECIFICATIONS
Limited Warranty: 1 Year Material: Anodized aircraft aluminum Weight (w/battery): 4.6 oz. / 130.4 grams Length: 3.4 in. / 8.7 cm Diameter: 1 in. / 2.5 cm
Features include
► Meets MIL-STD 810F for adverse environ-mental conditions ► Fully adjustable
windage & elevation ► Modular design
allows the laser tailcap to interchange with our OPERATOR tactical light tailcap switches ► Mounts to a variety of firearms using LDI’s suppressor, magazine tube or MIL-SPEC-1913 rail mounts
► Supplied with battery and alignment tool ► Made in the U.S.A.
T
he versatile LAS/TAC laser fits rifles, shotguns and
submachine guns including the MP5SD. LAS/TAC
mounts to any MIL-SPEC-1913 rail using a one inch
ring mount, the MP5SD using our one piece
suppres-sor mount or to a variety of shotguns using one of our
magazine tube mounts. Choice of red or green visible
laser—the brightest visible lasers allowed by law.
Inter-changeable tailcaps provide users with multiple
switch-ing options to meet every mission requirement.
Our new GREEN Ultra Power Point
TMlaser is designed
to improve range and visibility in daylight and at night.
The green laser offers faster target acquisition and is
TWENTY times more visible than our red Super Power
Point
TMlaser.
Export License Required. Optional infrared lasers
are restricted to government and law enforcement
agencies only.
TACTICAL LIGHT SPECIFICATIONS
Light output:
Incandescent 95 Lumens
LED 150 Lumens
Lamp type:
Incandescent High Pressure Xenon LED High Intensity Light Emitting Diode Battery: Two 3-volt 123A Lithium Battery Life:
Incandescent 1 hour continuous LED 1.5 hours continuous
MECHANICAL SPECIFICATIONS
Limited Warranty: 1 yr /3 yrs on LED Weight (w/battery): 11.13 oz. / 315.5 grams Size: L 9.5 in. x W 2.125 in. x H 3 in. L 24.1 cm x W 5.4 cm x H 7.6 cm Head Diameter: 1.25 in. / 3.2 cm Environment: Waterproof to 20 meters
O
ur tactical light foregrips
for the MP5 offer a tough,
reliable lighting solution for
active law enforcement or
military special operations
teams using the HK MP5
subma-chine gun.
Powered
with either
a 95 lumen
incandescent lamp or a blinding 150 lumen high intensity LED, our
tactical light foregrips enable Law Enforcement and Military units to
accomplish any mission requirement
Features include
► Choice of Incandescent or LED
• focusable/defocusable incandescent light produces a stunning 95 lumens
• high intensity LED produces a blinding 150 lumens ► Shock absorbing incandescent
light head virtually eliminates shock induced lamp failure ► Compatible with suppressors—
No special adapter required ► Tip-off filters available ► Available with momentary
switch, momentary with positive On/Off rocker switch or momentary with positive Off (kill) switch
► Supplied with batteries ► Manufactured in the U.S.A.
NEW
Green Visible
Laser
Tactical Light
Foregrips
Shown with MP5 Laser p. 10MULTI-OPERATIONAL
LASER AIMING DEVICE
LDI Patent No. 5,581,898
Laser Features
► Parallel aiming lasers follow identical optical path to target
► Low parallax to the sight
IR Illuminator Features
► LED Illuminator with 20 lumens of power—Illuminates up to a 10 x 10 meter room
Tactical Light Features
► 6-volt, shock absorbing incandescent light produces 95 lumens of stunning light and virtually eliminates shock induced lamp failure
► Focusable/defocusable lamp ► Available with compact or full-size
tactical light head
T
he MOLAD laser and tactical light
system delivers with proven
reli-ability and pin-point accuracy when
it counts. This multi-functional device
offers a durable tactical light and
infrared illuminator combined with
red visible Super Power Point™ and
infrared aiming lasers.
MOLAD allows for users to move
seamlessly in low light with or
without the use of night vision. This
unbeatable combination offers the
power and precision required by law
enforcement and military personnel
worldwide.
Fits a variety of popular pistols.
Also available with quick release
throw lever mount for use on rifles.
Restricted to law enforcement
and government agencies only.
Export License Required.
Overall Features
► Visible functions include
• Visible laser only
• Tactical light only
• Visible laser and tactical light combined
► Infrared functions include
• Infrared laser only
• Infrared illuminator only
• Infrared laser and infrared illuminator combined ► Supplied with alignment tool,
batteries and nylon pouch
► Available with quick release throw lever mount for use on rifles ► Manufactured in the U.S.A.
AVAILABLE FOR: GLOCK • SIG WALTHER • SMITH & WESSON • IMI
BERETTA • MIL-SPEC-1913 RAILS SPRINGFIELD • HECKLER & KOCH
“
Innovative, unique device.
incorporates a high-intensity white light, visible laser, IR laser and LED illuminator in an extremely lightweight and compact package.”
—Charlie C., evaluator/writer
MOLAD
TM
LASER SPECIFICATIONS
Type: Visible Pointer Laser Class IIIa IR Pointer / IR Illuminator Laser Class IIIb IR Illuminator Light Emitting Diode Power Output: Visible pointer <5mW IR Pointer / IR Illuminator <1mW Wavelength: Visible Pointer 635nm IR Pointer / IR Illuminator 835nm Full Angle Beam Divergence:
Visible Pointer / IR Pointer 0.3 mrad Range/Visibility*:
Visible Pointer (Night / Day) 450 meters / 30 meters
IR Pointer 600 meters
Battery: Two 3-volt 123A Lithium Battery Life: 24 hours continuous
Specifications may change without notice.
*Range may vary depending on light conditions
Tactical light Specifications
Light output: 95 Lumens
Lamp type: Xenon
Diameter of Head (Full-size): 1.25 in. / 3.2 cm Battery: Two 3-volt 123A Lithium Battery Life: 1.5 hours continuous
Mechanical Specifications
Limited Warranty: 1 Year Material: Specially formulated polymer Weight (w/batteries, w/o mount): 7.3 oz. / 207 grams Size: L 4 in. x W 1.55 in. x H 1.85 in. L 10.1 cm x W 3.9 cm x H 4.7 cm Environment: Water Resistant
12
MOLAD
Visible Laser, Simulated IR Laser, IR Illuminator &
Tactical Light
LASER OR TACTICAL LIGHT
LAS/TAC 2
TM
LASER SPECIFICATIONS
Type: Visible Pointer Laser Class IIIa IR pointer Laser Class IIIb Power Output: Visible Pointer <5mW
IR Pointer <1mW
Wavelength: Visible Pointer 635nm
IR Pointer 835nm
Full Angle Beam Divergence:
Visible / IR Pointer 0.3 mrad Range/Visibility*:
Vis Pointer (Night / Day) 450 meters / 30 meters IR Pointer 600 meters Battery: Two 3-volt 123A Lithium Battery Life: 48 hours continuous
Specifications may change without notice.
*Range may vary depending on light conditions
TACTICAL LIGHT SPECIFICATIONS
Light Output: Incandescent 95 Lumens
LED 150 Lumens
Lamp Type: Incandescent High pressure Xenon LED High intensity light emitting diode Diameter of Compact Head 1 in. / 2.5 cm Battery: Two 3-volt 123A Lithium Battery Life: Incandescent 1 hour continuous LED 1.5 hours continuous
MECHANICAL SPECIFICATIONS
Limited Warranty: 1 Year on Laser/Tactical Light 3 Years on LED Illuminator Material: High impact polymer Weight (with batteries): 3.1 oz. / 88 grams Size:
LAS/TAC 2 L 3.2 in. x W 1.4 in. x H 1.3 in. L 8.3 cm x W 3.7 cm x H 3.3 cm BLAST 2 L 3.2 in. x W 1.9 in. x H 1.8 in.
L 8.3 cm x W 4.8 cm x H 4.7 cm Environment: Waterproof to 3 meters
LAS/TAC 2
LED
Overall Features include
► Attaches and detaches in seconds ► Popular holsters available
► Choice of custom-molded remote cable
pressure pad or standard lever switch
► Supplied with batteries ► Manufactured in the U.S.A.
Laser Features include
► Super Power Point™ visible laser—
the brightest red laser allowed by law
► Fully adjustable windage and elevation—
attaches and detaches without realignment
Tactical Light Features include
► Choice of Incandescent or LED
• focusable/defocusable incandescent lights produce 95 lumens of light
• high intensity LEDs produce a blinding 150 lumens
► Shock absorbing incandescent lamp
virtually eliminates shock induced lamp failures
► Full-size or compact light head available ► Optional tip-off filters available
“
LAS/TAC 2 is indispensable.
In addition to evaluating military and law enforcement equipment, I have used several lights
as a reserve police officer. The best I have seen is the LAS/TAC 2 LED. This light is the brightest I
have ever used.”—Charlie C., Florence, AL
AVAILABLE FOR: GLOCK • SIG WALTHER • SMITH & WESSON • IMI
BERETTA • MIL-SPEC-1913 RAILS SPRINGFIELD • HECKLER & KOCH
BLAST 2
LED
T
he powerful BLAST 2 is equipped
with a visible red Super Power
Point™ laser for pin-point accuracy
and a bright, white tactical light to
provide the exceptional illumination
needed for low light encounters.
LAS/TAC 2 is available with either
a visible red Super Power Point™
laser or a rugged tactical light.
Each device is compact, extremely
lightweight and designed to attach
or detach in seconds to a variety of
popular weapons.
Tactical lights can be configured
with either a 6-volt incandescent
lamp that produces 95 lumens of
bright, white light or a high intensity
LED that produces 150 lumens of
stunning white light.
Switch options include a 3-way
lever switch or a custom-molded
remote cable pressure pad switch
with incorporated lever switch.
Fits a variety of popular pistols.
Also available with quick release
throw lever mount for use on rifles.
Export License Required for Lasers.
Optional infrared lasers restricted
to government
and law
enforcement
agencies
only.
LASER AND TACTICAL LIGHT
BLAST 2
LDI Patent No. 5,581,898
“
BLAST 2 is the best
laser and light combo I’ve seen.” —Richard, Seminole, FL
“
Impressive.
Simple, sturdy, quick to attach and universal.”—Ben, Belmont, CA
OP-6 & OP-9
HANDHELD OR WEAPON-MOUNTED
TACTICAL LIGHTS
LDI Patent No. 6,183,106
OPERATOR
©
TACTICAL LIGHT SPECIFICATIONS
Light Output: OP-6 Incandescent 95 Lumens OP-9 Incandescent 125 Lumens OP-6 & OP-9 LED’s 150 Lumens Lamp Type: Incandescent High Pressure Xenon LED High Intensity Light Emitting Diode Battery:
OP-6 Two 3-volt 123A Lithium OP-9 Three 3-volt 123A Lithium Battery Life:
Incandescent 1 hour continuous LED 1.5 hours continuous
Specifications may change without notice.
MECHANICAL SPECIFICATIONS
Limited Warranty: 1 Year on Tactical Light 3 Years on LED Illuminator Material: Anodized aircraft aluminum 6061T-6 Weight (with push button tailcap and batteries): OP-6 4.6 oz. / 130.4 grams OP-9 5.7 oz. / 161.6 grams Length:
OP-6 5.3 in. / 13.4 cm OP-9 6.7 in. / 16.9 cm Diameter of Head: 1.25 in. / 3.2 cm Environment: Waterproof to 20 meters
O
ur impeccable OPERATOR
series
of tactical lights can be handheld
or mounted with or without a laser
on a variety of law enforcement and
military weapons. Their compact size,
ultra-light weight and superior beam
quality make the OPERATOR lights a
must for any operation or extended
mission where every ounce counts.
Choice of 6-volt OP-6 or 9-volt
OP-9 equipped with either a shock
absorbing incandescent light or a
blinding high intensity LED.
Mounting options include a quick
release throw lever mount or
MIL-SPEC ring mount (shotgun mounts
sold separately, see p. 20).
Interchangeable tailcap switches
allow users to custom configure the
light to meet mission requirements.
LDI’s superior quality OPERATOR
lights are used worldwide by law
enforcement and military personnel
who depend on professional grade
lights with the versatility and
durabil-ity to accomplish any task.
FEATURES INCLUDE
► Choice of Incandescent or LED
• OP-6: focusable/defocusable incandes-cent lights produce 95 lumens of bright white light
• OP-9: focusable/defocusable incan-descent lights produce 125 lumens of intense white light
• OP-6 & OP-9: high intensity LED’s produce a stunning 150 lumens—Over 30 times brighter than a standard high power LED
► Shock absorbing incandescent light head
virtually eliminates shock induced lamp failures
► Deeply knurled non-slip grip
► Available with MIL-SPEC-1913 ring mount
or quick release throw lever mount
► Interchangeable tailcap switches include
• coil wire pressure pad switch
• straight wire pressure pad switch
• push button switch
• toggle switch
► Supplied with batteries
► Optional tip-off filters available in red and
blue. Infrared tip-off filter available for incandescent lights only
► Manufactured in the U.S.A.
OP-6
shown with Red Tip-Off Filter
14
“
An excellent flashlight
that supports us and sheds light in the darkest of places that we soldiers go. Myself and many Soldiers that I know prefer your flashlight over other brands and it is because your flashlight is dependable, rugged and works in extreme climate situations. Due to your support of the military we all Thank You and are Honored to use your products.”—Nick SFC, U.S.A
“I’
m VERY happy with my OPERATOR OP-9.
Nice and compact. The mount grips the body rock solid. Good all around bargain, too.”—Ian, via the Internet
OP-6 LED
shown with EOLAD-2VI, pp. 2–3
MEETS MIL-STD-810F FOR TOUGH ENVIRONMENTAL CONDITIONS
Optional
Tip-Off
Filters
OV-1 HANDHELD TACTICAL LIGHTS
OPERATIVE
©
TACTICAL LIGHT SPECIFICATIONS
Light Output: Incandescent 95 Lumens
LED 150 Lumens
Lamp Type: Incandescent High Pressure Xenon LED High Intensity Light Emitting Diode Battery: Two 3-volt 123A Lithium Battery Life: Incandescent 1 hour continuous LED 1.5 hours continuous
Specifications may change without notice.
mechanical SPECIFICATIONS
Limited Warranty: 1 Year on Tactical Light 3 Years on LED Illuminator Material: Anodized aircraft aluminum 6061T-6 Weight (with battery): 3.1 oz. / 88 grams Length: 4.7 in. / 11.9 cm Diameter of Head: 1 in. / 2.5 cm Environment: Waterproof to 20 meters
FEATURES INCLUDE
► Choice of Incandescent or LED
• 6-volt focusable/defocusable incandes-cent lights produces 95 lumens of bright, white light
• high intensity LEDs produce a stunning 150 lumens—Over 30 times brighter than a standard high power LED
► Aircraft 6061T-6 aluminum housing ► Deeply knurled non-slip grip ► Easy one-hand activation ► Supplied with
• Push button switch (On/Off/Momemtary)
• Removable pocket clip
• Wrist lanyard
• Batteries
► Optional tip-off filters available in red,
green and blue. Infrared filter available for incandescent lights only
► Manufactured in the U.S.A.
O
ur OPERATIVE
®OV-1 handheld
tactical lights are compact and
lightweight, yet powerful and precise
with the versatility you need to face
any situation. These pocket-sized
flashlights pack the power of many
full-size flashlights at a fraction of
their size and weight.
The white light emitted by our
tac-tical lights allows users to accurately
identify facial features at 30 feet.
The 95 lumen incandescent lamp
can be focused from a bright spot to
a wide beam that will illuminate an
entire room.
The extremely powerful LED
pro-duces 150 lumens of blinding, white
light.
Incandescent lights are available
in an array of colors including NEW
Desert Sand and Foliage Green. LED’s
available in black only.
“Rugged, reliable, waterproof for sure!
My OV-1 LED never leaves my pocket. Which is exactly where my wife recently found it when she pulled a pair of my pants out of the dryer! Needless to say, my trustworthy handheld LED works flawlessly even after a trip through the washer
and dryer.”—Mike, Monterey, CA
Tip-Off Filters
NEW
OV-1
Desert Sand
CUSTOM LOGO SERVICE ON ORDERS OF 100 OR MORE!
BORELIGHTS
MBS-AA
•
MBS-1WE
LDI Patent No. 6,295,753
NEW
MBS-AA
with Green
Laser
LASER SPECIFICATIONS
Type: Visible Pointers Laser Class IIIa Power Output: <5mW Wavelength: Visible Red Pointer 635nm Visible Green Pointer 535nm Full Angle Beam Divergence:
Visible Red Pointer 0.3 mrad Visible Green Pointer 0.5 mrad Range/Visibility*:
Vis Green Pointer (Night / Day) 2000 meters / 60 meters Vis Red Pointer (Night / Day) 500 meters / 30 meters Battery:
MBS-1WE One 3-volt 123A Lithium MBS-AA One 1.5-volt AA Battery Life:
MBS-1WE Up to 24 hours continuous MBS-AA 10 hours continuous
MECHANICAL SPECIFICATIONS
Limited Warranty: 1 Year Material: Anodized aircraft aluminum 6061T-6 Weight (with battery):
MBS-1WE 4.8 oz. / 135 grams MBS-AA (with borerod) 5.4 oz. / 153.1 grams Length: (with long bore rod)
MBS-1WE 9.7 in. / 24.5 cm MBS-AA 9.25 in. / 23.5 cm Environment:
MBS-1WE Water resistant MBS-AA Waterproof to 3 meters
Specifications may change without notice. Range may vary depending on light conditions.
Overall Features include
► Precision stainless steel bore rod for pin-point alignment
► Specially formulated plastic inserts protect barrel rifling from contact with bore rod to preserve weapon accuracy ► Aligns any type of weapon sight—
including devices not located directly over the center line of the barrel ► Supplied with
• Inserts to align calibers .22, .223, 5.56mm / .223, 5.56 oversized / 7mm / .30, .308, 30-06, 7.62mm / .38, .357, 9mm / .40, 10mm / .45 / .50
• Battery
► Manufactured in the U.S.A.
MBS-AA Features include
► NSN #4933-01-564-2609
► External adjustment knobs offer the abil-ity to true borelight for precise accuracy ► Rotary switch offers ON/OFF and low
power mode for low light conditions ► Optional metal spring insert available
in 5.56
MBS-1WE Features include
► External adjustment knobs offer the ability to true borelight for precise accuracy
► Built-in, twist-on and twist-off switches ► Supplied with interchangeable bore rod
assemblies. Includes short bore rod for pistols and long bore rod for rifles.
16
[email protected]
Q
uality engineered for a flawlessly
centered dot every time, our
MIL-SPEC borelights allow users to
quickly perform a precise, accurate
alignment check without ever test
firing their weapon. Choice of red or
green visible laser—the brightest
visible lasers allowed by law.
Our new GREEN Ultra Power
Point
TMlaser is designed to improve
range and visibility in daylight and
at night. The green laser offers faster
target acquisition and is TWENTY
times more visible than our
tradition-al red Super Power Point
TMlaser.
Precision machined from aircraft
grade aluminum for reliable
perfor-mance under harsh environmental
conditions.
MBS-AA
• For rifles and submachine guns
• Equipped with external adjustment
knobs for precise accuracy
• Choice of Red or Green visible laser
MBS-1WE
• For rifles and pistols
• Protected adjusters true the device
• Choice of Red or Green visible laser
MBS-1WE
Laser Borelight shown with OP-6 Light, p. 14
LASERBLASTER-Z
DRY FIRE LASER
•
MARKSMANSHIP TRAINING
Available for: 38, 357, 9mm, 10mm, 40, 44 and 45 cal.
Custom configurations available for: FATS, AIS, LaserShot and MPRI/Beamhit Electronic Targets or Training Systems
LASER SPECIFICATIONS
Type: Visible Pointer Laser Class IIIa Power Output: <5mW
Wavelength: 650nm
Full Angle Beam Divergence: 0.3 mrad Range/Visibility*: 30 meters Day Battery: LDI Part #71105 Battery Life: Over 5,000 shots
MECHANICAL SPECIFICATIONS
Limited Warranty: 1 Year Material: Anodized aircraft aluminum 6061T-6 Weight (with battery): .4 oz. / 11.3 grams Size: Length 2.8 in. x Diameter .35 Length 7.0 cm x Diameter .9 cm Environment: Water resistant
Specifications may change without notice.
*Range may vary depending on light conditions.
O
ver 5,000
DRY FIRE LASER SHOTS
PER BATTERY!
FEATURES INCLUDE
► Over 5000 laser shots per battery ► Improves marksmanship,
point-and-shoot and fast draw techniques ► Encourages practice with standard
duty weapon
► Compatible with most law enforcement firearms holsters
► Accur-Aim Target (sold separately) makes it easy to practice in bright sunlight
► Manufactured in the U.S.A.
T
he LaserBlaster-Z provides the ultimate way to improve gun handling
tech-niques and targeting skills without firing a single round of ammunition.
This state-of-the-art marksmanship training device allows users to
prac-tice dry-firing with the maximum level of safety. When you aim and dry fire
your weapon at a target, LaserBlaster-Z emits a bright red laser point that
simulates where an actual bullet would impact on the target.
Recommended by a number of firearms instructors and law enforcement
professionals, the LaserBlaster-Z is a safe and easy-to-use way to maximize
your shooting skills.
Laser Devices can custom manufacture laser transmitters to work with a
variety of commercial and law enforcement training systems. Please contact
us for more information.
“
LaserBlaster can prove to be a valuable training tool.
The student can see the result and make the necessary corrections immediately. This translates to more effective training time on the range and better overall firearm proficiency levels.”
—Chris Shepard Specialized Weapons Training Instructor James River Training Site
LaserBlaster-Z
Deluxe Master Set
18
SHOT TRACKER
MIL-SPEC TRACKING MODULE
Patent Pending
H
OW MANY SHOTS
HAVE BEEN FIRED?
Preventive weapon maintenance is
vital to the safety and welfare of our
military and law enforcement
person-nel. The NEW SHOT TRACKER enables
maintenance personal to quickly and
easily monitor weapon use and set
parameters for the replacement of
key components.
The SHOT TRACKER module is
designed to record the number of
shots fired through a weapon. It also
monitors user defined parameters
including weapon issuance, user
performance, general rate of fire and
accessories assigned to the weapon.
An active RFID circuit transmits the
data to a receiver and a basic
soft-ware package collects the data which
can be exported to your PC and
stored in a database file, spreadsheet
or user developed application.
The SHOT TRACKER module can be
purchased individually, in sets or in
the following packages:
STARTER PACK
• One SHOT TRACKER module
• Programming Unit / Reader
• Software Package
ADVANCED PACK
• One SHOT TRACKER module
• Programming Unit / Reader
• Software Package
• Handheld Data Terminal
• Wireless Reader
NEW
MEETS MIL-STD-810F FOR ADVERSE ENVIRONMENTAL CONDITIONS
FEATURES
►Tracks and monitors the following
for the life of the firearm • Rounds fired
• General rate of fire
• Serial numbers of accessories assigned to the weapon—optics, nightvision, thermal and more
• Replacement of key components
►Reliable and cost effective
►Factory configured to your specifications—
Works with 22 caliber firearms to 40mm grenade launchers
►Improves shooting performance at all
operator levels
►Mounts to any MIL-STD-1913 rail ►Active RFID readable—No wires required ►Manufactured in the U.S.A.
SHOT TRAcker
MECHANICAL SPECIFICATIONS
Limited Warranty: 2 Years Material: Anodized aircraft aluminum 6061T-6 Data Storage Capacity: up to 65,000 rounds Weight: 1.1 oz. / 31.2 grams Size: L 2.4 in. x W 1.0 in. x H .0625 in. L 6.1 cm x W 2.5 cm x H .2 cm Battery Life (non-replacable): 4 years Environment: Waterproof to 20 meters
Specifications may change without notice.
TM
NEW
SHOT TRACKER
Module
[email protected]
SHOT TRACKER MODULE
Software Package
( Windows
® compatible)• Reads data from Programming Unit, Handheld Data Terminal or Wireless Reader • Correlates data for export to database file, spreadsheet or user developed application • Records user defined tracking data (e.g. weapon and accessory serial numbers) to the
SHOT TRACKER module
• Capacity to reset SHOT TRACKER module to zero
Programming Unit / Reader
• Reads total number of shots fired and shots fired per minute from a single
SHOT TRACKER module from 3”
• Records user defined tracking data like weapon and accessory serial numbers to the SHOT TRACKER module
• Capacity to reset SHOT TRACKER module to zero
Handheld Data Terminal
• Reads data from a single SHOT TRACKER module from 10” • Reads total number of shots fired
Wireless Reader
• Reads data simultaneously from multiple SHOT TRACKERS from 40’
• Reads total number of shots fired and shots fired per minute
Taking the guesswork out
of weapons maintenance is crucial to the safety and welfare of our military and law enforcement personnel. Improving reliability through better maintenance could literally spell the difference between life or death for combatants in the line of fire.
Software Package
(monitor sold separately)
Programming
Unit / Reader
Wireless
Reader
Handheld
Data
Terminal
ACCESSORIES
20
O
ur full line of weapon mounts will attach to virtu-ally any commercial and military firearm. We also supply a variety of tailcap switches for our OPERATOR lights and LAS/TAC lasers.tip-off Filters
► Flip-top cap provides instant access
to white light or filtered light
► Security latch ensures tight closure
and prevents white light exposure
► Protects tactical light lens ► Full-size filters: red, blue, infrared ► Compact filters: red, blue, green,
infrared
► Infrared filters (incandescent lights
only) block 100% of visible wave-length—eliminates faint, red glow
Rail & Ring Mounts
► Machined from aircraft grade
aluminum
► Hard black anodized to MIL-A 8625F ► Black oxide coated steel mounting
screws resist stripping
► All MIL-SPEC-1913 rails meet
military specifications
tailcap Switches & Lamp Assemblies
► Interchangeable tailcap switches allow our
OPERATOR lights and LAS/TAC lasers to be configured as either a handheld or weapon-mounted device
► Patented, shock absorbing incandescent
lamp assemblies allow our tactical lights to be mounted on rifles, pistols, submachine guns and shotguns
► LED assemblies provide 150 lumens
of blinding, white light—over 30 times brighter than a standard LED
Target • Glasses • batteries
► Accur-Aim Target makes it easy to practice
in bright sunlight at 100 yards
► Laser viewing glasses improve laser point
visibility in daylight
► Large selection of quality batteries for our
entire product line
Other accessories include colored and infrared tip-off filters; the Accur-Aim™ target which significantly improves
visibility of the laser point on the target in daylight; daytime laser viewing glasses; and batteries.
HOLSTERS & POUCHES
Features include
► Name brand manufacturers—
Safariland, Bianchi, Gould & Goodrich
► Fits a wide variety of popular military
and law enforcement style weapons
► Available in nylon and hard-shell ► Tactical thigh rigs available
► Safariland holsters available with dual
retention
► Bianchi Cobra series offers popular
military retention belt and tactical thigh holsters that can expand to fit even the largest weapon mounted lights and lasers
