Setup & Configuration Guide

138  Download (0)

Full text

(1)

Secure Web Gateway

Setup &

Configuration Guide

(2)

M86 S

ECURITY

S

ETUP

AND

C

ONFIGURATION

-G

UIDE

© 2010 M86 Security All rights reserved.

828 W. Taft Ave., Orange, CA 92865, USA

Version 1.01, published November 2010 for SWG software release 10.0

This document may not, in whole or in part, be copied, photo-copied, reproduced, translated, or reduced to any electronic medium or machine readable form without prior written con-sent from M86 Security.

Every effort has been made to ensure the accuracy of this document. However, M86 Security makes no warranties with respect to this documentation and disclaims any implied war-ranties of merchantability and fitness for a particular purpose. M86 Security shall not be liable for any error or for incidental or consequential damages in connection with the furnishing, performance, or use of this manual or the examples herein. Due to future enhancements and modifications of this product, the information described in this documentation is subject to change without notice.

Trademarks

(3)

CONTENTS

CONTENTS . . . .iii

M86 OVERVIEW. . . 1

ABOUT THIS MANUAL . . . 3

M86 SECURITY APPLIANCES . . . 5

SWG APPLIANCE SERIES 7000- SWG . . . 5

7000-SWG Front Panel . . . 7

7000-SWG Rear Panel . . . 8

Advanced Management Module . . . 9

7000-SWG Hardware Specifications . . . 10 SWG APPLIANCE SERIES 5000- SWG . . . 12 5000-SWG Front Panel . . . 13 5000-SWG Rear Panel . . . 14 5000-SWG Hardware Specifications . . . 15 SWG APPLIANCE SERIES 3000 - SWG. . . 17 3000-SWG S1 Front Panel . . . 18 3000-SWG Rear Panel . . . 19 3000-SWG Hardware Specifications . . . 20

CONFIGURING THE SWG APPLIANCE . . . 21

MANAGEMENT CONSOLE SYSTEM REQUIREMENTS . . . 22

Operating Systems . . . 22

Software Requirements . . . 22

CONNECTING YOUR SWG APPLIANCE . . . 23

Limited Shell Connection Procedure . . . 23

Using an Ethernet Cable . . . 23

Using a Serial Cable . . . 26

Initial Setup of your SWG Appliance using Limited Shell. . . 28

Initial Setup . . . 29

Running the Setup . . . 29

LIMITED SHELL COMMANDS . . . 44

LIMITED SHELL CONFIGURATION COMMANDS . . . 48

access_list . . . 48

change_password . . . 49

(4)

config_time. . . 58 config_psweb . . . 59 config_exclude . . . 59 config_bridge . . . 59 disable . . . 60 disable_service_snmpd . . . 60 disable_service_ssh. . . 60 enable . . . 61 enable_service_snmpd . . . 61 enable_service_ssh . . . 62 ethconf . . . 62 flush_dnscache . . . 64 reset_config . . . 64

LIMITED SHELL MONITORING COMMANDS . . . 65

arp . . . 65 df . . . 65 ifconfig . . . 67 ip2name . . . 68 iptraf . . . 69 last . . . 70 name2ip . . . 71 netstat . . . 71 ping . . . 73 poweroff . . . 73 reboot. . . 73 restart_role. . . 74 save_support_logs. . . 74 setup . . . 74 show. . . 75 show_config . . . 75 show_network . . . 76 show_dbsize . . . 80 show_route . . . 80 show_time . . . 81 supersh . . . 81 tcpdump . . . 81 top . . . 82 traceroute. . . 83 uptime . . . 84 vmstat . . . 85 w . . . 85 wget . . . 85

(5)

Configuring the Firewall for Automatic Updates. . . 90

Offline Updates . . . 91

ROUTING TRAFFIC THROUGH THE APPLIANCE . . . 92

Configuring Workstations: Routing Traffic through Appliance . . . 92

Transparent Proxy . . . 93

WORKING WITH HTTP . . . 95

HTTP Proxies. . . 95

Working with Caching Proxies . . . 95

Downstream. . . 95

Upstream . . . 96

HTTP Authentication . . . 97

WORKING WITH ICAP. . . 98

Why work with ICAP? . . . 98

Secure Web Gateway as an ICAP Server . . . 98

REQMOD – RESPMOD Deployment . . . 100

ICAP Clients. . . 100

CONFIGURING ICAP CLIENTS. . . 101

NETWORK APPLIANCE NETCACHE SERIES (NETAPP). . . 101

BLUE COAT. . . 108

APPENDIX: INSTALLATION DETAILS. . . 121

INSTALLING YOUR SECURE WEB GATEWAY APPLIANCE . . . 121

Remote Installation on 7000-SWG . . . 125

Post-Installation Bonding Script on 7000- SWG . . . 132

POST-INSTALLATION SYSTEM HARDENING . . . 133

System Hardening . . . 133

Policy Server . . . 133

Management Access List. . . 133

Management Console Password . . . 135

Default SNMP v2 Community String . . . 135

Scanning Servers. . . 136

Proxy IP Address . . . 136

Management Access List. . . 137

Nortel Switches (Applicable only to 7000- SWG Series) . . . 138

Defaults SNMP Community String. . . 138

Telnet and HTTP Access to the Switch . . . 138
