Course 361

(2)

2

3 Objectives

In this lab, you’ll learn how to protect a Linux machine using EDPM. This portion is going to being using the EVault Agent as opposed to the Microsoft DPM Agent. The same installation process is used to install the VMWare ESX Agent.

Scenario

The first thing we’ll do is install the Agent. From there, we’ll use the EVault Console on the EDPM appliance to configure it. Next we’ll run a backup and then restore the data to an alternate location.

Estimated Time to

Complete This Lab

60 Minutes

Requirements for

This Lab

• Linux Server is on the same subnet as the EDPM appliance.

• The Linux Server must have inbound TCP ports open on 8086 and 8087 • For backups to occur data is transmitted from the Agent to the EDPM

(4)

4 Exercise 1 – Installing EVault Linux Agent on Linux Server

In the next steps, we’ll be installing the Linux Agent onto our Linux server. This will involve mounting a folder that’s currently shared on our EDPM server, copying the installer, unpacking it, and installing the Agent.

Tasks Detailed Steps

1. Initial Login

LINUX01

a. Once the environments states Available within Surgient, click the drop-down next to Linux_Server and choose VNC.

b. If the browser prompts you to download any ActiveX controls, please go ahead and do so.

c. You’ll see a prompt for a VNC Password type evault.

d. You should now see the desktop. If you just see a black screen, move your mouse around some.

e. In this example, we do have a graphical desktop (GNOME). However, I’ll have you conduct the exercises via command-line as not all Linux environments are configured with a graphical desktop.

f. To open a new command-line terminal, right-click anywhere on the Desktop and choose Open Terminal.

2. Mounting the Linux Share

a. In the next steps, you will need to know the IP address of your EDPM server and the local Administrator credentials. Our EDPM server is on

192.168.0.100. It has local login credentials of administrator/password. b. To mount our share, it will be in the following syntax. Note the Linux/UNIX

is case sensitive:

• mount –o username=<local_administrator>,password=<administrator_password> //<EDPMs_IP_Address>/<Sharename> <Local_Mount_Directory>

c. Notice that there is no space between “,” and “password”. d. The command will type is the following:

• mount –o username=administrator,password=password //192.168.0.100/EVaultAgents

/mnt

e. This should complete without any errors. If there are errors, you’ve typed in something incorrectly.

3. Copy Linux Agent Locally and Unpack It

a. Navigate to the directory that we’ve mounted. • cd /mnt

b. Verify that you’ve correctly mounted the directory. • ls –la

c. This will display the contents of the directory, and several subdirectories. For instance, Unix, Novell, etc.

d. We’ll navigate to the to the Linux Agent directory. • cd Unix/Linux

e. Now, we’ll copy the Linux Agent installer locally to our Linux server. • cp Agent-Linux.tar.gz /root

f. Navigate to the directory that we’ve copied the installer • cd /root

g. The installer file is a compressed file. It’s been tarballed and gzipped. The file must be unpacked.

• tar xfz Agent-Linux.tar.gz

(5)

5

• You should see that a new directory has been created called

Agent-WCC-Linux-6.00.2415.

i. Navigate to the newly created directory. • cd Agent-WCC-Linux-6.00.2415

4. Install Linux Agent

a. In the next steps, we’ll go ahead and install and register our Linux Agent to the EDPM appliance.

b. In the directory that was created Agent-WCC-Linux.6.00.2415, there is an install script and this is what we’ll run.

• ./install.sh

c. The Agent will install by default into /usr/local/BUAgent. Click Enter. d. The installer will indicate that the directory doesn’t exist. Click Enter to

create it.

e. The default language is English (US). Click Enter to accept this.

f. The installer will prompt “Do you wish to register to a Web-based Agent

Console Server?” Click Enter.

g. When prompted “What is the Web-based Agent Console address?”, we’ll need to enter the address of our EDPM appliance.

• 192.168.0.100

h. When prompted “What is the Web-based Agent Console connection port?”, it defaults to Port 8086. Just click Enter to accept the defaults.

i. When prompted “What is your Web-based Agent Console username?”, the EDPM appliance comes with a default user.

• Type user and click Enter.

j. When prompted for “What is your Web-based Agent Console password?”, we need to enter the same password we configured when initially

configuring the EVault Console (See Course 101: Initial Setup: The Onboarding Wizard).

• Type I365password and click Enter.

k. The Agent should now be installed and ready to configure on the EDPM appliance.

For access to the Web-based Agent Console, both TCP ports 8086

and 8087 must be available. If there are firewalls in place in

between the Agent and the EDPM appliance, these ports need to

be opened for inbound connections to the Agent machine. In

(6)

6 Exercise 2 – Configure Linux Agent for Protection on EDPM Appliance

In the next steps, we’ll be configuring our Agent for backup and also schedule it. This is completed on the EDPM appliance through the EVault Console.

1. Switch Machines

EDPM

a. Using the Server drop-down at the top of the Surgient window, choose

EDPM_Server to connect to the EDPM server.

b. If it prompts you for a login, please make sure to use the following: • Username: TrainingLab\Administrator

• Password: I365password

2. Open EVault Console

a. Open Internet Explorer from either the Start Menu or Quick Launch bar. b. In the Address Bar, type the following

• http://localhost/EVaultConsole/login.aspx

c. This should launch the EVault Console landing page. 3. Configure

Agent

a. Within the EVault Conosle site, we should see our Linux01 server highlighted in the middle pane. EDPM has detected that it has not yet been configured yet.

b. Click Configure This Agent.

c. On the Configure Agent screen, you’ll see Description. This field is optional and it allows you to describe your Agent, IE “Backup of Boss’ Computer.” We’ll leave this field empty in this example.

d. Click Advanced Agent Settings.

• On the Retention Types tab, we see the default retentions that can be used. Retentions dictate how far back in time you can restore your data. We’ll leave the default for now, but please reference the course titled Understanding EVault Retentions for more information about retention customization.

• On the Open File tab, you will have no options for the Linux Agent as there is no need for an open file handler.

• On the Notification tab, we will setup email notifications. In this lab, we’ll use some fictitious information, but on your production machines, you’ll want to make sure that you fill this out correctly.

i. Click Send e-mail on failure

Default Retentions allow you protect and restore from the following if scheduled:

Daily – Restore from the last 7 days

Weekly – Restore from the last 5 Saturdays

Monthly – Restore from the last 12 first of the months going back 1

year.

(7)

7

has problems processing a file.

iii. For the E-Mail “From” address, enter [email protected] iv. For the Outgoing mail server, enter mail.acme.com.

v. For the Specify address(es) of recipients, enter

[email protected].

vi. If your email server required an authenticated account, you will fill that out in the SMTP Credentials if required. In this lab, we’ll leave it Blank.

• On the Performance tab, you have options to change the following. However, we’ll use the defaults:

i. Execution Priority – Allows you to change the CPU priority of

your backup jobs.

ii. Bandwidth – Allows you to potentially throttle bandwidth of

backups during production hours.

• At the bottom of the Agent Settings window, click OK to accept the changes we’ve made.

e. Back on the Configure Agent window and the Agent Configuration section, click Next >.

f. On the Source Selection section:

• For the Protection Set Name, type Data. • For the Description, leave this blank.

• For the Source Type, we’ll use Local System. The EVault Agent supports backups via NFS mounts if you had this type of environment • Click Next >.

g. On the Selection section:

• You’re now browsing the file system of our Linux01 server, you see files and folders under Volume and what you selected for protection under Recovery Set.

• In this example, we’ll backup something small. (/etc) • Expand / and click the box next to etc.

• Select Include…

i. Recursively – Backups all subdirectories and files. Leave this

(8)

8

Checked.

ii. Only folders matching this filter – Allows for folder or file

wildcard selections.

iii. Only files matching this filter – Allows for filtering of files

based on extension. iv. Click OK.

• Click Next >. h. On the Options section:

• This is where you can choose to protect your data by password protecting it. If you’ve set a password, upon recovery, you will be prompted for this password.

• In this example, for the Encryption type, please select AES 128 bit. • For the password, we’ll set the Password and Confirm Password to

test.

• For the password, we’ll type something that reminds us of “test.” Type

quiz.

• Click Next >. i. On the Schedule section:

• This is where we can define a schedule such that our backups will run on automatic basis. Please refer to the course titled Scheduling

Backups with EVault for more detailed information.

• In this example, we’ll schedule the following: i. Daily – M – F – 8PM

ii. Weekly – Sat – 8PM

iii. Monthly – 1st – 8PM

• Per Best Practices, we’ll schedule the Longest retention first so that it is at the Top. Longest retention in this case being Monthly. You can always reorder them in this list if you had done it wrong.

• For the Monthly, click Add

Any encryption change after the initial backup will result in a

reseed of data. This means you will be storing double the amount

of data than you should be on the EDPM appliance. Encryption changes include:

• Changing encryption types • Changing encryption passwords • Changing encryption types

• Change from no encryption to use encryption or vice versa

Please make sure to keep your encryption password in a safe place. If you lose your encryption password, i365 will not be able

(9)

9

month.

iii. In the At field, type 8:00.

iv. In the Retention Scheme drop-down, choose Monthly. v. Advanced Schedule Options allows us to change the

compression level and backup time window. We’ll use the defaults here though.

vi. Click OK.

• For the Weekly, click Add i. Select Sat.

ii. For the At field, type 8:00.

iii. In the Retention Scheme drop-down, choose Weekly. iv. Click OK.

• For the Daily, click Add

i. Select each Mon, Tue, Wed, Thu, Fri. ii. For the At field, type 8:00

iii. In the Retention Scheme drop-down, leave the default with

Daily.

iv. Click OK.

• You’ve now completed creating the schedule. Click Next >.

j. A new pop window, Register Agent, will appear. This will attempt to register the Agent to the EDPM Appliance. Click OK.

k. On the Destination section, you should see an entry for Appliance and your EDPM appliance’s network address. Click Finish.

l. Your Linux Agent is now configured for backup and will run automatically based on its schedule that you had defined.

(10)

10 Exercise 3 – Performing an Ad Hoc Backup

In this section, you’ll learn how to run a manual (ad hoc) backup. Normally you’d wait for your schedule backup to run. Running an Ad Hoc backup in the middle of the day can impact network and system

performance of a production Agent machine.

1. Continued work on same machine

EDPM

a. For this exercise, we’ll continue work on the EDPM appliance.

b. You should still have the EVault Console open. If not, you call always access it via a browser on that machine. Address is

http://localhost/EVaultAgents/login.aspx.

2. Backup Job via Protect Now

a. In the EVault Console, your Linux01 Agent should be highlighted in the middle of the screen.

b. Down at the bottom pane, we see the Protection Set Data that we created earlier. Make sure to highlight this Protection Set.

c. To run an Ad Hoc backup, click Protect Now. d. On the Protect Now screen

a. Our Destination is Appliance. b. Our Retention Scheme is Daily.

c. Advanced Protection Options allows you to change the backup

window for your Ad Hoc backup. d. Click Start.

e. Your backup should initiate.

f. A new window, Process Details, should appear. Wait until the backup’s

Status says Completed and click Close.

g. Note that when the backup completes, you will see a message that states that the “Recovery pointed created with errors.” If we were to look at the logs, you would see that the Agent is having problems connecting to the base Vault (the Cloud). With version 1 of EDPM, your EDPM appliance will not replicate to the Cloud, and this is an expected error.

In production, you don’t have to leave the Process Details window open. You can click Close at any time, and the backup will continue in the background.

(11)

11 Exercise 4 – Recovering Data with EVault

In the next steps, we’ll use the EVault to recover the sample data that we had previously protected. In this example, we’ll restore the data to a new directory.

1. Continued work on same machine

EDPM

a. For this exercise, we’ll continue work on the EDPM appliance.

b. You should still have the EVault Console open. If not, you call always access it via a browser on that machine. Address is

http://localhost/EVaultAgents/login.aspx.

2. Recover Data via Recover Now

a. In the EVault Console, your Linux01 Agent should be highlighted in the middle of the screen.

b. Down at the bottom pane, we see the Protection Set Data that we created earlier. Make sure to highlight this Protection Set.

c. To run recover data from this protection set, click Recover Now. d. On the Recovery screen

a. For Select a recovery point, we’ll leave the default. The Agent will automatically select the most resent recovery point. Otherwise, you could pick and choose the specific date/time you wished to recover from.

b. For Select a recovery device section

i. Recover from this device, choose Vault (Appliance).

ii. Encryption password and Confirm password, type test. This

is what we had configured the job with. c. Click Next >.

e. On the Data Selection screen

a. Under Volume, we’re looking at the Recovery Point and the data that was backed up.

b. Expand the Recovery Point and expand “/”. c. Check off the etc folder and select Include…

d. On the Include Options screen, leave the defaults and choose OK. e. Choose Next >

f. On the Options screen

a. For Destination, choose Recover to an alternate location and type

/restore. /restore does not exist and the Agent will automatically

create it. You could restore to the original location, but for this lab we’re restoring to an alternate path.

b. Preserve folder structure – Will nest the original path under

whatever path you’ve chosen to restore to. Otherwise, any files selected will get recovered to the root of the directory you had chosen.

c. File Overwrite – Leave the defaults. You can change these options if

there are files in the destination directory already, and this option allows you how recovery will rename or overwrite files.

(12)

12

Restore Completed and click Close.

Exercise 5 – For this Lab Only – Check that the Data has been Recovered

We’ll switch back to the Linux01 server and check that the data has indeed been restored.

1. Switch Machines

LINUX01

a. Using the Server drop-down at the top of the Surgient window, choose

Linux_Server to connect back to the Linux01 server.

b. You’ll see a prompt for a VNC Password type evault. c. The Terminal window should still be open. Type cd /restore d. To see the contents of that directory, type ls –la

e. You should see the etc subdirectory. f. Type cd etc and then ls –la.

g. You should now see the contents of the directory that we’ve restored.

Conclusion

Hopefully you have a better understanding of how to protect Linux and UNIX using EVault. Please feel free to do further testing in your training lab. For further information regarding EVault, you can always access the EVault Knowledge Base and various user guides at http://csp.evault.com. For further information about DPM, you can always access their Technet site at http://technet.microsoft.com/en-us/library/ff399192.aspx. If this link is broken, goto http://technet.microsoft.com , navigate to Library, System Center, and choose System Center Data Protection Manager 2010.

EVault for Data Protection Manager. Course 361 Protecting Linux and UNIX with EVault

Course 361

2

Table of Contents

3

Objectives

Scenario

Estimated Time to

Complete This Lab

Requirements for

This Lab

4

Exercise 1 – Installing EVault Linux Agent on Linux Server

5

6

Exercise 2 – Configure Linux Agent for Protection on EDPM Appliance

7

8

9

10

Exercise 3 – Performing an Ad Hoc Backup

11

Exercise 4 – Recovering Data with EVault

12

Exercise 5 – For this Lab Only – Check that the Data has been Recovered

Conclusion
