TV. Internet. SmartTV

The best entertainment from both worlds

Discover

the future of television with TRIAX.

No matter what your existing home cinema looks like – with Triax you will

embark on a new TV future. The combination of classic television and

internet-based interactive services will thrill you.

You will not only expand the television offers of your TV, but it will also be

possible for you to feed television programmes into your home network and

distribute them to PCs, tablets, smartphones and other mobile units.

Discover the best entertainment from both worlds.

Satellite TV for smartphones, tablets etc.

04 - 09

SAT>IP server and receiver

Interactive options for your TV

08 - 09

Triax SmartTV-portal

SmartTV receiver for satellite and cable

10 - 15

S-150 Hybrid | S-HD 990 Hybrid |

C-150 Hybrid

SmartTV-upgrades for TV

16- 17

IP-100

TV broadcast via power supply lines

18 - 19

HDMI via PowerLine

Contents

Satellite TV for smartphones, tablets etc.

The new SAT>IP products from Triax makes it possible to distribute satellite TV over cable connected (LAN, Power LAN) or cableless networks (WLAN). SAT>IP-compatible units such as TV sets, receivers, PCs,

smartphones, tablets and other mobile

SAT>IP compatible devices

„ Up to 4 units can access different

TV programmes at the same time

„ Compatible with all SAT > IP-

compatible units such as

; SAT>IP receiver

; Tablets and smartphones

; PCs and laptops

units can thus be provided with all free available TV and radio programmes. Thanks to the web-based configura-tor the products are easily set up and controlled.

Features of SAT>IP

„ Reception of all free available TV

and radio programmes via satellite

„ SAT-distribution via cable

connected and cableless networks

„ Digital picture and audio quality –

even in high-resolution HD-format

„ All digital additional options such as

EPG, recording function and time shift can be used in the unit*

*provided the unit supports the function

Easy set-up

„ Supports Quad- and Quattro-LNBs,

optical LNBs with converter and Unicable-LNBs

„ Easy installation and control via the

web-based configurator

„ Software update by USB

„ Compatible with 100/1.000 -

Megbit networks Broadcast satellite TV live in home networks

Router for cable connected (LAN) and cableless (WLAN) networks

SAT dish with Quad- or Quattro-LNB Mobile unit

via cableless network (WLAN)

Network cable Coaxial cable

Application in practice: SAT > IP receiver and server

TV set with SAT > IP receiver via cable network (LAN)

Picturequality

HD

Converts SAT-IF signals to IPTV signals

TRIAX TSS 400 SAT>IP server receives classic SAT signals, converts them and distributes them to up to four different units in the IP network. The SAT signals can be fed via Quad- or Quattro-LNBs.

Optical LNBs with converter or Unicable-LNBs are also supported. The SAT>IP server is easily set up and controlled by means of the web-based configurator.

Features

„ Converts SAT into IPTV signals

„ Supports many LNB types

„ Easy installation and control by me-ans of the web-based configurator

„ Up to 4 units can access TV pro-grammes at the same time

„ Compatible with all SAT>IP compa-tible units

„ Software update by USB

„ Compatible with 100/1.000-Megabit networks

Converts SAT-ZF signals to IPTV signals

Connections

TSS 400

4x DVB-S2 1xÊUSBÊ2.0 Ethernet network Unicable capable Energy savingeco TM Version 1.1

1

2

3

4

5

1

2

3

4

5

F-connectors for LNB input USB 2.0 interface

Network interface

Reset button

TSS 400

Tuner

DVB-S | DVB-S2 (HDTV) • | •

Number of tuners (different units)) 4

Supported LNBs

Quad-LNB •

Quattro-LNB •

Unicable LNB •

Optical LNB with converter •

Equipment / Service

Plug & Play •

Unicable capable •

Updates via the Web configurator | via USB interface • | •

Supported protocols

SAT>IP protocol version 1.1 •

Unicast via HTTP 1.0/1.1 | Multicast via UDP/RTP • | •

Connections

DVB-S/S2 Eingang 4x F-Buchse

Ethernet-interface (100/1000 Megabit) •

USB-interface for software update • (USB 2.0)

Allgemeine Daten Colour White Dimensions (W x H x D mm) 250 x 126 x 35 Weight (kg) 0,75 Power switch • Ambient temperature (°C) 0 ... +40 Delivery

Converter | Power Supply | Quick Start Guide • | • | •

Order information

Article number 310 101

EAN 5702663101012

SAT>IP enjoyed on the TV

The TRIAX IP-100 SAT>IP receiver makes it possible to display SAT>IP signals on the TV and thereby offer access to all free available TV and radio programmes in the home network. Additional features like EPG, video text and subtitles ensure you the full benefit

of TV watching, and the possibility to record programmes on external storage media makes the picture complete. Thanks to the Android 2.2 OS many different apps can be played on the unit and make this receiver a true allrounder.

Display of SAT>IP signals etc. on the TV

Features

„ Display of SAT>IP signals on the TV

„ Recording function on external storage media such as USB can be upgraded by software update..

„ 14 days electronic program guide (EPG).

„ Videotext and subtitles.

„ Mediaplayer for access to photos, music and films via the home network (UpnP) or USB.

IP-100

Version 1.1 Picturequality

HD

eco

Many additional functions Are available with this receiver:

„ Internet-based additional services via HbbTV

„ TRIAX SmartTV portal with many apps

„ Free internet browsing for display of websites on the TV

„ Access to many broadcasts from the past 7 days via the media libraries of the program providers

Small. Compact. Energy-saving and simple installation:

„ Plug-and-Play installation assistant

„ HDMI interface for modern TV sets

„ Software update via USB interface

„ Network connection and WLAN-ready (via USB stick)

„ Compatible with 100/1.000 megabit networks

Tuner

SAT>IP •

Equipment/Operation

Plug & Play Installation assistant •

Menu languages 10

Updates via USB interface •

SmartTV (internet-based additional services)

TRIAX SmartTV portal •

HbbTV | Media libraries | adv. Videotext | adv. EPG • | • | • | •

Free internet browsing •

Recording and playback

Recording and playback function via USB Update via software

Mediaplayer USB | UPnP | dlna • | • | -

Connections

HDMI output |component output (YUV) • |

-Scart output | Cinch output - | •

Audio output cinch |coaxial | optical • | |

-Ethernet interface | WLAN ready • | •

USB 2.0 interface • (3x) General data Article number 305 250 EAN 5702663052727 Colour black Dimensions (W x H x D mm) 145 x 30 x 100 Weight (kg) 0,5

Power consumption max | Stand-by (W) 5 | < 1

Power supply •

Ambient temperature (°C) +5 ... +50

Scope of delivery

Remote control | Batteries | Operation manual • | 2x AAA | •

A selection of our Partner

Interactive TV-features

With the new SmartTV receivers from TRIAX you will find a quite new inter-net world on your TV. Simply connect the receiver to the internet, press the „TV Portal“ button on the remote con-trol and so it begins – quite simply and without auxiliary equipment. In the new

TRIAX SmartTV portal you have access to a vast variety of apps within news, sports, entertainment and services. Al-ready now you will find more than 100 internet-based applications optimised for TV, and more are added each day.

Discover the Internet world – simply and without auxiliary equipment

... and many more!

Bild.de

News and background information from the BILD newsdesk

Kicker

1xÊDVB-S2 Picturequality

HD

ready

S-150 Hybrid

Internet meets satellite TV

TRIAX Smart TV receiver S-150 hybrid is the ideal entry-level equipment for connection of classic satellite TV and internet. It allows access to the broadcasters’ additional internet-based facilities and interactive services like for instance media libraries, newscasts,

Maximal programme variety and simple operation makes TV watching a real pleasure:

„ Reception of all free HD and SD programmes via satellite (DVB-S/S2)

„ 4.000 programme places for TV and radio

„ Quick-Videotext

„ USB-interface for external data car-rier, recording (PVR ready) can be upgraded by software update

weather, videotext and advanced EPG. Moreover, TRIAX SmartTV portal can be activated with different apps like Bild. de, Facebook, pulpat and many others.

Many additional functions are available with this new receiver:

„ internet-based extra services via HbbTV

„ TRIAX SmartTV portal with numerous apps

„ Access to many broadcasts from the past 7 days via the media librari-es of the program providers

„ Mediaplayer for access to photos, music and films over the home network (UPnP) or USB

Small. Compact. Energy-saving and simple installation:

„ Plug-and-Play installation assistant

„ HDMI-interface with upscale func-tion for modern TV sets

„ Compatible with Unicable systems

„ Software update via satellite or USB interface

„ Network connection and WLAN-ready (via USB stick)

„ Digital audio output

„ Power supply

Tuner

DVB-S | DVB-S2 (HDTV) | Twin-Tuner • | • |

-Input frequency DVB-S/S2 950...2.150 MHZ

Remote feed voltage (DVB-S/S2) 14/18V, 350mA

Equipment/Operation

Plug & Play (pre-programmed) | Installation assistent • | •

Display numerical | alpha numercal • |

-OSD | EPG | Videotext • | • | •

Programme places 4.000

Menu languages 19

Unicable compatible •

Updates via satellite | via USB interface • | •

SmartTV (internet-based additional services)

TRIAX SmartTV portal •

HbbTV | Media libraries | adv. Videotext | adv. EPG • | • | • | •

Recording and playback functions

USB connection for external harddisk • (USB 2.0)

Connections

DVB-S/S2 input/output F-connector | F-connector

HDMI output | component output (YUV) • | •

Scart output •

Audi output cinch | coaxial | optical | • |

-Ethernet interface | W-LAN ready • | •

General data Item No. 305 214 EAN 5702663052147 Colour Black Dmensions WB x H x D mm) 280 x 40 x 160 Weight (kg) 1

Power consumption max | Stand-by (W) 15 | < 1

Power supply •

Ambient temperature (°C) +5 ... +40

Scope of delivery

Remote control | Batteries | Operation manual • | 2x AAA | •

2xÊDVB-S2 Picturequality

HD

S-HD 990 Hybrid

Internet meets Premium satellite TV

TRIAX Smart TV receiver S-HD 990 Hybrid is a premium receiver which combines all the features of the classic satellite TV and internet. It allows access to the broadcasters‘ additional internet-based facilities and interactive services like for instance media

Maximal programme variety

And simple operation makes TV watch-ing a real pleasure:

„ Reception of all free HD and SD programmes via satellite (DVB-S/S2)

„ HD+ ready and Sky ready thanks to CI+ interface

„ Watch one programme, and record another at the same time

„ Time shift TV

„ 4.000 programme place for TV and radio and Quick-Videotext

libraries, newscasts, weather, videotext and advanced EPG. Moreover, films, music and photos can be streamed over the home network to and from the receiver via dlna.

Many Premium functions

„ Internet-based extra services over HbbTV

„ TRIAX SmartTV-Portal with many apps (after software update)

„ Recording on integrated 500 GB harddisk

„ Access to many broadcasts from the past 7 days via the media librari-es of the program providers

„ Mediaplayer for access to photos, music and films over the home network (dlna/UPnP) or USB

Stylish. Elegant. Excellent design. and simple installation:

„ Plug-and-Play installation assistant

„ HDMI-interface with upscale func-tion for modern TV sets

„ Compatible with Unicable systems

„ Software update via satellite or USB interface

„ Network connection and WLAN-ready (via USB stick)

„ Digital audio output

„ Power supply

Energy saving

eco

TM ready HD+ ready Sky Tuner DVB-S | DVB-S2 (HDTV) | Twin-Tuner • | • | • Input frequency DVB-S/S2 950...2.150 MHZ

Remote feed voltage (DVB-S/S2) 14/18V, 350mA

Equipment/Operation

Plug & Play (pre-programmed) | Installation assistant • | •

Display numerical | alpha numerical - | •

OSD | EPG | Videotext • | • | •

Programme places 20.000

Menu languages 10

Unicable compatible •

Updates via satellite |via USB interface • | •

SmartTV (internet-based additional services)

TRIAX SmartTV portal • (after software update)

HbbTV | Media libraries | adv. videotext | adw. EPG • | • | • | •

Recording and playback functions

Integrated 500 GB harddisk •

Decoding systems / PayTV

CI +interface | HD+ ready | Sky ready • | • | •

Connections

DVB-S/S2 input | output 2xFconn. | 2xF-conn.

HDMI-output |Component output (YUV) • | •

Scart-output •

Audio-output cinch | coaxial | optical • | - | •

Ethernet-interface | WLAN ready • | •

General data Article number 940 538 001 EAN 4045824011340 Colour black Dimensions (B x H x D mm) 375 x 60 x 230 Weight (kg) 3,5

Power consumptionmax | Stand-by (W) 6 | < 1

Power supply •

Ambient temperature (°C) +5 ... +40

DVB-C Picturequality

HD

eco

TM

CI+ÊSchnittstelle

ready

C-150 Hybrid

Internet meets cable TV

TRIAX Smart TV receiver C-150 Hybrid ist he ideal entry-level unit for connec-tion of classic cable TV and Internet. It allows access to the different transmitters’ internet-based additional facilities and interactive services like e.g. media libraries, newscasts,

Maximal programme variety

and simple operation makes TV watch-ing a real pleasure:

„ Reception of all free HD and SD programmes via cable (DVB-C)

„ 4.000 programme places for TV and radio

„ Quick-Videotext

„ USB-interface for external data carriers, recording (PVR ready) can be upgraded by software update

weather, videotext and advanced EPG. Moreover, TRIAX SmartTV portal can be activated with different apps likeBild.de, Facebook, pulpat and many others.

Many additional functions are available with this entry-level receiver:

„ Internet-based additional services via HbbTV

„ TRIAX SmartTV portal with many apps

„ Access to many broadcasts from the past 7 days via the media librari-es of the program providers

„ Mediaplayer for access to photos, music and films over the home network (UPnP) or USB

Small. Compact. Energy-saving and simple installation:

„ Plug-and-Play installation assistant

„ HDMI-interface with upscale func-tion for modern TV sets

„ Compatible with Unicable-systems

„ Software update via satellite or USB interface

„ Network connection and WLAN-ready (via USB stick)

„ Digital audio output

„ External power supply

Tuner

DVB-C •

Equipment/Operation

Plug & Play pre-programmed) | Installation assistant • | •

Display numerical | alphanumerical • |

-OSD | EPG | Videotext • | • | •

Programme places 4.000

Menu languages 9

Updates via USB interface •

SmartTV (internet-based additional services)

TRIAX SmartTV portal •

HbbTV | Media libraries | adv. Videotext | adv. EPG • | • | • | •

Recording and playback

US connection for external harddisk • (USB 2.0)

Recording function via USB |Time shift TV optional

Mediaplayer USB | UPnP | dlna • | • |

-Connections

DVB-C input |output IEConnector |

-HDMI-output | component output (YUV) • | •

Scart output •

Audio output cinch | coaxial | optical - | - | •

Ethernet interface | WLAN ready • | •

General data Article number 305 229 EAN 5702663052291 Colour black Dimensions (W x H x D mm) 280 x 40 x 160 Weight (kg) 1

Power consumption max | Stand-by (W) 15 | < 1

External power supply •

Ambient temperature (°C) +5 ... +40

Scope of delivery

2xÊUSBÊ2.0 Ethernet-Netzwerk Energiesparend

eco

Internetfunction

BildqualitŠt

HD

IP-100

Upgrade existing TV sets with SmartTV

TRIAX IP receiver IP-100 is the ideal expansion of existing TV sets with SmartTV. It connects the TV with the internet and gives access to the whole spectrum of free browsing over TV and radio programmes to video-on-demand services on the screen.

Maximal compatibility

And simple operation makes TV watching a real pleasure:

„ Combinable with all TV sets with HDMI connection

„ Ideal expansion for all transmission methods: Satellite, cable or terrestrial TV

„ Mediaplayer for access to photos, music and films over the home network (UPnP) or USB

Moreover, TRIAX SmartTV portal can be activated with different apps like Bild. de, Facebook, pulpat and many others.

Many additional functions Are available with this receiver:

„ Internet-based additional services via HbbTV

„ TRIAX SmartTV portal with many apps

„ Free internet browsing for display of websites on the TV

„ Access to m any broadcasts from the past 7 days via the media librari-es of the program providers

Small. Compact. Energy-saving and simple installation:

„ Plug-and-Play installation assistant

„ HDMI interface for modern TV sets

„ Software update via USB interface

„ Network connection and WLAN-ready (via USB stick)

Upgrade SmartTV without a new TV set at a minimum of costs

Equipment/Operation

Plug & Play Installation assistant •

Menu languages 10

Updates via USB interface •

SmartTV (internet-based additional services)

TRIAX SmartTV portal •

HbbTV | Media libraries | adv. Videotext | adv. EPG • | • | • | •

Free internet browsing •

Recording and playback

USB connection for external harddisk • (USB 2.0)

Mediaplayer USB | UPnP | dlna • | • |

-Connections

HDMI output |component output (YUV) • |

-Scart output | Cinch output - | •

Audio output cinch |coaxial | optical • | |

-Ethernet interface | WLAN ready • | •

General data Article number 305 250 EAN 5702663052727 Colour black Dimensions (W x H x D mm) 145 x 30 x 100 Weight (kg) 0,5

Power consumption max | Stand-by (W) 5 | < 1

Power supply •

Ambient temperature (°C) +5 ... +50

Scope of delivery

Remote control | Batteries | Operation manual • | 2x AAA | •

A piece of cake!

Connect your receiver with the Internet

When you buy a new Internet capa-ble unit like a SmartTV receiver you must make a decision concerning the Internet connection. However, the integration into the home network of the new device is often easier than you think. On the following two pages we

will show you three examples of how to connect your new device to the home network so that you can enjoy the interactive Internet services on your TV set.

Cabled network connection via network cable (LAN)

SmartTV and Internet services with problem-free installation

Required components

„ Network router with free network connection (LAN)

„ Network cable (LAN) for connection of router and terminal

Required components

„ WLAN capable network router

„ WLAN-USB stick for connection to the USB interface of the terminal

„

Required components

„ Network router with free network connection (LAN)

„ 2 x Ethernet via powerline adaptorm for transmission os network data via the powerline

„ Network cable (LAN) for connection of router and powerline adaptor and

Cable-free network connection via WLAN-USB stick

HDMI via PowerLine

TV transmissions via power lines

With TRIAX HDMI via PowerLine Set, consisting of transmitter and receiver, HD-programmes can be transmitted via power lines. This transmission method guarantees a maximum of flexibility as all HDMI equipment in the home like TV or beamer can be activated without

laying additonal HDMI cabling. HDTV-programmes, Blu-Ray films and internet programmes etc. can thus easily and quickly be transmitted to children’s rooms, sleeping room or kitchen.

Features of performance

„ Distributes HDMI signals via the existing power line

„ Supports HDTV and resolutions up to 1920 x 1080

„ One transmitter can be used by the same receivers at the same time

„ Infrared transmitter and receiver can be used by the same original remote control

„ Compatible with all common HDMI-equipment

Unlimited TV transmissions without laying new cables

Equipment/Operation

HDTV-resolution (up to 1920 x 1080 @60i/50i/23.98p/24p) •

Infrared transmitter & receiver •

Video-Compression H.264

Audio-Compression MPEG 1 Layer 2

Audio-Quality 16 bit, 48 kHz

Transmission rate via power line 200 Mbps

Transmission range via power line min. 90 m

hDMI transmitter

HDMI input and output | Infrared output | Power supply • | • | •

hDM receiver

HDMI output | Infrared input | Power supply • | • | •

USB interface for software update •

Application in practice: hDMI via PowerLine

Beamer with hDMI via

PowerLine receiver PC with hDMI via PowerLine receiver

Your ultimate connection

TRIAX A/S

Bjørnkærvej 3

DK-8783 Hornsyld

www.triax.com

www.triax.com

All specification in this catalogue subject to change without notice Triax Marketing • © 2013 The T

riax Gr

oup | All rights r

eserved. Use of this material signifies your agr

eement to the terms of use.
