Version: 0.23.5 –
0.24(ish)
Lovingly Dedicated to:
Jebediah Kerman
Bob Kerman
Bill Kerman
The Team at Squad.
The
Kerbonaut’s
Guide to the
Galaxy.
1
st
Edition
"We who are about to die,
salute you."
Before you start:
It is recommended that you laminate
this guide.
When you see a “ ”
You should leave
a tick/cross in DRY WIPE marker
according to your current situation.
Failure is always an option.
Good luck and have fun exploring the
KSP Basics:
Delta-V - In astrodynamics a Δv or delta-v (literally “change
in velocity”) is a measure of the amount of the effort that is
needed to change from one trajectory to another by making
an orbital manoeuvre.
L”X”O – Low “Enter Planet Name Here” Orbit. For
example, LKO = “Low Kerbin Orbit.”
Escape Velocity – The velocity required to exit a planet’s
sphere of influence.
Periapsis (Pe) – The lowest point in your orbit.
Apoapsis (Ap) – The highest point in your orbit.
Prograde/Retrograde – Prograde is “forward relative to the
direction of movement” it will increase your orbital
velocity.Retrograde is “backwards relative to the direction of
movement” it will decrease your orbital velocity.
Navball – Used to get your bearings and to navigate when in
space.
Thrust-To-Weight-Ratio – TWR for short is a ratio that
defines the power of a craft's engines in relation to its own
weight. If a
craft
needs to get into a stable
orbit
or land safely
on the current
celestial body
without using
parachutes
, then
its engines must put out more thrust than its current weight to
counteract gravity. In the terms of a ratio, a craft with a
greater thrust than weight will have a TWR greater than 1.
Inclination - The tilt of the orbit is given by the inclination.
Usually the value is given in degrees where the value is given
between –90° and 270°. An inclination of 0° or 180° is
equatorial, so the craft is always above the equator.
Navball Point of Reference - As all movement in space is
relative, the point of reference determines the object from
which all distance measurements and velocity vectors are
made. Clicking this area will toggle the point of reference
between Surface and Orbit, as indicated by the green text. If a
target is selected, there is a third option, Target. Changing
the point of reference changes the location of the prograde
and retrograde markers.
Manoeuvre Nodes - A maneuver node is a planned velocity
change along an
orbit
. Multiple maneuver nodes can be
added which will affect the following maneuver nodes. After
adding a node it shows the velocity change needed to reach
the next new orbit next to the
navball
.
Manoeuvre Node Directions –
Prograde/Retrograde - These vectors directly change the
speed of the craft. Burning prograde will increase velocity,
raising the altitude of the orbit on the other side, while
burning retrograde will decrease velocity and reduce the orbit
altitude on the other side.
Normal/Anti-Normal - The normal vectors are orthogonal to
the orbital plane. Burning normal or anti-normal will change
the orbital inclination. On the navball the normal and
anti-normal vectors are located on the equator line directly
between the prograde and retrograde markers.
Radial in/Radial out - The radial-in vector points directly
toward the center of the orbited body (center of the brown
hemisphere on the navball), while the radial-out vector points
directly away from it (center of the blue hemisphere).
Performing a radial burn will rotate the orbit
around the craft like spinning a hula hoop
with a stick. Radial burns are the least
efficient way of adjusting one's path - it is
much more effective to use prograde and
retrograde burns.
Navball
Icons
Mass –
“The centre of mass, abbreviated CoM,
or centre of gravity, is the location of an object where all
mass is equally distributed around it. It is important to
balance a
craft
to prevent it from getting out of
control.
Planes
should have a centre of mass slightly in front of
the
centre of lift
. For all craft the thrustvector should point to,
point away from or go through the centre of mass.” – Kerbal Space
Program Wiki
Centre of Mass (Yellow)
Centre of Thrust (Pink)
Thrust –
“The centre of thrust or thrustvector is the
direction in which the thrust is acting and on which point the
thrust acts on the
craft
. The thrustvector and
centre of
mass
should be in one line to minimize steering.” – Kerbal Space
Program Wiki
Lift –
“The centre of lift is used mainly when creating
planes
, it shows the axis and direction of lift provided
by
wings
,
control surfaces
and
winglets
. Inside the editor it is
showed as a cyan-coloured sphere (axis) along with an arrow
(direction of the lift). The centre of lift should also always be
behind the centre of mass.”– Kerbal Space Program Wiki
Kerbin
“
A unique world, Kerbin has flat plains, soaring mountains and wide, blue oceans. Home to the Kerbals, it has just the right conditions to support a vast, seemingly undepletable population of the eager green creatures.” –Kerbal Astronomical Society”
Planetary Characteristics:
ΔV Stats (LKO):
Sphere Of Influence: 84,159.3km Body: Delta-V:
Atmosphere Present: Yes Mun ~860m/s Oxygen Present: Yes Minmus ~930m/s Atmospheric Height: 69,077m Eve ~1033m/s Surface Gravity: 9.81m/s (1G) Duna ~1060m/s Escape Velocity: 3,431m/s Moho ~1676m/s ΔV To LO from Sea Lvl: ≈4500 m/s Jool ~1915m/s Synchronous Orbit: 2868.75km Eeloo ~2100m/s Pe for Aerobrake(Suggested): ≈36,000m KEO ~1120m/s
Science Multiplier:
Surface: 0.4 Atmospheric: 0.7 Space: 1
Mun
“
The Muns discovery is widely regarded as one of the more important breakthroughs of Kerbal evolution. Granted it didn’t happen all that long ago, but it’s still fair to say that Kerbals are wiser and more evolved now than they were back then.”
–Kerbal Astronomical SocietyCharacteristics:
Mun Biomes:
Sphere Of Influence: 2429.6km Biome:
Atmosphere Present: No Midlands
Oxygen Present: No Midlands Craters Atmospheric Height: N/A Highlands
Surface Gravity: 1.63m/s (0.166G) Highland Craters Escape Velocity: 807.08m/s Canyons
ΔV To Low Orbit: ≈800m/s Northern Basin Synchronous Orbit: N/A (SoI too low) East Crater Pe for Aerobrake(Suggested): N/A Northwest Crater
Science Multiplier: Southwest Crater
Surface: 4 Farside Crater
Atmospheric: N/A East Farside Craters
Space: 3 Polar Crater
Poles
Minmus
“
Minmus is the smallest moon orbiting Kerbin. From the surface of Kerbin, it can be seen on clear days as a tiny blue speck in the sky.”
-Kerbal Astronomical SocietyPlanetary Characteristics:
Minmus Biomes:
Sphere Of Influence: 2,247.4km Biomes:
Atmosphere Present: No Highlands Oxygen Present: No Midlands Atmospheric Height: N/A Lowlands Surface Gravity: 0.491m/s (0.05G) Slopes Escape Velocity: 242.61m/s Lesser Flats ΔV To Transfer: 920m/s Flats
ΔV To LO from Sea Lvl: N/A Great Flats Synchronous Orbit: 357.94km Greater Flats Pe for Aerobrake(Suggested): N/A Poles
Science Multiplier:
Surface: 5
Atmospheric: N/A Space: 4
Eve
“
Eve is certainly the purplest object in the solar system. Its one of the larger, most visible objects, mainly because of its very, very purple tint.”
–Kerbal Astronomical SocietyPlanetary Characteristics:
ΔV Stats*:
Sphere Of Influence: 85,109.4km Body: Delta-V:
Atmosphere Present: Yes Kerbin ~1030m/s Oxygen Present: No Moho ~810m/s Atmospheric Height: 96,708m Duna ~190m/s Surface Gravity: 16.7m/s (1.7G) Dres ~430m/s Escape Velocity: 4831.96m/s Jool ~1045m/s ΔV To LO From Sea Lvl: ≈11,500 m/s Eeloo ~1230m/s Synchronous Orbit: 10,328.47km Gilly ~1650m/s Pe for Aerobrake(Suggested): ≈72,500m LEO ~12000m/s
Science Multiplier: Kerbol Orbit ~80m/s
Surface: 12 Atmospheric: 7 Space: 7
Duna
“
Also known as the red dot that you can see if you squint at it really hard, Duna has long been a wonder to Kerbalkind.”
–Kerbal Astronomical SocietyPlanetary Characteristics:
ΔV Stats *:
Sphere Of Influence: 47,921.9km Body: Delta-V:
Atmosphere Present: Yes Ike ~270m/s Oxygen Present: No Eve ~190m/s
Atmospheric Height: 41,446m Dres ~460m/s Surface Gravity: 2.94m/s (0.3G) Kerbin ~1060m/s Escape Velocity: 1372.41m/s Moho ~840m/s ΔV To LO from Sea Lvl: ≈1750 m/s Jool ~1075m/s Synchronous Orbit: 2880.00km Eeloo ~1260m/s Pe for Aerobrake(Suggested): ≈13,000m LDO ~1380m/s
Science Multiplier: Kerbol Orbit ~110m/s
Surface: 8
Atmospheric: N/A Space: 7
Dres
“
Dres is a very small planet. It was the first planet considered to be a dwarf. Its orbit is highly irregular and together with its size it took a long time to discover since half the time it was not where scientists expected to find a planet.”
–Kerbal Astronomical SocietyPlanetary Characteristics:
ΔV Stats *:
Sphere Of Influence: 32,832.8km Body: Delta-V:
Atmosphere Present: No Eve ~430m/s Oxygen Present: No Duna ~460m/s Atmospheric Height: N/A Jool ~1315m/s Surface Gravity: 1.13m/s (0.115G) Kerbin ~1300m/s Escape Velocity: 558.00m/s Moho ~1080m/s ΔV To LO from Sea Lvl: ≈555 m/s Eeloo ~1500m/s Synchronous Orbit: 732.24km LDO ~800m/s**
Pe for Aerobrake(Suggested): N/A Kerbol Orbit
~350m/s
Science Multiplier:
Surface: 8
Atmospheric: N/A Space: 7
*(From Orbit Around Dres + Does not include getting into orbit or landing) **(Delta-V needed to get into orbit after ascent)
Moho
“
Moho figures in Kerbal mythology as a fiery place with oceans of flowing lava. In reality however, its much less interesting.”
–Kerbal Astronomical SocietyPlanetary Characteristics:
ΔV Stats *:
Sphere Of Influence: 9,646.7km Body: Delta-V:
Atmosphere Present: No Eve ~810m/s Oxygen Present: No Duna ~840m/s Atmospheric Height: N/A Jool ~1695m/s Surface Gravity: 2.70m/s (0.275G) Kerbin ~1680m/s Escape Velocity: 1,161.41m/s Dres ~1080m/s ΔV To LO from Sea Lvl: ≈1,400 m/s Eeloo ~1500m/s Synchronous Orbit: N/A (SoI too Low) LMO
~2200m/s**
Pe for Aerobrake(Suggested): N/A Kerbol Orbit ~730m/s
Science Multiplier:
Surface: 9
Atmospheric: N/A Space: 8
*(From Orbit Around Moho + Does not include getting into orbit or landing) **(Delta-V needed to get into orbit after ascent)
Jool
“
Jool is particularly known for being a rather large, predominantly green planet. Kerbalkind has longed to visit it since it was first spotted in the sky. Philosophers reason that the swirling green planet must be a really nice place to visit, on account of its wholesome coloration.”
–Kerbal Astronomical SocietyPlanetary Characteristics:
ΔV Stats *:
Sphere Of Influence: 2.4559852×109m Body: Delta-V:
Atmosphere Present: Yes Eve ~1045m/s Oxygen Present: No Duna ~1075m/s Atmospheric Height: 138,155km Moho ~1695m/s Surface Gravity: 7.85m/s (0.8G) Kerbin ~1915m/s Escape Velocity: 9,704.43m/s Dres ~1315m/s ΔV To LO from Sea Lvl: ≈22,000 m/s Eeloo ~2115m/s Synchronous Orbit: 15,010.46km LJO
~2630m/s**
Pe for Aerobrake(Suggested): N/A Kerbol Orbit ~965m/s
Science Multiplier:
Surface: N/A Atmospheric: 7 Space: 7
*(From Orbit Around Jool + Does not include getting into orbit or landing) **(Delta-V needed to get into orbit after ascent)
Eeloo
“
There’s been a considerable amount of controversy status of Eeloo as being a proper planet or just a lump of ice going around the sun. The debate is still ongoing, as most academic summits held to address the issue have devolved into, on good days, petty name calling, and on worse ones, all-out brawls.”
–Kerbal Astronomical SocietyPlanetary Characteristics:
ΔV Stats *:
Sphere Of Influence: 119,082.94km Body: Delta-V:
Atmosphere Present: No Eve ~1230m/s Oxygen Present: No Duna ~1260m/s Atmospheric Height: N/A Moho ~1880m/s Surface Gravity: 1.79m/s (0.172G) Kerbin ~2100m/s Escape Velocity: 841.83m/s Dres ~1500m/s ΔV To LO from Sea Lvl: ≈840m/s Jool ~2115m/s Synchronous Orbit: 683.69km LEO
~2100m/s**
Pe for Aerobrake(Suggested): N/A Kerbol Orbit ~1150m/s
Science Multiplier:
Surface: 9
Atmospheric: N/A Space: 8
*(From Orbit Around Eeloo + Does not include getting into orbit or landing) **(Delta-V needed to get into orbit after ascent)
Time Warp Altitudes
VAB Checklist*
Booster:
Fuel
Engines
SRB’S
Decouplers
Struts!
Control Surfaces
Correct Staging
Action Groups
LES (Launch Escape System)
Orbital Stage:
RCS
Monopropellant
Fuel
Engine (LV-909/Poodle)
Batteries
Solar Panels/Reactor
Docking Port
Lander/Descent Stage:
Landing Legs
Ladder
Lights
Parachutes
Command Module
S.A.S/Reaction Wheels
More RCS and Monopropellant
Fuel
Batteries
Solar Panels
Crew (Jeb, Bill, Bob)
Science (Goo, Materials)
Clear Hatch
Snacks!
*Some parts may not be available if you play in Career
mode.
Rocket Construction Tools
Presuming that you’ve already built your first rocket (If not, whack a RT-10 Solid Fuel Booster onto a Command Pod Mk1 and launch!) These are tools designed to help make more efficient rockets:
Apologies for not having 0.23.5 rockets, there are no
graphs available on the internet including these. I’m
working on making my own.
To use this nomogram, pick a dV on the left and
Isp on the right. Draw a straight line between them.
The required mass fraction of your vehicle/stage is
where your line crosses the Mass Fraction scale.
Do the same as before, choose your desired
payload weight on the left and your mass fraction
which you obtained beforehand and draw a straight
line between them. This is the amount of fuel you will
need to lift the payload, the dry fuel tanks and fuel.
You Done Goofed!
Check That:
Hatch isn’t obstructed!
Landing leg orientation is
correct!
You have enough electricity!
You have strutted
EVERYTHING!
You have sufficient fuel
supplies!
You have crew!
Action groups are set up!
You have science modules!
Mission Planner:
Mission Name:
Budget:
/
Contracts:
Science Goal: +
Mission Briefing:
Chosen Crew Member(s):
Launch Vehicle:
Orbital Vehicle:
Lander:
Launch Date:
Flight Checklist:
Pre-Launch:
S.A.S
Staging
Crew
Damage Check
5P’s:
Pods: Command Modules, Habitats etc.
Propulsion: Fuel and Engines
Power: Panels, Batteries, Reactors
Piloting: RCS, S.A.S etc.
People: Crew,
(If using TAC)Food, Water
etc.
Launch:
Increase Throttle
Activate First Stage
Ascent Stage:
Jettison SRB’s
At 7.5-10km, Complete Gravity Turn
Continue To Burn Until Desired Apoapsis
is Reached
Orbital Stage:
Burn Pro-Grade until the Periapsis is
within 0-3km of the Apoapsis Height
Deploy Solar Panels
Perform Transfer Stage OR Burn
Retro-Grade to return to Kerbin.
Pre-Landing
(When Returning or Landing Anywhere):
Retract Solar Panels and Antenna
Deploy Legs
Arm Parachutes
Crew Check
Select Landing Area
Post Landing:
Do Science!
Stretch Legs!
Recover Vehicle (If landed on Kerbin)!
1) Build a rocket. It should have enough Delta-V to get into
LKO. A minimalistic rocket would be:
Command Pod Mk1
FL-T400 Fuel Tank
LV-909 Liquid Fuel Engine
TR-18A Stack Decoupler
FL-T800 Fuel Tank
LV-T30 Liquid Fuel Engine
2) Turn SAS on and throttle up
3) Countdown from 10.
4) Press Space to launch and wait until you are at 10,000m,
ensure that you head directly up (Keep your dot on the blue
top dot on the Navball)
5) Jettison your first stage with the spacebar
6) Throttle down to 2/3
rdpower
7) Turn 45 degrees East (Press D) and burn until your apoapsis
is at 70-75km. You can check this by pressing M.
8) As you approach apoapsis, orient your ship to the 0-degree
latitude mark (Directly East) between the blue and brown
halves of the navball.
9) Once you are 10-30 seconds away from apoapsis, begin your
orbital burn by using the Shift key to throttle up. You can go at
full throttle or partial throttle, but you may overshoot when at
full throttle.
10)
Wait until a periapsis appears directly opposite to your
apoapsis and wait until it’s altitude becomes >70km. Hit X to
turn off your engines instantly.
11)
Congratulations, you have made orbit!
Docking Tutorial
Courtesy of Leforian1.
Time your launch by putting the target slightly behind KSC in
its orbit
like this
.
2.
As you are burning start your
gravity turn
at the normal
altitude.
3.
In
orbital view
try to get your apoapsis to meet the target's
orbit ahead of the
4.
The tricky part is determining
where to put the apoapsis
. You
can make it encounter sooner by burning more vertically, and
encounter later by burning more horizontally.
5.
I
misjudged
the
timing and my
apoapsis crossed the
orbit too late. The
top red carrot is where I will be, and the bottom carrot is where
my target will be. I need to push my apoapsis farther away.
Remember that burning directly prograde will raise your
apoapsis further, so you will also have to burn slightly down in
pitch to keep your apoapsis at the altitude you need.
6.
After moving my apoapsis forward for a minute or two I get a
good 100 meter-ish
encounter
.
“For when you feel like Wernher Von Kerman”
Thrust to Weight Ratio –
Ft - Engine Thrust
M – Total mass of the craft
g – The local gravitational acceleration
Combined Specific Impulse –
If the Isp is the same for all
engines in a stage, then the Isp is equal to a single engine. If the
Isp is different for engines in a single stage, then use the equation
above.
Tsiolkovsky rocket equation –
Basic Δv
Calculation –
Δv - the velocity change possible in m/s
M
start- the starting mass in the same unit as
M
endM
end -the
end mass in the same unit as
M
startIsp – the specific impulse on the engine in
seconds.
Fuel flow rate –
Orbital velocity –
µ - Gravitational Parameter of parent body
(km
3/s
2)
r – Radius of orbit (km)
Science Modules:
Mystery Goo™ Containment Unit:
“The Mystery Goo™ Containment Unit is a science part used to expose a goo to atmospheres and vacuum in attempts to gain science from observing the goo inside. This can be achieved either via action group or right clicking the container and clicking observe mystery goo. The unit cannot be reused after its results were transmitted, unless it is cleaned via the Mobile Processing Lab MPL-LG-2. Like EVA reports, the science gained from observing the Mystery Goo varies depending on different conditions in flight.” – Kerbal Space Program Wiki
SC-9001 Science Jr.
“Science Jr. is the more advanced scientific sensor. It is used to
retrieve science points and to complete science experiments in space or other celestial body. The unit cannot be reused after its results were transmitted, unless it is cleaned by theMobile Processing Lab MPL-LG-2.” – Kerbal Space
PresMat Barometer:
“Displays atmospheric pressure to five significant figures, while active. A pressure below 0.0001 is shown as vacuum by the sensor. Lower atmospheric pressures markedly reduce lift and drag induced by the atmosphere, and cause a small change in engine efficiency.” – Kerbal Space Program Wiki
GRAVMAX Negative Gravioli
Detector:
“This instrument shows the gravity in your current sphere of influence to a maximum of 4 significant figures and two decimal places. This can be used with altitude to estimate the mass of the nearest celestial body or to measure its surface gravity. Alternatively, it can be used with the
accelerometer and altitude to make landing estimates.” – Kerbal Space
Program Wiki
2HOT Thermometer:
“The 2HOT Thermometer displays temperature to 5 significant figures when activated and right-clicked. There is no unit shown but it is assumed to be degrees Celsius. The 2HOT cannot be used to earnscience while distant from a celestial body, although it will continue to tell the temperature.” – Kerbal Space Program Wiki
“The Mobile Processing Lab MPL-LG-2 allows scientific data to be transmitted with higher efficiency and to reuse the Mystery Goo™ Containment
Unit andSC-9001 Science Jr. after transmitting their result. The module needs its full capacity of two Kerbals to work. Note that it is not a command module; any craft it's a part of will need a probe body or command pod to be piloted. Using the module consumes electricity” – Kerbal Space Program Wiki
Easy Science At Kerbin:
Gather a:
Crew Report!
EVA Report!
Surface Sample!
Mystery Goo!
Materials Bay!
Kerbin Biomes:
Launchpad
Runway
KSC
Mountain
Shores
Tundra
Water
Grasslands
Desert
Flying Over
Flying Over
Flying Over
Flying Over
Flying Over
Flying Over
Flying Over
Flying Over
Flying Over
Flying Over
Flying Over
Flying Over
Badlands
Highlands
Ice Caps
Interplanetary Travel
Orbital Transfer Guide
10 Year Launch Window Calendar (Earth
Years)
Gravity Assists
Delta-V Requirements
Travelling To Duna, Mun and Minmus
Landing and Parachutes
Interplanetary Travel
Orbital Transfer Guide
100 Year Launch Window Calendar
(Kerbin Years)
Landing Guides
Gravity Assists
Delta-V Requirements
Ideal Interplanetary Phase Angles
Orbital Transfer Guide
In map view, put the blue cross on the planet you’re orbiting and the red cross on your rocket. The point where the green line intersects your desired planet's orbit is where you
Hohmann & Bi-Elliptical Transfers
Hohmann Transfer:
A Hohmann transfer is a technique that involves burning your
engine twice whilst in orbit in order to reach a higher orbit.
You start off by burning prograde at your periapsis until you
reach the desired altitude for your apoapsis. You will now
have an elliptical orbit. Next you have to travel up to your
apoapsis and burn prograde once
again in order to raise your
periapsis to the same altitude as
your apoapsis. Like so:
A Bi-Elliptical transfer is similar to a Hohmann transfer
although it requires one extra step. Most of the time the
Hohmann technique is more useful but in some cases using a
Bi-Elliptical transfer can save you Delta-V!
You start a Bi-Elliptical transfer by burning prograde from
your periapsis in order to raise your apoapsis. Again, making
an ellipse. Once you are at apoapsis, you burn prograde to
raise your periapsis to your desired orbital altitude. After
travelling to periapsis, you want to burn retrograde and bring
your apoapsis down to roughly the same altitude as your
periapsi. Like so:
Landing
Guides
You’ve come this far; let’s not screw it up now!
25000 30000 35000 40000 45000 50000 55000
Kerbin SOI Entry Aerocapture Chart
Minmus Mun Sync Orbit SSync Orbit 1000 km 100 km Orbital Velocity (m/s) Aerocapture Periapsis (m) 55000 57000 59000 61000 63000 65000 67000 69000 71000 73000 75000
Eve SOI Entry Aerocapture Chart
Sync Orbit SSync Orbit 1000 km 100 km Orbital Velocity (m/s) Aerocapture Periapsis (m)
8000 9000 10000 11000 12000 13000 14000 15000 16000 17000 18000
Duna SOI Entry Aerocapture Chart
Ike Sync Orbit SSync Orbit 100km 50km Orbital Velocity (m/s) Aerocapture Periapsis (m) 100000 105000 110000 115000 120000 125000 130000 135000
Jool SOI Entry Aerocapture Chart
Pol Bop Tylo Vall Laythe Sync Orbit SSync Orbit 1000 km 150 km Orbital Velocity (m/s) Aerocapture Periapsis (m)
250 500 750 1000 1250 1500 1750 2000 2250 2500 2750 3000 20000 22000 24000 26000 28000 30000 32000 34000
Laythe SOI Entry Aerocapture Chart
SSync Orbit 1000 km 100 km
Orbital Velocity (m/s) Aerocapture Periapsis (m)
Transfer Windows
Gravity Assists:
“
A gravity assist is a maneuver in which you use a flyby of a secondary celestial body (such as a planet or moon) to alter your orbit about the primary (typically the sun, but occasionally a planet: forinstance, when navigating the Joolian moon system). Gravity assists are useful because they allow you to gain or lose orbital energy or make expensive maneuvers such as plane changes for free; however, they are difficult to set up and require careful planning and lots of patience. That said, once
you master them, you can manage feats you wouldn't have thought possible.
”
–Stochasty1. Firstly, you have to put yourself into a transfer orbit, ensuring that the celestial body is travelling in the direction you want to go in.
2. Time Accelerate until you reach the SoI of the celestial body.
3. Plan another course correction manoeuvre at Periapsis to increase your Apoapsis height after leaving the SoI, it is most effective when you are closer to the body, but ensure you won’t collide with anything and that you won’t be accidentally aerobraking.
4. Time Accelerate until you leave the SoI of the celestial body.
5. When you check the map you will notice that your Apoapsis height has increased.
6. You can repeat this, changing your course when furthest away from the
body you are getting a gravity assist from, until you have reached a the SoI of another planet or anywhere really.
7. You can use gravity assists to go from Kerbin to Duna, or Jool to Kerbin without using a lot of fuel. It is one of the most efficient ways of
8.
You can perform a powered gravity assist. Accelerating at your periapsis has the greatest effect on your apoapsis. This still applies to yourperiapsis during a gravity assist. When you accelerate during your fly-by, fuel is used very efficiently to increase the apoapsis of your final
trajectory. This is a very difficult technique because it is hard to control your final trajectory even when using a manoeuvre node but can save a lot of time and a lot of fuel.
