See the

light!

(2)

Torrent Trackside is the only specialist provider of portable

rail plant in the UK and has a unique appreciation of the

needs and challenges of the rail industry.

We understand the need for powerful and easily

transportable lighting which is why we have invested in a

complete range of lighting products to meet the needs of

the most demanding rail projects.

Many of our lights are battery or hydrogen powered so run

silently and have zero emissions.

Contents

page no.

Electric lights

3

Portable lights

6

Tower lights

7

Accessories

8

Modern and efficient lighting

for the rail industry

(3)

24hr helpline

0845 769 7168

www.torrent.co.uk

mail@torrent.co.uk

torrenttrackside @TorrentRail

Portable yet powerful the Night Searcher galaxy

Pro can run for up to 8 hours from a single

charge from it’s Li-ion rechargeable battery.

The emains recharger stores neatly in the

rear of the light.

The lamp can be angled up to 90 degrees and

comes with a handy fold down carrying handle.

Specification

Item code:

06-092

Charging source:

7.4v battery

Light beam:

15m flood beam

Light output:

1750-3500 lumens

Height:

310mm

Depth:

285mm

Width:

350mm

Weight:

1.5kg (inc. charger)

Specification

Night Searcher

Galaxy Pro Light

Battery Lights

l Twelve high performance LED up to 2000 lumens on high power with high, medium & low settings l Impact resistant adjustable head highly durable

polycarbonate head, can be rotated 230 degrees vertical and 240 degrees horizontal

l Protective guard secures the head and lens when the light is collapsed

l Extendable mast reaches from 1.10m to over 2.20m to light up work spaces from top without casting shadows

l IP54 protected from dust and splashing water l Compact footprint low centre of gravity and impact

resistant reinforced nylon legs to protect against damage

l Low battery indicator light flashes when battery is low

l Carry handles for easy one handed transport

Milwaukee M18 SAL

battery LED tripod light

Specification

Item code:

06-154

Battery type:

Li-ion

Charging time:

100 mins

Light output:

850-2000 lumens

Lamp type:

LED

Weight:

7.3kg

Specification

(4)

Twelve high performance LEDs and 3 light settings provide up to 3000 Lumens on high – up to 30% brighter than a 500 Watt halogen light

240° rotatable light head and integrated key holes for horizontal and vertical hanging

Impact resistant polycarbonate lens and durable roll cage to protect the light from rough jobsite conditions

Dual power source, powered by either M18™ REDLITHIUM-ION™ battery packs or use of 110V 2.5m hardwired cord

Easy one-handed transport with built-in carry handles Low battery indicator, light flashes when battery pack is low on charge

Milwaukee M18 HAL LED

Specification

Item code:

06-156

Charging source:

mains and 12v

Run time:

2/4/9 hours

Light output:

650/1500/3000 lms

Lamp type:

LED

Weight:

3.4kg

Specification

The ProTrack is a rechargeable, battery-powered link lighting system that offers a simple and versatile new off-grid solution for illuminating night-time trackside working.

As an alternative to diesel generators, ProTrack is silent and emission-free, so is ideal for lighting long stretches of track, tunnels, bridges and walkways. Weighing in at less than 50kg, each ProTrack portable battery unit powers up to 100 metres of link lighting, with up to 27 hours between rapid 3 hour recharging. Each ProTrack system is supplied with 100m of link lighting, comprising of 9 link lights, so bright LED lights can be positioned between 10 and 12 metres apart.

Protrack Battery Powered

Link Lighting

Specification

Item code:

XPL.LINK

Charging source:

mains

Run time:

up to 27 hours

Light output:

650/1500/3000 lms

Lamp type:

LED

Weight:

>50kg

Specification

(5)

24hr helpline

0845 769 7168

www.torrent.co.uk

mail@torrent.co.uk

torrenttrackside @TorrentRail

Used to light up relatively large areas with very

few lights. The light bracket is adjustable in

height from 1.5m to 2.4m.

Specification

Item code: 06-065

LED Max 2x20W

110V-240v - 50Hz

IP65 rating

180

o

swivel head

Cool white LEDs

5m cable

Specification

Tripod Lights

The STEL Lucia link light is an ideal way to easily and efficiently light rail track and tunnels.

The STEL Lucia LED Portable Link Lighting is perfect for use in the Rail Industry for temporary lighting of access and maintenance projects.

The STEL Lucia LED Portable Link Lighting avoids the expense of bulky lighting equipment, with excellent cost savings against tower lights, the STEL Lucia LED Portable Lighting will provide over 500 metres of lighting from a small, single 3KVA generator.

Stel Link Lights

Specification

Item code:

21-655

Input voltage:

AC 100-240

Rated power:

30W

Light output:

3600 lumens

Light angle:

180 degrees

Size (no stand):

64 x 11 x 6.5cm

Lamp type:

LED

Weight:

1.3kg

Specification

Portable lights

(6)

In just a few seconds, these lamps, which are based on almost unbreakable LED technology, immerse their entire environment into a flood of light. To achieve this, the newly developed, single-lens-based Xpect2 LED modules work in perfect combination which avoids scattering light and increases efficiency. l Installed within seconds

l maximum homogeneous light output l lower transport and installation costs l can be used a lighting station

Specification

Item code:

06-121

Charging source:

100-240v AC

Operating temp:

-40ºc to +59ºc

Light output:

90000 lumens

Height folded:

261mm

Width:

650mm

Weight:

17.5kg

Specification

Aldebaran XLD LED

l Glare-free XPECT2-LED lens optic (reduces scattering losses and glare effectively) l SETO LiveView colour mixing system for

optimum performance in any weather l Around 85% reduction of power

consumption compared with a 2,000 watts halogen spotlight

l Low weight and compact

Specification

Item code:

06-126

Power usage:

160w

Lumens:

23,000 approx.

Bulbs:

2x Xpect2 LED

Beam angle:

60 degrees

Focal point:

25 degrees

Width:

264mm

operating temp:

-25 - +40 degrees C

Specification

Aldebaran Gladius LED

(7)

Tower lights

l

Towable lighting system

l

Energy efficient luminaries providing massive

fuel savings

l

Lamps are easily adjustable by the average

person standing on the ground

l

Fully hydraulic single axis mast using

Eco-Friendly water based hydraulic system

l

Mechanical fail safe AMOSS mast safety system

l

9.1m 350 degree rotating mast with simple

push button operation

l

Ease of service a key factor of internal design

l

Fully adjustable stabiliser legs - unit can be

levelled for use on uneven ground.

l

Dusk to Dawn & 7 day timer operating options.

l

Auxillary power take of available 220v or 110v

l

Daisy chain or mains plug in as standard

Specification

Item code:

06-087

Weight dry/unladen: 750kg

Length/height/width 2500/2150/1345mm

Fuel capacity

95 ltr

Fuel consumption

0.5ltr/hour

Max running time

170 hours

Noise level

85dba

Specification

Mobile Lighting Towers

The world’s first low energy LED

hydrogen fuel cell powered

lighting tower

l ZERO exhaust emissions l ZERO Co2 emissions l ZERO particulate pollution l ZERO servicing

l ZERO combustion l ZERO contamination l Easy to operate

l Operational in enclosed spaces l Low-energy LED lighting l Up to 170 hours run time

l Automated dusk to dawn switching l Controllable light patterns

l Reduced environmental impact

Specification

Item code:

06-095

Total run time:

25 - 170 hours

Specification

TH2 ecolite lighting tower

24hr helpline

0845 769 7168

www.torrent.co.uk

mail@torrent.co.uk

torrenttrackside @TorrentRail

7

(8)

Lighting accessories

We offer a complete range of accessories to your lighting

projects are as effecient and effective as possible.

Accessories include:

l

Wall brackets

l

Stands

l

Tripods (various heights)

l

Magnetic feet

l

Baskets
