Qatar Air Distribution Network Manufacturing Factory (W.L.L)
CERTIFIED TO BS 476 PART 24 CERT. NO 785A CERT. NO 785
ASSESSED TO ISO 9001
Authorized Exclusive Licensee
HIGH PERFORMANCE FIRE
RATED DUCTWORK
DESIGN CRITERIA
It is essential when choosing a fire-rated system that it will be fit for the purpose for which it is being applied. Consultation with the local District Surveyor may be required and a fire- rated ductwork specialist is essential to enable the correct specifications and procedures to be applied. In order to ensure the fire-rated ductwork is correctly specified, several factors should be confirmed and defined.
Check Define the type of system required:
Fire Outside Type A
Fire Inside and Outside Type B
Check Define the type of Ductwork required: Ventilation/Kitchen
Extract/Car Park/ Stair Pressurisation.
Check Determine the fire rating to BS476 Part 24 and the required
time periods for : Stability - Integrity - Insulation
Check Determine static pressure requirements
Low Pressure Class A 500 Pa positive and negative Medium Pressure Class B 1000 Pa positive and negative High Pressure Class C 2000 Pa positive and negative
Check The design team shall be responsible for confirming with
the Client/Consulting Engineer, the stability, integrity’ and insulation requirement (i.e. where the ductwork crosses a means of escape).
Check Identify from the Architect’s drawings, the fire rating of
adjacent walls through which the fire-rated ductwork will penetrate.
Check Obtain details of additional access door requirements for
cleaning.
Check COMMISSIONING OF TEST HOLES - NOT IN OUR SCOPE
Check Where the fire-rated ductwork penetrates any fire-rated wall
a penetration seal has to be installed in accordance with Flameshield Fireduct specification.
Check Define from the contract specification any additional
requirements such as Attenuators, duct cleaning requirements and air leakage variations - VCD & Fire Dampers
FLAMESHIELD FIREDUCT THE UK’S FIRST NON-COATED
FIRE-RATED DUCTWORK TO ACHIEVE LPCB CERTIFICATION
FLAMESHIELD DUCT UNDER TEST Check-Circle NON COATED
Check-Circle 2 HOUR INSULATION Check-Circle 4 HOUR STABILITY Check-Circle 4 HOUR INTEGRITY
Check-Circle TESTED BY BRE Check-Circle LPCB CERTIFICATION
Check-Circle APPROVED BY LPCB
AGAINST BS 476 PART 24
Check-Circle CERTIFIED BY LPCB
AGAINST ISO 9001 Check-Circle RED BOOK ACCEPTANCE
Check-Circle CERTIFIED AS AN INSTALLER
AGAINST LPS 1531 Check-Circle FULL MEMBER ASFP
Check-Circle ENVIRONMENTALLY
FRIENDLY
FIRE -RATED DUCTWORK SUPPORTS
All fire-rated ductwork supports are calculated, designed and tested in consideration of a fully developed fire (as described in the 150834:1975 (E) fire resistance test standard time - temperature curve) using strict guidelines within the
permissible stress allowances and the specified period of protection required.
FlameshieldTM Utilizes the very latest computerized models to calculate all non- standard support arrangements. Due to the complex design calculations and the importance of having a fully compliant system, no modifications should be made to support arrangements.
FlameshieldTM offer a complete consultancy service with regard to the purchase of fully compliant ancillary plant and equipment. We design fire-rated enclosures to build around non fire-rated fans, fire-rated attenuator casings to incorporate the non fire-rated internal sections and are able to advise on all types of fully compliant air control dampers and motorized dampers to suit all needs and requirements.
ISO 834 : 1975 (E) FIRE RESISTANCE TEST STANDARD TIME - TEMPERATURE CURVE
DUCTWORK CONSTRUCTION
The FlameshieldTM ductwork system is manufactured from pre-galvanised, black &
stainless steel sheet as per FlameshieldTM specification. The fire-rated ductwork has been tested and certified by the Building Research Establishment to meet the following standards:
LPCB Certified.
BS 476: Part 24: 1987.
Furthermore, the Flameshield ranges of fire resistant ducts incorporates and are in compliance with the following standards :
BS 5588: Part 9.
DIN 1.44.
DW 172
Document B1 ( Means of Escape) and B3 (Internal fire spread structure)
Check Suitable for use as a Type A (Fire outside)
and Type B (Fire inside/outside) fire-rated ductwork systems for periods of up to 240 minutes Stability and Integrity, 120 minutes insulation.
Check Suitable as a Smoke Extract system for periods
of up to 120 minutes Stability, Integrity and Insulation.
Check Suitable for Kitchen Extract, Car park Extract,
Stair Pressurisation System and Dishwasher Extract.
Check Suitable for fire-rated ductwork Air Leakage up
to 2000 Pa Class C.
The unique fabrication process for Flameshield Fireduct has many distinct benefits which include:
A. Quicker to Manufacture and Install - no need for the application of external coating
B. More Environmental Friendly - At least six production processes are eliminated.
C. Handles Internal and External Heat - Gas temperatures in excess of 1100 deg. C.
INDUSTRIAL
Angle-right Stratiord Station Crew Accommodation (Tube Lines Limited)
Angle-right Waterloo London Underground Station (Tube Lines Limited)
Angle-right MOD Project Gemini, Aldermaston
Angle-right Big Yellow Storage, Liverpool, Twickenham Angle-right Global Switch, London
Angle-right Castle Espie, Northern Ireland Angle-right Metal Technology, Northern Ireland Angle-right City Point, London
Angle-right Audi, Brentiord
Angle-right ISG Wynyard, Middlesbrough Angle-right TEL, Southwark
Angle-right BT Tower, London
Angle-right Stratiord Station Ticket. Office
RETAIL LEISURE
Angle-right Totienham Hotspur FC
Angle-right The Olympic Stadium, Stratiord Angle-right Debenhams, Glasgow
Angle-right Ashford Shopping Centre, Kent Angle-right Sainsbury’s, Selsdon
Angle-right Tesco Cashel, Northern Ireland
Angle-right Walton on Thames Town Development Angle-right The 02 Centre, Finchley
Angle-right Burger King, Dublin
Angle-right Zizzi Restaurants, Liverpool, Leicester,
High Wycombe, Prezio Restaurants,
Newquay, Glasgow, Spalding Domino Pizza, Whitstable, Palmers Green, Moti ngham The Wine Theatre, London
Angle-right Marriot Hotel, Gatwick
Angle-right For Your Eyes Only Nightclub, London Angle-right Waterside Café, London
Angle-right Dim T Restaurant, Milton Keynes Angle-right The Shard, London
Angle-right Stratiord Shopping City Angle-right The Natural History Museum Angle-right Museum of London
Angle-right Huntingdon Racecourse Angle-right Twickenham Stadium
Angle-right Chipoti le Restaurant, London
RESIDENTIAL:
Angle-right Chalkhill Road Development, London Angle-right Quintessential Homes Development,
London
Angle-right Millharbour Development, London Angle-right Kew Gardens Herbarium, London Angle-right Bankside EDF, London
AIRPORTS
Angle-right Heathrow Terminals 1 & 4 Angle-right Gatwick South Terminal Angle-right Southampton
COMMERCIAL BOULEVARD - LUSAIL
LUSAIL STADIUM QATAR
COMMERCIAL
Angle-right Goldman Sachs HO, London Angle-right Store Street Project, London
Angle-right Metropolitan Wharf Project, London Angle-right Noti ng Hi II Village, London
Angle-right Sloane Terrace Project, London Grosvenor Street Project, London Angle-right Horsham Street Project, London Angle-right Ludgate West Development,
Angle-right London Rio Tinto HO Project, London Angle-right Clairville House Project, London Angle-right The Walbrook Project, London
Angle-right Plot 7 More London Riverside Project, London Angle-right One New Change Project, London
Angle-right Warwick Avenue Project, London Angle-right 4 Mastmaker Road Project, London Angle-right The Rolls Building Project, London Angle-right Merchant Square Project, London Angle-right Q.U.B MBC Building, Northern Ireland Angle-right Connaught Place Development, London Angle-right Bridges Wharf Development, London Angle-right The Shard, London Stratford Shopping City
HOSPITALS
Angle-right Queen Elizabeth Hospital, Kent Angle-right Craigavon Hospital, Northern Ireland Angle-right Pembury Hospital, Kent
Angle-right Horton Hospital, Buckinghamshire Angle-right St. Bartholomew Hospital, London Angle-right Altnagelvin Hospital, Northern Ireland
Angle-right Ulster Hospital, Northern Ireland Angle-right North Middlesex Hospital, London Angle-right Lewisham Hospital, London Angle-right Maidstone Hospital
SCHOOLS I COLLEGES
Angle-right Bangor Academy, Northern Ireland Angle-right Muckamore Abbey, Northern Ireland Angle-right Mid Kent College, Kent
Angle-right Ashfield Girls School, Northern Ireland Angle-right University of Surrey
Angle-right Ware Campus, Hertiordshire
Angle-right Drumragh College, Northern Ireland Angle-right City of Westminster College University
of Derby
Angle-right Noti ngham Preparatory School Angle-right St. Johns School, Gravesend Angle-right Bethnal Green College Angle-right West Thames College Angle-right University of Arts, Holborn Angle-right Garth Hill College
Angle-right Waingel College, Reading
AL MUTAHIDAH TOWER - PEARL QATAR
QATAR RAIL - METRO & LRT
FOX HILLS - LUSAIL CITY QADNET | 022021 | NL | R01 | 1000 PRITHVI: +91 93597 13489
