STEINER MILITARY SCOPES

(2)

BIGGEST MANUFACTURER OF GENUINE

MILITARY DAYLIGHT BINOCULARS

STEINER-OPTIK GmbH is the world’s biggest manu-facturer of genuine military daylight binoculars. Our products are under use by government, law enforcement and military departments in more than 70 different countries all over the world who trust in our long-time experience in the manufacturing of high precision quality products. STEINER military binocu-lars proved their reliability and effective performance during many peace-keeping missions and on several

combat fields. STEINER is the only manufacturer who had devel-oped binoculars especially for military purposes and who is perma-nently improving

and developing it further in close cooperation with the most important military forces in the world so that the products we offer always represent the latest state of-the-art and keep up with the latest technological developments. We are the leading company in the field of binoculars with integrated direction finder as well as in laser protection equipment for binoculars.

From Binoculars to Scopes

Many times we have been asked by our fully satisfied customers all over the world to offer scopes of the established STEINER quaility and performance. Until now we were not able to meet their needs because of our purposely focus on constantly optimizing our binoculars. But now we are proud to introduce the new STEINER Military Scopes – a innovative category of scopes, based on the establisched principles that our binoculars are famous for.

STEINER MILITARY SCOPES – FACTS

A new Field of Honor

By the time STEINER became a Beretta holding com-pany it was inevitable for us to meet our customers’ wish for the established STEINER-values to be applied on a range of professional scopes for Law Enforcement and the Military.

Bundling of Expertise

Our binocular specialists are working on transfering their outstanding knowledge in optics and the consis-tent focus on military purposes from the field of

binocu-lars to the field of scopes. The Know-how of the Beretta arms specialists was combined with the interaction with international experts, that can base their wealth of experience concerning the development of scopes on leading scope manufacturers.

Developed for military purposes

The STEINER Military Scopes were especially devel-oped for the tough requirements of military missons around the world. In close cooperation with special

forces and international weaponry experts we will keep on improving the range of scopes that will successfully represent the pride of STEINER.

The unique STEINER-class

As a result we will present a range of scopes that displays a new class in terms of performance, quality and reliability. The best price-performance ratio is of course guaranteed and is just what you expect to when it comes to STEINER products.

(3)

TELESCOPIC SIGHT:

MILITARY 1-4x24 mm

The STEINER Telescopic Sight Military 1-4x24 mm is the perfect optic for assault weapons and CQB engage-ments. With a true 1x magnification, the user can easily shoot with both eyes open for better situational aware-ness. The ballistic reticle was specially developed for both accurate ranging and quick target recognition. Advantages

Broad band Anti Reflection coated optic guarantee a maximum light transmission of greater than 90 %. 4x zoom factor provides a scope which has both a

wide field of view at low power plus the ability to zoom up and bring far objects into clear focus.

A rugged 30 mm compact 1-pc main tube construction. Integrated rotary side focus and digital illumination system knobs mounted on the turret for comfort and ease of use with or without gloves on.

11 Illumination steps (7 Night & 4 Day) with two off-posi-tions at each end, plus 10 standby (light-off) settings. Reticle in the second focal plane.

Illuminated, glass etched STEINER Rapid DOT 308. Fully waterproof to 10 meters.

Shock proof to 900 G’s.

Nitrogen filled to be fog proof inside.

Aircraft grade machined aluminum knobs for positive grip and durability in all conditions.

Magnification 1x – 4x Tube Diameter 30 mm Elevation Adjustment Knob Resettable to Zero with Wrench

Objective Size 24 mm Focal Plane Location Second focal plane Visual & Tactile Indication of Turns

Magnification Change 4x Reticle STEINER Rapid DOT 308 Elevation Range @ 100 m 93 cm (9.3 mils) Field of View @ 100 m _{≥ 37,6 – 9,09 m} Illumination Rotary Digital Control Windage Adjustment Increment 1 cm (0.10 mrad) Exit Pupil 11,5 – 6,0 mm Operating Temperature -25 °C / +63 °C Windage Range @ 100 m ± 46 cm (4.6 mils) Eye Relief 85 – 95 mm Storage Temperature -35 °C / +70 °C Parallax (Focus) Adjustment Knob

Twilight Factor 3,4 – 9,8 Weight with caps (without caps) 630 g (600 g) Parallax (Focus) Adjustment no, at 100 m fix

Battery CR 2450 Length 290 mm (at 0 diopter) Item No. 8705090001

(4)

6

TELESCOPIC SIGHT:

MILITARY 4-16x50 mm

The STEINER Telescopic Sight Military 4-16x50 mm is made for locating, identifying and engaging targets at long distances. Outstanding optical excellence com-bined with extreme ruggedness ensure brilliant perfor-mance that tactical shooters can rely on.

Advantages

A rugged 34 mm compact 1-pc main tube construction.

Integrated rotary knob system with digital illumination and parallax adjustment combined in left side turret for comfort and ease of use with or without gloves on.

11 Illumination steps (7 Night & 4 Day) with two off-posi-tions at each end, plus 10 standby (light-off) settings. Front focal plane, so sub-tension remains unchanged

over the magnification range for quick and easy target identification and accuracy. Illuminated, glass etched Mil-Dot reticle. Fully waterproof to 5 meters.

Objective Size 50 mm Focal Plane Location First focal plane Visual & Tactile Indication of Turns

Magnification Change 4x Reticle G2B Mil-Dot * Elevation Range @ 100 m 195 cm (19.5 mils) Field of View @ 100 m _{≥ 8,7 – 2,4 m} Illumination Rotary Digital Control Windage Adjustment Increment 1 cm (0.10 mrad) Exit Pupil 12,5 – 3,1 mm Operating Temperature -25 °C / +63 °C Windage Range @ 100 m ± 47 cm (4.7 mils) Eye Relief 77 – 90 mm Storage Temperature -35 °C / +70 °C Parallax (Focus) Adjustment Knob Side mounted, Rotary Twilight Factor 14,1 – 28,3 Weight with caps (without caps) 995 g (965 g) Parallax (Focus) Adjustment 50 m to Infinity

(5)

TELESCOPIC SIGHT:

MILITARY 3-12x56 mm

The STEINER Telescopic Sight Military 3-12x56 mm provides the same ruggedness and reliability as the 3-12x50, but offers increased performance in low light conditions. The 56 mm objective lens provides extra light transmission in all conditions and situations. Advantages

Broad band Anti Reflection coated optic guarantee a maximum light transmission of greater than 90 %. 56 mm objective for ultimate visibility even in lowest

light conditions.

4x zoom factor provides a scope which has both a wide field of view at low power plus the ability to zoom up and bring far objects into clear focus.

Fully waterproof to 5 meters. Shock proof to 900 G’s.

Integrated rotary knob system with digital illumination and parallax adjustment combined in left side turret for comfort and ease of use with or without gloves on. A rugged 34 mm compact 1-pc main tube construction. 11 Illumination steps (7 Night & 4 Day) with two

off-po-sitions at each end, plus 10 standby (light-off) settings. Front focal plane, so sub-tension remains unchanged

over the magnification range for quick and easy target identification and accuracy. Nitrogen filled to be fog proof inside.

Magnification 3x – 12x Focal Plane Location First focal plane Elevation Range @ 100 m 195 cm (19.5 mils) Objective Size 56 mm Reticle G2B Mil-Dot * Windage Adjustment Increment 1 cm (0.10 mrad) Magnification Change 4x Illumination Rotary Digital Control Windage Range @ 100 m ± 47 cm (4.7 mils)

Field of View @ 100 m ≥ 10,9 – 2,9 m Operating Temperature -25 °C / +63 °C Parallax (Focus) Adjustment Knob Side mounted, Rotary Exit Pupil 13,0 – 4,5 mm Storage Temperature -35 °C / +70 °C Parallax (Focus) Adjustment 50 m to Infinity Eye Relief 77 – 96 mm Weight with caps (without caps) 1035 g (1005 g) Item No. 8703090001 Twilight Factor 11,5 – 25,9 Length 395 mm (at 0 diopter)

Battery CR 2450 Elevation Adjustment Knob Resettable to Zero with Wrench

Diopter Setting +2 to -3 diopters Visual & Tactile Indication of Turns

Tube Diameter 34 mm Elevation Adjustment Increment 1 cm (0.10 mrad) * Other reticles available per special request.

TELESCOPIC SIGHT:

MILITARY 3-12x50 mm

The STEINER Telescopic Sight Military 3-12x50 mm is the ideal choice for multiple tactical scenarios. Professional ruggedness and precise and well thought-out controls al-low successful deployment under all weather conditions. Advantages

Integrated rotary knob system with digital illumination and parallax adjustment combined in left side turret for comfort and ease of use with or without gloves on.

11 Illumination steps (7 Night & 4 Day) with two off-po-sitions at each end, plus 10 standby (light-off) settings. Front focal plane, so sub-tension remains unchanged

over the magnification range for quick and easy target identification and accuracy. Illuminated, glass etched Mil-Dot reticle. Fully waterproof to 5 meters.

Magnification 3x – 12x Focal Plane Location First focal plane Elevation Range @ 100 m 195 cm (19.5 mils) Objective Size 50 mm Reticle G2B Mil-Dot * Windage Adjustment Increment 1 cm (0.10 mrad) Magnification Change 4x Illumination Rotary Digital Control Windage Range @ 100 m ± 47 cm (4.7 mils)

Field of View @ 100 m

_≥

10,9 – 2,9 m Operating Temperature -25 °C / +63 °C Parallax (Focus) Adjustment Knob Side mounted, Rotary Exit Pupil 13,0 – 4,5 mm Storage Temperature -35 °C / +70 °C Parallax (Focus) Adjustment 50 m to Infinity Eye Relief 77 – 96 mm Weight with caps (without caps) 980 g (950 g) Item No. 8702090001 Twilight Factor 11,6 – 24,5 Length 395 mm (at 0 diopter)

Battery CR 2450 Elevation Adjustment Knob Resettable to Zero with Wrench

Diopter Setting +2 to -3 diopters Visual & Tactile Indication of Turns

(6)

10

TELESCOPIC SIGHT:

MILITARY 5-25x56 mm

The STEINER Telescopic Sight Military 5-25x56 mm is a scope with an extremely high magnification, designed for use on long range tactical and sniper rifles. High magni-fication and elevation travel allow to extend the practical shooting range beyond 1,500 meters. The 5x zoom makes it extremely versatile, while the large 56 mm objective pro-vides outstanding visibility even in lowest light conditions. Advantages

Broad band Anti Reflection coated optic guarantee a maximum light transmission of greater than 90 %. 5x zoom erectors offer higher flexibility with both a wide

field of view at low power plus the ability to zoom up and bring far objects into clear focus extended elevation travel for precise targeting beyond 1,500 m.

Integrated rotary knob system with digital illumination and parallax adjustment combined in left side turret for

comfort and ease of use with or without gloves on. 11 Illumination steps (7 Night & 4 Day) with two off-posi-tions at each end, plus 10 standby (light-off) settings. Front focal plane, so sub-tension remains unchanged

over the magnification range for quick and easy target identification and accuracy.

Illuminated, glass etched Mil-Dot reticle. Fully waterproof to 10 meters.

Aircraft grade machined aluminum knobs for positive grip and durability in all conditions. Manufactured in Germany.

Objective Size 56 mm Focal Plane Location First focal plane Visual & Tactile Indication of Turns

Magnification Change 5x Reticle G2B Mil-Dot * Elevation Range @ 100 m 260 cm (26.0 mils) Field of View @ 100 m _{≥ 7,23 – 1,43 m} Illumination Rotary Digital Control Windage Adjustment Increment 1 cm (0.10 mrad) Exit Pupil 9,80 – 2,24 mm Operating Temperature -25 °C / +63 °C Windage Range @ 100 m ± 60 cm (6.0 mils) Eye Relief 90 mm Storage Temperature -35 °C / +70 °C Parallax (Focus) Adjustment Knob Side mounted, Rotary Twilight Factor 15,65 – 37,4 Weight with caps (without caps) _{≤ 1030 g (1000 g)} Parallax (Focus) Adjustment 50 m to Infinity

(7)
